CONTA-CLIP EMS-2-Plotter-System User Manual
EMS-2
Easy-Marking-System
EMS-2
Operating Instructions
Release: March 12, 2012
©
EMS-2
Easy-Marking-System
Operating Instructions
EMS-2
1. Introduction...................................................................................................2
2. Items supplied ..............................................................................................3
3. Product overview ..........................................................................................4
4. Set-up ...........................................................................................................5
5. Operation......................................................................................................6
6. Cleaning and product care ...........................................................................9
7. Accessories ................................................................................................10
8. Troubleshooting ..........................................................................................11
9.Technical information...................................................................................12
10. Instructions for packaging the plotter EMS-2............................................13
11. Safety instructions ....................................................................................14
1
1. Introduction:
Thank you for purchasing the EMS-2, a flexible plotter that helps you label marking
elements quickly and easily.
Rugged construction in stylish aluminium
Labelling area A3 size 440 mm x 305 mm, A4 size 220 mm x 305 mm
Easy to change fixtures to suit a variety of marking elements
Automatic fixture recognition largely avoids the need to select marking elements
Optimum plotter pen seal. The pens can be stored in the plotter's pen station
Auto calibration no adjustment necessary
Capable of labelling marking elements up to 10.5 mm in height.
Special solutions for up to 15 mm are possible
Universal power supply of 100-240V AC
The special start-up function for the plotter pens ensures neat labelling right from
the very first marking element
PC interfaces: centronics parallel and USB ports
Control language: HPGL
I/O interface for connecting peripheral equipment, e.g. handlings, etc.
Material held in place by vacuum contact (option)
Possible to update EMS-2 software through PC connection and downloading from
the Internet
2
2. Items supplied
Please check you have received all the items supplied with your labelling device
(see list below).
Please retain the packaging in case you need to return the device.
The following items are supplied as standard:
1. Plotter EMS-2
2. Power supply with corresponding mains power cord
3. USB cable
4. Operating instructions
2.
1.
3.
4.
3
3. Product overview
6 7 8 9
5
Segment 1 Segment 2 Segment 3 Segment 4
4
3
1
2
16
5
1) Plotting area
2) Pen station
3) Sealed storage holders in pen station
4) Start-up writing area
5) Pin stops for fixtures
6) Vacuum supply for the individual segments
7) Penholder
8) Drop pen unit
9) Vacuum connection point
10) Mains connection
11) Interface for optional external devices
12) Centronics printer port
13) USB port
14) Control panel/control keys
15) Writing arm
16) Fixture recognition sensors
15
10
11
12
13
14
4
