Introduction
Connect Tech’s FreeForm/PCI-104 features Xilinx’s Virtex-5 multi-platform FPGA offering users a
flexible, reconfigurable product that also takes advantage of the high bandwidth capabilities of the PCI
bus while communicating with various I/O interfaces.
Features
o PCI-104 form factor – 32-Bit/33MHz
o Xilinx multi-platform Virtex-5 FPGA with 3 million logic gates
o 8MB Flash for embedded code storage
o Designed for embedded processing using MicroBlaze™
o 100MHz input clock
o 128MB DDR2-400 memory
o External 5V power connection for stand alone usage
o 2 x 10/100 Ethernet with modular jacks
o 2 x RS-485 serial interface
o On-board reset switch
o 64 single ended or 32 LVDS general purpose I/O
o Available in industrial temperature range of -40°C to 85°
Figure 1: FreeForm/PCI-104 Block Diagram
Revision 0.00
6
Connect Tech FreeForm/PCI-104 User Manual
Figure 2: FreeForm/PCI-104 Layout
Table 1: FreeForm/PCI-104 Components
Connectors Description
P1 PCI-104 connector
P2 JTAG programming header
P3 SPI flash programming header
P5, P6 RS-485 header
P7 GPIO header
P8 External power header
P9 RJ-45 A
P10 RJ-45 B
Jumpers /Switches Description
RSW1 Slot selection
J1 FPGA configuration settings
Components Description
D1-D4 User LEDs
D5 FPGA load complete LED
U4 PLX PCI-local bus bridge
U5 Virtex-5 FPGA
U10 FPGA configuration flash
U11 Embedded code flash
U12, U13 DDR2 memory
U14 Parameter EEPROM
U15, U16 RS-485 transceiver
U17 Dual 10/100 PHY
O1 100MHz oscillator, main clock
Revision 0.00
7
Connect Tech FreeForm/PCI-104 User Manual
Hardware Description and Configuration
The following sections describe the function of all switches/jumpers and provide details on connector
pinouts.
Jumpers and Switches
Slot Selection (RSW1)
This rotary switch selects a slot position in the PCI-104 stack. When mounting on a PCI adapter
card, ensure slot one is selected.
Table 2: Slot Selection (RSW1)
Position Slot
0,4 0
1,5 1
2,6 2
3,7 3
FPGA Configuration Settings (J1)
Jumper J1 is used to control FPGA configuration.
Table 3: FPGA Configuration Settings (J1)
FPGA waits for configuration over JTAG, using
the cable it is connected to
FPGA reads configuration from SPI flash
FPGA is tri-state, program flash directly
Revision 0.00
8
