QuickSpecs

Overview

What's New

•

Price/performance dual processor server blade designed with enterprise availability ProLiant BL20p Server Blade includes:

•

Intel Pentium III FC-PGA

1.4 GHz processor (dual capability)

•

ServerWorks HE- SuperLite Chipset

•

512-MB or 1024-MB PC133-MHz Registered ECC SDRAM memory, (2 x 1 Interleaved Memory), expandable to 4 GB

•

Three NC3163 Fast Ethernet Embedded WOL (Wake On LAN) NICs standard

•

Two NICs are upgradable to 10/100/1000T using the Dual Gigabit Ethernet NC7780 NIC option kit

•

One additional 10/100 port dedicated to Integrated Lights-Out (iLO) Management

•

Smart Array 5i Controller with batterybacked write cache option (integrated on system board)

•

Wide Ultra3 SCSI Drive Cage standard

supports up to two 1″ Wide Ultra3 hot

plug hard drives

•

Integrated Lights-Out (iLO) Advanced Management (ASIC on motherboard)

•

Plugs vertically into 6U enclosure

•

Up to 48 BL20p blades fit in 42U rack

•

ProLiant BL p-Class Server Blade Enclosure:

•

Server blades and interconnects blind mate into server blade enclosures for network connection and power

•

Server blade enclosure is 6U and holds up to 8 ProLiant BL20p server blades and 2 interconnects

•

2 types of interconnects available: interconnect switches or patch panels

•

ProLiant BL p-Class Power Enclosure:

•

Use BL p-Class sizing tool to determine power based on your configuration

http://www.compaq.com/products/servers /proliant-bl/p-class/index.html

Note: This Web site is available in

•

BL p-Class power enclosure provides shared, external, redundant power

•

Power enclosure is 3U and holds up to 6 hot-plug power supplies

•

Choose single-phase or three-phase power

•

BL p-Class power enclosure with power supplies not needed if using facility

-48VDC ± 10% in this case purchase DC

option kit

•

ProLiant BL p-Class Power Distribution:

•

Distributes power from the power enclosure to the server blade enclosures

•

Three power distribution choices:

•

BL p-Class server blade, server blade enclosure, interconnects and power enclosure protected by a limited three year warranty with optional service uplifts available

•

Note: Power requirements for a ProLiant BL

p-Class system: 200V − 240V AC, 30 amp or facility DC -48V ± 10%.

English only.

BL p-Class scalable bus bar BL p-Class mini bus bar BL p-Class power bus box

ProLiant BL20p and p-Class system

DA-11411 Canada — Version 1 — August 26, 2002

QuickSpecs

Overview

Configuration Steps

•

For a complete configuration of the ProLiant BL20p, do the following:

1. Select BL p-Class server blades

• Single Intel Pentium III 1.40-GHz

• Two Intel Pentium III 1.40-GHz

2. Decide how many BL p-Class Server

Blade Enclosures to purchase (each enclosure can hold up to 8 ProLiant BL20p server blades)

• BL p-Class server blade enclosure

3. Select an Interconnect. Interconnects are sold in pairs. One pair of Interconnects is

required with each BL p-Class server

blade enclosure

• BL p-Class RJ-45 Patch panel (with

• ProLiant BL p-Class C-GbE

• ProLiant BL p-Class F-GbE

4. Select BL p-Class power enclosure and power supplies based on configuration. Use p-Class sizing tool to help determine power configuration

http://www.compaq.com/products/servers/ proliant-bl/p-class/index.html

Note: This Web site is available in

Note: Power enclosures and supplies are

• Single phase power enclosure with

• Three-phase power enclosure with

5. Select power distribution

• Scalable bus bar - Supports up to 5

• Mini bus bar – Supports up to 3

•

processor, 512-MB ECC SDRAM (230040-B21)

processors, 1-GB ECC SDRAM (Note: Additional options include processors, memory, and Gb NIC) (257959-B21)

PLUS

with 8 Rapid Deployment Pack licenses (281404-B21)

with Rapid Deployment Pack trial

(243564-B21)

32 RJ-45 connectors) (230766-B21)

Interconnect Kit (with 4 RJ-45 10/100/1000 T/TX/T and 4 RJ-45 10/100 T/TX uplink connectors) (249655-B21)

Interconnect Kit (with 4 LC 1000 SX and 4 RJ-45 10/100 T/TX uplink connectors) (279720-B21)

English only.

not needed if using facility DC

(-48V ± 10%).

four hot-plug power supplies (239162-001)

six hot-plug power supplies (230769-001)

server blade enclosures (240560-B21)

server blade enclosures (240559-B21)

Power Bus Box - connects 1 power enclosure to 1 server blade enclosure (240562-B21)

PLUS

ProLiant BL20p and p-Class system

DA-11411 Canada — Version 1 — August 26, 2002

QuickSpecs

Standard Features

ProLiant BL20p and p-Class system

Compaq ProLiant BL20p Server Blade

Processor

Upgradability

Cache Memory

Chipset

Memory

Network Controller

Manageability

Internal Storage

Expansion Slots

Intel Pentium III FC-PGA processor 1.40GHz

Upgradable to dual processing

512-KB Level 2 Cache

ServerWorks HE- SuperLite Chipset

Note: For more information regarding ServerWorks, please see the following URL:

Standard

Maximum 4096 MB Standard

Maximum 4096 MB

Note: Memory must be installed in pairs.

Four NICs total: Three Compaq NC3163 Fast Ethernet NIC PCI 10/100 with full WOL (Wake On LAN), one with PXE support One 10/100 iLO NIC dedicated to management Two NICs are upgradable to 10/100/1000T using the Dual Gigabit Ethernet NC7780 NIC option kit

Integrated Lights-Out (iLO) Management Advanced (ASIC on the System Board)

Hard Drives None ship standard

Maximum Internal Storage 145.6 GB (internal drive cage) (2 x 72.8 GB Wide Ultra3, 1″ drives)

No PCI slots all features are integrated

http://www.serverworks.com/products/overview.html

Note: This Web site is available in English only.

512MB PC133-MHz Registered ECC SDRAM DIMM Memory (2 X 256 MB) (1 processor model)

1024MB PC133-MHz Registered ECC SDRAM DIMM Memory (2 x 512 MB) (2 processor model)

Compaq ProLiant BL p-Class Server Blade Enclosure and Interconnects

ProLiant BL p-Class Server Blade Enclosure

ProLiant BL p-Class Power Requirements

6U (10.5-inch), 19-inch wide Holds up to 8 ProLiant BL20p servers blades 10 bays per server blade enclosure

8 bays for server blades

2 outside bays for interconnect modules (RJ-45 patch panels or GbE interconnect switches) Server blades blind mate into the server blade enclosure backplane for power and data connections Up to 6 BL p-Class 6U server blade enclosures fit in a 42U rack Server blade management module attached to the back of each BL p-Class 6U server blade enclosure to report

events all servers and provide asset and inventory information

Redundant 200V − 240V AC, 30 amp single-phase

Redundant 208V 30amp 3-phase 4 wire,

Redundant -48VDC ± 10%

DA-11411 Canada — Version 1 — August 26, 2002

QuickSpecs

Standard Features

ProLiant BL20p and p-Class system

Compaq ProLiant BL p-Class Server Blade Enclosure and Interconnects

ProLiant BL p-Class Interconnect Switch Option

(Two switches per kit) (Every BL p-Class server blade enclosure requires two Interconnect switches OR two

RJ-45 patch panels)

ProLiant BL p-Class RJ-45 patch panel

(Two patch panels per kit) (Every BL p-Class server blade enclosure

requires two Interconnect switches OR two

RJ-45 patch panels)

Required Network Cabling

Compaq ProLiant BL p -Class Power System and Rack Information

ProLiant BL p-Class Power Enclosure

Provides up to a 32 to 1 server networking cable reduction per server enclosure. Each interconnect switch (two per enclosure) reduces sixteen 10/100 Base-T/Base-TX server network ports to four uplinks ports (eight uplinks total). Only one to all eight uplinks may be used per enclosure.

The ProLiant BL p-Class F-GbE Interconnect Kit includes two GbE interconnect switches and two DualTSX Interconnect Modules that provide four (4) LC 1000 SX and four (4) RJ-45 10/100 T/TX uplink ports per server enclosure.

The ProLiant BL p-Class C-GbE Interconnect Kit includes two GbE interconnect switches and two QuadT Interconnect Modules that provide four (4) RJ-45 10/100/1000 T/TX/T and four (4) RJ-45 10/100 T/TX uplink ports per server enclosure.

Also included (per Interconnect Switch):

• Two (2) RJ-45 10/100 T/TX front panel ports for management or additional uplinks

• One (1) RS-232 DB-9 front panel out-of-band management port

• Redundant 10/100 cross links ports connecting the two Interconnect Switches

• Redundant power and cooling inputs

• Hot-plug and hot- remove with configuration retention capability

• Power ON, management, and per port status and speed LED indicators

• Reset/power momentary push-button switch

• Compaq ProLiant BL Interconnect Switch Management Utilities and User Documentation CD

• Fully pre-configured for rapid deployment and immediate operation

ProLiant BL Interconnect Switch Management System and Utilities: Full featured web-based interface, menu-driven console interface, Telnet, SNMP-based scripting utility and

example scripts, SNMP and RMON MIBs, BootP and DHCP client, port mirroring, QoS packet prioritization, IGMP multicasting, and TFTP server utilities for management of interconnect switch.

6U (10.5-inch), Plugs into BL p-Class 6U server blade enclosures Used to pass NIC signals from all server blades in server blade enclosure out as RJ-45 connections Supports Gigabit Ethernet network controllers

16 RJ-45 connectors on the back of each BL p-Class 6U RJ-45 patch panel (32 RJ-45 connections per server blade enclosure)

10Base-T Categories 3, 4 or 5 UTP (100 metres) EIA/TIA-568 100-ohm STP (100 metres) 100Base-TX Category 5 UTP (100 metres) EIA/TIA-568 100-ohm STP (100 metres) 1000Base-T Category 5 UTP (100 metres) EIA/TIA-568 100-ohm STP (100 metres) 1000Base-SX 50/125 µm Multimode Fiber, 400 MHz/Km (500 metres) 50/125 µm Multimode Fiber, 500 MHz/Km (550 metres)

62.5/125 µm Multimode Fiber, 160 MHz/Km (220 metres)

62.5/125 µm Multimode Fiber, 200 MHz/Km (275 metres)

Note: For cabling information, refer to the Compaq Web site at: http://www.compaq.com/products/servers/.

Note: This Web site is available in English only.

Note: To determine power configuration please refer to the ProLiant BL p-Class Overview and Planning

Whitepaper and sizing tool, please see the following URL:

http://www.compaq.com/products/servers/proliant-bl/p-class/index.html

Note: This Web site is available in English only.

3U (5.25-inch), 19-inch wide, 29-inch deep (0.48-metre wide, 0.74-metre deep), Dual input single phase and three phase models available

BL p-Class power enclosure provides external, shared hot-plug power. Each power enclosure houses up to six hot-plug power supplies to power the BL p-Class server blades and interconnects

Power enclosures and power supplies are not needed if using facility DC (-48V DC ± 10%). If using facility DC,

only Facility DC Power Connection kit part number (240563-B21) is needed.

(continued)

DA-11411 Canada — Version 1 — August 26, 2002

QuickSpecs

Standard Features

ProLiant BL20p and p-Class system

Compaq ProLiant BL p-Class Server Blade Enclosure and Interconnects

BL p-Class Power Distribution

Scalable Bus Bar 1 or 2 ≤ 5 36U Mini Bus Bar 1 ≤ 3 21U Power Bus Box 1 1 9U

Required Power Source

In the ProLiant BL p-Class infrastructure, redundant -48 VDC power (from the power enclosures or facility DC power) is distributed from the power enclosures to the server blade enclosures through the Compaq bus bar system. Hinges attach the ProLiant BL bus bars to the rails in a rack. The bus bars swing open from the centre to enable easy rear access to the server blades and network cables. Power is distributed redundantly through independent A- and B-sided bus bars.

Three different power distribution solutions are available depending on the maximum number of server blade enclosures planned for the rack:

• Compaq ProLiant BL p-Class scalable bus bar

• Compaq ProLiant BL p-Class mini bus bar

Note: To support a full 42U rack of BL20p server blades (6 server blade enclosures), two mini bus bars are

needed.

• Compaq ProLiant BL p-Class power bus box

Power Enclosures

Supported

Two 30amp redundant power feeds per power enclosure Connectors

–NEMA receptacles

NA 1-phase L6-30, 250v, 30A 3-wire NA 3-phase L15-30, 250V, 30A, 4-wire

Optimized for power cabling from bottom and network cabling from top For cabling information, refer to the Compaq Web site at

http://www.compaq.com/products/servers/

Note: This Web site is available in English only.

(continued)

Server Blade Enclosures

Supported

Max. Rack Space

Occupied

DA-11411 Canada — Version 1 — August 26, 2002

QuickSpecs

Standard Features

ProLiant BL20p and p-Class system

Compaq ProLiant BL p-Class Server Blade Enclosure and Interconnects

ProLiant Essentials Foundation Pack Software

Optional ProLiant Essentials Value

Packs

Insight Manager™ 7

Management Agents

Compaq ActiveUpdate

Compaq ROMPaq, support software, and configuration utilities

Compaq Survey Utility and diagnostics utilities

Compaq Health Driver

Compaq iLO Management Interface Driver

Optional software offerings that selectively extend the functionality of an Adaptive Infrastructure to address specific business problems and needs:

• Rapid Deployment Pack – an automated solution for multi-server

deployment and provisioning, enabling companies to quickly and easily adapt to changing business demands.

• Workload Management Pack – provides easier management of

complex environments, improving overall server utilization and enabling Windows 2000 customers for the first time to confidently deploy multiple applications on a single multiprocessor ProLiant Server.

• Integrated Lights-Out Advanced Pack - The BL20p includes the

advance version of the Integrated Lights-Out which includes graphical console and virtual media.

Insight Manager 7 helps maximize system uptime and performance and reduces the cost of maintaining the IT infrastructure by providing proactive notification of problems before those problems result in costly downtime and reduced productivity. Insight Manager 7 is easy to set up and provides rapid access to detailed fault and performance information gathered by the Management Agents. One-click-access to the Remote Insight Lights Out Edition board allows systems administrators to take full graphical control of ProLiant servers in remote locations or lights-out data centres. Finally, Insight Manager 7 in concert with the Version Control Agents and Version Control Repository Manager enables systems administrators to version manage and update system software across groups of Compaq ProLiant servers.

The Management Agents (http://www.compaq.com/products/servers/management/agents.html the foundation for Compaq's Intelligent Manageability strategy. They provide direct, browser-based access to in-depth instrumentation built into ProLiant servers, workstations, desktops, and portables, and send alerts to Insight Manager 7 and other management consoles in case of subsystem or environmental failures. For additional information about the Management Agents and other management product from Compaq, please visit the management Web site at http://www.compaq.com/manage

Note: These Web sites are available in English only.

ActiveUpdate is a web-based application that keep IT managers directly connected to Compaq for proactive notification and delivery of the latest software updates.

The latest software, drivers, and firmware fully optimized and tested for your ProLiant server and options.

The most advanced configuration analysis, reporting and troubleshooting utilities used by Compaq and at your fingertips.

Health Drivers interface with the Integrated Lights-Out ASIC to provide system management support, including monitoring of server components, event logging and support for the Compaq Insight Management Agents.

The iLO Management Interface Driver provides access to the iLO management processor for Insight Management Agents. This interface is used to provide SNMP alert forwarding and management agent integration.

Note: For more information regarding ProLiant Essentials Software, please

see the following URL: http://www.compaq.com/proliantessentials. Note: This Web site is available in English only.

(continued)

) form

DA-11411 Canada — Version 1 — August 26, 2002

QuickSpecs

Standard Features

ProLiant BL20p and p-Class system

Compaq ProLiant BL p-Class Server Blade Enclosure and Interconnects



OS Support

Intelligent Manageability

Availability

Microsoft LINUX Microsoft .NET Server

Note: For a more complete and up-to-date listing of supported OS’s and versions, please visit our OS Support

Note: For an up-to-date listing of the latest drivers available for the Compaq ProLiant BL p-Class, please see:

Note: These Web sites are available in English only.

Integrated Lights-Out Advanced (iLO)

Automatic Server Recovery-2 (ASR-2) Compaq Insight Manager 7 Redundant ROM Remote Flash ROM ROM Based Setup Utility (RBSU) Advanced Configuration and Power Interface Specification Ready (ACPI) Server Health Logs Compaq Redundant Power Supply Utility Pre-Failure Warranty (covers processors, as well as hard drives and memory) Compaq Interconnect Switch Management System and Utilities (interconnect switch option) Integrated Management Log (IML) Off-Line Backup Processor capability Dynamic sector repairing and drive parametre tracking (with Smart Array controllers) Redundant/adaptive load balancing NIC Support

* Advanced features such as Graphical Remote Console and Virtual Floppy are included with the BL p-Class

server.

Power redundancy: Redundant AC feeds into power enclosures, redundant DC feeds from power enclosure to

server blade enclosures, 1 + 1 redundant power supplies

Two hot-plug SCSI hard drive bays and integrated RAID (Smart Array 5i) on every server blade (Battery-backed write cache is optional.)

Redundant ROM on each server blade ECC Memory Interconnects Switch Availability

Network adapter teaming (network fault tolerance, transmit load balancing, switch-assisted load balancing)

Windows 2000



(Red Hat and SuSE)

Matrix at: ftp://ftp.compaq.com/pub/products/servers/os-support-matrix-310.pdf

http://www.compaq.com/support/files/server/us/index.html

Virtual Text and Graphical Remote Console * Virtual Floppy * Virtual Power Button Control Dedicated LAN Connectivity Automatic IP Configuration via DHCP/DNS/WINS Industry Standard 128-bit Secure Sockets Layer (SSL) Security IML and iLO Event Logging Support for 12 user accounts with customizable access privileges

Hot-plug and hot- remove with configuration retention capability Two network connections per server blade bay (four NICs total) routed to two redundant interconnect switches Redundant inter-switch communication with two sets of redundant uplink ports per each interconnect switch IEEE 802.1D Spanning tree protocol support for loop-free path redundancy Static IEEE 802.3ad (EtherChannel compatible) trunking with automatic port load balancing

(continued)

DA-11411 Canada — Version 1 — August 26, 2002

QuickSpecs

Standard Features

ProLiant BL20p and p-Class system

Compaq ProLiant BL p-Class Server Blade Enclosure and Interconnects

Security

Minimum Rack Requirements

Rack Airflow Requirements

Note: For additional information, refer to the Setup and Installation Guide or the Documentation CD provided with

Power-on password Administrator's password Integrated Lights-Out has 12 customizable user accounts and SSL encryption Integrated Lights-Out can be disabled via a Global Setting Interconnect Switch multilevel user names and passwords and management interface time out period setting Up to 64 Port-based IEEE 802.1Q tagged VLANs per interconnect switch

Mounts in Compaq, and Telco racks and Third Party racks that meet the following criteria:

• Compatible with 19-inch Standard EIA rail sets

• EIA rail-to-rail depth is 29 − 30″

• Cabinet depth must be at least 36-inch deep overall (Additional min. 3.5-inch clearance from rear

RETMA rail to rear door, inclusive in the 36-inch overall depth)

• Ample room for top and bottom cable egress (approximately 8 square inches for full rack configuration

with patch panel)

• Must be capable of supporting 1600 lb (for full rack configuration)

• Perforated front and rear doors to accommodate front-to-back cooling

• Must have 65% open perforation on server blade enclosure doors to support airflow requirements

• Optimized for use with the Compaq 10000 Series racks

Note: If using Compaq 7000 Series rack, Compaq Rack Extension Kit and High Air Flow Rack Door options are

required.

• Rack 9000 and 10000 series Cabinets

The increasing power of new high-performance processor technology requires increased cooling efficiency for rack-mounted servers. The Compaq 9000 Series Rack and the new 10000 Series Racks provides enhanced airflow for maximum cooling, allowing these racks to be fully loaded with servers using the latest processors.

• Rack 7000 series Cabinets

When installing a server with processors running at speeds of 550 MHz or greater in Compaq Rack 7000 series racks with glass doors (165753-001 (42U), and 163747-001 (22U)), the new processor technology requires the installation of Compaq’s new High Airflow Rack Door Inserts (327281-B21 (42U), 327281-B22 (42U 6 pack), or 157847-B21 (22U)) to promote enhanced airflow for maximum cooling.

CAUTION: If a third-party rack is used, observe the following additional requirements to ensure adequate airflow

CAUTION: Always use blanking panels to fill all remaining empty front panel U-spaces in the rack. This

and to prevent damage to the equipment:

o Front and rear doors:

allow 830 square inches (5,350 sq cm) of hole evenly distributed from top to bottom to permit adequate airflow (equivalent to the required 64 percent open area for ventilation).

o Side:

arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling that can lead to thermal damage.

the server, or to the server documentation located in the Support section at the following URL:

http://www5.compaq.com/products/servers/proliantdl380/index.html

Note: This Web site is available in English only.

The clearance between the installed rack component and the side panels of the rack must

be a minimum of 2.75 inches (7 cm)

If your 42U server rack includes closing front and rear doors, you must

(continued)

DA-11411 Canada — Version 1 — August 26, 2002

QuickSpecs

Standard Features

ProLiant BL20p and p-Class system

Compaq ProLiant BL p-Class Server Blade Enclosure and Interconnects

Service and Support

Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Centre at 1-800-567-1616

Compaq Services provides a three-year, limited warranty, including Pre-Failure Warranty (coverage of hard drives, memory and processors) fully supported by a worldwide network of resellers and service providers. Compaq technical assistance is available 7x24, toll free in the United States and Canada. Telephone support services may be covered under warranty or available for an additional fee.

Note: Limited Warranty includes 3 year Parts, 3 year Labour, 3-year on-site support.

A full range of CarePaq packaged hardware and software services:

• Installation and start up

• Extended coverage hours and enhanced response times

• System management and performance services

• Availability and recovery services

Note: For more information, customer/resellers can contact

http://www.compaq.com/services

Please see the following URL regarding Warranty Information For Your Compaq Products:

http://www.compaq.com/support/warranty_upgrades/web_statements/176738.html

For additional information regarding Worldwide Limited Warranty and Technical Support, please see the following URL: ftp://ftp.compaq.com/pub/supportinformation/ejourney/176738.pdf. Note: These Web sites are available in English only.

for details.

(continued)

DA-11411 Canada — Version 1 — August 26, 2002

QuickSpecs

Models

ProLiant BL20p and p-Class system

ProLiant BL20p P1400-512KB, 512MB (1P) 230040-B21

Network Controller

Form Factor

ProLiant BL20p P1400-512KB, 1GB (2P)

257959-B21

Network Controller

Processor(s) Cache Memory Memory

Storage Controller Hard Drives Internal Storage Optical Drive

Processor(s) Cache Memory Memory

Storage Controller Hard Drives Internal Storage Optical Drive Form Factor

(1) Intel Pentium III 1.40 GHz standard (up to 2 supported) 512-KB Level 2 writeback per processor 512 MB (Standard) to 4096 MB PC133-MHz Registered ECC SDRAM DIMM

Memory Three Compaq NC3163 Fast Ethernet NIC PCI 10/100 with full WOL (Wake On

LAN); one NIC has PXE support One additional 10/100 port dedicated to iLO Management

Smart Array 5i Controller (integrated on system board) None ship standard Up to 145.6-GB maximum (with optional hard drives) None Plugs vertically into Compaq ProLiant BL p-Class Server Blade Enclosure

(2) Intel Pentium III 1.40 GHz standard (up to 2 supported) 512-KB Level 2 writeback per processor 1024 MB (Standard) to 4096 MB PC133-MHz Registered ECC SDRAM DIMM

Memory Three Compaq NC3163 Fast Ethernet NIC PCI 10/100 with full WOL (Wake On

LAN); one NIC has PXE support One additional 10/100 port dedicated to iLO Management

DA-11411 Canada — Version 1 — August 26, 2002

QuickSpecs

Options

ProLiant BL20p and p-Class system

ProLiant BL20p Unique Options

ProLiant BL p-Class RJ-45 Patch panel (pair)

ProLiant BL p-Class F-GbE Interconnect Kit (with pair of GbE Interconnect Switches

Single Phase Redundant Power with 4 power supplies

3 Phase Redundant Power with 6 power supplies Single Phase Power Enclosure (empty) 3 Phase Power Enclosure (empty) Single Power Supply Facility DC Power Connection

ProLiant p-Class Scalable Bus Bar

ProLiant p-Class Bus Power Box

ProLiant Essentials Value Pack Software

Processor Pentium lll P1400-512KB Processor Option Kit 234277-B21

Memory (SDRAM DIMMs) 2048 MB PC133MHz Registered ECC SDRAM Memory Kit (2x1024 MB)

Dual NC7780 Gigabit Upgrade Module for ProLiant BL20p

Note: The Dual NC7780 Gigabit Upgrade Module replaces two of the standard NC3163

Fast Ethernet Embedded WOL (Wake On LAN) NICs to two 10/10/1000T NC7780 NICs.

Note: The GbE Interconnect Switch options support server NIC speeds to 100 Mbps. It

is recommended that the patch panel be used with the Dual NC7780 Gigabit Upgrade Module if server NIC speeds to 1000 Mbps are required.

ProLiant BL p-Class Server Blade Enclosure (ProLiant Essentials Rapid Deployment Pack Trial)

ProLiant BL p-Class Server Blade Enclosure (8 ProLiant Essentials Rapid Deployment Pack Licenses)

Note: Only one interconnect kit required per server blade enclosure.

ProLiant BL p-Class C-GbE Interconnect Kit (with pair of GbE Interconnect Switches and two QuadT Interconnect Modules)

Note: Only one interconnect kit required per server blade enclosure.

and two DualTSX Interconnect Modules)

Note: Only one interconnect kit required per server blade enclosure.

ProLiant p-Class Mini Bus Bar

Rapid Deployment Pack, 10 User, V1.x

Note: This license allows 10 servers to be managed and deployed via the Deployment

Server.

Note: Not necessary if you purchase the server blade enclosure with 8 Rapid

Deployment Pack licenses 281404-B21.

Rapid Deployment Pack, 1 User, V1.x

Note: This license allows 1 server to be managed and deployed via the Deployment

Server. Note: Not necessary if you purchase the server blade enclosure with 8 Rapid

Deployment Pack licenses 281404-B21.

ProLiant Essentials Workload Management Pack (Featuring Compaq Resource Partitioning Manager version 1.1)

Note: For more information regarding ProLiant Essentials Software, please see the following URL:

http://www.compaq.com/proliantessentials

Note: Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs. Refer to URL

http://www.compaq.com/proliantessentials

QuickSpecs for more information. Note: These Web sites are available in English only.

1024 MB PC133MHz Registered ECC SDRAM Memory Kit (2x512 MB) 512 MB PC133MHz Registered ECC SDRAM Memory Kit (2x256 MB) 256 MB PC133MHz Registered ECC SDRAM Memory Kit (2x128 MB)

or the various ProLiant Essentials Value Pack product

230255-B21

243564-B21

281404-B21

230766-B21

249655-B21

279720-B21

239162-001 230769-001 231710-001

231709-001 239161-B21 240563-B21 240560-B21

240559-B21 240562-B21

269817-B21

267196-B21

266988-B21

201695-B21 201694-B21 201693-B21 201692-B21

DA-11411 Canada — Version 1 — August 26, 2002

QuickSpecs

Options

ProLiant BL20p and p-Class system

Hard Drives

Storage Controllers Battery Backed Write Cache Enabler Option Kit

Communications Dual NC7780 Gigabit Upgrade Module for ProLiant BL20p 230255-B21

BL p-Class Server Blade Enclosures

BL p-Class Interconnects ProLiant BL p-Class RJ-45 Patch panel (pair)

ProLiant BL p-Class F-GbE Interconnect Kit (with pair of GbE Interconnect Switches

BL p-Class Power options Single Phase Redundant Power with 4 power supplies

3 Phase Redundant Power with 6 power supplies Single Phase Power Enclosure (empty) 3 Phase Power Enclosure (empty) Single Power Supply Facility DC Power Connection

Power Distribution ProLiant p-Class Scalable Bus Bar

ProLiant p-Class Bus Power Box

Diagnostic Options ProLiant p-Class Diagnostic Station

Wide Ultra3 SCSI – Universal Hot Plug

72.8-GB Wide Ultra3 SCSI 10,000 rpm Drive (1″)

36.4-GB Wide Ultra3 SCSI 10,000 rpm Drive (1″)

18.2-GB Wide Ultra3 SCSI 10,000 rpm Drive (1″)

36.4-GB Wide Ultra3 SCSI 15,000 rpm Drive (1″)

18.2-GB Wide Ultra3 SCSI 15,000 rpm Drive (1″)
