Conceptronic DARAY03W User Manual

DARAY03W

DARAY Wireless Pan/Tilt Cloud IP Camera, 1080P

Keep an eye on your home or office area from any location. This wireless network (IP) camera is ideal for
remotely monitoring different spaces, with pan and tilt features as well as advanced motion detection. With a
built-in microphone for two-way communication, the camera is designed for use at home in an area such as a
baby’s bedroom or living room where expensive equipment is kept, as well as for business use; monitoring a
reception area or warehouse. By connecting the IP camera to a wireless router, access the live images
recorded by the camera from any PC or notebook. With cloud functionality, images can be viewed from any
location in the world. Built-in infrared LEDs enable night-time monitoring and the agile pan and tilt functions
allow secure viewing of every corner for ultimate peace of mind.

Highlights

> Monitor your home or office from anywhere in the world
> 1/2.7" Progressive CMOS, 1920 x 1080 HD
> Supports wireless connection via 2.4G Wi-Fi
> Easy setup via mobile app
> Supports 300° pan and 60° tilt
> Built-in Infrared LEDs for night viewing
> Built-in microphone and audio line out for 2-way audio communication
> Wireless security with WEP, WPA and WPA2 encryption
> Supports iPhone/smartphone remote viewing over the Internet
> Supports cloud functionality
> Compatible with Alexa

Specifications

System Specifications

Storage Humidity

3% ~ 90%

Encryption

WEP

Monday, November 23, 2020 Page 1 of 5

WPA
WPA2

Operating Temperature (°C)

-10

Operating Humidity

10% ~ 90%

Wi-Fi Standard

802.11b

802.11g

802.11n

Storage Temperature

-40

Frames per second

max 25fps

Resolution

1920*1080/640*360

DARAY03W

Protocols

TCP/IP
DHCP
FTP
SMTP
NTP
UPNP
HTTP
UDP/IP
DDNS
P2P

Port

1 x Micro SD

Video Format

H.264

Image sensor

1/2.7” CMOS Sensor

Lens

f=3.6mm,F=2.1
