Contec IPC-BX701 Series, IPC-BX700-AC User Manual
IPC Series
BOX-PC
for IPC-BX701 Series
User’s Manual
CONTEC CO.,LTD.
Check Your Package
Thank you for purchasing the CONTEC product.
The product consists of the items listed below.
Check, with the following list, that your package is complete. If you discover damaged or missing items,
contact your retailer.
Product Configuration List
IPC-BX701-AC IPC-BX701P2-AC IPC-BX701P4-AC
Name Pcs. Pcs. Pcs.
BOX-PC 1 1 1
The attachment fittings 2 2 2
CF Card Lock
Slot Cover (Only P2 model, P4 model)
Cable fixed clamp
Power cable 1 1 1
Flat head screw (M3 x 5)
Three-point sems screw (M3 x 6)
Three-point sems screw (M4 x 8)
6 pin mini-DIN cable (2 in 1 cable for PS/2
Mouse & Keyboard function)
Secondary IDE Flat cable
Installation Media 1 *2, *3, *4 1 *2, *3, *4 1 *2, *3, *4
Secondary IDE Power cable 1 1 1
IPC-SLIB-01 *1
(User’s manual, Driver & Utility Soft Set)
Recovery Media
Royalty consent contract
Setup Procedure Document
IPC Precaution List
Product guide (this sheet)
Windows XP Embedded Notes
*1 Please confirm latest information on the CONTEC homepage though the user's manual is stored in IPC-SLIB-01.
*2 It is not packed to the Windows XP Professional pre-install model.
*3 It is not packed to the Windows XP Embedded pre-install model.
*4 It is not packed to the OS uninstall model.
1 1 1
- 2 4
4 4 4
4 4 4
5 5 5
4 4 4
1 1 1
1 1 1
1 1 1
1 *4 1 *4 1 *4
1 *4 1 *4 1 *4
1 *4 1 *4 1 *4
1 1 1
1 1 1
1 *2, *4 1 *2, *4 1 *2, *4
User’s Manual
i
Configuration image
x 2
The attachment
1234
Setup Procedure
Document
Document *4
fitting
Mouse & keyboard function)
CF Card
Lock
6pin mini-DIN cable
(2 in 1 cable for PS/2
IPC-SLIB-0 1
(User's manual,
Driver&Utility
Soft Set)
Royalty
consent contract
Royalty
consent contract *4
BOX-PC
Recovery
Media *4
IPC Precaution List
x 4
Cable
fixed
clamp
Installation
Media *2, *3, *4
IPC
Precaution List
Slot
cover
x 4
Flat head screw
(M3 x 5)
x 5
Three-point
sems screw
(M3 x 6)
Product guide
Product guide
Power
Cable
x 4
Three-point
sems screw
(M4 x 8)
Windo ws XP
Embedded
Notes
Windows XP
Embedded
Notes *2, *4
Secondary IDE Flat cable
Secondary IDE Power cable
Setup Procedure
Copyright
Copyright 2008 CONTEC CO., LTD. ALL RIGHTS RESERVE D.
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this
document.
The information in this document is subject to change without notice.
All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may appear
in this document or for results obtained by the user as a result of using this product.
Trademarks
Intel and Celeron are registered trademarks of Intel Corporation. MS, Microsoft and Windows are
trademarks of Microsoft Corporation. Other brand and product names are trademarks of their respective
holder.
User’s Manual
ii
Table of Contents
Check Your Package ............................................................................................................................... i
Copyright.................................................................................................................................................ii
Trademarks.............................................................................................................................................. ii
Table of Contents ...................................................................................................................................iii
1. INTRODUCTION 1
About the Product.................................................................................................................................... 1
Features ............................................................................................................................................ 1
Supported OS ................................................................................................................................... 2
Customer Support.................................................................................................................................... 3
Web Site ...........................................................................................................................................3
Limited One-Year Warranty ................................................................................................................... 3
How to Obtain Service ............................................................................................................................3
Liability ................................................................................................................................................... 3
Safety Precautions................................................................................................................................... 4
Safety Information ........................................................................................................................... 4
Handling Precautions....................................................................................................................... 4
FCC PART 15 Class A Notice......................................................................................................... 6
2. SYSTEM REFERENCE 7
Specifications .......................................................................................................................................... 7
System Configuration............................................................................................................................ 10
Physical Dimensions ............................................................................................................................. 11
3. HARDWARE SETUP 15
Before Using the BOX-PC for the First Time ...................................................................................... 15
Hardware Setup .....................................................................................................................................16
Locations and settings of Jumpers ................................................................................................. 16
Installing the Hard Disk ................................................................................................................. 17
Attaching the CF Card Retaining Bracket ..................................................................................... 19
PCI Board Installation Procedure .................................................................................................. 20
Fastening the Cable........................................................................................................................ 26
Installation Requirements .............................................................................................................. 27
User’s Manual
iii
4. BIOS SETUP 29
BIOS Setup............................................................................................................................................ 29
Starting the Setup Screen ...............................................................................................................29
Main Menu .....................................................................................................................................32
Standard CMOS Features............................................................................................................... 33
Advanced BIOS Features............................................................................................................... 35
Advanced Chipset Features............................................................................................................ 39
Integrated Peripherals..................................................................................................................... 41
OnChip IDE Device .......................................................................................................................42
Onboard Device.............................................................................................................................. 43
SuperIO Device.............................................................................................................................. 45
Power Management Setup ............................................................................................................. 47
PnP/PCI Configurations Setup....................................................................................................... 49
PC Health Status Setup .................................................................................................................. 53
Frequency/Voltage Control............................................................................................................ 55
Load Fail-Safe Defaults ................................................................................................................. 55
Load Optimized Defaults ...............................................................................................................55
Supervisor/User Password Setting................................................................................................. 56
Save & Exit Setup ..........................................................................................................................56
Exit Without Saving....................................................................................................................... 57
Clear CMOS (EEPROM) data .............................................................................................................. 57
POST Messages..................................................................................................................................... 57
POST Beep............................................................................................................................................ 57
Error Messages...................................................................................................................................... 58
5. EACH COMPONENT FUNCTION 61
Component Name.................................................................................................................................. 61
Component Function............................................................................................................................. 64
Line in Interface : LINE IN............................................................................................................ 64
Line out Interface : LINE OUT...................................................................................................... 64
MIC input Interface : MIC............................................................................................................. 64
Fast-Ethernet : LAN1..................................................................................................................... 65
Gigabit Ethernet : LAN2................................................................................................................ 66
USB Ports....................................................................................................................................... 67
Serial Port Interface........................................................................................................................ 68
CRT Interface................................................................................................................................. 75
LVDS Interface : LVDS................................................................................................................. 76
Keyboard / Mouse Interface : KB / MS......................................................................................... 77
Reset SW : RESET......................................................................................................................... 77
Connector for the Internal Drive (Primary IDE Master Connection) : P-IDE .............................78
Secondary IDE Connector (Secondary IDE Master Connection) : S-IDE.................................... 79
Power Connector for Secondary IDE (S-IDE) : S-IDE................................................................. 80
CF Card Connector (Secondary IDE Slave Connection) : CF ......................................................81
User’s Manual
iv
Expansion Slots (P2 and P4 model)............................................................................................... 82
LED: POWER, ACCESS, STATUS ............................................................................................. 83
Watch-Dog-Timer..........................................................................................................................86
6. APPENDIX 91
Memory Map......................................................................................................................................... 91
I/O Port Addresses................................................................................................................................. 92
Interrupt Level List................................................................................................................................ 93
List of Options....................................................................................................................................... 94
Difference from IPC-BX700 series....................................................................................................... 96
User’s Manual
v
User’s Manual
vi
1. Introduction
1. Introduction
About the Product
This product is an IBM PC/AT compatible, box computer designed for industrial use based on a
low-power-consumption CPU of the Ultra Low Voltage Intel(R) Celeron(R) M Processor 1.0GHz
(FSB400MHz), to operate as a completely nature-cooled (fanless) system. The box computer provides a
variety of interfaces including the USB2.0, LAN (1000BASE-T x 1, 100BASE-TX x 1), and RS-232C
ports, capable of serving for a wide range of applications as a compact platform based on a general-purpose
PC OS. As this series incorporates handpicked components such as the embedded types of CPU and
chipset, it excels in environmental resistance and remains in stable supply for an extended period of time.
You can therefore use the box computer under severe operating conditions such as FA with ease.
Base Model
IPC-BX701-AC
Model with Expansion Slot
IPC-BX701P2-AC (Expansion 2 Slot type)
IPC-BX701P4-AC (Expansion 4 Slot type)
Features
- Ultra-low voltage Celeron M 1.0GHz(FSB400M), 855GME chip set, and 1GB of memory
This product is provided with Intel's (R) 1.0GHz power-saving, ultra-low-voltage Celeron (R) M processor
(FSB400MHz), Intel (R) 855GME chipset and memory of 1GB. The adoption of an embedded-type CPU
and chipset enables a stable power supply.
- Fan-less operation achieved by natural air-cooling
The use of a power-saving CPU and naturally-cooled cabinet structure allows fanless operation.
- Extended interfaces located at the front for easier maintenance
Extended interfaces such as CF card slot (Type I, bootable), serial (RS-232C) x 4, USB2.0 x 6,
1000BASE-T x 1, 100BASE-TX x 1 and audio interfaces are all placed at the front, providing excellent
maintenance advantages. In addition to a general-purpose analog RGB interface, the product has an LVDS
interface, which enables dual screen display. This product also uses the slot-in system that makes it easier
to connect and disconnect a storage device. The Secondary-IDE connector is equipped and the
CD-ROM/DVD-ROM drive can be connected outside.
- Safety design with an anti-disconnection mechanism and BIOS setting retention function
Unnecessary trouble can be avoided by the use of insulation lock clamps for prevention of cable
disconnection and the use of metal fittings for prevention of CF card disconnection. Retention of CMOS
data by EEPROM allows the system to start up even when the battery has run out. In addition, the use of a
CONTEC-customized BIOS (by Award) allows support to be provided at the BIOS level.
User’s Manual
1
1. Introduction
- Structure free from mechanical moving parts (Windows XP Embedded pre-installed model)
The use of a silicon disk for the storage device has eliminated any moving parts, improving the levels of the
environment resistance (ambient temperature, impact, vibration), reliability and quietness.
- Expansion slots to hold PCI / ISA bus boards (Model with Expansion Slot).
IPC-BX701P2-AC has two slots for both PCI and ISA. IPC-BX701P4-AC has two slots for both PCI and
ISA and two slots for PCI. Board size that can be attached is 240(L) x 122(H)[mm]
- Installation-compatible with conventional products in the IPC-BX700/630/620/600 series
For the installation-compatible with conventional products in the IPC-BX700/630/620/600 series, it is easy
to migrate from the existing system.
Supported OS
- Windows XP Professional
- Windows XP Embedded
User’s Manual
2
1. Introduction
Customer Support
CONTEC provides the following support services for you to use CONTEC products more efficiently and
comfortably.
Web Site
Japanese http://www.contec.co.jp/
English http://www.contec.com/
Chinese http://www.contec.com.cn/
Latest product information
CONTEC provides up-to-date information on products.
CONTEC also provides product manuals and various technical documents in the PDF.
Free download
You can download updated driver software and differential files as well as sample programs available in
several languages.
Note! For product information
Contact your retailer if you have any technical question about a CONTEC product or need its price,
delivery time, or estimate information.
Limited One-Year Warranty
CONTEC products are warranted by CONTEC CO., LTD. to be free from defects in material and
workmanship for up to one year from the date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned freight prepaid with a copy of the original
invoice and a Return Merchandise Authorization to the distributor or the CONTEC group office, from
which it was purchased.
This warranty is not applicable for scratches or normal wear, but only for the electronic circuitry and
original products. The warranty is not applicable if the device has been tampered with or damaged through
abuse, mistreatment, neglect, or unreasonable use, or if the original invoice is not included, in which case
repairs will be considered beyond the warranty policy.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of the original invoice. Please
obtain a Return Merchandise Authorization number (RMA) from the CONTEC group office where you
purchased before returning any product.
* No product will be accepted by CONTEC group without the RMA number.
Liability
The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor be
liable for any incidental or consequential damages due to such defect or consequences that arise from
inexperienced usage, misuse, or malfunction of this device.
User’s Manual
3
1. Introduction
Safety Precautions
Understand the following definitions and precautions to use the product safely.
Safety Information
This document provides safety information using the following symbols to prevent accidents resulting in
injury or death and the destruction of equipment and resources. Understand the meanings of these labels to
operate the equipment safely.
DANGER
WAR NI NG
CAUTION
DANGER indicates an imminently hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result
in minor or moderate injury or in property damage.
Handling Precautions
WA RN IN G
- Always check that the power supply is turned off before connecting or disconnecting power cables.
- Do not modify the product.
- Always turn off the power before inserting or removing circuit boards or cables.
- This product is not intended for use in aerospace, space, nuclear power, medical equipment, or other
applications that require a very high level of reliability. Do not use the product in such applications.
- If using this product in applications where safety is critical such as in railways, automotive, or disaster
prevention or security systems, please contact your retailer.
- Do not attempt to replace the battery as inappropriate battery replacement poses a risk of explosion.
- For battery replacement, contact your retailer as it must be performed as a process of repair.
- When disposing of a used battery, follow the disposal procedures stipulated under the relevant laws and
municipal ordinances.
CAUTION
- Do not use or store the product in a location exposed to extremely high or low temperature or
susceptible to rapid temperature changes.
Example: - Exposure to direct sun
- In the vicinity of a heat source
- Do not use the product in extremely humid or dusty locations. It is extremely dangerous to use the
product with its interior penetrated by water or any other fluid or conductive dust. If the product must
be used in such an environment, install it on a dust-proof control panel, for example.
- Avoid using or storing the device in locations subject to shock or vibration.
User’s Manual
4
1. Introduction
- Do not use the product in the vicinity of devices that generate strong magnetic force or noise. Such
devices will cause this device to malfunction.
- Do not use or store the product in the presence of chemicals.
- The lower center of the left face (seen from the connector's front surface) may become hot. To avoid
being burned, do not touch that section while the product is in operation or immediately after turning
off the power. Avoid installation in a location where people may come into contact with that section.
- To clean the BOX-PC, wipe it gently with a soft cloth dampened with either water or mild detergent.
Do not use chemicals or a volatile solvent, such as benzene or thinner, to prevent pealing or
discoloration of the paint.
- Hard disks have a limited life span. Please perform systematic backup and maintenance.
- CONTEC does not provide any guarantee for the integrity of data on hard disks.
- To prevent corruption of files, always shutdown the OS before turning off the BOX-PC.
- 2.5 inches hard disk drive (HDD) of our company has not guaranteed use by continuation and
continuation power for 24 hours. When it is used by continuation operation and continuation power, a
life fails extremely. In the case of a 24 hours operation system, use of our company silicon disk drive
(SDD) is recommended.
- Before installing or uninstalling an expansion board (P2, 4P model) or connecting or disconnecting a
connector, be sure to unplug the power cable from the wall outlet.
- CONTEC reserves the right to refuse to service a product modified by the user.
- In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power cord
immediately and contact your retailer.
- To connect with peripherals, use a grounded, shielded cable.
- Use an AC cable that is compatible with both the rated supply voltage and the receptacle. (The cable
provided with the product is for 125VAC.)
- Component Life:
(1) Power supply---Estimated life is about 6 years based on continual operation at 40°C
(horizontal installation). However, (higher) operating temperatures will result
in shorter life.
(2) Battery---The internal calendar clock and CMOS RAM are backed by a Lithium primary battery.
The backup time at a temperature of 25°C with the power disconnected is 10 years or
more.
* Replacement of expendables is handled as a repair (there will be a charge).
User’s Manual
5
1. Introduction
FCC PART 15 Class A Notice
NOTE
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference at his own expense.
WARNING TO USER
Change or modifications not expressly approved the manufacturer can void the user's authority to
operate this equipment.
User’s Manual
6
2. System Reference
2. System Reference
Specifications
Table 2.1. Functional Specifications < 1 / 2 >
Model IPC-BX701-AC IPC-BX701P2-AC IPC-BX701P4-AC
CPU Ultra Low Voltage Intel(R) Celeron(R)M Processor 1.0GHz, FSB400MHz
Chip set Intel(R) 855GME
Memory
Video
System resolution 640 x 480 (16,770,000 colors), 800 x 600 (16,770,000 colors),
Audio
IDE HDD
I/F
CF card slot CF CARD Type I x 1 (dedicated to memory card, Secondary IDE Slave) bootable
Serial I/F RS-232C (general-purpose) : 4ch (SERIAL PORT1, 2, 3, 4) 9pin D-SUB connector
USB I/F 6ch (USB 2.0 specification)
Keyboard/mouse I/F PS/2 type (6 pin mini-DIN connector), (bundled with keyboard / mouse distribution cable)
General-purpose I/O -
L2 Cache 512KB
Main memory 1GB (2.5V 184pin DDR SDRAM PC2700 DIMM Socket x 1)
BIOS ROM 128KB E0000H - FFFFFH (Award)
Controller Intel 855GME (Built into the controller)
Video RAM Main memory shared
Video BIOS 48KB (C0000H - CBFFFF)
Display I/F Analog RGB I/F x 1 (15pin HD-SUB connector x 1)
LVDS I/F x 1 (26 pin half pitch connector x 1)
1,024 x 768 (16,770,000 colors), 1,280 x 1,024 (16,770,000 colors),
1,600 x 1,200 (16,770,000 colors) *1
AC97 compliant
Line IN : φ3.5 Stereo mini jack
Full-scale input level 1.6Vrms (Typ.)
LINE OUT : φ3.5 Stereo mini jack
Full-scale output level 1.5Vrms (Typ.), Dual 50mW Amplifier
MIKE IN : φ3.5 mono mini jack
Full-scale input level 1.6Vrms (Typ.)
Primary Ultra DMA/100
2.5 inch IDE HDD or silicon disk drive: 1 internal unit (Primary IDE Master)
Secondary Equipped with a dedicated 40pin, header connector
(for connection of an optional CD-ROM/DVD-ROM) (right surface)
Baud rate : SERIAL1, 2 is 50 -115,200bps and SERIAL3, 4 is 50 -230,400bps
For touch panel communication : within 1ch (SERIAL PORT5) LVDS connector
I/F 100BASE-TX/10BASE-T RJ-45 connector LAN1
Controller Intel(R) ICH4 integrated
I/F 1000BASE-T/100BASE-TX/10BASE-T RJ-45 connector LAN2
Controller Intel(R) 82541PI
User’s Manual
7
2. System Reference
Table 2.1. Functional Specifications < 2 / 2 >
Model IPC-BX701-AC IPC-BX701P2-AC IPC-BX701P4-AC
Watch dog timer Software programmable, 255 level (1sec - 255 sec)
Causes a reset upon time-out.
Expansion board slot None Shared PCI/ISA slot x 2,
Installable board length
: 240mm (Max.)
RTC/CMOS Lithium backup battery life: 10 years or more
Power
supply
Physical dimensions
(mm)
Weight
*1 It cannot output it to the LVDS I/F.
*2 Please do not connect it excluding the CD-ROM/DVD-ROM drive.
*3 The total capacity for power supply to external devices at +5 V must fall within 4 A.
* The PCI bus slots are 32-bit type, not verified for operation of boards for both 32-bit and 64-bit bus slots.
Input supply
voltage
Current
consumption
Expansion
board
power-supply
capacity
External
device power
supply
capacity
The real-time clock is accurate within ±3 minutes (at 25°C) per month
(ICH4 integrated RTC).
Automatically switched between 85 - 132 VAC and 170 - 265 VAC (47 - 63 Hz)
50VA (Max.) 90VA (Max.) 115VA (Max.)
None +5V : 2A (1A x 2 slot),
-5V : Not supplied,
-12V : 80mA,
+12V : 0.5A
- Power connector for *2
S-IDE *1 (S-IDE PWR)
+5V : 1.0A *3,
+12V : 1.0A
- CF card slot
+5V : 500mA *3
- USB I/F
+5V : 3A (500mA x 6) *3
262(W) x 262(D) x 55(H)
(No protrusions)
About 3.3kg
(Storage device isn't included)
- Power connector for *2
S-IDE *1 (S-IDE PWR)
+5V : 1.0A *3,
+12V : 1.0A
- CF card slot
+5V : 500mA *3
- USB I/F
+5V : 3A (500mA x 6) *3
- Expansion board slot
+5V : 2A (1A x 2 slot) *3,
+3.3V : 1A (total 2 slot),
-5V : Not supplied,
-12V : 80mA,
+12V : 0.5A
262(W) x 262(D) x 115(H)
(No protrusions)
About 4.0kg
(Storage device isn't included)
Shared PCI/ISA slot x 2,
PCI slot x 2
Installable board length
: 240mm (Max.)
+5V : 4A (1A x 4 slot),
-5V : Not supplied,
-12V : 80mA,
+12V : 0.5A
- Power connector for *2
S-IDE *1 (S-IDE PWR)
+5V: 1.0A *3,
+12V: 1.0A
- CF card slot
+5V: 500mA *3
- USB I/F
+5V: 3A (500mA x 6) *3
- Expansion board slot
+5V : 4A (1A x 4 slot) *3,
+3.3V : 1A (total 4 slot),
-5V : Not supplied,
-12V : 80mA,
+12V : 0.5A
262(W) x 262(D) x 160(H)
(No protrusions)
About 4.6kg
(Storage device isn't included)
User’s Manual
8
2. System Reference
Table 2.2. Installation Environment Requirements
Parameter Requirement description
Power supply
specifications
Ambient
specifications
*1 When Windows OS operates.
*2 When the HDD is not in use.
Allowable instantaneous Less than 20ms
power outage
Dielectric strength
Operating temperature
Storage temperature
Humidity 10 - 90%RH (No condensation)
Floating dust particles Not to be excessive
Corrosive gases None
Line noise
Line-noise
resistance
Vibration
resistance
*2
Impact resistance *2
Grounding
Static electricity
resistance
Sweep resistance
One minute each for AC2.0kV (input - FG) 20mA
50MΩ (500VDC)
0 - 50°C (SDD in use *1),
5 - 45°C (HDD in use)
-10 - 60°C
AC line/±2kV,
Signal line/±1kV (IEC61000-4-4Level 3, EN61000-4-4 Level 3)
Contact discharge/±4kV (IEC61000-4-2 Level 2, EN61000-4-2 Level 2)
Atmospheric discharge/±8kV (IEC61000-4-2 Level 3,
EN61000-4-2 Level 3)
10 - 57Hz/semi-amplitude 0.15mm 57 - 150Hz/2.0G
40 min. each in x, y, and z directions
(JIS C60068-2-6-compliant, IEC60068-2-6-compliant)
10G, half-sine shock for 11 ms in x, y, and z directions
(JIS C60068-2-27-compliant, IEC60068-2-27-compliant)
Class D grounding (previous class 3 grounding)
User’s Manual
9
2. System Reference
System Configuration
Expansion slot
(P2 and P4 models)
PC-HELPER
Series
When three or more slots are needed, select
the P4 model. To use five or more slots or
a full-size board, connect the expansion unit.
Expansion
bus adapter
PCI, ISA
Half-size board
LAN1
(100BASE-TX)
LINE IN
LINE OUT
MIC
USB x 2
LAN1
LINE IN
100/10
LINE OUT
MIC
RS-232C x 4
P - IDE
LVDS
SERIAL3
SERIAL4
USB
USB
SERIAL1
CF
SERIAL2
USB x 4
2.5inch hard (silicon) disk drive
Figure 2.1. Syst em Configuration
IPC-BX701P2-AC
LAN2
1000/100/10
POWER
ACCESS
VGA KB/MS
STATUS
RESET
Expansion chassis
LAN2
(1000BASE-T)
Option CD-ROM/DVD
drive
Display
General-purpose analog input
display
Keyboard/mouse
User’s Manual
10
2. System Reference
Physical Dimensions
IPC-BX701-AC
PASS
VCCI-A
MADE IN xxxxxx
E
C
TI
PS
N
4-φ5
CONTEC CO., LT D.
CTENCO
302
284
262
170
262
CAUTION!
HOT SURFACES
2-R2.5
5
R5.5
20
126
56
68
(26.9)
55
LAN1
LINE IN
100/10
LINE OUT
MIC
USB
P - IDE
LVDS
SERIAL3
SERIAL4
USB
SERIAL1
SERIAL2
CF
VGA KB/MS
XXXXXXXXXXXXXXXXXXXXX
9
26 210 26
LAN2
1000/100/10
POWER
ACCESS
STATUS
RESET
[mm]
Figure 2.2. IPC-BX701-AC
User’s Manual
11
2. System Reference
IPC-BX701P2-AC
VCCI-A
MADE IN JAPAN
CONTEC CO.,LTD.
PASS
E
C
TCI
N
P
S
TENCO
302
284
262
XXXXXXXXXXXXXXXXXXXXX
9
26
170
262
CAUTION!
HOT SURFACES
4-
φ
5
2-R2.5
5
R5.5
20
126
68
56
(26.9)
115
Figure 2.3. IPC-BX701P2-AC
21026
4-f5
VGA KB/ MS
LAN2
1000/100/10
POWER
ACCESS
STATUS
RESET
[mm]
LINE IN
LAN1
100/10
LINE OUT
MIC
USB
P - IDE
LVDS
SERIAL3
SERIAL4
USB
SERIAL1
CF
SERIAL2
User’s Manual
12
2. System Reference
IPC-BX701P4-AC
VCCI-A
MADE IN JAPAN
CONTEC CO . ,LT D.
PASS
P
E
C
TCI
N
S
E
NTOC
302
284
262
XXXXXXXXXXXXXXXXXXXXX
9
26
170
262
CAUTION!
126
HOT SURFACES
68
56
21026
(26.9)
4-φ5
2-R2.5
5
R5.5
20
160
LINE IN
LAN1
100/10
LINE OUT
MIC
USB
P - IDE
LVDS
SERIAL3
SERIAL4
USB
SERIAL1
SERIAL2
LAN2
1000/100/ 10
POWER
ACCESS
VGA KB/MS
STATUS
RESET
CF
[mm]
Figure 2.4. IPC-BX701P4-AC
User’s Manual
13
2. System Reference
User’s Manual
14
3. Hardware Setup
3. Hardware Setup
Before Using the BOX-PC for the First Time
Follow the next steps to set up the BOX-PC:
STEP1 Install the hard disk and set jumper switches.
By referring to the information in this chapter, set the BOX-PC.
STEP2 Connect cables.
Connect necessary external devices, such as COM and a CRT, to this product using
appropriate cables.
STEP3 Turn on the power.
After verifying that you have correctly followed steps 1 and 2, turn on the power. If you feel
something is wrong after turning on the power, turn off the power immediately and check to
see if the BOX-PC has been set up correctly.
STEP4 Set up BIOS.
By referring to Chapter 4, set up BIOS. This setup requires a keyboard and a display.
* Before using the BOX-PC, be sure to execute " LOAD SETUP DEFAULTS" to initialize
the BIOS settings to their default values.
(See Chapter 4, "Main Menu.")
CAUTION
If your BOX-PC is a Windows preinstalled model, be sure to connect the keyboard and mouse to it
before turning the power on for the first time.
User’s Manual
15
3. Hardware Setup
Hardware Setup
- Before you start, be sure that the power is turned off.
- Remove only those screws that are explained. Do not move any other screw.
Locations and settings of Jumpers
(1) Remove the top cover.
Figure 3.1. Removing the Top Cover
When you remove the top cover and hard disk bracket, the connectors, jumpers, and switches are laid out as
shown in the figure below:
JBAT1
JP3
Front
Figure 3.2. Locat i ons and Settings of Jumpers, Connectors, and Switches inside the Top Cover
(2) Set the jumpers according to the list below.
Table 3.1. Jumper List
No.
JBAT1
Clear CMOS(EEPROM) 1 - 2 shorted 57
JP3
Function Factory setting
Reference
Page
Remarks
(3) After setting the jumpers, attach the bracket and top cover back in place in the reverse order in which
they were removed.
User’s Manual
16
3. Hardware Setup
Installing the Hard Disk
(1) Remove the hard disk bracket from this product.
Figure 3.3. Removing the Hard Disk Bracket
(2) Remove the part of socket from the hard disk bracket.
Figure 3.4. Removing the Hard Disk Socket
(3) Peel the protective film off the thermal conduction sheet, and install the hard disk (silicon disk) to the
hard disk bracket. Then fasten it with four screws. Fasten the disk using the outer or inner hole
depending on the model you are using. (The figure below shows an example that uses the inner screw
hole.)
Figure 3.5. Installing the Hard Disk to the Bracket
User’s Manual
17
3. Hardware Setup
(4) Install the part of socket to the hard disk bracket. Plug the HDD into the socket first, then fasten it with
two screws.
Figure 3.6. Installing the Hard Disk to the Socket
CAUTION
Connect the HDD cable in alignment with pins from the left end of the connector on the HDD side.
Four master/slave setting pins are left unconnected on the right side. Be aware that connecting the
power with the connector misaligned will damage the cable.
(5) Insert the bracket holding the HDD into the system unit, then fasten it with the screws.
Figure 3.7. Installing the Hard Disk Bracket
CAUTION
When fastening the HDD to the bracket or the HDD bracket to the system unit, do not use any tool
which vibrates the HDD, such as an electric screwdriver. Using such a tool can break the HDD.
User’s Manual
18
3. Hardware Setup
Attaching the CF Card Retaining Bracket
(1) After inserting a CF Card, fasten the bundled CF Card retaining bracket with a screw.
Figure 3.8. Attaching the CF Card Retaining Bracket
CAUTION
Insert the CF Card face up.
Figure 3.9. After Attaching the CF Card Retaining Bracket
User’s Manual
19
3. Hardware Setup
PCI Board Installation Procedure
IPC-BX701P2-AC
(1) Be sure the power is turned off.
(2) Remove the top cover.
Figure 3.10. Removing the Top Cover
(3) Remove the brace that holds the printed circuit board (PCB) down.
Remove the screws on the brace. The brace will separate toward you.
Figure 3.11. Removing the PCB Brace 2
User’s Manual
20
3. Hardware Setup
(4) Insert the board into the slot and fasten it with screws.
Figure 3.12. Installation of an Expansion Board
CAUTION
Make sure carefully that the board has been secured in the slot.
(5) Install the PCB brace. It can hold down a board if its height is at least 68mm.
For an ISA board,
attach the PCB brace
with the retaining brackets
turned inside out.
Figure 3.13. Attaching the PCB Brace
User’s Manual
21
3. Hardware Setup
(6) Replace the expansion slot cover.
Figure 3.14. Replacing the Top Cover
User’s Manual
22
3. Hardware Setup
IPC-BX701P4-AC
(1) Be sure the power is turned off.
(2) Remove the top cover.
Figure 3.15. Removing the Top Cover
(3) Remove the brace that holds the printed circuit board (PCB) down.
Remove the screws on the brace. The brace will separate toward you.
Figure 3.16. Removing the PCB Brace 2
User’s Manual
23
Loading...
