Foreword

Thank you very much for purchasing the PM10 Portable ECG Monitor.

This user manual introduces detail product information about its character, requirement,

structure, performance, specification, appropriate methods of transportation, installation, usage,

operation, repair, maintenance and storage, and safety measures of how to protect the operator and

product. Please read details in the following chapters.

Please read the user manual carefully before using the product and strictly follow its

regulations to operate. The user manual indicates the operations that users need to pay much

attention to, that may lead to abnormality, or may danger to the device or human body during using.

Our company will not response the security, reliability and performance for any abnormality or

device and human body damage caused by not following this user manual to use, maintain and

store, nor provide free service for any situations above.

We apologize for the content in the manual is subject to change according to product upgrades

without notice.

The product is reusable as a medical instrument.

War ning:

 The product is not a examination device applied in clinical medicine, and its results can not

serve as the basis for diagnosis, but can be used as a reference for patient to take further

medical treatment and reference for doctor to diagnose.

 The reliability depends on whether users are following the operation and maintenance in the

user manual or not.

 All servicing and future upgrade to the device must be carried out by personnel trained and

authorized by our company, and using the original fittings for maintenance.

This user manual contains proprietary information, which is protected by copyright. All rights

reserved. Reproduction, adaption or translation, for any part of the manual without prior written

permission, is prohibited.

Our company takes the responsibilities as follows:

1. To provide qualified products according to enterprise standard for users;

2. To provide services of installation, debugging and training according to the contract;

3. To provide one year warranty and product maintenance after warranty period according to

the contract;

4. To respond user’s requests in time.

II

Chapter 1 Notice

1.1 Generic notice

1) Do not use the device in locations subject to high temperatures or humidity. Use in the

temperature within 5 to 40˚C and humidity within 25% to 80%RH.

2) Do not wash the device with water.

3) Do not use or store the device in the following ambient conditions:

 Near fires or open flames
 Locations exposed to strong vibration
 Locations exposed to strong electromagnetic fields

4) Do not disinfect the device in autoclave or gas sterilizer.

5) Such as skin allergies or skin damage, do not use this device.

6) The device service lift is 3 years. Do not throw away the device and accessories when

they can't work. If the device needs to dispose, it should meet the local laws and

regulations requirement.

7) lay responsible organization must contact its local authorities to determine the proper

method of disposal of potentially bio hazardous parts and accessories.

1.2 Measurement notice

1) If your skin is dry, wipe them with disinfectant alcohol or electric salve to strengthen the

electric capability

2) You are better to comfortably sit, draw yourself up, begin to measure when the waveform

level off.

3) When measuring, the finger and chest electrodes should touch your skin exactly, roundly

and well.

1.3 Safety notice

1) No sampling in the battery-charging.

2) Lay the device in shady and cool environment when you are not going to use it for a long

period of time, and electrify per three months.

3) Do not use the device in the environment placed inflammables objects, such as anesthetic.

1.4 EMC notice

1) Please note the effect from EMC when using the device, because it can be influenced by

portable or movable high electromagnetic compatibility RF devices.

1
