Control4 C416AMP3 Users Manual

Disclaimer

Trademarks

Copyright

Contact Us

Control4® makes no representations or warranties with respect to this publication, and specifically disclaims any express or implied warra nties of merchantability or fitness for any particular purpose. Control4 reserves the right to make changes to any and all parts of this publication at any time, without any obligation to notify any person or entity of such changes.

Control4, EZ ID, and the Control4 logo are trademarks or registered trademarks of Control4 Corporation. Other product and company names mentioned in this document may be the trademarks or registered trademarks of their respective owners.

Copyright © 2004-2007 Control4. All rights reserved. No part of this publication may be reproduced, photocopied, stored on a retrieval system, or transmitted without the express written consent of the publisher.

Control4 Corporation 11734 S. Election Road Salt Lake City, UT 84020 USA http://www.control4.com

Multi Channel Amplifier - 16 Installation and User Guide

Part Number: 200-00038 Rev A Hardware Model Number: C4-16AMP3-B

Contents

Preface Important Information ....................................1

Graphical Symbols in this Guide............1

Graphical Symbols on the Device..........1

Safety Instructions .................................2

Additional Resources.............................3

Chapter 1 Introduction to Multi Channel Amplifier - 16...5

Features and Benefits............................5

Requirements ........................................6

What’s in the Box................ ... ... .... ... ... ...6

About the Multi Channel Amplifier .........6

Front View............................ .... .........6

Back View.........................................7

Chapter 2 Installing the Multi Channel Amplifier ............9

Plan Your Physical Layout...................10

Connect Audio Input Sources and

Speakers..............................................11

Connect to the Network and Power.....12

Set Up Logical Connections ................12

Set Network Settings ...........................13

Chapter 3 Using Multi Channel Amplifier .....................15

View Output Assignments......... .... ... ... .15

Manage Amplifier Output Zones..........17

View or Change Output Settings....17

View or Change Input Settings.......19

View Network Settings..................... ... .20

Set Display Preferences ......................20

Options Available in Composer ...........21

Chapter 4 Regulatory Compliance.............. ... ... .... ... ... .23

North America......................................23

iii

FCC Interference Statement...........23

Industry Canada Statement............23

Underwriters Laboratories Inc.........24

Recycling Information.....................24

Warranty.........................................24

Index.....................................................................................25

PREFACE

Important Information

Graphical Symbols in this Guide

Warning, Important, and Note paragraphs draw your attention to important safe practices and additional information which may help you avoid injury, death, or loss of material or time.

WARNING! This indicates a potentially hazardous

situation that, if not avoided, may result in death or serious injury. DO NOT IGNORE A WARNING!

IMPORTANT! This indicates information that will help

you avoid damage to your equipment, loss of materials, or loss of time. PAY ATTENTION TO THESE IMPORTANT STATEMENTS!

NOTE: This indicates a note on related information

about the current topic.

Graphical Symbols on the Device

The following information has been placed on the device:

Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus (including other amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or

grounding-type plug. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or

pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the

manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table

specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lighting storms or when

unused for long periods of time.

14. Refer all servicing to qualified service personnel.

Servicing is required when the apparatus have been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15. Do not install in a cabinet that is smaller than

20” wide x 20” deep x 12” high.

WARNING! Do not expose the apparatus to dripping or

splashing. Do not place objects filled with liquids near the apparatus.

WARNING! To reduce the risk of fire or electrical shock,

do not expose this apparatus to rain or moisture.

WARNING! Equipment must be connected to a Mains

socket outlet with a protective earthing connection.

WARNING! To reduce the risk of fire, do not install in a

cabinet that is smaller than 20” wide x 20” deep x 12” high. If you do, the device may overheat.

Additional Resources

The following resources are available:

` Your Control4-authorized reseller ` Control4 Web Site: http://www.control4.com/

CHAPTER

1 Introduction to Multi

Channel Amplifier - 16

Control4 systems are uniquely configured for every customer and every site. A popular component among music lovers is the Control4 Multi Channel Amplifier.

This chapter introduces the Control4 Multi Channel Amplifier - 16 and its features.

Features and Benefits

` Receives up to eight stereo inputs with full audio

switching on inputs.

` Outputs eight stereo class D amplified channels at

100 W per channel (not all driven simultaneously), or at 40 W peak per channel (all channels driven).

` Adjustable gain, treble, and bass for each zone ` Master Volume Control for all outputs ` Control4 EZ ID

connections easy to identify

` Device chassis is three standard rack spaces and

rack mountable configuring to EIA 19” rack standards. Its dimensions are 5.25” x 17” x 16”.

` Communicates via Ethernet 10/100 port and ZigBee

mesh networking (IEEE 802.15.4).

™

LEDs for every I/O to make

Requirements

` Ensure that your home network wiring is in place

before starting your system setup. The Multi Channel Amplifier can be controlled through Ethernet or through ZigBee mesh networking (IEEE 802.15.4).

` Device must not be installed in a cabinet that is

smaller than 20” wide x 20” deep x 12” high.

What’s in the Box

The following hardware and software is required and included in your Control4 Multi Channel Amplifier box.

` Control4 Multi Channel Amplifier - 16 ` IEC power cord ` This manual

About the Multi Channel Amplifier

Front View

1. Front Display—LCD for displaying or setting Multi Channel Amplifier settings and navigating system menus. The front display is used to view or modify audio source

Back View

routing and zone settings for gain, bass, and treble. The display also shows zone activity .

Buttons—Provides access to menu options

displayed on the LCD.

Select Dial—Rotate to scroll through list

items and options displayed on the LCD. Press to make selections.

1. Power Plug Port—For use with a standard

IEC equipment power cord. Use the supplied power cord or ensure the power cord you are using is at least 18 AWG or larger.

Ethernet Port—RJ-45 for a 10/100 BaseT

Ethernet connection

Audio Inputs 1-16 —RCA jacks for 8 stereo

analog sources, and their supporting light emitting diodes (LEDs) for EZ ID™ during setup

Amplifier Outputs 1-16—5-way binding post

pair for 8 stereo class D amplified channels, and their supporting LEDs for EZ ID™ during setup
