HP Rack-mountable UPSs provide maximum uptime in the event of a power problem for a variety of rack-based computer systems,
providing powerful performance while occupying minimal rack space.
The HP R1500 G3 UPS is a 1U, high power density solution designed for customers who want to provide power protection, for
maximum uptime and data corruption avoidance, in space-constrained rack environments. In addition, HP's new Power Protector
software is included at no charge for robust and flexible UPS management.
1.
Input circuit breaker
NOTE:
NOTE:NOTE:
NOTE:
International model only
6.
Voltage configuration dip switches
2.
Network Transient protector IN Jack
7.
Serial communications port
3.
Network transient protector OUT Jack
8.
USB communications port
4.
Load segment one (two NEMA 5-15R output receptacles for
surge and battery backup protection)
9.
NA and JPN models input power connector is hardwired
NEMA 5-15P
5.
Load segment two (two NEMA 5-15R output receptacles for
surge and battery backup protection)
1.
Input circuit breaker
NOTE:
NOTE:NOTE:
NOTE:
International model only
6.
Voltage configuration dip switches
QuickSpecs
HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)
Overview
DA - 14059 Worldwide — Version 2 — July 20, 2011
Page 1
2.
Network Transient protector IN Jack
7.
Serial communications port
3.
Network transient protector OUT Jack
8.
USB communications port
4.
Load segment one (two IEC 320-C13 output receptacles for
surge and battery backup protection)
9.
Input power connector (IEC-320- C14 power inlet
NOTE:
NOTE:NOTE:
NOTE:
NA and JPN models input power connector is
hardwired NEMA 5-15P
5.
Load segment two (two IEC 320-C13 output receptacles for
surge and battery backup protection)
Models
ModelsModels
Models
HP R1.5kVA G3 1U NA Uninterruptible Power System
AF469A
HP R1.5kVA G3 1U JP/TW Uninterruptible Power System
AF470A
HP R1.5kVA G3 1U INTL Uninterruptible Power System
AF471A
QuickSpecs
HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)
Overview
DA - 14059 Worldwide — Version 2 — July 20, 2011
Page 2
Key Features
Key FeaturesKey Features
Key Features
Increased power density with up to 1500VA/1000 Watts of power packed in just 1U rack space
1U Chassis
Front panel LED display
Enterprise-wide intelligent manageability with bundled HP Power Protector management software
Support for the HP UPS Network Module that extends the power management capabilities of the
UPS
More efficient voltage regulation with revolutionary technology
Ultimate long-term battery reliability with HP Enhanced Battery Management
Enhanced system flexibility with two independently controlled load segments
Hot-Swappable Batteries
Backed by a three-year warranty with the first year including parts and labor Pre-Failure warranty,
and a $250,000 load protection guarantee
NOTE:
NOTE:NOTE:
NOTE:
Certain restrictions and exclusions apply
1U Power Packed Design
1U Power Packed Design1U Power Packed Design
1U Power Packed Design
Rated up to1500VA/1000W, the HP UPS R1500 G3 packs more power in space-conserving rack-mount
design, allowing you to support more critical equipment in your rack.
Lower Cost of Ownership
Lower Cost of OwnershipLower Cost of Ownership
Lower Cost of Ownership
with Innovative
with Innovativewith Innovative
with Innovative
Technology
TechnologyTechnology
Technology
The UPS R1500 G3 utilizes a line interactive which features true sine wave output and superior
input/output voltage regulation. This technology is inherently reliable and highly efficient. The HP UPS
can correct input voltage variations as low as -23% of nominal voltage without transferring to the battery.
This will ensure the battery is preserved and ready for the next power anomaly
Investment Protection with
Investment Protection withInvestment Protection with
Investment Protection with
HP Enhanced Battery
HP Enhanced BatteryHP Enhanced Battery
HP Enhanced Battery
Management
ManagementManagement
Management
The UPS R1500 G3 incorporates Enhanced Battery Management: an exclusive, patented technology that
doubles battery service life, optimizes battery recharge time, and provides advance notice of pending
battery failure. With Enhanced Battery Management, you have a lower total cost of ownership and
receive the best in the industry protection for your critical equipment.
Intelligent Manageability
Intelligent ManageabilityIntelligent Manageability
Intelligent Manageability
HP Power Protector management software included with the R1500 G3 models. The HP Power Protector
Software enables you to monitor and control HP UPSs locally or remotely. This software is a versatile,
fully configurable, alert response tool that gives system administrators a full overview of the UPSs
conditions. It enables you to monitor system status and power conditions, configure shut down timing,
customize alert messages, and gracefully shut down servers during an extended power outage. For more
information on HP Power Protector software be see:
www.hp.com/go/hppp
QuickSpecs
HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)
Standard Features
DA - 14059 Worldwide — Version 2 — July 20, 2011
Page 3
Optional UPS Network
Optional UPS NetworkOptional UPS Network
Optional UPS Network
Module
ModuleModule
Module
The HP UPS Network Module enables you to monitor and manage power environments through
comprehensive control of HP UPSs. The HP UPS Management Module can support either a single UPS
configuration or provides additional power protection with support for dual redundant UPS configuration
for no-single-point-of-failure. The UPS Network Module can be configured to send alert traps to HP
Systems Insight Manager and other SNMP management programs or used as a standalone management
system. This flexibility enables you to monitor and manage UPSs through the network. To facilitate dayto-day maintenance tasks, the embedded management software provides detailed system logs.
The HP UPS Network Module provides remote management of a UPS by connecting the UPS directly to
the network. Configuration & Management of the UPS from anywhere and at anytime via a standard web
browser.
NOTE:
NOTE:NOTE:
NOTE:
For more information on the UPS Network Module please see:
www.hp.com/go/hpunm
.
Independently
IndependentlyIndependently
Independently
Controllable Load
Controllable LoadControllable Load
Controllable Load
Segments
SegmentsSegments
Segments
With two independent controlled load segments, you have the flexibility to configure each segment's shut
down schedule to maximize runtime for critical equipment.
Ease of Maintenance with
Ease of Maintenance withEase of Maintenance with
Ease of Maintenance with
Hot-Swappable Batteries
Hot-Swappable BatteriesHot-Swappable Batteries
Hot-Swappable Batteries
The UPS R1500 G3 is modular in design, and the batteries are hot swappable. HP UPSs are designed
with simple access through the front panel. Users can safely install new batteries without ever powering
down connected server and server options.
HP Quality
HP QualityHP Quality
HP Quality
HP's hardware qualification is the toughest in the industry. Extensive evaluation, testing, product
improvement, and an unsurpassed warranty guarantee the highest level of system protection, electrical
performance, product quality and compatibility.
Compatibility
CompatibilityCompatibility
Compatibility
Compatible with all HP servers, storage, racks, rack options, and other rack mountable HP equipment.
Warranty
WarrantyWarranty
Warranty
The HP UPS R1500 G3 is covered by a three year warranty, with the first year including parts and labor.
Also, standard on all HP UPS units is our exclusive Pre-Failure Warranty which extends the advantage of
a HP three-year, limited warranty by applying it to the battery before it actually fails. This warranty is
offered worldwide. Specifically, the Pre-Failure Battery Warranty ensures that when customers receive
notification from HP Power Management Software that the battery may fail, the battery is replaced free of
charge under the warranty.
NOTE:
NOTE:NOTE:
NOTE:
$250,000 Computer/Load Protection Guarantee is also provided, in addition to the HP three
year, limited warranty.
Warranty Upgrade Options
Warranty Upgrade OptionsWarranty Upgrade Options
Warranty Upgrade Options
:
Response - Upgrade on-site response from next business day to same day 4-hours
Coverage - Extend hours of coverage from 5 days x 9 hours to 7 days x 24 hours
Duration - Select duration of coverage for a minimum period of 1 year or multiple years
QuickSpecs
HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)
Standard Features
DA - 14059 Worldwide — Version 2 — July 20, 2011
Page 4
Service and Support
Service and SupportService and Support
Service and Support
HP Technology Services
HP Technology ServicesHP Technology Services
HP Technology Services
HP Technology Services offers you consultants and support experts to solve your most complex
infrastructure problems. We help keep your business running, boost availability and avoid downtime.
Protect your business beyond warranty with HP Care Pack Services
Protect your business beyond warranty with HP Care Pack ServicesProtect your business beyond warranty with HP Care Pack Services
Protect your business beyond warranty with HP Care Pack Services
When you buy HP Options, it's also a good time to think about what level of service you may need. HP
Care Pack services provide total care and support expertise with committed response choices designed to
meet your IT and business need.
Recommended HP Care Pack Services for optimal satisfaction with your HP product
Recommended HP Care Pack Services for optimal satisfaction with your HP productRecommended HP Care Pack Services for optimal satisfaction with your HP product
Recommended HP Care Pack Services for optimal satisfaction with your HP product
Recommended Services
Recommended ServicesRecommended Services
Recommended Services
3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service
3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service
3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service
Provides you with rapid remote support and if required an HP authorized representative who will arrive
on site any time and day of the year to begin hardware maintenance service within 4 hours of the service
request being logged.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EEE
HP ProLiant Server Hardware Installation
HP ProLiant Server Hardware InstallationHP ProLiant Server Hardware Installation
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN
Related HP Care Pack Services to enhance your HP product experience
Related HP Care Pack Services to enhance your HP product experienceRelated HP Care Pack Services to enhance your HP product experience
Related HP Care Pack Services to enhance your HP product experience
Related Services
Related ServicesRelated Services
Related Services
3-Year HP 6 hour Hardware Support Onsite Call-to-Repair Service
3-Year HP 6 hour Hardware Support Onsite Call-to-Repair Service3-Year HP 6 hour Hardware Support Onsite Call-to-Repair Service
3-Year HP 6 hour Hardware Support Onsite Call-to-Repair Service
Provides an IT manager with a team of support specialists who will quickly begin troubleshooting the
system to help return the hardware to operating condition within 6 hours of the initial service request to
the HP Global Solution Center
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6636ENN
HP Proactive Select Service
HP Proactive Select ServiceHP Proactive Select Service
HP Proactive Select Service
Provides a flexible way to purchase HP best-in-class consultancy and technical services. You can buy
Proactive Select Service Credits when you purchase your hardware and then use the credits over the next
12 months.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENN
Insight Remote
Insight RemoteInsight Remote
Insight Remote
Support Delivers secure remote monitoring and support for HP servers and storage, 24x7 at no
additional cost. Available as part of HP Warranty, Care Pack and Service Contract offers.
Parts and materials
Parts and materialsParts and materials
Parts and materials
HP will provide HP-supported replacement parts and materials necessary to maintain the covered
hardware product in operating condition, including parts and materials for available and recommended
engineering improvements. Supplies and consumable parts will not be provided as part of this service;
standard warranty terms and conditions apply. Parts and components that have exceeded their maximum
supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's operating
manual or the technical product data sheet will not be provided, repaired or replaced as part of this
service.
Coverage
CoverageCoverage
Coverage
For ProLiant servers and storage systems, this service covers HP-branded hardware options qualified for
the server, purchased at the same time or afterward, internal to the enclosure, as well as external
monitors up to 22" and tower UPS products; these items will be covered at the same service level and for
the same coverage period as the server unless the maximum supported lifetime and/or the maximum
usage limitation has been exceeded. Coverage of the UPS battery is not included; standard warranty
QuickSpecs
HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)
Service and Support
DA - 14059 Worldwide — Version 2 — July 20, 2011
Page 5
terms and conditions apply.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
replaced by HP due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that
have not failed. SSD/Flash Drives that are specified by HP as consumable parts and/or that have
exceeded maximum supported lifetime and/or the maximum usage limit as set forth in the manufacturer's
operating manual or the technical data sheet are not eligible for the defective media retention service
feature option.
For more information
For more informationFor more information
For more information
To learn more on services for HP ESSN Options, please contact your HP sales representative or HP
Authorized Channel Partner. Or visit:
http://www.hp.com/services/proliant
or
www.hp.com/services/bladesystem
QuickSpecs
HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)
Service and Support
DA - 14059 Worldwide — Version 2 — July 20, 2011
Page 6
UPS Management
UPS ManagementUPS Management
UPS Management
HP UPS Network Module
AF465A
HP Care Pack
HP Care PackHP Care Pack
HP Care Pack
HP Install Universal Power Supply Less Than 3KVA Service
U4690E
QuickSpecs
HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)
Related Options
DA - 14059 Worldwide — Version 2 — July 20, 2011
Page 7
Part Number
Part NumberPart Number
Part Number
Operating Voltage
Operating VoltageOperating Voltage
Operating Voltage
Settings
SettingsSettings
Settings
Power Out (VA/Watts)
Power Out (VA/Watts)Power Out (VA/Watts)
Power Out (VA/Watts)
Input Connection
Input ConnectionInput Connection
Input Connection
Output Connection
Output ConnectionOutput Connection
Output Connection
Low-Voltage Models
Low-Voltage ModelsLow-Voltage Models
Low-Voltage Models
AF469A
120V
1440/1000
NEMA 5-15P
(4) Nema 5-15R
NOTE:
NOTE:NOTE:
NOTE:
Part Number AF469A is user selectable for 110V, 120V, or 127V via the rear panel dip switch
AF470A
100V
1200/900
NEMA 5-15P
(4) Nema 5-15R
110v
1320/1000
Nema 5-15P
(4) Nema 5-15R
NOTE:
NOTE:NOTE:
NOTE:
Part Number AF421A is user selectable for 100V, or 110V via rear panel dip switch
High Voltage Model
High Voltage ModelHigh Voltage Model
High Voltage Model
AF471A
230V
1500/1000
IEC-320 C14
(4) IEC 320-C13
NOTE:
NOTE:NOTE:
NOTE:
Part Number AF471A is user selectable for 220V, 230V, or 240V via the rear panel dip switch
Kit Contents
Kit ContentsKit Contents
Kit Contents
HP UPS R1500 G3
Power Products Documentation CD
Depth adjustable fixed rack mounting rails
Serial communications cable (1.83 meters)
Additional IEC to IEC jumper cords, and detachable country specific input cord with the high
voltage INTL model
USB communications cable (1.8 meters)
QuickSpecs
HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)
UPS Model Matrix
DA - 14059 Worldwide — Version 2 — July 20, 2011
Page 8
Unit Dimensions
Unit DimensionsUnit Dimensions
Unit Dimensions
17.5 x 1.75 x 24.0 in (44.45 x 4.44 x 61 cm)
Shipping Dimensions
Shipping DimensionsShipping Dimensions
Shipping Dimensions
32 x 11.5 x 26.75 in (81.28 x 29.21 x 67.95 cm)
Unit Weight
Unit WeightUnit Weight
Unit Weight
50.5 lb (22.9 kg)
Shipping Weight
Shipping WeightShipping Weight
Shipping Weight
76 lb (34.5 kg)
Electrical Input
Electrical InputElectrical Input
Electrical Input
Voltage Range
Voltage RangeVoltage Range
Voltage Range
± 20% of nominal100, 120 and 230V models. See Model Matrix for
nominal and user selectable voltage settings via the rear panel dip switch
Frequency
FrequencyFrequency
Frequency
50/60 Hz ± 5Hz (auto sensing)
Input Plug
Input PlugInput Plug
Input Plug
See Model Matrix
Online Efficiency
Online EfficiencyOnline Efficiency
Online Efficiency
95%
Surge Suppression
Surge SuppressionSurge Suppression
Surge Suppression
High Energy 6500A peak
Electrical Output
Electrical OutputElectrical Output
Electrical Output
Online Regulation
Online RegulationOnline Regulation
Online Regulation
-10% to +6% of nominal voltage
On battery Regulation
On battery RegulationOn battery Regulation
On battery Regulation
±5% of nominal voltage
Voltage Wave Form
Voltage Wave FormVoltage Wave Form
Voltage Wave Form
Sine wave
Connections
ConnectionsConnections
Connections
See Model Selection Matrix; divided into 2 Load Segments
Output Protection
Output ProtectionOutput Protection
Output Protection
Firmware overload sensing and control, customer supplied facility input
circuit breaker, and re-settable rear panel circuit breaker on the INTL HV
AF418A
Battery
BatteryBattery
Battery
Type
TypeType
Type
Maintenance-free, sealed, valve-regulated lead acid (VRLA)
Backup Time
Backup TimeBackup Time
Backup Time
See Backup Times Chart
Recharge Time
Recharge TimeRecharge Time
Recharge Time
<3 hours to 90% usable capacity; <24 hours for complete recharge
Voltage
VoltageVoltage
Voltage
36V Battery String
Communications
CommunicationsCommunications
Communications
Ports
PortsPorts
Ports
Standard DB-9 port (ships with communication cable)
USB port (ships with communication cable)
Option Slot
Option SlotOption Slot
Option Slot
One
Option Cards
Option CardsOption Cards
Option Cards
HP UPS Network Module
LED Indicators
LED IndicatorsLED Indicators
LED Indicators
LED display integrated into the front panel
Software
SoftwareSoftware
Software
HP Power Protector management software available via download
Environmental and Safety
Environmental and SafetyEnvironmental and Safety
Environmental and Safety
Operating Temperature
Operating TemperatureOperating Temperature
Operating Temperature
50° to 104° F (10° to 40° C)
Transit Temperature
Transit TemperatureTransit Temperature
Transit Temperature
-5° to 131° F (-15° to 55° C)
Storage Temperature
Storage TemperatureStorage Temperature
Storage Temperature
-15° to 55° F (-26° to 13° C)
Humidity
HumidityHumidity
Humidity
(Operation)
5% to 95%
Humidity
HumidityHumidity
Humidity
(Non-operating)
5% to 95%
Operating Altitude
Operating AltitudeOperating Altitude
Operating Altitude
3000 m <35 d C; 1500 m 36 - 40 d C
Storage Altitude
Storage AltitudeStorage Altitude
Storage Altitude
<40db in normal operation; <45db while on inverter
Audible Noise
Audible NoiseAudible Noise
Audible Noise
<46db (at 1m from surface of unit)
Safety Markings
Safety MarkingsSafety Markings
Safety Markings
UL/cUL ICES, GS, GOST, EK
Safety Certifications
Safety CertificationsSafety Certifications
Safety Certifications
UL1778; UL6950, CSA22.2 No.107.1,No.107.2,No.950; CB Bulletin
No.86AI; EN50091-1; EN60950
EMC Markings
EMC MarkingsEMC Markings
EMC Markings
FCC-A; CISPR 22; VCCI-A; CE, BSMI, C-TICK
Emissions
EmissionsEmissions
Emissions
FCC CFR 47, Part 15 Class A, EN50091-2
Immunity
ImmunityImmunity
Immunity
IEC 801-2, IEC 801-3, IEC 801-4, IEC 801-5
Surge Suppression
Surge SuppressionSurge Suppression
Surge Suppression
Conforms to IEEE 587B and ANSI C62.41
QuickSpecs
HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)
Technical Specifications
DA - 14059 Worldwide — Version 2 — July 20, 2011
Page 9
Estimated Backup Times Chart (Minutes)
Estimated Backup Times Chart (Minutes)Estimated Backup Times Chart (Minutes)
Estimated Backup Times Chart (Minutes)
Load, Percent
Load, PercentLoad, Percent
Load, Percent
Load, Watts
Load, WattsLoad, Watts
Load, Watts
Minutes of Back up time
Minutes of Back up timeMinutes of Back up time
Minutes of Back up time
20%
20%20%
20%
200
200200
200
58
5858
58
50%
50%50%
50%
500
500500
500
17
1717
17
80%
80%80%
80%
800
800800
800
8888
100%
100%100%
100%
1000
10001000
1000
5555
Environment-friendly
Environment-friendlyEnvironment-friendly
Environment-friendly
Products and Approach
Products and ApproachProducts and Approach
Products and Approach
End-of-life Management
End-of-life ManagementEnd-of-life Management
End-of-life Management
and Recycling
and Recyclingand Recycling
and Recycling
Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling
programs in many geographic areas. For trade-in information, please go to:
http://www.hp.com/go/green
. To recycle your product, please go to:
http://www.hp.com/go/green
or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities.
This information (product disassembly instructions) is posted on the Hewlett
Packard web site at:
http://www.hp.com/go/green
. These instructions may be
used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
© Copyright 2011 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft and Windows NT are US registered trademarks of Microsoft Corporation. Intel is a US registered trademark of Intel
Corporation. Unix is a registered trademark of The Open Group.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
QuickSpecs
HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)HP R1500 G3 Uninterruptible Power Supply (UPS)
HP R1500 G3 Uninterruptible Power Supply (UPS)
Technical Specifications
DA - 14059 Worldwide — Version 2 — July 20, 2011
Page 10
Loading...
