QuickSpecs
Compaq SDLT 110/220GB Tape Drive
MODELS
Compaq SDLT 110/220GB Tape Drive
SDLT 110/220-GB, Internal
192106-B21, Worldwide (Opal)
SDLT 110/220-GB, External
192103-001, North America (Opal)
192103-B31, International (Opal)
192103-291, Japan (Opal)
SDLT 110/220-GB, 3U Rackmount
274331-B21, Worldwide (Carbon)
Single drive installed in 3U Rackmount Kit
SDLT 110/220-GB, Dual-Drive, 3U Rackmount
274334-B21, Worldwide (Carbon)
Two drives installed in 3U Rackmount Kit
SDLT 110/220-GB Tape Array III, 5U Rackmount
274336-B21, Worldwide (Carbon)
Four drives installed in 5U Rackmount Kit
Rackmount Kits:
3U Rackmount Kit
274338-B21, Worldwide
Accommodates up to 2 internal
5U Rackmount Kit
274339-B21, Worldwide
Accommodates up to 4 internal SDLT drives
Feature List
• SCSI LVD standard Interface
• Maximum native storage capacity of 110GB, up to 220GB with compression
• Maximum native data transfer rate of 39.6GB/hour, up to 79.2GB/hour with compression
• Backward-read compatibility with DLT Type IV tape cartridges
• Available in internal, external, and rackmount configurations
• Supported in multiple rackmount kit options including the 3U Rackmount Kit and 5U Rackmount Kit
• Tape Storage Software provided through StorageWorks™ Data Protection Software Suite by Compaq
SDLT drives
OVERVIEW
Compaq’s SDLT 110/220 is the first product in the SDLT family, offering increased capacity and performance over previous DLT tape drives and
backward read compatibility with DLT Type IV media
Compaq SDLT 110/220-GB Tape Drive Customer benefits include:
• Industry leading native storage capacity with 110-GB capacity per data cartridge
• Native data transfer rate of 39.6GB/hr offers highest performance in DLT/SDLT product class
• Investment protection through backward-read compatibility with previously written DLT Type IV media
• Increased reliability and performance through technological advances in drive head and media design
• Reduces dependence on spares inventory with a 24 hour exchange
• SDLT technology roadmap offers future capacities beyond 1 TB per cartridge
DA-10772 World Wide — Version 10 — J une 24, 2002 1
QuickSpecs
Compaq SDLT 110/220GB Tape Drive
KEY FEATURES
• 110-GB native capacity, minimum 10% higher capacity advantage over competitive tape drives
• 11MB/s, 83% faster than Compaq’s 40/80-GB DLT drive
• Utilizes new SDLT media with Advanced Metal Powder (AMP) Technology
• Backward-read compatible with DLT Type IV media
• Internal and external models, with multiple options for rackmount configurations
• Rackmount-ready models for quick installation into ProLiant™ and AlphaServer™ racks
• Standard industry interface, SCSI LVD
• DRTape-ready and supported by StorageWorks Data Protection Software Suite
• Supported with VERITAS Backup Exec, Computer Associates ARCserve, and Dantz Retrospect Backup
• Qualified behind Windows NT
4.0, Windows 2000, Netware, Tru64™ Unix, OpenVMS™, Linux, and SCO/Caldera Unix
PRODUCT HIGHLIGHTS
Super DLT Technology
Super DLTtape is an extension of the DLT platform, the industry’s de-facto standard for tape backup and data protection. It is designed to meet the
business critical demands of enterprise storage customers. The new SDLT platform extends the advantages of DLT technology by increasing capacity,
performance, and reliability standards through technological advances in drive head and media design. With backward-read compatibility for DLT Type IV
media, the new SDLT tape drive provides customers with an easy migration path to advanced technology for their data protection strategies.
Qualified with StorageWorks Data Protection Software Suite
Complete set of Compaq Data Protection Tools focused on simplifying the process of configuring, implementing, and maintaining a data protection
strategy. Includes software applications such as Tape Storage Management Console and Compaq Insight Manager™, as well as product information
tools including technology White Papers, Service Advisories, and the Compaq Storage Products CD. An annual subscription service is also included
providing up to three updates per year for Data Protection Tools that have been refreshed. For information on ordering the Data Protection Software
Suite, please check the “Related Options” section of this QuickSpec or visit the Compaq.com website.
DRTape-Ready (Disaster Recovery Utility)
Compaq’s DRTape Disaster Recovery Utility is a new data recovery tool which replaces the traditional recovery methods associated with manual
downloads from floppy or CD-ROM. DRTape is a firmware driven software utility that pr ovides a disaster recovery solution for Compaq ProLiant servers.
Embedded in the firmware of each supported tape device, DRTape uses Compaq tape drives to emulate bootable drive devices, similar to floppy and CDROM drives. When implemented, DRTape can provide for the complete recovery of server software and data. The recovery process requires the use of
only one tape cartridge, in conjunction with the Compaq SmartStart CD, and can typically be completed in less than an hour.
**Note: DRTape does not support Compaq Smart Array Controllers. Please see "Compaq DRTape Compatibility Matrix" at:
http://www.compaq.com/products/storageworks/drtape/compatibility.html
DRTape.
Rackmount Tape Options
Supported in StorageWorks 3U and 5U Rackmount Kits, allowing customer to install up to 2 internal DLT or SDLT drives in a 3U rackmount space or up to
4 internal DLT or SDLT drives in a 5U rackmount space, respectively. Standard configuration for 3U Rackmount Kit provides two internal SCSI buses
(channels) supporting one DLT or SDLT drive per bus. Standard configuration for 5U Rackmount Kit provides two internal SCSI buses (channels)
supporting up to 2 DLT or SDLT drives per bus. Optional cable kit permits user to extend from two to four internal SCSI buses in 5U Rackmount Kit,
increasing the performance (data transfer rate) by allowing the customer to stream data to all four drives simultaneously. Please refer to “Rackmount
Tape Drive Kits” QuickSpec for further information.
for further information regarding the minimum requirements for operating
DA-10772 World Wide — Version 10 — J une 24, 2002 2
QuickSpecs
Compaq SDLT 110/220GB Tape Drive
PRODUCT HIGHLIGHTS (continued)
Compatibility and Integration Testing
Compaq’s SDLT 110/220-GB tape drives are fully supported and compatible with Compaq Servers, StorageWorks DLT Tape Enclosures & Array, and
controllers. Compaq thoroughly tests products with leading software and operating systems, including VERITAS Backup Exec and CA ARCserve.
Software Supporte d
VERITAS Backup Exec v8.5 for Windows NT/2000
VERITAS Backup Exec v8.5 for NetWare
VERITAS Backup Exec Disaster Recovery Option
Computer Associates ARCserve 2000 for Windows NT/2000
Computer Associates ARCserveIT v6.6 for NetWare
Computer Associates ARCserve Disaster Recovery Option
Dantz Retrospect Backup v5.6 for Windows NT/2000 (Server & Workgroup version)
CarePaq™ Service & Support
Additional Warranty protection and/or Compaq Installation packages can be purchased.
Software Product Services
• Standalone telephone support
• Rights to a new license
• Media and documentation updates
Hardware Product Services
• Installation services
• On-site Maintenance (includes warranty support)
• Response time upgrades during the warranty period
• Post-warranty coverage
• RAID setup and performance consulting via statement of work
For additional hardware installation and maintenance information please refer to the URL’s listed below:
http://www.compaq.com/services/carepaq/us/install/cp_storage.html
http://www.compaq.com/services/carepaq/us/hardware/cp_storage.html
Warranty Upgrade Options
• Response - Upgrade on-site response from next business day to same day 4-hours
• Coverage - Extend hours of coverage from 9 hours x 5 days to 24 hours x 7 days
• Duration - Select duration of coverage for a period of 1, 3, or 5 years
CarePaq Information
• CarePaq is defined as an upgrade to the product warranty attribute, available for a specific duration and hours of coverage.
• CarePaq is not available for less than the products warranty duration.
• CarePaq is available for sale anytime during the warranty period for most products, but the commencement date will be the same as the Warranty
Start Date (delivery date to end user customer). Proof of purchase may be required.
• CarePaq services are prepaid.
For additional CarePaq (hardware & software) information, as well as, orderable part numbers please refer to the URL listed below:
http://www.compaq.com/services/carepaq/index.html
DA-10772 World Wide — Version 10 — J une 24, 2002 3
QuickSpecs
Compaq SDLT 110/220GB Tape Drive
PRODUCT HIGHLIGHTS (continued)
CarePaq Service & Support (continued)
EMEA CarePaq Information
Information on EMEA CarePaqs is available at http://emea-inline.eur.compaq.com/csd/smb/
Sample Part numbers
206959-022/021 provides 4 hour hardware response 9 x 5
206960-022/021 provides 4 hour hardware response 24 x 7
CS Support
Compaq Services provides a three-year, limited warranty, fully supported by a worldwide network of resellers and service providers and toll-free 7 x 24
hardware technical phone support during the warranty period. In addition, available service offerings include a full range of CarePaq packaged hardware
and software services:
• Installation and start up
• Extended coverage hours and enhanced response times
• System management and performance services
• Availability and recovery services
Warranty
3-0-0 (Three year parts)
.
C
OMPAQ SDLT 110/220-GB TAPE DRIVE SPECIFICATIONS
Protocol Support
O/S Support
Dimensions
Ultra2 SCSI, SE/LVD interface (switchable)
Windows NT v4.0, Windows 2000
Netware v4.12 & 5.0
OpenVMS (native) VMS7.1-2/7.2-1
Tru64 Unix (native) 4.0f/5.0a/5.1
Linux (native) – Red Hat 7.0/7.1, SuSE 7.0/7.1, Caldera 3.5
SCO/Caldera Unix (native) - OpenServer 5.0.6/OpenUnix 8 (Certified)
Physical (HxWxD) SDLT 110/220-GB, Internal 3.4 x 5.84 x 8.35 in/8.64 x 14.83 x 21.21 cm
SDLT 110/220-GB, External 6.3 x 6.9 x 12.8 in/16 x 17.51 x 32.51 cm
SDLT 110/220-GB, Rackmount (1 or 2-Drive) 5.2 x 16.8 x 23 in/13.2 x 42.7 x 58.4 cm
SDLT 110/220-GB, Rackmount (4-Drive) 8.75 x 19 x 18.125 in / 22.2 x 48.26 x 46 cm
Shipping (LxWxH) SDLT 110/220-GB, Internal 14.5 x 13 x 11.85 in/36.83 x 33.02 x 30.1
SDLT 110/220-GB, External 17.13 x 19.75 x13.25 in/43.51 x 50.17 x
SDLT 110/220-GB, Rackmount (1 or 2-Drive) 15.75 x 23.75 x 33.50 in/40.005 x 60.325 x
SDLT 110/220-GB, Rackmount (4-Drive) 32.25 x 15.38 x 31 in / 81.92 x 39.07 x
cm
33.66 cm
85.09 cm
78.74 cm
DA-10772 World Wide — Version 10 — J une 24, 2002 4
QuickSpecs
Compaq SDLT 110/220GB Tape Drive
COMPAQ SDLT 110/220-GB TAPE DRIVE SPECIFICATIONS (continued)
Weight
UPC/JAN Code
Cables
Out of box SDLT 110/220-GB, Internal 5.25 lb/2.4 kg
SDLT 110/220-GB, External 14.0 lb/6.35 kg
SDLT 110/220-GB, Rackmount (1-Drive) 32.4 lb/14.7 kg
SDLT 110/220-GB, Rackmount (2-Drive) 37.6 lb/17.1 kg
SDLT 110/220-GB, Rackmount (4-Drive) 52 lb/23.7 kg
Shipping SDLT 110/220-GB, Internal 13 lb/5.9 kg
SDLT 110/220-GB, External 32 lb/14.5 kg
SDLT 110/220-GB, Rackmount (1-Drive) 52.4 lb/23.8 kg
SDLT 110/220-GB, Rackmount (2-Drive) 57.6 lb/26.2 kg
SDLT 110/220-GB, Rackmount (4-Drive) 81 lb/36.8 kg
192106-B21 720591440848 4948382197047
192103-001 720591440794
192103-B31 720591440800
192103-291 720591440817 4948382165862
274331-B21 613326372722 4948382246790
274334-B21 613326372784 4948382247322
274336-B21 613326372548 4948382247346
Required/Supported
Cables
Internal Options contain a 2-Device ribbon cable with switchable LVD/SE terminator
External Options contain 6 ft 68-pin HD to VHDCI External Cable, 6 ft 68-pin HD to 68-pin HD
External Cable, and 3 FT 68-pin HD to 68-pin HD External Cable
Drive LED Indicators
Buffer
Input Requirements
Interface
Maximum Number of Drives
Maximum Transfer Rate
Average Access Time from
BOT
Load/Unload Time
Media
Power
Reliability Features
Relative Humidity
(non-condensing)
Temperature Range
Altitude
Required/Supported Cables
(Rackmount Models Only –
must be ordered separately)
Ready/Busy When constantly illuminated, the drive is ready for next command
When blinking, drive is executing a command
Write Protected When illuminated, the tape cartridge is write protected
Attention An error has occurred and requires intervention
32-MB embedded within the tape drive
Nominal Line Voltage 100 to 264
Range Line Voltage VAC
Line Frequency 47 to 63 Hz
Typical Input Current 46 W
SE/LVD (switchable) LVD: Ultra2 SE: Ultra
2 or more drives per scsi bus * Depending on compressibility of data
80MB/s (burst)
70 seconds
40 sec / 12 sec
SDLT
+5V±5% / +12V±10%
Head Life 30,000 Hours
MTBF 250,000 Hours @ 80% duty cycle
Operating 20% to 80%
Shipping 5% to 95%
Operating 50° to 104°F/10° to 40°C
Shipping -32° to 150.8°F/-40° to 66°C
Operating -500 ft/-152 m to 10,000 ft/3,048 m
LVD Cable Kit, 68-Pin HD/VHDCI
LVD Cable Kit, 68-Pin HD/68-Pin HD
68-Pin HD/VHDCI, 12ft
68-Pin HD/68-Pin HD, 5m
68-Pin HD/68-Pin HD, 10m
DA-10772 World Wide — Version 10 — J une 24, 2002 5
QuickSpecs
Compaq SDLT 110/220GB Tape Drive
SDLT 110/220 RACKMOUNT MODELS SPECIFICATIONS
Protocol Support
Form Factor
LED Indicators
(On Front Panel)
Cable Type (External)
External Connector
Type/Quantity
Maximum Number of
Devices/Ports
Maximum Number of Drives
Tape Drive (Installed)
Capacity
Transfer Rate (maximum)
Single/Dual-Drive Models SDLT 110/220 Tape Array III
Wide SCSI LVD/SE Wide SCSI LVD/SE
3U, Rackmount 5U, Rackmount
(1) Power Supply LED (1) Power Supply LED, (1) Service Required LED
Not Included
(Please refer to section entitled
“Related Options”)
68 Pin High-Density (HD) / 2
Wide SCSI Connectors
2 internal SCSI buses
(channels) supporting 1 drive
per SCSI bus
2 Full-Height (DLT & SDLT) 4 Full-Height (DLT & SDLT)
SDLT 110/220 (1 or 2 drives
installed)
Up to 220-GB Native Capacity 440-GB Native Capacity
Up to 22MB/s 44MB/s
(2) 12ft. 68-Pin HD-to-VHDCI
68 Pin High-Density (HD) / 2 Wide SCSI Connectors (Can increase to 4 connectors with
Optional LVD Cable Kit)
2 internal SCSI buses with up to 2 drives per SCSI bus;
Optional LVD cable kit can increase unit to 4 internal SCSI buses with 1 drive per bus
SDLT 10/220 (4 drives installed)
FAMILY COMPARISON
DLT 20/40 DLT 40/80 SDLT 110/220
Announce Date 1996 2000 January 2001
Capacity (native) 20GB 40GB 110GB
SCSI Interface Fast SE Fast-Wide SE/LVD Ultra2, LVD
Buffer 4MB 8MB 32MB
Firmware Upgradeable Yes Yes Yes
Maximum Drives per bus 2 2 2 or more
MTBF 200,000 @ 80% 250,000 @ 80% 250,000 @ 80%
Transfer Rate 1.5MB/s 6MB/s 11MB/s
SERVER AND TAPE COMPATIBILITY
ProLiant Servers Internal External Rackmount
DL320 X X
DL360 X X
DL380 X X X
DL580 X X
PL8500 X X
ML330 X X X
ML350 X X X
ML370 X X X
ML530 X X X
ML570 X X X
PL8000 X X X
CL380 X X X
CL1850 X X X
Host Bus Adapters and
Controllers for Intel Based
Servers
Dual Channel 64-bit Wide Ultra3 127693-001
Single Channel 64-bit Wide Ultra3 154457-B21, -291
SCSI-3 272514-001
64-bit Dual Channel 348757-B21
Dual Channel Ultra III 129803-B21, -291
DA-10772 World Wide — Version 10 — J une 24, 2002 6
QuickSpecs
Compaq SDLT 110/220GB Tape Drive
ALPHASERVER AND TAPE COMPATIBILITY
AlphaServers Internal External Rackmount**
DS10 * X X X
XP900 * X X X
XP1000 * X X X
DS10L X X
AlphaStation™ DS20E * X X X
ES40 * X X X
AlphaStation ES40 * X X X
GS60E X X
GS80/160/320 X X
GS140 * X X X
* Internal Drive support for these platforms is limited to use in a Rack Mount enclosure
** Compatible with SDLT 110/220 Tape Array III and 5U Rackmount Kit only
Host Bus Adapters and
Controllers Compatibility for
AlphaServers
32-bit Single Channel LSI SYM 8951Uia 30-56041-01
Comb SCSI/Ether Dual Channel KZPCM-DA
32-bit Single Channel KZPBA-CA
32-bit Single Channel LSI SYM 8952Uia SN-KZPCA-AA
32-bit to LVD SCSI LSI SYM 8952Uia 3X-KZPCA-AA
CONFIGURATION INFORMATION
STEP 1 – SDLT 110/220-GB TAPE DRIVE – BASE CONFIGURATION
Select one:
Model Number Part Number Model Description:
SDLT 110/220-GB Internal 192106-B21 Contains one SDLT 110/220-GB tape drive, 1 SDLT data cassette, 1 internal 2-Device Ribbon
SDLT 110/220-GB External 192103-001
192103-B31
192103-291
SDLT 110/220-GB, 3U
Rackmount
SDLT 110/220-GB, Dual Drive,
3U Rackmount
SDLT 110/220-GB Tape Array
III, 5U Rackmount
274331-B21 Wide SCSI LVD rack-mountable enclosure (3U) with power supply and fan, one internal SDLT
274334-B21 Wide SCSI LVD rack-mountable enclosure (3U) with power supply and fan, two internal SDLT
274336-B21 Wide SCSI LVD rack-mountable enclosure (5U) with power supply and fan, four DLT 40/80-GB
Cable w/switchable LVD/SE Terminator, Warranty Card, User’s Guide on CD, and Native
Drivers on CD.
Contains one SDLT 110/220-GB tape drive enclosed in an external housing, power cord, SCSI
terminator, 1 SDLT data cassette, 1 external 3′ Wide to VHDCI cable, Warranty Card, User’s
Guide on CD, and Native Drivers on CD.
110/220-GB tape drive, one SDLT data cartridge, Power Cord, Native Drivers on CD, User’s
Guide on CD, and Documentation.
110/220GB tape drives, two SDLT data cassettes, Power Cord, Native Drivers on CD, User’s
Guide on CD, and Documentation.
tape drives, four DLT IV data cassettes, one DLT cleaning cassette, two SCSI cables, Power
Cord, Native Drivers on CD, User’s Guide on CD, and Documentation.
DA-10772 World Wide — Version 10 — J une 24, 2002 7
QuickSpecs
Compaq SDLT 110/220GB Tape Drive
RELATED OPTIONS
Media
SDLT Media, 20-Pack 188527-B26
SDLT Media, 10-Pack 188527-B22
SDLT Media, 5-Pack 188527-B21
SDLT 110/220 Maintenance Kit 270445-B21 (includes SDLT cleaning cartridge)
Rackmount Tape Options, Cable Kits, & Rail Ki ts
5U Rackmount Kit, All 274339-B21 (Please refer to “Rackmount Tape Drive Kits” QuickSpec for further information)
3U Rackmount Kit, All 274338-B21 (Please refer to “Rackmount Tape Drive Kits
LVD Cable Kit, 68-Pin HD/VHDCI 168048-B21 (Internal & External Cables)
LVD Cable Kit, 68-Pin HD/68-Pin HD 242381-B21 (Internal & External Cables)
68-Pin HD/VHDCI, 12ft 341177-B21 (External Cable only)
68-Pin HD/68-Pin HD, 5m 328215-001 (External Cable only)
68-Pin HD/68-Pin HD, 10m 328215-002 (External Cable only)
Alpha Rail Kit
Tape Storage Software
Data Protection Software Suite 259596-B21
© 2002 Compaq Information Technologies Group, LP.
Compaq, the Compaq logo, AlphaServer, AlphaStation, CarePaq, Insight Manager, OpenVMS, ProLiant, StorageWorks, and Tru64 are trademarks of
Compaq Information Technologies Group, L.P. in the U.S. and/or other countries. Windows NT and Windows 2000 are trademarks of Microsoft Corporation in
the U.S. and/or other countries. The Intel Inside Logo is a trademark of Intel Corporation in the U.S. and/or other countries. Unix is a trademark of The Open
Group in the U.S. and/or other countries. All other product names mentioned herein may be trademarks of their respective companies.
Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information is provided “as is” without warranty of any kind and
is subject to change without notice. The warranties for Compaq products are set forth in the express limited warranty statements accompanying such
products. Nothing herein should be construed as constituting an additional warranty.
254795-001 (Rail Kit is required for installation of SDLT 110/220 Tape Array III into AlphaServer rack)
” QuickSpec for further information)
DA-10772 World Wide — Version 10 — J une 24, 2002 8
Loading...
