Control Products PS16 User Manual

®

TITAN

®

TITAN

Fabricated

D

ØA

ØB

H

C

ØA

ØB

H

C

Temporary Strainers

TITAN FLOW CONTROL, INC.

Titan Flow Control, Inc

Cone Type Basket Type

Model Class

PS15 150/300
PS15 600
PS15 900
PS15 1500

Temporary Strainers are fabricated in the Titan FCI factory, so they

can be made to meet your unique specications! Listed are standard

models and dimensions. Contact factory for more information.

(3)

C

Gauge

Thickness

Basket Type

Tel: [phone]

L=100% L=150% L=200% L=300% L=100% L=150% L=200% L=300%

290 Corporate Drive

ANSI

300

Cone Type

ØA (OD)

ANSI

600

ANSI

900

ANSI

1500

ØB

(ID)

Nominal

Pipe

Size

3

1 1/

2 4.00 4.25 4.25 5.50 5.50 1.75 11 4.00 6.00 8.00 11.00 2.50 3.00 4.00 6.00 1.00

2 1/

3 5.25 5.75 5.75 6.50 6.75 2.75 11 5.00 7.00 9.00 13.00 3.00 4.50 6.00 8.00 1.50

4 6.75 7.00 7.50 8.00 8.13 3.75 11 8.00 10.00 12.00 18.00 4.00 5.00 7.00 11.00 2.00

5 7.63 8.38 9.38 9.63 9.88 4.63 11 8.00 11.00 14.00 22.00 4.50 7.00 9.00 14.00 2.50

6 8.63 9.75 10.38 11.25 11.00 5.38 11 9.00 13.00 18.00 25.00 5.50 8.00 11.00 17.00 3.00

8 10.88 12.00 12.50 14.00 13.75 7.38 11 12.00 17.00 23.00 33.00 7.00 11.00 14.00 21.00 4.00

10 13.25 14.13 15.63 17.00 17.00 9.38 11 14.00 21.00 28.00 41.00 8.00 13.00 17.00 26.00 5.00

12 16.00 16.50 17.88 19.50 20.38 11.00 11 16.00 25.00 34.00 49.00 10.00 15.00 20.00 31.00 6.00

14 17.38 19.00 19.00 20.38 22.63 12.25 11 18.00 27.00 36.00 53.00 10.00 16.00 22.00 33.00 7.00

16 20.13 21.13 21.88 22.50 C/F 14.00 11 21.00 31.00 40.00 61.00 12.00 19.00 24.00 37.00 8.00

18 21.25 23.38 23.75 25.00 C/F 15.75 11 24.00 35.00 46.00 68.00 14.00 21.00 27.00 41.00 9.00

20 23.50 25.63 26.63 C/F C/F 17.50 11 26.00 38.00 51.00 76.00 16.00 24.00 31.00 48.00 10.00

24 27.88 30.38 30.88 C/F C/F 21.25 11 31.00 45.00 61.00 90.00 18.00 28.00 37.00 57.00 12.00

1. Dimensions for Titan's PS 15 and PS 16 are provided for reference only. When required, request certied drawings. All dimensions, except thickness are given in inches.

2. Larger sizes are available; please contact factory.

3. Gauge thickness is for ange thickness only. The standard gauge of strainer material ranges between 11 to
22, depending on hole size.

4. Dimension H, height of strainer, is dependant upon the open area of the strainer as dened in the table by L.
L, or the percentage of open area in the strainer relative to the cross section of pipe, is available in a range
of 100% to 300% (based on the perforated screens).

ANSI

(2)

150

/

2.13 C/F 2.50 2.63 2.63 0.63 11 C/F C/F C/F C/F C/F C/F C/F C/F 0.38

4

1 2.50 C/F 2.75 3.00 3.00 0.75 11 C/F C/F C/F C/F C/F C/F C/F C/F 0.50

3.25 3.63 3.63 3.75 3.75 1.25 11 3.50 4.50 6.00 9.00 2.00 2.50 3.50 5.00 0.75

2

4.75 5.00 5.00 6.38 6.38 2.25 11 4.00 6.00 8.00 11.00 2.50 3.00 4.50 6.00 1.25

2

Titan Flow Control, Inc

Model Class

PS16 150/300
PS16 600
PS16 900
PS16 1500

Dimensions and Technical Data

H (Cone Type, Height)

with 1/8” Perf. On 3/16” Centers

Uses

Temporary Cone and Basket Strainers are used for start up of new or revamped
piping systems. They are designed to provide inexpensive protection for costly valves,
pumps, meters, and other mechanical equipment.

Open Area

100% to 300%.

Materials

however, other materials are also available. Contact factory.

Perforation/Mesh

perforation, but most sizes/varieties are available. For mesh lined strainers, ow direction
must be specied.

Flanges

anges.

Handles

1" wide x 3" long.

Illustrations represent Titan FCI's Temporary Cone Strainer and Temporary Basket Strainer. Titan

FCI's fabricated products are made to each customer's unique specications. Dimensions, materials,
illustrations, and all other product details referenced in this literature are general in nature. Some
options may not be available in all sizes and/or models. Titan FCI reserves the right to make design
and specication changes to improve the products without prior notication. For exact product
specications, please consult the Titan FCI factory and request cer tied engineering documents.

f

Fax: [phone]

The available range in open area of strainer to cross section of pipe is

Standard temporary strainer materials are stainless steel and carbon steel;

Titan can manufacture anges to accommodate raised face or ring joint

Temporary Baskets and Cone Strainers have handles. Handles are generally

f

(4)

f

[e-mail]

PO Box 7408

H (Basket Type, Height)

with 1/8” Perf on 3/16” Centers

Diameter holes of 1/8" on 3/16" centers is the standard

f

f

Lumberton, NC 28358

www.titanfci.com

(4)

(1)

D

Bottom

Diameter

PS-0912
