Conrad X-220 User Manual
User Manual V1.0
Congratulations on purchasing your new your
new X-220 racing drone.Please read this manual
carefully before using this product.
We recommend checking the following page
at www.conrad.com for news and updates for
product specs to manual updates. Due to ongoing
development, information contained in this manual
may change without prior notice.
If you have any question or concerns about your
product, please contact your local Conrad shops or
Conrad customer service.
2
3-6
8
9
9
10
10
10
10
11
11
11
13
14
14
17-18
18-19
20
20
14-17
12-13
CONTENTS
Contents
Disclaimer & warning
In a box
1.0 Get to know your aircraft
2.0 Specifications
3.0 Attention before flight
4.0 Charge the battery
5.0 Assemble Aircraft
5.1 Propeller Installed
5.2 Battery Installed
6.0 Ready to fly
6.1 Binding
6.2 Motor Unlock/Lock
7.0 Operation Instruction
8.0 End flight
9.0 Additional remark
9.1 Remote controller menu operate
9.2 Remote controller system menu operate
9.3 Remote controller function menu operate
9.4 Remote controller notice
9.5 OSD Interface introduction
9.6 Power Board introduction
