Page 1
ASSEMBLY GUIDE
MARKET UMBRELLA
MYRTLE / GREVILLEA
5Y R
Warranty
A
G
A
I
N
S
T
U
V
D
E
G
R
A
D
A
T
I
O
N
5
Y
E
A
R
F
A
B
R
I
C
W
A
R
R
A
N
T
Y
Page 2
3.3m/10'10" 2 x 3m/6'7" x 9'10"
2.72m/8'11" 2.2m/7'2" 2.72m/8'11" 2.3m/7'3"
MYRTLE
GREVILLEA
Page 3
a) Umbrella frame with canopy x 1
b) Lower pole x 1
c) Finial x 1
STEP 1
Take all parts out of the box and
ensure they are all present.
STEP 2
Screw the nial into the pre-drilled hole
at the top of the canopy. Ensure nial is
secure, do not overtighten.
a
b
c
ASSEMBLY GUIDE
Page 4
STEP 3
To assemble the umbrella, screw the top
pole into the bottom pole until secure.
STEP 4
To open the umbrella, pull the cord down
until the canopy is up past the pin hole, place
the stop pin into the desired hole to hold the
umbrella in place.
To close the umbrella, remove the stop pin
and lower the canopy down, making sure you
keep hold of the pulley cord whilst doing so.
STEP 5
You can tilt the umbrella by pressing
the tilt button. Hold onto the top
section of the pole as you do this.
Ensure canopy is closed when not in use. Close in windy conditions or when a storm approaches.
Never allow the umbrella to ap in the wind; this could damage the canopy.
Page 5
Exposure to ultraviolet (UV) radiation from the sun is the
major cause of skin cancer. In some countries the UV radiation
is strong enough to cause sunburn in just 11 minutes on a
ne summers day. To prevent sun damage we recommend
following the Sun Smart steps: slip on clothing, slop on
sunscreen, slap on a hat, slide on sunglasses and seek shade.
Attention: The schematics in this manual are for assembly and operation
illustration only. They may dier from the umbrella’s actual appearance.
We recommend that you insert the umbrella into an umbrella base or table
(not included) to help secure the umbrella.
THANK YOU
FOR PURCHASING A
COOLAROO PRODUCT
When not in use, close the umbrella, place a protective
cover over it and store in a dry place.
If canopy is wet, allow to dry naturally opened up before storing.
If necessary, clean the fabric with a hose.
Components subject to turning and sliding can be treated
with a non-staining lubricant spray (silicon-based).
Store in a dry place when not in use.
CARE & MAINTENANCE
To register your product go to coolaroo.com.au. The product code can be found
printed above the barcode on the product packaging, alternatively you can nd it
on the relevant coolaroo.com.au product page.
For help with product assembly
or for any other questions
you may have, contact our
Customer Service Department.
Page 6
A
G
A
I
N
5
Y
E
WARNING
When assembling and using this product, safety precautions should always be followed to reduce the
risk of personal injury and damage to equipment. Please read all instructions before assembly and use.
At least two or more people are recommended for safe assembly.
Keep all children and pets away from assembly area.
Install on level ground.
Check all nuts and bolts for tightness before and during usage.
Close the umbrella in windy conditions or when a storm approaches. Never allow the umbrella
to ap in the wind; this could damage the canopy.
Do not leave the umbrella open unattended.
Do not place the product near an open ame; or too close to any heat source.
The best under the sun
Coolaroo is the leader in shade fabric technology.
Our extensive range of attractive shade solutions
is carefully manufactured to protect your home,
garden and family from the harsh sun.
coolaroo.com.au
For help with product assembly
or for any other questions
you may have, contact our
Customer Service Department.
Australia Toll Free: 1800 331 521
New Zealand Toll Free: 0800 555 171
United States Ph: +1 407 772 7900
Middle East Ph: +971 4 881 7114
China Ph: +86 574 5626 8888
Gale Pacic Limited
145 Woodlands Drive,
Braeside, Victoria, 3195 Australia
Coolaroo is a registered trademark
of Gale Pacic Limited
430498 / 1505
