Compal Electronics VC 5U User Manual
OPERATING MANUAL
(VC -5U)
Revision : 0.1
Page# Modification Remark
VACOM WIRELESS, INC
1
IMPORTANT SAFETY INFORMATION
GETTING TO KNOW YOUR PHONE
DISPLAY INDICATOR
BATTERY INFORMATION
BASIC FUNCTIONS
1. Making a Call
2. Ending a Call
3. Answering a Call
4. Correcting Dialing Mistakes
5. Storing Phone Numbers
6. Adjusting Earpiece Volume During a Call
7. Using Caller ID
8. Speed Dialing
9. Short Cut
a. Keypad Lock
b. Phone Lock
c. Etiquette Mode
d. Phone Number Search
e. Calendar
f. Alarm
10. Current Time Setting
MENUS
I. Phone Book
1. Call List (missed call / incoming call / outgoing call)
2. Phone Book Search (by name / by location / by phone number / by group)
3. Storing Phone Numbers
4. Call Time View
5. My Phone Number
6. Delete Phone Book
2
II. MESSAGE SERVICE
1. SMS (Short Message Service)
a. Read Text Messages
b. Send Text Message
Send New Message
Send from Message Box
Send Message That You Already Sent Out
Group Edit
c. Message Box
d. SMS Setting
Message Alert
Direct View
Delivery Ack
2. Voice Mail Service
3. Message Delete
III. PHONE SETTING
1. Wallpaper
2. Language
3. Backlight
4. LCD Contrast
5. Auto Answer
6. Any Key Answer
7. Auto Redial
8. DTMF Tone
9. Auto Keypad Lock
IV. SOUND MENU
1. Incoming Calls
2. Ring Type
3
3. Roam Ringer
4. Volume Control
5. Alert
V. SECURITY FUNCTION
1. Phone Lock
2. Changing Password
3. Restrict Sending Calls
4. Voice Privacy
5. Network Change
6. Initialization
VI. PIM (Personal Information Management)
1. Alarm
2. Schedule
3. Calendar
4. Calculator
5. Memo
6. World Time View
VII. CALL FUNCTION
1. Call Forward
2. Call Waiting
3. Caller Identification
4. Service Access Number Edit
Using Menu During a Call
1. Phone Book
2. Message
3. Phone Setting
4. Sounds (Earpiece / Mic / Key Tone / Alert / Mic Mute / Key Tone Mute / Alert Setting)
ENTERING LETTERS & NUMBERS
FCC RF EXPOSURE INFORMATION
4
IMPORTANT SAFETY INFORMATION
Some of the following information may not apply to your particular product. However, as with
any electronic product, you should observe safety precautions when you use this product.
Save this manual : it contains important safety information and operating instructions.
Before using this product, please follow and adhere to all warnings, safety, and operating
instructions located on the product and in this User ’s Manual.
Do Not expose the product to water or moisture.
Do Not expose the product to extreme hot or cold temperatures.
Do Not expose the product to open flames.
Do Not allow objects to fall on, or liquids to spill on the product.
Use only Original Accessories. Damage from the use of non-approved accessories will void
your phone warranty.
Connect the approved charger only to designed power sources as marked on the product.
To reduce the risk of damage, remove the electrical cord from an outlet by pulling the
charger rather than the cord.
Make sure the electric cord is located accordingly, so that it will not be subjected to damage.
To reduce the risk of electric shock, unplug the product from the power source before
attempting any cleaning. Once unplugged, use a soft cloth dampened with water.
DANGER : Never alter the cord or plug. If the plug does not fit into the outlet, have a
proper outlet installed by a qualified electrician. Improper connection can result electric
shock.
5
Do Not attempt to disassemble the product – doing so will void the warranty. This product
does not contain consumer-serviceable components. Service should be performed only by
Authorized Service Centers.
Do Not remove the antenna. A detached antenna may be a choking hazard for children.
Do Not allow battery to be placed inside the mouth. Electrolytes could be released and may
be toxic if swallowed.
6
GETTING TO KNOW YOUR PHONE
LED Indicator
: Flashes to indicate an incoming call or message. It also lights
up (flashes) when you turn on the phone.
Backlit LCD Screen
: The LCD screen contains three areas;
- The top line displays indication about your phone’s
operating mode.
- Two lines in the middle are the display areas for numbers
and characters.
- The bottom line displays menus.
Menu Keys ( / )
: This key performs several useful functions.
- During incoming calls, press it to answer the incoming
call.
- In Standby mode, press it briefly to access Main Menu
and Select Menu.
- When navigating a menu, press it to select the highlighted
selection.
SMS Key ( )
: When in Standby Mode, press this key to access Message
Menu items.
Navigation Key ()
: This key allows you to navigate the phone ’s variable
functionality and useful shortcut.
Microphone
: Your typical voice microphone for conve rsation and you can
also mute the microphone during conversation by pressing
“MENU ” “4” “5”.
Accessories Connector
: The location where you connect your charging device. It can
also be used to connect wireless data device or hands-free car
kit.
CLR Key
: This key is used to erase numbers or characters you may have
entered incorrectly, or to return to a previous screen.
- To erase one character from the display screen, briefly
press it once.
- To erase all of them, hold it for one second.
- To back up one menu level, press it once.
- To return to Standby Mode, hold it for one second.
7
- During a call, press it to control earpiece volume.
END/ Key
: Press this key to disconnect a call or to return to Standby
Mode from any menu. Press and hold this key to turn the
phone On or Off.
SEND Key
: This key performs several useful functions.
- Dial a number and press it to connect.
- Press it once to redial the last outgoing number.
Numeric Keys
: These keys are to dial and to input numbers and characters.
*
: This key performs several useful functions.
- Change bells to vibration
- Use as navigation key.
#
: This key performs several useful functions.
- Use as instance phone lock.
- Use as navigation key.
Antenna
8
DISPLAY INDICATORS
Display indicators appear across the bottom of your phone’s LCD screen. These display
indicators (or icons) will vary based on your phone ’s operating modes.
Signal strength : This icon shows your current signal strength. More lines
indicate more signal strength. Five lines indicate maximum strength, and one
line indicates least strength.
No service indicator : This icon indicates your phone cannot find a signal
because you’re outside a service area. When this is displayed, you cannot make
or receive calls. Wait a little while for a signal or move into an open area.
Roaming : This icon indicates you are “roaming ” on to other carrier’s service
area. But you must register the roaming service.
Vibrator on : This icon means that an incoming call will vibrate the phone rather
than ring it or before/after the phone ring.
It also means that your phone is on Etiquette mode. An incoming call will
vibrate the phone rather than ring it. This feature is good for quiet situations
where you don’t want your ringer to disturb anyone.
Message indicator : This icon indicates you have message(s) waiting.
Press SMS Menu button to see the message menu, or press and hold to be
connected to voicemail.
Alarm on : This icon means that you set the alarm On.
Battery strength : This icon shows the level of your battery charge. The more
black bars you see the greater the charge. When the battery becomes very low,
an empty box appears and the phone flashes an alert.
9
BATTERY INFORMATION
Your phone comes with a partially charged, rechargeable Li -ion battery so that you can use the
phone immediately after it is activated.
Installing the Battery.
To insert the battery into your phone:
1. Remove the battery compartment cover of the phone by sliding it down.
2. Put the battery pack into the battery cradle.
3. Replace the battery compartment cover by sliding it up towards the phone.
4. Charge the battery pack for at least 3 hours prior to using it.
Charging the Battery.
You can tell whether or not your battery needs to be recharged by checking the upper-right
corner of your phone’s display.
When the battery charge level gets low, the battery sensor will let you know by blinking the
battery icon and making audible warning tone. If the battery level gets too low, the phone will
be turned off automatically. When this happens while you were receiving incoming call or
making outgoing call, the call will be automatically disconnected. Watch the battery strength
icon and make sure your battery is adequately charged to avoid such situation.
Charging with the Traveler’s Charger.
Use traveler ’s charges certified only. Using any other unauthorized accessories may be
dangerous and will invalidate the phone warranty if said accessories caused damage or defected
the phone.
To Charge the Battery using the Traveler’s Charger:
- Plug the power cord of the charger into a wall outlet.
- Insert the connector of the charger at the bottom of the phone.
- Charging status will be shown on the display.
- Note) Make sure you put the connector of the charger into the phone correctly.
10
Failure to do so may cause damages to the phone.
A completely discharged standard battery recharges fully in approximately tbd hours. The
extended battery recharges in approximately tbd hours. Leaving your phone turned on during
charging, or charging batteries simultaneously, will increase charging time. Leaving the battery
in the charger once it is fully charged does not harm the battery.
WARNING
After the battery is fully charged, the battery can be discharged. If the charger is
connected to your phone for over 3hrs, please pull the plug from the phone and recharge
the battery even if the battery is fully charged.
Turning your phone on and off.
When you’re ready to turn on your phone, press and hold “ END/ ” until the display is turned
on and the phone makes the sound. When the phone has found a signal, the “ ” icon appears.
Once the phone is turned on, it enters Standby mode and you ar e able to make and receive calls.
To turn your phone off, press and hold “END/ ” until the display is turned off and the phone
makes the sounds. Then the display will go blank. When the phone is turned off, nothing is
displayed on screen.
Note: If “END/ ” is pressed for less than one second, the phone will not be turned off. This
function prevents your phone from being turned off accidentally.
Standby Mode.
Standby is the most basic state of your phone. The phone goes into standby mode soon after you
turn it on, or whenever you briefly press “END/ ”. When your phone is in Standby Mode, you
will typically see the banner (that’s the message displayed when you turn on your phone). If you
enter a phone number, you press “ SEND” to complete the call, or press “STO ( )” to save it in
the internal phone book.
Power Save Mode
Your phone comes with a Power Save feature that will automatically be activated if your phone
is unable to find a signal after 15 minutes of searching. While this feature is active, the pho ne’s
11
battery power is conserved.
The phone will automatically recheck for a signal periodically. To manually force the phone to
recheck for a signal, press any key. A message on the display will let you know when the phone
is operating in Power Save Mode.
Conversation Mode.
You can place and answer calls only when your phone is turned on. During a call, the phone is
in Conversation Mode.
