TEC-M2065MP
Magnification 2.0X, WD65mm
for 2/3 type Cameras, 2 Megapixel Telecentric Lens
C‐Mount, Straight type
Model No. TEC-M2065MP NA 0.076
Magnification 2.0X TV Distortion 2/3 type 0.02%
Working Distance 65.4mm Back Focal Length 17.0mm
Effective F Number
Max. Image Format φ11mm Mount C-Mount
Control Iris - Filter Size -
Focus -
Field of View 4.4mm(H) x 3.3mm(V) 2/3" Dimensions φ25mm x 77.4mm
Resolving Power *1 4.4µm Weight 49g
Depth of Field *2 0.26mm Operating Temperature -10℃ - +50℃
*1:Theoretical resolution calculated with a wavelength of 550nm
*2:Value calculated with a permissible circle of confusion of 40μm
Dimensions
12.8 Flange Back Length 17.526mm
（O/I=160.4）
WD 65.4
Field of View at Sensor Size
Format Field of View(HxV)
2/3" 4.4 x 3.3mm
1/1.8" 3.59 x 2.66mm
1/2" 3.2 x 2.4mm
1/3" 2.4 x 1.8mm
（77.4）
0
-0.1
φ16
0
-0.1
φ25
21.4
21
28.5
17.526
(IN AIR)
4
6.5
3-M3ｘ6 Socket Head
φ29
C Mount
Specification is subject to change without any notice. 2015.9
