Compaq 124708-001 - ProLiant Cluster - 1850, ProLiant CL1850 Software User's Manual

ProLiant CL1850

Software User Guide

First Edition (October 1999)
Part Number 157839-001
Compaq Computer Corporation

Notice

The information in this publication is subject to change without notice.
COMPAQ COMPUTER CORPORATION SHALL NOT BE LIABLE FOR TECHNICAL OR

EDITORIAL ERRORS OR OMISSIONS CONTAINED HEREIN, NOR FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE FURNISHING, PERFORMANCE, OR
USE OF THIS MATERIAL. THIS INFORMATION IS PROVIDED “AS IS” AND COMPAQ
COMPUTER CORPORATION DISCLAIMS ANY WARRANTIES, EXPRESS, IMPLIED OR
STATUTORY AND EXPRESSLY DISCLAIMS THE IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, GOOD TITLE AND AGAINST
INFRINGEMENT.

This publication contains information protected by copyright. No part of this publication may be
photocopied or reproduced in any form without prior written consent from Compaq Computer
Corporation.

© 1999 Compaq Computer Corporat ion.
All rights reserved. Printed in the U.S.A.
The software described i n t his guide is furnished under a license agreement or nondisclosure agr eement.

The software may be us ed or copied only in accordance with the t erms of the agreement.
Compaq, Deskpro, Fastart, Compaq Insi ght Manager, Systempro, Systempro/LT, ProLiant, ROMPaq,

QVision, SmartStar t, NetFlex, QuickFind, PaqFax, Pr oSignia, registered United States Patent and
Trademark Office.

Neoserver, Netelligent, Systempro/XL, SoftPaq, QuickBlank, QuickLock are trademarks and/or service
marks of Compaq Computer Corporati on.

Microsoft, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation.
Pentium is a regist er ed trademark and Xeon is a trademark of Intel Corporation.
Other product names mentioned herein may be trademarks and/or registered t rademarks of their

respective companies.

Compaq ProLiant CL1850 Software User Guide
First Edition (October 1999)
Part Number 157839-001

Contents

About This Guide

Text Conventions......................................................................................................viii

Symbols in Text..........................................................................................................ix

Symbols on Equipment...............................................................................................ix

Getting Help................................................................................................................x

Compaq Technical Support..................................................................................x

Compaq Website.................................................................................................xi

Compaq Authorized Reseller ..............................................................................xi

Chapter 1

System Setup and Configuration for Microsoft Windows NT Server 4.0, Enterprise
Edition

Configuring the System............................................................................................1-2

Preconfiguration Checks...................................................................................1-2

Configuring Server Node 1 ...............................................................................1-2

Configuring Server Node 2 ...............................................................................1-4

Manual Installation Using SmartStart ......................................................................1-5

Configuring Server Node 1 ...............................................................................1-6

Configuring Server Node 2 ...............................................................................1-7

Verifying Creation of the Cluster.............................................................................1-8

Verifying Server Node Failover........................................................................1-9

Verifying Network Client Failover .................................................................1-10

Setting Up Cluster Groups and Cluster Resources.................................................1-11

iv Compaq ProLiant CL1850 Software User Guide

Chapter 2

System Setup and Configuration for Novell NetWare

Configuring the System........................................................................................... 2-2

Preconfiguration Checks................................................................................... 2-2

Configuring the Shared Storage Array............................................................. 2-2

Configuring Server Node 1............................................................................... 2-2

Configuring Server Node 2............................................................................... 2-3

Configuring the Cluster for NetWare 4.2.................................................................2-5

Preparations for Installing NHAS..................................................................... 2-5

Installation of NHAS........................................................................................ 2-6

Verifying Functionality of the Cluster.............................................................. 2-7

Verifying Direct and NetWare Links................................................................ 2-7

Verifying Server Node Failover ....................................................................... 2-8

Configuring the Cluster for NetWare 5....................................................................2-8

Verifying NCS Cluster Creation....................................................................... 2-9

Chapter 3

CR3500 Configuration Utility

Online Help.............................................................................................................. 3-2

Before You Begin.................................................................................................... 3-2

CR3500 Configuration Utility Features ................................................................... 3-3

SCSI Connection.............................................................................................. 3-3

Serial Connection ............................................................................................. 3-4

Configuration Utility Features................................................................................. 3-6

Main Window................................................................................................... 3-6

Main Window Menu Bar.................................................................................. 3-7

Main Window Toolbar ..................................................................................... 3-7

Logical Drives window..................................................................................... 3-8

Physical Drives Window................................................................................ 3-11

Configuration Procedures...................................................................................... 3-13

Adding a Controller........................................................................................ 3-13

Configuring the CR3500 Controller ............................................................... 3-13

Adding Physical Drives.................................................................................. 3-18

Adding Logical Drives ................................................................................... 3-19

Replacing a Failed Controller......................................................................... 3-24

Replacing a Failed Drive................................................................................ 3-25

Setting a Physical Drive as a Spare ................................................................ 3-26

Deleting Logical Drives.................................................................................. 3-27

Using Configuration Files............................................................................... 3-27

Updating Firmware................................................................................................ 3-28

Upgrading from a Single Controller to Redundant Controllers............................. 3-28

Error and Warning Messages................................................................................. 3-29

Contents v

Chapter 4

Integrated Management Log

Multiple Ways of Viewing the Log..........................................................................4-2

Compaq Insight Manager..................................................................................4-2

Compaq Survey Utility......................................................................................4-3

List of Events............................................................................................................4-4

Chapter 5

System Management for Microsoft Windows NT Server 4.0, Enterprise Edition

Cluster Management Concepts Using Microsoft Windows NT ...............................5-2

Managing a Cluster without Interrupting Applications or Services..................5-2

Managing a Cluster in a Degraded Condition...................................................5-2

Managing Hardware Components of Individual Server Nodes.........................5-2

Managing Network Clients Connected to a Cluster..........................................5-3

Managing a Cluster’s Shared Storage...............................................................5-3

Remotely Managing a Cluster...........................................................................5-4

Cluster Events ...................................................................................................5-4

Compaq Insight Manager.........................................................................................5-4

Explorer Device List Screen..............................................................................5-5

Cluster Management Screen..............................................................................5-6

Cluster Shared Resources Screen......................................................................5-7

Cluster Group Hierarchy...................................................................................5-8

Filter Groups Dialog Box..................................................................................5-9

Cluster Address.................................................................................................5-9

Microsoft Cluster Administrator ............................................................................5-10

Modifying Physical Cluster Resources...................................................................5-10

Removing Shared Storage...............................................................................5-10

Adding Shared Storage....................................................................................5-11

Adding or Removing Shared Storage Drives..................................................5-12

Backing Up Your Cluster.......................................................................................5-14

Managing Cluster Performance..............................................................................5-15

Index

About This Guide

This guide is designed to be used as step-by-step instruction s for hardware and

software installation and as a reference for operation, troubleshooting, and

future upgrades.

This guide serves as a quick way for customers experienced in server

installation to install the software for the Compaq ProLiant CL1850.

Use this guide with the technical information on the configuration and

installation poster, the access panel labels, the Systems Reference Library CD,

the SmartStart and Support Software CD , and the Management CD for

complete reference source materials. Now you can also quickly access much

of the system’s co nfiguration and installa tion information by using the poste r

or access panel labels that shipped with your Compaq ProLiant CL1850.

viii Compaq ProLiant CL1850 Software User Guide

Text Conventions

This document uses the following conventio ns to distinguish elements of text:

Keys Keys appear in boldface. A plus sign (+) betwee n

two keys in dicates tha t they shoul d be pressed
simultaneously.

USER INPUT User input appears in a different typeface and in

uppercase.
FILENAMES File names appear in uppercase italics.
Menu Options,

Command Names,
Dialog Box Names

These elements appear in initial capital letters.

COMMANDS,
DIRECTORY NAMES,
and DRIVE NAMES

These elements appear in uppercase.

Type When you ar e instructed to type information, type

the information without pressing the Enter key.
Enter When you are i nstructed to enter information, type

the information and then press the Enter key.

About This Guide ix

Symbols in Text

These symbols may be f ound in the text of this guide. They have the following
meanings.

WARNING: Text set off in this manner indicates that failure to follow directions
in the warning could result in bodily harm or loss of life.

CAUTION: Text set off in this manner indicates that failure to follow directions
could result in damage to equipment or loss of information.

IMPORTANT: Text set off in this manner presents clarifying information or specific
instructions.

NOTE: Text set off in this manner presents commentary, sidelights, or interesting points
of information.

Symbols on Equipment

These icons may be located on equipment in areas where hazardous conditions
may exist.

Any surface or area of the equipment marked with these symbols
indicates the presence of electrical shock hazards. Enclosed area
contains no operator serviceable parts.

WARNING: To reduce the risk of injury from electrical shock hazards,
do not open this enclosure.

Any RJ-45 receptacle marked with these symbols indicates a Network
Interface Connection.

WARNING: To reduce the risk of electrical shock, fire, or damage to
the equipment, do not plug telephone or telecommunications
connectors into this receptacle.

x Compaq ProLiant CL1850 Software User Guide

Any surface or area of the equipment marked with these symbols
indicates the presence of a hot surface or hot component. If this
surface is contacted, the potential for injury exists.

WARNING: To reduce the risk of injury from a hot component, allow
the surface to cool before touching.

Power supplies or systems marked with these symbols indicate
the equipment is supplied by multiple sources of power.

WARNING: To reduce the risk of injury from electrical shock,
remove all power cords to completely disconnect power from
the system.

Getting Help

If you have a problem and have exhausted the information in this guide, you
can get fur ther information and other help in the following locations.

Compaq Technical Support

In North America, call the Compaq Technical Phone Support Center at
1-800-OK-COMPAQ

1

. This service is available 24 hours a day, 7 days a week.

Outside North America, call the nearest Compaq Technical Support Phone
Center. Telephone numbers for worldwide Technical Support Centers are
listed on the Compaq website. Visit the Compaq website:

http://www.compaq.com

Be sure to have the foll owing information available before you call Compaq:

■ Technical support registration number (if applicable)

■ Product serial numbers

■ Product model names and numbers

■ Applicable error messages

■ Add-on boards or hardware

1

For continuous quality improvement, calls may be recorded or monitored.

About This Guide xi

■

Third-par ty ha rdw ar e or softw ar e

■ Operating system type and revision level

■ Detailed, specific questions

Compaq Website

The Compaq website has information on this pro duct a s well as the latest
drivers and Flash ROM images. Visit the Compaq website:

http://www.compaq.com

Compaq Authorized Reseller

For the name of your nearest Compaq authorized reseller:

■ In the United States, call 1- 800-345-1518.

■ In Canada, call 1-800-263-5868.

■ Elsewhere, see the Compaq website for locations and telephone

numbers.

Chapter 1

System Setup and Configu ration

for Microsoft Windows NT Server 4.0,

Enterprise Edition

Have the following items available as you configure your Compaq
ProLiant CL1850.

■ Hardware Configuration and Installati on Poster

■ Compaq SmartStart and Support Software CD

■ Compaq SmartStart Installation Poster

■ Compaq Insight Manager Installation Poster

■ Operating system documentation

■ Microsoft Window s NT Server 4.0, Enterprise Edition

■ Microsoft Windows NT Server 4.0, Enterprise Edition Administrator’s

Guide

■ Microsoft Cluster Server Administr at or’s Gui de

1-2 Compaq ProLiant CL1850 Software User Guide

Configuring the System

The sectio ns below provide instructions for co nfiguring your ProLiant CL1850
system.

Preconfiguration Checks

■ Be sure yo u have sufficient software rights to install the operating

system and software applications on each server node.

■ All hardware must be installed before you install the software.

Configuring Server Node 1

1. Apply power to the shared storage array a nd boot ser ver node 1 with the

SmartStart and Support Software CD in the CD-ROM drive.

2. When the system boots, you will see the Select Language screen. Select

the language you would like to use and follow the installation process.

3. When prompted to select an installation path, select the Assisted

Integration path. Follow the guided installation proce ss. If you need
help, refer to the online help by clicking on the Help b ut ton.

After the operating system has been selected, SmartStart runs the

System Conf iguration Utility and configure s the server node hardware.
It is very important that the adapter card in each server node, connected
to the shared storage RAID controller, have a unique SCSI ID number.

4. To verify or change the SCSI ID number after the system configuration

is done, select Review or Modify Hardware Settings then press Enter.
This allows you to see all of the hardware settings.

5. Select Step 3: View or Edit Details.

6. Arrow down to Com paq 64-Bit Dual Channel Wide Ultra2 SC SI

Controller (Port1). Underneath this heading is a subheading titled SCSI
ID. To change the SCSI ID setting, highlight the SCSI ID option then
press Enter. After makin g a new selection, press Enter to accept the
change.

IMPORTANT: Make a note of the SCSI ID setting. When server node 2 is configured, it
cannot have the same ID as server node 1. For example, if server node 1 is set for SCSI
ID 7 then server node 2 must be set to ID 6.

7. Press F10 to exit.

System Setup and Confi guration for Microsoft Windows NT S/E 4.0 1-3

8. Select Step 5: Save and Exit then press Enter.

9. The Pro duct Selection window appears. Continue to foll ow the guided

installation process, se l ecting options as nee ded. If you need help, ref er
to the online help by clicking on the Help button.

10. At the end of the Windows NT installation, you have the option of

viewing the Error Log. You may view the log by clicking on Yes. When
you select No, t he system reboots.

11. Log on to Wind ows NT.

12. If you elected to i nst all Compa q Insight Agents, a configuration screen

appears. Configure the agents as needed.

13. A prompt to load Service Pack 3 appears. Insert the Microsoft

Windows NT Server 4.0, Ent erprise Edition CD #1 and click OK. When
the Confirm File Replace window appears, select No To All.

14. After Service Pack 3 is loaded, remove the CD and click OK. The

system reboots.

15. Log on to Windows NT. Exit the installation of Enterprise Edition

Installer.

16. Start the CR3500 Co nfiguration Utility found in the Compaq System

Tools Folder. This utility allows you to configure the shared storage
RAID controllers and set up the logical drives. See Chapter 3, “CR3500
Configuration Utility,” for detailed information on this utility.

NOTE: When using the CR3500 Configuration Utility, it is only necessary to configure the
shared drives during server node 1 setup. When configuring server node 2, the utility
shows the results of the shared drives configured during the server node 1 setup.

NOTE: Compaq recommends that you create a 100-MB quorum drive to store cluster
information.

17. After the shared storage drives have been configured, run the

Windows NT Disk Administrator to create volumes out of the logical
drives. Be sure to assign drive letters and format the volumes for NTFS.

18. Close Disk Administrator and restart Windows NT.

19. At the Enterprise Edition Installer, ins tall Micr osoft Cluster Server

(MCCS) Administrator. Refer to MSCS documentation for installation
steps.

20. After installing MSCS, instal l the latest Service Pack, if applicable.

1-4 Compaq ProLiant CL1850 Software User Guide

21. To ensure that the latest Com paq drivers have not been overwritten by

the service pack, rerun the Server Support Software.

Configuring Server Node 2

1. Press Print Screen to access the KVM (Keyboard/Video/Mouse) switch

and choose server node 2 from the lis t.

NOTE: For detailed instructions on using the KVM switch, refer to the Compaq
ProLiant CL1850 User Guide.

2. Boot server node 2 with the SmartStart CD in the CD-ROM drive.

3. When the system boots, you will see the Select Language screen. Select

which language you would like to use and foll ow the installation
process.

4. When prompted to select an installation path, select the Assisted

Integration path. Follow the guided installation proce ss. If you need
help, refer to the online help by clicking on the Help b ut ton.

After the operating system has been selected, SmartStart runs the

System Conf iguration Utility and configure s the server node’s hardware.
It is very important that the adapter card in each server node connec ted
to the shared storage RAID controller have a unique SCSI ID number.

IMPORTANT: Server node 2 cannot have the same SCSI ID as server node 1. For
example, if server node 1 is set for SCSI ID 7 then server node 2 must be set to ID 6.

5. To verify or change the SCSI ID number after the system configuration

is done, select Review or Modify Hardware Settings then press Enter.
This allows you to see all of the hardware settings.

6. Select Step 3: View or Edit Details.

7. Arrow down to Com paq 64-Bit Dual Channel Wide Ultra2 SC SI

Controller (Port1). Underneath this heading is a subheading titled SCSI
ID. To change the SCSI ID setting, highlight the SCSI ID option then
press Enter. After makin g a new selection, press Enter to accept the
change.

8. Press F10 to exit.

9. Select Step 5: Save and Exit then press Enter.

10. The Pro duct Selection window appears. Continue to foll ow the guided

installation process, se l ecting options as nee ded. If you need help, ref er
to the online help by clicking on the Help button.

System Setup and Confi guration for Microsoft Windows NT S/E 4.0 1-5

11. At the end of the Windows NT installation, you have the option to view

the Error L og. You may vi ew the log by clicking on Yes. When you
select No, the system reboots.

12. Log on to Wind ows NT.

13. If you elected to i nstall Compaq Insight A gents, a configuration screen

will appear. Configure the Agents as needed.

14. A prompt to load Service Pack 3 appears. Insert t he Windows N T 4.0,

Enterprise Edition CD #1 and click OK. When the Confirm File Re place
window appears, select No To All.

15. After Service Pack 3 is loaded, remove the CD and click OK. The

system reboots.

NOTE: It is only necessary to configure the shared drives during server node 1 setup.
When configuring server node 2, the CR3500 Configuration Utility shows the results of the
shared drives configured during server node 1 setup.

16. At the Enterprise Edition Installer, ins tall Micr osoft Cluster Server

Administrator. Refer to MSCS doc umentation for installation steps.

17. After installing MSCS, install the latest Service Pack if applicable.

18. To ensure that the latest Com paq drivers have not been overwritten by

the service pack, rerun the Server Support Software.

Manual Installation Using SmartStart

Performing a manual installation with SmartStart minimizes SmartStart’s
involvement. The manual install ation rout i ne runs Compaq’s System
Configuration Utility. When you are prom pted for the Microsoft Windows NT
Server 4.0, Enterprise Edition CD, SmartStart transfers the i nstallation
procedure to Windows NT . Follow the instructions on the Windows NT
installation screens.

To perform a manual installation of cluster software using SmartStart, you
need the following:

■ Compaq SmartStart 4.40 or later

■ Microsoft Window s NT Server 4.0, Enterprise Edition

■ SmartStart installation poster

1-6 Compaq ProLiant CL1850 Software User Guide

Configuring Server Node 1

1. Apply power to the shared storage area and boot server node 1 from the

SmartStart CD.

2. When the system boots, you will see the Select Language screen. Select

which language you would like to use and foll ow the installation
process.

3. When prompted to select an installation path, select the Manual

Configurat ion path. Follow the g ui ded installation process. If you ne ed
help, refer to the online help by clicking on the Help b ut ton.

After the operating system has been selected, SmartStart runs the

System Conf iguration Utility and configure s the server node’s hardware.
It is very important that the adapter card in each server node connec ted
to the shared storage RAID controller have a unique SCSI ID number.

4. To verify or change the SCSI ID number after the system configuration

is done, select Review or Modify Hardware Settings then press Enter.
This allows you to see all of the hardware settings.

5. Select Step 3: View or Edit Details.

6. Arrow down to Com paq 64-Bit Dual Channel Wide Ultra2 SC SI

Controller (Port1). Underneath this heading is a subheading titled SCSI
ID. To change the SCSI ID setting, highlight the SCSI ID option and
press Enter. After makin g a new selection, press Enter to accept the
change.

IMPORTANT: Make a note of SCSI ID setting. When server node 2 is configured, it cannot
have the same ID as server node 1. For example, if server node 1 is set for SCSI ID 7 then
server node 2 must be set to ID 6.

7. Press F10 to exit.

8. Select Step 5: Save and Exit, then press Enter.

9. Select Save the Configuration and Restart the Computer, then press

Enter.

10. SmartStart is no longer invol ved in t he installation process. Follow the

instructions offered b y Windows NT.

11. After installing Windows NT and Service Pack 3, it will be necessary to

configure the shared storage area. Install the CR3500 Configuration
Utility located on the SmartStart CD.

System Setup and Confi guration for Microsoft Windows NT S/E 4.0 1-7

12. Start the CR3500 Co nfiguration Utility found in the Compaq System

Tools Folder. This utility allows you to configure the shared storage
RAID controllers and set up the logical drives. See Chapter 3, “CR3500
Configuration Utility,” for de tailed information on this utility.

NOTE: When using the CR3500 Configuration Utility, it is only necessary to configure the
shared drives during server node 1 setup. When configuring server node 2, the utility
shows the results of the shared drives configured during server node 1 setup.

13. After the shared storage drives have been configured, run the

Windows NT Disk Administrator to create volumes out of the logical
drives. Be sure to assign drive letters and format the volumes for NTFS.

14. Close Disk Administrator and restart Windows NT.

15. At the Enterprise Edition Installer, ins tall Micr osoft Cluster Server

Administrator (MSCS.) Refer to MSCS documentation for installation
steps.

16. After installing MSCS install the latest Service Pack if applicable.

17. To ensure latest Compaq drivers have not been overwritten by the

service pack, rerun the Server Support Software.

Configuring Server Node 2

1. Press Print Screen to access the KVM (Keyboard/Video/Mouse)

switch and choose server node 2 from the list.

NOTE: For detailed instructions on using the KVM switch, refer to the Compaq
ProLiant CL1850 User Guide.

2. Boot server node 2 with the SmartStart CD in the CD-ROM drive.

3. When the system boots, you will see the Select Language screen. Select

which language you would like to use and foll ow the installation
process.

4. When prompted to select an installation path select the M anual

Configurat ion path. Follow the g ui ded installation process. If you ne ed
help, refer to the online help by clicking on the Help b ut ton.

After the operating system has been selected, SmartStart runs the

System Conf iguration Utility and configure s the server node’s hardware.
It is very important that the adapter card in each server node connected
to the shared storage RAID controller have a unique SCSI ID number.

1-8 Compaq ProLiant CL1850 Software User Guide

IMPORTANT: Server node 2 cannot have the same SCSI ID as server node 1. For
example, if server node 1 is set for SCSI ID 7 then server node 2 must be set to ID 6.

5. To verify or change the SCSI ID number after the system configuration

is done, select Review or Modify Hardware Settings then press Enter.
This allows you to see all of the hardware settings.

6. Select Step 3: View or Edit Details.

7. Arrow down to Com paq 64-Bit Dual Channel Wide Ultra2 SC SI

Controller (Port1). Underneath this heading is a subheading titled SCSI
ID. To change the setting, highlight the SCSI ID option then press
Enter. After making a new selection, press Enter to accept the change.

8. Press F10 to exit.

9. Select Step 5: Save and Exit then press Enter.

10. Select Save the Configuration and Restart the Computer, then press

Enter.

11. From now on SmartStar t is n o longer involved in the installation

process. Fol low the instructions offered by Win dows NT.

12. After Windows NT, Service Pack 3, and MSCS are installed, install the

latest Service Pack if applicable.

13. To ensure latest Compaq drivers have not been overwritten by the

service pack, rerun the Server Support Software.

Verifying Creation of the Cluster

Now that the software is installed, use the following steps to verify the
creation of the cluster.

1. Shut down and power down both server nodes.

2. Power down and then power up the shared storage area.

3. Power up both server nodes.

When Windows NT finishes booting up on both server nodes, follow these
steps to use Microsoft Cl uster Administrator to verify creation of the cluster:

1. From the desktop on either server node, select Start, Programs,

Administrat ive Tools (Common), Cluster Administrator.

2. When prompted for the cluster or server name, enter the name or IP

address of one of the ser ver node s.

System Setup and Confi guration for Microsoft Windows NT S/E 4.0 1-9

3. If the cluster has been created correctly, the names of both server nodes

appear on the left side of the Cluster Administr ator window ( s ee Figure
1-1). Note t he cluster name.

Figure 1-1. Microsoft Cluster Administrator

Verifying Server Node Failover

NOTE: When running the failover test, start with the least complex test. Do not run any

client activity while testing failover events.

Follow these steps to verify failover of a server node:

1. From the desktop on both server nodes, select Start, Programs,

Administrat ive Tools (Common), Cluster Administrator.

2. When prompted for the cluster or server name, enter the name or IP

address of one of the ser ver node s.

3. Make sure all pre defined resou rces and gr oups are online. Verify that

some of the resources and groups are owned by the server node you are
powering down so that a failure event will result in failover of resources
and groups.

1-10 Compaq ProLiant CL1850 Software User Guide

4. Power down one of the server nodes.

5. Within several seconds, Cluster Administrator running on the surviving

server node should bri ng online all of the predefined resources and
groups tha t were previously owned by the powered-down server node.
If, after a minute, not hing appear s to have happened, ref resh the screen
by selecting Ref re sh (F5).

Verifying Network Client Failover

Now that you have verified that each server node is running correctly as a part
of the cluster, the next st ep is to verify that net work client s can interact with
the cluster.

The following steps will lead you t hrough this validatio n procedure.

1. Ensure both server nodes are running, and verify, using Cluster

Administra tor, that all groups and resources are online.

2. For each hard drive in the shared storage, Cluster Server automatically

creates a cluster group that consists of a single resource, the hard drive.
Using Cluster Administ rator, add an existing IP address as another
resource to one of these gr oups. (DO NOT use the Cluster Group.) Sa ve
the changes and return to the mai n Cluster Administrator screen.

3. Open a DOS window on a networ k client machine.

4. Ensure the network client can access the IP address, added in Step 2.

From the network client, execute a PING command, using the cluster IP
address as the argument.

NOTE: Regardless of whether you are using WINS or DHCP, you can execute the DOS
command “PING” to check the connection.

The client has successfully accessed the cluster resource if you get a

response similar to:

Reply from <IP Address>: bytes=xx time=xxxms TTL=xx.

The client has not successfully accessed the cluster resource if you get a

response of:

Reply from <IP Address>: Destination host unreachable

5. Following the completi on of the PING command, use Cluster

Administrator to perform a manual failover of the cluster group that
contains the IP address.

6. After the manual failover completes, execute the PING command again.

System Setup and Confi guration for Microsoft Windows NT S/E 4.0 1-11

7. As soo n as the other server node brings the cluster gro up online, a

response simi l ar to the one noted in Step 4 should be returned. If the
client successfully accessed the failed over IP address, your cluster is
working. If the client wa s unsuccessful, either t he cluster gr oup was not
configure d correctly, the failover did not occ ur, or the PING command
was performed before the failover activity completed.

NOTE: To verify a more extreme case, rather than fail over the IP address, power down
the primary cluster server node and verify that the resource fails over to the other server
node.

Setting Up Cluster Groups and Cluster
Resources

You have now set up and c onfigure d all your clustering hardware. Microsoft
Windows NT Server 4.0, Ent erprise Edi t ion and Cluster Server are installed on
both server s. You have done some minimal validation of your cluster a nd
everything is working as planned. Now it is time to set up your applicat ions to
utilize the capabilities of clustering.

If you have defined your cluster needs correc tly and deter mined how t o fit
your applications and environment into a cluster, conf iguring y our applications
will be a straightforward task.

Although details of these procedures are beyond the scope of this guide,
several documents are available f rom both Mic rosoft and Compaq to a s sist
you with thes e final steps.

The best source of information concerning the steps to configure cluster
groups and c luster res ources is Micr osoft’s Cluster Server Administrato r’s
Guide. Refer to that guide for detailed setup information.

Compaq has worked directly with several application vend ors through out the
development of Compaq ProLiant Clust ers. As a re sult of these efforts,
Compaq pro vides a number of Integr ation TechNotes to assist you with
installing these applications in a Compaq ProLiant cluster environment.

The following TechNotes are included with your Compaq ProLiant cluster
documentation:

■ Microsoft File and Print Service Failover Using Microsoft Cluster

Server (MSCS)

■ Microsoft Internet Information Server (IIS) 3.0 Service Failover Using

MSCS

1-12 Compaq ProLiant CL1850 Software User Guide

■

Microsoft IIS 3.0 Resource Failover Using MSCS

The following Integration TechNotes are available on the Compaq website:

http://www.compaq.com

Visit the Compaq website to download the most current ver sions of these and
other technical documents:

■ Microsoft SQL Server Service Failover Using MSCS

■ Oracle Service Failover Using MSCS

■ Resource Failover Using Oracle FailSafe 2.0x and MSCS

■ Lotus Domino Server 4.51 Service Failover Using MSCS

Chapter 2

System Setup and Configu ration

for Novell NetWare

Have the following items available as you configure your Compaq
ProLiant CL1850.

■ Hardware Configuration and Installati on Poster

■ Compaq SmartStart and Server Management CD

■ Compaq SmartStart Installation Poster

■ Compaq Insight Manager Installation Poster

■ Operating system documentation

■ Novell NetWare 4.2 or Net W are 5

■ Novell High Avail ability Server for NetWare 4.2 or N ovell Cluste r

Services for NetWare 5

2-2 Compaq ProLiant CL1850 Software User Guide

Configuring the System

The sectio ns below provide instruct ions for configuring your ProLiant CL1850
system.

Preconfiguration Checks

1. Be sure you have sufficient software rights to install the operating

system and software applications on each server.

2. All hardware must be installed before you install the software.

Configuring the Shared Storage Array

1. Place the appropriate number of disk drives in the shared storage array

for your RAID configuration and drive size re quirements .

2. Power up the shared storage array.

3. Configure the sha red storage array usin g the CR3500 Configuration

Utility. For instructions on using this ut ility, refer to Chapter 3,
“CR3500 Configuration Utility.”

Configuring Server Node 1

1. Apply power to the shared storage area and boot server node 1 with the

SmartStart and Support Software CD in the CD-ROM drive.

2. When the system boots, you will see the Select Language screen. Select

which language you would like to use and foll ow the installation
process.

3. When prompted to select the installation path, select the Assisted

Integration Path. Follow the guided installation process. If you need
help, refer to the online help by clicking on the help button.

After the operating system has been selected, SmartStart runs the

System Conf iguration Utility and configure s the server node’s hardware.
It is very important that the adapter card in each server node connec ted
to the shared storage RAID controller have a unique SCSI ID number.

4. To verify or change the SCSI ID number after the system configuration

is done, select Review or Modify Hardware Settings then press Enter.
This allows you to see all of the hardware settings.

5. Select Step 3: View or Edit Details.

System Setup and Configuration for Novell NetWare 2-3

6. Arrow down to Com paq 64-Bit Dual Channel Wide Ultra2 SC SI

Controller (Port1). Underneath this heading is a subheading titled SCSI
ID. To change the SCSI ID set t ing, highli ght the SCSI I D option then
press Enter. After makin g a new selection, press Enter to accept the
change.

IMPORTANT: Make a note of the SCSI ID setting. When server node 2 is configured, it
cannot have the same ID as server node 1. For example, if server node 1 is set for SCSI
ID 6 then server node 2 must be set to ID 7.

7. Press F10 to exit.

8. Select Step 5: Save and Exit, then press Enter.

9. The Product Selection Win dow appears. Follow the guided installation

process. If you need hel p refer to the online help by clicking on the Hel p
button.

10. Once NetWare has been loaded, type Load Install (for NetWare 4.2) or

Nwconfig (for NetWare 5) at the NetWare Console prompt. This allows
you to set up the NetWare disk partitions and to create or modify the
volumes that the system will use.

NOTE: The Compaq 53c876 is the local controller for the internal hard disk drives on the
server nodes. The Compaq 53c896 is the controller device for the shared array controller.
Always install the SYS volume on the local non-shared drives.

Configuring Server Node 2

1. Press Print Screen to access the KVM (Keyboard/Video/Mouse) switch

and choose server node 2 from the lis t.

For detailed instructions on using the KVM switch, refer to the Compaq

ProLiant CL1850 User Guide.

2. Boot server node 2 with the SmartStart CD in the CD-ROM drive.

3. When the system boots, you will see the Select Language screen. Select

which language you would like to use and foll ow the installation
process.

2-4 Compaq ProLiant CL1850 Software User Guide

4. When prompted to select the installation path, select the Assisted

Integration Path. Follow the guided installation process. If you need
help, refer to the online help by clicking on the Help b ut ton.

After the operating system has been selected, SmartStart runs the

System Conf iguration Utility and configure s the server node’s hardware.
It is very important that the adapter card in each server node connec ted
to the shared storage RAID controller have a unique SCSI ID number.

5. To verify or change the SCSI ID number after the system configuration

is done, select Review or Modify Hardware Settings then press Enter.
This allows you to see all of the hardware settings.

6. Select Step 3: View or Edit Details.

7. Arrow down to Com paq 64-Bit Dual Channel Wide Ultra2 SC SI

Controller (Port1). Underneath this heading is a subheading titled SCSI
ID. To change the SCSI ID setting, highlight the SCSI ID option then
press Enter. After makin g a new selection, press Enter to accept the
change.

IMPORTANT: Make a note of this setting. When server node 2 is configured, it cannot
have the same ID as server node 1. For example, if server node 1 is set for SCSI ID 6 then
server node 2 must be set to ID 7.

8. Press F10 to exit.

9. Select Step 5: Save and Exit, then press Enter.

10. The Product Selection Win dow appears. Follow the guided installation

process. If you need help, refer to the online help by clicking on the
Help button.

11. Once NetWare has been loaded, type Load Install (for NetWare 4.2) or

Nwconfig (for NetWare 5) at the NetWare Console prompt. This allows
you to set up the NetWare disk partitions and to create or modify the
volumes that the system will use.

12. After the operating system has be en successfully installed on both server

nodes, install the appropriate Novell clustering software.

System Setup and Configuration for Novell NetWare 2-5

Configuring the Cluster for NetWare 4.2

Novell High Availability Server (NHAS) is the software needed to run the
clusterin g aspect of the ProLiant CL1850 when running NetWare 4.2. T his
software must be installed after each server node has NetWare 4.2 loaded and
at least one volume from the shared storage array has been mounted to each
server node. NHAS will allow you to accomplish the following:

■ Configure the cluster

■ Pause the cluster

■ Manual failover

■ Manual failback

■ Automatic failover

■ Automatic failback

For instructions on NHAS installation and detailed use of these functions,
please refer to the

Novell High Availability Server User’s Guide from Novell.

Preparations for Installing NHAS

The following is a list of preparations needed prior to installation of NHAS.

■ Check network connections to and from each server using Display

Servers command at NetWare console.

■ Use the Config command to check all IP addresses and to make sure

there is a network connection bo unded to the IPX protocol for the D i rect
Link. Label this network port as such for simpl icity in re cognition
during the NHAS installation. A second network connection should
exist for public NetWare Link.

■ Be sure to allocate and mount at leas t one shared volume for each server

by using the Volume Options in the Install utilit y. Multiple volumes will
imply the same rule. Try to gauge which applications will be installed so
the volumes’ File Compression and Block Subal location se ttings are
appropriate. Otherwise, you will need to reinstall NHAS later.

■ Each server in the cluster must have an internal hard drive that is not

part of the shared subsystem. A SYS: volume on the shared subsystem
would be confusing a nd potential ly damaging.

2-6 Compaq ProLiant CL1850 Software User Guide

■

NetWare volumes can span multiple drives. When a volume spans more
than one drive, all of the drives that it spans must be shared or all of
them must be not shared. Otherwise if one drive fails, there will be no
access to the volume from either cluster server.

■ NHAS cluster server will function within different containers in the

NDS tree, but they must reside in the same directory tree to ensure
smoother failover of NDS resource objects.

■ It is not necessary for servers in the cluster to contain NDS replicas as

long as multiple trusted replica s exist on the network. If one server i n
the cluster contains a trusted NDS replica, then for NDS availability
reasons, both servers should contai n a replica.

NOTE: You must install the latest NetWare Support Pack and then the NSSD before
installing NHAS.

Installation of NHAS

NHAS is installed by mounting the NHAS CD on a server and using the
CD-Mount H A command, then entering the following on the console.

LOAD HA:HASERVER/HASINST

When prompted to selec t the other se rver node of the cluster pair, enter the
“V” command at the NetWare console of the other server node. From t he first
server node, you will then select the Direct Link. When the file copy is
complete, finish the installation by pressing Enter, Down, Exit, and Restart
both servers.

System Setup and Configuration for Novell NetWare 2-7

Verifying Functionality of the Cluster

Now that the software is installed, you can verify the creation of the cluster
from the NHAS Console. All three links under Connection Status will show
Connected. See Figure 2-1.

Figure 2-1. NHAS: Connected

Verifying Direct and NetWare Links

To test Direct Link Disconnect:

1. Remove the network cable from the server’s network car d to which

Direct Link is dedicated. The Direct Link status on the NHAS screen
should change from Co nnected to Not Connected.

2. Reconnect the network cable to the network card. The Direct Link status

should change from Not Connected to Connected.

2-8 Compaq ProLiant CL1850 Software User Guide

To test NetWare Link Disconnect:

1. Remove the network cable from the server’s network car d to which

NetWare Link is dedicated. The NetWare Link status should change
from Connected to Not Connected.

2. Reconnect the network cable to the network card. The NetWare Link

status should change from Not Connected to Connected.

Verifying Server Node Failover

When running the failover test, it is recommended to star t with the least
complex test, so do not run any client activity while testing failover events.
For instructions on testing NHAS Failover, please refer to the NHAS user’s
guide from Novell.

Configuring the Cluster for NetWare 5

Do the following prepar ations bef ore installation.

1. Install all necessary Support Packs and NSSDs.

2. Ten MB of free space that is not part of an NSS or DDFS partition on

the shared storage array is required for the split brain partition. Be sure
this partition can be readily seen through both server n odes.

3. If you want to zone the intra-c l uster links and separate it from the ma i n

public network link, be sure to assi gn it an IP addr ess of a different
subnet on a NIC through NetWare. You will have the optio n t o choose
the specific NIC during NCS installation.

The Novell Cluster Services Installation creates a new cluster object and
installs Novell Cluster Services s oftware on the server nodes you specify to be
part of your cluster. This installation is done from a remote client workstation
machine.

1. Insert the NCS CD into the CD- ROM drive on the client workstation

with administration rights to the directory tree to which the server nodes
reside.

2. From the initial splash screen, lau nch the Novell Cluster Services

installation. Continue throug h the installation screens until you get to the
screen that prompts you to create a new cluster.

3. Select Create a New Cluster. Then click Next.

4. Enter a name for the new cluster object y ou are creating and specify the

directory tree and context where you want it created. Then click Next.

System Setup and Configuration for Novell NetWare 2-9

5. Enter t he name of the server nod e you want to add to the cluster, or

browse and select one from the list, and then click Add to Cluster.
Repeat this step for the second server node to add to the cluster. When
you add a server node to a c luster, Novell Cluster Se rvices automatically
detects the server node’s IP address. If the server node you are adding
has more than one IP addre ss, you will be prompted t o select the IP
address you want Novell Cluster Service s to use.

6. Specify that your cluster has a shared disk system, then select the drive

where you want the small cluster partition created. Novell Cluster
Services requires a small cluster partition on the shared disk system.
You are also given the option of mirroring the partiti on for greate r fault
tolerance.

IMPORTANT: You must have a small amount of free space on one of the shared disk
drives to create the cluster partition. If no free space is available, the shared disk drives
will be unusable by Novell Cluster Services.

7. Continue through the final installation screen. The Novell Cluster

Services installation program will then create a new cluster for you and
add the server nodes you specified in the install to the cluster.

After creating a new cluster, you now need to create cluster resources and
configure those resour ces. You also should consider adding NetWar e volumes
to the cluster and creating cluster resource templates.

Verifying NCS Cluster Creation

Create a simple application cluster resource object via a “load monitor.” Be
sure to add the server nodes to the resource so the resources can startup. Start
up the resource and force a migration. On the local server console screens you
should be able to see the monitor utility load and unload.

Create a simple volume object (note you will need to create a NSS volume
from NetWare first). Be sure to add the server nodes to the resource so the
resources can startup. Start up the resource and force a migration. On the local
server console screens you should be able to see the monitor utility load a nd
unload.

Chapter 3

CR3500 Configuration Utility

This chapter provides instructions for using the Compaq CR3500
Configuration Utility and describes m ethods to configure your CR3500
controller quickly and easily. The CR3500 Configuration Utility is located on
the Compaq SmartStart and Support Software CD.

The utility uses a graphical user interface (GUI) to help you configure the
CR3500 controller. You can use the utility to configure a controller initially or
to reconfigure a controller.

The CR3500 Configuration Utility can create arrays (a group of physical
drives that are similar in size) called logical drives. Logical drives are created
using the CR3500 Configuration Utility’s Add Logical Drive Wizard. You can
create:

■ Single-device arrays (JBODs)

■ Striped arrays (RAID 0)

■ Mirrored arrays (RAID 1)

■ Striped mirrored arrays (RAID 0+1)

■ Striped parity ar rays with fixed parity disk (RAID 4)

■ Striped parity ar rays with fl oating parity disk (RAID 5)

For more information on RAID levels, refer to the Online Help.

3-2 Compaq ProLiant CL1850 Software User Guide

This chapter includes the following sections:

■ Online Help

■ Before You Begin

■ CR3500 Configuration Utility Features

■ Configuration Procedures

■ Error and Warning Messages

The CR3500 Configuration Utility:

■ Uses easy-to-understand graphics to illustrate controller configuration

■ Uses a wizard that guides y ou through t he configuration process

Online Help

Press the F1 key to activate context-sensitive, online help for each screen.
Help is also available by clicking the Help heading on the toolbar. A status bar
at the bottom of the screen also displa ys help messa ges describing the curre nt
selection.

Before You Begin

Before a first-time installation and configuration of the system, c omplete the
following:

■ Install a redundant CR3500 controller ( optional). To install a redundant

CR3500 controller, refer to the Compaq ProL iant CL1850 User Guide .

■ Determine which fault tolerance method and logical drive configuration

you want to use. For more information on RAID levels, refer to the
Online Help.

CR3500 Configuration Utility 3-3

CR3500 Configuration Utility Features

There are two methods you can use to run the CR3500 Configuration Utili ty.

■ SCSI connection—This option is only f or systems running

Windows NT.

■ Serial cable connection—For server nodes not running W i ndows NT, a

separate system running Windows 9 5/98/NT is required. A ser i al cable
is used to connect the separate system to the CR3500 RAID controller
through a connection in the back of the shared storage area.

SCSI Connection

The system must be runni ng Windows NT to connect online via the SCSI
interface.

1. Insert the SmartStart CD into the server node.

2. From Windows NT Ex plorer, go t o the CR3500 directory on the

SmartStart CD and run SETUP.EXE. This will install the CR3 500
Configuration Utility to the server node.

3. Go to Start, Compaq System Tools, C R3500 Utility to run the utility.

4. A connection window appears (Figure 3-1).

Figure 3-1. CR3500 Configuration Utility SCSI connection

5. Select SCSI and click OK. You will the n be taken to the main window

of the utility.

3-4 Compaq ProLiant CL1850 Software User Guide

Serial Connection

This method uses a separate system run ning Window s 95/NT.

1. Connec t t he Windows 95/98/NT system to the port labeled CTRL-1 on

the back of the shared storage area using a serial cable. If using
redundant controllers, connect another serial cable fr om the Win95/NT
system to the port labeled CTRL 2. See Figure 3-2 for connection
locations.

2

1

Figure 3-2. Shared storage array ports

Table 3-1

Shared Storage Array Connection

Identifier Description

1

CTRL-1 connection (top controller)

2

CTRL-2 connection (bottom controller)

2. Insert the SmartStart CD into the system running Windows 95/NT.

3. From Windows Expl orer, go to the CR3500 dir ectory on the SmartStart

CD and run SETUP.EXE. This will install t he C R3500 Configuration
Utility.

4. Go to Start, Compaq System Tools, C R3500 Utility to run the utility.

CR3500 Configuration Utility 3-5

5. A connection window appears (Figure 3-3).

Figure 3-3. CR3500 Configuration Utility Serial connection

6. Select Serial, then click OK.

7. Next you will see the Serial Connection window (Figure 3-4). Choose

the COM port (usually COM1) used to make the connection to the
shared storage array. Click Connect. If you are us ing a dual controller
setup, a second serial connection window will appear and you must
select the COM port (usually COM2) for the second controller. After
Connect is clicked, the main window will appear.

Figure 3-4. CR3500 Configuration Utility: Serial Connection

3-6 Compaq ProLiant CL1850 Software User Guide

Configuration Utility Features

Main Window

The CR3500 Configuration Utility main window (Figure 3-5) has f o ur ar eas:

■ The menu bar

■ The tool bar

■ The logical drives window

■ The physical dr ives window

Figure 3-5. CR3500 Utility main window

Drop-Down Menus

The main wi ndow has menu bars and drop-down m enus. For more
information, see the “Main Window Me nu Bar ” section later i n t his chapter.
Each drop-down menu presents a group of related functions.

Menu and Command Access Methods

You can use the mouse or the keyboard to access me nus and commands. For
keyboard access, simultaneously press the Alt key and the underlined letter in
the name of t he menu. Next, press the underlined letter of a command na me
shown in the drop-down list.

CR3500 Configuration Utility 3-7

Shortcut Menus

Frequently used commands can also be accessed by clicking the right mouse
button on t he system, logical drive, device, or folder icon.

Main Window Menu Bar

The menu bar (Figure 3- 6) provides cascading m enu selections for most of the
functions you can perform in the configuratio n utility.

There are four, drop-down menus i n the menu bar :

■ The File menu

■ The View menu

■ The Storage menu

■ The Help menu

You can reach any menu command using a keyboard shortcut. Each shortcut is
formed by pressing the Alt key along wi t h the letter underlined on the menu
bar. You can reach sub menu commands by a ppending an additional character,
shown underlined in the sub menu’s menu bar.

Figure 3-6. Main window menu bar

For more information on these menus and their commands, access the Online
Help by pressing F1.

Main Window Toolbar

The tool bar (Figure 3- 7) provide s buttons wi th which you can perform many
of the functions available in the CR3500 Configuration Utility.

Figure 3-7. Main window toolbar

3-8 Compaq ProLiant CL1850 Software User Guide

Each tool bar icon is described in T able 3-2.

Table 3-2

Storage Window Tool Bar Icons

Icon Icon Name Description

Add logical drive button Enables you to add a new logical drive

to your storage subsystem

Large icons button Displays your logical drives as large

icons

Small icons button Displays your logical drives as small

icons

List button Displays your logical drives in a list of

small icons

Details button Displays your logical drives in a detailed

list

Logical Drives Window

The Logica l Drives wi ndow (Figure 3-8) pro vides detailed information abo ut
the logical drives you have configured in your storage subsystem.

Figure 3-8. Logical Drives window

View Options

You have four options for viewing the inform ation in the Logical Dri ves
window:

■ Large icons

■ Small icons

■ List

■ Details

CR3500 Configuration Utility 3-9

Large Icons, Sma ll Icons, and List Views

If you choose the Large Icons, Small Icons, or List options in the Logical
Drives View menu, the program uses i cons to indicate the underlying structure
of the logical drives in the Logical Drives window. The logical drive types and
their corre sponding icons are shown in Table 3-3.

Table 3-3

Logical Drive Types

Logical Drive Type Description

Indicates a JBOD (single-disk) logical drive

Indicates a RAID 0 logical drive

Indicates a RAID 1 logical drive

Indicates a RAID 0+1 logical drive

Indicates a RAID 4 logical drive

Indicates a RAID 5 logical drive

The program also uses icons to indicate the status of the logical drives in the
Logical Drives window. The logical drive status and corresponding icons are
shown in Table 3-4.

Table 3-4

Logical Drive Status

Logical Drive State Icon State Description

Good Logical drive is operating normally.

Failed Logical drive is not working.

continued

3-10 Compaq ProLiant CL1850 Software User Guide

Table 3-4
Logical Dri ve Status

continued

Logical Drives State Icon State Description

Reduced One physical drive in a logical drive has

failed.

Initializing The program is creating a starting parity

for a logical drive that has parity, or is
starting data for a logical drive that does
not have parity.

Reconstructing A failed physical drive’s data is being

regenerated on a spare disk.

Details View

If you choose the Detai l s option in the View menu, the logic al drive wi ndow
displays four informa t ion fields:

■ Name—The name the utility has given your logical drive

■ State—The current operational state of the logical drive

■ Capacity—The maximum amount of data, in bytes, that the logical drive

can contain

■ RAID level—The unde rlying structure of the logical drive

NOTE: You can change the width of an information field by dragging on one of its
borders.

Logical Drives Prop erty Sheets

You can view very detailed attributes of your logical drives by accessing their
property sheets. You can access a logical drive’s property sheet directly by
double clicking the logical drive’s icon in any view. You can also right-click
the icon and select Properties from the shortcut menu. For more information
regarding logical dr ive properties, refer to the Online Help.

Locating Logical Drive M emb e rs

You can locate the members of any logical drive by clicking on the logical
drive icon in the Logical Drive window. The drive’s members are shown as
shaded physical drive icons in the Physical Drive window.

CR3500 Configuration Utility 3-11

Physical Drives Window

The Physica l Drives wi ndow (Figure 3-9) provides detailed information about
the physical drives you have configured in your stora ge subsystem.

Figure 3-9. Physical Drives window

3-12 Compaq ProLiant CL1850 Software User Guide

The CR3500 Configuration Utility uses icons to indicate the stat us of the dis ks
in the disk window. The physical drive states and corresponding icons are
shown in Table 3-5.

Table 3-5

Physical Drive States

Drive State Icon State Description

Good Physical drive is operating normally as part of a

logical drive.

Reconstructing Reconstruction data is being written to this

physical drive.

Spare Physical drive is available to replace a failed

physical drive that is a group member.

Failed Physical drive is not available but is installed.

Available Physical drive is available for use in a logical

drive or as a spare.

Icons representing the Shared Storage RAID controllers are arranged just
below the physical drives. The utility uses icons to indicate the status of your
controller s, as shown in Table 3-6.

Table 3-6

Controller status

Controller Status Icon Description

Indicates an operational controller

Indicates a controller that is not operational

CR3500 Configuration Utility 3-13

Configuration Procedures

Adding a Controller

A second CR3500 contr oller may be added for redundancy of the shared
storage array. To install a second controller, refer to the Compaq

ProLiant CL1850 User Guide.

Configuring the CR3500 Controller

Each installed controller has configuration properties that can be modified
using the CR3500 Configuration Utility. When the controllers are installed, the
utility assigns them default settings. You can change these settings to meet
your own ne eds.

To access the controller properties, right-click the controller icon and select
Properties. You may also select the controller and then choose Properties from
the File pull-down menu.

The Controller Properties screen (Fi gure 3-10) appears showing the four
property tabs. They are:

■ General

■ Host Ports

■ Environment

■ Cache

3-14 Compaq ProLiant CL1850 Software User Guide

Figure 3-10. Controller Properties window, General tab

The General t ab has the following properties.

■ System Name—Shows the syste m name as it i s known by t he operating

system.

■ Failover Mode—Shows the failo ver mode select ed: high performance

(active/active), high availability (active/passive), or stand-alone (single
controller). High availability is only available with tw o contro ller s.

■ Read-ahead cache limit—Enter the desired read-ahead limit (0-16). If

you enter 0, the read-ahead is disabled. Each increment equals 32 blocks
of data that are read ahead in the cache. For example, 2 would equal
64 blocks read ahead.

■ Controller mode —Shows the controller mode, which is active or

unavailable.

■ Rebuild rate—Enter the desired rebuild rate, which ranges from

1 to 100. The controller rebuilds while it handles I/O activity. A rate
below 50 emphasizes I/O response over the RAID rebuild. A rate above
50 puts a higher priority on the RAID rebuild at the expense of I/O
activity.

CR3500 Configuration Utility 3-15

■

Create rate—Enter the desired create rate, which ranges from 1 to 100.
The controller creates RAID sets while it handles I /O activity. A rate
below 50 emphasizes I/O response over the RAID set creation. A rate
above 50 puts a higher priority on the RAID set creation at the expense
of I/O activity.

■ Firmware revision—Shows the current software revision.

■ Serial number—Shows the serial number of the controller.

■ Connection type —Shows the connection type, which can be serial or

SCSI.

3-16 Compaq ProLiant CL1850 Software User Guide

The next tab, Host Ports (Figure 3-11), has the following properties.

Figure 3-11. Controller Properties window, Host Ports tab

■ Failover Mode—Enter the desired failover mode: Performance

(active/active) or High Availability (active/passive). High availability is
only available with two controllers. If two controllers are present , both
must be set to the same failover mode.

NOTE: Compaq recommends running in active/active mode only.

■ Host I/O channel 0—Enter the desired host I/O channel mo de, which

can be active or passive.

■ Channel 0 Target ID—The physical address a bus initiator uses to

connect with a bus target. Each bus target is assigned a unique target
address. Yo u must select an ID between 0 and 15 for a 16-bit module, or
between 0 and 7 for an 8- bit module. Make sure the ID you select does
not conflict with other IDs. Target ID s are also referred to as the SCSI
ID.

NOTE: Compaq recommends using the default values for the Channel 0 Target ID.

■ Bus width—Enter the desired bus width, 8 bit or 16 bit.

CR3500 Configuration Utility 3-17

■

SCSI transfer rate—Enter the desired SCSI transfer rate. You can
choose from 5 MB to 40 MB.

■ Tag queuing—If your host adapter supports tag queuing che ck here. Ta g

queuing permits each initiator to have multi ple commands outstanding
and each target to optimize the commands it receives.

The Environment tab ( F igure 3-1 2) monitors the following items:

■ Power

■ Temperature

■ Fan State

Figure 3-12. Controller Properties window, Environment tab

Refer to the Online Help for more information regarding each area’s warning
icon and meaning.

3-18 Compaq ProLiant CL1850 Software User Guide

The Cache tab (Figure 3-13) indicates the cache memory size for each
occupied slot in a controller’s memory.

Figure 3-13. Controller Properties window, Cache tab

Adding Physical Drives

The system’s CR3500 RAID Controllers must recognize the physical drives in
the shared storage area before you can create logical drives from them. The
controller will recognize all physical drives at start up. To add physical drives
to your configuration after the controller has st arted, follow these ste ps:

IMPORTANT: Before adding physical drives that have previously been used by another
ProLiant CL1850, it is necessary to delete any configuration settings on the drives. Failure
to do so can cause conflicting RAID settings on the CR3500 controller.

1. Physically add the drives to the system.

2. Run the CR3500 Configuration Utility to configure the drives.

NOTE: You cannot increase the capacity of an existing logical drive.

CR3500 Configuration Utility 3-19

3. From the Main window, click Physical Drive, then click New.

4. The Add New Physical Drive Window appears. Enter the channel

number and Target ID for the new physical drive. The Target ID is
displayed o n the gr id.

NOTE: An alternate method for adding drives is to click on an empty cell in the grid, then
right click and select New. This presents the Add New Physical Drive window with the
channel number and target ID currently assigned.

5. Click the OK button. The program adds your physical dr ive to your

configura tion and refreshes the ma in screen.

Adding Logical Drives

From the Stor age pull-down menu, sele ct Add Logical Drive. There is a
six-step Wizard to assist you in adding a logical drive.

1. Select the RAID level for the new logical drive (Figure 3-14). Click the

Next button to continue.

Figure 3-14. Add Logical Drive: Step 1

3-20 Compaq ProLiant CL1850 Software User Guide

2. Select the physical drives for the new logical drive (Figure 3-15). The

number of p hysical drives you cho ose will deter mine the amount of
storage that will be available for the new logical drive. To select a
physical drive, click on an available physical drive and it will be added
to the selected physical drive list.

The Next button is disabled until the minimum number of disks is

chosen.

Figure 3-15. Add Logical Drive: Step 2

CR3500 Configuration Utility 3-21

3. Add the capacity for the logical drive (Figure 3-16).

Figure 3-16. Add Logical Drive: Step 3

■ To create a single logical drive using the total capacity available, click

Add. The capacity remaining changes to 0. The new logical drive will
appear in the bottom window, along with its capacity size. Click Next to
continue.

■ To create more than one logical drive, enter a number less than the

amount appearing in the Logical D rive Capac ity window and click Add.
The capacity remaining changes to reflect the new amount of capacity in
use. Repeat this step if you want to create another logical drive, or click
Next to cont inue.

3-22 Compaq ProLiant CL1850 Software User Guide

4. Define t he strip size and the host port for the new logical drives

(Figure 3-17). Click Next to continue. For more informa tion on strip
size and host ports, refer to the Online Help.

Figure 3-17. Adding Logical Drive: Step 4

CR3500 Configuration Utility 3-23

5. Select a Logical Unit Number (LUN) for the logical drive (Figure 3-18).
The Step 5 scre en also gives you the opt ion of enabli ng the Write back

Cache to improve host performance. For more information on LUNs and
Writeback Cache, refer to the Online Help.

Figure 3-18. Adding Logical Drive: Step 5

3-24 Compaq ProLiant CL1850 Software User Guide

6. View a summary of the new logical drives (Figure 3-19). In this

summary you will find the RAID level, capacity, cache options, and
member physical drives that you selected for each new logical drive. If
you are not satisfied with these characteristics, you can go back and
make changes by clicking on the Bac k Button. If you are satisfied with
the summary, click Finish.

Figure 3-19. Adding Logical Drive: Step 6

Replacing a Failed Controller

Replacing a Failed Controller in a Single
Controller Environment

1. Power down the shared storage array.

2. Remove the failed controller.

3. Insert the new controller.

4. Restore the configuration settings. See the section “Restoring

Configuration Setting from a File” for this procedure.

CR3500 Configuration Utility 3-25

Replacing a Failed Controller in a Redundant
Controller Environment

A failed co nt roller can be replaced without powering down the share d storage
array. To replace a failed controller:

1. Remove the failed controller.

2. Insert the new controller.

Replacing a Failed Drive

A failed drive can be replaced without powering down the shared storage
array. When a drive fai ls, two things can happen:

■ The logical drive associated with the failed drive utilizes a spare and

rebuilds the spare drive to join the logical drive. The logical drive will
be in a reconstructing state.

■ The logical drive stays in a reduced state until a new drive is added.

To replace the failed drive:

1. Remove the failed drive.

2. Insert the new drive.

3. See the “Adding Physical Drives” section for procedures to make the

new drive k nown.

4. Set the new drive status.
If a spare drive was used to reconstruct the affected logical drive, set the

new drive as a spare drive.

If there was no spare drive to use, the logical drive is still in a reduced

state. Add the new physical drive to the logical drive and reconstruction
can start.

a. Select the logical drive in reduced status.
b. Select Logical Drive from the Storage pull down menu.
c. Select Reconstruct.
d. A list appears showing you available drives. Select the drive you just

added.

e. Reconstruction begins.

3-26 Compaq ProLiant CL1850 Software User Guide

Setting a Physical Drive as a Spare

NOTE: Spare drives serve as spares to all logical drives. They are not grouped with a

particular logical drive.

How a Spare Works

■ If a physical drive fails in a RAID 1, RAID 0+1, RAID 4, or RAID 5

logical drive, the spare automatically replaces the failed physical drive
and the controller reconstructs all logical drives the failed physical drive
was a member of.

■ Once the controller writes data to a spare, the spare becomes part of the

same device group in whi ch a device failed.

■ Once the controller writes data to a spare, the status of the spare changes

to Good.

To Define a Spare Physical Drive

1. In the main window, click the physical drive to be used as a spare. The

physical drive must be in the Available state.

2. From the Storage menu, choose Physical Drive, then choose Make

Spare.

NOTE: The spare must have a capacity equal to or greater than the failed physical drive
for an automatic reconstruct to start.

Managing Spare Physical Drives

Making a spare physical drive part of a logical drive will protect the integrity
of the RAID setup. This proves especially true for logical drives that have
RAID requirements of two or more physical drives. Sh ould one physical drive
fail, the logical drive will automatically activate the spare physical drive as an
instant replacement for the failed one.

Managing Failed Physical Drives

To return a failed physical drive to a nonfailed state, from the Storage menu,
select Physical Drive, and then select Clear Failure.

You can easily identify a failed physical drive from the main screen because
the failed icon will appear. See Table 3-5 for the physical drive icons.

CR3500 Configuration Utility 3-27

Deleting Logical Drives

CAUTION: If you delete a logical drive, all of your data on that logical drive will

be lost. The logical drives in your storage subsystem are logical units that
contain your user data. Although they do not exist in a physical sense, it is their
logical structure that ties together the physical pieces of your data spread
across their members. Use extreme caution when deleting a logical drive.

1. Click t he logical drives that you want t o delete.

2. From the Storage pull-down menu, select Logical Drive, then select

Delete. A system message a ppears, asking if you wa nt to delete all disks
in the group.

3. Click Yes to delete all the disks in the group.

Using Configuration Files

You can use a configuration file to save the conf iguration settings of t he
CR3500 RAID Controllers and disk drives and vi ew or reconstruct the settings
at a later time. You also can revert to one of these saved configurations at any
time. The CR3500 Configuration Utility read s the configuration file you
choose and se t s up your su bsystem accordingly.

Saving Configuration Settings to a File

From the Storage pull-down menu, select Controller, then select
Configuration, then select Save. The current c onfiguration settings, i ncluding
caches, LUNs, host ports, and strip size will be saved.

CAUTION: When saving a configuration, all controller data and RAID set data is
preserved at the time of the Save operation. When restoring a configuration, the
configuration being restored must match EXACTLY the configuration when it
was saved. Any RAID sets in existence when the Restore Configuration operation
takes place that were not in existence when the configuration was saved will be
reinitialized, and any data on those RAID sets will be lost. Make sure you have a
recent backup copy of your configuration data before you execute this operation.

Restoring Configuration Settings from a File

You can automatically restore or configure your entire storage subsystem from
a previously saved configuration file. The CR3500 Configurati on Utility can
configure your subsystem from a file only if t he file corresponds to your
subsystem’s har d wa re confi g ur ati on.

3-28 Compaq ProLiant CL1850 Software User Guide

From the Storage pull-down menu, select Controller, then select
Configuration, then select Restore .

All of the configurati on settings, i ncluding caches, LUNs, host port, and strip
size will be restored to their original condition.

CAUTION: When restoring a configuration, the configuration being restored
must match EXACTLY the configuration as it was saved. Any RAID sets in
existence when the Restore Configuration operation takes place that were not in
existence when the configuration was saved will be reinitialized, and any data
on those RAID sets will be lost.

You will not be able to restore the original configuration settings if the original
hardware and connections have been replaced or if the original configuration
settings were not saved before implementing the changes.

Updating Firmware

At some time, new firmware may be released for the CR3500 RAID
Controller. This firmware can be obtained from the Compaq website. To
update the firmware on the controller, select Update Firmware from the
Storage pull–down menu from the main screen. Enter the new firmware file
location and click Update.

IMPORTANT: Microsoft Cluster Server service, SNMP service, and any I/O must be
stopped during the firmware update.

Upgrading from a Single Controller
to Redundant Controllers

To upgrade your system from a single CR3500 RAID Controller to a
redundant CR3500 RAID Controlle r configuration, follow these steps.

1. Save the existing single controll er configuration usi ng the Save

Configurat ion function.

2. Suspend all I/O and power down the shared storage subsystem.

CR3500 Configuration Utility 3-29

3. Install the redundant contr ol ler in the bottom controller slot of the

shared storage subsystem.

4. Power up the shared storage subsystem.

5. Restore the controller configuration settings that you saved in Step 1.

NOTE: If restoring configuration settings using a serial connection, both controllers must
be attached to the host machine.

Error and Warning Messages

When you start the CR35 00 Configuration Utili ty, the softw are checks each
controller to detect e rrors in its configuration. If a problem is found, the
CR3500 Configuration Utility displays an error warning message that
describes the problem.

IMPORTANT: If a warning message indicates “Internal Error Has Been Detected” and
cites an error code number, the problem requires assistance from Compaq technical
support. See the “About This Guide” section at the beginning of this book for technical
support phone numbers.

Refer to the Online Help for more information.

Chapter 4

Integrated Management Log

NOTE: The Compaq Integrated Management Log (IML) only records events for the server

nodes. The IML does not record events in the shared storage array.

The Compaq Integrated Management Log (IML) records events and stores
them in an easily viewable form. The Compaq Integrated Management Log
records hundreds of events and then marks each e vent with a time-stamp with
one-minute granularity.

Events listed in the Compaq Integrated Management Log are categorized as
one of four event severity levels:

■ Status–indicates that the message is informational only.

■ Repaired–indicates that corrective action has been taken.

■ Caution–indicates a nonfatal error condition.

■ Critical–indicates a component failure.

The Compaq Integrated Management Log requires Compaq Operating
System-dependent drivers. Refer to the Compaq SmartStart and Support
Software CD for instructions on insta l ling the appropriate dr i vers.

4-2 Compaq ProLiant CL1850 Software User Guide

Multiple Ways of Viewing the Log

You can view an event in the Compaq Integrated Manageme nt Log two w ays:

■ From within Compaq Insight Manager

■ From within Compaq Survey Utility

Compaq Insight Manager

Compaq Insight Manager is a server management tool providing in-depth
fault, configuration, and performance monitoring of hundreds of Compaq
servers from a single management console. The system parameters that are
monitored describe the status of all key server node components.

By being abl e to view the events that occur, y ou can take immediate ac t ion.
You can view and print the event list from within Compaq Insight Manager by
following the instructions below. You can also mark a critical or caution event
as repaired after the affected component has been replaced, for example, if a
fan that has failed has been replaced. You can lower the severity of the event
by marking it as repaired.

Viewing the Event List

1. From Compaq Insight M anager, select the appr opriate server node; then

select View Device Data.

The selected server node is displayed with buttons around it s perimeter.

2. Select the Recovery button.

3. Select Compaq Inte grated Management Log.

NOTE: You can only view the list from the Recovery/Integrated Management screen. To
print the list, follow the instructions in the following section.

4. If a failed component has been replaced, select the event from the list

and then select Mark Repaired.

Integrated Management Log 4-3

Printing the Event List

NOTE: You can only view the list from the Recovery/Integrated Management Log screen

as described above. To print the list, follow the instructions below.

1. From Compaq Insight M anager, select the appr opriate server node. The

selected server node displays with buttons around its perimeter.

2. Click t he Configuration button.

3. Click the Recovery button.

4. Click Print.

Compaq Survey Utility

The Compaq Survey Utility is a serviceability tool available for Microsoft
Windows NT and Novell NetWare that delivers online configuration capture
and comparison to maximize serve r node availability. It is deliver ed on the
Compaq Management CD in the Cluster Setup and Manageme nt pack, or is
available on the Compa q website. Re fer to the Compaq Management CD for
information on installing and running the Surve y Utili ty.

After you have run the Survey Utility, you can view the Compaq Integrated
Management Log by loading the output of the utility (typically called
SURVEY.TXT) into a text viewer such as Microsoft Notepad. The event list
follows the system slot information. Once yo u have opened the text file, you
can print it using the print feature of the viewer.

4-4 Compaq ProLiant CL1850 Software User Guide

List of Events

The event list displays the affected components and the associated error
messages. Al though the same basic information is displayed, the format of the
list may be di fferent depending on how you are viewing i t from within
Compaq Insight Manager or the Compaq Survey Utility.

The following table identifies the event types (affected components) and
associated event messages.

Table 4-1

Event Messages

Event Type Event Message

Machine Environment

Fan Failure
Fans Not Redundant
Overheat Condition

System Fan Failure (Fan X, Location)
System Fans Not Redundant
System Overheating (Zone X, Location)

Main Memory

Correctable Error Threshold
exceeded

Corrected Memory Error threshold passed (Slot X, Memory Module X)
Corrected Memory Error threshold passed (System Memory)
Corrected Memory Error threshold passed (Memory Module unknown)

Uncorrectable Error Uncorrectable Memory Error (Slot X, Memory Module X)

Uncorrectable Memory Error (System Memory)
Uncorrectable Memory Error (Module unknown)

Processor

Correctable Error Threshold
exceeded

Uncorrectable Error
Host Bus Error

Processor Correctable Error Threshold passed (Slot X, Socket X)

Processor Uncorrectable internal error (Slot X, Socket X)
Unrecoverable Host Bus Data Parity Error
Unrecoverable Host Bus Address Parity Error

PCI Bus Error PCI Bus Error (Slot X, Bus X, Device X, Function X)
POST Error POST Error: Error message

continued

Integrated Management Log 4-5

Table 4-1
Event Messages

continued

Event Type Event Message

Power Subsystem

Power Supply Failure
Power Supply Inserted
Power Supply Removed
Power Supply Not Redundant
System Configuration

Battery Low
Power Module Failure

AC Voltage Problem
Power AC Overload

System Power Supply Failure (Power Supply X)
System Power Supply Inserted (Power Supply X)
System Power Supply Removed (Power Supply X)
System Power Supplies Not Redundant
Real-Time Clock Battery Failing

A CPU Power Module (System Board, Socket X)
A CPU Power Module (Slot X, Socket X)
System AC Power Problem (Power Supply X)
System AC Power Overload (Power Supply X)

Automatic Server Recovery

System Lockup ASR Lockup Detected: Cause

Operating System

System Crash

Automatic OS Shutdown

Blue Screen Trap: Cause [NT]
Kernel Panic: Cause [UNIX]
Abnormal Program Termination: Cause [NetWare]
Automatic Operating System Shutdown Initiated Due to Fan Failure
Automatic Operating System Shutdown Initiated Due to Overheat

Condition
Fatal Exception (Number X, Cause)

Chapter 5

System Management for Microsoft

Windows NT Server 4.0,

Enterprise Edition

Throughout the life of your Compaq ProLiant CL1850 you will encounter the
need to improve performance, upgrade hardware components, upgrade
software, increase storage capacity, restructure cluster groups, back up cluster
data, or merely monitor ongoing activities. This chapter describes the se
management concepts a s t hey pertain to Microsoft Cluster Ser ve r (MSCS)
clusters. The chapter also details the utilities and programs used in the ongoing
management of your system. The topics addressed in this c hapter incl ude:

■ Cluster Management Conce pts

■ Compaq Insight Ma nager

■ Microsoft Clust er Administrator

■ Modifying Physic al Cluster Resources

■ Backing Up Your Cluster

■ Managing Cluster Performance

5-2 Compaq ProLiant CL1850 Software User Guide

Cluster Manageme n t Conce p ts Usi ng
Microsoft Windows NT

Managing a Cluster without Interrupting
Applications or Services

At some time during the life of your system, it is likely you will need to
perform an operation on a server node that will require it to be powered down.
Always use Cluster Administrator to fail over (or at a minimum, bring offline)
clustered a pplications before powe ring dow n t he server.

Managing a Cluster in a Degraded Condition

Due to the high-availability nature of clustering, applications and network
clients remain operational even while some cluster components do not. When
the cluster is in this degraded condition, it is important to fo llow this process:

1. Under s tand what caused the de gradatio n.

2. Determine whether the condition will conti nually worsen.

3. Determine how critical it is to repair the problem.
a. If the problem is considered noncritical, wait until a nonpeak time to

service the problem.

b. If the problem is considered critical, fail over all cl ustered

applications and resources to the other server node before servicing
the proble m.

Managing Hardware Components of Individual
Server Nodes

Compaq Insight Manager has been enhanced to operate with the Compaq
ProLiant CL1850. While Compaq Insight Manager maintains its current
features of viewing and managing servers and their components, it now allows
you to view t wo server nodes as a single cluster e nt ity. A comprehensive
overview of Compaq Insight Manager’s cluster capabilities appears later in
this chapter.

System Management for Microsoft Windows NT Server 4.0, Enterprise Edition 5-3

Managing Network Clients Connected to a Cluster

An important aspect of m anaging network clients is to inform the users that
their applications are now running on a cluster. Since users will experience
some disruption of service, and possibly a performance degradation during
failover, they might become concerned about the availability and stability of
their applications. As the cluster is initially brought into a production
environment, it might be beneficial to describe in a memorandum the effects a
cluster will have on the users ’ information systems needs.

When a failover or failback event occurs, the users’ perspective will be only
that they cannot access their application or data. When users have been
properly forewarned of the effects of operating in a clustered environment,
they will more readily recognize when a failover or failback event is occurring
or has occurred. Most will wait several minutes before trying to reconnect to
their application or data.

Managing a Cluster’s Shared Storage

Compaq Insight Manager monitors the cluster. The physical drives and
hardware are monitored via the Mass Storage Overview screen, accessed from
the Device View screen.

The shared logical drives (as well as other cluster resources and services) are
monitore d vi a the Cluster Management and Cluster Shared Re sources scr eens,
accessed from a cluster folder in the Device List.

Because this storage system is shared, either server node could be the owner of
any shared logical drive. While only one server node can own the logical drive
at any given time, ownership can sw itch from one server node to another.
Compaq Insight Manager reports the current owner of a logic al drive and
updates this informat ion dynamically if a failover occurs.

NOTE: Compaq Insight Manager shows the shared logical drives as cluster resources
owned by a particular server node. It shows the cluster hardware as a physical resource
of both servers in the cluster.

When viewing the Compa q Insight Manager Cluster Shared Resources screen,
you can dete rmine which logical drive contains a parti cular dri ve by looking at
the Physical ID field under the Shared Resources heading.

5-4 Compaq ProLiant CL1850 Software User Guide

Remotely Managing a Cluster

Both Compaq Insight Manager and Mic rosoft Clust er Administ rator can be
run from network client machines . Each pr ogram allows monitoring of
multiple clusters from a single remote client. See the corresponding
documentation to determine how to set up and configure each of these
programs to run remotely.

Cluster Events

Cluster events are logged in the Windows NT Event Log. Use the
Windows NT Event Viewer to view the data in the Event Log.

Compaq Insight Mana ge r

Compaq Insight Manager is the Compaq applica tion for eas ily managing
network de vi ces. Compaq Insight Manager delivers intelligent mo ni toring and
alerting as well as visual control of your networked systems. Compaq I nsight
Manager 4.50 or great er has been updated to r ecognize and monitor t he
Compaq ProLiant CL1850. The foll owing is an overview of the cluster­specific features found in Compaq Insight Manager.

NOTE: The term cluster group used in this section refers to Compaq Insight Manager, not
to Microsoft Cluster Server.

System Management for Microsoft Windows NT Server 4.0, Enterprise Edition 5-5

Explorer Device List Screen

When Compaq Insight Manager discovers a cluster, a cluster group is
automatic ally created and added to the Group window of Insight Manager’s
Explorer Device List screen (Figure 5-1). The cluster protocol and address are
also displayed.

Figure 5-1. Insight Manager Explorer Device list screen

When the cluster group i s selected in the Group window, the two server n odes
and a generic Cluster Software item are listed in the Device window of Insight
Manager’s Explorer Device List screen (Figure 5- 2).

Figure 5-2. Explorer Device list screen, Cluster Group selected

5-6 Compaq ProLiant CL1850 Software User Guide

Cluster Management Screen

Compaq Insight Manager includes a Cluster Management scree n. From the
Cluster Management screen you can:

■ Launch Microsoft Cluster Administrator

■ Bring up the Compaq Insight Manager Cluster Shared Res ources screen

■ View the status of the cluster service running on each server node

■ View the overall status of all cluster resources. This information is

updated dynamically.

You can launch the Cluster Management screen (Figure 5-3) by using any of
the following methods:

■ Select from the Task List or right-mouse menu of a clustered device.

■ Select from the right-mouse menu of the Cluster Software item.

■ Double-click on the Cluster Software item.

Figure 5-3. Cluster Management screen

If Microsoft Cluster Administrator is installed on the Compaq Insight Manager
console, you can launch Cluster Administrat or by clicking on the Cluster
Administrator button near the upper-right corner of the screen, or by selecting
an option from the right-mouse menu of the Cluster Software item. Cluster
Administrator will launch directly to the cluster represented by the Cluster
Manageme nt screen.

System Management for Microsoft Windows NT Server 4.0, Enterprise Edition 5-7

Cluster Shared Resources Screen

The Cluster Shared Resources screen (Figure 5-4) contains specific
information about the cluster interconnect and all cluster resources running on
the server node.

From the Com paq Insight Manager Cluster Shared Resources screen you can:

■ View address, transport protocol, and physical ID of all cluste r

interconnects

■ View the current state of all cluster resources

■ Sort the interconnect information and resources by multiple criteria

Figure 5-4. Cluster Shared Resources screen

All displayed interconnect and resource information is polled and updated
dynamically, including status and ownership.

For example, assume two drive volumes are defined in your shared storage.
The primar y owner of the drive volume labeled E: is server node 1. The
primary ow ner of the drive volume labeled F: is server node 2. When the
cluster is in a normal state, Insight Manager will show E: as being owned by
server node 1, and F: as being owned by server node 2. When a failover eve nt
occurs, ownership of t he drives changes. Assume server n ode 1 experiences a
failure and its resources fail over to server node 2. When the failover is
complete a nd Insight Manager polls the clust er, server node 2 will be
identified as the owner of both F: a nd E:.

5-8 Compaq ProLiant CL1850 Software User Guide

Cluster Group Hierarchy

You can manage cluster groups at a n appropri ate level in the group hierarchy.
Cluster gr oups are always displayed at the All Devices le vel (Figure 5-5), but
cluster group shortc ut s can be added to other groups.

Figure 5-5. Sample group hierarchy

System Management for Microsoft Windows NT Server 4.0, Enterprise Edition 5-9

Filter Groups Dialog Box

The Filter Groups dialog box (Figure 5-6) is used to create, edit, or delete
groups in the group list hierarch y.

Follow these steps to launch the Filter Groups dia log:

1. From the G roup window in the Dev i ce List window , select the group

you want t o work with. (For exampl e, if you want to create a group
within Network, select Network.)

2. Select the Set Up Group button on the control bar.

Figure 5-6. Filter Groups dialog box

The Insert cluster shortcut button allows you to create shortcuts for existing
cluster groups and place them in different levels in the group hierarchy.

Cluster Address

A cluster address acts as a proxy, communicating with different servers in the
cluster depending on the state of the cluster. A Compaq Insight Mana ger
device using a cluster address may switch communication from one physical
device to another, whi ch may result in erroneous inform ation being delivered.
Consequen tly, Compaq Insight Manager does not allow management of a
device that uses a known cluster address.

5-10 Compaq ProLiant CL1850 Software User Guide

Microsoft Cluster Administrato r

While the primary res ponsibility of Compaq Insight Manager is to monitor the
overall status of the cl uster hardware, services , and resources, Microsoft’s
Cluster Administrator is most ade pt at managing the groups , resources, and
operating state of the cluster. Cluster Administr ator gives you the ability to:

■ View the current st atus of cl uster groups and resources

■ Bring groups an d resources online and of fline

■ Manually move groups and re sources t o another ser ver node

■ Manually move groups and resources t o their preferred server

■ Pause groups and re sources

■ Restructure a group’s resource dependency tree

Cluster Administrator can be run remotely or on a server node. If Cluster
Administrator is installed remotely, the remote node must be i n t he same
domain as t he server node . When run ni ng Cluster A dministrat or remotely, you
should connect to the cl uster via Compaq Insig ht Manager or by using the
cluster IP address or cl ust er name.

NOTE: The remote feature is not supported in Microsoft Windows 95/98.

Refer to the Microsoft Cluster Server Administrator’s Guide for a thorough
descripti on of Cluster Administrator’s features and specifics on how to use the
utility.

Modifying Physical Cluster Resources

Removing Shared Storage

Each server node, and the cluster as a whole, depends on the shared storage for
data, log, and, possibly, application program files. If the s hared storage is
removed, all clustered applications that are dependent on that shared storage
system will be offline. Clearly, network clients will not have access to the
clustered applications.

Before removing a shared storage system (that is, the cluster), use Cluster
Administrator to bring offline all c luster groups and resources on both server
nodes. This ensures the groups and resources are gracefully brought offline,
rather tha n causing an abrupt interruption of service by pow ering down the
cluster.

System Management for Microsoft Windows NT Server 4.0, Enterprise Edition 5-11

Adding Shared Storage

A ProLiant storage syste m cannot be added while the cluster is running.
Follow these steps to add another shared storage system to an existing cluster.

1. Use Mic rosoft Clus t er Adminis trator to bring all cluster groups and

resources offline.

2. When i nst alling the new storage system, you do not want the cluster

service to start automatically. On each server node, go into the
Windows NT Services Control Panel a pplet and set the cluster service to
Manual.

3. Shut down and power off both server nodes an d the shared storage

array.

4. Plug all of the SCSI drives into the shared storage array.

5. Power u p the newly a dded storage system and the CL1850 shared

storage array.

6. Power up server node 1 and run the CR35 00 Co nfiguration Utility. Set

up the logical drives.

IMPORTANT: Be sure you understand your cluster groupings of applications and
resources whose data, log, and program files may reside on these drives. See Chapter 4
for information on creating cluster group.

7. Run Disk Administra tor to assign permanent letters to the drive

volumes.

8. Shut down the server node 1.

9. Power u p the server node 2.

IMPORTANT: Do not run the CR3500 Configuration Utility on the second server node. The
information entered from the first server node is maintained on the drives; therefore, the
drives are already configured for the second server node.

10. Boot Windows NT on server node 2, then run Disk Administrator.

Verify that the drive letters displayed are the same as those assigned
from the first server node.

11. Power on server node 1 and allow it to boot into Windows NT. Go into

the Service Control Panel applet and start the cluster service. Start
Cluster Administrator and verify that the added drives ar e visible as
unassigned physical disk resources.

5-12 Compaq ProLiant CL1850 Software User Guide

12. On server node 2, go into the Service Control Panel applet and st art the

cluster service. Start Cluster Administrator and verify that the added
drives are visible as unassigned physical disk resources.

13. On the server node 1, create the groups or resources that use the new

physical disk resources.

14. Ensure that all applications and resources are still offline on both server

nodes. If not , take them offline.

15. On each server node, go into the Service Control Panel applet and set

the cluster service to start automatically.

16. Shut down and power down both server nodes.

17. Wait several seconds, then power up both server nodes. Windows NT

will start, followed by the execution of Cluster Server.

18. Run Cluster Administrator and verify t hat the original groups and

resources are in their expected states. Then verify that the added groups
and resources are in their expected states.

Adding or Removing Shared Storage Drives

There are two situations in which you would add or remove drives from the
shared storage:

■ When one of the drives fails. In this case, you are simply exchanging the

failed drive for a new one.

■ When you want to add capacity to your cluster.

In both sit uations, it is assumed you are employing RAID 1, 0+1, 4, or 5 for all
the devices in the storage unit.

Replacing a Failed Drive

The procedure for replacing a failed drive is completed within the storage area.
Neither Cluster Server nor Windows NT is aware of the change, and operation
of both cont inues without interruption.

IMPORTANT: If the failed drive was not configured to use RAID 1, 0+1, 4, or 5 (that is,
your drives have no fault tolerance), you may lose some or all of the data on the failed
drive.

See Chapter 3, “CR3500 Configuration Utility,” for instructions on replacing a
failed drive.

System Management for Microsoft Windows NT Server 4.0, Enterprise Edition 5-13

Adding a Drive to Increase Storage Capacity

It is foreseeable that during the life of your ProLiant CL1850 you will need to
expand the capacity of your storage system. The f ol lowing steps describe how
to add a drive to the system and to allocate it to Cluster Server.

NOTE: You cannot increase the capacity of an existing logical drive in the shared storage
array.

1. Physically add the drives to the system.

2. Run the CR3500 Configuration Utility to configure the drives.

3. Run Windows NT Disk Administrator from server node 1 to assign a

drive letter to the newly created RAID volume.

4. While still runnin g Dis k Administrator, format the drives using NTFS.

5. Cluster Server requires a reboot of each server node following the

addition of a drive. Shut down both servers and reboot them.

6. Following the reboot, start Cluster Administrator and verify all newly

added drive volumes appear to the cluster as available disk resources.

5-14 Compaq ProLiant CL1850 Software User Guide

Backing Up Your Cluster

The need for cluster backup is essential for both business- critical and non­business-critical data. As data becomes an increasingly valued company asset,
it needs to be backed up on a regular basis. The pr ocess of backing up data
will ensure that a company’s assets are secure and available when a disaster
strikes. The cluster itself provides a high degree of application availability but
does not prevent a user from deleti ng or corrupting a file or set of files.
Backing up a cluster’s data will increase the overall level of data availability.

Compaq currently suggests the use of one of the following solutions:

■ The first solution uses two tape backup subsystems, one tape backup

subsystem att ached to each server node.

■ The second solution shares a S C SI tape backup subsystem between the

two server nodes.

Each solution has its limitations from bot h the har dware and software
perspective. The limitations are due to the fact that tape backup software for
use with Win dows NT has not been updat ed for clustering. As Windows NT
clustering becomes more prevalent, tape backup vendors will update their
software to become cluster-aware.

The lack of cluster-aware tape backup software presents the user with two
problems:

■ First, there may be an inability to locate files when the cluster is in a

degraded state. For example, assume server node 1 owns a shared drive,
G:. A tape backup is performed fr om server no de 1 and drive G: is
backed up. At some point in the future, a need arises to restore some
files to drive G:. However, drive G: is in a failover state and is currently
owned by server node 2. An attempted restoration of the files from
server node 1 may fail if the tape bac kup software is unable t o
comprehend the shared characteristic of drive G:.

■ Second, if a failover or failback event occurs while a backup i s

executing, you may not be able to continue t he backup; you may be
required to restart the backup from the beginning. For example, if you
are backing up drive G: from server node 1 and a failover event moves
drive G: to server node 2, the backup process will abort since drive G: is
no longer accessible from server node 1. The backup process, if
configured as a cluster group and i f the backu p software su pports a
restart, can possibly be automatically restarted on server no de 2. Still,
the restarted backup will start at the beginning; the data placed on tape
by the inter rupted bac kup process o n server node 1 is lost.

System Management for Microsoft Windows NT Server 4.0, Enterprise Edition 5-15

Managing Cluster Performance

As applications or resources transfer from one server to a n other, the
performance of the clustered servers will likely change. The extent of the
performanc e change depends greatly on how well equipped the other se rver
node is to handle the increase in workload. This is especially obvious after a
server failure, where all of the cluster resources may move to the other server.

You can use the Windows NT Performance Monitor to observe and track
system performance. Some applications may also have their own internal
performance measurement capabilities. Constant monitoring of each system’s
performance in a cluster may identify a disparity in the workload being
performed by each server . Adjust the distribution of the clust er applica t ions so
that the overall cluster performance is maximized.

Dynamic load balancing is not available in the initial release of Microsoft’s
Cluster Server. However, Cluster Server does offer the ability to manually
load balanc e your server nodes. You can use information obt ained from
Performance Monitor to determine whether either of the server nodes is
operating at too high a performance level. Us e Cluster A dministrat or to fail
over as many cluster groups as necessary to balance the load of each server
node.

The timing of manuall y moving a cluster group to balanc e the load should
depend strongly on what type of group needs to be moved and how many
clients are using the group. File and print services are norma l ly not
business-critical, nor do they sustain an extrem ely high utilization rate. For
these reasons, file and print services are good candidates to move whenever
load balancing needs to occur, even when the overall cluster utilizati o n is high.

However, some applica t ions, such as databases, should not be moved from one
server to another duri ng peak processing periods. When a da tabase is m oved
from one server to another, the data base must be s hut down and r estarted.
During the time it takes the database to restart, users do not have access to the
database. In these cases, moving a database group to anot her server should be
performed during non peak hours.

Index

A

access panel labels vii
active/active 3-14, 3-16
active/passive 3-14, 3-16
add logical drive wizard 3-1
administrat ive tools 1-8, 1-9
applications

configuring 1-11
installing 1-11
setting up 1-11

arrays 3-1

mirrored 3-1
single device 3-1
striped 3-1

mirrored 3-1
parity 3-1

assisted integration path 1-2, 1-4,

1-6, 2-2, 2-4

B

boards, add-on xi
bus width 3-1 6
buttons

add logical drive 3-8
configuration 4-3
CR3500 Configuration

Utility 3-7

details 3-8

help 1-3, 1-4, 1-6, 1-7, 2-2,

2-4

accessing 1-2, 1-4
large icons 3-8
list 3-8
recovery 4-3
small icons 3-8

C

cables, network 2-7
cache 3-27, 3-28

limit 3-14
memory size 3-18
options 3-24
tab 3-13
writeback 3-23

capacity 3-24

adding 3-21

cards

network 2-7
SCSI ID 1-4, 1-6, 1-7

cautions

configurations

restoring 3-28

saving 3-27
logical drives 3-27

CDs

Compaq SmartStart 2-1
Management vii

2 Compaq ProLiant CL1850 Software User Guide

Microsoft Windows NT

Enterprise Edition 1-3, 1-5
SmartStart 1-1, 1-2
SmartStart and Support

Software vii
Systems Reference Library vii

cluster

capabilities 1-11
configuring 2-5
creating 1-8, 2-8, 2-9
documentation 1-11
group

bringing online 1-11
configuring 1-11

setting up 1-11
interacting with 1-10
IP address 1- 10
name 1-8, 2-8
object 2-8
partition 2-9
pausing 2-5
resources 1- 11

configuring 1-11, 2-9

creating 2-9
testing 2-7
verifying 1-8, 2-7

Cluster Administrator See

Microsoft, Cluster
Administrator

commands viii

accessing 3-6

Compaq

authorized reseller xi

telephone numbers x i
Insight Agents 1-3, 1-5
Insight Manager 1-1

installation poster 1-1
Integration TechNotes 1-11
service hours x
SmartStart 1-1, 1-4, 2-1

installation poster 1-1

manual installation 1-5
Survey Utility 4-3
System Tools 3-3, 3-4
System Tools Folder 1-7

Technical Phone Support

Center x

website x, xi, 1-12, 3-28

configuration

logical drive 3-2
Novell NetWare 2-1
procedures 3-2, 3-13
reconstructing 3-27
restoring 3-29
saving 3-27, 3-28
server node 1- 4
settings

caches 3-27
host ports 3-27
LUNs 3-27
restoring 3-27
saving 3-27

strip size 3-27
system 1-2
using files 3- 27
viewing 3- 27

connection

checking 1-10
CTRL-1 3-4
CTRL-2 3-4
network 3-15
online 3-3
SCSI 3-15
serial 3-5, 3-15, 3-29
status 2-7

console, HA Server 2-7
controllers

active 3-14
adding 3-13
configuration settin gs 3-27
configuring 1-3, 1-7, 3-1, 3-13
dual 3-5
errors 3-29
failed, replacing 3-24
icons 3-12
memory 3-18
mode 3-14
modifying properties 3-13
operatio nal 3-12
optional 3-2
reconfiguring 3-1

Index 3

redundant 3-2, 3-13

installing 3-29
serial connection 3-3
serial number 3-15
setting up 2-3, 2-4
shared storage 1-6
single 3-14
status 3-12
unavailable 3-14
Wide Ultra2 SCSI 1-2, 1- 4,

1-6, 1-8, 2-3, 2- 4

writing data 3-26

CR3500 Configuration Utility 1-3,

1-5, 1-7, 2-3, 2- 4, 3-1

features 3-2
installing 1-6, 3-3, 3-4
running 3-3 , 3-4
warning me ssages 3-2 9

create rate 3-15

D

desktop 1-8
DHCP 1-10
Disk Administrator 1-3
documentation

cluster 1-11
Microsoft Cluster Server

Administrator 1-3, 1-7
MSCS 1-5
operating system 1-1, 2-1
technical 1-12

drivers 1-3, 1-5, 1-7, 1-8

information on xi

drives

adding 3-18
assigning letters 1-3
configuration settin gs 3-27
failed 3-9

managing 3-26

replacing 3-25
good 3-9
initializing 3-10

logical 1-3, 1-7, 2- 3, 2-4, 3- 8

adding 3-19
creating 3-1
defined 3-1
deleting 3-27
locating members 3-10
property sheets 3-10
RAID 0+1 3-26
RAID 1 3-26
RAID 4 3-26
RAID 5 3-26
window 3-10

parity

fixed 3-1
floating 3-1

physical 3-10

adding 3-18
information 3-11
setting as spare 3-26

target ID 3-19
quorum 1-3
reconstructing 3-10
reduced 3-10
selecting 2-9
shared stor age 1-3, 1-5, 1-10
spare 3-25

defining 3-26

managing 3-26

E

environments

cluster 1-11
controller properties 3-18
machine 4-4
redundant 3-25
single controller 3-24
tab 3-17

Error Log 1- 3, 1-4
error messages x
errors

correctable 4-4
host bus

address parity 4-4

data parit y 4-4

4 Compaq ProLiant CL1850 Software User Guide

PCI bus 4-4
uncorrect able 4-4
unrecoverable 4-4

event

messages

associated 4-4
log 4-4
table 4-4

severity levels

caution 4-1
critical 4-1
repaired 4- 1
status 4-1

type 4-4, 4-5

event list

IML 4-4
printing 4- 3
viewing 4- 2

F

failback

automatic 2-5
manual 2-5

failover 1-9, 2-8

automatic 2-5
Lotus Domino Server 1-12
manual 1-10, 2-5
mode 3-14, 3-16
resource 1- 12

using Orac l e 1-12
FailSafe, Oracle 1-12
failure, clearing 3-26
fans, monitoring 3-17
fault tolerance 2-9

determining 3-2

method 3-2
features

configuration utility

main wind ow 3-6
online co nnection 3-3
serial cable connection 3-3
SmartStart CD 3-3

file names viii
files, configuration 3- 27

firmware

updating 3-28
firmware revision 3-15
Flash ROM xi

G

getting help x
graphical user interface 3-1
groups

deleting members 3-27

device 3-26

predefined 1-9

H

HA Server 2-5, 2-7. See also

Novell, High Availability Server

documentation 2-8

failover 2-8
hardware

add-on xi

cluster 1-11

configuration 3-27

configuration and installation

poster 1-1, 2-1
configuring 1-2, 1-4, 1-6, 1-7
installing 1-2, 2-2
modification 1-2, 1-4, 1-6
modifying 1-8
review 1-2 , 1-4, 1-6, 1-8
settings 1-2, 2-2, 2-4
third-par ty xi

help

additional sources x
Compaq

authorized resellers xi

website xi
menu 3-7
online 1-2, 1-3, 1-4, 1-6, 1-7,

2-2, 2-4, 3-2, 3- 7, 3-1 7,

3-29
technical support x
telephone numbers x
toolbar 3-2

high availability 3-14, 3-16

Index 5

high performance 3-14
http://www.compaq.com x, xi, 1-12

I

I/O

activity 3-14
channel mode 3-16
host 3-16
response 3-14

icons

add logical drive 3-8
controllers 3-12
detail button 3-8
failed drive 3-26
JBOD 3-9
large 3-8
list button 3-8
logical drive 3-10
logical drive state 3-9, 3-10
physical drive 3-10, 3-26
RAID 0 3-9
RAID 0+1 3-9
RAID 1 3-9
RAID 4 3-9
RAID 5 3-9
small 3-8
status 3-12
symbols on equipment ix
tool bar 3-8
using 3-7

warning 3-17
IIS 1-11
IMD 4-2
IML

defined 4-1

event list 4-4

printing from Insight

Manager 4-2
requirements 4-1
severity levels 4-1
viewing

from Insight Manager 4-2
log 4-2
using Survey Utility 4-3

information

capacity 3-10
name 3-10
RAID level 3-10
setup 1-11
sources 1-11
state 3-10
storing 1-3
technical vii

installation

final screen 2-9
HA Server 2-5
hardware 2-2
manual 1-5
Novell Cluster Services 2-8
operating system 2-2
overview 2- 2
poster 2-1
software 2-2

Integrated Management

Display See IMD

Integrated Management Log See

IML

IP addresses 1-8, 1-9, 1-10, 2-9

J

JBOD 3-1

K

KVM switch 1-4, 1-7, 2-3

L

labels, access panel vii
languages, selecting 1-2
logical drives 1-7

adding 3-19, 3-25

capacity 3-21
attributes 3-10
creating 3-1, 3-18
defined 3-1
deleting 3-27
display 3-8
icons 3-8, 3-9

6 Compaq ProLiant CL1850 Software User Guide

increasing capacity 3-18
locating members 3-10
name 3-10
reconstructing 3-25
reduced state 3-25
setting up 2-3, 2-4
state 3-10
status 3-9
storage available 3-20
strip size 3-22
types 3-9
window 3-9, 3-10

wizard 3-1
Logical Unit Number See LUN
Lotus Domino Server 1-12
LUN 3-23, 3-27, 3-28

M

management

CD vii

Insight Manager 4-2

tool 4-2
manual configuration 1-6
manual configuration path 1-7
manual installation 1-5, 1-6
memory

cache 3-18

main 4-4

size 3-18
menu bar 3- 7
menus

accessing 3-6

file 3-7

help 3-7

shortcut 3-7

storage 3-7 , 3-26

view 3-7
messages

error 3-2, 3-29

warning 3-2, 3-29

Microsoft

Cluster Administrator 1-8,

1-9, 1-10

Cluster Server 3-28

Administrator 1-3, 1-5

administrator’s guide 1-1, 1-11
Disk Administrator 1-3, 1-7
Enterprise Edition

Installer 1-3, 1-5, 1-7
file service 1-11
Internet Information

Server 1-11
Notepad 4-3
NTFS 1-3, 1-7
print service 1-11
resource failover using

MSCS 1-12
service failover 1-11

using MSCS 1-11
SQL Server 1-12
Windows NT

administrator’s guide 1-1

configuration 1-1

Explorer 3-3

installation 1-3

logging in 1- 3

system setup 1-1

MSCS 1-1, 1- 7

administrator 1-3, 1-5, 1-7
Internet Information

Server 1-11

N

names

cluster 1-9
directory viii
drive viii
server node 1- 9

NCS See Novell, Cluster Services

Index 7

network

cable 2-8
card 2-7
client

failover 1-10

connection type

SCSI 3-15
serial 3-15

machine 1-10
nodes See server nodes
Novell

Cluster Services 2-8, 2-9

documentation 2-5

High Availability Server 2-1

NetWare

4.2 2-1, 2-5
5 2-1
configuration 2-1
link disconnect 2-7
setup 2-1
testing 2-7
volumes 2-9

NTFS 1-3

O

online co nnection 3-3
operating system 3-14

documentation 1-1, 2-1

installing 2-2

revision level xi

selecting 1-2, 1-4, 1-6, 1-7

shutdown 4-5

software rights 1-2

type xi
options view 3-8
Oracle

FailSafe 1-12

service failover 1-12

using MSCS 1-12

P

partition 2-9
physical drives

available 3-12, 3-20
failed 3-12
good 3-12
recognizing 3-18
reconstructing 3-12
spare 3-12

states 3-12
PING command 1-10
ports

COM1 3-5

COM2 3-5

CTRL-1 3-4

CTRL-2 3-4

host 3-22, 3-27, 3-28
posters

Hardware Configuration and

Installation 1-1, 2-1

Insight Manager

Installation 1-1, 2-1

SmartStart Installation 1-1,

2-1

power

monitori ng 3-17

supplies

failure 4-5
inserted 4-5

removed 4- 5
preconfiguration checks 1-2, 2-2
product

information on xi
model

names x

numbers x

numbers

model x

serial x
property sheets 3-10

8 Compaq ProLiant CL1850 Software User Guide

R

RAID

0 3-1
0+1 3-1, 3-26
1 3-1, 3-26
4 3-1, 3-26
5 3-1, 3-26
cache options 3-24
capacity 3-24
integrity 3-26
level 3-1, 3-2, 3-24

selecting 3-19
member ph ysical drives 3-24
requirements 3-26
sets 3-27, 3-28

rebuild rate 3-14
reconstruction 3-25
registration number x
resources

accessing 1-10
cluster 1-9
configuring 2-9
creating 2-9
failover 1-12
online 1-10
predefined 1-9
templates 2-9

RJ-45 receptacle ix

S

screens

add new physical drive 3-19
Cluster Administrator 1-10
configuration 1-3, 1-5
confirm file replace 1-3, 1-5
connection 3-3, 3-5
controller properties 3-13
DOS 1-10
final installation 2-9
help 3-2
initial splash 2-8
installation 2-8
logical drive 3-6, 3-8
menu bar 3- 6

physical drive 3-6, 3-11
product selection 1-3 , 1-4,

2-3, 2-4
refreshing 1-10
select language 1-2, 1-4, 1-6,

1-7, 2-2, 2-3
status bar 3-2
tool bar 3-6
Windows NT installation 1-5

SCSI

connection 3-3
ID 1-2, 1-4, 1-6, 1-7, 1- 8, 2-3,

2-4
transfer rate 3-17
Wide Ultra2 controller 1-2,

1-4, 1-8, 2-3, 2- 4

serial numbers x, 3-15
server node s

adding to cluster 2-9
booting 1-4, 1-6, 1-7, 2-2, 2-3
configuring 1-2, 1-4, 1-7, 2-2,

2-3
failover 1-9
hardware, configuring 1-2
name 1-8
powering off 1-8
powering on 1-8
SCSI ID 1-2
