CSW-HD440

INTRODUCTION

The CSW-HD440 routes high definition video in multiple resolutions up to

1080p plus multichannel digital audio from any of the four HDMI sources to the

displays. Four outputs give you the choices of sending high definition audio

and video signals up to four displays. Any four to any four matrix switching

allows for maximum versatility for integrated systems. The CSW-HD440

eliminates the need to disconnect and reconnect sources to a display

equipped with one input. It works with HD-DVD players, TiVo systems, HT PCs,

and satellite set top boxes that connect to an HDMI display. Every source is

accessible at all times by any display by selecting it with an IR remote or

through RS232 port.

Cable and Connectivity Company

CSW-HD440 has many features that enable it to perform in a superior

manner. Among those features you will find:

Allows any HDMI display to view any source at any time

Allows any source to be displayed on multiple displays at the same time

Maintains resolutions up to 1080p.

Maintains highest HDMI single link video resolution

Maintains highest HDMI digital audio signal

HDMI or DVI to HDMI cables are used to connect the inputs and the matrix

output

Each display’s inputs can be switched with the IR remote control or through

RS232

Supports HDCP

Supports HDMI 1.3b

SPECIFICATIONS

Signal Inputs/Output

HDMI Connector type A 19 pin female

Input DDC Signal 5 volts p-p (TTL)

Remote Control Port RS-232 Female, Mini-Stereo

Operating Frequency

Video Amplifier Bandwidth 2.25Gbps/225MHz

Frequency Up to225MHz

Resolutions(HDTV)

Interlaced(50&60Hz) 480i,576i,1080i

Progressive(50&60Hz) 480p,576p,720p,1080p

Mechanical

Size(H-W-D)

Weight(Net)

Warranty
