Comstock Castle FHP-12-1RB Specifications

CONSTRUCTION: Easy cleaning, corrosion resistant stainless steel

finish, welded with angle iron and aluminized inner framing. Sturdy 4"
heavy duty stainless pipe legs with adjustable feet. Stainless steel bullnose­rail is functional on which to set plates or utensils and also serves as
control. Corrosion resistant, 16 gauge, welded aluminized steel firebox
with excellent heat reflection characteristics. Double wall construction
with heavy insulation for cooler operation. Installation clearances for
non-combustible surfaces are 0" on the sides and 4" in the rear. Char­broilers are approved for use in non-combustible locations only.

TOP GRATES: Cast iron top grate sections measure 20.5" deep,

designed with cast-in grease trough on each blade to allow grease run
off into the front cold zone grease trough and reduces flare up. Each
section is reversible for sloped or level grilling. Stainless steel splash
guards on 3 sides graduating up to 4" high. Grease drain slot is 3.5" x
1" and feeds into a large, removable grease drawer.

BURNERS: 12" incremental griddles feature 25,000 BTU cast iron

“H” pattern burners, one for each 12" increment. 18" & 30" models
feature 2 and 4 straight burners respectively, each rated at 20,000 BTU.
Optional 40,000 BTU “H” burners available.

RADIANTS: Char-broiler radiants are either lava rock or heavy duty

angle iron, inverted “V” type for superior uniform heating temperature. “V”
type radiants are easily removable for cleaning.

CONTROLS: Equipped with brass gas valves and automatic standing

pilots. Pressure regulators are set at the factory for the gas specified.
Optimal pressures are 4" WC for natural gas and 10" WC for propane.

Manifold size is

3

/4" NPT. All controls are tested and confirmed in good
working order. Calibration and adjustments are the responsibility of the
installer.

MATCH-UP: FHP Series char-broilers are designed to match up with

FHP griddles and hot plates.

ACCESSORIES: Lava rock, grate scrapers, spatulas, cleaning supplies,

gas hoses, carrying handles, knob protectors and matching equipment
stands.

SPECIFICATIONS

Model Broiler Width Total Approx.
Number Type in./mm. BTU lbs/kg

FHP12-1LB Lava 12/305 25K 100/45
FHP12-1RB Radiant 12/305 25K 100/45
FHP18-1.5LB Lava 18/457 40K 175/80
FHP18-1.5RB Radiant 18/457 40K 175/80
FHP24-2LB Lava 24/610 50K 185/84
FHP24-2RB Radiant 24/610 50K 175/80
FHP30-2.5LB Lava 30/762 80K 275/125
FHP30-2.5RB Radiant 30/762 80K 275/125
FHP36-3LB Lava 36/914 75K 260/118
FHP36-3RB Radiant 36/914 75K 245/111
FHP48-4LB Lava 48/1219 100K 360/164
FHP48-4RB Radiant 48/1219 100K 360/164
FHP60-5LB Lava 60/1524 125K 450/205
FHP60-5RB Radiant 60/1524 125K 450/205
FHP72-6LB Lava 72/1829 150K 600/273
FHP72-6RB Radiant 72/1829 150K 600/273

America’s Oldest Stove Company

(Est. 1838)

JOB ITEM #

CHAR-BROILERS

FHP SERIES

Comstock-Castle Stove Co. • 119 W. Washington • Quincy, IL 62301 USA

Tel.: [phone] • Telefax: 217-223-0007 • www.castlestove.com

FHP36-3RB

FHP24-2RB

FHP48-4RB

19

Standard Features & Benefits

®

®

®

®

28"

12.25"

21"

11.75"

7.25"

4"
