D - S U B H o o d s a n d A c c e s s o r i e s
D-SUB Plastic Hood
Straight cable entry – 9-50 pos. – With jack screws
RoHS compliant – CSA listed, File No.: LR 115000-1 – UL listed, File No.: E202784
Product drawing
Description
Two-part plastic hood
Integrated cable clamping
Material:
- Plastic hood grey
- Plastic hood metallized: ABS, UL 94 V-0
Fastening:
- 4-40 UNC jack screw
- M3 jack screw
Bulk or single packaged units
No. of pos. A B C D E Ø F
09 34.00 25.00 25.00 27.75 14.50 8.50
15 42.30 33.30 37.00 39.75 14.50 10.00
25 56.00 47.00 37.00 39.75 14.50 10.50
37 72.50 63.50 37.00 39.75 14.50 10.50
50 67.00 61.10 49.10 51.40 19.80 14.00
black: Polyamide + Glas filled, UL 94 V-0
10|14
Order data
D-SUB Plastic hood – Straight cable entry
No. of pos. Design Part Number
09
Black housing
15
Black housing
25
Black housing
37
Black housing
50
Black housing
09
Black housing
15
Black housing
25
Black housing
37
Black housing
50
Black housing
09
Grey housing
15
Grey housing
25
Grey housing
37
Grey housing
50
Grey housing
09
Grey housing
15
Grey housing
25
Grey housing
37
Grey housing
50
Grey housing
For single packaged add the letter „E“ at the end of the part number.
4-40 UNC Jack screw
4-40 UNC Jack screw
4-40 UNC Jack screw
4-40 UNC Jack screw
4-40 UNC Jack screw
M3 Jack screw
M3 Jack screw
M3 Jack screw
M3 Jack screw
M3 Jack screw
4-40-UNC Jack screw
4-40-UNC Jack screw
4-40-UNC Jack screw
4-40-UNC Jack screw
4-40-UNC Jack screw
M3 Jack screw
M3 Jack screw
M3 Jack screw
M3 Jack screw
M3 Jack screw
165 X 10139 X
165 X 10149 X
165 X 10159 X
165 X 10169 X
165 X 10179 X
165 X 10189 X
165 X 10199 X
165 X 10209 X
165 X 10219 X
165 X 10229 X
165 X 14109 X
165 X 14119 X
165 X 14129 X
165 X 14139 X
165 X 14149 X
165 X 14159 X
165 X 14169 X
165 X 14179 X
165 X 14189 X
165 X 14199 X
D-SUB Plastic hood – Straight cable entry - Metallized
No. of pos. Design Part Number
09
15
25
37
50
09
15
25
37
50
Metallized housing
Metallized housing
Metallized housing
Metallized housing
Metallized housing
Metallized housing
Metallized housing
Metallized housing
Metallized housing
Metallized housing
4-40 UNC Jack screw
4-40 UNC Jack screw
4-40 UNC Jack screw
4-40 UNC Jack screw
4-40 UNC Jack screw
M3 Jack screw
M3 Jack screw
M3 Jack screw
M3 Jack screw
M3 Jack screw
165 X 10909 X
165 X 10919 X
165 X 10929 X
165 X 10939 X
165 X 10949 X
165 X 10959 X
165 X 10969 X
165 X 10979 X
165 X 10989 X
165 X 10999 X
