QuickSpecs
Overview
HP Compaq Pro 4300 All-in-One PC
HP COMPAQ PRO 4300 ALL-IN-ONE PC
FRONT
1.
Webcam Activity LED
2.
Webcam & Microphone (optional)
3.
Power Button
4.
Power Indicator LED
5.
Business Quality Speakers
DA - 14287 Worldwide — Version 16 — May 14, 2013
Page 1
QuickSpecs
Overview
HP Compaq Pro 4300 All-in-One PC
HP COMPAQ PRO 4300 ALL-IN-ONE PC
BACK
1.
HP 6-in-1 Media Card Reader
2.
(2) USB 2.0 ports
3.
Microphone jack
4.
Headphone jack
5.
Serial Port
6.
(4) USB 2.0 ports
7.
Stereo audio line out
8.
RJ-45 Gigabit Ethernet port
9.
Power connector
10.
11.
Power connector LED indicator
Security lock slot
DA - 14287 Worldwide — Version 16 — May 14, 2013
Page 2
QuickSpecs
Overview
HP Compaq Pro 4300 All-in-One PC
HP COMPAQ PRO 4300 ALL-IN-ONE PC
SIDE
1.
Slim tray-load ODD (optional)
2.
Brightness increase button
3.
Brightness decrease button
4.
Hard drive activity LED
DA - 14287 Worldwide — Version 16 — May 14, 2013
Page 3
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Overview
At A Glance
Windows 7 or Windows 8
20-inch diagonal widescreen WLED backlit anti-glare LCD
Integrated all-in-one form factor
Intel® H61 Express chipset
Intel 2nd & 3rd generation Core™ processors
Integrated Intel HD Graphics
Realtek RTL8111F GbE Ethernet Controller optional wireless connectivity:
Intel Advanced-N 6205 WLAN (mini PCI Express)
Intel 802.11 a/b/g/n
WLAN (mini PCI Express)
HP 802.11 b/g/n
WLAN and Bluetooth Combo Card
HP 802.11 a/b/g/n Bluetooth® 4.0
Optional Integrated 1.3 MP webcam & Single Non-Array Microphone
Business quality speakers
Up to 16 GB of DDR3 SDRAM, dual channel memory support, two SODIMM slots
Up to 1 TB SATA hard drive, up to 128GB Solid State Drive and a 256GB Self-Encrypting Drive / Solid State Drive
Slim Tray-load SuperMulti Optical Disc Drive or DVD ROM Optical Disc Drive
6-in-1 Media Card Reader
ENERGY STAR® qualified. EPEAT® registered where applicable/supported. See
CCC, CECP & SEPA Certified
www.epeat.net
for registration status by country.
DA - 14287 Worldwide — Version 16 — May 14, 2013
Page 4
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Standard Features and Configurable Components (availability may vary by country)
OPERATING SYSTEM
Preinstalled
Windows 8 Professional (64-bit)*
Windows 8 (64-bit)*
Windows® 7 Ultimate (32-bit)**
Windows® 7 Ultimate (64-bit)**
Windows® 7 Professional (32-bit)**
Windows® 7 Professional (64-bit)**
Windows® 7 Professional (32-bit) (available through downgrade rights from Windows 8 Pro)***
Windows® 7 Professional (64-bit) (available through downgrade rights from Windows 8 Pro)***
Windows® 7 Home Premium (32-bit)**
Windows® 7 Home Premium (64-bit)**
Windows® 7 Home Basic (32-bit)**
FreeDOS 2.0
Novell SUSE Linux Enterprise Desktop 11
*Not all features are available in all editions of Windows 8. Systems may require upgraded and/or
separately purchased hardware, drivers and/or software to take full advantage of Windows 8
functionality. See
http://www.microsoft.com
.
**Not all features are available in all editions of Windows 7. This system may require upgraded and/or
separately purchased hardware to take full advantage of Windows 7 functionality. See
http://www.microsoft.com/windows/windows-7/
***This system is preinstalled with Windows® 7 Pro software and also comes with a license and media
for Windows 8 Pro software. You may only use one version of the Windows software at a time.
Switching between versions will require you to uninstall one version and install the other version. You
must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid
loss of your data.
for details.
PROCESSOR
Intel® 3rd Generation Core™ i7 Processors
Intel® Core™ i7-3770S
Up to 3.9 GHz Max. Turbo Frequency (3.1 GHz base frequency), 8 MB cache, 4 cores, 8 threads
Intel HD Graphics 4000
Intel Stable Image Platform Program (SIPP)
Intel® 3rd Generation Core™ i5 Processors
Intel® Core™ i5-3570S
Up to 3.8 GHz Max. Turbo Frequency (3.1 GHz base frequency), 6 MB cache, 4 cores, 4 threads
Intel HD Graphics 2500
Intel Stable Image Platform Program (SIPP)
Intel® Core™ i5-3475S
Up to 3.6 GHz Max. Turbo Frequency (2.9 GHz base frequency), 6 MB cache, 4 cores, 4 threads
Intel HD Graphics 4000
Intel Stable Image Platform Program (SIPP)
DA - 14287 Worldwide — Version 16 — May 14, 2013
Page 5
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Standard Features and Configurable Components (availability may vary by country)
Intel® Core™ i5-3470S
Up to 3.6 GHz Max. Turbo Frequency (2.9 GHz base frequency), 6 MB cache, 4 cores, 4 threads
Intel HD Graphics 2500
Intel Stable Image Platform Program (SIPP)
Intel® 3rd Generation Core™ i3 Processors
Intel® Core™ i3-3240
3.4 GHz base frequency, 3 MB cache, 2 cores, 4 threads
Intel HD Graphics 2500
Intel® Core™ i3-3225
3.3 GHz base frequency, 3 MB cache, 2 cores, 4 threads
Intel HD Graphics 4000
Intel® Core™ i3-3220
3.3 GHz base frequency, 3 MB cache, 2 cores, 4 threads
Intel HD Graphics 2500
Intel® Core™ i3-3210
3.2 GHz base frequency, 3 MB cache, 2 cores, 4 threads
Intel HD Graphics 2500
Supports DDR3 memory up to 1600 MT/s data rate
Intel® 3rd Generation Pentium® Processors
Intel® Pentium® G2120
3.1 GHz base frequency, 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1600 MT/s data rate
Intel® Pentium® G2020
2.9 GHz base frequency, 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1333 MT/s data rate
Intel® Pentium® G2010
2.8 GHz base frequency, 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1333 MT/s data rate
Intel® 2nd Generation Pentium® Processors
Intel® Pentium® G870
3.10 GHz base frequency , 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Intel® Pentium® G860
3.00 GHz base frequency , 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
DA - 14287 Worldwide — Version 16 — May 14, 2013
Page 6
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Standard Features and Configurable Components (availability may vary by country)
Intel® Pentium® G645
2.9 GHz base frequency, 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1066 MT/s data rate
Intel® Pentium® G640
2.80 GHz base frequency , 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Intel® 3rd Generation Celeron® Processors
Intel® Celeron® G1620
2.7 GHz base frequency, 2 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1333 MT/s data rate
Intel® Celeron® G1610
2.6 GHz base frequency, 2 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1333 MT/s data rate
Intel® 2nd Generation Celeron® Processors
Intel® Celeron® G555
2.7 GHz base frequency, 2 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1066 MT/s data rate
Intel® Celeron® G550
2.60 GHz base frequency , 2 MB cache, 2 cores, 2 threads
Intel HD Graphics
Intel® Celeron® G540
2.50 GHz base frequency , 2 MB cache, 2 cores, 2 threads
Intel HD Graphics
Intel® Celeron® G460
1.80 GHz base frequency, 1.5 MB cache, 1 core, 2 threads
Intel HD Graphics
Intel® Celeron® G465
1.90 GHz base frequency, 1.5 MB cache, 1 core, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1066 MT/s data rate
CHIPSET
Intel® H61 Express
SMBIOS
System Management BIOS, previously known as DMI BIOS, is used to store system management information.
DA - 14287 Worldwide — Version 16 — May 14, 2013
