Compaq Combo Mouse Owner's Manual

2-Button 3D Optical
Combo Mouse

with Scroll Wheel

Owner’s Manual

Please read before using this equipment.

ˆ

Contents

Features .............................................. 4

System Requirements ...................... 5

FCC Statement .................................... 6

Installation .......................................... 8

Hardware ......................................... 8

Computer with USB Mouse Port .. 8
Computer with PS/2 Mouse Port . 9

Software ......................................... 10

Operation .................................. ........ 13

Configuring the Mouse ................... 13

Buttons Tab ................................ 15

Pointers Tab ............................... 16

Motion Tab ................................. 17

Double-Click Tab ....................... 18

2001 RadioShack Corporation. All Rights Reserved.

©

RadioShack and RadioShack.com are trademarks

used by RadioShack Corporation.

Compaq is registered by the U.S. Patent and

Trademark Office.

2

Contents

Orientation Tab .......................... 18

Wheel Tab ................................. 19

Pointer Utility Tab ...................... 20

Mouse Suite Tab ....................... 22

General Tab .............................. 22

Special Functions ............................ 23

Using the Wheel ............................ 23

Scroll ........ ................................. 23

Auto Scroll ................................. 24

Zoom ......................................... 25

Using Hyper Grid ........................... 25

Troubleshooting ............................... 30

Care ................................................... 33

Contents

3

ˆ

Features

Your Compaq 2-Button 3D Optical Com­bo Mouse is designed specifically for
notebook PCs or PCs with either a uni­versal serial bus (USB) or PS/2 port. You
can scroll, zoom, or click using the scroll
wheel and programmable buttons.

Optical Sensing Technology

es mouse movement precisely and
smoothly, with no moving parts to clean
or replace.

True 400 DPI (Dots per Inch) Resolu­tion

— use the mouse with a monitor that
supports 1024 × 768 resolution or more,
letting you move your mouse fluidly
across higher resolution monitors.

4

Features

— sens-

Supplied Driver CD

configure your mouse with almost any
IBM-compatible computer.

— lets you quickly

SYSTEM REQUIREMENTS

Hardware

one available USB or PS/2 port and a CD
drive.

Software

dows 98, Windows 2000, or Windows
ME.

Note:

the USB port, Windows 98, 2000, or ME
must be installed on your computer.

— IBM PC or compatible with

— Microsoft Windows 95, Win-

To use the mouse connected to

Features

5

ˆ

FCC Statement

This device complies with Part 15 of the

FCC Rules

following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any interfer­ence received, including interference that
may cause undesired operation.

This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to Part 15 of
the
signed to provide reasonable protection
against harmful interference in a residen­tial installation. This equipment gener­ates, uses and can radiate radio
frequency energy and, if not installed and
used in accordance with the instructions,

. Operation is subject to the

FCC Rules

. These limits are de-

6

FCC Statement

may cause harmful interference to radio
communications.

However, there is no guarantee that inter­ference will not occur in a particular in­stallation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct the in­terference by one or more of the following
measures:

• Reorient or relocate the receiving
antenna.

• Increase the separation between the
equipment and receiver.

• Consult your local RadioShack store
or an experienced radio/TV techni­cian for help.

FCC Statement

7

ˆ

Installation

HARDWARE

Notes:

• Refer to your computer’s owner’s
manual for the location of the USB or
PS/2 port.

• The mouse only works with a USB or
PS/2 port. Do not use a serial port
adapter.

Computer with USB Mouse
Port

1. With the computer on, connect the
mouse cable’s rectangular USB plug
to the computer’s USB port.

8

Installation

2. Proceed with software installation.
See “Software” on Page 10.

Computer with PS/2 Mouse
Port

1. Turn off the computer.

2. Connect the supplied PS/2 adapter
plug to the mouse cables’ USB plug.

3. Plug the mouse cable’s round PS/2
plug to the computer’s PS/2 mouse
port.

4. Turn on the computer.

5. Proceed with software installation.
See “Software” on Page 10.

Installation

9

SOFTWARE

To use all of the mouse features, you
must install the supplied Mouse Suite
software onto your computer.

1. Insert the Mouse Suite software CD
into your CD-ROM drive.

Start

2. Click

on the task bar.

3. Click

4. Type

Run

.

<drive>:\setup

in the
box. (For example, if the software
setup CD is in drive D, type

5. Click

Setup

6. Click
tion. The

tion

10

OK or Enter

screen appears.

Next

to continue the installa-

Hardware Interface Selec-

screen appears.

Installation

. The

Mouse Suite

Run

d:\setup

dialog

.)

7. Select

PS/2 Interface

a PS/2 port, or

Bus) Interface

port.

if you are using

USB (Universal Serial

if you are using a USB

8. Click

9. Select

Next

tion

screen appears.

Right side of the keyboard

you are right-handed, or

the keyboard

10. Click

Next

Choose Mouse Loca-

. The

Left side of

if you are left-handed.

. The

Start Installation

if

screen appears.

11. Verify that the configuration settings
on the screen are the ones you pre­viously selected.

Back

If they are not, click

to return to
the appropriate screen and adjust
your configuration settings.

Installation

11

Otherwise, click
matically copied, then the

Complete

Next

. Files are auto-

screen appears.

Setup

12. Remove the Mouse Suite software
CD from the driver.

13. Select

Finish

12

Restart my computer now

and

to activate the mouse settings.

Installation

ˆ

Operation

CONFIGURING THE MOUSE

1. Click

2. Double-click the

Start

, then

trol Panel

Mouse Properties

appears.

.

Operation

Settings

, then

Mouse

icon. The

dialog box

Con-

13

Notes:

•The

Mouse Properties

dialog box
contains several tabs, which vary
depending on the default configura­tion of your operating system. The
tabs described in this manual are
common for most operating systems.

14

Operation

• For unique tabs that are not avail-

able for other operating system(s),
refer to that operating system’s
user’s guide or help menu.

•The

Buttons

default tab when the

ties

dialog box is opened. Click on

tab appears as the

Mouse Proper-

another tab to open that tab.

• After selecting the desired functions

OK

in each tab, click

.

Buttons Tab

The mouse buttons can be assigned to
any function listed in the corresponding

Function

drop-down menu.

Operation

15

The default settings for your mouse but­tons are as follows:

Button Function

Left Button Primary Mouse Button

(standard click and drag

action)
Wheel Button Quick/Auto Scroll
Right Button Context Menu

Use Default

Click

at any time to restore

the default button settings.

Pointers Tab

This tab allows you to customize the
pointer’s appearance. Select a pointer
display from the

Customize

a scheme to apply from the
down list.

list, or select

Scheme

drop-

16

Operation

Use Default

Click

at any time to restore

the default pointer setting.

Motion Tab

Note:

If you are using Windows ME, the

Motion

tab is replaced by the

tions

tab. Refer to your operating system

manual for more information on this tab.

Pointer Op-

Pointer speed

— Adjust how fast or slow

the pointer travels across the screen as
you move it. Drag the
er toward

Note:

adjust

Pointer Trail

Drag the
or

Slow

or

If mouse movement is not smooth,

Pointer speed

— Click

Pointer trail

Long

.

Pointer speed

Fast

.

to a lower speed.

Show pointer trails.

slider toward

Operation

slid-

Short

17

Double-Click Tab

Drag the slider toward

Slow

or

Fast

change the double-click speed. To test
the setting, double-click on the mouse
icon in the

Click

Test Area

Reset to Default Value

.

at any time to

restore the original double-click setting.

Orientation Tab

This tab lets you re-calibrate the mouse
to your liking. Click
the mouse horizontally to the right until
the dog icon moves to the right side.
Then move your cursor around the
screen to test its calibration, and reset if
necessary.

Reset Orientation

Click
store the original setting.

18

Set Orientation

at any time to re-

Operation

. Move

to

Wheel Tab

This tab lets you set scroll options for the
Wheel button.

Wheel

— Select

ing

Use Microsoft Office 97 Scrolling

or

Emulation Only

Wheel Button

Scroll Control

Enable Universal Scroll-

.

— Select

Button Function

or

Quick/Auto

for the

wheel as a third button function.

Note:

If you are running Microsoft Office
97 with Windows 2000 for the first time,
you must reboot your computer before in­stalling this mouse driver, to activate the
wheel button functions. For Windows op­erating systems other than Windows
2000, you do not need to reboot the com­puter to activate these functions.

Operation

19

Scrolling Speed

per notch

Scroll one screen per notch

or

— Select

Scroll line(s)

.

Reverse Scrolling Direction

Reverse Scrolling Direction

— Click

to reverse the
direction in which the wheel button scrolls
through a document.

Pointer Utility Tab

Select any of the options on this screen
to customize pointer movement and func­tion.

Pointer Wrap

reaches the edge of the screen, it auto­matically goes through and appears on
the other side.

Pointer Vanish

while you are typing. The pointer auto-

20

— When the pointer

— The pointer is hidden

Operation

matically reappears when you use your
mouse again.

Sonar

— Helps you locate your pointer if

Ctrl

you cannot find it. Press

to activate

the Sonar function. This function does not

Ctrl

interfere with other

key functions.

Slow Motion

— Holding down

Shift

acti­vates slow motion to temporarily slow
pointer movement for increased preci­sion. This function does not interfere with

Shift

other

X Focus

key functions.

— Makes an open window ac­tive by moving the pointer over its title
bar. This is useful when you want to alter­nate between several open windows
without clicking.

Operation

21

Auto Jump

appears on the default button (such as

OK

) whenever a dialog box is opened.

— The pointer automatically

Mouse Suite Tab

This tab lets you show a mouse icon in
the task bar or uninstall the mouse driver.

General Tab

This tab is available for Windows 95 only.
Refer to your Windows 95 manual for
more information on this tab.

22

Operation

ˆ

Special Functions

USING THE WHEEL

Most applications use a scroll function to
move the cursor through text. Your
mouse’s wheel makes scrolling easier.

Important:

is enabled by default in your mouse’s
software, you might have to manually en­able it in order to use scrolling functions
in applications not compatible with Mi­crosoft Office 97. See “Wheel Tab” on
Page 19.

Although

Universal Scrolling

Scroll

To scroll, rotate the wheel forward or
backward. To select, press the wheel.

Special Functions

23

Auto Scroll

Your mouse’s auto scroll function lets you
automatically scroll through a document
without having to move the mouse or
mouse wheel. You can select auto scroll
using either of the mouse’s buttons or the
wheel.

1. Make sure

Quick/Auto Scroll

(Wheel

tab) is set, then press the wheel.

appears at your pointer position.

2. Move the pointer vertically, horizon­tally, or diagonally away from the
original mark to start auto scrolling.
Auto scroll speed increases as the
pointer is moved away from the origi­nal mark.

3. Press any mouse button or rotate the
wheel to stop auto scroll.

24

Special Functions

Zoom

Some Microsoft Office 97-compatible ap­plications (such as Microsoft Word 97)
have additional zooming functions. Use
the zooming function to “zoom in” for a
closer look at a page or “zoom out” to see
more of a page.

Ctrl

To zoom in, hold down
mouse wheel forward. To zoom out, hold

Ctrl

down
backward.

and rotate the mouse wheel

and rotate the

USING HYPER GRID

Use the supplied Hyper Grid software
(automatically installed as part of the
Mouse Suite software) to set up the
mouse to quickly execute commonly­used commands. Hyper Grid is enabled

Special Functions

25

when assigning button functions. See
“Buttons Tab” on Page 15.

1. Hold down the mouse button you
assigned as Hyper Grid (using the

Function

drop-down list) when you
installed Mouse Suite. The grid
appears.

Minimize Recall

Context
menu

Next
Window

Close

Vertical
scroll

26

Start

Special Functions

Horizontal
scroll

Resize

2. While holding the button, move the
pointer to an icon on the grid and
release the button to execute the
command associated with that icon.

The following commands are available
when using Hyper Grid:

Minimize

— minimizes the active win-

dow.

Recall

— restores the active window.

Close

— closes the active window.

Next Window

— makes the next window

active.

Context Menu

— emulates the right

mouse button.

Vertical Scroll

— scrolls documents ver-

tically.

Special Functions

27

Start

— activates the Windows Start

menu.

Horizontal Scroll

— scrolls documents

horizontally.

Resize

— jumps to the size grid to resize
the active window. Press one of the
mouse buttons to cancel this command.

Notes:

• The Hyper Grid software automati­cally grays out functions that are not
available with the software you are
using.

• The Vertical Scroll and Horizontal
Scroll commands let you set the
mouse so it does not scroll automati­cally. If you select these commands,
you must move the mouse to scroll.

28

Special Functions

Press either of the mouse buttons to
cancel either of these commands.

• Selecting the Context command lets

you select the Context menu, even if
you programmed the right mouse
button to minimize windows.

Special Functions

29

ˆ

Troubleshooting

If your mouse is not working as it should,
these suggestions might help you elimi­nate the problem. If the mouse still does
not operate properly, take it to your local
RadioShack store for assistance.

Problem:

mouse are notworking with my notebook.

Solution:

pad in your notebook’s BIOS and enable
the external port to successfully use all
the mouse’s functions.

Problem:

by my computer.

30

The scrolling functions of my

Disable the trackball or touch-

The mouse was not detected

Troubleshooting

Solution:

• Make sure the mouse is securely

plugged into your computer’s mouse
port.

• If you connect the mouse to the USB

port, check if your PC’s USB port is
working properly. Look on the Device
Manager of System Properties. If
there is a circled exclamation point
through the icon, it means this USB
controller has some problem. Try to
remove and re-install it or contact
your PC manufacturer’s technical
support.

• If you connect the mouse to the USB

port, check the version of your oper­ating system. If you are not running
Windows 98, Windows 2000, or Win­dows ME, update your operating

Troubleshooting

31

system so the USB device can be
enabled.

• If you connect the mouse to the USB
port, make sure the USB port was
enabled in the BIOS setup.

Problem:

There is no pointer on the
screen or the pointer is not responding to
the mouse’s movement.

Solution:

Your computer did not detect
the mouse. Make sure your mouse’s ca­ble is properly connected to the correct
port.

32

Troubleshooting

ˆ

Care

Keep the mouse dry; if it gets wet, wipe it
dry immediately. Use and store the
mouse only in normal temperature envi­ronments. Handle the mouse carefully;
do not drop it. Keep the mouse away
from dust and dirt, and wipe it with a
damp cloth occasionally to keep it looking
new.

Modifying or tampering with the mouse’s
internal components can cause a mal­function. If your mouse is not performing
as it should, take it to your local
RadioShack store for assistance.

Note:

Your mouse is optical, and does
not use a ball. You do not need to clean
the mouse like a ball-type mouse.

Care

33

Limited Ninety-Day Warranty

This product is warranted by RadioShack against manufactur­ing defects in material and workmanship under normal use for
ninety (90) days from the date o f purchase from RadioS hack
company-owned stores and authorized RadioShack franchi­sees and dealers. EXCEPT AS PROVIDED HEREIN,
RadioShack MAKES NO EXPRESS WARRANTIES AND ANY
IMPLIED WARRANTIES, INCLUDING THOSE OF MER­CHANTABILITY AND FITNESS FOR A PARTICULAR PUR­POSE, ARE LIMITED IN DURATION TO THE DURATION OF
THE WRITTEN LIMITED WARRANTIES CONTAINED
HEREIN. EXCEPT AS PROVIDED HEREIN, RadioShack
SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO CUS­TOMER OR ANY OTHER PERSON OR ENTITY WITH RE­SPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED
DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE
OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF
THIS WARRANTY, INCLUDING, BUT NOT LIMITED TO, ANY
DAMAGES RESULTING FROM INCONVENIENCE, LOSS
OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR
ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUEN­TIAL DAMAGES, EVEN IF RadioShack HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an i mplied
warranty lasts or the exclusion or limitation of incidental or
consequential damages, so the above limitations or exclu­sions may not apply to you.

(Continued)

34

Care

(continued)

In the event of a product defect during the warranty period,
take the product and the RadioShack sales rece ipt as proof of
purchase date to any RadioShack store. RadioShack will, at
its option, unless otherwise provided by law: (a) correct the
defect by product repair without charge for parts and labor; (b)
replace the product with o ne of th e same or similar desig n; or
(c) refund the purchase price. All replaced parts and products,
and products on which a refund is made, become the property
of RadioShack. New or reconditioned parts and products may
be used in the performance of warranty service. Repaired or
replaced parts and products are warranted for the remainder
of the original warranty period. You will be charged for repair
or replacement of the product made after the expiration of the
warranty period.
This warranty does not cover: (a) damage or failure caused by
or attributable to acts of God, abuse, accident, misuse, im­proper or abnormal usage, failure to follow instructions, im­proper installation or maintenance, alteration, lightning or
other incidence of excess voltage or current; (b) any repairs
other than those provided by a Radi oShack Authorized Ser­vice Facility; (c) consumables such as fuses or batteries; (d)
cosmetic damage; (e) transportation, shipping or insurance
costs; or (f) costs of product removal, installation, set-up ser­vice adjustment or reinstallation.
This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
RadioShack Customer Relations, 200 Taylor Street, 6th Floor,

Fort Worth, TX 76102

We Service What We Sell

12/99

Care

35

RadioShack Corporation
Fort Worth, Texas 76102

26-492

08A01

Printed in China
