CHE-HDBT200
Operation Manual
HDMI Extender over CAT5e/6/7 (HDBaseT)
I. Introduction
The HDMI Extender over cat5e/cat6 is a tool for extending your HDMI
signal over long distances to a compatible display. It is designed to
convert HDMI signal to standard HDBaseT signal and transmit by
Internet cable. It also supports Transfer Bidirectional Infrared control
signal together with the HDMI signal, so you can control the Source in
the Sink side which is 230 feet outside, also you can control the Sink in
the Source side which is 230 feet outside using the HDMI Extender.
II. Features
One pair as a full functional module, no need for setting.
POE (Power Over Ethernet) function support, either TX or RX powered
12V@2.5A,another device will no need power form the DC jack. POE
Power Consumption less than 10W.
Use single UTP LAN cable (CAT-5E/6) to substitute HDMI cable to
achieve long distance transmission.
UTP cable termination follows the standard of IEEE-568B.
Transmission distance:
70 meters: 1080P @60Hz36bit; 3D1080P@30Hz36bit;
40 meters: 1080P @60Hz@48bit; 1080P @120Hz@24bit;
3D1080P@60Hz@36bit
4K x 2K@30Hz@24bit.
HDMI V1.4 supported.
HDCP compliant.
Full HD support: 1080p@60Hz@48 bit/pixels, 1080p@120Hz@24
bit/pixels, 3D 1080P60Hz and 4K x 2K@30Hz@24bit
Transfer Bidirectional Infrared control signal together with the HDMI
signal.
III. Package
HDMI Extender Transmitter -------------------------------------------------- 1PC
HDMI Extender Receiver ------------------------------------------------------- 1PC
IR Transmitter ------------------------------------------------------------------- 2PCS
IR Receiver ----------------------------------------------------------------------- 2PCS
12V2.5A DC Power Supply adapter ---------------------------------------- 1PCS
Operation Manual --------------------------------------------------------------- 1PC
IV. Specifications
Frequency Bandwidth: 2.97Gbps
HDMI Transmitter Input/Output Ports: 1x HDMI Female port/1 x CAT6
HDMI Receiver Input/Output Ports: 1x HDMI Female port/1 x CAT, 1x
IR Transmitter/1x IR Receiv
Power Supply: DC 12V 2.5A
ESD Protection Human Body Model: ± 8kV (air-gap discharge), ± 4kV
(contact discharge)
Dimensions (mm): 65(W) X 100 (D) X 25 (H)
Weight: 200g x 2
Operating Temperature: 0°C ~ 40°C / 32°F ~ 104°F
Operating Temperature: 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature: -20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity: 20 ~ 90% RH (Non-condensing)
Power Consumption (Max): 20W
80 Little Falls Rd, Fairfield NJ 07004
Phone: 1-800-526-0242
www.comprehensiveco.com
