DS3- Quad 10/100 RIOP Installation Guide
Compatible Systems Corporation
4730 Walnut Street
Suite 102
Boulder, Colorad o 80301
303-444-9532
800-356-0283
http://www.compatible.com
DS3-Quad 10/100 RIOP Installation Guide, Version 1.0
Copyright© 1999, Compatible Systems Corporation
All rights reserved. VSR, VSR-2, MicroRouter and CompatiView are trademarks of Compatible
Systems Corporation. Other trademarks are the property of their respective holders.
FCC Notice: This product has been certified to comply with the limits for a Class A computing device,
pursuant to Subpart J of Part 15 of FCC Rules. It is designed to provide reasonable protection against
radio or television communication interference in a commercial environment. Operation of this
equipment in a residential area could cause interference with radio or television communication.
Table of Contents
Introduction to the DS3-Quad 10/100 RIOP 1
Chapter 1 - Network Installation 2
Connecting the DS3-Quad 10/100 to the Ethernet 2
DS3 Line Connection Requireme nts 2
Connecting the DS3-Quad 10/ 100 to a DS3 Line 3
Connecting a Management Console 3
Powering Up the Router 3
Chapter 2 - Quickstart Instructions 4
ETHERNET INTERFACE CONFIGURATION 4
IP Protocol 4
Required for IP 4
Suggested for IP 5
IPX Protocol 5
Required for IPX 5
Suggested for IPX 5
AppleTalk Protocol 5
Required for Apple Talk 5
Suggested for AppleTalk 5
DECnet Protocol 5
Required for DECnet 5
Suggested for DECnet 6
WAN INTERFACE CONFIGURATION 6
Internal DS3 CSU/DSU Physical Communications Settings 6
Required for Dedicated Line Operation 6
Suggested for Dedicated Line Operation 6
PPP Configuration 6
Internal DS3 CSU/DSU Link Configuration 6
Required for Dedicated Line Operation 6
Suggested for Dedicated Line Operation 6
IP Protocol 6
Required for IP 6
Suggested for IP 6
IPX Protocol 7
Required for IPX 7
AppleTalk Protocol 7
Required for Apple Talk 7
DECnet Protocol 7
Required for DECnet 7
Frame Relay Configuration 7
Internal DS3 CSU/DSU Link Configuration 7
Required for Dedicated Line Operation 7
Suggested for Dedicated Line Operation 8
Frame Relay DLCI Mappings 8
i
Table of Contents
IP Protocol 8
Required for IP Numbered Interface 8
Required for IP Unnumbered Interface 8
Suggested for IP 8
IPX Protocol 9
Required for IPX 9
Suggested for IPX 9
AppleTalk Protocol 9
Required for Apple Talk 9
Suggested for AppleTalk 9
DECnet Protocol 9
Required for DECnet 9
SMDS Config ur ation 10
Link Configuration 10
Suggested for Dedicated/Leased Line Operation 10
SMDS Addressing 10
AVING A CONFIGURATION FILE TO FLASH ROM 10
S
Chapter 3 - Shipping Defaults 11
Ethernet Interface s 11
IP Routing Defaults 11
IP Bridging Defaults 11
IPX Routing Defaults 11
IPX Bridging Defaults 11
AppleTalk Routing Defaults 11
AppleTalk Bridging Defaults 11
DECnet Defaults 11
WAN Interface 11
IP Defaults 11
IPX Defaults 11
AppleTalk Defaults 11
DECnet Defaults 11
DS3 CSU/DSU Defaults 11
Chapter 4 - LED Patterns 12
ROUTER LED PATTERNS 12
Over Temp 12
Sys Ready 12
General Indicators 12
DS3-QUAD 10/100 RIOP LED PATTERNS 13
Ethernet Traffic Indicators 13
DS3 Indicators 13
Ethernet Connection Indicators 13
DS3 Connection Indicators 13
ii
Introduction to the DS3-Quad 10/100 RIOP 1
Introduction to the DS3-Quad 10/100 RIOP
The DS3-Quad 10/100 Routing Input/Output Processor (RIOP), as part of the VSR multigigabit switching router, allows you to connect a remote corporate network and up to four local
Ethernet segments. The DS3 interface has a data capacity of 44.736 Mbps, while the Ethernet
interfaces can operate at either 10 Mbps or 100 Mbps.
This section of the manual contains information specific to the DS3-Quad 10/100 RIOP. It is
divided into the following sections:
Chapter 1: Network Installation
Here you will find st ep- by-step instructions o n ho w to p hys i cal ly i ns tal l t he DS 3-Qu ad 10/100
and connect it to your network.
Chapter 2: Quickstart Configuration
The Quickstart section provides a basic list of parameters that must be entered into the
DS3-Quad 10/100 for proper operation.
Chapter 3: Shipping Defaults
This section of the manual lists factory defaults for each interface.
Chapter 4: LED Patterns
This section of the manual describes the LED indicators for the DS3-Quad 10/100.
Chapter 1 - Network Installation 2
Chapter 1 - Network Installation
DS3-Quad 10/100 RIOP Front Panel
This section of the manual will help you install the DS3-Quad 10/100 RIOP to connect a local
Ethernet and remote corporate network. These connections can be made to other Compatible
Systems routers or routers from other vendors.
In summary, the steps for installation are:
1. After mounting the router or placing on a desktop, make sure it is not connected to
any power source.
2. Connect the router to the Ethernet network.
3. Connect the router to the DS3 transmission equipment.
4. Connect a management console to the router (optional).
5. Plug in the power cable and power up the router.
Connecting the DS3-Quad 10/100 to the Ethernet
The 10/100 Ethernet interfaces directly support 100BaseTx or 10BaseT twisted-pair Ethernet.
To connect one of the router’s Ethernet interfaces to twisted-pair Ethernet cabling, you will
need an unshielded twisted-pair station cable that is already connected
ible twisted-pair hub (for a transmit speed of 10 Mbps) or a 100Mbps Fast Ethernet hub (for a
transmit speed of 100 Mbps).
v
Note: Ethernet cables and cable connectors are not supplied with the DS3-Quad 10/100
RIOP product. Category 5 cabling is required for 100 BaseT operation. Please contact your
reseller or your Compatible Systems representative for information on obtaining the correct
Ethernet cabling supplies .
To connect the router to the twisted-pair network, simply plug the twisted-pair cable into the
RJ-45 Ethernet connector on the front of the unit.
DS3 Line Connection Requirements
The DS3-Quad 10/100 RIOP includes an integrated DS3 C SU/DSU. To connect this interface
to your DS3 transmission equipment, you will need two coaxial cables.
These cables require special tools to be built correctly. You can use your approved cable
supplier or you can contact your reseller or your Compatible Systems representative for a list
of cable suppliers. To have a cable built, use the following specifications:
• Cable Type: AT&T type 734A or equivalent
• Connector Type: AMP Incorporated 413589-7 or equivalent (75 Ohm BNC plug)
• Maximum L ength: 900 feet
to a 10BaseT-compat-
Chapter 1 - Network Installation 3
v Note: The DS3-Quad 10/100 RIOP includes loopback features which can be used to check
the functionality of your DS3 line. Before attempting to route network traffic, use these
features to check the line’s basic integrity.
Connecting the DS3-Quad 10/100 to a DS3 Line
The DS3 line port consists of two 75 ohm BNC female coaxial connectors labeled DS3 XMT
and DS3 RCV. To connect the router to the DS3 line, you need two AT&T type 734A or equivalent coaxial cables.
Install one cable between the router’s DS3 XMT connector and the RCV connector on the DS3
transmission equipment. Install the other cable between the router’s DS3 RCV connector and
the XMT connector on the DS3 transmission equipment.
Connecting a Management Console
If you wish to connect an out-of-band management console, use the supplied DB-25 male to
DB-25 female console cable and connect to the Console interface on the DS3-Quad 10/100
RIOP. You can use a dumb terminal or a computer equipped with VT100 terminal emulation.
The default settings for the Console interface are VT100 terminal emulation, 9600 bps, 8 bits,
no parity, 1 stop bit and no Flow Control.
v
Note: The DS3-Quad 10/100 RIOP also has an AUX interface. This is a modem connection
which should only be used in consultation with Compatible Systems Technical Support staff,
who will provide instruction on its use.
Powering Up the Router
Connect the supplied power cord to the front of the VSR and set the power switch to “On.” At
power-up, the router will take approximately one minute to become visible to CompatiView.
v
Note: If you want to use Telnet as a management method, you must first configure an IP
address into the router with an out-of-band console, or reconfigure the IP address on an IP
host or workstation on the same Ethernet segment as the router. See the appropriate VSR
chassis section of the manual for more information on Command Line Management.
Chapter 2 - Quickstart Instructions 4
Chapter 2 - Quickstart Instructions
This Quickstart chapter briefly discusses the major parameters that must be set in order to use
the DS3-Quad 10/100 RIOP as part of your VSR multigigabit switching ro uter.
Detailed information on the meaning of the router’s parameters is provided in the Compa-
tiView Management Software Reference Guide and the Text-Based Configuration and
Command Line Management Reference Guide. You should use this chapter as a starting point
to look up more specific information in the other document s.
If you need more general information on IP, IPX, AppleTalk or wide area protocols, see the
Appendices in the CompatiView Management S oftware Reference Guide.
There are a number of parameter settings which are optional, in the sense that they are not
required for all installations. These settings are not covered in this chapter.
In this chapter:
CV = CompatiView
TB = Text-Based Configuration
In order to successfully connect to an Internet Service Provider (ISP), you must use router
configuration parameters which will be provided by the technical staff of the ISP. These
parameters must include all IP addresses, WAN settin gs and any applicable aut hor ization
routines. Please check with your ISP before changing the configuration of your DS3-Quad
10/100 RIOP.
v
Note: This Quickstart does not include information on setting up packet filters for using the
router as a Firewall. Se e the CompatiView Management Software Reference Guide or
Text-Based Configuration and Command Line Management Reference Guide regarding IP
packet filters for more information.
Ethernet Interface Confi guration
Ethernet interfaces are considerably easier to set up than WAN interfaces since there are fewer
choices that need to be made regarding commu ni cati ons protocols and parameters. We recommend that you begin by configuring any Ethernet interface parameters before proceeding to
configure WAN interface parameters.
IP Protocol
Required for IP
These parameters set the basic address characteristics of the interface. They provide enough
information for another IP node to find the interface (such as a Telnet client), but not enough
information for routing to take place.
• IP address
• IP subnet mask
• IP broadcast address
CV: Use the TCP/IP Routing: Ethernet Dialog Box to set these parameters.
TB: Use the configure command and the IPAddress, SubnetMask, and IPBroadcast
keywords in the IP Ethernet 0 (and/or other port numbers you wish to configure) section.
IPX Protocol
Chapter 2 - Quickstart Instructions 5
Suggested for IP
These parameters help supply information a bout the segment that the interface is connected to.
With this information, routing can take place.
• Set IP RIP 1, IP RIP 2 or OSPF (Open Shortest Path First)
• Set IP static routes
CV: Use the TCP/IP Routing: Ethernet Dialog Box to set RIP, and the IP Static Routing
Dialog Box (under Global/IP Static Routes) to set static routes. OSPF can only be configured
using text-based configuration.
TB: Use configure and set either the RIPVersion keyword or the OSPFEnabled keyword for
the IP Ethernet 0 (and/or other port numbers yo u w ish to co nfi gu re) s ectio n. Use edit config
and add static routes in the IP Static section.
Required for IPX
Generally, there are no required changes from the shipping Ethernet configuration for IPX.
The Ethernet interface will autoconfigure to use the two most common IPX frame types, and
will adapt to conditions on the Ethernet.
Suggested for IPX
You may want to set your own network numb ers , rat her than using the autoconfigured values.
You may also want to turn off unused frame types.
CV: Use the IPX Routing: Ethernet Dialog Box.
TB: Use configure and set keywords in the IPX Ethernet 0 (and/or other port numbers you
wish to configure) section.
AppleTalk Protocol
Required for AppleTalk
There are generally no required changes from the shipping Ethernet configuration for AppleTalk. The Ethernet interface will autoconfigure to use AppleTalk Phase 2, and will adapt to
conditions on the Ethernet.
Suggested for AppleTalk
You may want to set your own network numb ers , rat her than using the autoconfigured values.
You may also want to use more meaningful zone names.
CV: Use the AppleTalk Routing: Ethernet Dialog Box.
TB: Use configure and set keywor ds in the AppleTalk Phase 2 Ethernet 0 (and/or other port
numbers you wish to configure) section.
DECnet Protocol
Required for DECnet
The router’s shipping configuration does not have DECnet turned on. In order to be used,
DECnet must be turned on both globally and for a particular port.
• Set DECnet on (globally, and for this port)
• Set DECnet area
• Set DECnet node
CV: Use the DECnet Routing Dialog Box (under Global/DECne t Routing) and the DECnet:
Ethernet Dialog Box.
TB: Use configure and set the Mode keyword in the DECnet Ethernet (and/or other port
Chapter 2 - Quickstart Instructions 6
numbers you wish to configure) section. Use configure and set the Enabled, Area, and Node
keywords in the DECnet Global section.
v
Note: Setting DECnet on for any port with the command line also sets DECnet on globally.
In CompatiView you must set a global parameter and a port-specific parameter.
Suggested for DECnet
Setting the parameters above should be adequate for most installations.
WAN Interface Configuration
In order to use the WAN interface, you may want to set some physical parameters. Then set up
the link and protocol parameters.
Internal DS3 CSU/DSU Physical Communications Settings
Required for Dedicated Line Operation
No changes from the default values are required for standard operation over a DS3 line. The
default values are listed in Chapter 3.
Suggested for Dedicated Line Operation
Changing to a different Line Build Out may be required. These parameters can only be set
using the command line interface.
TB: Use configure and the DS3 Interface WAN 0 section.
PPP Configuration
This section covers the settings required for PPP (point-to-point) protocol operation of the DS3
WAN interface.
Internal DS3 CSU/DSU Link Configuration
Required for Dedicated Line Operation
This is the only mode of operation supported via the built-in DS3 CSU/DSU.
• Set Dedicated connection
• Set PPP connection
CV: Use the Link Configuration: WAN Dialog Box.
TB: Use configure and then set the Mode and ConnectMode keywords in the Link Config
WAN 0 section.
Suggested for Dedicated Line Operation
Dedicated line operation generally does not require additional parameters for operation.
IP Protocol
Required for IP
WAN interfaces which are set for PPP operation do not generally use an IP address. They are
set to act as an “unnumbered interface.” In this mode of operation, there are no required
settings.
Suggested for IP
These parameters help supply information a bout the segment that the interface is connected to.
With this information, routing can take place.
• Set IP RIP 1, IP RIP 2, OSPF (Open Shortest Path First) or BGP (Border Gateway
IPX Protocol
Chapter 2 - Quickstart Instructions 7
Protocol)
• Set IP static routes
CV: Use the TCP/IP Routing: WAN Dialog Box to set RIP, and the IP Static Routing Dialog
Box (under Global/IP Static Routes) to set static routes. OSPF and BGP can only be configured using text-based configuration.
TB: Use configure and set either the RIPVersion keyword or th e OSPFEnabled keyword in
the IP WAN 0 section. Add static routes and a default router using the edit config IP Static
command.
v
Note: Due to the complexity of BGP, configuration parameters for BGP ar e no t given in this
Quickstart. For help with BGP configuration parameters, and other configuration questions,
refer to the Tech Support pages on the Compatible Systems Web site at:
http://www.compatible.com/.
Required for IPX
WAN interfaces which are set for PPP operation do not generally use an IPX address. They are
set to act as an “unnumbered interface.” In this mode of operation, there are no required
settings.
AppleTalk Protocol
Required for AppleTalk
WAN interfaces which are set for PPP operation do not generally use an AppleTalk address.
They are set to act as an “unnumbered interface.” In this mode of operation, there are no
required settings.
DECnet Protocol
Required for DECnet
The router’s shipping configuration does not have DECnet turned on. In order to be used,
DECnet must be turned on both globally and for a particular port.
• Set DECnet on (globally, and for a port)
• Set DECnet area
• Set DECnet node
CV: Use the DECnet Routing Dialog Box (under Global/DECne t Routing) and the DECnet:
WAN Dialog Box.
TB: Use configure and set the Mode keyword in the DECnet W AN 0 section. Us e configure
and set the Enabled, Area, and Node keywords in the DECnet Global section.
v
Note: Setting DECnet on for any port with the command line also sets DECnet on globally.
In CompatiView you must set a global parameter and a port-specific parameter.
Frame Relay Configuration
This section covers the settings required for Frame Relay operation o f the DS3 WAN interface.
Internal DS3 CSU/DSU Link Configuration
Required for Dedicated Line Operation
This is the only mode of operation supported via the built-in DS3 CSU/DSU.
• Set Dedicated connection
Chapter 2 - Quickstart Instructions 8
• Set Frame Relay connection
CV: Use the Link Configuration: WAN Dialog Box.
TB: Use configure and then set the Mode
WAN 0 section.
Suggested for Dedicated Line Operation
Dedicated line operation generally does not require additional parameters for operation.
Frame Relay DLCI Mappings
If you are connecting to another Compatible Systems router, this information is not required
for Frame Relay operation. Compatible Systems uses IARP (Inverse Address Resolution
Protocol) to dynamically generate this information. To connect to other vendors’ routers
which do not support IARP, you must provide DLCI-to-protocol mapping information.
v
Note: Many Internet Service Providers (ISP’s) do not support IARP as a default. If your
WAN interface will be connected to an ISP via Frame Relay, check with your ISP technical
staff on whether or not you must manually enter DLCI information.
CV: Use the DLCI Mapping Database window.
TB: Use configure and set the DLCI keyword in the Frame Relay WAN 0 section.
IP Protocol
There are two ways to set up Frame Relay. One is to set the WAN interface as a “numbered
interface.” This means that the interface (and thus the Frame Relay network) will have an IP
address, subnet mask, etc. The other is to set it as an unnumbered interface and specify that the
link is point-to-point Frame Relay and set the local DLCI. Unnumbered Frame Relay can only
be configured using text-based configuration. Instructions are provided for both options.
and ConnectMode keywords in the Link Config
Required for IP Numbered Interface
• IP numbered interface
• IP address
• IP subnet mask
• IP broadcast address
CV: Use the TCP/IP Routing: WAN Dialog Box.
TB: Use the configure command and the Numbered, IPAddress, SubnetMask, and
IPBroadcast keywords in the IP WAN 0 section.
Required for IP Unnumbered Interface
• IP unnumbered interface
• Point-to-Point Frame Relay
• Local DLCI
TB: Use the configure command and the Numbered, PointToPointFrame and InterfaceDLCI keywords in the IP WAN 0 section.
Suggested for IP
These parameters help supply information a bout the segment that the interface is connected to.
With this information, routing can take place.
• Set IP RIP 1, IP RIP 2, OSPF (Open Shortest Path First) or BGP (Border Gateway
Protocol)
• IP static routes
CV: Use the TCP/IP Routing: WAN Dialog Box to set RIP, and the IP Static Routing Dialog
IPX Protocol
Chapter 2 - Quickstart Instructions 9
Box (under Global/IP Static Routes) to set static routes. OSPF and BGP can only be configured using text-based configuration.
TB: Use configure and set either the RIPVersion keyword or th e OSPFEnabled keyword in
the IP WAN 0 section. Add static routes and a default router using the edit config IP Static
command.
v
Note: Due to the complexity of BGP, configuration parameters for BGP ar e no t given in this
Quickstart. For help with BGP configuration parameters, and other configuration questions,
refer to the Tech Support pages on the Compatible Systems Web site at:
http://www.compatible.com/.
Required for IPX
Frame Relay operation requires that the WAN interface be set as an IPX “numbered interface.” This means that the interface (and thus the Frame Relay network) must have an IPX
network number.
• IPX numbered interface
• IPX network number
CV: Use the IPX Routing: WAN Dialog Box.
TB: Use configure and set the Numbered and Net keywords in the IPX WAN 0 section.
Suggested for IPX
The settings above are all that is generally required for IPX operation over Frame Relay.
AppleTalk Protocol
Required for AppleTalk
Frame Relay operation requires that the WAN interface be set as an AppleTalk “numbered
interface.” This means that the interface (and thus the Frame Relay network) must have an
AppleTal k network number and an AppleTalk node number.
• AppleTal k numbered interface
• AppleTalk network number
• AppleTalk node numbe r
• AppleTal k zone name
CV: Use the AppleTalk Routing: WAN Dialog Box.
TB: Use configure and set the Numbered, NetLower, and DefZone keywords in the Apple-
Talk WAN 0 section.
Suggested for AppleTalk
The settings above are all that is generally required for AppleTalk operation over Frame Relay.
DECnet Protocol
Required for DECnet
In order to be used, DECnet must be turned on both globally and for a particular port.
WAN interfaces which are set for Frame Relay operation do not need any additional parame-
ters set in order to function.
• Set DECnet on (globally, and for this port)
CV: Use the DECnet Routing Dialog Box (under Global/DECne t Routing) and the DECnet:
WAN Dialog Box.
TB: Use configure and set the Mode keyword in the DECnet WAN 0 section.
v
Note: Setting DECnet on for any port with the command line also sets DECnet on globally.
In CompatiView you must set a global parameter and a port-specific parameter.
SMDS Configuration
This section covers the settings required for SMDS (Switched Multi-megabit Data Service)
operation of the DS3 WAN interface (IP only). SMDS is a connectionless, packet-switched
service that offers LAN-to-LAN connectivity across a wide area at up to 1.544 Mbps. SMDS
addresses and other parameters can only be set using the command line interface.
v
Note: The IP protocol settings and the physical communication settings are the same as they
would be for Frame Relay operation. The only parameters which sh ould be set differently for
SMDS are the Link Configuration and the SMDS addressing section.
Link Configuration
SMDS is presently supported in the DS3-Quad 10/100 RIOP only via synchronous dedicated
line operation.
• Set Dedicated connection
• Set SMDS connection
TB: Use configure to set the Mode
section.
Chapter 2 - Quickstart Instructions 10
and ConnectMode keywords in the Link Config WAN 0
Suggested for Dedicated/Leased Line Operation
Dedicated line operation generally does not require additional parameters for operation.
SMDS Addressing
Many of these parameters will be given to you by your service provider.
TB: Use configure and set the StationAddress, IPMulticast and PollingFrequency
keywords in the SMDS WAN 0 section.
Saving a Configuration File to Flash ROM
Once a configuration is complete, you can save it to the router’s Flash ROM. Until saved, all
changes are made in a separate buf f e r an d th e actual r outer interfaces co ntinue to r un as before
the changes were made.
CV: Use the Save to/Device option from the File menu.
TB: Use the save command.
Chapter 3 - Shipping Defaults 11
Chapter 3 - Shipping Defaults
Ethernet Interfaces
IP Routing Defaults
• Off, all interfaces
IP Bridging Defaults
• On, all interfaces
• Address: 198.41.12.1
• Subnet Mask: 255.255.255.0
• Broadcast Address: 198.41.12.255
• IP RIP off
IPX Routing Defaults
• 802.3 on, autoseeding, all interfaces
• 802.2 on, autoseeding, all interfaces
• Type II on, nonseeding
• 802.2 SNAP on , nonseeding
IPX Bridging Defaults
• Off, all interfaces
WAN Interface
AppleTalk Routing Defaults
• Phase I off, all interfaces
• Phase II on, autoseeding, all interfaces
AppleTalk Bridging Defaults
• Off, all interfaces
DECnet Defaults
• Off, all interfaces
IP Defaults
• On
• Unnumbered interface
• RIP off
• Van Jacobson compression off
IPX Defaults
• On
• Unnumbered interface
AppleTalk Defaults
• On
• Unnumbered interface
DECnet Defaults
• Off
DS3 CSU/DSU Defaults
• PPP
• 16 bit CRC
Chapter 4 - LED Patterns 12
Chapter 4 - LED Patterns
Some of the LEDs on the front of the VSR multigigabit switching router serve dual functions.
In addition to indicating certain router-wide operating conditions, they can also display
port-specific information.
v
Note: Any continuous flashing pattern not noted in this chapter may be caused by a hard-
ware failure. Please call Compatible Systems Technical Support if your router shows a hardware failure.
Router LED Patterns
The following LEDs and li ght pat terns provid e info rmation about t he VSR’s physical state and
operating conditions.
Over Temp
The router is above the proper operating temperature. The filter needs changing. See the
appropriate VSR chassis section of the manual for instructions.
Sys Ready
The router booted properly without detecting any failures.
General Indicators
Ethernet Lights DS3 Lights Indication
5 flashing 1 flashing Router stacks starting up.
3&4 flashing 2&3 flashing No OS loaded. Running from ROM.
1&4 flashing 2&5 flashing Erasing OS in Flash ROM.
5 flashing 1,2&3 flashing Erasing config in Flash ROM.
1 - 5 scanning 5 - 1 scanning Flash ROM erase due to switch setting five or six is
complete. Set switch to zero and cycle power.
Chapter 4 - LED Patterns 13
DS3-Quad 10/100 RIOP LED Patterns
The following LEDs and light patterns provide information about the DS3-Quad 10/100 RIOP
interfaces.
Ethernet Traffic Indicators
Scan from 1 to 3: Ethernet transmit packet
Scan from 5 to 3: Ethernet receive packet
DS3 Indicators
Scan from 1 to 3: WAN transmit packet
Scan from 5 to 3: WAN receive packet
Ethernet Connection Indicators
Link: The Link light indicates that there is a good connection to the hub.
Activity: The Activity light indicates that there is activity across the link.
100: The 100 light indicates that the interface is operating at 100 Mbps.
DS3 Connection Indicators
TX: WAN transmit packet
RX: WAN receive packet
Link: The Link light indicates that the interface is receiving signal from the upstream terminal.
Loading...
