Contec SPC-8450-LVA User Manual

Download
SBC Series
Single Board Computer Middle Size PCI with LAN, VGA, Audio
SPC-8450-LVA
User’s Manual
CONTEC CO.,LTD.

Check Your Package

Thank you for purchasing the CONTEC product. The product consists of the items listed below. Check, with the following list, that your package is complete. If you discover damaged or missing items, contact your retailer.
Product Configuration List
- Industrial PCI CPU board (SPC-8450-LVA) …1
- Product Guide …1
- IPC Precaution List ...1
- Driver disk utility *1 (CD-ROM) ...1
- IDE 80Ribbon Cable...1
- FDD Ribbon Cable...1
- Serial port(9pin D-SUB male x 2) ribbon cable(with bracket) ...1
- Parallel port(25pin D-SUB female x 1) ribbon cable(with bracket) ...1
- Audio jack cable(with bracket)...1
- 6 pin mini-DIN cable (2 in 1 for PS2 Mouse & Keyboard functions)
- DVI-Analog RGB conversion adapter...1
- +12V power supply cable...1
- Jumper short pin...5
*1 The CD-ROM contains the driver software and User’s Manual (this Manual)
CPU board
[SPC-8450-LVA]
Driver disk utility
[CD-ROM]
IDE 80 Ribbon Cable
Parallel cable Audio jack cable
Floppy Ribbon Cable
Product
Guide
Product Guide
IPC Precaution
List
IPC Precaution List
Serial cable
DVI-Analog RGB
Converter
+12V power supply cable
6 pin mini-D IN cable (2 in 1 for PS2 Mouse
& Keyboard functions)
x 5
Jumper Short Pin
(2.0mm)
i

Copyright

Copyright 2005 CONTEC CO., LTD. ALL RIGHTS RESERVED. No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document. The information in this document is subject to change without notice.
All relevant issues have been considered in the preparation of this document. Should you notice an omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may appear in this document or for results obtained by the user as a result of using this product.

Trademarks

Intel, Celeron and Pentium are registered trademarks of Intel Corporation. Microsoft Windows is a registered trademark of Microsoft Corporation. All Other product names or trademarks are properties of their respective owners.

Caution about Battery

Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the local ordinances or regulations.
ii

Table of Contents

Check Your Package ................................................................................................................................i
Copyright.................................................................................................................................................ii
Trademarks ..............................................................................................................................................ii
Caution about Battery..............................................................................................................................ii
Table of Contents....................................................................................................................................iii
1. Introduction 1
About the SBC.........................................................................................................................................1
Features............................................................................................................................................. 1
Option List........................................................................................................................................1
Customer Support....................................................................................................................................2
Web Site............................................................................................................................................2
Limited One Year Warranty.................................................................................................................... 2
How to Obtain Service ............................................................................................................................2
Liability....................................................................................................................................................2
Safety Precautions ...................................................................................................................................3
Safety Information............................................................................................................................3
Handling Precautions .......................................................................................................................3
Environment .....................................................................................................................................4
Inspection..........................................................................................................................................4
Storage.............................................................................................................................................. 4
Disposal ............................................................................................................................................4
2. System Reference 5
Specifications........................................................................................................................................... 5
Power Requirements................................................................................................................................6
Connector & Jumper Location ................................................................................................................7
Block Diagram.........................................................................................................................................8
3. Hardware Installations 9
Installation procedure ..............................................................................................................................9
CPU Installation: ...................................................................................................................................10
Main Memory Installation: CN21 .........................................................................................................11
Serial Port Connector: CN1 , CN2 ........................................................................................................12
RS-422 / RS-485 specifications .....................................................................................................13
USB Connector: CN3, CN9 ..................................................................................................................14
DVI Connector: CN4.............................................................................................................................15
10/100BASE-TX LAN Connector: CN6 ..............................................................................................16
Keyboard / Mouse Connector: CN7...................................................................................................... 16
iii
External Keyboard Connector: CN8......................................................................................................17
Audio Connector: CN10 ........................................................................................................................17
CD-IN Connector: CN11 .......................................................................................................................17
External Battery Connector: CN12........................................................................................................17
Primary IDE Connector: CN13..............................................................................................................18
Floppy Disk Drive Connector: CN14....................................................................................................19
Parallel Port Connector: CN16 ..............................................................................................................20
Front Panel Connector: CN17................................................................................................................21
ATX power control Connector: CN18...................................................................................................22
DC Power supply connector: CN19.......................................................................................................23
+12V power supply Connector: PW1....................................................................................................23
FAN Connector: FAN1/FAN2...............................................................................................................23
4. Jumper Setting 25
RS-232C/422/485 Selector: JP1/JP8 .....................................................................................................25
RS-422 Setting................................................................................................................................26
RS-485 Setting................................................................................................................................26
RS-422/485 Terminator: JP7..........................................................................................................28
CF Master/Slave Selector: JP6...............................................................................................................29
ATX/AT Power supply select: JP9........................................................................................................29
Clear CMOS Content: JP10...................................................................................................................29
5. Board Resources 31
System Address Map .............................................................................................................................31
6. Watch-Dog-Timer (WDT) Setting 33
7. BIOS Setup 37
Introduction............................................................................................................................................37
Starting Setup..................................................................................................................................37
Using Setup.....................................................................................................................................37
Main Menu.............................................................................................................................................39
Standard CMOS Setup...........................................................................................................................40
Advanced BIOS Features Setup.............................................................................................................43
Advanced Chipset Features Setup .........................................................................................................47
Integrated Peripherals ............................................................................................................................51
Power Management Setup .....................................................................................................................57
PnP/PCI Configuration Setup ................................................................................................................62
PC Health Status ....................................................................................................................................65
iv
Frequency/Voltage Control ...................................................................................................................66
Defaults Menu ................................................................................................................................67
Supervisor/User Password Setting ........................................................................................................68
Exit Selecting......................................................................................................................................... 69
POST Messages.....................................................................................................................................69
POST Beep ............................................................................................................................................69
Error Messages ......................................................................................................................................70
POST Codes...........................................................................................................................................74
v
vi

1. Introduction

1. Introduction About the SBC
This product, which is equipped with an 845GV chip set, is a PCI bus compliant middle-sized single board computer that supports Pentium(R) 4, Celeron(R) and Celeron(R) D. It features all-in-one-design with a variety of interfaces including LAN, DVI-I, EIDE, USB2.0, serial, parallel and PS/2. This product is also equipped with a CF card slot (Type I/II), enabling boot-up from a CF card.
When connecting external devices or building the system, please read this manual carefully.

Features

- Compact PCI bus middle-sized board
- The corresponding CPU is as follows : Intel(R) Pentium(R) 4 Processor 1.7G - 2.8GHz(FSB400/533MHz)
Intel(R) Celeron(R) Processor 1.7G - 2.6GHz(FSB400MHz) Intel(R) Celeron(R) D Processor 2.26G - 2.8GHz(FSB533MHz)
- DDR SDRAM of up to 1GB can be mounted.
- Equipped with a CF card slot (Type I/II), enabling boot-up from a CF card.
- Equipped with DVI-I I/F, enabling connection with the CONTEC PanelLink type LCD display.
- Provides the AC97 compliant sound function.

Option List

CPU
- PCP4-28S Pentium 4 2.8GHz CPU with HeatSink-FAN *1
- PCP4C-20S Celeron 2.0GHz CPU with HeatSink-FAN *1
- PCP4-24 Pentium 4 2.4GHz CPU with HeatSink-FAN *2
- PCP4C-20 Celeron 2.0GHz CPU with HeatSink-FAN *2
*1 Since a heatsink-fan interferes to board, the next 4 slots can use only a PCI half size board(length of 120mm). *2 Since a heatsink-fan interferes to board, the next 3 slots can not use for board.
Memory
- PC-MDD256-200 200-Pin SO-DIMM DDR-Memory(PC2100, 256MB)
- PC-MDD512-200 200-Pin SO-DIMM DDR-Memory(PC2100, 512MB)
- PC-MDD1G-200 200-Pin SO-DIMM DDR-Memory(PC2100, 1GB)
CABLE
- USB Connector Cable USB connector shielded cable
1
1. Introduction

Customer Support

CONTEC provides the following support services for you to use CONTEC products more efficiently and comfortably.

Web Site

Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/
Latest product information CONTEC provides up-to-date information on products. CONTEC also provides product manuals and various technical documents in the PDF. Free download You can download updated driver software and differential files as well as sample programs available in
several languages. Note! For product information
Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information.

Limited One Year Warranty

CONTEC Industrial CPU board is warranted by CONTEC CO., Ltd. to be free from defects in material and workmanship for up to one year from the date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned freight prepaid with a copy of the original invoice and a Return Merchandise Authorization to the distributor or the CONTEC group office from which it was purchased.
This warranty is not applicable for scratches or normal wear, but only for the electronic circuitry and original boards. The warranty is not applicable if the device has been tampered with or damaged through abuse, mistreatment, neglect, or unreasonable use, or if the original invoice is not included, in which case repairs will be considered beyond the warranty policy.

How to Obtain Service

For replacement or repair, return the device freight prepaid, with a copy of the original invoice. Please obtain a Return Merchandise Authorization Number (RMA) from our Sales Administration Department before returning any product.
* No product will be accepted by CONTEC group without an RMA number.

Liability

The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor be liable for any incidental or consequential damages due to such defect or consequences that arise from inexperienced usage, misuse, or malfunction of this device.
2
1. Introduction

Safety Precautions

Understand the following definitions and precautions to use the product safely.

Safety Information

This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely.
DANGER
WARNING
CAUTION

Handling Precautions

CAUTION
- Do not modify the product. CONTEC will bear no responsibility for any problems, etc., resulting from modifying this product.
- Do not strike or bend the board. Otherwise, the board may malfunction, overheat, cause a failure or breakage.
- Do not touch the board's metal plated terminals (edge connector) with your hands. Otherwise, the board may malfunction, overheat, or cause a failure. If the terminals are touched by someone's hands, clean the terminals with industrial alcohol.
- There are switches and jumpers on the board that need to be set in advance. Be sure to check these before installing to the expansion slot.
- Only set the switches and jumpers on the board to the specified settings. Otherwise, the board may malfunction, overheat, or cause a failure.
DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or in property damage.
DANGER
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.
3
1. Introduction

Environment

Use this product in the following environment. If used in an unauthorized environment, the board may overheat, malfunction, or cause a failure.
Operating temperature
0 - 60°C
Operating humidity
10 - 90%RH (No condensation)
Corrosive gases
None
Floating dust particles
Not to be excessive

Inspection

Inspect the product periodically as follows to use it safely.
- Check that the bus connector of the board and its cable have been plugged correctly.
- Check that the board has no dust or foreign matter adhering.
- The gold-plated leads of the bus connector have no stain or corrosion.

Storage

When storing this product, keep it in its original packing form. (1) Put the board in the storage bag. (2) Wrap it in the packing material, then put it in the box. (3) Store the package at room temperature at a place free from direct sunlight, moisture, shock, vibration,
magnetism, and static electricity.

Disposal

When disposing of the product, follow the disposal procedures stipulated under the relevant laws and municipal ordinances.
4

2. System Reference

Specifications

2. System Reference
Table 2.1. Functional Specifications <1/2>
Type
Intel(R) Pentium(R) 4 Processor 1.7G - 2.8GHz(FSB400/533MHz)
CPU(Option)
Cache Built in CPU Processor socket Socket 478 Memory(Option) One SO-DIMM 200-pin socket for PC2100 DDR SDRAM for up to 1GB.
Chipset BIOS Award BIOS, PnP support
VGA Built in Intel(R) 845GV, DVI-I connector x 1 Multi I/O Winbond W83627HF
Keyboard / Mouse connector
Serial I/F
Parallel I/F On board expansion bus None
LAN Port 100BASE-TX/10BASE-T, Intel ICH4 integrated controller, One RJ-45 connector IDE I/F
SATA I/F FDD I/F
VGA / DVI I/F DVI-I 29-pin (Bundled the DVI-Analog RGB conversion adapter) Compact Flash Slot One CF card(Type I / II ) slot, Support boot-up from a card SSD Socket None
USB Port RAID None
Audio AC97 CODEC., One pin-header 5x2-pins connector for speaker-out, line-in, microphone-in. Watchdog Timer Software programmable 255 levels (1 - 255Sec.). Reset occurrence at the time of time up. General-purpose I/F None Hardware Monitor Monitoring of the temperature of CPU and board, power supply voltage, and fan speed RTC
Power Management
Intel(R) Celeron(R) Processor 1.7G - 2.6GHz(FSB400MHz) (Only corresponding to the Northwood core) Intel(R) Celeron(R) D Processor 2.26G - 2.8GHz(FSB533MHz)
845GV Chipset includes GMCH (Graphics and Memory Controller Hub), ICH4 (I/O Controller Hub) and FWH (Firm Ware Hub)
One PS/2 keyboard/Mouse connector(Bundled the 2 in 1 cable) , One box-header 5-pins connector for external keyboard
Two 16550 UART ports, SERIAL1 is RS-232C, SERIAL2 is RS-232C/422/485 configurable, Baud rate: 115.2K - 50bps (programmable), Two box-header 5 x 2-pins connectors
One high-speed parallel port, support SPP/EPP/ECP mode, One box-header 13 x 2-pins connector
One EIDE port, up to two IDE devices, support Ultra DMA 33/66/100, One box-header 20 x 2-pins connector
None One FDD port, up to two floppy drives (360KB, 720KB, 1.2MB, 1.44MB, 2.88MB) , One
box-header 17 x 2-pins connector
3ch USB2.0 compliant ports: One USB A Type connector(Front panel) , One box-header 5 x 2-pins connector that support 2ch
The coin type Lithium battery specification is shown in table The Lithium battery specification is shown in table
* Backup time: Over 7 years at none AC power 25ºC. * Real Time Clock accurate:
Power management setup via BIOS Modem Ring On/Wake On LAN Supports PC98/PC99 ACPI Power management
Specification CR2450
Voltage 3V
Capacity 620mAh
Weigh 6.3g
SPC-8450-LVA
±3 minutes/month at 25ºC.
5
2. System Reference
Table 2.1. Functional Specifications <2/2>
Type
Bus specification/Size(mm) PCI/223(L) x 122(H)
+5VDC±5
DC Power Requirements
Power supply specifications(Max.)
Operating temperature Storage temperature -20 - 80°C
Floating dust particles Not to be excessive Corrosive gases None Weight 390g
Operating System Support
%
+12VDC±5% +5VSB(Stand by) ±5%(Only when using the ATX power supply) Pentium 4 2.4GHz
+5VDC±5%, 5.40A +12VDC±5 +5VSB±5
0 - 60 10 - 90
Windows XP Professional Windows XP Home Edition Windows 2000 Professional
%, 6.20A
%, 0.65A
°C (It depends on the specification of CPU and heat sink.)
%RH(No condensation)
SPC-8450-LVA

Power Requirements

Your system requires a clean, steady power source for reliable performance of the high frequency CPU on the SPC-8450-LVA , the quality of the power supply is even more important. For the best performance makes sure your power supply provides a range of 4.75 volts minimum to 5.25 volts maximum DC power source.
Power Consumption For typical configurations, the CPU card is designed to operate with at least a 250 W power supply. A
higher-wattage power supply should be used for heavily-loaded configurations. The power supply must meet the following requirements:
- Rise time for power supply: 2 ms - 20 ms
- Minimum delay for reset to Power Good: 100 ms
- Minimum Power down warning: 1 ms
The following table lists the power supply’s tolerances for DC voltages:
Table 2.2. DC voltage tolerance
DC Voltage Acceptable Tolerance
+5V ± 5%
+5VSB (standby) ± 5%
+12V ± 5%
6

Connector & Jumper Location

CN1
CN2 CN9 CN10 CN11 CN13 CN14 CN16 PW1FAN2
JP/JP8
CN3 JP6
JP7
CN4
CN6
2. System Reference
CN7
CN8
CN12
FAN1JP9JP2,3,4,5
Figure 2.1. Connector & Jumper Location
Item Content
CN1 / CN2 Serial Port Connector CN3 / CN9 USB Connector CN4 DVI Connector CN6 10/100BASE-TX LAN Connector CN7 Keyboard / Mouse Connector CN8 External Keyboard Connector CN10 Audio Connector CN11 CD-IN Connector CN12 External Battery Connector CN13 Primary IDE Connector CN14 Floppy Disk Drive Connector CN16 Parallel Port Connector CN17 Front Panel Connector
JP10
Item Content
CN18 ATX power control Connector CN19 DC Power supply connector CN21 SO-DIMM Memory Socket FAN1 FAN Connector1 FAN2 FAN Connector2 PW1 +12V power supply Connector JP1 / JP8 RS-232C/422/485 Selector JP2, 3, 4, 5 Keyboard / Mouse Connector JP6 CF Master/Slave Selector JP7 RS-422/485 Terminator JP9 ATX/AT Power supply select JP10 Clear CMOS Content CF CF Slot
CN17
CF
CN21
CN19
CN18
7
2. System Reference

Block Diagram

DC TO DC REGULATOR
DVH
CONNECTOR
Processor
PWM
RGB BUS
TMDS Sir164
CF Card Slot
(Secondary)
IDE
(Primary)
USB 2.0 PORT 1-3
FirmWare Hub
DVOS BUS
UDMA66/100
USB
LPC BUS
SOCKET 478 P4/Celeron D PROCESSOR
CTRL
ADDR
AGTL+BUS
CTRL
ADDR
GMCH
845GV
ICH4
DATA
DATA
HUB LINK
LAN DAT A
AC'97 LINK
CLOCK Generator
DDR266 SO-DIMM Modules x 1
PCI CNTRL
PCI ADDR/DAT A
LAN 10/100M Connector
AC'97 CODEC
PCI GOLD FINGER
Super I/O
Floppy
Keyboard
Mouse
Serial1/ Serial2
Parallel
Figure 2.2. Block Diagram
8

3. Hardware Installations

3. Hardware Installations
This chapter provides information on how to use the jumpers and connectors on the SPC-8450-LVA in order to set up a workable system.

Installation procedure

(1) Confirm the power supply is off. (2) Install the processor with correct orientation. (3) Insert the DRAM module with correct orientation. (4) Mount the Fan on the top of the processor and connect it to FAN2 connector. (5) Insert +12V Power supply cable to PW1 connector. (6) The jumpers are set up according to the conditions to be used. (7) Insert all external cables (Hard disk, floppy, keyboard, Mouse, LAN, etc.) (8) Insert CRT or LCD monitor to DVI-I connector (CN4). (9) Turn on the power. (10)Enter the BIOS setup mode by pressing ‘Del’ key during boot up. (11)Use the “Load BIOS Optimal Defaults” feature. (12)Configure the Peripheral Setup and the Standard Setup correctly.
CAUTION
The CMOS memory may be in an undefined state at power-on after a period of no battery backup.
9
3. Hardware Installations

CPU Installation:

The SPC-8450-LVA supports a single Intel 478pin FC-PGA2 type, Pentium 4, Celeron or Celeron D processor. The processor’s VID pins automatically program the voltage regulator on the CPU card to the required processor voltage. The host bus speed is automatically selected. The processor connects to the CPU card through the 478-pins socket.
The CPU card supports the processors listed in table below:
Celeron Processor
Host Bus frequency
400MHz
Celeron D Processor
Host Bus frequency
533MHz
Pentium 4 Processor
Host Bus frequency
400MHz / 533MHz
The socket-478 comes with a lever to secure the processor. Make sure the notch on the corner of the CPU corresponds with the notch on the inside of the socket.
After you have installed the processor into the socket 478, check if the configuration setup for the CPU type and speed are correct. The CPU should always have a Heat Sink and a cooling fan attached to prevent overheating.
CAUTION
Ensure that the CPU heat sink and the CPU top surface are in total contact to avoid CPU overheating problem that would cause your system to hang or be unstable
Cache size
128KB
Cache size
256KB
Cache size
256K/512K/1MB
The heights of the heat sink that optional CPU. PCP4-24, PCP4C-20 :70mm PCP4-28S, PCP4C-20S :83mm
Height
10
3. Hardware Installations

Main Memory Installation: CN21

The SPC-8450-LVA support one single-side or double-sided DDR200(PC1600)/266(PC2100) unregistered SO-DIMM, 200-pin SO-DIMM sockets for a maximum memory of 1GB. Using the non­ECC DDR SDRAM SO-DIMM.
The CPU card supports the following memory features:
- 200-pin SO-DIMM with gold-plated contacts
- 200 MHz (PC1600)/266 MHz (PC2100) DDR SDRAM
- Non-ECC DIMM
- Unbuffered, unregistered single-sided or double-sided SO-DIMMs
Table 3.1. DDR SDRAM
SO-DIMM Size Non-ECC
128MB 16Mbit x 64 256MB 32Mbit x 64 512MB 64Mbit x 64 1024MB 128Mbit x 64
CAUTION
All memory components and DIMM used with the SPC-8450-LVA CPU card must comply with the PC SDRAM Specification. These include: the PC SDRAM Specification *memory component specific), the PC Unbuffered DIMM Specification, and the PC Serial Presence Detect Specification.
11
3. Hardware Installations

Serial Port Connector: CN1 , CN2

Serial1(CN1) and Serial2(CN2) are 10-pin box-headers. Both are onboard serial ports of the CPU card SPC-8450-LVA. The following table shows the pin assignments of these connectors. RS-232C/422/485 assigned for Serial2(CN2) connector only.
Table 3.2. Serial Port connector (CN1, 2)
Pin No.
CN1/CN2
16
510
* RS-422/485 assigned for Serial2(CN2) connector only.
Pin assignment after conversion by attached cable (D-SUB 9Pin Male Connector, No.4-40UNC )
Table 3.3. Attached cable (9pin D-SUB) pin assignment
RS-232C
1
DCD
2
RXD
3
TSD
4
DTR
5
GND
6
DST 7 8 9
10
N.C.
RTS CTS
RI
RS-422*
TX­TX+ RX+
RX-
GND
RTS­RTS+ CTS+
CTS-
N.C.
RS-485*
TX­TX+ RX+
RX-
GND
N.C. N.C. N.C. N.C. N.C.
15
9
6
Pin No.
RS-232C 1 2 3 4 5 6 7 8 9
CAUTION
RS-422 DCD RXD TXD DTR
GND
DSR RTS CTS
RI
TX­TX+ RX+
RX-
GND RTS­RTS+ CTS+ CTS-
RS-485
TX­TX+ RX+
RX­GND N.C. N.C. N.C. N.C.
- For RS-485, TX+(pin 2) and RX+ (pin 3) must jumper together inside the D type connector.
- TX- (pin 1) and RX- (pin 4) is the same.
12
3. Hardware Installations

RS-422 / RS-485 specifications

- Transmission system: Asynchronous, half-/full-duplex serial transmission conforming to RS-422/ RS-485
- Baud rate: 115.2K - 50bpx (programmable)
- Signal extensible distance: 1.2km Max.
RTS#
JP1: 7-8
47k Ω
JP1: 4-6 JP1: 5-6
RXD
TXD
CTS#
RTS#
6.2kΩ
R
Terminating Resister
6.2kΩ
47
k Ω
D
+5V
47k Ω
6.2kΩ
R
6.2kΩ
47
k Ω
D
120 Ω
JP7: 5-6120 Ω
JP7: 7-8120 Ω
JP7: 1-2120 Ω
JP7: 3-4
CN2
10 5
61
13
3. Hardware Installations

USB Connector: CN3, CN9

This board have one USB(v2.0 compliant) A Type connector(USB1 CN3) and one box-header connector(USB2/3 CN9). This box-header is for the optional USB cable to provide two A Type connectors.
Table 3.4. USB A TYPE Connector (Front panel)
Pin No.
Function
CN3
4
1
Table 3.5. USB box-header Connector
Pin No.
CN9
12
910
* Optional USB Cable : USB Connector Cable
1
GND
2
USBP1+
3
USBP1-
4
VCC1
Function
1
VCC2
3
USBP2-
5
USBP2+ 7 9
GND
N.C.
Pin No.
2 4 6 8
10
Function
VCC3
USBP3-
USBP3+
GND
Chassis GND
CAUTION
Computer systems that have an unshielded cable attached to a USB port may not meet FCC Class B requirements, even if no device or a low-speed USB device is attached to the cable. Use shielded cable that meets the requirements for full-speed devices.
14
3. Hardware Installations

DVI Connector: CN4

This connector is DVI-I connector for CRT/LCD. The pin assignment is shown below. In using the CRT(Analog RGB display), use DVI-Analog RGB conversion adapter. 20 pin 21 pins are connecting to Serial1 for the touch panel signal. CN1 cannot be used when using this
signal.
Table 3.6. DVI-Analog RGB converter
Connector-type DVI-I 29pin
1
8
C1
C2
C5
16
17
9
Pin No.
1 DATA2- 13 N.C. C1 RED 2 DATA2+ 14 +5V C2 GREEN
3
4N.C.16 HPD C4HSYNC 5 N.C. 17 DATA0- C5 GND 6 DDC CLK 18 DATA0+
7
8 VSYNC 20 FPS_OUT(TxD) 9 DATA1- 21 FPS_IN(RxD)
10 DATA1+ 22 DATA0 SHIELD
11
12 N.C. 24 CLK-
Signal
name
DATA2
SHIELD
DDC
DATA
DATA1
SHIELD
Pin No.
24
Signal
name
15 GND C3 BLUE
19
23 CLK+
DATA0
SHIELD
C4
C3
Pin No.
Signal
name
15
3. Hardware Installations

10/100BASE-TX LAN Connector: CN6

This connector is for the LAN adapter that has LED indicated the 10/100Mbps transfer rate / Link / Act status of Ethernet capability of the CPU card. The follow table shows the pin assignments of this connector.
Table 3.7. LAN Connector
Function 1 2 3 4
TX+
TX­RX+ N.C.
Pin No.
5 6 7 8
Function
N.C.
RX­N.C. N.C.
Link / ACT
LED
CN6
81
Speed
LED
Pin No.
Left LED: Link/Ack LED Link: Green, Ack: Blink Right LED: Speed LED 10M: OFF, 100M: Green

Keyboard / Mouse Connector: CN7

The CPU card provides a standard PS/2 keyboard/mouse connector for attaching a PS/2 keyboard/mouse. You will connect with an add-on cable for a PS/2 keyboard/mouse. You can select that plug a PS/2 mouse directly, PS/2 keyboard directly or both(use 2 in 1 cable) by jumper setting.
The PS2 Keyboard/Mouse Connector pin definition is shown below:
Table 3.8. Keyboard / Mouse Connector
Pin No.
CN7
6
4
5
3
1
2
1
KB or MS Data
2
MS or KB DATA 3 4 5
KB or MS Clock
6
MS or KB Clock
Function
GND
+5VSB
Table 3.9. K/B & M/S Select Jumpers: JP2/JP3/JP4/JP5
JP5
123
123
123
Plug Keyboard
Plug PS/2 Mouse
Plug Keyboard
& Mouse
(Y-cable to connection)
JP2Select the function
123
123
123
JP3
123
123
123
JP4
123
123
123
16
3. Hardware Installations

External Keyboard Connector: CN8

This is a 5-pin connector for external keyboard.
Table 3.10. External Keyboard Connector
CN8
5 4 3 2 1
Pin No.
5 4 3 2 1
Function
VCC GND
N.C. KB Data KBClock
Housing: XHP-5(JST) Contact : SXH- 001T-P06(JST)

Audio Connector: CN10

This connector connects the Audio jack cable.
Table 3.11. Audio Connector
CN10
Pin No.
21
109
1 3 5 7 9
Function
LINE-OUT-R
GND
N.C.
GND
LINE-IN-R
Pin No.
2 4 6 8
10
Function
LINE-OUT-L
N.C.
MIC-IN
GND
LINE-IN-L

CD-IN Connector: CN11

This connector is used to connect CD Audio cable from CD-ROM or DVD drive to onboard sound.
Table 3.12. CD-IN Connector
1
Pin No.
CN11
4
Function
1
Audio-L
2
GND
3
GND
4
Audio-R

External Battery Connector: CN12

It is a 2 Pin connector used for external battery. An external battery power for used of Real-time clock and CMOS memory.
Table 3.13. External Battery Connector
CN12
2
1
Pin No.
1 2
Function
GND
External battery
(3V)
Housing: IL-2S-S3L-(N) (JAE) Contact: IL-C2-1-1000 0 (JAE)
17
3. Hardware Installations

Primary IDE Connector: CN13

The SPC-8450-LVA provides a bus-mastering PCI IDE interface. This interface support PIO Mode 3, PIO Mode 4, ATAPI devices (e.g., CD-ROM), and Ultra DMA/33/66/100 synchronous-DMA mode transfers. The BIOS supports logical block addressing (LBA) and extended cylinder head sector (ECHS) translation modes. The BIOS automatically detects the IDE device transfer rate and translation mode.
This connector supports the provided IDE hard disk ribbon cable. After connecting the single end to the board, connect the two plugs at the other end to your hard disk(s). If you install two hard disks, you must configure the second drive to Slave mode by setting its jumper accordingly. Please refer to your hard disk documentation for the jumper setting.
Table 3.14. Primary IDE Connector
39
CN13
1
40
Pin No.
1 3 5 7
9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39
Function
RESET
D7 D6 D5 D4 D3 D2 D1 D0
GND
DREQ
IOW
IOR
IORDY
DACK
IRQ
A1 A0
CS0
HD ACT
Pin No.
2 4 6
8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40
2
Function
GND
D8
D9 D10 D11 D12 D13 D14 D15 N.C.
GND GND GND
ALE
GND
N.C.
P66DET
A2 CS1
GND
18
3. Hardware Installations

Floppy Disk Drive Connector: CN14

The floppy interface can be configured for the following floppy drive capacities and sizes:
- 360 KB, 5.25-inch
- 1.2 MB, 5.25-inch
- 720 KB, 3.5-inch
- 1.44 MB, 3.5-inch
- 2.88 MB, 3.5-inch
This connector supports the provided floppy drive ribbon cable. After connecting the single and to the board, connect the two plugs on the other end to the floppy drives.
Table 3.15. Floppy Disk Drive Connector
33
Pin No.
1 3 5 7
9 11 13 15 17 19 21 23 25 27 29 31 33
Function
GND GND GND GND GND GND GND GND GND GND GND GND GND GND GND GND GND
CN14
Pin No.
2 4 6
8 10 12 14 16 18 20 22 24 26 28 30 32 34
1
234
Function
RWC
N.C. N.C.
INDEX
DS0 DS1 DS2
MOT ON
DIR
STEP
WD WG
TRCK 0
WP RD
SIDE 1
DSK CHG
19
3. Hardware Installations

Parallel Port Connector: CN16

The parallel port bracket can used to add an additional parallel port for additional parallel devices. There are four options for parallel port operation:
- Compatible (Standard mode)
- Bi-Directional (PS/2 compatible)
- Bi-Directional EPP. A driver from the peripheral manufacturer is required for operation.
- Bi-Directional High-speed ECP
Table 3.16. Parallel Port Connector
25
CN16
1
Pin No.
1 3 5 7
9 11 13 15 17 19 21 23 25
26
Function STROBE
PD0 PD1 PD2 PD3 PD4 PD5 PD6 PD7 ACK
BUSY
PE
SLCT
Pin No.
2 4 6
8 10 12 14 16 18 20 22 24 26
2
Function
ALF
ERROR
INIT
SLCT IN
GND GND GND GND GND GND GND GND N.C.
20
3. Hardware Installations

Front Panel Connector: CN17

This header can be connected to a front panel power switch. The front panel connector includes headers for these I/O connections:
Power Button: When the ATX power supply is used, this header connects power supply ON button.
Power LED: This header is connected with a LED when turning on power to the computer.
Reset Button: This header connects the reset button.
HDD LED: This header is connected with a LED shown while being reading the data of the IDE hard disk drive or
writing it.
Speaker: An external speaker can be installed in this CPU board as an option. When the computer cannot use the
video interface, the speaker offers the error warning sound in POST. Moreover, because this speaker is not connected with the audio subsystem, it is not possible to sound it by the output from the audio subsystem.
Table 3.17. Front Panel Connector
CN17
15
1
16
Pin No.
Speaker Reset Button Power LED
Function
Power BT
1
GND
3
RESET
5
GND
7 9
VCC
GND
11
GND
13
BUZZER
15
2
Function
Pin No.
VCC
2
N.C. VCC VCC
N.C.
N.C.
Power Swi tch for ATX
Reset Switch
External Speaker
(Ex. 8
Ω 0.25W)
1, 3 2, 4
IDE ACT
4 6 8
10
Power LED
12 14 16
9, 11, 13, 15 5, 7 8, 10, 12
Power Button HDD LED
1
HDD Active Indicato r LED
Power LED
15
21
3. Hardware Installations

ATX power control Connector: CN18

When used with an ATX-compliant power supply that supports remote power on/off, the CPU board can turn off the system power through software control.
To enable soft-off control in software, advanced power management must be enabled in the Setup program and in the operation system. When the system BIOS receives the correct APM command from the operating system, the BIOS turns off power to the computer.
Table 3.18. ATX power control Connector
CN18
12345
Pin No.
1 2 3 4 5 6
PCI_PME# : Connect to PME# signal of PCI bus, this CPU board can wake up from the PCI board which supports PME (Power Management Event) function. When you do not use this function, please keep open.
PSWIN : Connect power push switch. The same function as CN2-1pin (PowerBT). PS_ON : Output for ATX power supply On/Off control. 5VSB : Input 5V standby power from ATX power supply.
6
Function
PCI_PME#
GND
PSWIN
GND
PS_ON
5VSB
CN18
6 5 4 3 2 1
Housing : XHP-6 (JST) Contact : SXH-001T-P0.6 (JST)
5VSB
PS-ON
ATX Power Control signal
5VSB PS-ON GND
22
3. Hardware Installations

DC Power supply connector: CN19

In using this board without a back plain, please supply VCC(+5V) from this connector. Furthermore, the supply from PW1 connector is required for +12 V.
Table 3.19. DC Power supply connector
CN19
PIN No.
4
1
CAUTION
Function
4
VCC(+5V)
3
VCC(+5V) 2 1
GND
Housing:VHR-4N(JST) Contact: SVH-21T-1.1(JST)
GND
Depending on the characteristic of the power supply to be used, this CPU board can not operate. When used, please enough evaluate by the user. In addition, the support about this connector use cannot be performed in our company.

+12V power supply Connector: PW1

The power supply that conformed for ATX12V is used, this connector connect 4Pin +12V cable directly from power supply. Use the 12V power cable of the accessories, when other power supplies are used.
Table 3.20. +12V power supply Connector
PW1
2
1
Pin No.
4
3
Function
GND
2
GND
1
Pin No.
Function
+12V
4
+12V
3

FAN Connector: FAN1/FAN2

FAN1, FAN2 is a 3-pins box-header for the cooling fan power connector. The fan must be a 12V fan. Pin 3 is for Fan speed sensor input.
Table 3.21. FAN Connector
FAN1/FAN2
1
2
3
Pin No.
1 2 3
Function
GND
POWER
FAN
Housing : 5102-03 (molex) Contact : 5103 (molex)
23
3. Hardware Installations
24
4. Jumper Setting RS-232C/422/485 Selector: JP1/JP8
Table 4.1. RS-232C/422/485 Selector(JP1/JP8)
JP1 JP8
RS-232C (Default)
RS-422
RS-485
1. For RS-485, TX+(pin 2) and RX+ (pin 3) must jumper together inside the D type connector.
2. TX- (pin 1) and RX- (pin 4) is the same.
19 17 15 13 11 9 7 5 3 123 21
20 18 16 14 12
19 17 15 13 11 9 7 5 3 123 21
20 18 16 14 12
19 1 7 15 13 11 9 7 5 3 123 21
20 1 8 16 14 12
10 8 6 4 225 22
JP1 JP8
10 8 6 4 225 22
JP1 JP8
10 8 6 4 225 22
9
7531
10
8642
97531
10
864
9
31
75
10
864
2
2

4. Jumper Setting

Transmit date control in half-duplex mode
In half-duplex mode, the transmission buffer must be controlled to prevent transmit data from causing a collision. The SPI-8450-LLVA uses the RTS signal and bit 1 in the modem control register to control transmit data.
Modem control register (Setting I/O address +4H) bit 1: 0 … RTS High (Disables transmission) 1 … RTS low (Enables transmission)
Setting the RS-422/RS-485 receiver disable control jumper
When the RS-422/RS-485 port is used, the RTS signal is used for driver enable control Connecting JP2 Pins 4 and 6 set to OFF disable the receiver at the same time, preventing the port from receiving output data to an external device.
25
4. Jumper Setting

RS-422 Setting

TXD#
D
JP8: 4-6
JP8: 5-6
RXD#
RTS
CTS
R
D
R
Figure 4.1. RS-422 Setting

RS-485 Setting

TXD#
D
JP8: 4-6
JP8: 5-6
RXD#
R
JP8: 7-8
120Ω
120Ω
120Ω
120
JP8: 7-8
120 Ω
120 Ω
RTS#
Ω
RTS#
JP7: 7-8
JP7: 5-6
JP7: 7-8
JP7: 5-6
JP7: 3-4
JP7: 1-2
TX­RTS­TX+ RTS+ RX+ CTS+ RX­CTS-
SERIAL2
6 7 8 9
SERIAL2
1
6
2
7
3
8
4
9
5
1 2 3 4 5
DATA-
DATA+
Figure 4.2. RS-485 Setting
26
I/O addresses and instructions
The table below lists I/O addresses for use as SERIAL2.
4. Jumper Setting
Table 4.2.
I/O addresses and instructions
I/O address DLAB Read/Write Register
0
02F8h
1 W Divisor latch Register (LSB) DLL
1 W Divisor latch Register (MSB) DLM
02F9h
02FAh X R Interrupt ID Register IIR
02FBh X W Line control Register LCR
02FCh X W Modem Control Register MCR
02FDh X R Line status Register LSR
02FEh X R Modem Status Register MSR
02FFh X R/W Scratch Register SCR
0 W Interrupt enable Register IER
W Transmitter holding Register THR
R Receiver buffer Register RBR
27
4. Jumper Setting

RS-422/485 Terminator: JP7

Table 4.3. RS-422/485 Terminator(JP7)
JP7 Terminator
9
1
No terminating resister
Terminating resisiter provided
Terminating resisiter provided
Terminating resisiter provided
Terminating resisiter provided
10 2
9
10
9
10
9
10
9
10
---
1
CTS for RS-422
2
1
RTS for RS-422
2
1
RXD for RS-422/485
2
1
TXD for RS-422/485
2
Function
(Default)
28
4. Jumper Setting

CF Master/Slave Selector: JP6

On board CF slot is connected to Secondary IDE. This jumper is select Master/Slave of CF memory card. Usually, please use it with a master setup.
Table 4.4. CF Master/Slave Selector (JP6)
JP6 Function
12
12
Master(Default)
Slave

ATX/AT Power supply select: JP9

This jumper is set up according to the power supply type to be used.
Table 4.5. ATX/AT Power supply select (JP9)
JP9 Function
321
321
ATX(Default)
AT

Clear CMOS Content: JP10

The time, date, and CMOS values can be specified in the Setup program. The CMOS values can be returned to their defaults by using the Setup program. The RAM data contains the password information is powered by the onboard battery. User can erase the CMOS memory content by short pin2 and pin3 of JP10.
Table 4.6. Clear CMOS Content (JP10)
JP10 Function
1
Normal Operation( Defa u lt )
2
3 1
2
3
Clear CMOS Content
29
4. Jumper Setting
30

5. Board Resources

5. Board Resources System Address Map
The GMCH memory map includes a number of programmable ranges. All of these ranges must be unique and non-overlapping. There are no fardware interlocks to prevent problems in the case of overlapping ranges. Accesses to overlapped ranges may produce indeterminate results.
Table 5.1. Compatibility Area
Address Description
0 - 640KB DOS area 640 - 768KB Video Buffer area 768 - 896KB Expansion Area 896 - 960KB Extended System BIOS Area
960 - 1MB System BIOS Area
Table 5.2. Memory Segment
Memory Segments Comments
00000h - 9FFFh 0 - 640K DOS Region A0000h - BFFFFh Video Buffer B0000h - B7FFFh Monochrome Adapter range C0000h - CBFFFh Video BIOS CC000h - DFFFFh Expansion Area E0000h - EFFFFh Extended System BIOS Area
F0000 - FFFFFh System BIOS Area
100000h - 7FFFFFFFh Extended Memory Area
00100000 to Top of Main Memory Main DRAM Address Range
Top of Main Memory Extended SMRAM Address Range
Top of Main Memory To 4GB P CI Memory Address Range
FEC00000h - FECFFFFFh,
FEE00000h - FEEFFFFFh FFFE0000h - FFFFFFFFh High BIOS Area
APIC configuration space
31
5. Board Resources
32

6. Watch-Dog-Timer (WDT) Setting

6. Watch-Dog-Timer (WDT) Setting
The watchdog timer serves as a safeguard against possible system lock-up in your industrial computer system. In most industrial environments, there are heavy equipment, generators, high-voltage power lines, or power drops that have adverse effects on your computer system. For instance, when a power drop occurs, it could cause the CPU to come to a halt state or enter into an infinite loop, resulting in a system lock-up.
The application software created by user with the watchdog timer enabled, a RESET automatically generated unless the software periodically triggers the timer within the setting time-out interval. That is, while the system gets hung up, the running program can’t trigger the timer periodically. The timer will generate a reset signal to reboot the system. This feature allows a running program to restart in an orderly way when a power glitch or any abnormal condition occurs.
The watchdog timer comes with 255-level time-out interval, 1 - 255 seconds per interval, which can be adjusted by software setting. There is a tolerance of 2 second for this time-out interval. For example, if the time-out interval has been set to 32 seconds, your program should trigger the watchdog timer before 28 seconds are escaped. Otherwise, after 28-32 seconds are escaped, the system will automatically reboot. To keep the system running normally, your program should trigger the watchdog timer every 28 seconds.
The I/O port is defined at address 2e/2fH. You can trigger/enable disable the timer by writing address 2e/2fH.
Here is an example for flow chart and programming how to use the watch-dog-timer.
(1) Example flow chart
START
WDT Initial
WDT Start
WDT Stop
Yes
WDT Restart?
* It is also possible not to perform [WDT Stop] instead of performing [WDT Stop] to [WDT Start], but to perform [WDT
Start] continuously at the time of a re-start.
}
When performing the re-start of WDT, it repeats [WDT Start] and [WDT Stop].
No
END
If [WDT Stop] is not performed within the limit time set up by [WDT Start], system reset occurs.
33
6. Watch-Dog-Timer (WDT) Setting
(2) Example programming
The following example is written in Intel8086 assembly language.
;=============== ;<WDT Initial> ;=============== ;----------------------------------­;Enter the extended function mode ;----------------------------------­MOV DX,2EH MOV AL,87H OUT DX,AL OUT DX,AL ;----------------------------------­;Set WDT function at pin89 ;----------------------------------­MOV DX,2EH MOV AL,2BH OUT DX,AL MOV DX,2FH MOV AL,0DH OUT DX,AL ;-----------------------------------------------­;Select logical device WDT(number 8) ;------------------------------------------------­MOV DX,2EH MOV AL,07H OUT DX,AL MOV DX,2FH MOV AL,08H OUT DX,AL ;--------------------------------------------------­;Activate logical device WDT(number 8) ;--------------------------------------------------­MOV DX,2EH MOV AL,30H OUT DX,AL MOV DX,2FH MOV AL,01H OUT DX,AL ;----------------------------------­;Set timer unit : second ;----------------------------------­MOV DX,2EH MOV AL,F5H OUT DX,AL MOV DX,2FH MOV AL,00H OUT DX,AL
34
6. Watch-Dog-Timer (WDT) Setting
;-----------------------------------------­;Exit the extended function mode ;-----------------------------------------­MOV DX,2EH MOV AL,AAH OUT DX,AL
;================================ ;<WDT START : counter set and a start > ;================================ ;--------------------------------------------­;Enter the extended function mode ;--------------------------------------------­MOV DX,2EH MOV AL,87H OUT DX,AL OUT DX,AL ;-----------------------------------------------­;Select logical device WDT(number 8) ;-----------------------------------------------­MOV DX,2EH MOV AL,07H OUT DX,AL MOV DX,2FH MOV AL,08H OUT DX,AL ;-----------------------------------------------------­;Set time of WDT and start to count down ;-----------------------------------------------------­MOV DX,2EH MOV AL,F6H OUT DX,AL MOV DX,2FH ;---------------------------------------------------------------------------------­;The data of an example is 15 seconds.(01H=1sec.- FFH=255sec.) MOV AL,0FH ; 0FH = 15Sec. ;----------------------------------------------------------------------------------­OUT DX,AL ;----------------------------------­;Exit the extended function mode ;----------------------------------­MOV DX,2EH MOV AL,AAH OUT DX,AL
35
6. Watch-Dog-Timer (WDT) Setting
;============== ;<WDT STOP> ;============== ;----------------------------------­;Enter the extended function mode ;----------------------------------­MOV DX,2EH MOV AL,87H OUT DX,AL OUT DX,AL ;----------------------------------­;Select logical device WDT(number 8) ;----------------------------------­MOV DX,2EH MOV AL,07H OUT DX,AL MOV DX,2FH MOV AL,08H OUT DX,AL ;----------------------------------­;Stop count down of WDT ;----------------------------------­MOV DX,2EH MOV AL,F6H OUT DX,AL MOV DX,2FH ;----------------------------------­;The data of 00H is stop WDT MOV AL,00H ;----------------------------------­OUT DX,AL ;----------------------------------­;Exit the extended function mode ;----------------------------------­MOV DX,2EH MOV AL,AAH OUT DX,AL
CAUTION
The timer’s intervals have a tolerance of ±2 seconds.
36

7. BIOS Setup

7. BIOS Setup Introduction
This chapter discusses Award’s Setup program built into the FLASH ROM BIOS. The Setup program allows users to modify the basic system configuration. This special information is then stored in battery­backed RAM so that it retains the Setup information when the power is turned off.
The rest of this chapter is intended to guide you through the process of configuring your system using Setup.

Starting Setup

The Award BIOS is immediately activated when you first power on the computer. The BIOS reads the system information contained in the CMOS and begins the process of checking out the system and configuring it. When it’s finish , the BIOS will seek an operating system on one of the disks and then launch and turn control over to the operating system.
While the BIOS is in control, the Setup program can be activated in one of two ways:
1. By pressing <Del> immediately after switching the system on, or
2. By pressing the <Del> key when the following message appears briefly at the bottom of the screen during the POST (Power On Self-Test).
Press DEL to enter SETUP.
If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" button on the system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to...
Press F1 to continue, DEL to enter SETUP

Using Setup

In general, you use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more detail about how to navigate in the Setup program using the keyboard.
Table 7.1. Using Setup
Key Function
Up Arrow Move to the previous item Down Arrow Move to the next item Left Arrow Move to the item on the left (menu bar) Right Arrow Move to the item on the right (menu bar)
Esc
Move Enter Move to the item you desired PgUp key Increase the numeric value or make changes PgDn key Decrease the numeric value or make changes
Main Menu: Quit without saving changes Submenus: Exit Current page to the next higher level menu
37
7. BIOS Setup
Key Function
+ key Increase the numeri c val ue or make changes
- key Decrease the numeric value or make changes
Esc key
F1 key General help on Setup navigation keys F5 key Load previous values from CMOS F6 key Load the fail-safe defaults from BIOS default tabl e F7 key Load the optimized defaults F10 key Save all the CMOS changes and exit
Main Menu -- Quit and not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -- Exit current page and
return to Main Menu
Getting Help
Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window press <Esc> or the F1 key again.
In Case of Problems
If after making and saving system changes with Setup, you discover that your computer no longer is able to boot, the AwardBIOS supports an override to the CMOS settings which resets your system to its defaults.
The best advice is to only alter settings which you thoroughly understand. To this end, we strongly recommend that you avoid making any changes to the chipset defaults. These defaults have been carefully chosen by both Award and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override.
A Final Note About Setup
The information in this chapter is subject to change without notice.
38
7. BIOS Setup

Main Menu

Once you enter the Award BIOS CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and two exit choices. Use the arrow keys to select among the items and press <Enter> to accept and enter the sub-menu.
Note that a brief description of each highlighted selection appears at the bottom of the screen.
Figure 7.1. Main Menu
Setup Items
The main menu includes the following main setup categories. Recall that some systems may not include all entries.
Standard CMOS Features
Use this menu for basic system configuration.
Advanced BIOS Features
Use this menu to set the Advanced Features available on your system.
Advanced Chipset Features
Use this menu to change the values in the chipset registers and optimize your system's performance.
Integrated Peripherals
Use this menu to specify your settings for integrated peripherals. See section 6.6. for the details.
Power Management Setup
Use this menu to specify your settings for power management.
PnP / PCI Configuration
This entry appears if your system supports PnP / PCI.
39
7. BIOS Setup
PC Health Status
This menu shows the health/temperature of your PC if your computer contains a monitoring system.
Frequency/Voltage Control
Use this menu to configure CPU Clock Ratio settings and enable/disable Spread Spectrum
Load Fail-Safe Defaults
Use this menu to load the BIOS default values for the minimal/stable performance for your system to operate.
Load Optimized Defaults
Use this menu to load the BIOS default values that are factory settings for optimal performance system operations. While Award has designed the custom BIOS to maximize performance, the factory has the right to change these defaults to meet their needs.
Supervisor / User Password
Use this menu to set User and Supervisor Passwords.
Save & Exit Setup
Save CMOS value changes to CMOS and exit setup.
Exit Without Saving
Abandon all CMOS value changes and exit setup.

Standard CMOS Setup

Figure 7.2. Standard CMOS Setup
The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.
40
Main Menu Selections
This table shows the selections that you can make on the Main Menu
Item Options Description
Date Month DD YYYY
Time HH : MM : SS Set the system time
IDE Primary Master
IDE Primary Slave
IDE Secondary Master
IDE Secondary Master
Drive A Drive B
Video
Halt On
Base Memory N/A
Extended Memory N/A
Total Memory N/A
Options are in its sub menu(described in Table 64)
Options are in its sub menu(described in Table 64)
Options are in its sub menu(described in Table 64)
Options are in its sub menu(described in Table 64)
None 360K, 5.25 in
1.2M, 5.25 in 720K, 3.5 in
1.44M, 3.5 in
2.88M, 3.5 in EGA/VGA CGA 40
CGA 80 MONO
All Errors No Errors All, but Keyboard All, but Diskette All, but Disk/Key
Set the system date. Note that the ‘Day’ automatically changes when you set the date
Press <Enter> to enter the sub menu of detailed options
Press <Enter> to enter the sub menu of detailed options
Press <Enter> to enter the sub menu of detailed options
Press <Enter> to enter the sub menu of detailed options
Select the type of floppy disk drive installed in your system
Select the default video device
Select the situation in which you want the BIOS to stop the POST process and notify you
Displays the amount of conventional memory detected during boot up
Displays the amount of extended memory detected during boot up
Displays the total memory available in the system
7. BIOS Setup
41
7. BIOS Setup
IDE Adapters
The IDE adapters control the hard disk drive. Use a separate sub menu to configure each hard disk drive. Use the legend keys to navigate through this menu and exit to the main menu. Use Table 3 to configure
the hard disk.
Item Options Description
IDE HDD Auto-detection Press Enter
IDE Primary Master
Capacity
Access Mode
The following options are selectable only if the ‘IDE Primary Master’ item is set to ‘Manual’
Cylinder
Head
Precomp
Landing zone
Sector
None Auto Manual
Auto Display your disk drive size
Normal LBA Large Auto
Min = 0 Max = 65535
Min = 0 Max = 255
Min = 0 Max = 65535
Min = 0 Max = 65535
Min = 0 Max = 255
Press Enter to auto-detect the HDD on this channel. If detection is successful, it fills the remaining fields on this menu.
Selecting ‘manual’ lets you set the remaining fields on this screen. Selects the type of fixed disk. "User Type" will let you select the number of cylinders, heads, etc. Note: PRECOMP=65535 means NONE !
Disk drive capacity (Approximated). Note that this size is usually slightly greater than the size of a formatted disk given by a disk checking program.
Choose the access mode for this hard disk
Set the number of cylinders for this hard disk.
Set the number of read/write heads
**** Warning: Setting a value of 65535 means no hard disk
****
Number of sectors per track
42
7. BIOS Setup

Advanced BIOS Features Setup

This section allows you to configure your system for basic operation. You have the opportunity to select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security.
Figure 7.3. Advanced BIOS Features Setup
Virus Warning
When enabled, you receive a warning message if a program (specifically, a virus) attempts to write to the boot sector or the partition table of the hard disk drive. You should then run an anti-virus program. Keep in mind that this feature protects only the boot sector, not the entire hard drive.
CAUTION
Many disk diagnostic programs that access the boot sector table can trigger the virus warning message. If you plan to run such a program, we recommend that you first disable the virus warning.
Enabled
Disabled
Activates automatically when the system boots up causing a warning message to appear when anything attempts to access the boot sector or hard disk partition table.
No warning message will appear when anything attempts to access the boot sector or hard disk partition table.
43
7. BIOS Setup
Description Choice
CPU L1/L2 Cache ECC Checking When you select Enabled, memory checking is enabled when the external cache contains ECC SRAMs.
Quick Power On Self Test Select Enabled to reduce the amount of time required to run the power-on self-test (POST). A quick POST skips certain steps. We recommend that you normally disable quick POST. Better to find a problem during POST than lose data during your work
First/Second/Third/Other Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items.
Swap Floppy Drive This field is effective only in systems with two floppy drives. Selecting Enabled assigns physical drive B to logical drive A, and physical drive A to logical drive B. If the system has two floppy drives, you can swap the logical drive name assignments.
44
Description Choice
Boot Up Floppy Seek When Enabled, the BIOS tests (seeks) floppy drives to determine whether they have 40 or 80 tracks. Only 360-KB floppy drives have 40 tracks; drives with 720 KB, 1.2 MB, and 1.44 MB capacity all have 80 tracks. Because very few modern PCs have 40-track floppy drives, we recommend that you set this field to Disabled to save time. Seeks disk drives during boot up. Disabling speeds boot up.
Boot Up NumLock Status Toggle between On or Off to control the state of the NumLock key when the system boots. When toggled On, the numeric keypad generates numbers instead of controlling cursor operations.
Gate A20 option Gate A20 refers to the way the system addresses memory above 1 MB (extended memory). When set to Fast, the system chipset controls Gate A20. When set to Normal, a pin in the keyboard controller controls Gate A20. Setting Gate A20 to Fast improves system speed, particularly with OS/2 and Windows
7. BIOS Setup
Typematic Rate Setting When Disabled, the following two items (Typematic Rate and Typematic Delay) are irrelevant. Keystrokes repeat at a rate determined by the keyboard controller in your system. When Enabled, you can select a typematic rate and typematic delay.
Typematic Rate (Chars/Sec) When the typematic rate setting is enabled, you can select a typematic rate (the rate at which character repeats when you hold down a key) of 6, 8, 10,12, 15, 20, 24 or 30 characters per second.
45
7. BIOS Setup
Description Choice
Typematic Delay (Msec) When the typematic rate setting is enabled, you can select a typematic delay (the delay before key strokes begin to repeat) of 250, 500, 750 or 1000 milliseconds.
Security Option Select whether the password is required every time the system boots or only when you enter setup. If you have set a password, select whether the password is required every time the System boots, or only when you enter Setup. System: The system will not boot and access to Setup will be denied if the correct password is not entered at the prompt. Setup: The system will boot, but access to Setup will be denied if the correct password is not entered at the prompt. Note: To disable security, select PASSWORD SETTING at Main Menu and then you will be asked to enter password. Do not type anything and just press <Enter>, it will disabl e security. Once the security is disabled, the system will boot and you can enter Setup freely.
OS Select For DRAM > 64MB Select OS2 only if you are running OS/2 operating system with greater than 64 MB of RAM on your system.
Report No FDD For Win 95 Select Yes to release IRQ6 when the system contains no floppy drive, for compatibility with Windows 95 logo certification. In the Integrated Peripherals screen, select Disabled for the Onboard FDC Controller field.
46

Advanced Chipset Features Setup

7. BIOS Setup
Figure 7.4. Advanced Chipset Features Setup
This section allows you to configure the system based on the specific features of the installed chipset. This chipset manages bus speeds and access to system memory resources, such as DRAM and the external cache. It also coordinates communications between the conventional ISA bus and the PCI bus. It must be stated that these items should never need to be altered. The default settings have been chosen because they provide the best operating conditions for your system. The only time you might consider making any changes would be if you discovered that data was being lost while using your system.
47
7. BIOS Setup
Description Choice
RAM Timing Selectable The value in this field depends on performance parameters of the installed memory chips (DRAM). Do not change the value from the factory setting unless you install new memory that has a different performance rating than the original DRAM
CAS Latency Time When synchronous DRAM is installed, the number of clock cycles of CAS latency depends on the DRAM timing. Do not reset this field from the default value specified by the system designer. You can select CAS latency time in HCLK of 2/2 or 3/3. The system board designer should set the values in this field, depends on the DRAM installed specifications of the installed DRAM or the installed CPU.
Active to Precharge delay Select the precharge delay timer.
DRAM RAS# to CAS# delay This field lets you insert a timing delay between the CAS and RAS strobe signals, used when DRAM is written to, r ead from, or refreshed. Fast gives faster performance; and Slow gives more stable performance. This field applies only when synchronous DRAM is installed in the system.
DRAM RAS# Precharge The precharge time is the number of cycles it takes for the RAS to accumulate its charge before DRAM refresh. If insufficient time is allowed, refresh may be incomplete and the DRAM may fail to retain data.
48
Description Choice
Memory Frequency for Select the memory frequency for DDR200/DDR266 when install the memory with specification of DDR200, or when install the memory with specification of DDR266, or Auto define by the BIOS.
System BIOS Cacheable Selecting Enabled allows caching of the system BIOS ROM at F0000h-FFFFFh, resulting in better system performance. However, if any program writes to this memory area, a system error may result.
Video BIOS Cacheable Selecting Enabled allows caching of the video BIOS ROM at C0000h to C7FFFh, resulting in better video performance. However, if any program writes to this memory area, a system error may result.
7. BIOS Setup
Memory Hole At 15M-16M You can reserve this area of system memory for ISA adapter ROM. When this area is reserved, it cannot be cached. The user information of peripherals that need to use this area of system memory usually discusses their memory requirements.
Delay Transaction The chipset has an embedded 32-bit posted write buffer to support delay transactions cycles. Select Enabled to support compliance with PCI specification version 2.1.
49
7. BIOS Setup
Description Choice
Delay Prior to Thermal Select the interval to setup the delay timer for CPU Thermal-Throttling.
AGP Aperture Size (MB) Select the size of the Accelerated Graphics Port (AGP) aperture. The aperture is a portion of the PCI memory address range dedicated for graphics memory address space. Host cycles that hit the aperture range are forwarded. Host cycles that hit the aperture range are forwarded to the AGP without any translation.
On-Chip VGA setting
On-Chip VGA When Enabled to choice the on-board VGA function, otherwise disabled the on-board VGA function.
On chip Frame buffer size When Enabled, a fixed VGA frame buffer from A000h to BFFFh and a CPU-to-PCI write buffer are implemented.
Boot Display To select display device .
50

Integrated Peripherals

7. BIOS Setup
Figure 7.5. Integrated Peripherals
Description Choice
On-Chip Primary PCI IDE The integrated peripheral controller contains an IDE interface with support for two IDE channels. Select Enabled to activate each channel separately.
51
7. BIOS Setup
Description Choice
IDE Primary Master/Slave PIO The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of the four IDE devices that the onboard IDE interface supports. Modes 0 through 4 provide successively increased performance. In Auto mode, the system automatically determines the best mode for each device.
IDE Primary Master/Slave UDMA UDMA (Ultra DMA) is a DMA data transfer protocol that utilizes ATA commands and the ATA bus to allow DMA commands to transfer data at a maximum burst rate of 33 MB/s. When you select Auto in the four IDE UDMA fields (for each of up to four IDE devices that the internal PCI IDE interface supports), the system automatically determines the optimal data transfer rate for each IDE device.
On-Chip Secondary PCI IDE The integrated peripheral controller contains an IDE interface with support for two IDE channels. Select Enabled to activate each channel separately.
IDE Secondary Master/Slave PIO The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of the four IDE devices that the onboard IDE interface supports. Modes 0 through 4 provide successively increased performance. In Auto mode, the system automatically determines the best mode for each device.
IDE Secondary Master/Slave UDMA UDMA (Ultra DMA) is a DMA data transfer protocol that utilizes ATA commands and the ATA bus to allow DMA commands to transfer data at a maximum burst rate of 33 MB/s. When you select Auto in the four IDE UDMA fields (for each of up to four IDE devices that the internal PCI IDE interface supports), the system automatically determines the optimal data transfer rate for each IDE device.
52
Description Choice
USB Controller Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have USB peripherals.
USB 2.0 controller Select Enabled if your system contains a Universal Serial Bus (USB 2.0) controller and you have USB peripherals.
USB Keyboard Support Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have a USB keyboard.
7. BIOS Setup
USB Mouse support Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have a USB mouse.
AC’97 Audio Select Enabled to use the audio capabilities of your system. Most of the following fields do not appear when this field is Disabled.
53
7. BIOS Setup
Description Choice
Init Display First Initialize the AGP video display before initializing any other display device on the system. Thus the AGP display becomes the primary display.
Internal LAN Select Enabled to active the Internal LAN controller, select Disabled to turn-off the Internal LAN controller when you do not want to use this function
IDE HDD Block mode Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/writes per sector the drive can support.
POWER ON Function When system into suspend mode , to choice wake Up method as list .
54
Description Choice
Hot Key Power ON To select hot key for power on wake up .
Onboard FDC Controller Select Enabled if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it. If you install and-in FDC or the system has no floppy drive, select Disabled in this field.
7. BIOS Setup
Onboard Serial Port 1 Select a logical COM port name and matching address for the first and second serial ports. Select an address and corresponding interrupt for the first and second serial ports.
Onboard Serial Port 2 Select a logical COM port name and matching address for the first and second serial ports. Select an address and corresponding interrupt for the first and second serial ports.
55
7. BIOS Setup
Description Choice
Onboard Parallel Port Select a logical LPT port name and matching address for the physical parallel (printer) port
Parallel Port Mode Selected an operating mode for the onboard parallel port. Select Compatible or extended unless you are certain both your hardware and software support EPP or ECP mode.
EPP Mode Select
ECP Mode Use DMA Select a DMA channel for the port
PWRON After PWR-Fail Select a Power On status by the BIOS setup when power fail.
56
7. BIOS Setup

Power Management Setup

The Power Management Setup allows you to configure you system to most effectively save energy while operating in a manner consistent with your own style of computer use
Figure 7.6. Power Management Setup
57
7. BIOS Setup
Description Choice
Power-Supply Type Select the power supply type.
ACPI function Select to Enabled the ACPI function and select Disabled to disable the APCI.
Power management
Video Off Method
This determines the manner in which the monitor is blanked.
Blank Screen
This option only writes blanks to the video buffer.
V/H SYNC+Blank
This selection will cause the system to turn off the vertical and horizontal synchronization ports and write
blanks to the video buffer.
DPMS
Initial display power management signaling.
58
Description Choice
Video Off In Suspend This determines the manner in which the monitor is blanked.
Suspend Type Select the Suspend Type.
MODEM Use IRQ Name the interrupt request (IRQ) line assigned to the modem (if any) on your system. Activity of the selected IRQ always awakens the system.
7. BIOS Setup
Suspend Mode Setup up the time of the suspend in DOS.
59
7. BIOS Setup
Description Choice
HDD Power Down When enabled and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active.
Soft-Off by PWR-BTTN When enabled, turning the system off with the on/off button places the system is a very low-power-usage state, with only enough circuitry receiving power to detect power button activity or Resume by Ring activity.
CPU THRM-Throttling To select throttling ratio for CPU speed down active when CPU temperature up to over specification .
Wake up by PCI card When Enabled, your can awakens the system from Suspend mode from a PCI card event.
60
Description Choice
Power On by Ring An input signal on the serial Ring Indicator (RI) line (in other words, an incoming call on the modem) awakens the system from a soft off state.
Resume by Alarm When Enabled, your can set the date and time at which the RTC (real-time clock) alarm awakens the system from Suspend mode.
7. BIOS Setup
Reload Global Timer Events:
timer for Standby mode.
When Enabled, an event occurring on each listed device restarts the global
61
7. BIOS Setup

PnP/PCI Configuration Setup

This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.
Figure 7.7. PnP/PCI Configuration Setup
62
Description Choices
PNP OS Installed Select Yes if the system operating environment is Plug-and­Play aware (e.g. Windows 95).
Reset Configuration Data Normally, you leave this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system can not boot.
Resource Controlled by The Award Plug and Play BIOS can automatically configure all the boot and Plug and Play – compatible devices. If you select Auto, all the interrupt request (IRQ) and DMA assignment fields disappear, as the BIOS automatically assigns them
7. BIOS Setup
63
7. BIOS Setup
IRQ n Resources
Figure 7.8. IRQ n Resources
When resources are controlled manually, assign each system interrupt as on of the following type, depending on the type of device using the interrupt.
Legacy ISA Devices compliant with the original PC AT bus specification, requiring a specific interrupt (Such as IRQ4 for serial port 1)
PCI/ISA PnP Devices compliant with the Plug and Play standard, whether designed for PCI or ISA bus architecture.
The Choice: Legacy ISA and PCI/ISA PnP.
PCI/VGA Palette Snoop Leave this field at Disabled.
64

PC Health Status

Figure 7.9. PC Health Status
The BIOS shows the PC health status in this window.
Item Description
7. BIOS Setup
Current System Temp.
Current CPU1 Temp.
Current CPUFAN1/2 Speed
+12V / -12V / +5V / -5V / +3.3V / VBAT / 5VSB
This field displays the current system temperature, if your computer contains a monitoring system.
This field displays the current CPU1 temperature, if your computer contains a monitoring system.
These fields display the current speed of up to three CPU fans, if your computer contains a monitoring system. These fields display the current voltage of input lines, if your computer contains a monitoring system.
65
7. BIOS Setup

Frequency/Voltage Control

Figure 7.10. Frequency/Voltage Control
Spread Spectrum When the system clock generator pulses, the extreme values of the pulse generate excess EMI. Enabling pulse spectrum spread modulation changes the extreme values from spikes to flat curves, thus reducing EMI. This benefit may in some cases be outweighed by problems with timing-critical devices.
66
7. BIOS Setup

Defaults Menu

Selecting “Defaults” from the main menu shows you two options which are described below
Load Fail-Safe Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to:
Load Fail-Safe Defaults (Y/N) ?
Pressing ‘Y’ loads the BIOS default values for the most stable, minimal-performance system operations.
Load Optimized Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to:
Load Optimized Defaults (Y/N) ?
Pressing ‘Y’ loads the default values that are factory settings for optimal performance system operations.
N
N
67
7. BIOS Setup

Supervisor/User Password Setting

You can set either supervisor or user password, or both of them. The differences between are:
SUPERVISOR PASSWORD USER PASSWORD
When you select this unction, the following message will appear at the center of the screen to assist you in creating a password.
Type the password, up to eight characters in length, and press <Enter>. The password typed now will clear any previously entered password from CMOS memory. You will be asked to confirm the password. Type the password again and press <Enter>. You may also press <Esc> to abort the selection and not enter a password.
To disable a password, just press <Enter> when you are prompted to enter the password. A message will confirm the password will be disabled. Once the password is disabled, the system will boot and you can enter Setup freely.
When a password has been enabled, you will be prompted to enter it every time you try to enter Setup. This prevents an unauthorized person from changing any part of your system configuration.
Additionally, when a password is enabled, you can also require the BIOS to request a password every time your system is rebooted. This would prevent unauthorized use of your computer.
You determine when the password is required within the BIOS Features Setup Menu and its Security option (see Section 3). If the Security option is set to “System”, the password will be required both at boot and at entry to Setup. If set to “Setup”, prompting only occurs when trying to enter Setup.
: can enter and change the options of the setup menus.
: can only enter but do not have the right to change the options of the setup menus.
ENTER PASSWORD:
PASSWORD DISABLED.
68
7. BIOS Setup

Exit Selecting

Save & Exit Setup
Pressing <Enter> on this item asks for confirmation:
Save to CMOS and EXIT (Y/N)?
Pressing “Y” stores the selections made in the menus in CMOS – a special section of memory that stays on after you turn your system off. The next time you boot your computer, the BIOS configures your system according to the Setup selections stored in CMOS. After saving the values the system is restarted again.
Exit Without Saving
Pressing <Enter> on this item asks for confirmation:
Quit without saving (Y/N)?
This allows you to exit Setup without storing in CMOS any change. The previous selections remain in effect. This exits the Setup utility and restarts your computer.
Y
Y

POST Messages

During the Power On Self-Test (POST), if the BIOS detects an error requiring you to do something to fix, it will either sound a beep code or display a message.
If a message is displayed, it will be accompanied by:
PRESS F1 TO CONTINUE, CTRL-ALT-ESC OR DEL TO ENTER SETUP

POST Beep

Currently there are two kinds of beep codes in BIOS. This code indicates that a video error has occurred and the BIOS cannot initialize the video screen to display any additional information. This beep code consists of a single long beep followed by two short beeps. The other code indicates that your DRAM error has occurred. This beep code consists of a single long beep repeatedly.
69
7. BIOS Setup

Error Messages

One or more of the following messages may be displayed if the BIOS detects an error during the POST. This list includes messages for both the ISA and the EISA BIOS.
CMOS battery has failed
CMOS battery is no longer functional. It should be replaced.
CMOS checksum error
Checksum of CMOS is incorrect. This can indicate that CMOS has become corrupt. This error may have been caused by a weak battery. Check the battery and replace if necessary.
DISK BOOT failure
INSERT SYSTEM DISK AND PRESS ENTER
No boot device was found. This could mean that either a boot drive was not detected or the drive does not contain proper system boot files. Insert a system disk into Drive A: and press <Enter>. If you assumed the system would boot from the hard drive, make sure the controller is inserted correctly and all cables are properly attached. Also be sure the disk is formatted as a boot device. Then reboot the system.
Diskette drives or types mismatch error
RUN SETUP
Type of diskette drive installed in the system is different from the CMOS definition. Run Setup to reconfigure the drive type correctly.
Display switch is set incorrectly
Display switch on the motherboard can be set to either monochrome or color. This indicates the switch is set to a different setting than indicated in Setup. Determine which setting is correct, and then either turn off the system and change the jumper, or enter Setup and change the VIDEO selection.
Display type has changed since last BOOT
Since last powering off the system, the display adapter has been changed. You must configure the system for the new display type.
EISA configuration checksum error
PLEASE RUN EISA CONFIGURATION UTILITY
The EISA non-volatile RAM checksum is incorrect or cannot correctly read the EISA slot. This can indicate either the EISA non-volatile memory has become corrupt or the slot has been configured incorrectly. Also be sure the card is installed firmly in the slot.
EISA configuration is not complete
PLEASE RUN EISA CONFIGURATION UTILITY
The slot configuration information stored in the EISA non-volatile memory is incomplete.
Note: When either of these errors appear, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility.
Error encountered initializing hard drive
Hard drive cannot be initialized. Be sure the adapter is installed correctly and all cables are correctly and firmly attached. Also be sure the correct hard drive type is selected in Setup.
70
7. BIOS Setup
Error initializing hard disk controller
Cannot initialize controller. Make sure the cord is correctly and firmly installed in the bus. Be sure the correct hard drive type is selected in Setup. Also check to see if any jumper needs to be set correctly on the hard drive.
Floppy disk controller error or no controller present
Cannot find or initialize the floppy drive controller. Make sure the controller is installed correctly and firmly. If there are no floppy drives installed, be sure the Diskette Drive selection in Setup is set to NONE.
Invalid EISA configuration
PLEASE RUN EISA CONFIGURATION UTILITY
The non-volatile memory containing EISA configuration information was programmed incorrectly or has become corrupt. Re-run EISA configuration utility to correctly program the memory.
NOTE: When this error appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility.
Keyboard error or no keyboard present
Cannot initialize the keyboard. Make sure the keyboard is attached correctly and no keys are being pressed during the boot.
If you are purposely configuring the system without a keyboard, set the error halt condition in Setup to HALT ON ALL, BUT KEYBOARD. This will cause the BIOS to ignore the missing keyboard and continue the boot.
Memory address error at ...
Indicates a memory address error at a specific location. You can use this location along with the memory map for your system to find and replace the bad memory chips.
Memory parity error at ...
Indicates a memory parity error at a specific location. You can use this location along with the memory map for your system to find and replace the bad memory chips.
Memory size has changed since last BOOT
Memory has been added or removed since the last boot. In EISA mode use Configuration Utility to reconfigure the memory configuration. In ISA mode enter Setup and enter the new memory size in the memory fields.
Memory verify error at ...
Indicates an error verifying a value already written to memory. Use the location along with your system's memory map to locate the bad chip.
Offending address not found
This message is used in conjunction with the I/O CHANNEL CHECK and RAM PARITY ERROR messages when the segment that has caused the problem cannot be isolated.
71
7. BIOS Setup
Offending segment
This message is used in conjunction with the I/O CHANNEL CHECK and RAM PARITY ERROR messages when the segment that has caused the problem has been isolated.
Press a key to REBOOT
This will be displayed at the bottom screen when an error occurs that requires you to reboot. Press any key and the system will reboot.
Press F1 to disable NMI, F2 to REBOOT
When BIOS detects a Non-maskable Interrupt condition during boot, this will allow you to disable the NMI and continue to boot, or you can reboot the system with the NMI enabled.
RAM parity error
CHECKING FOR SEGMENT ...
Indicates a parity error in Random Access Memory.
Should be empty but EISA board found
PLEASE RUN EISA CONFIGURATION UTILITY
A valid board ID was found in a slot that was configured as having no board ID.
NOTE; When this error appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility.
Should have EISA board but not found
PLEASE RUN EISA CONFIGURATION UTILITY
The board installed is not responding to the ID request, or no board ID has been found in the indicated slot.
NOTE: When this error appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility.
Slot not empty
Indicates that a slot designated as empty by the EISA Configuration Utility actually contains a board. NOTE: When this error appears, the system will boot in ISA mode, which allows you to run the EISA
Configuration Utility.
System halted, (CTRL-ALT-DEL) to REBOOT ...
Indicates the present boot attempt has been aborted and the system must be rebooted. Press and hold down the CTRL and ALT keys and press DEL.
Wrong board in slot
PLEASE RUN EISA CONFIGURATION UTILITY
The board ID does not match the ID stored in the EISA non-volatile memory.
NOTE: When this error appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility.
72
7. BIOS Setup
Floppy disk(s) fail (80)
Unable to reset floppy subsystem.
Floppy disk(s) fail (40)
Floppy Type dismatch.
Hard disk(s) fail (80)
HDD reset failed.
Hard disk(s) fail (40)
HDD controller diagnostics failed.
Hard disk(s) fail (20)
HDD initialization error.
Hard disk(s) fail (10)
Unable to recalibrate fixed disk.
Hard disk(s) fail (08)
Sector Verify failed.
Keyboard is locked out - Unlock the key.
Unlock the key. BIOS detect the keyboard is locked. P17 of keyboard controller is pulled low.
Keyboard error or no keyboard present
Cannot initialize the keyboard. Make sure the keyboard is attached correctly and no keys are being pressed during the boot.
Manufacturing POST loop
System will repeat POST procedure infinitely while the P15 of keyboard controller is pull low. This is also used for M/B burn in test.
BIOS ROM checksum error - System halted
The checksum of ROM address F0000H-FFFFFH is bad.
Memory test fail
BIOS reports the memory tests fail if the onboard memory is tested error.
73
7. BIOS Setup

POST Codes

POST
Description
(hex)
CFh Test CMOS R/W functionality.
Early chipset initialization:
-Disable shadow RAM
C0h
-Disable L2 cache (socket 7 or below)
-Program basic chipset registers
Detect memory
C1h
C3h Expand compressed BIOS code to DRAM
C5h Call chipset hook to copy BIOS back to E000 & F000 shadow RAM.
0h1 Expand the Xgroup codes locating in physical address 1000:0
02h Reserved
03h Initial Superio_Early_Init switch.
04h Reserved
05h
06h
07h
08h
-Auto-detection of DRAM size, type and ECC.
-Auto-detection of L2 cache (socket 7 or below)
1. Blank out screen
2. Clear CMOS error flag
Reserved
Clear 8042 interface
1.
2.
Initialize 8042 self-test
Test special keyboard controller for Winbond 977 series Super I/O chips.
1.
2.
Enable keyboard interface.
09h Reserved
74
POST
(hex)
Description
Disable PS/2 mouse interface (optional).
1.
7. BIOS Setup
0Ah
0Bh Reserved
0Ch Reserved
0Dh Reserved
0Eh Test F000h segment shadow to see whether it is R/W-able or not. If test fails, keep beeping the speaker.
0Fh Reserved
2.
Auto detect ports for keyboard & mouse followed by a port & interface swap (optional).
3.
Reset keyboard for Winbond 977 series Super I/O chips.
Auto detect flash type to load appropriate flash R/W codes into the run time area in F000 for ESCD & DMI
10h
support.
11h Reserved
Use walking 1’s algorithm to check out interface in CMOS circuitry. Also set real-time clock power status, and
12h
then check for override.
13h Reserved
14h Program chipset default values into chipset. Chipset default values are MODBINable by OEM customers.
15h Reserved
16h Initial Early_Init_Onboard_Generator switch.
17h Reserved
18h Detect CPU information including brand, SMI type (Cyrix or Intel®) and CPU level (586 or 686).
19h Reserved
1Ah Reserved
Initial interrupts vector table. If no special specified, all H/W interrupts are directed to
1Bh
SPURIOUS_INT_HDLR & S/W interrupts to SPURIOUS_soft_HDLR.
1Ch Reserved
1Dh Initial EARLY_PM_INIT switch.
75
7. BIOS Setup
POST
Description
(hex)
1Eh Reserved
1Fh Load keyboard matrix (notebook platform)
20h Reserved
21h HPM initialization (notebook platform)
22h Reserved
Check validity of RTC value: e.g. a value of 5Ah is an invalid value for RTC minute.
1.
2.
Load CMOS settings into BIOS stack. If CMOS checksum fails, use default value instead.
3.
Prepare BIOS resource map for PCI & PnP use. If ESCD is valid, take into consideration of the ESCD’s
legacy information.
Onboard clock generator initialization. Disable respective clock resource to empty PCI & DIMM slots.
4.
23h
5.
Early PCI initialization:
-Enumerate PCI bus number
-Assign memory & I/O resource
-Search for a valid VGA device & VGA BIOS, and put it into C000:0.
24h Reserved
25h Reserved
26h Reserved
27h Initialize INT 09 buffer
28h Reserved
Program CPU internal MTRR (P6 & PII) for 0~640K memory address.
1.
2.
Initialize the APIC for Pentium class CPU.
3.
29h
Program early chipset according to CMOS setup. Example: onboard IDE controlle r.
4.
Measure CPU speed.
5.
Invoke video BIOS.
76
POST
Description
(hex)
2Ah Reserved
2Bh Reserved
2Ch Reserved
Initialize multi-language
1.
2Dh
2.
Put information on screen display, including Award title, CPU type, CPU speed ….
2Eh Reserved
2Fh Reserved
30h Reserved
31h Reserved
32h Reserved
33h Reset keyboard except Winbond 977 series Super I/O chips.
34h Reserved
7. BIOS Setup
35h Reserved
36h Reserved
37h Reserved
38h Reserved
39h Reserved
3Ah Reserved
3Bh Reserved
3Ch Test 8254
3Dh Reserved
3Eh Test 8259 interrupt mask bits for channel 1.
3Fh Reserved
77
7. BIOS Setup
POST
Description
(hex)
40h Test 8259 interrupt mask bits for channel 2.
41h Reserved
42h Reserved
43h Test 8259 functionality.
44h Reserved
45h Reserved
46h Reserved
47h Initialize EISA sl ot
48h Reserved
Calculate total memory by testing the last double word of each 64K page.
1.
49h
2.
Program writes allocation for AMD K5 CPU.
4Ah Reserved
4Bh Reserved
4Ch Reserved
4Dh Reserved
Program MTRR of M1 CPU
1.
2.
Initialize L2 cache for P6 class CPU & program CPU wi th proper cacheable range.
4Eh
3.
Initialize the APIC for P6 class CPU.
4.
On MP platform, adjust the cacheable range to smaller one in case the cacheable ranges between each
CPU are not identical.
4Fh Reserved
50h Initialize USB
51h Reserved
52h Test all memory (clear all extended memory to 0)
78
POST
Description
(hex)
53h Reserved
54h Reserved
55h Display number of processo rs (multi-processor platform)
56h Reserved
Display PnP logo
1.
2.
57h
58h Reserved
59h Initialize the combined Trend Anti-Virus code.
5Ah Reserved
5Bh
Early ISA PnP initialization
-Assign CSN to every ISA PnP device.
(Optional Feature)
Show message for entering AWDFLASH.EXE from FDD (optional)
7. BIOS Setup
5Ch Reserved
Initialize Init_Onboard_Super_IO switch.
1.
5Dh
5Eh Reserved
5Fh Reserved
2.
Initialize Init_Onbaord_AUDIO switch.
60h Okay to enter Setup utility; i.e. not until this POST stage can users enter the CMOS setup utility.
61h Reserved
62h Reserved
63h Reserved
64h Reserved
65h Initialize P S/2 Mouse
79
7. BIOS Setup
POST
Description
(hex)
66h Reserved
67h Prepare memory size information for function call: INT 15h ax=E820h
68h Reserved
69h Turn on L2 cache
6Ah Reserved
6Bh Program chipset registers according to items described in Setup & Auto-configuration table.
6Ch Reserved
Assign resources to all ISA PnP devices.
1.
6Dh
2.
Auto assign ports to onboard COM ports if the corresponding item in Setup is set to “AUTO”.
6Eh Reserved
Initialize floppy controller
1.
6Fh
2.
Set up floppy related fields in 40:hardware.
70h Reserved
71h Reserved
72h Reserved
(Optional Feature)
Enter AWDFLASH.EXE if :
73h
-AWDFLASH is found in floppy drive.
-ALT+F2 is pressed
74h Reserved
75h Detect & install all IDE devices: HDD, LS120, ZIP, CDROM…..
76h Reserved
77h Detect serial ports & parallel ports.
80
POST
Description
(hex)
78h Reserved
79h Reserved
7Ah Detect & install co-processor
7Bh Reserved
7Ch Reserved
7Dh Reserved
7Eh Reserved
Switch back to text mode if full screen logo is supported.
1.
-If errors occur, report errors & wait for keys
7Fh
-If no errors occur or F1 key is pressed to continue:
Clear EPA or customization logo.
80h Reserved
7. BIOS Setup
81h Reserved
Call chipset power management hook.
1.
2.
82h
83h Save all data in stack back to CMOS
84h Initialize ISA PnP boot devices
Recover the text fond used by EPA logo (not for full screen logo)
3.
If password is set, ask for password.
81
7. BIOS Setup
POST
Description
(hex)
85h
86h Reserved
87h Reserved
88h Reserved
89h Reserved
USB final Initialization
1.
2.
NET PC: Build SYSID structure
3.
Switch screen back to text mode
4.
Set up ACPI table at top of memory.
5.
Invoke ISA adapter ROMs
6.
Assign IRQs to PCI devices
7.
Initialize APM
8.
Clear noise of IRQs.
90h Reserved
91h Reserved
92h Reserved
93h Read HDD boot sector information for T rend Anti-Virus code
Enable L2 cache
1.
2.
Program boot up speed
3.
Chipset final initialization.
4.
94h
Power management final initialization
5.
Clear screen & display summary table
6.
Program K6 write allocation
7.
Program P6 class write combining
82
POST
Description
(hex)
Program daylight saving
1.
95h
2.
Update keyboard LED & typematic rate
Build MP table
1.
2.
Build & update ESCD
3.
96h
FFh Boot attempt (INT 19h)
Set CMOS century to 20h or 19h
4.
Load CMOS time into DOS timer tick
5.
Build MSIRQ routing table.
7. BIOS Setup
83
SPC-8450-LVA
User’s Manual
CONTEC CO.,LTD. March 2006 Edition
3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/
English http://www.contec.com/ Chinese http://www.contec.com.cn/
No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [03272006]
[07042005] Management No. A-51-043 [03272006_rev2] Parts No. LYEY991
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
