QuickSpecs

Intel PRO/100+ Management

Adapter Kits

MODELS

Intel PRO/100+ Management Adapter – Standard on select Deskpro EN Series models

Intel PRO/100+ Management Adapter on Configure to Order Deskpro Systems with Intel 440 BX Chipsets

179156-002

Intel PRO/100+ Management Adapter on Configure to Order Deskpro Systems with Intel 810, 810e, 820 and future Intel Chipsets

108893-B21

Intel PRO/100+ Management Adapter After-Market Options Kits
127453-B21 (single)
127453-B22 (5 pack)

127453-B23 (20 pack)
127453-B24 (80 pack)
124737-B21 (CCP 1 for 20)

OVERVIEW

Improve network response time and reduce support costs with this easy-to-install desktop adapter. With built-in advanced management capabilities, such
as Wake on LAN and Alert on LAN, the Intel PRO/100+ Management Adapter delivers industry-leading performance and reliability.

Note: Alert on LAN technology is not supported on all Compaq platforms.

ADVANCED MANAGEMENT CAPABIL ITIES

Remote Management

The Intel PRO/100+ Management Adapter NIC allows for greater network manageability by featuring support for the latest Wired for Management (WfM)

2.0 specification. This adapter also provides advanced management features like Wake on LAN for remote PC Wake-up, Alert on LAN (AoL)
monitoring of the PC, and the pre-installed PRO/100 Boot Agent for OS deployment and upgrades.

Wake on LAN (WoL) and Desktop Management Interface (DMI) 2.0

Lowers cost of ownership by allowing remote power-up and upgrade of the PC from a sleep state during non-work hours

Alert on LAN Hardwa re Support

Allows your PC to proactively inform a management workstation when there is a problem with the PC, such as boot failure, overheating, unauthorized
tampering or even component theft

Note: Also requires Intel 810, 810e, 820 and future Intel Chipsets, HP Openview, and appropriate client and Server driver agents.

Plug and Play

Fully compliant with the 2.2 PCI specification, allowing for easy configuration and installation

Pre-installed PRO/100 Boot Agent

Embedded Boot ROM enables a network administrator to upgrade or install new software onto systems from a remote location. Because the Boot ROM is
embedded, businesses save the time and money that they would otherwise spend qualifying, purchasing and installing Boot ROM chips into Boot ROM
sockets.

DA-10375 North America — Version 05 — February 12, 2001 1

for proactive

QuickSpecs

Intel PRO/100+ Management

Adapter Kits

PERFORMANCE

New Intel 82559 Controller

Intel’s latest high performance chip technology

Intel Priority Packet (IEEE 801.1p)

Traffic prioritization speeds throughput for critical applications.

Built-in Int el Adaptive Technology

Fine tunes the adapter to maintain peak performance as the network environment evolves and full-duplex capability increases the performance of
demanding desktop applications

10/100 Autosensing

Automatically connects as the highest available speed

STANDARDS-BASED NETWORKIN G

Supports all major OSs and NOSs

Inter-operable with all major network and PC operating systems

Backwards compatible and common core driver suite

Integrates with existing Intel and Compaq (Intel-based) Fast Ethernet technology adapters, as well as compatible with Intel’s new generation of server and
mobile adapters, for easy and efficient driver installation and administration
