Coolaroo Cabana Assembly Manual

ASSEMBLY GUIDE

GAZEBO

CABANA

5YR

Warranty

A

G

A

I

N

S

T

U

V

D

E

G

R

A

D

A

T

I

O

N

5

Y

E

A

R

F

A

B

R

I

C

W

A

R

A

N

T

Y

STEP 1

Take all parts out of the box

and ensure they are all present.

a) Common pole x 14

b) Centre pole x 3

c) Lower leg pole x 4

d) Right plastic moulded corner x 2

e) Centre plastic moulded corner x 2

f)

g) Metal peg x 4

h) Fabric cover x 1

3.35m/11'

2.06m/6'9"

3.65m/12'

CABANA

a

d

g

b

e

c

f

h

ASSEMBLY GUIDE

STEP 2

Connect four common poles (a) to plastic

moulded corners (d), (e) and (f) as shown

in diagram to form gazebo roof ends.

d

a

e

a

STEP 3

Connect six common poles (a) to centre poles (b) and

use to connect gazebo roof ends as shown in diagram.

b

a

f

STEP 4

Connect the remaining four

common poles (a) to lower leg

poles (c) and connect to

completed roof frame

as shown in diagram.

STEP 6

The height of the back of the canopy can be

adjusted by removing the lower leg poles at

the back. Secure the cover to the bottom

of the upper leg poles with hooks and use

metal pegs to secure to the ground.

STEP 5

Place the fabric cover (h) over the gazebo

frame and secure with metal hooks into

desired hole at the bottom of pole (c).

Then use the metal pegs to secure each

corner of the cover to the ground.

a

c

d

a

c

a

f

Ensure gazebo is closed when not in use. Dismantle before strong storms approach. Never allow to ap in the wind; this could damage the canopy.

A

G

A

I

N

5

Y

E

For help with product assembly or for any other questions you may have, contact our Customer Service Department.

Australia Toll Free: 1800 331 521 New Zealand Toll Free: 0800 555 171 United States Ph: +1 407 772 7900 Middle East Ph: +971 4 881 7114 China Ph: +86 574 5626 8888

The best under the sun

Coolaroo is the leader in shade fabric technology. Our extensive range of attractive shade solutions

is carefully manufactured to protect your home,

garden and family from the harsh sun.

coolaroo.com.au

Gale Pacic Limited 145 Woodlands Drive, Braeside, Victoria, 3195 Australia

Coolaroo is a registered trademark of Gale Pacic Limited

WARNING

When assembling and using this product, safety precautions should always be followed to reduce the risk of personal injury and damage to equipment. Please read all instructions before assembly and use.

At least two or more people are recommended for safe assembly.

Keep all children and pets away from assembly area.

Install on level ground.

Check all connections for tightness before and regularly during use.

Do not leave the gazebo open unattended for long periods of time.

Do not place the product near an open ame; or too close to any heat source.

430556 / 1505

Exposure to ultraviolet (UV) radiation from the sun is the

major cause of skin cancer. In some countries the UV radiation

is strong enough to cause sunburn in just 11 minutes on a

ne summers day. To prevent sun damage we recommend

following the Sun Smart steps: slip on clothing, slop on

sunscreen, slap on a hat, slide on sunglasses and seek shade.

THANK YOU

FOR PURCHASING A

COOLAROO PRODUCT

When not in use, dismantle the gazebo,

place in bag and store in a dry place.

If the cover is wet, allow to dry naturally

opened up before storing.

If necessary, clean the fabric with a hose.

Components subject to turning and sliding can be treated

with a non-staining lubricant spray (silicon-based).

CARE & MAINTENANCE

To register your product go to coolaroo.com.au. The product code can be found printed above the barcode on the product packaging, alternatively you can nd

it on the relevant coolaroo.com.au product page.
