QuickSpecs
Overview
At A Glance
•
Convertible minitower form factor
•
Supports up to two Intel® Xeon
processors, up to 2.2-GHz (400
MHz Front Side Bus)
•
Intel 860 chipset with 400-MHz
front side bus and dual memory
channels
•
512-KB L2 cac he integrated on
processor
•
ECC RDRAM expandable to 2
GB
•
High-perform anc e Ul tr a16 0 SCSI
10,000 rpm or 15,000 rpm hard
drives or UATA/100 7200 rpm
hard drives
•
Integrated Ultra160 SCSI and
Ultra ATA/10 0 controllers
•
Up to 360 GB of highperformance internal st orage
•
Choice of NVIDIA® Quadro2 EX,
NVIDIA Quadro2 MXR, NVIDIA
Quadro2 Pro, Matr ox
Millennium
Quad Multi-monitor Series,
Matrox Millennium G5 50, ATI
Fire GL2, ATI Fi re GL4, or
3Dlabs Wildc at™ II 5110
Graphics Cont roller
•
Multiple display support
•
Integrated Intel PRO/100+
Management Adapter
•
Four total slots (three PCI and
one AGP Pro 4X)
•
Five bays (three external and
two internal )
•
CD-ROM, DVD-ROM, or CD-RW
drive (depending on model)
•
SoundBlaster 128 audio
•
Windows® XP® Professional,
Windows 2000
Compaq support software preinstalled
•
Protected by Compaq Services,
including a t hree-year, li mited
warranty
and exclusions apply. Consult the
Compaq Customer Su pp ort
Center for det ails. Three-year
onsite and labor not avail able in
all countries.
®
®
— certain restrictions
G450, Matrox G200
®
Professional and
®
Compaq Evo W orkstation W6000
DA-10840 North America — Versi on 22 — March 18 , 2002 1
QuickSpecs
Standard Features - Pre-configured Models
Compaq Evo W orkstation W6000
Models
Processor
One of the following:
Cache Memory
Upgradabili ty
Memory
One of the following:
Network Con troller
Expansion Slots
AGP Pro 4X 1, up to 1 depending on model
Expansion Bays
Internal 2/1
External 3/1
Storage Diskette Drive 1.44 MB
Removable Media CD-ROM, or DVD-ROM Drive
Hard Drive 18.2-GB Ultra160 SCSI (10,000 rpm)
Interfaces
Compaq Evo Workstation W6000
Available in multiple configurations.
Not all configurations available in all countries.
Check with your Authorized Compaq Reseller or Compaq.
Intel Xeon processor 1.8 GHz, 512-KB cache
Intel Xeon processor 2.0 GHz, 512-KB cache
Intel Xeon processor 2.2 GHz, 512-KB cache
512-KB integrated, full speed Level 2 cache per processor
Upgradable to dual processor
Standard 1 GB of 800-MHz ECC RDRAM
Standard 512 MB of 800-MHz ECC RDRAM
Maximum 2 GB of 800-MHz ECC RDRAM
Integrated Intel PRO/100+ Management Adapter
I/O (Total) 4, up to 3 available
32-bit/33-MHz PCI 3, up to 3 depending on model
(Total/Available) 5/2
Parallel
USB
Serial
Ultra160 SCSI
Ultra ATA/100
Keyboard (PS/2)
Pointing Device (PS/2 mouse)
Video
Microphone Jack
Headphone Jack
Line-In Jack
Line-Out Jack
RJ-45
1
4
2
1 (68-pin internal)
2
1
1
1
1
1
1
1
1
DA-10840 North America — Versi on 22 — March 18 , 2002 2
QuickSpecs
Standard Features - Pre-configured Models
Compaq Evo W orkstation W6000
Graphics
One of the following:
Audio
Software
Intelligent M anageability
Security
Power Supply
Service and Support
Matrox Millennium G550 with analog and DVI cables (AGP)
Matrox Millennium G450 (AGP or PCI)
Matrox G200 Quad Multi-monitor Series (PCI)
NVIDIA Quadro2 EX (AGP)
NVIDIA Quadro2 MXR (AGP)
NVIDIA Quadro2 Pro (AGP
ATI Fire GL2 (AGP)
ATI Fire GL4 (AGP)
3Dlabs Wildcat II 5110 (AGP)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
Windows XP Professional
Windows 2000 Professional or Microsoft Windows NT Workstation 4.0
Microsoft Service Pack 2 for Windows 2000 Professional
Microsoft Service Pack 6a for Windows NT 4.0
Compaq Restore CD
Compaq Management Agents
Compaq PC Diagnostics via the Web
ROM-based Setup
Diagnostics for Windows 2000 and Windows NT
Microsoft Internet Explorer
System Software Manager via the Web
Altiris eXpress (Limited time license)
Asset Control
Alert on LAN (AoL) hardware ready
Wake on LAN (WoL)
Fault Management
Lite Console
Security Management
Pre-Failure Warranty (processors, hard drives and memory)
Remote Management
Remote Wakeup via Magic Packet Support
Remote ROM Flash
Remote Security
Remote Shut Down
Bios Features
Advanced Configuration and Power Interface (ACPI) 1.0b
Advanced Power Management (APM) 1.2
Desktop Management Interface (DMI) 2.1
System Management (SM) Bios 2.3
Diskette write and boot control
Flash ROM lock
Keyboard password
Network server mode
Parallel interface control
Power-on password
Serial interface control
Setup password
Cable lock provision
460-Watt, with Power Factor Correction
Protected by Compaq Services including a three-year, limited warranty with three-year parts coverage, three year,
on-site service, and three-year labor; 7 x 24 hardware technical phone support and on-line support through the
Internet; Pre-Failure Warranty coverage of hard drives, memory, and processors.
Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center for details. Three-
year, onsite and labor not available in all countries.
DA-10840 North America — Versi on 22 — March 18 , 2002 3
QuickSpecs
Pre-configured Models
Compaq Evo W orkstation W6000
W6P/2.2/18S/512/Xd
470029-950 and graphics option
Graphics
Audio
OS
W6P/2.2/18S/1/Xd
470029-977 and graphics option
Graphics
Audio
OS
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Intel Xeon 2.2 GHz
512-KB integrated L2
512-MB 800-MHz ECC RDRAM
16X/40X DVD-ROM Drive
18.2-GB Ultra160 SCSI 10,000rpm
Choice of graphics option:
Matrox Millennium G550 with analog and DVI cables (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
Intel Xeon 2.2 GHz
512-KB integrated, L2
1-GB 800-MHz ECC RDRAM
16X/40X DVD-ROM Drive
18.2-GB Ultra160 SCSI 10,000rpm
Choice of graphics option:
Matrox Millennium G550 with analog and DVI cables (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
DA-10840 North America — Versi on 22 — March 18 , 2002 4
QuickSpecs
Pre-configured Models
Compaq Evo W orkstation W6000
W6P/2.0/18S/512/Xd
470031-197 and Compaq after market
graphics option
Graphics
Audio
OS
W6P/2.0/18S/1/Xd
470031-208 and Compaq after market
graphics option
Graphics
Audio
OS
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Intel Xeon 2.0 GHz
512-KB integrated L2
512-MB 800-MHz ECC RDRAM
16X/40X DVD-ROM Drive
18.2-GB Ultra160 SCSI 10,000rpm
Choice of graphics option:
Matrox Millennium G550 with analog and DVI cables (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
Intel Xeon 2.0 GHz
512-KB integrated, L2
1-GB 800-MHz ECC RDRAM
16X/40X DVD-ROM Drive
18.2-GB Ultra160 SCSI 10,000rpm
Choice of graphics option:
Matrox Millennium G550 with analog and DVI cables (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
DA-10840 North America — Versi on 22 — March 18 , 2002 5
QuickSpecs
Pre-configured Models
Compaq Evo W orkstation W6000
W6P/1.8/18S/512/Xd
470031-273 and Compaq after market
graphics option
Graphics
Audio
OS
W6P/1.8/18S/1/Xd
470031-304 and Compaq after market
graphics option
Graphics
Audio
OS
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Intel Xeon 1.8-GHz
512-KB integrated L2
512-MB 800-MHz ECC RDRAM
16X/40X DVD-ROM Drive
18.2-GB Ultra160 SCSI 10,000 rpm
Choice of graphics option:
Matrox Millennium G550 with analog and DVI cables (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
Intel Xeon 1.8-GHz
512-KB integrated L2
1-GB 800-MHz ECC RDRAM
16X/40X DVD-ROM Drive
18.2-GB Ultra160 SCSI 10,000 rpm
Choice of graphics option:
Matrox Millennium G550 with analog and DVI cables (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
DA-10840 North America — Versi on 22 — March 18 , 2002 6
QuickSpecs
,
(
)
Pre-configured Models
Compaq Evo W orkstation W6000
W6/2.2/18S/0/Xc
470029-895 and Compaq after-market
graphics option and memory option
Optical Drive 48X Max CD-ROM Drive
Hard Drive 18.2-GB Ultra160 SCSI 10,000rpm
Audio
OS Windows 2000 SP2/Windows XP Professional (dual install)
W6/2.2/36S/0/Xd
470029-904 and Compaq after-market
graphics option and memory option
Optical Drive 16X/40X DVD-ROM Drive
Hard Drive 36.4-GB Ultra160 SCSI 10
Graphics Choice of graphics option:
Audio Integrated SoundBlaster 128 Audio
OS Windows 2000 Professional/Windows NT Workstation 4.0 (dual install)
Processor
Cache Memory
Memory
Graphics
Processor
Cache Memory
Memory
Intel Xeon 2.2 GHz
512-KB integrated L2
Choice of memory option:
512-MB Memory Module (800-MHz ECC) (103996-B21)
256-MB Memory Module (800-MHz ECC) (157341-B21)
128-MB Memory Module (800-MHz ECC) (157338-B21)
Note: Memory must be installed in like pairs. Option kits contain one memory module.
Choice of graphics option:
Matrox Millennium G550 Graphics Controller (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Intel Xeon 2.2-GHz
512-KB integrated L2
Choice of memory option:
512-MB Memory Module (800-MHz ECC) (103996-B21)
256-MB Memory Module (800-MHz ECC) (157341-B21)
128-MB Memory Module (800-MHz ECC) (157338-B21)
Note: Memory must be installed in like pairs. Option kits contain one memory module.
000 rpm
Matrox Millennium G550 Graphics Controller (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110
224085-B21
DA-10840 North America — Versi on 22 — March 18 , 2002 7
QuickSpecs
Pre-configured Models
Compaq Evo W orkstation W6000
W6/2.2/40A/0/Xc
470029-911 and Compaq after-market
graphics option and memory option
Graphics
Audio
OS
W6/2.0/40A/0/Xc
470031-142 and Compaq after-market
graphics option and memory option
Graphics
Audio
OS
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Intel Xeon 2.2 GHz
512-KB integrated L2
Choice of memory option:
512-MB Memory Module (800-MHz ECC) (103996-B21)
256-MB Memory Module (800-MHz ECC) (157341-B21)
128-MB Memory Module (800-MHz ECC) (157338-B21)
Note: Memory must be installed in like pairs. Option kits contain one memory module.
48X Max CD-ROM Drive
40-GB Ultra ATA/100 7200 rpm
Choice of graphics option:
Matrox Millennium G550 Graphics Controller (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
Intel Xeon 2.0 GHz
512-KB integrated L2
Choice of memory option:
512-MB Memory Module (800-MHz ECC) (103996-B21)
256-MB Memory Module (800-MHz ECC) (157341-B21)
128-MB Memory Module (800-MHz ECC) (157338-B21)
Note: Memory must be installed in like pairs. Option kits contain one memory module.
48X Max CD-ROM Drive
40-GB Ultra ATA/100 7200 rpm
Choice of graphics option:
Matrox Millennium G550 Graphics Controller (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
DA-10840 North America — Versi on 22 — March 18 , 2002 8
QuickSpecs
Pre-configured Models
Compaq Evo W orkstation W6000
W6/2.0/18S/0/Xc
470031-140 and Compaq after-market
graphics option and memory option
Graphics
Audio
OS
W6/2.0/18K/0/Xd
470031-144 and Compaq after-market
graphics option and memory option
Graphics
Audio
OS
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Intel Xeon 2.0 GHz
512-KB integrated L2
Choice of memory option:
512-MB Memory Module (800-MHz ECC) (103996-B21)
256-MB Memory Module (800-MHz ECC) (157341-B21)
128-MB Memory Module (800-MHz ECC) (157338-B21)
Note: Memory must be installed in like pairs. Option kits contain one memory module.
48X Max CD-ROM Drive
18.2-GB Ultra160 SCSI 10,000rpm
Choice of graphics option:
Matrox Millennium G550 Graphics Controller (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
Intel Xeon 2.0-GHz
512-KB integrated L2
Choice of memory option:
512-MB Memory Module (800-MHz ECC) (103996-B21)
256-MB Memory Module (800-MHz ECC) (157341-B21)
128-MB Memory Module (800-MHz ECC) (157338-B21)
Note: Memory must be installed in like pairs. Option kits contain one memory module.
16X/40X DVD-ROM Drive
18.2-GB Ultra160 SCSI 15,000 rpm
Choice of graphics option:
Matrox Millennium G550 Graphics Controller (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
DA-10840 North America — Versi on 22 — March 18 , 2002 9
QuickSpecs
Pre-configured Models
Compaq Evo W orkstation W6000
W6/2.0/36S/0/Xd
470031-146 and Compaq after-market
graphics option and memory option
Graphics
Audio
OS
W6/1.8/40A/0/Xc
470031-243 and Compaq after-market
graphics option and memory option
Graphics
Audio
OS
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Intel Xeon 2.0-GHz
512-KB integrated L2
Choice of memory option:
512-MB Memory Module (800-MHz ECC) (103996-B21)
256-MB Memory Module (800-MHz ECC) (157341-B21)
128-MB Memory Module (800-MHz ECC) (157338-B21)
Note: Memory must be installed in like pairs. Option kits contain one memory module.
16X/40X DVD-ROM Drive
36.4-GB Ultra160 SCSI 10,000 rpm
Choice of graphics option:
Matrox Millennium G550 Graphics Controller (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
Intel Xeon 1.8-GHz
512-KB integrated L2
Choice of memory option:
512-MB Memory Module (800-MHz ECC) (103996-B21)
256-MB Memory Module (800-MHz ECC) (157341-B21)
128-MB Memory Module (800-MHz ECC) (157338-B21)
Note: Memory must be installed in like pairs. Option kits contain one memory module.
48X Max CD-ROM Drive
40-GB Ultra ATA/100 7200 rpm
Choice of graphics option:
Matrox Millennium G550 Graphics Controller (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
DA-10840 North America — Versi on 22 — March 18 , 2002 10
QuickSpecs
Pre-configured Models
Compaq Evo W orkstation W6000
W6/1.8/18S/0/Xc
470031-241 and Compaq after-market
graphics option and memory option
Processor
Cache Memory
Memory
Optical Drive
Hard Drive
Graphics
Audio
OS
Intel Xeon 1.8 GHz
512-KB integrated L2
Choice of memory option:
512-MB Memory Module (800-MHz ECC) (103996-B21)
256-MB Memory Module (800-MHz ECC) (157341-B21)
128-MB Memory Module (800-MHz ECC) (157338-B21)
Note: Memory must be installed in like pairs. Option kits contain one memory module.
48X Max CD-ROM Drive
18.2-GB Ultra160 SCSI 10,000rpm
Choice of graphics option:
Matrox Millennium G550 Graphics Controller (AGP) (250227-B21)
Matrox Millennium G450 (AGP) (202389-B21)
Matrox Millennium G450 (PCI) (202390-B21)
Matrox G200 Quad MMS with analog cables (159513-B21)
Matrox G200 Quad MMS with DVI cables (179597-B21)
NVIDIA Quadro2 EX (250066-B21)
NVIDIA Quadro2 MXR (221412-B21)
NVIDIA Quadro2 Pro (225339-B21)
ATI Fire GL2 (224087-B21)
ATI FireGL4 (245012-B21)
3Dlabs Wildcat II 5110 (224085-B21)
Integrated SoundBlaster 128 Audio
Windows 2000 SP2/Windows XP Professional (dual install)
DA-10840 North America — Versi on 22 — March 18 , 2002 11
QuickSpecs
Standard Features – Custom Configuration Models
Compaq Evo W orkstation W6000
Processor
One of the following:
Cache Memory
Upgradabili ty
Memory
Network Con troller
Expansion Slots
Expansion Bays
Storage
Ecrix 33/66 GB VXA-1 Tape Drive (SCSI or IDE)
Interfaces Parallel
Graphics
One of the following:
Intel Xeon processor 1.8 GHz, 512-KB cache
Intel Xeon processor 2.0GHz, 512-KB cache
Intel Xeon processor 2.2 GHz, 512-KB cache
512-KB integrated, full speed Level 2 cache per processor
Upgradable to dual processor
Maximum 2 GB of 800-MHz ECC RDRAM
Integrated Intel PRO/100+ Management Adapter
3COM 3C920C PCI card
I/O (Total)
32-bit/33-MHz PCI
AGP Pro 4X
(Total/Available)
Internal
External
Diskette Drive 1.44 MB
Removable Media CD-ROM, CD-RW or DVD-ROM drive
Hard Drives 72-GB, 36.4-GB, 18.2-GB Ultra160 SCSI (10,000 rpm)
36.4-GB,18.2-GB Ultra160 SCSI (15,000 rpm)
120-GB, 80, 60-GB, 40-GB or 20-GB Ultra ATA/100 (7200 rpm)
Tape Drives TR5 10/20-GB
250-MB ATAPI ZIP
USB
Serial
Ultra160 SCSI
Ultra ATA/100
Keyboard (PS/2)
Pointing Device (PS/2 mouse)
Video
Microphone Jack
Headphone Jack
Line-In
Line-Out
RJ-45
Matrox Millennium G550 with analog and DVI cables (AGP)
Matrox Millennium G450 (AGP or PCI)
Matrox G200 Quad Multi-monitor Series (PCI)
NVIDIA Quadro2 EX (AGP)
NVIDIA Quadro2 MXR (AGP)
NVIDIA Quadro2 Pro (AGP)
ATI Fire GL2 (AGP)
ATI FireGL4 (AGP)
3Dlabs Wildcat II 5110 (AGP)
4, up to 3 available
3, up to 3 depending on model
1, up to 1 depending on model
5/2
2/1
3/1
1
4
2
1 (68-pin internal)
2
1
1
1
1
1
1
1
1
DA-10840 North America — Versi on 22 — March 18 , 2002 12
QuickSpecs
Options
Compaq Evo W orkstation W6000
Processor Intel Xeon processor 1.8 GHz, 512-KB cache
Intel Xeon processor 2.0 GHz, 512-KB cache
Intel Xeon processor 2.2 GHz, 512-KB cache
Memory (RDRAM) 512-MB Memory Module Upgrade Kit (800-MHz ECC)
Monitors TFT8030 Flat Panel Color Monitor (18-inch, Carbon/Silver)
TFT8020 Flat Panel Color Monitor (18-inch, Carbon)
TFT8020 Flat Panel Color Monitor (17-inch, Opal)
TFT7020 Flat Panel Color Monitor (17-inch, Carbon/Silver, baseless)
TFT7020 Flat Panel Color Monitor (17-inch, Carbon/Silver, built in speakers)
TFT5030 Flat Panel Color Monitor (15-inch, Carbon/Silver)
TFT5015 Flat Panel Color Monitor (15-inch, Multimedia)
TFT5015 Flat Panel Color Monitor (15-inch, Carbon/Silver)
TFT5015 Flat Panel Color Monitor (15-inch, Opal)
P1220 CRT Color Monitor (22-inch, Carbon/Silver)
P920 CRT Color Monitor (19-inch, Carbon/Silver)
P720 CRT Color Monitor (17-inch, Carbon/Silver Two Tone)
V720 CRT Color Monitor (17-inch, Carbon/Silver Two Tone)
Graphics Matrox G200 Quad Multi-monitor Series with cables for analog output (PCI) 159513-B21
Matrox G200 Quad Multi-monitor Series with cables for DVI output (PCI) 179597-B21
Matrox G200 Quad MMS DVI Upgrade Cable Kit (for option kit 159513-B21) 170840-B21
Matrox Millennium G550 with analog and DVI cables (AGP) 250227-B21
Matrox Millennium G450 (PCI) 202390-B21
Matrox Millennium G450 (AGP) 202389-B21
NVIDIA Quadro2 EX (AGP) 250066-B21
NVIDIA Quadro2 MXR (AGP) 221412-B21
NVIDIA Quadro2 Pro (AGP) 225339-B21
ATI FireGL2 (AGP) 224087-B21
ATI FireGL4 (AGP) 245012-B21
3Dlabs Wildcat II 5110 (AGP Pro 4X) 224085-B21
Diskette Drives 250-MB ATAPI ZIP (carbon) 294416-B22
250-MB ATAPI ZIP Media 3-Pack 217896-B21
Tape Drives TR5 10/20-GB 294243-B22
TR5 10/20-GB Media 3-pack 125782-B21
33/66GB VXA-1 IDE 237109-B22
33/66GB VXA-1 SCSI 237108-B22
33/66GB VXA-1 Media 2-pack 237111-B21
VXA-1 Cleaning Cartridge 237110-B21
Note: When adding an additional processor, both processors must have the same speed and cache size.
256-MB Memory Module Upgrade Kit (800-MHz ECC)
128-MB Memory Module Upgrade Kit (800-MHz ECC)
Note: Memory must be installed in like pairs. Option kits contain one memory module. Only 800-MHz speed is
qualified..
Note: AssetControl monitor. AssetControl features are accessible with Compaq
Workstations featuring Intelligent Manageability.
277599-B21
277600-B21
267805-B21
103996-B21
157341-B21
157338-B21
234362-001
159244-001
326100-001
253218-001
253217-001
228134-001
234046-001
234044-001
234043-001
244374-001
244375-001
244373-001
232944-001
DA-10840 North America — Versi on 22 — March 18 , 2002 13
QuickSpecs
Options
Compaq Evo W orkstation W6000
Hard Drives
Storage Controllers Adaptec 29160N Ultra160 Single Channel SCSI Controller 157810-B21
Adaptec 2100S Ultra 160 (U3) Single Channel RAID Controller
5 Device SCSI Cable
Biometrics USB Biometric FIT Device (Carbon)
Multimedia 48X CD-ROM (carbon)
16X/10X/40X CD-RW Drive (carbon)
16X/40X DVD-ROM (carbon, without MPEG2 decoder)
12X/8X/32X CD-RW Drive (carbon)
8X Combo CD-RW/DVD-ROM (carbon)
4.7-GB DVD-RAM Drive (carbon)
4.7-GB DVD RAM (Single Sided) Media Kit
Labtec Spin-22 Carbon Speakers
Compaq Digital Video (DV) Option Kit
4.7-GB DVD-RW drive (carbon) 246625-B22
4.7-GB DVD-RAM (Single Sided) Media Kit 211082-B21
Communications Compaq NC3123 Fast Ethernet NIC PCI 10/100 WoL 174830-B21
Compaq NC3134: 64 PCI, Dual Base 10/100 WoL 138603-B21
Compaq NC3135: 10/100 Dual Upgrade Module (for NC3134) 138604-B21
Compaq NC6134: Gbit NIC 64 PCI 1000SX 174818-B21
Compaq NC6136 Fiber Gbit NIC 203539-B21
Compaq NC7131 Gigabit Server Adapter PCI (64/44 10/100/1000-T) 158575-B21
Lucent V.90 56K PCI Win Modem 239137-B21
Intel Pro/100+Management Adapter w/IP Security (Single Pack) 212953-B21
Intel Pro/100+Management Adapter w/IP Security (20 Pack) 212954-B21
Uninterruptible Power Systems Compaq Tower UPS Model T1500 (low voltage) 242688-003
Compaq Tower UPS Model T1000 (low voltage) 242688-001
Ultra3 (Ultra160) SCSI Drives
72-GBUltra160 SCSI 10,000 rpm
36.4-GB Ultra160 SCSI 10,000 rpm
36.4-GB Ultra 160 SCSI 15,000 rpm
18.2-GB Ultra160 SCSI 15,000 rpm
18.2-GB Ultra160 SCSI 10,000 rpm
Ultra ATA Drives
120-GB Ultra ATA 7200 rpm Quiet Seek and Quiet Idle
80-GB Ultra ATA 7200 rpm Quiet Seek and Quiet Idle
60-GB Ultra ATA 7200 rpm Quiet Seek and Quiet Idle
40-GB Ultra ATA 7200 rpm Quiet Seek and Quiet Idle
20-GB Ultra ATA 7200 rpm Quiet Seek
IEEE 1394 PCI Card with Adobe Premiere 6.0
Compaq Tower UPS Model T700 (low voltage)
250023-B21
191189-B21
250022-B21
191188-B21
159764-B21
250021-B21
250020-B21
230253-B21
201066-B21
176272-B21
192842-B21
230777-B21
240238-B21
187217-B22
240598-B22
237495-B22
217682-B22
244885-B22
294415-B22
211082-B21
246637-001
229966-B21
295372-B21
DA-10840 North America — Versi on 22 — March 18 , 2002 14
QuickSpecs
Options
Compaq Evo W orkstation W6000
Other Compaq Scroll Mouse (carbon)
3 Button Mouse (carbon)
Compaq Easy Access Keyboard (Carbon)
External SCSI Adapter 68-/50-Pin
Sliding Shelf Kit
5 Device LVD/SE Cable Kit
Spaceball 4000 3D Motion Controller (Carbon)
Rack Fixed Shelf
Depth Adjustable Rails
Support Software CD Single CD-ROM (current month)
170299-B22
269192-B23
202109-008
270187-B21
332564-B21
230777-B21
112138-B22
303606-B21
332558-B21
272505-001
DA-10840 North America — Versi on 22 — March 18 , 2002 15
QuickSpecs
y
emory Channe
Memory
Compaq Evo W orkstation W6000
Compaq Evo Workstation W6000
S
TANDARD MEMORY
256-MB of 800-MHz ECC RDRAM is standard. Memory must be installed in like pairs. (Only 800-MHz memory speed is supported.)
S
TANDARD MEMORY PLUS OPTIONAL MEMORY
Support for up to 1280 MB of 800-MHz ECC RDRAM is available with the installation of optional Memory Kits. Memory must be installed in like
pairs.
S
TANDARD MEMORY REPLACED WITH OPTIONAL MEMORY
Support for up to 2 GB of 800-MHz ECC RDRAM is available with the removal of the standard 128-MB RDRAM modules and the installation of
optional 512MB 800-MHz ECC RDRAM Kits. Memory must be installed in like pairs
Note: This chart does not represent all possible memory configurations. Memory must be installed in like pairs. Option kits contain one memory
module.
Memor
XMM1 XMM2 XMM3 XMM4
Standard 256 MB
Optional 512 MB
Optional 768 MB
Maximum 1024 MB
Maximum 2048 MB
M
128 MB CRIMM 128 MB CRIMM
128 MB 128 MB 128 MB 128 MB
128 MB 256 MB 128 MB 256 MB
256 MB 256 MB 256 MB 256 MB
512 MB 512 MB 512 MB 512 MB
l A Memory Channel B
Following are memory options available from Compaq:
• 512-MB Memory Kit (800 MHz ECC RDRAM) 103996-B21
• 256-MB Memory Kit (800 MHz ECC RDRAM) 157341-B21
• 128-MB Memory Kit (800 MHz ECC RDRAM) 157338-B21
DA-10840 North America — Versi on 22 — March 18 , 2002 16
QuickSpecs
y
emory Channe
Memory
Compaq Evo W orkstation W6000
Compaq Evo Workstation W6000
S
TANDARD MEMORY
512-MB of 800-MHz ECC RDRAM is standard. Memory must be installed in like pairs. (Only 800-MHz memory speed is supported.)
S
TANDARD MEMORY PLUS OPTIONAL MEMORY
Support for up to 1536 MB of 800-MHz ECC RDRAM is available with the installation of optional ECC RDRAM Kits. Memory must be installed in
like pairs.
S
TANDARD MEMORY REPLACED WITH OPTIONAL MEMORY
Support for up to 2 GB of 800-MHz ECC RDRAM is available with the removal of the standard 128-MB RDRAM modules and the installation of
optional 512MB 800-MHz ECC RDRAM Kits. Memory must be installed in like pairs.
Note: This chart does not represent all possible memory configurations. Memory must be installed in like pairs. Option kits contain one memory
module.
Memor
XMM1 XMM2 XMM3 XMM4
Standard 512 MB
Optional 1024 MB
Optional 2048 MB
M
256 MB CRIMM 256 MB CRIMM
256 MB 256 MB 256 MB 256 MB
512 MB 512 MB 512 MB 512 MB
l A Memory Channel B
Following are memory options available from Compaq:
• 512-MB Memory Kit (800 MHz ECC RDRAM) 103996-B21
• 256-MB Memory Kit (800 MHz ECC RDRAM) 157341-B21
• 128-MB Memory Kit (800 MHz ECC RDRAM) 157338-B21
DA-10840 North America — Versi on 22 — March 18 , 2002 17
QuickSpecs
emory Channe
Memory
Compaq Evo Workstation W6000
S
TANDARD MEMORY
1 GB of 800-MHz ECC RDRAM is standard. Memory must be installed in like pairs. (Only 800-MHz memory speed is supported.)
S
TANDARD MEMORY PLUS OPTIONAL MEMORY
Support for up to 2 GB of ECC RDRAM. Memory must be installed in like pairs.
Note: This chart does not represent all possible memory configurations. Memory must be installed in like pairs. Option kits contain one memory
module.
Compaq Evo W orkstation W6000
Memory
XMM1 XMM2 XMM3 XMM4
Standard 1024 MB
Optional 2048 MB
M
512 MB CRIMM 512 MB CRIMM
512 MB 512 MB 512 MB 512 MB
l A Memory Channel B
Following are memory options available from Compaq:
• 512-MB Memory Kit (RDRAM RIMM, 800 MHz) 103996-B21
• 256-MB Memory Kit (RDRAM RIMM, 800 MHz) 157341-B21
• 128-MB Memory Kit (RDRAM RIMM, 800 MHz) 157338-B21
DA-10840 North America — Versi on 22 — March 18 , 2002 18
QuickSpecs
Storage
Compaq Evo W orkstation W6000
RIVE SUPPORT
D
Removable Media
1.44-MB Diskette Drive Up to 1 1, 2, 3 Integrated
CD-ROM Drive Up to 1 1, 2 Integrated EIDE
250-MB ATAPI ZIP Drive Up to 1 1, 2 Integrated EIDE
16X/40X DVD-ROM Drive Up to 1 1, 2 Integrated EIDE
16X/10X/40X CD-RW Drive Up to 1 1, 2 Integrated EIDE
8X Combo CD-RW/DVD-ROM Up to 1 1, 2 Integrated EIDE
TR5 10/20-GB tape drive Up to 1 1, 2 Integrated EIDE
33/66GB VXA-1 tape drive Up to 1 1, 2 Integrated EIDE
4.7-GB DVD-RAM Drive Up to 1 1, 2 Integrated EIDE
Hard Drive s
Ultra3 (Ultra160) SCSI Drives
1-inch
72-GB 10,000 rpm
36.4-GB 10,000 rpm
36.4-GB 15,000 rpm
18.2-GB 15,000 rpm
18.2-GB 10,000 rpm
Ultra ATA Drives
1-inch
20-GB 7200 rpm
40-GB 7200 rpm
60-GB 7200 rpm
80-GB 7200 rpm
120-GB 7200 rpm
Maximum Sto rage Capacity
Internal
Quantity
Supported
Position
Supported Controller
Up to 3
1, 2, 3, 4, 5 Integrated Ultra160 SCSI Controller
Up to 3
360 GB (assumes two removable media drives installed)
1, 2, 3, 4, 5 Integrated EIDE
DA-10840 North America — Versi on 22 — March 18 , 2002 19
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
System Unit
Power Supply Operating Voltage Range 90 VAC to 264 VAC
Rated Line Frequency 50 Hz to 60 Hz
Rated Input Current 8.6A @ 115 VAC; 4.3A @ 230 VAC
Maximum Rated Power 460-Watt output
Physical Dimensions 5.9 x 3.85 x 6.3 in/15 x 9.8 x 16 cm
Weight 4.5 lbs/2.05 kg
Non-operating 4° to 140°F/–15° to 60°C
Non-operating 10% to 90%
Non-operating 30,000 ft/9,144 m
Compaq Easy Access Keyboard Dimensions (HxWxD)
Weight
Electrical
Tower Dimensions (HxWxD) 17.65 x 6.6 x 17.61 in/44.83 x 16.76 x 44.73 cm
Weight
(standard configuration)
Temperature
(Values are subject to change)
Humidity (non-condensing)
(Values are subject to change)
Maximum Altitude
(nonpressurized)
Mechanical Languages
Environmental Operating Temperature
Non-operating Temperature
Operating Humidity
Non-operating Humidity
Operating Shock
Non-operating Shock
Operating Vibration
Non-operating Vibration
26 lbs/12 kg
Rated Voltage Range 100 VAC to 120 VAC; 200 VAC to 240 VAC
Operating 50° to 95°F/10° to 35°C
Operating 20% to 80%
Operating 10,000 ft/3,048 m
18.3 x 6.3 x 1.4 in/465 x 160 x 36 mm
Approximately 2 lbs/0.9 kg
Operating Voltage
Power Consumption
System Interface
ESD
EMI-RFI Conforms to FCC rules for a Class B computing
PC98
Keycaps Low-profile design
Switch Actuation
Switch Life
Switch Type
Key Leveling Mechanism
Cable Length
PC98-99
Acoustics
+5VDC ± 5%
50 mA maximum (with 3 LEDs on)
PS/2 mini-din connector
CE level 4, 15 kV air discharge
device
Functionally compliant
30+ available
55 g nominal peak force with tactile feedback
20 million keystrokes (using Hasco modified tester)
Contamination resistant membrane
For all double wide and greater length keys
6 ft/1.8 m
Mechanically compliant
50 dBA maximum sound pressure level
50° to 122° F/10° to 50° C
−22° to 140° F/−30° to 60° C
10% to 90% (non condensing at ambient)
20% to 80% (non condensing at ambient)
40 g, 6 surfaces
80 g, 6 surfaces
2 g peak acceleration
4 g peak acceleration
DA-10840 North America — Versi on 22 — March 18 , 2002 20
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
1.44-MB Diskette Drive
LED Indicators (front panel) Green
Drive Height One-third
Drive Rotation 300 rpm
Transfer Rate (high/low) 500/250 Kb/s
Bytes/Sector 512
Sectors/Track (high/low) 18/9
Tracks/Side (high/low) 80/80
Access Times Track-to-Track (high/low)
Average (high/low)
Settling Time
Latency Average
Cylinders (high/low)
Read/Write Heads
Compaq 3-Button Mouse
Environmental
Diskette Size 3.5 in
Read/Write Capacity per
Diskette (high/low)
Dimensions/Weight
Mechanical Resolution
Regulatory Approvals
1.44 MB/720 KB
3/6 ms
94/173 ms
15 ms
100 ms
80/80
Two
Height 1.42 in/3.6 cm
Length 4.17 in/10.7 cm
Width 2.87 in/7.4 cm
Weight 5.20 oz/150 g
Operating Temperature
Non-operating Temperature
Operating Humidity 10% to 90% (non condensing at ambient)
Tracking Speed
Switch Life
Switch Type
Tracking Mechanism Life
Cable Length
PC98-99
Compliant UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI,
32° to 104° F/0°C to 40° C
–4° to 140° F/–20° to 60°C
400 ± 20% DPI
10 in/s Maximum
1,000,000 operations (using Hasco modified
tester)
Micro-switches
155 miles/250 km at average speed of 10 in/s
6 ft/1.8 m
Mechanically compliant
BSMI, C-Tick
DA-10840 North America — Versi on 22 — March 18 , 2002 21
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
Ultra160 SCSI Hard Drives
Transfer Rate Synchronous
Full-Stroke 7 ms
Physical Configuration Bytes/Sector 512
Logical Blocks 71,132,000
Operating Temperature 50° to 95°F/10° to 35°C
72 GB Capacity
250023-B21 Height
Width
Interface
36.4 GB Capacity
191189-B21 Height
Width
Interface
36.4 GB
250022-B21 Width 4.0in/101.6mm
Single Track 0.4 ms
Average 3.8 ms
18.2 GB Capacity
191188-B21
Synchronous Transfer Rate
(Maximum)
Seek Time (typical reads,
including settling)
Logical Blocks 142,264,000
Operating Temperature 50° to 95°F/10° to 35°C
Synchronous Transfer Rate
(Maximum)
Seek Time (typical reads,
including settling)
Logical Blocks 71,132,000
Operating Temperature 50° to 95°F/10° to 35°C
Capacity
Height
Interface Wide Ultra3 SCSI
(Maximum)
Seek Time
(typical reads, including
settling)
Height 1 in/25.4 mm
Width 3.5 in/88.9 mm
Interface Ultra160 SCSI
Synchronous Transfer Rate
(Maximum)
Seek Time (typical reads,
including settling)
Logical Blocks 35,566,000
Operating Temperature 50° to 95°F/10° to 35°C
72,000 MB
1.0 in/40.64 mm
3.5 in/88.9 mm
Ultra160 SCSI
160 MB/s
Single Track 0.6 ms
Average 5.2 ms
Full-Stroke 12 ms
Rotational Speed 10,000 rpm
36,400 MB
1.0 in/25.4 mm
3.5 in/88.9 mm
Ultra160 SCSI
160 MB/s
Single Track 0.6 ms
Average 4.7 ms
Full-Stroke 12 ms
Rotational Speed 10,000 rpm
36419.2 MB
1 in/25.4mm
160 MB/s
Rotational Speed 15,000 rpm
18,209 MB
160 MB/s
Single Track 0.8 ms
Average 4.1 ms
Full-Stroke 7.7 ms
Rotational Speed 15,000 rpm
DA-10840 North America — Versi on 22 — March 18 , 2002 22
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
Ultra160 SCSI Hard Drives
(continued)
18.2 GB Capacity
159764-B21 Height
Width
Interface
Synchronous Transfer Rate
(Maximum)
Seek Time (typical reads,
including settling)
Logical Blocks 35,566,000
Operating Temperature 50° to 95°F/10° to 35°C
18,209 MB
1 in/25.4 mm
3.5 in/88.9 mm
Ultra160 SCSI
160 MB/s
Single Track 0.6 ms
Average 4.7 ms
Full-Stroke 12 ms
Rotational Speed 10,000 rpm
DA-10840 North America — Versi on 22 — March 18 , 2002 23
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
Ultra ATA Hard Drives
120 GB Capacity
250021-B21 Height
Width
Interface
80 GB Capacity
250020-B21 Height
Width
Interface
60 GB Capacity
230253-B21 Height
Width
Interface
Synchronous Transfer Rate
(Maximum)
Seek Time (typical reads,
including settling)
Logical Blocks 234,441,648
Operating Temperature 41° to 131°F (5° to 55°C)
Synchronous Transfer Rate
(Maximum)
Seek Time (typical reads,
including settling)
Logical Blocks 157,278,240
Operating Temperature 41° to 131°F (5° to 55°C)
Synchronous Transfer Rate
(Maximum)
Seek Time (typical reads,
including settling)
Logical Blocks 117,231,408
Operating Temperature 41° to 131°F/5° to 55°C
120,000 MB
1 in/25.4 mm
3.5 in/88.9 mm
Ultra ATA/100
100 MB/s
Single Track 1.2 ms (2.7 ms quiet seek)
Average 8.0 ms (14.3 ms quiet seek)
Full-Stroke 18.0 ms (24.1 ms quiet seek)
Rotational Speed 7200 rpm
80,000 MB
1 in/25.4 mm
3.5 in/88.9 mm
Ultra ATA/100
100 MB/s
Single Track 1.2 ms (2.7 ms quiet seek)
Average 8.0 ms (14.3 ms quiet seek)
Full-Stroke 18.0 ms (24.1 ms quiet seek)
Rotational Speed 7200 rpm
60,000 MB
1 in/25.4 mm
3.5 in/88.9 mm
Ultra ATA/100
100 MB/s
Single Track 1.2 ms (2.7 ms quiet seek)
Average 8.0 ms (14.3 ms quiet seek)
Full-Stroke 18.0 ms (24.1 ms quiet seek)
Rotational Speed 7200 rpm
DA-10840 North America — Versi on 22 — March 18 , 2002 24
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
Ultra ATA Hard Drives
(continued)
40 GB Capacity
201066-B21 Height
Width
Interface
20 GB Capacity
176272-B21
Synchronous Transfer Rate
(Maximum)
Seek Time (typical reads,
including settling)
Logical Blocks 78,165,360
Operating Temperature 41° to 131°F/5° to 55°C
Height
Width
Interface
Synchronous Transfer Rate
(Maximum)
Seek Time (typical reads,
including settling)
Logical Blocks 39,102,336
Operating Temperature 41° to 131°F/5° to 55°C
40,000 MB
1 in/25.4 mm
3.5 in/88.9 mm
Ultra ATA
100 MB/s
Single Track 1.2 ms (2.7 ms quiet seek)
Average 8 ms (10.1 ms quiet seek)
Full-Stroke 18.0 ms (21.1 ms quiet seek)
Rotational Speed 7200 rpm
20,000 MB
1 in/25.4 mm
3.5 in/88.9 mm
Ultra ATA
100 MB/s
Single Track 1.2 ms (2.7 ms quiet seek)
Average 8 ms (10.1 ms quiet seek)
Full-Stroke 18.0 ms (21.1 ms quiet seek)
Rotational Speed 7200 rpm
DA-10840 North America — Versi on 22 — March 18 , 2002 25
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
48X CD-ROM Drive Disk Applicable Disk
Capacity 540 MB (Mode 1, 12 cm)
650 MB (Mode 2, 12 cm)
Audio Output Level Line-Out 0.7 VRMS
Block Size Mode 1 2,048 bytes
Mode 2 2,340, 2,336 bytes
CD-DA 2,352 bytes
CD-XA 2,328 bytes
Interface IDE
Access Times (typical) Random < 100 ms
Full-Stroke < 150 ms
Data Transfer Rate Sustained
Variable
Cache Buffer 128 KB minimum
Start-up Time (typical) < 7 s
Stop Time < 4 s
Operating Conditions Temperature
Humidity
Dimensions
Weight
Rotational Speed
Diameter
Center Hole
Thickness
Track Pitch
(HxWxD, maximum)
CD-ROM (Mode 1 and 2), CD-R/W, CD-R
Photo CD (Single and Multi-session), Mixed Mode (Audio
and Data combined), CDI Ready, CD-XA Ready, CD TEXT,
CD EXTRA
8750 maximum
4.7 in, 3.15 in/12 cm, 8 cm
0.6 in/15 mm diameter
0.05 in/1.2 mm
1.6 µm
150 KB/s (1X, using audio disc)
3,000 to 7,200 KB/s
41° to 113°F/5° to 45°C
10% to 80%
1.7 x 5.9 x 8.19 in/4.29 x 15 x 20.8 cm
2.65 lbs/1.2 kg
DA-10840 North America — Versi on 22 — March 18 , 2002 26
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
16X/10X/40X CD-RW Drive Interface
Media formats written
Variable
Media capacity 650 MB
Write methods Disc-at-once, track-at-once, session-at-once, fixed packet, and variable packet
Recording/playing time 74 minutes
Data transfer rates Sustained CD-R write—2,400 Kbps (16X)
Data transfer modes ATA PIO mode 4—16.7 Mbps
ATA multi-word DMA mode 2—16.7 Mbps
ATA UltraDMA mode 0—16.7 Mbps (mandatory and default setting)
ATA UltraDMA mode 1—24 Mbps (optional); mode 2—33 Mbps (optional)
Media formats read
Access times Random < 20 ms typical
Full stroke < 200 ms typical
Rotational speed 17X-40X CAV
Start-up time Single < 7 seconds typical
Multi-session < 30 seconds typical
Stop time < 4 seconds
Block size Mode 1—2,048/2,352 bytes
Disc diameter 120 mm or 80 mm
Track pitch 1.6 µm
Disc loading mechanism Half-height, tray load
Operating conditi ons Temperature 5° to 45° C (41° to 113° F) operating
Humidity 10% to 80%
ATAPI IDE
CD-R and CD-RW
16X CLV
10X CLV
8X CLV
4X CLV
CD-RW write (1-4X media) —1,500 Kbps
(4X)
CD-RW write (4-10X media) —1,500 Kbps
(10X)
CD-RW read—1,500 Kbps (10X)
Digital audio extraction (minimum) —1,500
Kbps (10X)
CD-ROM, CD-R read—1,500 to 6,000
Kbps (10X to 40X)
CD-audio, CD-ROM (modes 1 and 2), CDROM XA (mode 2, forms 1 and 2), singleor multi-session photo CD, CD-I, video CD,
CD-text
8,350 RPM (constant)
3,424-7,952 RPM
2,140-4,970 RPM
1,712-3,976 RPM
856-1,988 RPM
Mode 2, Form 1—
2,048/2,328/2,336/2,340/2,352 bytes
Mode 2, Form 2—2,328/2,336/2,340/2,352
bytes
CD-DA—2,352/2,368 bytes
DA-10840 North America — Versi on 22 — March 18 , 2002 27
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
16X/10X/40X CD-RW Drive
(continued)
Mounting orientat ion Horizontal or vertical
Dimensions Fits in a standard 5.25-inch drive bay
Weight 1.2 kg (2.6 pounds)
Approvals/
environmental
Operating systems
supported
Kit contents
UL 94 and 1950, CSA, CE, FDA, FCC
Microsoft Windows 98, Microsoft Windows NT 4.0, Microsoft Windows 2000, Microsoft
WindowsXP Professional
16X CD-R media, CD-RW high-speed media, Roxio™ EasyCD Creator, Dantz
Retrospect Express Backup for CD-RW, IDE cable (opal kit), audio cable
DA-10840 North America — Versi on 22 — March 18 , 2002 28
QuickSpecs
Technical Specifications
4.7-GB DVD-RAM Drive Typ e Internal mounting
Total capacity DVD-RAM 4.7 GB (per-side capacity) and 2.6 GB (per-side capacity)
Data transfer rate DVD-RAM (read) 2,770 Kbps (4.7 GB)
DVD-RAM (write) 1,385 Kbps (4.7 GB) with ″write verify″ enabled
DVD-ROM and DVD-R 3,438 to 8,310 Kbps (maximum 6X)
CD-ROM 1,520 to 3,600 Kbps (maximum 24X)
Burst transfer rate 33.3 Mbps maximum (Ultra DMA 33)
Interface Enhanced IDE (ATAPI)
Bus speed Ultra DMA 33
Access time (random) DVD-RAM < 155 ms
DVD-ROM < 135 ms
CD-ROM < 135 ms
Buffer capacity 1 MB (minimum)
Dimensions Drive (HxWxD) 1.67 x 5.83 x 8.18 inches (4.23 x 14.81 x 20.75 cm)
Weight 2.65 pounds (1.20 kg)
DVD-ROM (read only) DVD-ROM (single- or dual-layer, single- or double-sided)
DVD-video (read only) DVD-video
DVD-R (read only) 3.9 GB (per side)
CD-ROM (read only) CD-ROM, CD-R, CD-RW, CD-ROM XA, CD-I, CD-audio
Mounting/operational
Kit contents DVD-RAM drive, single-sided 4.7-GB DVD-RAM media, InterVideo™ WinDVD 2000,
Operating system
Average seek time DVD-RAM 75 ms
DVD-ROM 65 ms
CD-ROM 65 ms
Compatible disc
formats
Operating and storage
conditions
Relative humidity
support
DVD-RAM (read/write) 4.7 GB (per-side capacity) and 2.6 GB (per-side capacity);
Ambient temperature
(operating)
(operating)
orientation
Software Architects WriteDVD!™ software, IDE cable, audio cable, installation guide,
user guide, warranty card
Microsoft Windows 98/98 SE, Microsoft Windows 2000, Microsoft Windows XP
Professional, and Microsoft Windows NT 4.0
Note: MPEG video playback is not supported on Microsoft Windows NT.
Compaq Evo W orkstation W6000
1,385 Kbps (2.6 GB)
695 Kbps (2.6 GB)
may be used with or without case
(CD-DA), photo CD multi-session, video CD
41° to 113° F/5° to 45° C
10% to 85% relative humidity
Operates in horizontal or vertical position
DA-10840 North America — Versi on 22 — March 18 , 2002 29
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
8X Combo CD-RW/DVD-ROM
5.25-inch, half-height, tray-load
Orientation Either horizontal or vertical
Interface type ATAPI
Dimensions—external,
excluding bezel
(W x H x D)
Disc diameter 5 inches, 3 inches (12 cm, 8 cm)
Disc thickness 0.05 inch (1.2 mm)
Track pitch 1.6 µm (CD), 0.74 µm (DVD)
Disc center hole
diameter
Reference scanning
velocity
Read only disc
parameters
Capacity
Block size
Writeable disc
parameters
Write methods Disc at Once, Track at Once, Session at Once, Variable
Format and modes supported CD-ROM (mode 1); CD-ROM XA (mode 2, forms 1 and 2);
Capacity 540 MB (mode 1, 12 cm); 650 MB (mode 2, 12 cm); 700
Block size Mode 1 Disc type—2,048 bytes; mode 2, form 1—2,048
5.8 x 1.7 x 7.7 inches (146.5 x 42.1 x 196 mm)
0.6 inch (15 mm)
1.2 m/s (CD); 3.5 m/s (DVD SL); 3.8 m/s (DVD DL)
Formats and modes supported CD-ROM—Mode 1; CD-ROM XA—Mode 2 (forms 1 and
2); CD digital audio; CD Extra; CD-I—Mode 2 (forms 1 and
2) and CD-I-Ready; Photo CD (single and multi-session);
video CD; DVD (single- and double-layer); DVD-R (3.95GB); DVD-R (4.7-GB)
540 MB (CD— mode 1, 12 cm); 650 MB (CD—mode 2, 12
cm); 700MB (CD-ROM—80 minutes); 180 MB (CDROM—8 cm); 4.7 GB (DVD-5); 8.5 GB (DVD-9); 9.4 GB
(DVD-10)
Mode 1—2,048 and 2,352 bytes; mode 2, form 1—2,048,
2,328, 2,336, 2,340 and 2,352 bytes; mode 2, form 2—
2,328, 2,336, 2,340 and 2,352 bytes; CD-DA—2,352 and
2,368 bytes; DVD—2,048 bytes
Disc type CD-R and CD-RW
Packet, Fixed Packet
CD digital audio, CD-I (mode 2, forms 1 and 2); video CD
MB (CD-ROM, 80 minutes); 180 MB (CD-ROM, 8 cm)
and 2,352 bytes; mode 2, form 2—2,352 bytes; CD-DA—
2,352 bytes
DA-10840 North America — Versi on 22 — March 18 , 2002 30
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
8X Combo CD-RW/DVD-ROM
(continued)
Access times (typical
reads, including settling)
Data transfer rates
Data transfer modes ATA PIO mode 4 (16.7 Mbps; ATA Multi-word DMA mode 2 (16.7 Mbps); ATA UltraDMA
Cache buffer
Startup time (single)
Startup time (multi-session)
Stop time < 4 seconds
Power Source Four-pin, DC power receptacle
DC power requirement
DC current
Total drive power (standby
Audio output level 0.7 Vrms (typical)
Configuration jumper
block
Data interface
connector
Environmental (all
conditions noncondensing
Relative humidity (operating) 10% to 85%
Maximum wet bulb
Certifications,
requirements
Operating systems
supported
Option kit contents 8X Combo CD-RW/DVD-ROM Drive, Roxio™ EasyCD Creator, InterVideo™ WinDvd™
Random < 130 ms (typical)
Full stroke < 240 ms (typical)
Sustained—1,200 KB/s (8X)
Sustained— 600 KB/s (4X)
Sustained—1,200 KB/s (8X
CAV)
Variable—1,500 to 4,800 KB/s
(10X to 32X)
Variable—2,705 to 10,820
KB/s (2X to 8X)
mode 0 (16.7-Mbps—default setting if UDMA supported); ATA UltraDMA mode 1 (24
Mbps, optional), mode 2 (33 Mpbs, optional)
mode)
Master, slave, and cable select modes
40-pin, shrouded and keyed, flat ribbon
Temperature (operating)
temperature (operating)
MPC-3 compliant, multi-read requirements, PC'99 certified, ACA AS/NZS 3548, ANSI
C63.4–1992, ATAPI Spec SFF-8020, ATA Spec X3T9.2791D, Australian Communications
Authority, CB Bulletin No. 92A1, CFR 21, Part 1040, CSA C22.2 No. 950, C.I.S.P.R. Pub
22, ECMA 74, EEC/93/68, EEC/73/23, EEC/99/5, EMKO-TSE (74SEC) 207/94
Microsoft Windows 98, Microsoft Windows NT 4.0, Microsoft Windows 2000,and Microsoft
WindowsXP Professional
Note: MPEG video playback is not supported on Microsoft Windows NT.
2000, Dantz Retrospect Express for RW, CDR media, CD-RW media, audio cable, and
installation guide
CD-R write
CD-RW
Digital audio extraction (minimum)
CD-ROM, CD-R read, CD-RW read
DVD read
2 MB (minimum)
< 7 seconds (typical)
< 30 seconds (typical)
5 VDC ± 5%—100 mV ripple p-p
12 VDC ± 5%—200 mV ripple p-p
5 VDC (< 1 A typical, < 1.5 A maximum)
12 VDC (< 1 A typical, < 1.5 A maximum)
< 2.5 watt
41° to 113°F (5° to 45°C)
86°F (30°C)
DA-10840 North America — Versi on 22 — March 18 , 2002 31
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
16X/40X DVD-ROM Drive with
RAM Read
Disk Rotation
Access Time (ms)
Full Stroke Seek DVD = <240 ms; CDROM = <160 ms
Cache Buffer Standard
ATAPI Interface
Disk Formats Read
DVD-Video Yes
DVD-R Yes
DVD-RW Yes
DVD-RAM Yes
Photo-CD/Multi-session Yes
CD-ROM Yes
CD TEXT Yes
Audio CD Yes
CD-I Yes
CD-RW Yes
CD-R Yes
CD-DA Yes
Video CD Yes
CD EXTRA Yes
CD-ROM XA Yes
MPEG Yes
MPC Level 2 Yes
Disk Formats Written
Disk
Block Size Mode 0 2352 (bytes)
Diameter 12 cm, 8 cm
Thickness 1.2 mm (CD-ROM)
Bus
Data Transfer Rate
(1 KB = 1024 bytes)
Technology
/ Max
Ultra DMA 33
Sustained DVD = 8.1 MB/s to 21.6 MB/s
CD-ROM = 2.55 KB/s to- 6.00 KB/s
Random DVD = <100 ms; CDROM = < 80 ms
512 KB
ATAPI
DVD-ROM Yes
None
Capacity CD = 650 MB
DVD: CAV -Constant Angular Velocity
CD: CAV - Constant Angular Velocity
DVD: 4.7 GB, 8.5 GB, 9.4 GB
Mode 1 2352, 2340, 2336, 2048 (bytes)
Mode 2 2352, 2340, 2336, 2048 (bytes)
DVD – 2048 (bytes)
1.2 mm (DVD)
DA-10840 North America — Versi on 22 — March 18 , 2002 32
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
16X/40 DVD-ROM Drive with
RAM Read (continued)
Operating Conditions
Humidity 5% to 85% relative humidity
Dimensions (HxWxD)
Centimeters 4.23 x 14.8 x 20.75
Weight
Kilograms 1
Agency Approvals /
OS Support Windows 98/98SE, Windows ME, Windows 2000, Microsoft Windows XP Professional,
MPEG Video playback
RPC2 (Regional
Minimum CPU
Mounting Orientation Operates in horizontal or vertical position.
Kit Contents DVD-ROM Drive, MPEG playback software, ReadDVD™ software, IDE
Audio Output Level
Headphones 0.45 ± 0.2 Vrms
Environmentals
compatibility
Protection Control)
Supported
Line Out 0.7± 0.1 Vrms
Temperature 41° to 113°F/5° to 45°C
Inches 1.67 x 5.83 x 8.18
Pounds 2.22
UL, CSA, TUV, FDA, FCC, CE, EMI
and Windows NT 4.0 (for data applications only)
Please refer to the platform for support
Yes
Pentium II 400 MHz or Celeron 466 MHz
Cable, audio cable, installation instructions, and warranty card.
DA-10840 North America — Versi on 22 — March 18 , 2002 33
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
Intel PRO/100 + Management
Adapter
Network Interface 10Base-T or 100Base-TX
Expansion Bus Architecture PCI 2.2
Network Transfer Rate
10Base-T (Half-Duplex) 10 Mb/s
10Base-T (Full-Duplex) 20 Mb/s
100Base-TX (Half-Duplex) 100 Mb/s
100Base-TX (Full-Duplex) 200 Mb/s
Connectors RJ-45
Standards Compliance
10-MB/s Ethernet IEEE 802.3
100-Mb/s Ethernet IEEE 802.3µ
I/O Address Auto-configured
Remote Wakeup
Yes
Operating Temperature
0° to 55°F/10° to 35°C
Operating Humidit y (non-condensing)
85% at 131°F/55°C
Operating Altitude
10,000 ft/3,048 m
Communication Processor
Intel 82559
OS Driver Support
Windows NT 4.0 NDIS 3.0, 4.0 Compliant
Windows 95, 98, 2000, XP Pro NDIS 3.0, 4.0, 5.0 Compliant
Novell NetWare Server v. 3.x, 4.x
and 5.0
SunSoft Solaris™ Not supported
SCO UnixWare, OpenDesktop,
OpenServer
ODI Compliant
Supported
DA-10840 North America — Versi on 22 — March 18 , 2002 34
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
NVIDIA Quadro2 Pro Graphics
Controller
VGA Controller Integrated into the Quadro2 Pro GPU
Bus type AGP 4X
RAMDAC 350 MHz
Memory type 400 MHz 4Mx16DDr-5ns
Memory amount 64 MB
Memory Speed 400 MHz (DDR)
Controller clock speed 250 MHz
Color planes 32-bit color buffer
Overlay planes
Stencil planes 8-bit stencil buffer
Alpha planes 8-bit alpha buffer
Z-buffer 24-bit
Total bits/pixel 64
Maximum vertical refresh rate 240 Hz
Maximum pixel clock 350 MHz
Multi-display support No
Resolution Maximum Colors
3D/2D Controller
Operating systems
640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 1024
1600 x 1000
1600 x 1000
1600 x 1200
1600 x 1200
1600 x 1280
1600 x 1280
1920 x 1080
1920 x 1080
1920 x 1200
1920 x 1200
Supported
16.7 M
16.7 M
16.7 M
16.7 M
16.7 M
64 K
16.7 M
64 K
16.7 M
64 K
16.7 M
64 K
16.7 M
64 K
16.7 M
Integrated Quadero2 Pro 2D/3D 128-bit graphics processor unit
(GPU)
1 16-bit Video overlay plane, software emulation for OpenGL overlay
planes
Microsoft Windows 2000, Microsoft Windows XP Professional,
Windows NT 4.0 available from Compaq
Maximum Refresh
Rate
240 Hz
240 Hz
240 Hz
200 Hz
150 Hz
120 Hz
120 Hz
100 Hz
100 Hz
100 Hz
100 Hz
85 Hz
85 Hz
85 Hz
85 Hz
Memory Dedicated to
Texture Support
60.4 MB
58.4 MB
54.8 MB
52.3 MB
48.6 MB
54.6 MB
45.3 MB
52.8 MB
41.5 MB
52 MB
40 MB
51.9 MB
39.7 MB
50.5 MB
37 MB
DA-10840 North America — Versi on 22 — March 18 , 2002 35
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
Matrox Millennium G550 AGP
Graphics Controller
Bus type AGP 4X, AGP 2X, and AGP 1X
Standard memory 32-MB, high-speed DDR
DAC speed 360-MHz RAMDAC; secondary 230-MHz RAMDAC
Data path 64-bit DDR external bus to frame buffer memory/256-bit internal
Internal bus width 256-bit DualBus
Memory interface 64-bit DDR Memory
Frame buffer 32 MB
Operating systems supported Microsoft Windows 2000, Microsoft Windows 98, Microsoft
Two integrated RAMDACs Yes
DualHead 3-D display features
Other 3-D features
Other
Form factor Low profile (LP) board with ATX bracket attached (kit also includes
3-D engine acceleration Matrox HeadCasting* engine, two dual-textured 3-D pixels/clock for
3-D features
Optional software bundles (not included)
Single cycle multi-texturing Yes
nvironment-mapped bump
mapping
Internal rendering 32-bit
Source textures Up to 32-bit
Maximum texture size 2048 x 2048
32-bit color output Yes
32-bit independent Z-buffer Yes
Stencil buffering Yes
AGP texturing Yes
Trilinear filtering Yes
Microsoft DirectX support Yes
OpenGL support Yes, through Matrox
a Small Form Factor (SFF) bracket
Windows NT 4.0, Microsoft Windows XP Professional
fast 3-D game play, dual pixel pipelines with dual texturing units
per pipeline, floating point 3-D setup engine with dynamically reallocatable resources; Microsoft DirectX Environment-Mapped
Bump Mapping; Vibrant Color Quality rendering; bilinear, 8sample-per-pixel trilinear, and anisotropic filtering; Microsoft
DirectX and OpenGL® alpha blending modes; Z-buffer support
Yes
HeadCasting, Microsoft DirectX compliant, dual texturing units per
pixel pipeline, two pixel pipelines, single-cycle multi-texturing,
environment-mapped bump mapping, 32-bit internal rendering
precision, up to 32-bit source textures, 32-bit color output, bilinear,
trilinear and anisotropic 3-D filtering, 32-bit independent Z-buffer,
OpenGL support
Alpha blending, fogging, specular highlighting, environment
mapping, stencil buffering, triple buffering, AGP texturing
Texture mapping support; true color RGB, flat, and Gouraud
shading; Direct3-D support; anisotropic filter; perspective-correct
texture mapping; specular highlighting (any color); hardware
dithering (including dithering of LUT textures); sort-dependent
antialiasing; vertex and table fogging; dual texture mapping; Plugand-Play; 0.18-micron technology (lower heat/power consumption);
high-quality DVD playback with DVDMax; color space conversion;
QuickDraw supported DCI and Microsoft DirectX and OpenGL
blend modes; Microsoft DirectDraw support; support for picture-inpicture and multiple video windows; Unique Motion Video
Rendering support
Matrox Virtual Presenter for Microsoft PowerPoint; Digimask™
System, HeadFone™ by LipSinc; The Matrox Software DVD
Player; eDualHead browser enhancements (PageWrap, PageLog,
and PageJump); Matrox PowerDesk
DA-10840 North America — Versi on 22 — March 18 , 2002 36
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
Matrox Millennium G550 AGP
Graphics Controller (continued)
DualHead 2-D display features
Note: System recommendations for HeadCasting and DVD—450-MHz or higher computer; 128 MB RAM; 56-K or
Resolutions Supported Maximum Colors Supported Refresh Rates
640 x 480 16 million 200 Hz vertical, 130 kHz horizontal
800 x 600 16 million 200 Hz vertical, 130 kHz horizontal
1024 x 768 16 million 160 Hz vertical, 130 kHz horizontal
1152 x 864 16 million 150 Hz vertical, 130 kHz horizontal
1280 x 1024 16 million 120 Hz vertical, 130 kHz horizontal
1600 x 1200 16 million 100 Hz vertical, 130 kHz horizontal
1800 x 1440 16 million 90 Hz vertical, 120kHz horizontal
1920 x 1440 16 million 85 Hz vertical, 115 kHz horizontal
2048 x 1536 16 million 85 Hz vertical, 110 kHz horizontal
Secondary Resolutions
640 x 480 16 million 200 Hz vertical, 130 kHz horizontal
800 x 600 16 million 200 Hz vertical, 130 kHz horizontal
1024 x 768 16 million 160 Hz vertical, 130 kHz horizontal
1152 x 864 16 million 140 Hz vertical, 130 kHz horizontal
1280 x 1024 16 million 120 Hz vertical, 130 kHz horizontal
1600 x 1200 16 million 100 Hz vertical, 130 kHz horizontal
DualHead configurations
DualHead display technology chip
specifications
higher modem with minimum 40-K connection, microphone, and DVD-ROM; Internet Explorer 5.5 or higher,
Microsoft PowerPoint 2000 or Microsoft PowerPoint XP (for Matrox Virtual Presenter)
Supported
VGA monitor/analog flat panel + VGA monitor/analog flat panel
VGA monitor/analog flat panel + television
Digital flat panel + VGA monitor/analog flat panel
Digital flat panel + television
DualHead Multi-Display support; DualHead Browser Enhancement
Suite, DualHead DVDMax, DualHead Zoom, DualHead Clone,
DVDMax, DualHead MultiDesk, DualHead TV-out, DualHead
Snapshot, Dual DVI support, ; True Multi-Display support with
Microsoft Windows 2000
Multiple independent displays with a single AGP card: analog flat
panel (RGB monitor)/analog flat panel (RGB monitor); digital flat
panel/digital flat panel
Maximum Color Depths (bpp) Refresh Rates
DA-10840 North America — Versi on 22 — March 18 , 2002 37
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
Matrox Millennium G450
Graphics Controllers
Form Factor
Bus Type
Standard Memory
DAC Speed
Data Path
Internal Bus Width
Memory Interface
Frame Buffer
Two Integrated RAMDACS
Engine Acceleration
Output
OS Support
Other
3D Features
DualHead Display Features Multi-Display Mode, DVD Max Mode, DualHead Zoom Mode, DualHead Clone
ATX
AGP 1X, 2X, 4X: PCI rev 2.2 bus specification
AGP: 32 MB / PCI: 16 MB
360 MHz (secondary DAC: 200 MHz)
64-bit DDR External/256-bit Internal
256-bit DualBus
64-bit DDR Memory
AGP: 32 MB / PCI: 16 MB
Yes
3 ROP bitBLT, line draw, text, color expansion, basic video color conversion and
scaling, triangle setup engine
Analog, 2 ports
Microsoft Windows 2000, Microsoft Windows XP Professional, Windows 98 and
Windows NT 4.0 available from Compaq.
PCI bus mastering, texture mapping support, flat and Gouraud shading, direct 3D
support, Anisotropic Filter, perspective texture, specular highlighting, wireframe,
dithering, full scene anti-aliasing, vertex fog, dual texture mapping, Plug-and-Play
AGP 2X and AGP 4X, 0.18-micron technology (lower heat/power consumption),
high-quality DVD playback with full access to Windows, Color Space Conversion,
Quick Draw support, DCI and DirectX video playback, MS DirectDraw support
Single-cycle multi-texturing Yes
Environment-Mapped Bump Mapping Yes
Internal Rendering 32-bit
Source Textures Up to 32-bit
Maximum Texture Size 2048 x 2048
Hardware non-power-of- 2 textures Yes
32-bit Color Output Yes
32-bit Independent Z-buffer Yes
Stencil Buffering Yes
AGP Texturing Yes
Trilinear Filtering Yes
DirectX Support Yes
OpenGL Support Yes
Mode, DualHead TV Output Mode, Single Chip Multi-Monitor Support
DA-10840 North America — Versi on 22 — March 18 , 2002 38
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
Matrox Millennium G450
Graphics Controllers
(continued)
640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 960
1280 x 1024
1600 x 1200
1800 x 1440
1856 x 1392
1920 x 1440
2048 X 768
Secondary CRT Color Depths
640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 960
1280 x 1024
1600 x 1200
Supported Modes
This list assumes setup to be DualHead multi-display running Microsoft Windows 98. If using Windows NT 4.0 or
Windows 2000 while in multi-display, primary CRT is limited to modes supported by 2
Primary CRT Color Depths
nd
CRT.
Color Depths (bpp) Refresh Rates
8, 16, 24, 32 60 Hz, 72 Hz, 75 Hz, 85 Hz
8, 16, 24, 32 60 Hz, 72 Hz, 75 Hz, 85 Hz
8, 16, 24, 32 60 Hz, 70 Hz, 75 Hz, 85 Hz
8, 16, 24, 32 75 Hz
8, 16, 24, 32 60 Hz, 75 Hz, 85 Hz
8, 16, 24, 32 60 Hz, 75 Hz, 85 Hz
8, 16, 24, 32 60 Hz, 65 Hz, 70 Hz, 75 Hz,
85 Hz
(available in single monitor
configuration only)
8, 16, 24 60 Hz, 72 Hz, 75 Hz, 85 Hz
8, 16, 24 60 Hz, 75 Hz, 85 Hz
8, 16, 24 60 Hz, 75 Hz, 85 Hz
8, 16 60 Hz, 75 Hz
Color Depths (bpp) Refresh Rates
16, 32 60 Hz, 72 Hz, 75 Hz, 85 Hz
16, 32 60 Hz, 72 Hz, 75 Hz, 85 Hz
16, 32 60 Hz, 70 Hz, 75 Hz, 85 Hz
16, 32 75 Hz
16, 32 60 Hz, 75 Hz, 85 Hz
16, 32 60 Hz, 75 Hz, 85 Hz
16, 32 60 Hz, 65 Hz, 70 Hz, 75 Hz,
85 Hz
DA-10840 North America — Versi on 22 — March 18 , 2002 39
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
Matrox G200 Quad
Multi-Monitor Series (MMS)
Graphics Controller
Dimensions (HxW) 4.5x8 in/11.43x20.32 cm
Refresh Rate (per display)
Aspect Ratio Resolution Vertical Ho riz on tal
4:3/5:4 640 x 480 60 to 200 Hz 31 to 102 kHz
800 x 600 60 to 200 Hz 38 to 114 kHz
1024 x 768 60 to 140 Hz 48 to 113 kHz
1152 x 864 60 to 120 Hz 54 to 110 kHz
1280 x 1024 60 to 100 Hz 64 to 107 kHz
1600 x 1200 60 to 90 Hz 75 to 113 kHz
1800 x 1440 60 to 70 Hz 89 to 104 kHz
16:9/16:10 856 x 480 60 to 200 Hz 30 to 108 kHz
1280 x 720 60 to 100 Hz 44 to 76 kHz
1600 x 1024 60 to 100 Hz 64 to 108 kHz
1920 x 1080 60 to 80 Hz 70 to 94 kHz
1920 x 1200 60 to 76 Hz 75 to 95 kHz
With DVI digital flat panel displays, the maximum display resolution is 1280 x 1024.
Maximum refresh rates may not be attainable at the highest display resolutions with 24 or 32-bit color palettes.
Interface
Standard Memory
DAC Speed
Data Path
Color Space Conversion
Scaling
Quick Draw Support
DCI & DirectX Video Playback
Direct3D Support
Engine Acceleration
Output
Other
OS Support
PCI
32-MB SGRAM (8 MB per port)
250 MHz
128-bit Internal/64-bit External
Yes
Yes
Yes
Yes
Yes
3 ROP bitBLT, Line Draw, Text, Color Expansion,
Basic Video Color Conversion and Scaling,
Triangle Setup Engine
Two output ports, which require 2 adapter cables to connect analog or digital
output displays
Analog Display Support
DVI (Digital Visual Interface) Display
Support
Display options supported
PCI bus-mastering, texture mapping support, flat and Gouraud shading,
Anisotropic Filter, perspective texture, specular highlighting, dithering, full
scene anti-aliasing, Vertex fog
Windows 2000 (not available for Chinese, Taiwanese, or Korean languages) ,
MicrosoftWindows XP Professional, and Windows NT 4.0
2 RGB cables support two DB-15
analog displays per cable
DVI cable option kit provides two DVI
cables for connecting two DVI
compliant displays per cable
Four analog displays via two RGB
cables
Four DVI displays via two DVI cables
Two analog displays via one RGB
cable and two DVI displays via one
DVI cable
DA-10840 North America — Versi on 22 — March 18 , 2002 40
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
NVIDIA Quadro2 MXR Graphics
Controller
Dimensions (LxHxW)
Resolution Maximum Colors
640 x 480 16.7 M 240 Hz 28.4 MB
800 x 600 16.7 M 240 Hz 26.4 MB
1024 x 768 16.7 M 200 Hz 22.8 MB
1152 x 864 16.7 M 170 Hz 20.3 MB
1280 x 1024 16.7 M 150 Hz 16.6 MB
1600 x 1000 64 K 120 Hz 22.6 MB
1600 x 1000 16.7 M 120 Hz 13.3 MB
1600 x 1200 64 K 100 Hz 20.8 MB
1600 x 1200 16.7 M 100 Hz 9.5 MB
1600 x 1280 64 K 100 Hz 20 MB
1600 x 1280 16.7 M 100 Hz 8 MB
1920 x 1080 64 K 85 Hz 19.9 MB
1920 x 1080 16.7 M 85 Hz 7.7 MB
1920 x 1200 64 K 85 Hz 18.5 MB
1920 x 1200 16.7 M 85 Hz 5 MB
3D/2D Controller
VGA Controller Integrated into the Quadro2 MXR GPU
Bus Type
RAMDAC
Memory Type
Memory Amount
Memory Speed
Controller Clock Speed
Color Planes
Overlay Planes
Stencil Planes
Alpha Planes
Z-buffer
Total bits/pixel
Maximum Vertical Refresh Rate
Maximum Pixel Clock
Multi-display support
Operating Systems
Approximately 6.5 x 3.8 x 0.6 in/16.51 x 9.65 x 1.52 cm
Maximum Refresh Rate Memory Dedicated to
Supported
Integrated Quadro2 MXR 2D/3D 128-bit graphics processor unit (GPU)
AGP 2X, 4X Graphics Bus
350 MHz
183 MHz SDR 2Mx32
32 MB
183 MHz
200 MHz
32-bit color buffer
1 16-bit Video overlay plane, software emulation for OpenGL overlay planes
8-bit stencil buffer
8-bit alpha buffer
24-bit Z buffer
64-bits
240 Hz
350 MHz
Yes
Microsoft Windows 2000, Microsoft Windows XP Professional, Windows NT
4.0 available from Compaq
Texture Support
DA-10840 North America — Versi on 22 — March 18 , 2002 41
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
NVIDIA Quadro2 EX Graphics
Controller
640 x 480 16.7 M 120 Hz 28.4 MB
800 x 600 16.7 M 120 Hz 26.4 MB
1024 x 768 16.7 M 120 Hz 22.8 MB
1152 x 864 16.7 M 120 Hz 20.3 MB
1280 x 1024 16.7 M 100 Hz 16.6 MB
1600 x 1000 16.7 M 85 Hz 13.3 MB
1600 x 1200 64 K 100 Hz 20.8 MB
1600 x 1200 16.7 M 85 Hz 9.5 MB
1920 x 1080 64 K 85 Hz 19.9 MB
1920 x 1080 16.7 M 75 Hz 7.7 MB
1920 x 1200 64 K 85 Hz 18.5 MB
1920 x 1200 16.7 M 70 Hz 5 MB
Dimensions (LxHxW) Approximately 6.5 x 2.5 x 0.6 in/16.5 x 6.4 x 1.5 cm
3D/2D Controller Integrated Quadro2 EX 2D/3D 128-bit graphics processor unit (GPU)
VGA Controller Integrated into the Quadro2 EX GPU
Bus Type AGP 2X, 4X
RAMDAC 350 MHz
Memory Type 183 MHz SDR 2Mx32
Memory Amount 32 MB
Memory Speed 166 MHz
Controller Clock Speed 175 MHz
Color Planes 32-bit color buffer
Overlay Planes
Stencil Planes 8-bit stencil buffer
Alpha Planes 8-bit alpha buffer
Z-buffer 24-bit Z buffer
Total bits/pixel 64-bits
Maximum Vertical Refresh Rate 240 Hz
Maximum Pixel Clock 350 MHz
Multi-display support No
Operating Systems
Resolution Maximum Colors
Supported
One 16-bit Video overlay plane, software emulation for OpenGL overlay
planes
Microsoft Windows 2000, Microsoft Windows XP Professional, Windows NT
4.0 available from Compaq
Note: All drivers and enhanced software can be found on the Compaq web site
at:www.compaq.com/support/files/workstations/us/index.html.
Maximum Refresh Rate Memory Dedicated to
Texture Support
DA-10840 North America — Versi on 22 — March 18 , 2002 42
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
3Dlabs Wildcat II 5110
Dimensions (LxHxW)
Aspect Ratio 96 bits per pixel 128 bits per pixel 160 bits per pixel 192 bits per pixel
4 x 3 1920 x 1440 @75 Hz 1920 x 1440 @75 Hz 1920 x 1440 @75 Hz 1920 x 1440 @75 Hz
5 x 4 1600 x 1280 @76 Hz 1600 x 1280 @76 Hz 1600 x 1280 @76 Hz 1600 x 1280 @76 Hz
16 x 9 2048 x 1152 @75 Hz 2048 x 1152 @75 Hz 2048 x 1152 @75 Hz 2048 x 1152 @75 Hz
16 x 10 1920 x 1200 @75 Hz 1920 x 1200 @75 Hz 1920 x 1200 @75 Hz 1920 x 1200 @75 Hz
5 x 4 Frame
Sequential Stereo
4 x 3 Frame
Sequential Stereo
3D/2D Controller
VGA Controller
Bus Type
RAMDAC
Memory Type
Memory Amount
Memory Speed
Controller Clock Speed
Color Planes
Overlay Planes
Stencil Planes
Alpha Planes
Z-buffer
Total bits/pixel
Maximum Vertical Refresh Rate
Maximum Pixel Clock
Multi-display support
Operating Systems
1280 x 1024 @60 Hz 1280 x 1024 @60 Hz 1280 x 1024 @60 Hz 1280 x 1024 @60 Hz
1280 x 960 @60Hz 1280 x 960 @60Hz 1280 x 960 @60Hz 1280 x 960 @60Hz
Approximately 13.5 x 3.8 x 1.5 in/ 34.29 x 9.65 x 3.81 cm
3Dlabs Wildcat II 2D/3D graphics controller technology
Standard VGA onboard
AGP 4X / AGP Pro Graphics Bus
300 MHz
SDRAM
64 MB
166 MHz
204 MHz
32-bit color buffer
8-bit double buffer
8-bit stencil buffer
8-bit alpha double buffer
24, 32-bit Z buffer
96, 128, 160, 192
90 Hz
300MHz (analog); 162 Mhz (digital)
Yes
Microsoft Windows 2000, Microsoft Windows XP Professional, and Windows
NT 4.0 available from Compaq
DA-10840 North America — Versi on 22 — March 18 , 2002 43
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
ATI Fire GL2 Graphics
Controller
640 x 48 0 16.7 M 240 Hz 28.4 MB
800 x 60 0 16.7 M 240 Hz 26.4 MB
1024 x 768 16.7 M 200 Hz 22.8 MB
1152 x 864 16.7 M 170 Hz 20.3 MB
1280 x 1024 16.7 M 150 Hz 16.6 MB
1600 x 1000 64 K 120 Hz 22.6 MB
1600 x 1000 16.7 M 120 Hz 13.3 MB
1600 x 1200 64 K 100 Hz 20.8 MB
1600 x 12 00 16.7 M 100 Hz 9.5 MB
1600 x 1280 64 K 100 Hz 20 MB
1600 x 12 80 16.7 M 100 Hz 8 MB
1920 x 1080 64 K 85 Hz 19.9 MB
1920 x 10 80 16.7 M 85 Hz 7.7 MB
1920 x 1200 64 K 85 Hz 18.5 MB
1920 x 12 00 16.7 M 85 Hz 5 MB
Form Factor ATX
3D/2D Co ntroller IBM RC1000 Rasterize r Chip
VGA Controller IBM RC1000 Rasterizer Chip
Bus Type AGP 2X/4X Version 2 compliant including side band signaling support
RAMDAC 300 MHz IBM RC1000
Memory Type DDR SGRAM
Memory Amount 64 MB DDR SGRAM unified frame buffer, Z-buffer and Texture storage
Memory Speed 120 M Hz
Controller Clock Speed 120 MHz
Color Planes 32 bit, True Color
Overlay Planes 8-bit
Stencil Planes 8-bit
Alpha Planes 8-bit
Z-buffer 24-bit
Video Engine support YU V ( 4: 2: 2 , 4: 2: 0 ) co nversion, poi n t an d bil inear scalin g
Mini-Din Stereo Interface support StereoGrap hic s Cr y st al E y es s hu tt e r gl a ss es
Monitor 15-pin D-type analog
Flat Panel Interface DVI-D digit al (supported resolutions up to 1280x1024 )
Video Timings compliance VESA DMT 1.0 and VESA GTF 1.0 specifications
Total bits/pixel 117
Maximum Vertical Refresh Rate 100 Hz / 120 Hz when Quad Buf fe r St er e o is en a bl e d
Maximum Pixel Clock 300 MHz
Operating Systems
Dimensions (HxW) Approximately 6.5 x 3.8 x 0.6 in/16.51 x 9.6 5 x 1.52 cm
Resolution
Note: All drivers can be found on the Compaq web site at:
www.compaq.com/support/files/workstations/us/index.html.
Maximum Colors
Supported
Microsoft Windows 2000, Microsoft Windows XP Professional, and Windows
NT 4.0
Maximum Refresh
Rate
Memory Dedicated to
Texture Support
DA-10840 North America — Versi on 22 — March 18 , 2002 44
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
ATI Fire GL4 3-D Graphics
Accelerator
3-D/2-D controller
VGA connector
Bus type
RAMDAC
Memory
Geometry engine core clock speed
Colour planes
Overlay planes
Stencil planes
Alpha planes
Display data channel (DDC)
Power Draw
Z-buffer
Total bits per pixel
Maximum vertical refresh rate
Maximum pixel clock
Multi-display support
Operating systems support
Software support
Bus interface
Form factor
Regulatory certifications
Documentation
CRT Resolutions Maximum Refresh Rate Bits per Pixel
1920 x 1200 60, 76, 75Hz 32
1600 x 1200 60, 75 and 85Hz 32
1280 x 1024 60, 75 85 and 100Hz 32
1280 x 960 60, 75, 85 and 100Hz 32
1600 x 1000 60, 76, and 85Hz 32
1024 x 768 60, 75, 85, 100, and 120 Hz (stereo) 32
800 x 600 60, 75, 85, 100, and 120 Hz (stereo) 32
640 x 480 60, 75, 85, 100, and 120 Hz (stereo) 32
Dimensions 10.2 x 4.3 inches (26.0 x 10.8 cm)
ATI Fire GL4 3-D and 2-D Graphics Accelerator
Standard VGA on board
AGP Pro50 1x/2x/4x
300-MHz, 30-bit
Type—DDR SDRAM
Amount—128 MB
Speed—145 MHz
Bus width—256 bits
190 MHz
Four
8-bit DB (double buffer)
8-bit clip/stencil planes
8-bit stored alpha planes DB
DDC2B support
8.5A@ 3.3V; 1.8A @ 5V; .5A @ 12V
24-bit z buffer
32
100 Hz (120 Hz stereo)
300 MHz single head, 135 MHz dual head
Yes, two VGA or two DVI
Microsoft Windows 2000, Microsoft Windows NT 4.0, Windows XP
Professional
2-D—GDI / GDI+ (GDI 2K)
3-D—OpenGL 1.1 / 1.2
Note: OpenGL extensions support the requirements of OpenGL
applications
AGP 1X/2X/4X; universal connector/slot—use one AGP Pro, one PCI
physical space, no connector
AGP Pro50 ATX half-length
UL 1950 (U.S.), CUL 1950, CSA C22.2 No. 950 (1995), IEC 950, CISPR
nd
22, 2
Edition 1993, FCC Class B, CE, CSA C108.8 Class B, SMA
AS/NZS 3548 (Australia) C-Tick
User guide (CD and online)
Connectors 2 DVI-I; one standard three-pin stereo connector
DA-10840 North America — Versi on 22 — March 18 , 2002 45
QuickSpecs
Technical Specifications
Compaq Evo W orkstation W6000
ATI Fire GL4 3-D Graphics
Accelerator (continued)
1600 x 1200 60 Hz 32
1280 x 1024 60, 75 and 85Hz 32
1280 x 960 60, 75 and 85Hz 32
1600 x 1000 60 Hz 32
1024 x 768 60, 75, 85 and 100 Hz 32
800 x 600 60, 75, 85 and 100Hz 32
640 x 480 60, 75, 85 and 100Hz 32
Note: The above table shows the highest resolutions supported for the Fire GL 4 when it is configured in single
Digital Resolutions Maximum Refresh Rate Bits per Pixel
display mode. Resolutions higher than 1600 x 1200 are supported only for analog CRT monitors. Digital
output not recommended for stereo support.
Compaq PCs use genuine Microsoft Windows
www.microsoft.com/piracy/howtotell
©2002 Compaq Information Technologies Group, LP.
Compaq, the Compaq logo the Compaq logo, Evo, and StorageWorks are trademarks of Compaq Information
Technologies Group, L.P. in the U.S. and/or other countries. Microsoft, Windows 2000, Windows NT, and Windows
XP are trademarks of Microsoft Corporation in the U.S. and/or other countries. Intel, and Xeon are trademarks of
Intel Corporation in the U.S. and/or other countries. All other product names mentioned herein may be trademarks
of their respective companies.
aq shall not be liable for techni cal or editorial er rors or omissions c ontained herein. The info rmation is provi ded “as
is” without warranty of any kind and is subject to change without notice. The warranties for Compaq products are set
forth in the express limited wa rranty statements accompa nying such prod ucts. Nothing herei n should be const rued
as constituting an additional warranty.
DA-10840 North America — Versi on 22 — March 18 , 2002 46
Loading...
