Full mesh on the front panel
Supports a 240mm liquid cooling radiator or two
120mm fans on the right side / at the top
Supports a 120mm liquid cooling radiator in the rear
Includes two SickleFlow 120 fans arranged for
optimum airflow with support for up to 8 fans
Can install one optional 120/140mm fan on the left
side panel to cool the graphics cards
Supports high-end graphics cards up to 320mm /
12.6 inch, including NVIDIA GTX 690 & AMD HD
7990
Super Speed USB 3.0 support
Supports up to 8 HDDs (2 tool-less)
Dust filter under the PSU for easy maintenance
Accessible power switch button with blue LED
illuminated when the power is on
Available Color
Midnight Black
Materials
Polymer, mesh front bezel
Dimensions
190 x 426 x 491.5 mm / 7.5 x 16.7 x 19.3 inch
(W x H x D)
Net Weight
5.2 kg / 11.5 lbs
M/B Type
microATX, ATX
5.25" Drive Bays
2 (exposed)
3.5" Drive Bays
1 (exposed), 7 (hidden)
2.5" Drive Bays
1 (hidden)
I/O Panel
USB 3.0 x 1 (int.), USB 2.0 x 2, Mic x 1,
Audio x 1 (supports AC97 / HD Audio)
Expansion Slots
7
Cooling System
Top: 120mm fan x 2 (optional)
Front: 120mm fan x 2 (one SickleFlow fan
installed, one optional);
or 140mm fan x 1 (optional)
Rear: 120mm SickleFlow fan x 1 (installed)
Left side: 120/140mm fan x 1 (optional)
Right side: 120mm fan x 2 (optional)
Power Supply
Standard ATX PS2 (optional)
Maximum
Compatibility
VGA card length: 320 mm / 12.6 inch
CPU cooler height: 164mm / 6.4 inch
EAN Code
KKN1: 4719512043134
KKN1-JP: 4719512043417
UPC Code
884102022302
Carton Size
(L x W x H)
518 x 280 x 580mm
(20.4x 11.0 x 22.8 inch)
Pallet Size
(L x W x H)
1120 x 1040 x120mm
(44.1 x 40.9 x 4.7 inch)
Container
w/ pallet
carton/pallet
w/o pallet
20’
340
34
412
40’
714
34
864
40’ HQ
840
40
956
N300
NSE-300-KKN1
2 years
Features
Specifications
Package Information
Warranty
Mesh Front Panel & Large Vents
Supports two 120mm fans on the right side
Supports 240mm radiator on the right side
Supports 240mm radiator at the top
Supports 120mm radiator in the rear;
Enlarged top vents
Supports long graphics cards
up to 320mm / 12.6 inch
Appendix
Photo taken: 2013/2/21
320mm/ 12.6 inch
*Photos may slightly differ from the final product
