Page 1
ProLiant ML350 Generation 2 Server
Tower-to-Rack Conversion Guide
First Edition (August 2001)
Part Number 236991-001
Compaq Computer Corporation
Page 2
Notice
© 2001 Compaq Computer Corporation
Compaq, the Compaq logo, and ProLiant Registered in U.S. Patent and Trademark Office.
All other product names mentioned herein may be trademarks of their respective companies.
Compaq shall not be liable for technical or editorial errors or omissions contained herein. The
information in this document is provided “as is” without warranty of any kind and is subject to change
without notice. The warranties for Compaq products are set forth in the express limited warranty
statements accompanying such products. Nothing herein should be construed as constituting an
additional warranty.
Compaq ProLiant ML350 Generation 2 Server
Tower-to-Rack Conversion Guide
First Edition (August 2001)
Part Number 236991-001
Page 3
Contents
About This Guide
Server Name ................................................................................................................v
Text Conventions........................................................................................................vi
Symbols in Text.........................................................................................................vii
Symbols on Equipment..............................................................................................vii
Important Safety Information .......................................................................... viii
Rack Stability .............................................................................................................ix
Getting Help ...............................................................................................................ix
Compaq Technical Support .................................................................................ix
Compaq Website ..................................................................................................x
Compaq Authorized Reseller................................................................................x
Chapter 1
Preparing the Server
Unpacking and Identifying Conversion Kit Contents.............................................. 1-2
Powering Down the Server...................................................................................... 1-3
Removing Tower-Specific Chassis Components..................................................... 1-4
Removing the Bezel Door ................................................................................ 1-5
Removing the Feet............................................................................................ 1-6
Removing the Locking Brackets ...................................................................... 1-7
Removing the Tower Configuration Panel....................................................... 1-9
Setting the System Configuration Switch....................................................... 1-10
Installing Rack-Mountable-Specific Chassis Components.................................... 1-10
Installing the Rack-Mount Front Panel........................................................... 1-11
Installing Component Rails on the Server ...................................................... 1-12
Installing the Cable Management Arm Bracket.............................................. 1-14
Page 4
iv Compaq ProLiant ML350 Generation 2 Server Tower-to-Rack Conversion Guide
Chapter 2
Rack Installation
Rack Warnings and Precautions............................................................................... 2-2
Server Warnings and Precautions ............................................................................ 2-2
Optimum Environment ............................................................................................ 2-3
Space Requirements.......................................................................................... 2-3
Power Requirements......................................................................................... 2-4
Grounding Requirements.................................................................................. 2-4
Temperature Requirements............................................................................... 2-5
Airflow Requirements....................................................................................... 2-6
Securing the Mounting Hardware to the Server and Rack....................................... 2-6
Marking with the Template............................................................................... 2-7
Inserting Cage Nuts into the Rack Frame ......................................................... 2-8
Securing the Slide Rail to the Mounting Bracket.............................................. 2-9
Installing the Mounting Bracket Slide Assembly ........................................... 2-11
Installing the Server into the Rack......................................................................... 2-13
Installing the Cable Management Arm .................................................................. 2-15
Cabling the Server.................................................................................................. 2-17
Appendix A
Electrostatic Discharge Information
Preventing Electrostatic Discharge ......................................................................... A-1
Grounding Methods ................................................................................................ A-2
Index
Page 5
This guide is designed to be used as step-by-step instructions for installation
and as a reference for operation, troubleshooting, and future upgrades for the
Compaq ProLiant ML350 Generation 2 server.
Server Name
A generation identifier (G2) located on the front of the server indicates the
model of the server purchased. The generation identifier is required to
accurately identify the model for service and support. Throughout the user
documentation, G2 and Generation 2 are used interchangeably.
About This Guide
Page 6
vi Compaq ProLiant ML350 Generation 2 Server Tower-to-Rack Conversion Guide
Text Conventions
This document uses the following conventions to distinguish elements of text:
Keys Keys appear in boldface. A plus sign (+) between
two keys indicates that they should be pressed
simultaneously.
USER INPUT User input appears in a different typeface and in
uppercase.
FILENAMES File names appear in uppercase italics.
Menu Options,
Command Names,
Dialog Box Names
COMMANDS,
DIRECTORY NAMES,
and DRIVE NAMES
Type When you are instructed to type information, type
Enter When you are instructed to enter information, type
These elements appear in initial capital letters and
may be displayed in boldface for emphasis.
These elements appear in uppercase and may be
displayed in boldface for emphasis.
the information without pressing the Enter key.
the information, and then press the Enter key.
Page 7
Symbols in Text
These symbols may be found in the text of this guide. They have the following
meanings.
WARNING: Text set off in this manner indicates that failure to follow directions
in the warning could result in bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions
could result in damage to equipment or loss of information.
IMPORTANT: Text set off in this manner presents clarifying information or specific
instructions.
NOTE: Text set off in this manner presents commentary, sidelights, or interesting points
of information.
Symbols on Equipment
About This Guide vii
The following symbols may be placed on equipment to indicate the presence
of potentially hazardous conditions:
This symbol in conjunction with any of the following symbols indicates the
presence of a potential hazard. The potential for injury exists if warnings
are not observed. Consult your documentation for specific details.
This symbol indicates the presence of hazardous energy circuits or electric
shock hazards. Refer all servicing to qualified personnel.
WARNING: To reduce the risk of injury from electric shock hazards, do not
open this enclosure. Refer all maintenance, upgrades, and servicing to
qualified personnel.
This symbol indicates the presence of electric shock hazards. The area
contains no user- or field-serviceable parts. Do not open for any reason.
WARNING: To reduce the risk of injury from electric shock hazards, do
not open this enclosure.
Page 8
viii Compaq ProLiant ML350 Generation 2 Server Tower-to-Rack Conversion Guide
This symbol on an RJ-45 receptacle indicates a network interface
connection.
WARNING: To reduce the risk of electric shock, fire, or damage to the
equipment, do not plug telephone or telecommunications connectors into
this receptacle.
This symbol indicates the presence of a hot surface or hot component. If
this surface is contacted, the potential for injury exists.
WARNING: To reduce the risk of injury from a hot component, allow the
surface to cool before touching it.
These symbols on power supplies or systems indicate that the
equipment is supplied by multiple sources of power.
WARNING: To reduce the risk of injury from electric shock,
remove all power cords to completely disconnect power from
the system.
This symbol indicates that the component exceeds the recommended
weight for one individual to handle safely.
Weight in kg
Weight in lb
WARNING: To reduce the risk of personal injury or damage to the
equipment, observe local occupational health and safety requirements and
guidelines for manual material handling.
Important Safety Information
Before installing this product, read the Important Safety Information document
provided.
Page 9
Rack Stability
Getting Help
If you have a problem and have exhausted the information in this guide, you
can get further information and other help in the following locations.
About This Guide ix
WARNING: To reduce the risk of personal injury or damage to the equipment,
be sure that:
■ The leveling jacks are extended to the floor.
■ The full weight of the rack rests on the leveling jacks.
■ The stabilizing feet are attached to the rack if it is a single-rack
installation.
■ The racks are coupled together in multiple-rack installations.
■ Only one component is extended at a time. A rack may become unstable if
more than one component is extended for any reason.
Compaq Technical Support
In North America, call the Compaq Technical Support Phone Center at
1-800-OK-COMPAQ. This service is available 24 hours a day, 7 days a week.
For continuous quality improvement, calls may be recorded or monitored.
Outside North America, call the nearest Compaq Technical Support Phone
Center. Telephone numbers for worldwide Technical Support Centers are
listed on the Compaq website. Access the Compaq website by logging on to
the Internet at
www.compaq.com
Page 10
x Compaq ProLiant ML350 Generation 2 Server Tower-to-Rack Conversion Guide
Be sure to have the following information available before you call Compaq:
■ Technical support registration number (if applicable)
■ Product serial number
■ Product model name and number
■ Applicable error messages
■ Add-on boards or hardware
■ Third-party hardware or software
■ Operating system type and revision level
Compaq Website
The Compaq website has information on this product as well as the latest
drivers and flash ROM images. You can access the Compaq website by
logging on to the Internet at
www.compaq.com
Compaq Authorized Reseller
For the name of your nearest Compaq authorized reseller:
■ In the United States, call 1-800-345-1518.
■ In Canada, call 1-800-263-5868.
■ Elsewhere, see the Compaq website for locations and telephone
numbers.
Page 11
Chapter 1
Preparing the Server
This chapter provides instructions to prepare a Compaq ProLiantä ML350
Generation 2 server to be mounted into a Compaq 19-inch-wide rack.
To mount the server into a rack, you need the following tools:
■ Torx T-15 screwdriver
■ Phillips screwdriver
Preparing the server involves the following steps:
1. Unpacking and identifying conversion kit contents
2. Powering down the server
3. Removing tower-specific chassis components
4. Installing rack-mountable-specific chassis components
IMPORTANT: As with any upgrade, be sure that you have created a backup of all your
data before you begin.
Page 12
1-2 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
Unpacking and Identifying Conversion Kit Contents
Unpack the conversion kit. Check the kit contents against Figure 1-1 and
Table 1-1 to ensure that you have all the components and assembly hardware.
5
6
ProLiant ML350 Tower
to Rack Install Guide
8
11
Figure 1-1. Conversion kit contents
1
4
2
9
3
7
10
Page 13
Table 1-1
Conversion Kit Contents
Item Description Item Description
Preparing the Server 1-3
Bar nut
Cable management arm
mounting bracket
Cable management arm bracket
Template
Rack-mount front panel
Documentation
Powering Down the Server
To power down the server:
1. Schedule downtime for the server upgrade.
2. Perform a system backup of your server according to your operating
system requirements.
3. Power down your server according to your network operating system
requirements.
4. Power down the server, and then power down all peripheral devices.
CAUTION: Never power down a storage system unless the server controlling it
has been powered down first. Powering down the storage system first causes
the controller to mark the drives as failed.
Screws and cage nuts (6 bags)
Slide rail assemblies
Rail mounting brackets
Tiewraps
Cable management arm
5. Disconnect the AC power cord from the AC outlet, and then from the
server.
6. Label and disconnect all cables connected to the back of the server.
Page 14
1-4 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
Removing Tower-Specific Chassis Components
Before beginning these procedures, make sure that you understand the
following precautions.
WARNING: To reduce the risk of personal injury from hot surfaces, allow the
hard drives and internal system components to cool before touching them.
CAUTION: Electrostatic discharge (ESD) can damage electronic components.
Refer to Appendix A for ESD information before you remove or install server
parts.
When you convert a ProLiant ML350 Generation 2 tower model server to a
rack-mountable model, you must first remove the following components:
■ Bezel door
■ Feet
■ Locking bracket
■ Tower configuration panel
After removing the components, it is necessary to set the system board switch
to a rack configuration. See “Setting the System Configuration Switch” later in
this chapter for detailed instructions.
Page 15
Removing the Bezel Door
To remove the bezel door:
1. If the keylock is locked, unlock it using the included key
2. Swing the bezel door open, and then lift it up and away from the
chassis
.
Preparing the Server 1-5
.
3
1
2
Figure 1-2. Removing the bezel door
NOTE: The bezel door of the server may look different depending on the model
purchased.
Page 16
1-6 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
Removing the Feet
To remove the feet:
1. Turn the server upside down.
2. Remove the screw from the center of one of the feet
3. Lift up the outside edge of the foot
2
Figure 1-3. Removing the feet
, and then remove the foot.
1
3
4. Repeat this procedure with the other three feet.
.
Page 17
Removing the Locking Brackets
To remove the locking brackets:
1. Loosen the two thumbscrews located on the left side of the front
chassis
2. Slide the access panel back about 1.5 cm (0.5 inch), and then pull the
access panel away from the chassis to remove it
.
2
Preparing the Server 1-7
.
1
Figure 1-4. Removing the access panel
Page 18
1-8 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
3. Disengage the locking brackets, and then remove them by pulling
.
out
Figure 1-5. Removing the locking brackets
NOTE: The interior of the server may look different depending on the model purchased.
1
1
2
Page 19
Removing the Tower Configuration Panel
The tower configuration panel covers the indentations in the server chassis that
are used to secure the mounting rails. To remove the tower configuration
panel:
1. Lay the server on its side with the tower configuration panel facing up.
Preparing the Server 1-9
2. Using a Torx T-15 screwdriver, remove the two retaining screws
indicated in Figure 1-6.
3. Slide the panel back, and then up
.Youmayneedtoexertasmall
amount of force to release the panel from the chassis.
1
2
Figure 1-6. Removing the tower configuration panel
,as
Page 20
1-10 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
Setting the System Configuration Switch
Switch 3 on the system configuration switch is the rack configuration switch.
To enable this switch setting, set switch 3 to the on position, as shown in
Figure 1-7.
5 678
on
Figure 1-7. Setting the system configuration switch
1 234
Installing Rack-Mountable-Specific Chassis Components
You must install the following components onto the server before installing
the server in the rack:
■ Rack-mount front panel
■ Component rails
■ Cable management arm bracket
Page 21
Installing the Rack-Mount Front Panel
To install the rack-mount front panel:
1. Align the pins on the front panel with the corresponding slots on the
chassis.
Figure 1-8. Installing the rack-mount front panel
2. Secure the front panel to the chassis by tightening the thumbscrews.
Preparing the Server 1-11
Figure 1-9. Securing the rack-mount front panel
3. Reinstall the access panel, and then tighten the thumbscrews.
Page 22
1-12 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
Installing Component Rails on the Server
Your conversion kit includes a set of 22-inch slide rail assemblies. A slide rail
assembly consists of:
■ A component rail that is mounted to the server or component being
installed
■ A slide rail, which is the mechanism that accepts the component rail and
is mounted to the rail mounting bracket
The component rails are installed into the slide when shipped and must be
removed before the component rails can be mounted to the server.
To remove the component rail from the slide:
1. Extend the component rail from the slide until the component rail
release latch clicks
.
2. Holding down the latch, pull the component rail out of the slide
may need to give the rail a sharp tug to disengage it from the slide.
2
Figure 1-10. Removing the component rail from the slide
1
.You
Page 23
Preparing the Server 1-13
To install the component rails onto the server:
1. Place the tab of one component rail at the front of the server chassis.
The holes in the component rail line up only one way with the chassis.
2. Secure the flat side of the component rail to each side of the server
chassis with three 8-32 x 1/4-inch Phillips screws (supplied). Do not use
washers or other screws.
3. Repeat this procedure on the other side of the server using the second
component rail.
Figure 1-11. Installing a component rail on the server
Page 24
1-14 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
Installing the Cable Management Arm Bracket
The cable management arm bracket allows you to secure the cable
management arm to the server and to the rear frame of the rack.
To install the cable management arm bracket:
1. Locate the two bracket screws (Part Number 192308-002) included with
your kit.
2. Using a Torx T-15 screwdriver and the two bracket screws, secure the
cable management arm bracket to the back of the server, as illustrated in
Figure 1-12.
Figure 1-12. Securing the cable management arm bracket to the server
NOTE: The rear of the server may look different depending on the model purchased.
When you have completed the procedures in this chapter, proceed to
Chapter 2, “Rack Installation.”
Page 25
Chapter 2
Rack Installation
This chapter provides the procedures required to install the prepared Compaq
ProLiant ML350 Generation 2 server into a Compaq 19-inch-wide rack.
Installing the prepared server into the rack requires the following steps:
■ Securing the mounting hardware to the server and rack
■ Installing the server into the rack
■ Securing the cable management arm
■ Cabling the server
Page 26
2-2 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
Rack Warnings and Precautions
Before beginning these procedures, read and understand the following
statements.
WARNING: To avoid the risk of personal injury or damage to the equipment, at
least two people are needed to safely unload the rack from the pallet. An empty
42U rack weighs 115 kg (253 lb), is over 2.1 m (7 ft) tall, and may become
unstable when being moved on its casters. Do not stand in front of the rack as it
rolls down the ramp from the pallet, but handle it from the sides.
WARNING: To reduce the risk of personal injury or damage to the equipment,
be sure that:
■ The leveling jacks are extended to the floor.
■ The full weight of the rack rests on the leveling jacks.
■ The stabilizing feet are attached to the rack if it is a single-rack
installation.
■ The racks are coupled together in multiple-rack installations.
■ Only one component is extended at a time. A rack may become unstable if
more than one component is extended for any reason.
Server Warnings and Precautions
Before beginning these procedures, read and understand the following
statements.
WARNING: To avoid the risk of personal injury or damage to the equipment, a
minimum of two people MUST lift the server into the rack. The server weighs
about 27.24 kg (60 lb). If the unit is to be loaded above chest level, a third
person must assist in aligning the rails while the other two support the unit.
WARNING: To reduce the risk of personal injury from hot surfaces, allow the
hot-plug drives and internal system components to cool before touching them.
Page 27
Rack Installation 2-3
WARNING: This equipment is designed for connection to a grounded (earthed)
AC outlet. The grounding-type plug is an important safety feature. To avoid risk
of electric shock or damage to your equipment, do not disable this feature.
CAUTION: The rack-mountable ProLiant ML350 Generation 2 server
always be operated with the access panel on. Proper cooling cannot be
achieved if the access panel is removed.
Optimum Environment
When installing your ProLiant ML350 Generation 2 server into a rack, the
following requirements must be met:
■ Space
■ Power
■ Grounding
■ Temperature
■ Airflow
Space Requirements
To allow for servicing and adequate airflow, observe the following spatial
requirements when selecting a site for your rack-mounted server:
■ Leave a minimum clearance of 63.5 cm (25.0 inches) in front of the
rack.
must
■ Leave a minimum clearance of 76.2 cm (30.0 inches) behind the rack.
■ Leave a minimum clearance of 121.9 cm (48.0 inches) from the back of
the rack to the back of another rack or row of racks.
Page 28
2-4 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
Power Requirements
WARNING: To reduce the risk of personal injury, fire, or damage to the
equipment, do not overload the AC supply branch circuit that provides power to
the rack. Consult the electric authority having jurisdiction over your facility
wiring and installation requirements.
The installation of this equipment shall be in accordance with local/regional
electric regulations governing the installation of information technology
equipment by licensed electricians. This equipment is designed to operate in
installations covered by NFPA 70-1999 (National Electric Code) and
NFPA-75, 1992 (code for Protection of Electronic Computer/Data Processing
Equipment). For electric power ratings on options, refer to the product rating
label or user documentation supplied with that option.
When installing more than one server, it may be necessary to utilize additional
power distribution devices to safely provide power to all devices.
■ Balance the power load between available AC supply branch circuits.
■ The overall system AC current load must not exceed 80 percent of the
AC supply branch circuit current rating.
Grounding Requirements
To ensure proper operation and safety, the server must be properly grounded
(earthed). In the United States, install the equipment in accordance with NFPA
70-1999 (National Electric Code) Article 250 as well as any local and regional
building codes. In Canada, install the equipment in accordance with Canadian
Standards Association, CSA C22.1, Canadian Electric Code. In all other
countries, follow any regional or national electric wiring codes such as the
International Electrotechnical Commission (IEC) 364 parts 1 through 7.
Furthermore, you must ensure that all power distribution devices used in the
installation—such as branch wiring and receptacles—are Listed or Certified
grounding-type devices.
Because of the high ground-leakage currents associated with multiple servers
connected to the same power source, Compaq recommends the use of a power
distribution unit (PDU) that is either permanently wired to the building branch
circuit or is provided with a nondetachable cord that is wired to an
industrial-style plug. NEMA locking-style plugs or those complying with IEC
60309 are considered suitable for this purpose. Compaq does not recommend
using common power outlet strips for this equipment.
Page 29
Temperature Requirements
To ensure continued safe and reliable operation of the equipment, install or
place the system in a well-ventilated, climate-controlled environment.
The Compaq Maximum Recommended Ambient Operating Temperature
(TMRA) for most server products is 35°C (95°F). The temperature in the room
where the rack is located should not exceed
The operating temperature inside the rack is always higher than the room
temperature and is dependent on the configuration of equipment in your rack.
The TMRA for each piece of equipment should be checked before installation.
The maximum internal rack temperature for your configuration should not
exceed the values shown in the following table.
Internal Rack Temperature Maximums
Equipment Included Internal Rack Temperature Maximum
Rack-mountable ProLiant servers 47°C/122°F
Compaq rack-mountable options 40°C/104°F
Other manufacturer options See other manufacturer specifications
Rack Installation 2-5
35°C (95°F).
Table 2-1
CAUTION: To reduce the risk of damage to the equipment when installing
third-party options:
■ Make sure that the option equipment does not impede airflow to the
rack-mountable ProLiant servers or increase the internal rack temperature
beyond the maximum rating specified by Compaq.
■ Make sure that the Manufacturer Maximum Recommended Ambient
Operating Temperature of the option equipment is not exceeded when
installed into the rack.
Page 30
2-6 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
Airflow Requirements
The ProLiant ML350 Generation 2 server draws cool air in through the front
of the chassis and exhausts warm air out through the rear of the chassis.
Therefore, the front of the rack must be adequately ventilated to allow ambient
room air to enter the cabinet, and the rear door must be adequately ventilated
to allow the warm air to escape from the cabinet.
IMPORTANT: Do not block the ventilation openings.
When there is any vertical space in the rack not filled by a server or rack
component, the gaps between the components cause changes in airflow
through the rack and across the servers. Cover all gaps with blanking panels to
maintain proper airflow.
CAUTION: Always use blanking panels to fill empty vertical spaces in the rack.
This arrangement ensures proper airflow. Using a rack without blanking panels
results in improper cooling that can lead to thermal damage.
Compaq 9000 Series racks provide proper server cooling from flow-through
perforations, ensuring 64 percent open area for ventilation. Refer to the
documentation provided with Compaq 7000 Series racks for guidelines on
meeting airflow requirements.
CAUTION: When using a Compaq 7000 Series rack, you must install the
high-airflow rack door insert [Part Number 327281-B21 (42U) and Part Number
157847-B21 (22U)] to provide proper front-to-back airflow and cooling and
prevent damage to the equipment.
Securing the Mounting Hardware to the Server and Rack
Securing the mounting brackets and slide rail assemblies consists of the
following:
■ Marking the server rack position with the template
■ Installing cage nuts into the rack frame
■ Securing the slide rail to the mounting bracket
■ Installing the mounting bracket slide assembly onto the rack
Page 31
Marking with the Template
A template is provided to mark the rack for cage nut and mounting bracket
positions. Starting at the bottom of the rack or at the top of a previously
mounted component:
1. With the two push tabs, place the template in the desired location. Make
sure that you match the hole pattern printed on the template with the
actual holes on the rack vertical rails.
Template
Rack Installation 2-7
Template
Figure 2-1. Using the template
2. Use a pencil to mark locations indicated on the template for cage nuts
and mounting brackets.
3. After marking the front of the rack, flip the template over, and then
repeat the procedure on the back rails of the rack. Also mark the top of
the template on the rack to help align the next components.
Page 32
2-8 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
Inserting Cage Nuts into the Rack Frame
Use the fitting tool to insert cage nuts on the inside of the rails at the marked
locations. Make sure to install two cage nuts at the front of the rack and two
cage nuts at the back of the rack.
NOTE: The cage nuts and fitting tool are included in the hardware kit supplied with the
rack.
1. On the inside of the rail, hook one of the lips of the cage nut through the
square rail hole.
2. Insert the tip of the fitting tool through the other side of the hole, and
then hook the opposite lip of the cage nut.
Figure 2-2. Inserting cage nuts
3. Using the fitting tool as a lever, slide the cage nut lip into position.
4. Repeat this procedure for each cage nut.
Page 33
Securing the Slide Rail to the Mounting Bracket
The mounting bracket and slide rail form an assembly that secures to the rack.
To secure the slide rail to the mounting bracket:
1. Lay a slide rail inside a mounting bracket, making sure that the front of
the slide rail is at the front of the mounting bracket. To identify the front
of the mounting bracket and the bracket rail:
GThe front of the mounting bracket has screw threads on its flange.
GThe front of the slide rail allows the inner slide to move forward.
Rack Installation 2-9
Figure 2-3. Identifying the front of the slide rail and the mounting bracket
2. Align the front screw holes in the slide rail and the mounting bracket.
Page 34
2-10 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
3. Fasten the slide rail to the mounting bracket using three 8-32 x 1/4-inch
slotted screws (supplied). Adjust the inner slide to access the screw
holes through the slotted opening in the inner slide, and then insert the
screws, asshowninFigure2-4.
1
2
Figure 2-4. Securing the slide rail to the mounting bracket
4. Repeat steps 1 through 3 for the other slide rail and mounting bracket.
Page 35
Installing the Mounting Bracket Slide Assembly
To install the mounting bracket slide assembly:
1. Position the mounting bracket according to the pencil marks made with
the template earlier.
2. Secure the front of the mounting bracket first, using an M6 x 1.0-12L
Phillips screw in the bottom hole of the bracket. Do not use washers.
Rack Installation 2-11
Figure 2-5. Securing the mounting bracket slide assembly to the front of the
rack
IMPORTANT: Do not tighten the mounting bracket screws completely until after the
server is inserted into the rack. A small amount of play helps position the brackets to the
exact width of the component being installed.
Page 36
2-12 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
3. Secure the back of the mounting bracket with an M6 x 1.0-12L Phillips
screwandthecagenut.
IMPORTANT: Make sure that the mounting bracket is level from front to back.
Figure 2-6. Securing the mounting bracket slide assembly to the back of
the rack
4. Repeat this process for the other mounting bracket slide assembly.
Page 37
Installing the Server into the Rack
To install the server into the rack:
WARNING: To reduce the risk of personal injury or damage to the equipment, a
minimum of two people MUST lift the server into the rack. If the unit is loaded
above chest level, a third person must assist in aligning the rails while the other
two support the unit.
1. Pull the slide rails forward from the mounting brackets until they lock
into position.
2. Carefully align the server component rails with the rack slide rails, and
then slide the server all the way into the rack.
CAUTION: Be sure to keep the component parallel to the floor when sliding the
component rails into the slide rails. Tilting the component up or down can result
in damage to the rails.
Rack Installation 2-13
Page 38
2-14 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
3. Press the component rail release latch on either side of the server,and
then slide the server into the rack
1
Figure 2-7. Loading the server into the rack
WARNING: To reduce the risk of personal injury, be careful when pressing the
component rail release latches and sliding the component into the rack. The
slide rails could pinch your fingertips.
.
2
IMPORTANT: The first time you slide the component into the rack, you may have to apply
some pressure. After the first time, the ball bearings in the slide move easily.
4. Slide the server in and out of the rack several times to properly align the
slide mount rails.
5. Tighten the mounting bracket screws.
6. Secure the server by screwing the front panel thumbscrews into the rack.
Page 39
Installing the Cable Management Arm
The cable management arm secures to the cable management arm bracket that
was previously installed. See “Installing the Cable Management Arm Bracket”
in Chapter 1. All cables running to and from the server are tied to this arm.
The cable management arm allows the cables to swing out of the way when
the server is accessed.
To install the cable management arm, follow these steps:
1. Slide the server into the rack. See “Installing the Server into the Rack”
earlier in this chapter.
2. Secure one end of the cable management arm to the cable management
arm bracket on the server using two M6 x 1.0-12L Phillips screws
(supplied).
Rack Installation 2-15
Figure 2-8. Securing the cable management arm to the bracket
NOTE: The rear of the server may look different depending on the model purchased.
3. Align the other end of the cable management arm with the outside of
the rear rack frame.
Page 40
2-16 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
4. Secure the cable management arm mounting bracketto the rear rack
frame using the bar nut
Figure 2-9. Securing the mounting bracket and bar nut to the rack frame
and two 10-32 x 5/8 screws (supplied).
1
2
5. Secure the cable management arm to the mounting bracket using two
10-32 x 5/8 screws (supplied).
Figure 2-10. Securing the cable management arm to the mounting bracket
Page 41
Cabling the Server
After the cable management arm is installed, cable the server by following
these procedures:
1. Plug all external cables into the server.
2. If you installed a switchbox into the rack, route the CPU-to-switchbox
cables to the switchbox.
3. Bundle all of the cables, including the power cable, and then secure
them to the cable management arm using the tiewraps (supplied).
Rack Installation 2-17
Figure 2-11. Routing and securing the cables
4. Extend the bundled cables down the rack cable channel.
Page 42
Appendix A
Electrostatic Discharge Information
To prevent damaging the system, be aware of the precautions you must follow
when setting up the system or handling parts. A discharge of static electricity
from a finger or other conductor may damage system boards or other
static-sensitive devices. This type of damage may reduce the life expectancy of
the device.
Preventing Electrostatic Discharge
To prevent electrostatic damage, observe the following precautions:
■ Avoid hand contact by transporting and storing products in static-safe
containers.
■ Keep electrostatic-sensitive parts in their containers until they arrive at
static-free workstations.
■ Place parts on a grounded surface before removing them from their
containers.
■ Avoid touching pins, leads, or circuitry.
■ Always be properly grounded when touching a static-sensitive
component or assembly.
Page 43
A-2 Compaq ProLiant ML350 Generation 2 Tower-to-Rack Conversion Guide
Grounding Methods
There are several methods for grounding. Use one or more of the following
methods when handling or installing electrostatic-sensitive parts:
■ Use a wrist strap connected by a ground cord to a grounded workstation
or computer chassis. Wrist straps are flexible straps with a minimum of
1 megohm
proper grounding, wear the strap snug against the skin.
■ Use heel straps, toe straps, or boot straps at standing workstations. Wear
the straps on both feet when standing on conductive floors or dissipating
floor mats.
■ Useconductivefieldservicetools.
■ Use a portable field service kit with a folding static-dissipating
work mat.
If you do not have any of the suggested equipment for proper grounding, have
a Compaq authorized reseller install the part.
NOTE: For more information on static electricity, or assistance with product installation,
contact your Compaq authorized reseller.
± 10 percent resistance in the ground cords. To provide
