Compal Electronics VC 1 Users manual

OPERATING MANUAL

(VC-1)

Revision : 1.0

COMPAL ELECTRONICS, INC

1

FCC RF EXPOSURE INFORMATION

In August 1996 the Federal Communications Commission (FCC) of the United States
with its action in Report and Order FCC 96-326 adopted an updated safety standard
for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC
regulated transmitters. Those guidelines are consistent with the safety standard
previously set by both U.S. and international standards bodies. The design of this
phone complies with the FCC guidelines and these international standards.

Use only the supplied or an approved antenna. Unauthorized antennas, modifications,
or attachments could impair call quality, damage the phone, or result in violation of
FCC regulations.

Do not use the phone with a damaged antenna. If a damaged antenna comes into
contact with the skin, a minor burn may result. Please contact your local dealer for
replacement antenna.

Body-worn Operation

This device was tested for typical body-worn operations. To comply with FCC RF
exposure requirements, a minimum separation distance of 0.4 inches (1.0 cm) must be
maintained between the user’s body and the handset, including the antenna whether
extended or retracted. Third-party belt-clips, holsters, and similar accessories used by
this device should not contain any metallic components. Body -worn accessories that
do not meet these requirements may not comply with FCC RF exposure requirements
and should be avoided.

For more information about RF exposure, please visit the FCC website at www.fcc.gov

Read this information before using your handset

CONTENTS

IMPORTANT SAFETY INFORMATION

GETTING TO KNOW YOUR PHONE

DISPLAY INDICATOR

BATTERY INFORMATION

BASIC FUNCTIONS

Making a Call
Ending a Call
Answering a Call
Correcting dialing Mistakes
Storing Phone Numbers
Adjusting Microphone Volume During a Call
Adjusting Voice Volume
Last Number Redial
Speed Dialing
Using Caller ID

MENUS

I. SEARCH MENU

Last Call Numbers
Last Call Numbers You Received
Group Menu
ABC Sequence Menu
Name Search Menu
Location Search Menu
Search by Phone Number

II. PHONE SETTING MENU

Greeting Type
Text Edit (Banner)
Icon Changes

2

Menu Type
Languages
Back Light
Auto Answer
Auto Redial
Current Time

III. SOUND MENU

Incoming Ring
Ring Type
Volume
Alert Setting

IV. SECURITY FUNCTION

Auto Lock
Changing Password
Call Limiting Options
Phone Initialize
NAM Select
Memory Clear
Network Change
System Change

V. PHONE BOOK

Schedule Manager
Alarm
Storing a Number, e-Mail Address and Name
Calculator
Memo View
World Time

VI. MY PHONE NUMBER

MESSAGE SERVICES

I. TEXT MESSAGE SERVICES (SMS)

Read Text Messages
Sending Text Messages
Deleting Messages

II. VOICE MAIL SERVICE

Listening Voice Mails
Deleting Messages

3

III. MESSAGE ALERTS

USING MENU During a Call

Sending My Phone Number
Writing a Memo
Storing a Phone Number
Muting the Microphone
To See My Phone Number
Microphone Volume Control

ENTERING LETTERS & NUMBERS

4

IMPORTANT SAFETY INFORMATON

Some of the following information may not apply to your particular product. However, as with
any electronic product, you should observe safety precautions when you use this product.

 Save this manual : it contains important safety information and operating instructions.
 Before using this product, please follow and adhere to all warnings, safety and operating

instructions located on the product and in this User’s Manual.

 Do Not expose the product to water or moisture.
 Do Not expose the product to extreme hot or cold temperatures.
 Do Not expose the product to open flames.

Do Not allow objects to fall on, or liquids to spill on the product.


 Use only Original Accessories. Damage from use of non-approved accessories will void

your phone warranty.

 Connect the approved charger only to designed power sources as marked on the product.

To reduce the risk of damage, remove the electrical cord from an outlet by pulling the



charger rather than the cord.

 Make sure the electric cord is located so that it will not be subjected to damage.
 To reduce the risk of electric shock, unplug the product from the power source before

attempting any cleaning. Once unplugged, use a soft cloth dampened with water.

 DANGER : Never alter the cord or plug. If the plug will not fit into the outlet, have a proper

outlet installed by a qualified electrician. Improper connection can result in electric shock.

 Do Not attempt to disassemble the product – doing so will void the warranty. This product

does not contain consumer-serviceable components. Service should be performed only by
Authorized Service Centers.

 Do Not remove the antenna. A detached antenna may be a choking hazard for children.
 Do Not allow battery to be placed in the mouth. Electrolytes could release and may be toxic

if swallowed.

5

GETTING TO KNOW YOUR PHONE

6

Active Flip

: Just open the flip to answer an incoming call, and close the
flip to hang up. You can also set the flip to turn the backlight
on and off.

LED Indicator
: Flashes to indicate an incoming call or message. Also lights
up (flashes) when you turn on the phone.

Volume/Scroll Keys
: This keys are used to set volume levels, a etiquette mode and
help you navigate through Menus and the phone book.
Press the volume keys to :

- Go to Etiquette mode to press “” key while flip closed.

- Adjust voice volume during conversation.

- Adjust key tone volume in Standby mode.

- Answer the incoming call.

- Scroll through menu options.

- Scroll through your Internal Phone Book.

Backlit LCD Screen
: The LCD screen contains two areas;

- The bottom line displays indications about your phone’s
operating mode.

- The upper area displays in-use information such as the
other party’s number of the other party (if available),
Mute, Call Waiting, etc. Your menus also display in the
upper area.

Nemu Key

: This key performs several useful functions.

- During incoming calls, press it to answer the incoming
call.

- From Standby mode, press it briefly to access Main Menu
and Select menus.

- When navigating a menu, press it to select the highlighted
selection.

SMS Key
: When in Standby mode, press this key to access Message
Menu items.

- During incoming calls, press it to answer the incoming
call.

- From Standby mode, press it briefly to access Message
Services.

- When navigating a menu, press it to go back to previous
menu.

Navigation Keys
: This key is similar to the volume key. Press “” key to scroll
“up”, and press “” key to scroll “down”. And use it to scan

7

menu options, Last 10 numbers dialed, Call Stack or to move
the cursor when editing. As shown in the illustration, there are
several keys that can be used to scroll.

Microphone
: Your typical voice microphone for conversation and you can
also mute the microphone during conversation by pressing
“MENU” “4”.

Accessory Connector
: The location where you connect your charging device.

CLR Key
: This key is used to erase numbers or characters you may have
entered incorrectly, or to return to a previous screen.

- To erase one character from the display screen, briefly
press it once.

- To erase all of them, hold it for one second.

- To back up one menu level, press it once.

- To return to Standby mode, hold it for one second.

END/ Key
: Press this key to disconnect a call or to return to Standby
mode from any menu. Press and hold this key to turn the
phone On or Off.

SEND Key
: This key performs several useful functions.

- Dial a number and press it to connect.

- Press it once to redial the last outgoing number.

Antenna
: Makes the call sound clearest when it’s fully Extended.

8

DISPLAY INDICATORS

Display indicators appear across the bottom of your phone’s LCD screen. These display
indicators (or icons) will vary based your phone’s operating mode.

Signal strength : This icon shows your current signal strength. More lines
indicate more signal strength. Four lines indicate maximum strength, and one
line indicates least strength.

No service indicator : This icon indicates your phone cannot find a signal
because you’re outside a service area. When this is displayed, you cannot make
or receive calls. Wait a little while for a signal or move into an open area.

Roaming : This icon indicates you are “roaming” on to other carrier’s service
area. But you must resister the roaming service.

Message indicator : This icon indicates you have message(s) waiting.
Press SMS Menu button to see the message menu, or press and hold to be
connected to voicemail.

Digital mode : This icon indicates your phone is operating in digital mode. If
you are in analog service area, “D” will be disappeared.

Ring mode : This icon means that an incoming call will ring the phone along
with LED lightening.

LED lightening mode : This icon means that an incoming call will light the LED
on top of the front cabinet rather than ring it.

Vibrator on : This icon means that an incoming call will vibrate the phone rather
than ring it or before/after the phone ring. (Vibration+LED, Vibration after Bell,
Bell after Vibration)

Etiquette mode on : This icon means that an incoming call will vibrate the phone
rather than ring it. This feature is good for quiet situations where you don’t want
your ringer to disturb anyone.

Alarm on : This icon means that you set the alarm On.

Battery strength : This icon shows the level of your battery charge. The more
black bars you see the greater the charge. When the battery becomes very low,
an empty box appears and the phone flashes an alert.

9

BATTERY INFORMATION

Your phone comes with a partially charged, rechargeable Lithium Ion (LiIon) Battery so that
you can use the phone immediately after it is activated.

Installing the Battery.

To attach the battery to your phone :

1. Hold the battery so that metal contacts on the base of the battery line up with the metal
contacts on the base of the phone.

2. Place the battery on the back of the phone with the top of the battery about a quarter of an
inch from the latch.

3. Gently slide the battery toward the top of the phone until it snaps into place.

Charging the Battery.

You can tell whether or not your battery needs to be recharged by checking the lower-right
corner of your phone’s display.

When the battery charge level gets low, the battery sensor will let you know by blinking the
battery icon and sounding a warning tone. If the battery level gets too low, the phone will turn
off automatically. Unfortunately, if this happens you’ll lose whatever you were just doing,
including dropping your call. Watch the battery strength icon and make sure your battery is
adequately charged.

Charging with the Single-Slot Desktop Charger.

Use only Vacom approved chargers and adapters with your phone. Use of any unauthorized
accessories may be dangerous and will invalidate the phone warranty if said accessories cause
damage or a defect to the phone.

To charge the battery using the Single-Slot Desktop Charger :

- Plug the power cord of the charger into a wall outlet.

- Insert the entire phone with battery attached or a single battery into the cradle of the
charger.

10

If you charge the battery while it is attached to your phone, a green LED on the charger denotes
that the battery has completed its charge cycle.

A completely discharged standard battery recharges fully in approximately tbd hours. The
extended battery recharges in approximately tbd hours. Leaving your phone powered on during
charging, or charging batteries simultaneously, increases charging time. Leaving the battery in
the charger once it is fully charged does not harm the battery.

Turning your phone on and off.

When you’re ready to turn your phone on, fully extend the antenna for best reception. Press and
hold “END/ ” until the LED comes on and the phone sounds. When the phone has found a

signal, the “ ” icon appears. Once the phone is on, it enters Standby mode, which is the
phone’s idle state. You can make and receive calls now.

To turn your phone off, press and hold “END/ ” until the LED comes on and the phone sounds,
then the display will goes blank. When the phone is turned off, nothing is displayed on the
screen.

Note : If “END/ ” is pressed for less than one second, the phone will not turn off. This helps
your phone from being turned off accidentally.

Standby mode.

Standby is the most basic state of your phone. The phone goes into standby mode soon after you
turn it on, or whenever you briefly press “END/ ”. When your phone is in Standby mode, you
will typically see the banner (that’s the message displayed when you turn on your phone). If you
enter a phone number, you can press “SEND” to dial it, or press “SMS key (…)”to save it in the
internal phone book.

Power Save mode.

Your phone comes with a Power Save feature that will automatically be activated if your phone
is unable to find a signal after 15 minutes of searching. While this feature is active, the phone’s
battery charge is conserved.
The phone will automatically recheck for a signal periodically. To manually force the phone to

11
