CCN-DH101
USER MANUAL
Table of Contents
1.0 Introduction..........................................................................1
2.0 Specifications…………………………………….………..……1
3.0 Package Contents………………………………………….…..2
4.0 Panel Descriptions…………………………………….…….…2
5.0 Connection and Operation..................................................3
Cable and Connectivity Company
DVI + Audio to HDMI Converter
1
Signal Inputs/Output
Input DDC Signal
5 volts p-p (TTL)
Input Video
DVI 1.1v
Output Video
HDMI
DVI + Audio to HDMI Converter
Dear Customer
Thanks for your purchase of the DVI Audio to HDMI Converter. For optimum
performance and safety, please read these instructions carefully before
connecting, operating or adjusting this product. Please keep this manual for future
reference.
1.0 INTRODUCTION
This converter is designed to make your A/V equipment more comfortable, more
productive and less expensive. It converts a digital DVI signal and toslink audio
and digital audio input to an HDMI format allowing the viewing or switching of a
digital AV signal on an HDMI system.
The DVI+Audio to HDMI Converter is a unique device that combines digital video
(DVI) and digital audio into HDMI to seamlessly integrate into the modern home
theaters. This product not only meets the ideal image of the HDTV but also
meets the need of the enthusiasts’ requirement for audio, because it transmits the
audio signal by toslink audio and digital audio.
This DVI+Audio to HDMI Converter offers solutions for noise, space and security
concerns, data center control, information-distribution, conference-room
presentation, school and corporate training environments.
1.1 FEATURES
This Converter has many features that enable it to perform in a superior manner.
Among those features you will find:
Supports highest video resolution 1080p.
Supports 225MHz/2.25Gbps per channel (6.75Gbps all channel) bandwidth.
Supports 12bit per channel (36bit all channel) deep color.
Toslink Audio and Digital Audio input/output
Encodes digital audio onto the video signal for HDMI™ video and audio
Allows you to connect computers or other sources with DVI output and SPDIF
to an HDMI display
Supports uncompressed audio such as LPCM
Supports compressed audio such as DTS Digital, Dolby Digital（including
DTS-HD and Dolby True HD）
2.0 SPECIFICATIONS
DVI + Audio to HDMI Converter
2
Connector
HDMI Connector
type A (19 pin) female
DVI Connector
DVI-I (29 pin) female (digital only)
Audio Connector
Toslink Audio and Digital Audio
Operating Frequency
Vertical Frequency Range
50/60Hz
Video Amplifier Bandwidth
2.25Gbps/225MHz
Resolutions(HDTV)
Interlaced(50&60Hz)
480i,576i,1080i
Progressive(50&60Hz)
480p,576p,720p,1080p
Mechanical
Size(L-W-H)
Weight (Net)
260g
Warranty
Limited Warranty
2 Years Parts and Labor
Environmental
Operating Temperature
0 to +70
Operating Humidity
10% to 85 % RH (no condensation)
Storage Temperature
Storage Humidity
5% to 90 % RH (no condensation)
Power Requirement
External Power Supply
5V DC@2A
Power Consumption
5 watts (max)
Regulatory Approvals
Converter Unit
FCC,CE,UL
Power Supply
UL,CE,FCC
Accessories Adapter
AC Power Adapter
US standard, UK standard and so on
User Manual
English Version
87.5× 67.5 × 25.5mm
-10 to +80
Note: Specifications are subject to change without notice.
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the shipping carton:
1) Main unit.
2) 5V DC Power Supply.
3) User’s Manual.
4.0 PANEL DESCRIPTIONS
Please study the panel drawings below and become familiar with the signal
input(s), output(s) and power requirements.
DVI + Audio to HDMI Converter
3
CNN DH10
Power Input Output
COAX
DC/5V
SPDIF
Output
HDMI
DVI
Input
COAX
SPDIF
5.0 CONNECTION AND OPERATION
Before installation, please make sure all devices you wish to connect have been
turned off.
1) Insert the DC side of 5v power supply into the converter and then connect the
AC side of the power supply into the wall outlet.
2) Connect the appropriate cables to the source device and then the converter.
3) Connect the output cables to the Converter and then to the destination device.
4) Turn on the Power
.
Attention: Insert / Extract cable gently.
5.1 CONNECTION DIAGRAM
