Conquer Treadmill Desk

Manual and Assembly Instructions

Read all instructions carefully before using this
product. Retain this owner’s manual for future

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

Product name: Conquer Treadmill Desk

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

Safety Warnings:

Warning: Consult with your physician or health professional before beginning any exercise
regimen. Treadmill should be carefully assembled and covered with the motor shield before
connecting to power.

 Ensure the safety clips are attached to clothing or belt before using the treadmill.

 Please do not modify any part of the equipment, this may damage the equipment.

 Position the treadmill on a clean, level surface. Do not place the treadmill on thick

carpet as it may interfere with proper ventilation. Do not place the treadmill near

water or outdoors.

 Do not start the treadmill while you are standing on the walking belt. After turning the

power on and adjusting the speed control, there may be a pause before the walking

belt begins to move. Always stand on the foot rails on the sides of the frame until the

belt is moving.

 Wear appropriate clothing when exercising on the treadmill. Do not wear long or

loose fitting clothing that may be caught in the treadmill. Always wear running or

other athletic shoes with rubber soles.

 For adult use only. Keep children and pets away from the treadmill.

 Treadmill is for indoor use only, not for outdoor use. Use and store in a clean, dry

place.

 If the speed increases suddenly or inadvertently (for any reason), please pull out the

safety lock from the console and the treadmill will stop.

 Do not use an extension cord, do not lengthen existing cord or change the cord plug.

Do not put any heavy thing on cord or place cord near any heat source. Do not use

treadmill with a power strip/surge protector, as it may cause a sudden stop and/or

result in injury.

 Turn off the power after each use. Unplug when unit will not be used for an extended

period.

 This treadmill is for home use only, and is not intended for commercial use.

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

Product name: Conquer Treadmill Desk

Parts:

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

Ⅰ

Ⅳ

Ⅶ

Ⅱ

Ⅴ

31 34

Ⅲ

Ⅵ

40 42

No. Description Specification Qty.

I Main Frame 1set
II Safety lock 1pc
III Bottle 1pc

Ⅳ Base tube 1set
Ⅴ
Ⅵ
Ⅶ Desk 1pc

31 Nylon nut M8 4pcs
34 Flat washer D8 8
40 Bolt M8*55 4
42 Bolt M8*10 4

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

Upright frame 1set
Tools 1set

Product name: Conquer Treadmill Desk

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

Assembly Instructions:

STEP 1：

Open the carton, take out the above parts, and put the treadmill (main frame) onto level
ground. Use a partner to help you lift, as this piece is heavy!

Step 2:

Assemble upright frame/desk support (V) onto base tube (IV) with 4pcs M8*55 bolt(40) and
4pcs D8 flat washer(34) and 4pcs M8 nylon nut(31).

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

Product name: Conquer Treadmill Desk

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

Step 3: Assemble desk (VII) onto upright frame/desk support (V) with 4pcs M8*10 bolts(42)
and 4pcs D8 flat washer(34). Connect the wires.

Step 4: Put the treadmill/main frame under desk, then connect wires from control unit to
treadmill.

Step 5:

Be sure all wires are connected, be
sure all bolts are tightened, then put
safety lock on.

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

Product name: Conquer Treadmill Desk

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

NOTE：Fasten all the bolts after making sure the treadmill is assembled as instructed.
Connect the power after double checking. For other operations, follow below instructions.

Technical Parameters

Assembly

size(mm)

Running

space(mm)

N.W. kg

4 window LED

display

1645*1200*（1045~1445）mm

400*1250mm Output As shown

speed time distance calorie

Input As shown

Speed

0.6-4mile/H

range

Max.

110KG/242 lbs.

Weight

Grounding methods:

This product must be grounded. If it should malfunction or breakdown, grounding provides a
path of least resistance for electric current to reduce the risk of electric shock. This product is
equipped with a cord having an equipment-grounding conductor and a grounding plug. The
plug must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.

*WARNING* Improper connection of the equipment-grounding conductor can result in risk of

electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether
the product is properly grounded. Do not modify the plug provided with the product – if it will not
fit the outlet; have a proper outlet installed by a qualified electrician.
This product is for use on a nominal 240-volt circuit and has a grounding plug that looks like the
plug illustrated in sketch A in following figure. Make that the product is connected to an outlet
having the same configuration as the plug. No adapter should be used with this product.

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

Product name: Conquer Treadmill Desk

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

Maintenance and Belt Adjustment:
Clean: General cleaning or the unit will greatly prolong the treadmill’s life. Keep treadmill

clean by dusting regularly. Be sure to clean the exposed part of the deck on either side of
the walking belt and also the side rails. Reduce the buildup of foreign material underneath
the belt by wearing clean shoes.

Warning: Always unplug the treadmill from electrical outlet before removing the
motor cover, cleaning, or servicing the unit. At least once a year remove the motor

cover and vacuum under the motor cover.

BELT AND DECK LUBRICATION

This treadmill is equipped with a pre-lubricated, low maintenance deck system. The belt/
deck friction play a major role in the function and life of your treadmill, thus requiring
periodic lubrication. Treadmill lubricant is readily available online and elsewhere.
Periodically inspect the deck for optimal performance.

We recommend lubrication of the deck according to the following timetable:

 Light use (less than 3 hours/ week) - Annually

 Medium use (3-5 hours/ week) - Every six months

 Heavy use (more than 5 hours/ week) - every three months

NOTE: Any repairs require a professional technician.

 If treadmill is in use for 2 hours without stopping, be sure to power it down for at

least 10 minutes for continued optimal performance.

 The belt may slip if too loose during use. If the belt is too tight, it may affect the

performance of motor and increase the abrasion of roller and belt. The belt can
be lifted away from the deck for around 50 — 75mm.

 The treadmill belt may gradually shift to one side or another, and may feel “loose”

while walking. This can lead to premature wear and tear. Realigning the belt is
simple, all you need is an Allen wrench.

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

Product name: Conquer Treadmill Desk

To center the treadmill belt:

1. First, be sure treadmill is on a level surface.

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

Run treadmill to check the condition. If the

belt has drifted to the right, pull out the safety

lock and switch. Turn the right adjusting bolt

near end cap 1/4 turn clockwise, then run until

belt centers. Be careful when tightening and

loosening bolts as less is more. Perform only

a quarter-inch turn at a time. Test your work

by turning the treadmill on to its lowest setting

for 30 seconds. If belt seems to be properly

aligned, your work is done. If not, then adjust

further; just do so in small increments. A

2. If the belt has drifted to the left, pull out of the

safety lock and switch. Turn the left adjusting

bolt 1/4 turn clockwise, then run unit until belt

centers. B

3. Check the belt for looseness periodically. Pull

out safety lock and switch, turn the left and

right adjusting bolt 1/4 turn clockwise.

Re-start treadmill to confirm the belt tightness

and run until the belt is correct. C

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

Product name: Conquer Treadmill Desk

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

Exploded Diagram

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

Product name: Conquer Treadmill Desk

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

Item

no.

1

2

3

4

5

6

7

DESCRIPTION QTY

Main Frame

L/R base tube

Bottom upright tube

Monitor base

Motor base

Reinforce tube of running

board

Computer frame

1

2

1

1

1

1

1

Item

no.

62 Flat washerφ20*φ23*1 4

63

64

65 Screw ST2.5*7 7

66 Screw ST4.2*15 10

67 Limited bushφ8.5*φ12*80 4

68 Bush φ8.5*φ12*25 2

DESCRIPTION QTY

E-shaped snap ring

desk

2

1

8 M10 foot pad adjust frame

9 Upper upright tube

10 Inside upright tube

11 Up down tube

12 Up down frame fix plate

13 Desk support

14 axle

15 Bolt M8*100

16 Bolt M8*30 1

4

2

2

2

4

1

1

2

69 Screw M4*15 4

70 Foot pad M10*30 8

71 Plastic screw bloack 2

72 Plastic bush

73 Kss

74 Motor upper cover 1

75 Motor bottom cover

76 Side rail 2

77 L&R rear end cap

1

1

1

1

17 Bolt M8*45 2

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

78 Rubber blanketφ29.5*φ10*6 6

Product name: Conquer Treadmill Desk

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

18 Bolt M8*40 2

19 Bolt M8*20 2

20

21 Bolt M8*60 3

22 Bolt M8*35 2

23 Bolt M6*60 2

24 Bolt M6*35 2

25 Screw ST4.8*25 4

26 Screw ST4.2*12 21

27 Screw ST4.2*12 2

28 Screw ST4.2*20 2

29 Screw M5*12 9

30 Screw ST3.0*8 4

W1507-00001double head

boltφ8*210

2

79 Cap 1

80 EVA pad 1

81 wheelφ70*φ8.5*23mm 2

82 Felt 2

83 Wheel φ39*φ20*19 2

84 Belt 1

85 Bearing 608ZZ 8

86 Monitor upper cover 1

87 Monitor bottom cover 1

88 Cap 4

89 Cap 2

90 Cap 4

91 Cap 4

31 Nylon nut M8 16

32 Nylon nut M6 6

33 Hex nut M10 4

34 Flat washer D8 16

35 Spring washer D8 2

36 Front roller 1

37 Rear roller 1

38 Allen wrench S6 1

39 Wrench 13*14*15 1

40 Bolt M8*55 4

41 Bolt M6*20 2

42 Bolt M8*10 16

43 Screw φ5*19 14

44 Screw M6*12

5

92 Plastic box1 2

93 Plastic box 2 2

94 Pad 1

95 Belt (5400-S06) 1

96 Running deck (5400-S07) 1

97 Rubber pad 6

98 Power cord 1

99 Over-current protector 1

100 DC motor 1

101 Magnetic ring 2

102 Power cord 1

103 Power cord 1

104 Power cord 1

105 Display 1

45 Flat washerφ6.5*φ16*1 2

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

106 Control board 1

Product name: Conquer Treadmill Desk

46 Spring washer D=6 5

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

107 Signal wire 1

47 Allen wrench S5 1

48 Allen wrench S4 1 109 Safety key 1

49 Bolt M4*28 8 110 Poly dome 1

50 Nylon nut M4 8 111 Incline motor 1

51 Screw M5*8 4 112 Magnetic sensor 1

52 Screw M5*48 4 113 Support horizontal tube 2

53 Limited block 2 114 Fix plate

54 Bolt 2 115 Safety key sensor

55 Nylon nut M4 2 116 R-shaped wire bush

56 Bearing 6001RS 2 117 20*20cushion pad

57 Spiral bevel gear1 2 118 Chain adjusterM6*40

58 Spiral bevel gear 2 2 119 Up down controller

59 Dabber 2 120 Switch

60 Copper bush 2

108 Signal wire 1

1

1

3

2

4

1

1

61 Bearing 6802Z 2

CONSOLE OPERATION

The LED window shows: MPH (speed), TIME, MILES (distance) and CAL. (calories).

1. MPH (speed): Displays the current speed. Speed Range: 0.6~4.0MPH.

2. TIME: Displays the total workout time. Time Range: 0:00~99:59.

3. MILES (distance): Displays the total workout distance. Distance range: 0.0~99.9.

4. CAL. (calories): Displays the total workout calories. Calories range: 0~999.

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

Product name: Conquer Treadmill Desk

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

BUTTON OPERATIONS:
Please NOTE that the treadmill can be operated ONLY when the safety key is inserted.

1. START: Press the button to start the treadmill.

2. STOP: Press the button to stop the treadmill.

3. SPEED▲:
a. To set the speed, press the speed button until the desired speed shows on the display.
b. Increase the speed as desired while walking by pressing the Speed

▲. When the

speed reaches 4.0mph, pressing SPEED▲will no longer increase the speed.

4. SPEED▼

a. To set the speed, press the speed button until the desired speed show on the display.
b. Decrease the speed as desired while walking by pressing the Speed
speed reaches 0.6mph, pressing SPEED

▼will no longer decrease the speed.

▼. When the

5. HEIGHT▲: Increase the height as desired by pressing the HEIGHT▲.

6. HEIGHT▼: Decrease the height as desired by pressing the HEIGHT▼.

7. HEIGHT MEMORY 1, 2, 3, 4: Press buttons will automatically take you to the desired

height level.

8. Press height memory button for 5 seconds to set height memory

OPERATION MODES

1. Normal: Insert the safety key then press “START”. The running belt will start to move.

The treadmill will start from the speed of 0.6mph and the time will count up from 0:00 to
99:59. When the time reaches to 99:59, it will count up from 0 again. Press SPEED▲
and ▼ to adjust the speed.

2. Sleep: The treadmill will turn to SLEEP status if inactive for 10 minutes.

3. Emergency stop: The emergency switch is designed to function as an emergency stop

mechanism. For this reason it is extremely important that the safety key CORD is
attached to your clothing at all times while using the treadmill. When cord is pulled out
from the emergency switch, the treadmill will stop immediately, a beep signals and the
windows will display “---“. The treadmill will stop. Attach the switch to start the treadmill
again.

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]

Product name: Conquer Treadmill Desk

SKU: 330-TMDSK01
EMAIL: [e-mail]
TEL: [phone]

help.conquerequipment.com

TROUBLESHOOTING GUIDE

Error
code

E01

E02

E03

Cause Checking Correction

No sensor signal

Over-voltage protection of the

motor

Over-current protection

1. Check the distance and place
between sensor and magnet.

2. Check if the wire is broken. 2. Change the wire.

3. Check if the magnetism is
good.

4. Check if the controller is
damaged.

1. Check if the network voltage is
stable.

2. Check if the controller is
damaged.

1. The machine is overloaded.

2. Check if the motor or the roller
gets stuck by something.

3. Check roller lubrication. 3. Lubricate the roller.

1. Adjust the distance between
the sensor and the magnet.

3. Change the magnet.

4. Change to a new controller.

1. Regulator is needed to adjust
the voltage.

2. Change to a new controller.

1. Verify user weight is within
allowed parameters

2. Take the foreign matter out.

E04

E06

E07

Open circuit

Message failure

Emergency switch off

4. Check if the controller is
damaged.

5. Check if the motor is damaged. 5. Change to a new motor.

1. Check the wires of the motor
are connected well.

2. Check if the motor is
open-circuit.

3. Check if the controller is
open-circuit.

1. Check if the connecting wires
are plugged well.

2. Check if the connecting wires
are broken.

3. Check if the console is broken. 3. Change to a new console.

4. Check if the controller is
damaged.

1. Check if the emergency switch
is attached.

4. Change to a new controller.

1. Connect the motor wires
properly.

2. Change to a new motor.

3. Change to a new controller.

1. Plug all the wires properly.

2. Change to the new wires.

4. Change to a new controller.

1. Attached the emergency
switch.

EMAIL: [e-mail] WEB: help.conquerequipment.com TEL: [phone]
