Page 1
Installation Guide
Internet
Wi-Fi
Page 2
Package Contents
COMWAVE DCW775
INTERNET MODEM
Package Contents
POWER ADAPTER
OUTPUT: 12V
ETHERNET CABLE
1
2
3
4
LAN
USB
Cable
Power
Adapter
(1 to 4)
Connect to your computer using the Ethernet Cable supplied.
Currently not supported.
Connect Comwave Internet Modem to your cable connection.
Connect to a power source using the Power Adapter supplied.
1
2 3 4
Page 3
LED Light Indicators
Upon completion of set
up, the following LED
lights should be on.
Power Online
Please follow the step by step instructions on the following pages.
Note: Indicator will
only be lit when Wi-Fi is
enabled.
Page 4
Installation
Continue to
1
STEP
Cable Jack
Internet
Line
Internet
Modem
Computer
Wi-Fi
3
step
2
step
Power Bar
with Surge Protector
Comwave
Home Phone Adapter
Telephone
5
step
4
step
7
step
6
step
Page 5
1
step
2
STEP
3
STEP
4
STEP
5
STEP
6
STEP
7
STEP
8
STEP
9
STEP
To begin installation, shut down your computer.
Connect the Comwave Internet Modem using the cable
connection.
Connect the supplied Ethernet Cable from the LAN port of
the Comwave Internet Modem to your computer.
(For Home Phone) Connect the supplied Ethernet cable
from the LAN port of your Comwave Internet Modem to
the WAN port of the Home Phone Adapter.
Connect the Comwave Internet Modem to a power outlet.
Note: Wait until the LED Light Indicators on your Comwave
Internet Modem indicate that the Modem is operational.
This may take up to 5 minutes.
(For Home Phone) Connect a telephone to the PHONE 1
port on the Home Phone Adapter.
Connect the Home Phone Adapter to a power outlet and
wait 5 minutes for dial tone.
DO NOT DISCONNECT POWER as it may damage the Home
Phone Adapter.
Start your computer. You should be able to browse the
Internet instantly.
Test your phone line, you should have a dial tone and be
able to make calls.
Can’t access the Internet?
4
5
6
1
2
3
Unplug the power to your
Comwave Internet Modem,
Home Phone Adapter and shut
down your computer.
Wait 30 seconds and then
plug your Comwave Internet
Modem’s Power Cord back into
the power outlet.
Wait until the LED Light
Indicators on your Comwave
Internet Modem indicate the
Modem is operational. This may
take up to 5 minutes.
Start your computer and plug in
the Home Phone Adaptor into a
power outlet.
Open your browser and start
surng the Internet. Check for a
dial tone.
Still unable to surf the Internet?
Call us at 1-866-210-9149.
We’ll get you back
up online!
Page 6
Wi-Fi Settings
1
STEP
2
STEP
To log into your Wi-Fi, use the
default login information found on
the “STOP” sticker on the back of
your modem.
To change your default Wi-Fi User
Name and Password make sure
your computer is connected via the
Ethernet Cable to your Comwave
Internet Modem.
Wireless
CAUTION
Your Comwave Internet Modem is
already Wi-Fi enabled by Comwave.
We do not recommend making any
changes to the default settings. Only
advanced users should attempt to
make changes or shut o the Wi-Fi
settings by following the steps below.
4
STEP
5
STEP
Page 7
5
STEP
6
STEP
7
STEP
Open your Internet browser and type
http://192.168.0.1 in the address bar.
Enter your User Name: <blank>
and Password: “admin”. Click OK to
proceed to the Comwave Internet
Modem Administration screen.
Click on Wireless in the top menu.
Click on Primary Network in the left
menu.
Use caution when making the
following changes:
i. Disable your Wi-Fi Primary Network
ii. Change your Network Name (SSID)
iii. Change your Security Type
iv.
Choose your Wireless Key
Click Apply.
4
STEP
8
STEP
3
STEP
Comwave
i.
ii.
iv.
iii.
6
STEP
7
STEP
Page 8
Need more help?
1-866-210-9149
DCW775
