Cookworks EHS15AP-P Instruction manual

Breadmaker

Model No. EHS15AP-P

Care & Instruction Manual

For household and indoor use only

Please read these instructions before use and retain for

future reference

ISSUE-1 26/10/2017 1

Electrical safety
 You should only plug the appliance into a 220V‐240V AC, 50Hz

supply. Connecting it to other power sources may damage the
appliance and will invalidate the guarantee.

 Switch off and unplug when not in use and before cleaning the

appliance.

 Keep the appliance and its cord out of reach of children less than

8 years.

 Do not allow children to use the appliance without supervision.
 This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they are older
than 8 and supervised.

 Keep cooker housing, cable, and plug dry and away from areas

where it is likely to get splashed. Never immerse in water.

 Do not pull on the cable to disconnect from the mains supply.
 Do not operate the appliance if damaged or after it malfunctions.

In the event the supply cord is damaged, in order to avoid a
hazard it must only be replaced by a qualified service engineer,
with a suitably approved part.

 This appliance must be positioned so that the plug is accessible

and the plug socket is within easy reach of the power cord.

 This appliance must be plugged in to an earthed socket outlet.

ISSUE-1 26/10/2017 2

Warning!
 This appliance is intended exclusively for use in domestic

households. It is not suitable for commercial use.

 The surfaces of the breadmaker will become hot during use. Do

not touch; wear oven gloves when handling the appliance during
and immediately after use. Note the heating element is subject
to residual heat after use.

 Do not use the breadmaker on, near or under surfaces that are

heat sensitive or those that may be damaged by steam.

 Do not operate the breadmaker using a timer or separate remote

control.

 Do not cover and allow the breadmaker to cool completely before

storing.

 Only use with the parts supplied and use only for the intended

purposes detailed in this manual.

ISSUE-1 26/10/2017 3

Parts



1. Lid

2. Bread pan (removable)

3. Display

4. Control panel

ISSUE-1 26/10/2017 4

5. Measuring cup

6. Measuring spoon

7. Kneading blade

8. Housing

Control Panel

Menu Used to select the program of choice. The program

number selected will be shown in the top left corner of
the display.

Color Used to select crust colour of the loaf being baked. A

small arrow will illuminate on the left side of the
display next to the crust colour selected. Option
available for programs 1–7 only.

Loaf Used to select the size of the loaf to be baked. A

small arrow will illuminate on the right side of the
display next to the loaf size selected. Option available
for programs 1–6 only.

Time / This function allows the bread maker start time to be

programmed up to 13 hours in advance of when the
bread is wanted.

ISSUE-1 26/10/2017 5

Available programs

1. Basic – Kneads, rises and bakes bread. Program permits
additional ingredients to be added.

2. French – Kneads, rises and bakes bread. Program has a
longer rise time, the crust will be crisper and the
bread should be lighter in texture than the basic
program.

3. W. wheat Kneads, rises and bakes whole wheat bread. This
program has a longer preheat time to allow the
grain to soak up the water and expand. The use of
the delay start option with this program is not
recommended.

4. Quick - Kneads, rises and bakes bread using baking powder
or baking soda as the raising agent. Bread made
using this program is usually smaller and has a
denser texture than breads baked with yeast.

5. Sweet - Kneads, rises and bakes sweet breads. Because of
the longer rising phase the bread will be light and
airy.

6. Ultra fast - Kneads, rises and bakes in the quickest time.
Bread baked using this program is usually smaller
and denser in texture than other programs and the
mix requires hot water (40 - 45°C) to be added.

7. Dessert – Mixes and bakes dessert recipes.

8. Pasta – Mixes and kneads dough used for pasta and
noodles. This program does not have a rise or
baking option.

9. Dough – Kneads and rises but does not bake the dough.
Permits the dough to be removed and used or
shaped into bread rolls, pizza bases, steamed
bread etc.

10. Jam – Boils jams and marmalades.

11. Cake – Mixes and bakes cakes. This program does not
have a rise option.

12. Bake – Baking only option. This program bakes at a
temperature of 180°C and can be used for baking
cakes or to extend baking time of program being
used after the program has ended.

ISSUE-1 26/10/2017 6

Before first use

1. Wash the bread pan, kneading blade, measuring cup and

spoon as described in the cleaning section of these
instructions.

2. Place the bread maker on a stable, flat heat resistant surface

in a well-ventilated area. Position away from the edge of the
surface as some slight movement may occur during the
kneading process.

3. Fit the bread pan and turn the pan clockwise to lock into

position.

4. Fit the kneading blade to the spindle in the bread pan.

5. Close the lid gently, plug in and switch on at the mains. A

single bleep will be heard.

6. Press the START / STOP button to start the bread maker

working and allow it to operate for 10 minutes. During first
operation a slight burning smell maybe noticed and some
fumes may be given off. This is normal and is some of the
processing oils used in the manufacture of the bread maker
being burnt off.

7. After 10 minutes, press and hold the START / STOP button for

2-3 seconds to stop the bread maker operating. A bleep will
be heard to confirm that the program has been switched off.

8. Switch off at the mains and unplug.

9. When the bread maker has cooled, twist the bread pan

anticlockwise to release, lift out and wash the pan and
kneading blade again.

10. The bread maker is now ready to be used.

ISSUE-1 26/10/2017 7

Basic operation

1. Place the bread maker away from the edge on a stable, flat

heat resistant surface and clean thoroughly before use.

2. Fit the kneading blade to the spindle in the bread pan.

3. Place the ingredients into the bread pan following the

quantities and order shown in the recipes provided.

4. Fit the bread pan and turn clockwise to lock into position.

5. Close the lid gently, plug in and switch on at the mains. A

single bleep will be heard. Do not allow the cable to dangle
over the edge of units.

6. Press the MENU button until the desired program is displayed.

The program number is displayed above the time in the
display.

7. Press the COLOR button and select the desired crust colour

(light, medium or dark). A small arrowhead next to the
description in the display indicates the colour selected. This
operates in programs 1-7, 11 & 12 only)

8. Press the LOAF button and select the loaf size (small or large)

corresponding to the recipe chosen (programs 1-6 only). A
small arrowhead underneath the description in the display
indicates the size selected.

9. Press the START/STOP button to start the bread maker

working.

10. If using the BASIC, FRENCH, WHOLEWHEAT, QUICK, SWEET

and ULTRAFAST programs a series of bleeps will be heard
part way through the cycle to prompt the addition of
ingredients such as fruit, nuts etc. where specified in the
recipes. Lift the lid, and add the ingredients to the bread pan.

11. When the program cycle is complete, 10 bleeps will be heard.

12. Press the START / STOP button for 2-3 seconds to stop the

bread maker. Switch off at the mains and unplug.

13. Wearing oven gloves, lift the lid, twist the bread pan

anticlockwise to release the pan and lift the bread pan out of
the bread maker.

14. Place the bread pan on a heatproof surface before turning the

pan upside down over a clean wire rack and shaking the pan
gently until the loaf drops out. If necessary use a non-stick
spatula to gently loosen the loaf from the sides of the pan.

ISSUE-1 26/10/2017 8

15. Allow the loaf to cool for a minimum of 20 minutes before

slicing. Before slicing check that the kneading blade is not
still in the loaf.

Notes
 This bread maker is suitable for recipes with a maximum of

400g flour (approx 2.5 cups) and a maximum of 8g
fermentation agent

 If the START / STOP button is not pressed at the end of the

program, the bread will be kept warm for one hour. After one
hour the bread maker will automatically switch off.

 The program can be stopped at any time by pressing and

holding the START / STOP button for 2-3 seconds.

 To prevent accidental disruption of operation, after the

START/STOP has been pressed all buttons are inactive except
the START/STOP button.

 If the power supply is interrupted (e.g. in the event of a power

cut) the bread making process will automatically continue if
the outage is less than 10 minutes. If the outage is greater
than 10 minutes, the bread maker must be restarted. If the
process has not passed the kneading phase then the
START/STOP button maybe pressed to restart the program
from the beginning.

Delayed start

This function allows the start time to be programmed up to 13
hours in advance of when the bread is wanted.

1. Select the program, bread size, crust colour as usual.

2. Press the TIME  button to increase the time shown in the

display until the required time is shown. Each press of the
button increments the display time by 10 minutes. If an error
has been made the time can be adjusted down using the TIME
 button.
 For example if it is 8:30 pm (20:30 hrs) and the bread is

required at 7am (07:00hrs) the next morning (10 ½ hours
later) the time in the display should be set to 10:30.

3. Press the START / STOP button, the timer will start to count

down and the bread maker will start baking the bread when
the clock reaches the appropriate time for the baking cycle
selected.

ISSUE-1 26/10/2017 9

Tips for making successful bread
 After adding the flour to the bread pan make a small well in

the flour with a finger or spoon and add the yeast into the well.

 Do not permit the yeast to come in direct contact with salt as

this will kill the yeast and prevent the loaf from rising.

 Always measure the ingredients accurately.

 When measuring liquids use the

measuring cup, place the cup on a
flat surface and bring the eyes
level with the level of the liquid
when checking the reading.

 If using the measuring spoon to

measure powders, do not
compress the powder and draw a
straight edge (e.g. knife blade)
across the top of the measuring
spoon to level the surface.

 Add the ingredients in the sequence shown in the recipe.

Typically liquid ingredients, eggs, salt, milk powder, sugar are
added first and these are then followed by the flour and lastly
the yeast or baking powder. Fruit ingredients are usually
added later in the program cycle to preserve their more
delicate flavours. In some instances with heavy dough (high
rye or whole wheat flours) this order is reversed to ensure
better kneading.

 Ensure liquid ingredients are between 20 – 25°C unless

otherwise advised by the recipe.

ISSUE-1 26/10/2017 10
