USER MANUAL
CSW-HD201C
Table of Contents
1.0 Introduction……………………………………………………..1
2.0 Specifications………………………………………………..…2
3.0 Package Contents…............................................................2
4.0 Panel Descriptions…………………………………………..…2
5.0 Connection and Operation……...........................................3
Cable and Connectivity Company
The HDMI Switcher 2×1 Pigtail
１
The HDMI Switcher 2×1 Pigtail
DEAR CUSTOMER
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
1.0 INTRODUCTION
This is a kind of high performance HDMI Switcher. It can easily switches two
sources to one display. It not only has the key-press-switching function, but also
has intelligent function. With one fixed HDMI cable (pigtail) this converter not only
reduces cost but also save time for consumers.
This kind of HDMI Switcher routes high definition video (in multiple resolutions up
to 1080p) and digital audio from any one of the two sources to display units. All
inputs accommodate the connections of the high definition video sources
simultaneously, compatible well for HD-DVD,SKY-STB, PS3, Xbox360 etc. The
output sends the high definition audio/video signals to a high definition display.
1.1 INTELLIGENT FUNCTION
1) Once the source device is turned on or plugged in (should stay power-on
mode), the switcher will automatically select this source.
2) Once the source device is turned off or plugged out, the switcher will
automatically select the next power-on source depending on the sequence
Note:
1) When the source devices are on the stand-by mode, its power supply should
be turned off, otherwise this switcher can not meet intelligent function.
2) When plugged in or out, this switcher is completely intelligent.
1.2 FEATURES
This HDMI Switcher has many features that enable it to perform in a superior
manner. Among those features you will find:
Multifunctional on switching : intelligent or mechanical
Supports highest video resolution 1080p.
Supports 250MHz/2.5Gbps per channel (7.5Gbps all channel) bandwidth.
Supports 12bit per channel (36bit all channel) deep color.
HDCP pass-through.
Supports uncompressed audio such as LPCM.
Supports compressed audio such as DTS Digital, Dolby Digital（including
DTS-HD and Dolby True HD）
Support 3D all format, including 1080p@23.98/24Hz,
720p@59.94/60Hz/50Hz, bandwidth up to 250MHz.
Signal Inputs/Output
Input DDC Signal
5 volts p-p (TTL)
Maximum Single Link Range
1920X1080p
Output Video
HDMI
Operating Frequency
Vertical Frequency Range
50/60Hz
Video Amplifier Bandwidth
2.5Gbps/250MHz
Resolutions(HDTV)
Interlaced(50&60Hz)
480i,576i,1080i
Progressive(50&60Hz)
480p,576p,720p,1080p
Warranty
Limited Warranty
2 Years Parts and Labor
Environmental
Operating Temperature
Operating Humidity
10% to 85 % RH (no condensation)
Storage Temperature
-10 to +80
Storage Humidity
5% to 90 % RH (no condensation)
Power Requirement
External Power Supply
No power needed
Power consumption (Max)
5W
Regulatory Approvals
Converter Unit
FCC,CE,UL
Accessories Adapter
User Manual
2.0 SPECIFICATIONS
The HDMI Switcher 2× 1 Pigtail
0 to +70
Note: Specifications are subject to change without notice.
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the shipping carton:
Main unit.
User's Manual
4.0 PANEL DESCRIPTIONS
２
The HDMI Switcher 2× 1 Pigtail
1
Select
2
Input 1Input 2
5.0 CONNECTION AND OPERATION
1) Connect the HDMI input sources to the HDMI Switcher. (Input cables are
optional)
*Please refer to connection diagram section.
2) Connect the fixed HDMI cable (pigtail) to display.
3) Press the “select” button to select input sources.
Attention: Insert / Extract cable gently.
5.1 CONNECTION DIAGRAM
55 Ruta Ct. South Hackensack, NJ 07606
Toll Free: 800 526-0242
Email:
sales@comprehensivecable.com
customerservice@comprehensivecable.com
www.comprehensivecable.com
３
