Contours Maxi-cosi, Nuna, Cybex User Manual

ContoursBaby.com

AIP006-R2 07/18

mWARNING

Your child’s safety depends on you. Proper infant car seat
adapter use cannot be assured unless you follow these
instructions. DO NOT USE THE INFANT CAR SEAT ADAPTER UNTIL
YOU READ AND UNDERSTAND THESE INSTRUCTIONS.

IMPORTANT SAFETY INFORMATION:

• NEVER leave child unattended.

• For double strollers, always place the car seat in the front
adapter before placing another in the back adapter.
When removing children, always remove the child’s car seat
in the back adapter rst before removing the child’s in the
front. Failure to do so may cause the stroller to become
unstable and tip.

• When using this product, to avoid serious injury from falling
or sliding out, infant must always be secured in the infant car
seat with the car seat harness. Refer to infant car seat
instructions for proper adjustment.

• Make sure the stroller is fully unfolded and the car

seat adapter is securely latched before attaching your
infant car seat. This prevents nger pinching and injuries

caused by stroller collapsing.

How to Use this adapter with your infant car seat

• To ensure your infant car seat is properly installed on the
stroller, make sure it is:

- Facing the person pushing the stroller.

- Tightly secured to the stroller.

• Only transport infants that are within the size and

weight limitations of your infant car seat, as described
in the instruction manual provided by the infant car
seat manufacturer.

2 ContoursBaby.com

• This adapter is compatible with Contours Bliss and the following
infant car seats:

-Maxi-Cosi® Mico® AP

-Maxi-Cosi® Mico® Nxt

-Nuna Pipa

-Nuna Pipa™ Lite

™

-Maxi-Cosi® Mico® Prezi

• This adapter is compatible with Contours Options (model ZT017)
and the following infant car seats:

-Maxi-Cosi® Mico® AP

-Nuna Pipa

™

-Maxi-Cosi® Mico® Nxt

-Maxi-Cosi® Mico® Prezi

• This adapter is compatible with Contours Options (model ZT019)
and the following infant car seats:

-Maxi-Cosi

-Maxi-Cosi® Mico® Prezi

-Maxi-Cosi® Mico® 30

-Maxi-Cosi® Mico® Max 30

-Nuna Pipa

®

Mico® AP

™

-Nuna Pipa™ Lite

-Cybex® Aton Q - Platinum

-Cybex® Aton 2 - Gold

-Cybex® Aton - Silver

• This adapter is compatible with Contours Options Elite (model
ZT015) and the following infant car seats:

-Maxi-Cosi® Mico® AP

-Maxi-Cosi® Mico® Nxt

-Maxi-Cosi® Mico® Prezi

-Nuna Pipa

™

• This adapter is compatible with Contours Options Elite (model
ZT018) and the following infant car seats:

-Maxi-Cosi® Mico® AP

-Maxi-Cosi® Mico® Prezi

-Maxi-Cosi® Mico® 30

-Maxi-Cosi® Mico® Max 30

-Nuna Pipa

™

-Nuna Pipa™ Lite

-Cybex® Aton Q - Platinum

-Cybex® Aton 2 - Gold

-Cybex® Aton - Silver

-Cybex® Cloud Q

• This adapter is compatible with Contours Curve and the following
infant car seats:

-Maxi-Cosi

-Nuna Pipa

-Nuna Pipa™ Lite

®

Mico® Prezi

™

-Cybex® Aton Q - Platinum

-Cybex® Aton 2 - Gold

-Cybex® Cloud Q

Maxi-Cosi®, Nuna®, and Cybex® are trademarks of their respective owners. They are not
associated with Kolcraft Enterprises, Inc. and no approval by them is to be implied.

888.226.4469 3

To Attach Infant Car Seat Adapters

1 2 3

1 Find the adapter marked “L”.

Align “L” adapter over Left frame hub as shown.

It is the left side as you are standing behind stroller.

NOTE: The adapters won't t properly if placed on the wrong
side.

2

Push “L” adapter down onto the left frame hub until the
button on the hub engages with the adapter. Pull up on the
“L” adapter to ensure it is securely attached.

3

Repeat Steps 1 and 2 for “R” adapter.

NOTE: To remove adapter, push button on frame hub in, then
lift the adapter up.

L

4 ContoursBaby.com

R

To Secure Infant Car Seats

2

If using on a double stroller, keep car seat handle up to avoid
interfering with other child.

1 Lock foot brake to keep stroller from rolling.

2 With one hand, grasp the infant car seat handle (in its

upright, carrying position). With your other hand, grasp
infant car seat near baby’s feet. Gently position the infant
car seat above infant car seat adapters so the baby faces the
stroller handle.

3 Lower the infant car seat receptors onto the adapters.
Push down rmly. Pull up on car seat to ensure
securely attached on both sides.

NOTE: If you are using this adapter on a tandem stroller, in
combination with our universal adapter (included with most
tandems), always put the universal adapter in the mount
position closest to the handle to avoid any interference
between the car seats.

3

it is

888.226.4469 5

To Remove Car Seats With Side Release

Levers

1 Grip the sides of the car seat and engage the levers /
buttons on each side of child seating area.

2 Carefully lift the car seat o the adapters.

NOTE: Do not try and remove the adapters and car seat
together.
