Con-Serv SR 020 Installation Manual

INSTALLATION INSTRUCTIONS

Polar Slide Rail (SR 020)

1 2 3 4

Top bracket is fixed to
rail - do not remove.
Select height for rail
and screw wall mount
to wall.

Bottom bracket can
be raised or lowered
to suit wall mount.
When both wall
mounts are in place,
tighten grub screws
top and bottom.

Screw top wall mount and flange 700mm
below water outlet. (Vertical)

Screw wall mount
and flange 700mm
below water outlet.

700

(Vertical)

Fit top and bottom
brackets to wall
mounts by
tightening rear grub
screws (hex key).

SR 020 Mii H040 R1
