Compal NM-A272 ACLU1, NM-A272 ACLU2 Schematic

A

1 1

B

C

D

E

LCFC Confidential

ACLU1/2 UMA M/B Schematics Document

2 2

Intel Haswell/Broadwell U-Processor

2013-12-05

3 3

4 4

Security Classification

Security Classification

Security Classification

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

A

B

REV:1.0

Issued Date

Issued Date

Issued Date

2013/08/08

2013/08/08

2013/08/08

C

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2013/08/05

2013/08/05

2013/08/05

D

Title

Title

Title

Cover Page

Cover Page

Cover Page

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

E

of

of

of

1 59

1 59

1 59

1.0

1.0

1.0

A

LCFC confidential

File Name : ACLU2

B

C

D

E

Memory BUS (DDR3L)
Dual Channel

1 1

HDMI Conn.

Page34

HDMI

1.35V DDR3L 1600 MT/s

USB Left

USB 3.0 1x

USB 3.0 Port1

DDR3L-SO-DIMM X2

Page 14,15

UP TO 8G x 2

USB 2.0 Port1

VGA Conn.

DP to VGA

Parade PS8613

Page35Page36

eDP Conn

Int. Camera

USB2.0 Port5

2 2

Int. MIC Conn.

Page33

SATA HDD

Page42

SATA Port0

DPx2 Lane

Intel MCP

eDP x2 Lane

USB2.0 1x

Haswell U 15W /

Broadwell U 15W

SATA Gen3

BGA-1168

SATA ODD

Page42

RJ45 Conn.

Page38

3 3

LAN Realtek

RTL8111GUL (1G)
RTL8106EUL (10M/100M)

Page37

SATA Port1

PCIe Port3

SATA Gen1

PCIe 1x

HD Audio

Page3~13

40mm*24mm

USB 2.0 2x

USB 2.0 1x

USB2.0 1x

USB2.0 1x

USB 2.0 1x

PCIe 1x

SPI BUS

USB 2.0 Port2

Page41

Touch Screen

Page33

USB2.0 Port4

USB Right

USB2.0 Port0

Cardreader Realtek
RTS5170

NGFF Card
WLAN&BT

Page40

USB2.0 Port3

PCIe Port4
USB2.0 Port6

SPI ROM
8MB

Page07

SD/MMC Conn.

USB Board

Sub-board ( for 14")

POWERBOARD

Codec

Conexant CX20752

Page43

SPK Conn.

Page43

SPI ROM 4MB

for reserve

Page07

USBBoard

EC
ITE IT8586E-LQFP

Page44

HP&Mic Combo Conn.

USB Board

4 4

A

B

Touch Pad Int.KBD

Page45 Page45

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

C

Thermal Sensor
NCT7718W

Page39

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

D

2013/08/05

2013/08/05

2013/08/05

Date: Sheet

Date: Sheet

Date: Sheet

Sub-board ( for 15")

POWERBOARD

USBBoard

ODDBoard

Title

Title

Title

Block Diagram

Block Diagram

Block Diagram

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

2 59

2 59

E

2 59

1.0

1.0

1.0

A

B

C

D

E

Voltage Rails

Power Plane

1 1

( O --> Means ON , X --> Means OFF )

+3VALW

B+

+3VALW_PCH

+5VALW

+1.35V

+5VS

+3VS

+1.5VS

+1.35VS

+1.05VS

+0.675VS

CPU_CORE

STATE

Full ON

S1(Power On Suspend)

S3 (Suspend to RAM)

S4 (Suspend to Disk)

S5 (Soft OFF)

SIGNAL

SLP_S1# SLP_S3# SLP_S4# SLP_S5# +VALW +V +VS Clock

HIGH HIGH HIGH HIGH

HIGH

LOWLOWLOW

HIGHHIGHHIGH

HIGH

HIGH

LOW

LOW

LOW

LOW LOW LOW LOW

ON

ON

ON

OFF

OFF

ON ON

ON

OFF

OFF

OFF

LOW

OFF

OFF

OFF

ON

ON

ON

ON

ON

State

USB Port Table

USB 3.0USB 2.0

EHCI1

S0

S3

2 2

S3
Battery only

S5 S4/AC Only

O

O

O

O X

OO O

OO

O

O

O

O

O

O

O

X

0

USB Port (Right Side)

1

USB Port1 (Left Side)

X

X

2

USB Port2 (Left Side)

3

Cardreader

4

TOUCH PANEL

5

Camera

6

NGFF(WLAN)

1

2

3

4

7

S5 S4
Battery only

O

XX

X

X

XHCI

USB Port1 (Left Side)

BOM Structure Table

BTO ItemBOM Structure

@
14@
15@
8111GUL@
8106EUL@
AOAC@
GIGA@
JET@
ME@
TS@

Not stuff

For 14" part

For 15" part

8111GUL LAN Part

8106EUL LAN Part

AOAC support part

GIGA LAN Part

For AMD Jet GPU part

ME part(connector, hole)

For support touch panel sku part

S5 S4
AC & Battery
don't exist

XX

X

X

X

PCIE PORT LIST

3 3

4 4

SMBUS Control Table

EC_SMB_DA1

EC_SMB_CK2

EC_SMB_DA2

PCH_SMB_CLK

PCH_SMB_DATA

+3VALW_PCH

EC SM Bus1 address

Device

Smart Battery

Charger

0X16

0001 0010 b

A

SOURCE

IT8586EEC_SMB_CK1

+3VALW

IT8586E

+3VS

PCH

WLAN

BATT SODIMM

IT8586E

V

+3VALW

X

V

+3VS

XX X

X

VV

+3VS +3VS

WiMAX

X

X

V

Thermal
Sensor

XXV

V

+3VS

EC SM Bus2 address

Device

Thermal Sensor NCT7718W

PCH

Address

1001_100xb

need to update

B

TP

PCH

V

+3VALW_PCH

+3VALW_PCH

PCH SM Bus address

Device Address

DDR DIMMA

DDR DIMMB

Wlan

charger

Module

XX

X

X

V

X

X

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

1010 000Xb

1010 010Xb

Rsvd

C

Port

1
2
3
4
5
6

2013/08/08

2013/08/08

2013/08/08

Device

LAN

WLAN

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

D

2013/08/05

2013/08/05

2013/08/05

Title

Title

Title

Notes List

Notes List

Notes List

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

3 59

3 59

E

3 59

1.0

1.0

1.0

5

4

3

2

1

UC1A

D D

HDMI D2

HDMI D1

HDMI D0

HDMI CLK

DP TO VGA Converter

C C

ACLU2: delete PXS_PWREN_R PXS_RST#_R PORT
and RC7 RC8 RC170 QC13

B B

A A

5

HDMI_TX2-{34}
HDMI_TX2+{34}
HDMI_TX1-{34}
HDMI_TX1+{34}
HDMI_TX0-{34}
HDMI_TX0+{34}
HDMI_CLK-{34}
HDMI_CLK+{34}

VGA_TX0-{35}
VGA_TX0+{35}
VGA_TX1-{35}
VGA_TX1+{35}

+3VS

RPC1

1 8
2 7
3 6
4 5

10K_0804_8P4R_5%

+3VS

1 2

RC10 10K_0402_5%

1 2

RC11 10K_0402_5%

1 2

RC14 10K_0402_5%

1 2

RC15 10K_0402_5%

Reserve for NV GPU

1 2

RC27 10K_0402_5%@

1 2

RC30 10K_0402_5%@

RC17 100K_0402_5%@

1 2

RC18 10K_0402_5%@

12

HDMI_TX2­HDMI_TX2+
HDMI_TX1­HDMI_TX1+
HDMI_TX0­HDMI_TX0+
HDMI_CLK­HDMI_CLK+

VGA_TX0­VGA_TX0+
VGA_TX1­VGA_TX1+

1

TC1

BOARD_ID3
GPIO52
PXS_PWREN_R
PXS_RST#_R
GPIO53

GPIO52

GPIO53

PXS_PWREN_R

PXS_RST#_R

GPIO52

GPIO53

PXS_PWREN_R

PXS_RST#_R

PCH_EDP_PWM
PCH_ENBKL
PCH_ENVDD

PCI_PIRQA#
PCI_PIRQB#
PCI_PIRQC#
PCI_PIRQD#

PCH_EDP_PWM{33}

PCH_ENBKL{33}
PCH_ENVDD{33}

PAD@

BOARD_ID3{9}

PCI_PIRQA#
PCI_PIRQB#
PCI_PIRQC#
PCI_PIRQD#

4

C54

DDI1_TXN0

C55

DDI1_TXP0

B58

DDI1_TXN1

C58

DDI1_TXP1

B55

DDI1_TXN2

A55

DDI1_TXP2

A57

DDI1_TXN3

B57

DDI1_TXP3

C51

DDI2_TXN0

C50

DDI2_TXP0

C53

DDI2_TXN1

B54

DDI2_TXP1

C49

DDI2_TXN2

B50

DDI2_TXP2

A53

DDI2_TXN3

B53

DDI2_TXP3

HASWELL-ULT-DDR3L_BGA1168

UC1I

B8

EDP_BKLCTL

A9

EDP_BKLEN

C6

EDP_VDDEN

U6

PIRQA/GPIO77

P4

PIRQB/GPIO78

N4

PIRQC/GPIO79

N2

PIRQD/GPIO80

AD4

PME

U7

GPIO55

L1

GPIO52

L3

GPIO54

R5

GPIO51

L4

GPIO53

HASWELL-ULT-DDR3L_BGA1168

eDP SIDEBAND

HSW_ULT_DDR3L

C45

EDP_TXN0
EDP_TXP0
EDP_TXN1
EDP_TXP1

EDP_TXN2
EDP_TXP2

EDPDDI

1 OF 19

HSW_ULT_DDR3L

PCIE

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

DISPLAY

9 OF 19

3

EDP_TXN3
EDP_TXP3

EDP_AUXN
EDP_AUXP

EDP_RCOMP

EDP_DISP_UTIL

DDPB_CTRLCLK

DDPB_CTRLDATA

DDPC_CTRLCLK

DDPC_CTRLDATA

DDPB_AUXN
DDPC_AUXN
DDPB_AUXP
DDPC_AUXP

DDPB_HPD
DDPC_HPD

EDP_HPD

2013/08/08

2013/08/08

2013/08/08

CPU_EDP_TX0-

B46

CPU_EDP_TX0+

A47

CPU_EDP_TX1-

B47

CPU_EDP_TX1+

C47
C46
A49
B49

A45

CPU_EDP_AUX#

B45

CPU_EDP_AUX

D20

EDP_COMP

A43

LCD_BKLT_CTRL_R

B9

DDPB_CLK

C9

DDPB_DATA

D9

DDPC_CLK

D11

DDPC_DATA

C5
B6

VGA_AUX#

B5
A6

VGA_AUX

C8

HDMI_HPD

A8

VGA_HPD

D6

EDP_HPD

12

RC9

1M_0402_5%

@

EDP_HPD

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

RC1 24.9_0402_1%
RC2 0_0402_5%@

12

@

RC16 0_0402_5%

CPU_EDP_TX0- {33}
CPU_EDP_TX0+ {33}
CPU_EDP_TX1- {33}
CPU_EDP_TX1+ {33}

CPU_EDP_AUX# {33}
CPU_EDP_AUX {33}

1 2
1 2

DDPB_CLK {34}
DDPB_DATA {34}

VGA_AUX# {35}

VGA_AUX {35}

HDMI_HPD {34}
VGA_HPD {35}

RC37
100K_0402_5%

@

+3VS+3VS

G

2

13

QC4

D

S

2N7002KW_SOT323-3

1 2

@

2

After confirm with vendor, HPD
has internal pull-down ~100K at
PS8613, just reserve in case.
RC37 can be removed next phase
if no issue.

2013/08/05

2013/08/05

2013/08/05

+VCCIOA_OUT

INVT_PWM {33}

DDPB_DATA
DDPB_CLK
DDPC_DATA
DDPC_CLK

DDPx_CTRLDATA
The signal has a weak internal pull-down.
H Port is detected.

*

L Port is not detected.

12

RC13
100K_0402_5%

+VCCIOA_OUT & EDP_COMP :
Trace Width: 20mil
Space: 25mil
Max length: 100mil

RPC19

1 8
2 7
3 6
4 5

2.2K_0804_8P4R_5%

CPU_EDP_HPD {33}

Title

Title

Title

MCP (DDI,EDP)

MCP (DDI,EDP)

MCP (DDI,EDP)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

+3VS

UMA

UMA

UMA

1

4 59

1.0

1.0

1.0

of

of

of

4 59

4 59

5

4

3

2

1

+1.05V_VCCST

D D

H_PROCHOT#{44,51,52}

1 2

CPU_DRAMRST#{14,15}

C C

12

SM_RCOMP_2

RC24100_0402_1%

12

SM_RCOMP_1

RC25121_0402_1%

12

SM_RCOMP_0

RC26200_0402_1%

B B

RC23 0_0402_5%

1

CC1

0.01U_0402_25V7K

2

RC19

62_0402_1%

@

+1.35V

12

12

RC22
470_0402_5%

H_PECI{44}

1 2

1 2

10K_0402_5%

TC2 @
TC3 @

+1.35V

H_PROCHOT#_R

RC2056_0402_5%

CPU_PROCPWRGD

RC21

SM_RCOMP_0
SM_RCOMP_1
SM_RCOMP_2
CPU_DRAMRST#_R
SM_PG_CNTL1

RC3

SM_PG_CNTL1

1

PROC_DETECT#

1

CATERR#
H_PECI

1 2

1K_0402_5%

10K_0402_5%

UC1B

D61

PROC_DETECT

K61

CATERR

N62

PECI

K63

PROCHOT

C61

PROCPWRGD

AU60

SM_RCOMP0

AV60

SM_RCOMP1

AU61

SM_RCOMP2

AV15

SM_DRAMRST

AV61

SM_PG_CNTL1

HASWELL-ULT-DDR3L_BGA1168

+3VALW

12

RC28
100K_0402_5%

C

2

QC14

B

E

3 1

MMBT3904WH_SOT323-3

RC29

@

1 2

HSW_ULT_DDR3L

MISC

THERMAL

PWR

DDR3L

CPU_DRAMPG_CNTL {55}

1 2

RC31 0_0402_5%

@

.1U_0402_10V6-K

PROC_TCK
PROC_TMS

JTAG

PROC_TRST

PROC_TDI

PROC_TDO

BPM#0
BPM#1
BPM#2
BPM#3
BPM#4
BPM#5
BPM#6
BPM#7

2 OF 19

2

1

CD1

@

2

Need change to PJA138K.

PRDY
PREQ

G

+1.35V

1

3

J62

XDP_PRDY#

K62

XDP_PREQ#

E60

XDP_TCLK

E61

XDP_TMS

E59

XDP_TRST#

F63

XDP_TDI

F62

XDP_TDO

J60

XDP_BPM0#

H60

XDP_BPM1#

H61

XDP_BPM2#

H62

XDP_BPM3#

K59

XDP_BPM4#

H63

XDP_BPM5#

K60

XDP_BPM6#

J61

XDP_BPM7#

QC5

D

S

PJA138K_SOT23-3

1

PAD @

TC4

1

PAD @

TC5

1

PAD @

TC6

1

PAD @

TC7

1

PAD @

TC8

1

PAD @

TC9

1

PAD @

TC10

1

PAD @

TC11

1

PAD @

TC12

1

PAD @

TC13

1

PAD @

TC14

1

PAD @

TC15

1

PAD @

TC16

1

PAD @

TC17

1

PAD @

TC18

1 2

RD1 66.5_0402_1%

1 2

RD2 66.5_0402_1%

1 2

RD3 66.5_0402_1%

1 2

RD4 66.5_0402_1%

DDRA_ODT0

DDRA_ODT1DDR_ODT

DDRB_ODT0

DDRB_ODT1

DDRA_ODT0 {14}

DDRA_ODT1 {14}

DDRB_ODT0 {15}

DDRB_ODT1 {15}

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

MCP (MISC,THERMAL,JATG)

MCP (MISC,THERMAL,JATG)

MCP (MISC,THERMAL,JATG)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

5 59

5 59

1

5 59

1.0

1.0

1.0

5

4

3

2

1

UC1C

DDRA_DQ[0..15]{14}

D D

DDRB_DQ[0..15]{15}

DDRA_DQ[16..31]{14}

C C

DDRB_DQ[16..31]{15}

B B

DDRA_DQ0
DDRA_DQ1
DDRA_DQ2
DDRA_DQ3
DDRA_DQ4
DDRA_DQ5
DDRA_DQ6
DDRA_DQ7
DDRA_DQ8
DDRA_DQ9
DDRA_DQ10
DDRA_DQ11
DDRA_DQ12
DDRA_DQ13
DDRA_DQ14
DDRA_DQ15
DDRB_DQ0
DDRB_DQ1
DDRB_DQ2
DDRB_DQ3
DDRB_DQ4
DDRB_DQ5
DDRB_DQ6
DDRB_DQ7
DDRB_DQ8
DDRB_DQ9
DDRB_DQ10
DDRB_DQ11
DDRB_DQ12
DDRB_DQ13
DDRB_DQ14
DDRB_DQ15
DDRA_DQ16
DDRA_DQ17
DDRA_DQ18
DDRA_DQ19
DDRA_DQ20
DDRA_DQ21
DDRA_DQ22
DDRA_DQ23
DDRA_DQ24
DDRA_DQ25
DDRA_DQ26
DDRA_DQ27
DDRA_DQ28
DDRA_DQ29
DDRA_DQ30
DDRA_DQ31
DDRB_DQ16
DDRB_DQ17
DDRB_DQ18
DDRB_DQ19
DDRB_DQ20
DDRB_DQ21
DDRB_DQ22
DDRB_DQ23
DDRB_DQ24
DDRB_DQ25
DDRB_DQ26
DDRB_DQ27
DDRB_DQ28
DDRB_DQ29
DDRB_DQ30
DDRB_DQ31

AH63

SA_DQ0

AH62

SA_DQ1

AK63

SA_DQ2

AK62

SA_DQ3

AH61

SA_DQ4

AH60

SA_DQ5

AK61

SA_DQ6

AK60

SA_DQ7

AM63

SA_DQ8

AM62

SA_DQ9

AP63

SA_DQ10

AP62

SA_DQ11

AM61

SA_DQ12

AM60

SA_DQ13

AP61

SA_DQ14

AP60

SA_DQ15

AP58

SA_DQ16

AR58

SA_DQ17

AM57

SA_DQ18

AK57

SA_DQ19

AL58

SA_DQ20

AK58

SA_DQ21

AR57

SA_DQ22

AN57

SA_DQ23

AP55

SA_DQ24

AR55

SA_DQ25

AM54

SA_DQ26

AK54

SA_DQ27

AL55

SA_DQ28

AK55

SA_DQ29

AR54

SA_DQ30

AN54

SA_DQ31

AY58

SA_DQ32

AW58

SA_DQ33

AY56

SA_DQ34

AW56

SA_DQ35

AV58

SA_DQ36

AU58

SA_DQ37

AV56

SA_DQ38

AU56

SA_DQ39

AY54

SA_DQ40

AW54

SA_DQ41

AY52

SA_DQ42

AW52

SA_DQ43

AV54

SA_DQ44

AU54

SA_DQ45

AV52

SA_DQ46

AU52

SA_DQ47

AK40

SA_DQ48

AK42

SA_DQ49

AM43

SA_DQ50

AM45

SA_DQ51

AK45

SA_DQ52

AK43

SA_DQ53

AM40

SA_DQ54

AM42

SA_DQ55

AM46

SA_DQ56

AK46

SA_DQ57

AM49

SA_DQ58

AK49

SA_DQ59

AM48

SA_DQ60

AK48

SA_DQ61

AM51

SA_DQ62

AK51

SA_DQ63

HASWELL-ULT-DDR3L_BGA1168

HSW_ULT_DDR3L

DDR CHANNEL A

3 OF 19

SA_CLK#0

SA_CLK0

SA_CLK#1

SA_CLK1

SA_CKE0
SA_CKE1
SA_CKE2
SA_CKE3

SA_CS#0
SA_CS#1

SA_ODT0

SA_RAS

SA_WE

SA_CAS

SA_BA0
SA_BA1
SA_BA2

SA_MA0
SA_MA1
SA_MA2
SA_MA3
SA_MA4
SA_MA5
SA_MA6
SA_MA7
SA_MA8

SA_MA9
SA_MA10
SA_MA11
SA_MA12
SA_MA13
SA_MA14
SA_MA15

SA_DQSN0
SA_DQSN1
SA_DQSN2
SA_DQSN3
SA_DQSN4
SA_DQSN5
SA_DQSN6
SA_DQSN7

SA_DQSP0
SA_DQSP1
SA_DQSP2
SA_DQSP3
SA_DQSP4
SA_DQSP5
SA_DQSP6
SA_DQSP7

SM_VREF_CA
SM_VREF_DQ0
SM_VREF_DQ1

AU37
AV37
AW36
AY36

AU43
AW43
AY42
AY43

AP33
AR32

AP32

SA_ODT0

AY34
AW34
AU34

AU35
AV35
AY41

AU36

DDRA_MA0

AY37

DDRA_MA1

AR38

DDRA_MA2

AP36

DDRA_MA3

AU39

DDRA_MA4

AR36

DDRA_MA5

AV40

DDRA_MA6

AW39

DDRA_MA7

AY39

DDRA_MA8

AU40

DDRA_MA9

AP35

DDRA_MA10

AW41

DDRA_MA11

AU41

DDRA_MA12

AR35

DDRA_MA13

AV42

DDRA_MA14

AU42

DDRA_MA15

AJ61

DDRA_DQS#0

AN62
AM58

DDRB_DQS#0

AM55

DDRB_DQS#1

AV57

DDRA_DQS#2

AV53

DDRA_DQS#3

AL43

DDRB_DQS#2

AL48

AJ62

DDRA_DQS0

AN61

DDRA_DQS1

AN58

DDRB_DQS0

AN55

DDRB_DQS1

AW57

DDRA_DQS2

AW53

DDRA_DQS3

AL42

DDRB_DQS2

AL49

DDRB_DQS3

AP49
AR51
AP51

SMVREF

WIDTH:20MIL
SPACING: 20MIL

DDRA_DQS#[0..7]

DDRA_DQS[0..7]

1

TC19

DDRA_CLK0# {14}
DDRA_CLK0 {14}
DDRA_CLK1# {14}
DDRA_CLK1 {14}

DDRA_CKE0 {14}
DDRA_CKE1 {14}

DDRA_CS0# {14}
DDRA_CS1# {14}

PAD @

DDRA_RAS# {14}

DDRA_WE# {14}

DDRA_CAS# {14}

DDRA_BS0# {14}
DDRA_BS1# {14}
DDRA_BS2# {14}

DDRA_MA[0..15] {14}

DDR_SM_VREFCA {14}
DDR_SA_VREFDQ {14}
DDR_SB_VREFDQ {15}

DDRA_DQS#[0..7] {14}

DDRA_DQS[0..7] {14}

UC1D

DDRA_DQ[32..47]{14}

DDRB_DQ[32..47]{15}

DDRA_DQ[48..63]{14}

DDRB_DQ[48..63]{15}

DDRA_DQ32
DDRA_DQ33
DDRA_DQ34
DDRA_DQ35
DDRA_DQ36
DDRA_DQ37
DDRA_DQ38
DDRA_DQ39
DDRA_DQ40
DDRA_DQ41
DDRA_DQ42
DDRA_DQ43
DDRA_DQ44
DDRA_DQ45
DDRA_DQ46
DDRA_DQ47
DDRB_DQ32
DDRB_DQ33
DDRB_DQ34
DDRB_DQ35
DDRB_DQ36
DDRB_DQ37
DDRB_DQ38
DDRB_DQ39
DDRB_DQ40
DDRB_DQ41
DDRB_DQ42
DDRB_DQ43
DDRB_DQ44
DDRB_DQ45
DDRB_DQ46
DDRB_DQ47
DDRA_DQ48
DDRA_DQ49
DDRA_DQ50
DDRA_DQ51
DDRA_DQ52
DDRA_DQ53
DDRA_DQ54
DDRA_DQ55
DDRA_DQ56
DDRA_DQ57
DDRA_DQ58
DDRA_DQ59
DDRA_DQ60
DDRA_DQ61
DDRA_DQ62
DDRA_DQ63
DDRB_DQ48
DDRB_DQ49
DDRB_DQ50
DDRB_DQ51
DDRB_DQ52
DDRB_DQ53
DDRB_DQ54
DDRB_DQ55
DDRB_DQ56
DDRB_DQ57
DDRB_DQ58
DDRB_DQ59
DDRB_DQ60
DDRB_DQ61
DDRB_DQ62
DDRB_DQ63

AY31

SB_DQ0

AW31

SB_DQ1

AY29

SB_DQ2

AW29

SB_DQ3

AV31

SB_DQ4

AU31

SB_DQ5

AV29

SB_DQ6

AU29

SB_DQ7

AY27

SB_DQ8

AW27

SB_DQ9

AY25

SB_DQ10

AW25

SB_DQ11

AV27

SB_DQ12

AU27

SB_DQ13

AV25

SB_DQ14

AU25

SB_DQ15

AM29

SB_DQ16

AK29

SB_DQ17

AL28

SB_DQ18

AK28

SB_DQ19

AR29

SB_DQ20

AN29

SB_DQ21

AR28

SB_DQ22

AP28

SB_DQ23

AN26

SB_DQ24

AR26

SB_DQ25

AR25

SB_DQ26

AP25

SB_DQ27

AK26

SB_DQ28

AM26

SB_DQ29

AK25

SB_DQ30

AL25

SB_DQ31

AY23

SB_DQ32

AW23

SB_DQ33

AY21

SB_DQ34

AW21

SB_DQ35

AV23

SB_DQ36

AU23

SB_DQ37

AV21

SB_DQ38

AU21

SB_DQ39

AY19

SB_DQ40

AW19

SB_DQ41

AY17

SB_DQ42

AW17

SB_DQ43

AV19

SB_DQ44

AU19

SB_DQ45

AV17

SB_DQ46

AU17

SB_DQ47

AR21

SB_DQ48

AR22

SB_DQ49

AL21

SB_DQ50

AM22

SB_DQ51

AN22

SB_DQ52

AP21

SB_DQ53

AK21

SB_DQ54

AK22

SB_DQ55

AN20

SB_DQ56

AR20

SB_DQ57

AK18

SB_DQ58

AL18

SB_DQ59

AK20

SB_DQ60

AM20

SB_DQ61

AR18

SB_DQ62

AP18

SB_DQ63

HASWELL-ULT-DDR3L_BGA1168

HSW_ULT_DDR3L

4 OF 19

DDR CHANNEL B

SB_CK#0

SB_CK0

SB_CK#1

SB_CK1

SB_CKE0
SB_CKE1
SB_CKE2
SB_CKE3

SB_CS#0
SB_CS#1

SB_ODT0

SB_RAS

SB_WE

SB_CAS

SB_BA0
SB_BA1
SB_BA2

SB_MA0
SB_MA1
SB_MA2
SB_MA3
SB_MA4
SB_MA5
SB_MA6
SB_MA7
SB_MA8

SB_MA9
SB_MA10
SB_MA11
SB_MA12
SB_MA13
SB_MA14
SB_MA15

SB_DQSN0
SB_DQSN1
SB_DQSN2
SB_DQSN3
SB_DQSN4
SB_DQSN5
SB_DQSN6
SB_DQSN7

SB_DQSP0
SB_DQSP1
SB_DQSP2
SB_DQSP3
SB_DQSP4
SB_DQSP5
SB_DQSP6
SB_DQSP7

AM38
AN38
AK38
AL38

AY49
AU50
AW49
AV50

AM32
AK32

AL32

SB_ODT0

AM35
AK35
AM33

AL35
AM36
AU49

AP40
AR40
AP42
AR42
AR45
AP45
AW46
AY46
AY47
AU46
AK36
AV47
AU47
AK33
AR46
AP46

AW30
AV26
AN28
AN25
AW22
AV18
AN21
AN18

AV30
AW26
AM28
AM25
AV22
AW18
AM21
AM18

DDRB_DQS#[0..7]

DDRB_DQS[0..7]

DDRB_MA0
DDRB_MA1
DDRB_MA2
DDRB_MA3
DDRB_MA4
DDRB_MA5
DDRB_MA6
DDRB_MA7
DDRB_MA8
DDRB_MA9
DDRB_MA10
DDRB_MA11
DDRB_MA12
DDRB_MA13
DDRB_MA14
DDRB_MA15

DDRA_DQS#4DDRA_DQS#1
DDRA_DQS#5
DDRB_DQS#4
DDRB_DQS#5
DDRA_DQS#6
DDRA_DQS#7
DDRB_DQS#6DDRB_DQS#3
DDRB_DQS#7

DDRA_DQS4
DDRA_DQS5
DDRB_DQS4
DDRB_DQS5
DDRA_DQS6
DDRA_DQS7
DDRB_DQS6
DDRB_DQS7

1

DDRB_CLK0# {15}
DDRB_CLK0 {15}
DDRB_CLK1# {15}
DDRB_CLK1 {15}

DDRB_CKE0 {15}
DDRB_CKE1 {15}

DDRB_CS0# {15}
DDRB_CS1# {15}

PAD @

TC20

DDRB_RAS# {15}

DDRB_WE# {15}

DDRB_CAS# {15}

DDRB_BS0# {15}
DDRB_BS1# {15}
DDRB_BS2# {15}

DDRB_MA[0..15] {15}

DDRB_DQS#[0..7] {15}

DDRB_DQS[0..7] {15}

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

MCP (DDR3L)

MCP (DDR3L)

MCP (DDR3L)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

of

of

of

6 59

6 59

1

6 59

1.0

1.0

1.0

5

RTC_X1

RC32 10M_0402_5%

YC1

32.768KHZ_12.5PF_200458-PG14

2

CC4
15P_0402_50V8J

1

D D

C C

CRYSTAL

1, Space 15MIL
2, No trace under crystal
3, Place on oppsosit side of MCP for temp influence

+3VALW_PCH

RC47 1K_0402_5%@

HDA_SDO This signal has a weak internal pull-down.
0 = Enable security measures defined in the Flash Descriptor.

*

1 = Disable Flash Descriptor Security(override). This strap
should only be asserted high during external pull-up in
manufacturing/debug environments ONLY.

12

1 2

1 2

For EMI

1

@

CC7
10P_0402_50V8J

2

HDA_SDOUT

HDA_SDIN0

RTC_X2

2

CC5
18P_0402_50V8J

1

VCCRTC

1 2

RC33 20K_0402_1%

1 2

RC34 20K_0402_1%

VCCRTC

RC39 1M_0402_5%
RC41 330K_0402_5%

INTVRMEN
HIntegrated VRM enable (Default)

*

LIntegrated VRM disable　
(INTVRMEN should always be pull high.)

HDA_BITCLK_AUDIO{43}
HDA_SYNC_AUDIO{43}
HDA_RST_AUDIO#{43}
HDA_SDIN0{43}

HDA_SDOUT_AUDIO{43}
ME_FLASH{44}

4

1

CC3

1U_0402_10V6K

1U_0402_10V6K

2

1

CC6

2

12
12

1 2

RC42 33_0402_5%

1 2

RC43 33_0402_5%

1 2

RC44 33_0402_5%

1 2

RC45 33_0402_5%

1 2

RC46 0_0402_5%

@

TC24 @
TC25 @
TC26 @
TC28 @
TC30 @

TC32 @
TC33 @
TC34 @

12

JME1
SHORT PADS

@

12

JCMOS1
SHORT PADS

@

1
1
1
1
1

1
1
1

SRTC_RST#
RTC_RST#

RTC_X1
RTC_X2
SM_INTRUDER#
INTVRMEN
SRTC_RST#
RTC_RST#

HDA_BCLK
HDA_SYNC
HDA_RST#
HDA_SDIN0

HDA_SDOUT

TC21 @
TC22 @
TC23 @

PCH_JTAG_TRST#
PCH_JTAG_TCK
PCH_JTAG_TDI
PCH_JTAG_TDO
PCH_JTAG_TMS

PCH_JTAGX

UC1E

AW5

RTCX1

AY5

RTCX2

AU6

INTRUDER

AV7

INTVRMEN

AV6

SRTCRST

AU7

RTCRST

AW8

HDA_BCLK/I2S0_SCLK

AV11

HDA_SYNC/I2S0_SFRM

AU8

HDA_RST/I2S_MCLK

AY10

HDA_SDI0/I2S0_RXD

AU12

HDA_SDI1/I2S1_RXD

AU11

HDA_SDO/I2S0_TXD

1

AW10

HDA_DOCK_EN/I2S1_TXD

1

AV10

HDA_DOCK_RST/I2S1_SFRM

AY8

1

I2S1_SCLK

AU62

PCH_TRST

AE62

PCH_TCK

AD61

PCH_TDI

AE61

PCH_TDO

AD62

PCH_TMS

AL11

RSVD1

AC4

RSVD2

AE63

JTAGX

AV2

RSVD0

HASWELL-ULT-DDR3L_BGA1168

3

HSW_ULT_DDR3L

RTC

AUDIO SATA

JTAG

5 OF 19

SATA_RN0/PERN6_L3

SATA_RP0/PERP6_L3
SATA_TN0/PETN6_L3
SATA_TP0/PETP6_L3

SATA_RN1/PERN6_L2

SATA_RP1/PERP6_L2
SATA_TN1/PETN6_L2
SATA_TP1/PETP6_L2

SATA_RN2/PERN6_L1

SATA_RP2/PERP6_L1
SATA_TN2/PETN6_L1
SATA_TP2/PETP6_L1

SATA_RN3/PERN6_L0

SATA_RP3/PERP6_L0
SATA_TN3/PETN6_L0

SATA_TP3/PETP6_L0

SATA0GP/GPIO34
SATA1GP/GPIO35
SATA2GP/GPIO36
SATA3GP/GPIO37

SATA_IREF

RSVD3
RSVD4

SATA_RCOMP

SATALED

J5
H5
B15
A15

J8
H8
A17
B17

J6
H6
B14
C15

F5
E5
C17
D17

V1
U1
V6
AC1

A12
L11
K10
C12
U3

SATA_RCOMP
SATALED#

SATA_PRX_DTX_N0
SATA_PRX_DTX_P0
SATA_PTX_DRX_N0
SATA_PTX_DRX_P0

SATA_PRX_DTX_N1
SATA_PRX_DTX_P1
SATA_PTX_DRX_N1
SATA_PTX_DRX_P1

SATA0GP
ODD_DETECT#
SATA2GP
SATA3GP

RC48 3.01K_0402_1%
RC49 10K_0402_5%@

2

ODD_DETECT# {42}

12

1 2

SATA_PRX_DTX_N0 {42}
SATA_PRX_DTX_P0 {42}
SATA_PTX_DRX_N0 {42}
SATA_PTX_DRX_P0 {42}

SATA_PRX_DTX_N1 {42}
SATA_PRX_DTX_P1 {42}
SATA_PTX_DRX_N1 {42}
SATA_PTX_DRX_P1 {42}

+1.05VS_PSATA3PLL

+3VS

HDD

ODD

IREF&RCOMP

Width: 12-15Mil
Space:12Mil
Length: 500Mil

ODD_DETECT#
SATA0GP
SATA2GP
SATA3GP

SML0_CLK

RC35 2.2K_0402_5%

SML0_DATA

RC36 2.2K_0402_5%

SMB_ALERT#
SML0_ALERT#
SML1_ALERT#

1

RPC2

1 8
2 7
3 6
4 5

10K_0804_8P4R_5%

RPC22

1 8
2 7
3 6
4 5

10K_0804_8P4R_5%

+3VS

+3VALW_PCH

12

12

UC1G

SPI_CS0#_R
SPI_CS1#_RSPI_CS1#

SPI_SI_R
SPI_SO_R
SPI_WP#_R
SPI_HOLD#_R

AU14

LAD0

AW12

LAD1

AY12

LAD2

AW11

LAD3

AV12

LFRAME

AA3

SPI_CLK

Y7

SPI_CS0

Y4

SPI_CS1

AC2

SPI_CS2

AA2

SPI_MOSI

AA4

SPI_MISO

Y6

SPI_IO2

AF1

SPI_IO3

HASWELL-ULT-DDR3L_BGA1168

SPI_CS0#

SPI_SO

SPI_WP#

SPI_CS1#

SPI_SO_1

SPI_WP#_1

LPC_AD0{44}
LPC_AD1{44}
LPC_AD2{44}
LPC_AD3{44}

LPC_FRAME#{44}

SPI_CLK_1

SPI_CLK{44}
SPI_CS0#{44}

SPI_SI{44}

12

RC61
1K_0402_5%

12

RC180
1K_0402_5%

@

SPI_SO{44}

SPI_WP#

SPI_HOLD#

SPI_HOLD#_1

B B

+3V_SPI

12

RC60

1K_0402_5%

SPI_WP#_R

SPI_HOLD#_R

SPI_WP#_R SPI_WP#_1

A A

SPI_HOLD#_R

1 2

RC54 33_0402_5%@

1 2

RC55 33_0402_5%@

1 2

RC176 33_0402_5%@

1 2

RC178 33_0402_5%@

+3V_SPI

12

RC179

1K_0402_5%

@

5

SPI_CLK SPI_CLK_R
SPI_CS0#

SPI_SI_1
SPI_SI
SPI_SO
SPI_SO_1

+3VALW_PCH

+3VS

+3V_SPI

1. If support DS3, connect to +3VS and don't support EC mirror code;

2. If don't support DS3, connect to +3VALW_PCH and support EC mirror code.

*

1 2

RC173 33_0402_5%@

1 2

RC50 15_0402_5%

1 2

RC51 0_0402_5%

1 2

@

RC174 0_0402_5%@

1 2

RC175 33_0402_5%@

1 2

RC52 15_0402_5%

1 2

RC53 15_0402_5%

1 2

RC177 33_0402_5%@

1 2

RC171

0_0402_5%

1 2

RC172

@

0_0402_5%

4

+3V_SPI

HSW_ULT_DDR3L

LPC

UC3

1

CS#

2

DO

3

WP#

GND4DI

W25Q64FVSSIG_SO8

UC6

1

CS

2

DO(IO1)

HOLD/RST(IO3)

3

WP(IO2)

4

GND

W25Q32FVSSIG_SO8

AN2

SMBALERT/GPIO11

SMBCLK

SMBUS

SML1ALERT/PCHHOT/GPIO73

C-LINKSPI

8

VCC

7

HOLD#

6

CLK

5

@

8

VCC

7

6

CLK

5

DI(IO0)

Security Classification

Security Classification

Security Classification

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

SML0ALERT/GPIO60

SML1CLK/GPIO75

SML1DATA/GPIO74

7 OF 19

SPI_HOLD#

SPI_CLK

SPI_SI

SPI_HOLD#_1

SPI_CLK_1

SPI_SI_1

Issued Date

Issued Date

Issued Date

SMBDATA

SML0CLK

SML0DATA

CL_CLK

CL_DATA

CL_RST

+3V_SPI

AP2
AH1
AL2
AN1
AK1
AU4
AU3
AH3

AF2
AD2
AF4

1

CC8
.1U_0402_10V6-K

2

+3V_SPI

1

CC97
.1U_0402_10V6-K

@

2

SMB_ALERT#
PCH_SMB_CLK
PCH_SMB_DATA
SML0_ALERT#
SML0_CLK
SML0_DATA
SML1_ALERT#
PCH_SML1_CLK
PCH_SML1_DAT

2013/08/08

2013/08/08

2013/08/08

+3VALW_PCH +3VS +3VS

12

12

RC56

2.2K_0402_5%

PCH_SMB_CLK

PCH_SMB_DATA

+3VALW_PCH +3VS

12

12

RC62

2.2K_0402_5%

PCH_SML1_CLK

PCH_SML1_DAT

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

RC57

2.2K_0402_5%

QC2A

2N7002KDWH_SOT363-6

RC63

2.2K_0402_5%

QC3A

2N7002KDWH_SOT363-6

2

6 1

D

2

6 1

D

2013/08/05

2013/08/05

2013/08/05

G

S

5

3 4

QC2B

D

2N7002KDWH_SOT363-6

G

S

5

3 4

QC3B

D

2N7002KDWH_SOT363-6

DIMM1, DIMM2, NGFF

12

12

RC58

2.2K_0402_5%

G

S

RC59

2.2K_0402_5%

SMB_CLK_S3 {14,15,40}

SMB_DATA_S3 {14,15,40}

GPU, EC, Thermal Sensor

EC_SMB_CK2 {39,44}

G

S

EC_SMB_DA2 {39,44}

Title

Title

Title

MCP (RTC&AUDIO&SATA&SMBUS)

MCP (RTC&AUDIO&SATA&SMBUS)

MCP (RTC&AUDIO&SATA&SMBUS)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

C

C

C

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

1

7 59

7 59

7 59

of

of

of

1.0

1.0

1.0

5

4

3

2

1

+3VS

RPC3

1 8
2 7
3 6
4 5

10K_0804_8P4R_5%

D D

C C

B B

A A

+3VALW

+3VALW_PCH

RPC4

1 8
2 7
3 6
4 5

10K_0804_8P4R_5%

1 2

RC120 10K_0402_5%

1 2

RC74 10K_0402_5%

1 2

RC75 10K_0402_5%@

1 2

RC76 10K_0402_5%

1 2

RC78 10K_0402_5%

1 2

RC90 10K_0402_5%

CC104

1 2

1000P_0402_50V7K

CC103

1 2

1000P_0402_50V7K

CC101

1 2

1000P_0402_50V7K

1 2

RC91 10K_0402_5%

RPC21

1 8
2 7
3 6
4 5

10K_0804_8P4R_5%

12

12

1 2

12

5

@

@

@

RC92100K_0402_5%

RC94100K_0402_1% @

RC951K_0402_5% @

RC10510K_0402_5% @

PCIE_CLKREQ1#
PCIE_CLKREQ0#
PCIE_CLKREQ5#

LAN_CLKREQ#
WLAN_CLKREQ#
SYS_RESET#
PM_CLKRUN#

GPU_CLKREQ#

PCIE CLK2

PCIE CLK3

LAN

WLAN

PCIE CLK4 GPU

AC_PRESENT_R

PCH_GPIO72

WAKE#

SUSWARN#_R

PCH_GPIO72

SUSACK#{44}

SYS_PWROK{44}
PCH_PWROK{10,44}

PLT_RST#{37,40,44}

EC_RSMRST#{44}

SUSWARN#{44}

PBTN_OUT#{44}

PCH_PWROK

PCH_DPWROK_R

SYS_PWROK

PCH_PWROK
PCH_RSMRST#_R

PLT_RST#_R

PCH_DPWROK_R

SUSCLK

GPU_CLKREQ#

CLK_PCIE_LAN#{37}
CLK_PCIE_LAN{37}

LAN_CLKREQ#{37}

CLK_PCIE_WLAN#{40}
CLK_PCIE_WLAN{40}

WLAN_CLKREQ#{40}

Reserve for DS3

1 2

RC79 0_0402_5%@

1 2

RC139 0_0402_5%

1 2

RC126 0_0402_5%

@

1 2

RC83 0_0402_5%

@

1 2

@

RC84 0_0402_5%

@

1 2

RC85 0_0402_5%

1 2

@

RC86 0_0402_5%

1 2

RC87 0_0402_5%

@

AC_PRESENT{44}

UC1F

C43

CLKOUT_PCIE_N0

C42

CLKOUT_PCIE_P0

1 2

@

U2

PCIECLKRQ0/GPIO18

B41

CLKOUT_PCIE_N1

A41

CLKOUT_PCIE_P1

Y5

PCIECLKRQ1/GPIO19

C41

CLKOUT_PCIE_N2

B42

CLKOUT_PCIE_P2

AD1

PCIECLKRQ2/GPIO20

B38

CLKOUT_PCIE_N3

C37

CLKOUT_PCIE_P3

N1

PCIECLKRQ3/GPIO21

A39

CLKOUT_PCIE_N4

B39

CLKOUT_PCIE_P4

U5

PCIECLKRQ4/GPIO22

B37

CLKOUT_PCIE_N5

A37

CLKOUT_PCIE_P5

T2

PCIECLKRQ5/GPIO23

HASWELL-ULT-DDR3L_BGA1168

UC1H

AK2

SUSACK

AC3

SYS_RESET

AG2

SYS_PWROK

AY7

PCH_PWROK

AB5

APWROK

AG7

PLTRST

AW6

RSMRST

AV4

SUSWARN/SUSPWRDNACK/GPIO30

AL7

PWRBTN

AJ8

ACPRESENT/GPIO31

AN4

BATLOW/GPIO72

AF3

1

SLP_S0

1

AM5

SLP_WLAN/GPIO29

HASWELL-ULT-DDR3L_BGA1168

AC_PRESENT_R

13

D

2

G

S

@

QC8
2N7002KW_SOT323-3

PCIE_CLKREQ0#

PCIE_CLKREQ1#

CLK_PCIE_LAN#
CLK_PCIE_LAN
LAN_CLKREQ#

CLK_PCIE_WLAN#
CLK_PCIE_WLAN
WLAN_CLKREQ#

GPU_CLKREQ#

PCIE_CLKREQ5#

SUSACK#_R
SYS_RESET#
SYS_PWROK_R
PCH_PWROK_R
APWROK
PLT_RST#_R

PCH_RSMRST#_R
SUSWARN#_R
PBTN_OUT#_R PM_SLP_S4#_R
AC_PRESENT_R
PCH_GPIO72

TC38

PAD@

TC39

PAD@

RC88 0_0402_5%

ACIN#{44,53}

4

HSW_ULT_DDR3L

A25

XTAL24_IN

RSVD5
RSVD6

DSWVRMEN

DPWROK

WAKE

SLP_S4
SLP_S3

SLP_A
SLP_SUS
SLP_LAN

2013/08/08

2013/08/08

2013/08/08

B25

K21
M21
C26

C35
C34
AK8
AL8

AN15
AP15

B35
A35

AW7
AV5
AJ5

V5
AG4
AE6
AP5

AJ6
AT4
AL5
AP4
AJ7

XTAL24_OUT

DIFFCLK_BIASREF

CLOCK

SIGNALS

6 OF 19

HSW_ULT_DDR3L

SYSTEM POWER MANAGEMENT

8 OF 19

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

TESTLOW_C35
TESTLOW_C34
TESTLOW_AK8
TESTLOW_AL8

CLKOUT_LPC_0
CLKOUT_LPC_1

CLKOUT_ITPXDP

CLKOUT_ITPXDP_P

CLKRUN/GPIO32

SUS_STAT/GPIO61

SUSCLK/GPIO62

SLP_S5/GPIO63

XTAL24_IN
XTAL24_OUT

DIFFCLK_BIASREF

MCP_TESTLOW1
MCP_TESTLOW2
MCP_TESTLOW3
MCP_TESTLOW4

CLK_PCI_EC_R

DSWODVREN
PCH_DPWROK_R
WAKE#

PM_CLKRUN#
SUS_STAT#
SUSCLK
PM_SLP_S5#

PM_SLP_S3#_R

PM_SLP_SUS#_R

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

RC72 3.01K_0402_1%

RC73 22_0402_5%

RC182 0_0402_5%

RC81 0_0402_5%@

RC82 0_0402_5%

1

RC140 0_0402_5%
RC141 0_0402_5%

RC89 0_0402_5%@

1

TC40

PAD@

Deciphered Date

Deciphered Date

Deciphered Date

4.7P_0402_50V8-J

12

12

1 2

1 2
1 2

@

TC37@

1 2
1 2

@
@

1 2

Reserve for DS3

2

XTAL24_IN

CC12

+1.05VS_PLPTCLKPLL

2013/08/05

2013/08/05

2013/08/05

RC71 1M_0402_5%

1

12

DIFFCLK_BIASREF

Width: 12-15Mil
Space:12Mil
Length: 500Mil

CLK_PCI_EC {44}

EC_RSMRST#

Reserve for DS3

DPWROK_EC {44}
PCIE_WAKE# {9,37,40,44}

SUSCLK {40}
PM_SLP_S5# {44}

PM_SLP_S4# {44}
PM_SLP_S3# {44}

PM_SLP_SUS# {44}

12

YC2

GND12OSC2

OSC1

24MHZ_6PF_7V24000032

3

XTAL24_OUT

4

GND2

Title

Title

Title

MCP (Clock,PM)

MCP (Clock,PM)

MCP (Clock,PM)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

12

CC11

4.7P_0402_50V8-J

RPC5

VCCRTC

1

18
27
36
45

12

RC77
330K_0402_5%

12

RC80
330K_0402_5%

@

MCP_TESTLOW1
MCP_TESTLOW2
MCP_TESTLOW3
MCP_TESTLOW4

*

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

10K_0804_8P4R_5%

DSWODVREN

DSWODVREN - On Die DSW VR Enable
H Enable 　
L Disable

UMA

UMA

UMA

8 59

8 59

8 59

1.0

1.0

1.0

of

of

of

5

1 2

+3VALW

1 2

RC97 10K_0402_5%@

1 2

RC98 10K_0402_5%

1 2

RC99 10K_0402_5%

+3VALW_PCH

1 2

D D

C C

B B

A A

RC103 10K_0402_5%

+3VALW_PCH

10K_0804_8P4R_5%

10K_0804_8P4R_5%

10K_0804_8P4R_5%

10K_0804_8P4R_5%

+3VS

1 2

RC125 10K_0402_5%

10K_0804_8P4R_5%

10K_0804_8P4R_5%

10K_0804_8P4R_5%

10K_0804_8P4R_5%

10K_0804_8P4R_5%

10K_0804_8P4R_5%

10K_0804_8P4R_5%

+3VS

1 8
2 7
3 6
4 5

10K_0804_8P4R_5%

1 2

RC122 10K_0402_5%

RPC6

RPC7

RPC8

RPC9

RPC10

RPC11

RPC12

RPC13

RPC14

RPC15

RPC16

RPC18

18
27
36
45

18
27
36
45

18
27
36
45

18
27
36
45

18
27
36
45

18
27
36
45

18
27
36
45

18
27
36
45

18
27
36
45

18
27
36
45

18
27
36
45

PCH_GPIO12
DS3_WAKE#
PCH_GPIO25

ODD_EN

PCH_GPIO8

PCH_GPIO28
PCH_GPIO26

PCH_GPIO57
PCH_GPIO56
PCH_GPIO58
PCH_GPIO59

PCH_GPIO47
PCH_GPIO44
PCH_GPIO13
PCH_GPIO14

PCH_GPIO45
PCH_GPIO46
PCH_GPIO10
PCH_GPIO9

ODD_DA#

PCH_GPIO33
PCH_GPIO49
PCH_GPIO50
PCH_GPIO76

PCH_GPIO83
PCH_GPIO38
PCH_GPIO70
PCH_GPIO85

PCH_GPIO89
PCH_GPIO90
PCH_GPIO91
PCH_GPIO92

PCH_GPIO93
PCH_GPIO1
PCH_GPIO94
PCH_GPIO0

PCH_GPIO3
PCH_GPIO2
PCH_GPIO4
PCH_GPIO5

PCH_GPIO64
PCH_GPIO6
PCH_GPIO65
PCH_GPIO7

PCH_GPIO67
PCH_GPIO69
PCH_GPIO71

CMOS_ON#
PCH_WLAN_OFF#
PCH_BT_OFF#
KBRST#

SERIRQ

EC_LID_OUT#{44}

LAN PCIE3

WLAN

PCIE4

RC96

0_0402_5%

DC2

SDM10U45LP-7_DFN1006-2-2

ACLU2: delete VGA_PWRGD PORT

EC_SMI#{44}

ACLU2: delete CC14 CC15 CC16 CC17 CC18 CC19
CC20 CC21 and PCIE net of GPU

PCIE_PRX_DTX_N3{37}
PCIE_PRX_DTX_P3{37}

PCIE_PTX_C_DRX_N3{37}
PCIE_PTX_C_DRX_P3{37}

PCIE_PRX_DTX_N4{40}
PCIE_PRX_DTX_P4{40}

PCIE_PTX_C_DRX_N4{40}
PCIE_PTX_C_DRX_P4{40}

PCH_GPIO14

21

@

ODD_DA#{42}

ODD_EN{42}

PCIE_WAKE#{8,37,40,44}

EC_SMI#

PCH_BEEP{43}

+1.05VS_PUSB3PLL

RC119 3.01K_0402_1%

PCIE_RCOMP&PCIE_IREF

Width 12~15Mil
Space >12Mil
Length 500Mil

4

1 2

RC110

@

0_0402_5%

1 2

RC111 0_0402_5%

@

1 2

CC22 .1U_0402_10V6-K

1 2

CC23 .1U_0402_10V6-K

1 2

CC24 .1U_0402_10V6-K

1 2

CC25 .1U_0402_10V6-K

12

PCH_GPIO76
PCH_GPIO8
PCH_GPIO12
PCH_GPIO15
BOARD_ID0
ODD_DA#
ODD_EN
DS3_WAKE#
PCH_GPIO28
PCH_GPIO26

PCH_GPIO56
PCH_GPIO57
PCH_GPIO58
PCH_GPIO59
PCH_GPIO44
PCH_GPIO47
VGA_PWRGD
PCH_GPIO49
PCH_GPIO50
PCH_GPIO71
PCH_GPIO13
PCH_GPIO14
PCH_GPIO25
PCH_GPIO45
PCH_GPIO46

PCH_GPIO9
PCH_GPIO10
PCH_GPIO33
PCH_GPIO70
PCH_GPIO38
BOARD_ID2
PCH_BEEP

PCIE_PRX_DTX_N3
PCIE_PRX_DTX_P3

PCIE_PTX_DRX_N3
PCIE_PTX_DRX_P3

PCIE_PRX_DTX_N4
PCIE_PRX_DTX_P4

PCIE_PTX_DRX_N4
PCIE_PTX_DRX_P4

PCIE_RCOMP

UC1J

P1

BMBUSY/GPIO76

AU2

GPIO8

AM7

LAN_PHY_PWR_CTRL/GPIO12

AD6

GPIO15

Y1

GPIO16

T3

GPIO17

AD5

GPIO24

AN5

GPIO27

AD7

GPIO28

AN3

GPIO26

AG6

GPIO56

AP1

GPIO57

AL4

GPIO58

AT5

GPIO59

AK4

GPIO44

AB6

GPIO47

U4

GPIO48

Y3

GPIO49

P3

GPIO50

Y2

HSIOPC/GPIO71

AT3

GPIO13

AH4

GPIO14

AM4

GPIO25

AG5

GPIO45

AG3

GPIO46

AM3

GPIO9

AM2

GPIO10

P2

DEVSLP0/GPIO33

C4

SDIO_POWER_EN/GPIO70

L2

DEVSLP1/GPIO38

N5

DEVSLP2/GPIO39

V2

SPKR/GPIO81

HASWELL-ULT-DDR3L_BGA1168

UC1K

F10

PERN5_L0

E10

PERP5_L0

C23

PETN5_L0

C22

PETP5_L0

F8

PERN5_L1

E8

PERP5_L1

B23

PETN5_L1

A23

PETP5_L1

H10

PERN5_L2

G10

PERP5_L2

B21

PETN5_L2

C21

PETP5_L2

E6

PERN5_L3

F6

PERP5_L3

B22

PETN5_L3

A21

PETP5_L3

G11

PERN3

F11

PERP3

C29

PETN3

B30

PETP3

F13

PERN4

G13

PERP4

B29

PETN4

A29

PETP4

G17

PERN1/USB3RN3

F17

PERP1/USB3RP3

C30

PETN1/USB3TN3

C31

PETP1/USB3TP3

F15

PERN2/USB3RN4

G15

PERP2/USB3RP4

B31

PETN2/USB3TN4

A31

PETP2/USB3TP4

E15

RSVD9

E13

RSVD10

A27

PCIE_RCOMP

B27

PCIE_IREF

HASWELL-ULT-DDR3L_BGA1168

HSW_ULT_DDR3L

GPIO

10 OF 19

HSW_ULT_DDR3L

PCIE USB

11 OF 19

CPU/
MISC

SERIAL IO

3

THRMTRIP

RCIN/GPIO82

SERIRQ

PCH_OPI_RCOMP

RSVD7
RSVD8

GSPI0_CS/GPIO83

GSPI0_CLK/GPIO84
GSPI0_MISO/GPIO85
GSPI0_MOSI/GPIO86

GSPI1_CS/GPIO87

GSPI1_CLK/GPIO88
GSPI1_MISO/GPIO89

GSPI_MOSI/GPIO90
UART0_RXD/GPIO91
UART0_TXD/GPIO92
UART0_RTS/GPIO93
UART0_CTS/GPIO94

UART1_RXD/GPIO0
UART1_TXD/GPIO1
UART1_RST/GPIO2
UART1_CTS/GPIO3

I2C0_SDA/GPIO4
I2C0_SCL/GPIO5
I2C1_SDA/GPIO6
I2C1_SCL/GPIO7

SDIO_CLK/GPIO64

SDIO_CMD/GPIO65

SDIO_D0/GPIO66
SDIO_D1/GPIO67
SDIO_D2/GPIO68
SDIO_D3/GPIO69

USB2N0
USB2P0

USB2N1
USB2P1

USB2N2
USB2P2

USB2N3
USB2P3

USB2N4
USB2P4

USB2N5
USB2P5

USB2N6
USB2P6

USB2N7
USB2P7

USB3RN1
USB3RP1

USB3TN1
USB3TP1

USB3RN2
USB3RP2

USB3TN2
USB3TP2

USBRBIAS
USBRBIAS

RSVD11
RSVD12

OC0/GPIO40
OC1/GPIO41
OC2/GPIO42
OC3/GPIO43

D60
V4
T4
AW15
AF20
AB21

R6
L6
N6
L8
R7
L5
N7
K2
J1
K3
J2
G1
K4
G2
J3
J4
F2
F3
G4
F1
E3
F4
D3
E4
C3
E2

AN8
AM8

AR7
AT7

AR8
AP8

AR10
AT10

AM15
AL15

AM13
AN13

AP11
AN11

AR13
AP13

G20
H20

C33
B34

E18
F18

B33
A33

AJ10
AJ11
AN10
AM10

AL3
AT1
AH2
AV3

@

H_THRMTRIP#_R
KBRST#
SERIRQ
OPI_COMP

PCH_GPIO83
BOARD_ID1
PCH_GPIO85
PCH_GPIO86
PCH_BT_OFF#
PCH_WLAN_OFF#
PCH_GPIO89
PCH_GPIO90
PCH_GPIO91
PCH_GPIO92
PCH_GPIO93
PCH_GPIO94
PCH_GPIO0
PCH_GPIO1
PCH_GPIO2
PCH_GPIO3
PCH_GPIO4
PCH_GPIO5
PCH_GPIO6
PCH_GPIO7
PCH_GPIO64
PCH_GPIO65
PCH_GPIO66
PCH_GPIO67
CMOS_ON#
PCH_GPIO69

USB20_N0
USB20_P0

USB20_N1
USB20_P1

USB20_N2
USB20_P2

USB20_N3
USB20_P3

USB20_N4
USB20_P4

USB20_N5
USB20_P5

USB20_N6
USB20_P6

USB30_RX_N1
USB30_RX_P1

USB30_TX_N1
USB30_TX_P1

USBRBIAS

USB_OC0#
USB_OC1#
USB_OC2#
USB_OC3#

H_THRMTRIP#_R

.01U_0402_16V7-K

1

CC102

2

For EMI

1 2

RC124 0_0402_5%

@

12

RC106 49.9_0402_1%

1

@

TC41

1 2

RC112 0_0402_5%

@

USB20_N0 {45}
USB20_P0 {45}

USB20_N1 {41}
USB20_P1 {41}

USB20_N2 {41}
USB20_P2 {41}

USB20_N3 {45}
USB20_P3 {45}

USB20_N4 {33}
USB20_P4 {33}

USB20_N5 {33}
USB20_P5 {33}

USB20_N6 {40}
USB20_P6 {40}

USB30_RX_N1 {41}

USB30_RX_P1 {41}

USB30_TX_N1 {41}
USB30_TX_P1 {41}

22.6_0402_1%

USB_OC1# {41}
USB_OC2# {45}

12

RC118

2

+1.05V_VCCST

RC104
1K_0402_5%

ACLU2: delete H_THRMTRIP# port for GPU

1 2

KBRST# {44}

SERIRQ {44}

OPI_RCOMP

Width 20Mil
Space 15Mil
Length 500Mil

PCH_BT_OFF# {40}
PCH_WLAN_OFF# {40}

EC_SCI# {44}

CMOS_ON# {33}

RIGHT USB (2.0)

LEFT USB (3.0)

LEFT USB (2.0)

Card reader

Touch panel

Camera

BT

LEFT USB (3.0)

USBRBIAS

Width 20Mil
Space 15Mil
Length 500Mil

1

+3VS

RC102
10K_0402_5%

@

RC109
10K_0402_5%

Description

RC121
10K_0402_5%

@

1 2

RC123
10K_0402_5%

1 2

RC101

RC100

10K_0402_5%

10K_0402_5%

15@

@

1 2

RC108
10K_0402_5%

14@

1 2

18
27
36
45

1 2

1 2

UMA sku 14"

+3VALW_PCH

+3VS

+3VS

+3VS

+3VALW_PCH

PCH_GPIO15

PCH_GPIO66

PCH_GPIO86

PCH_BEEP

USB_OC0#
USB_OC1#
USB_OC3#
USB_OC2#

1 2

RC107
10K_0402_5%

1 2

BOARD_ID2 BOARD_ID3

BOARD_ID1

reserve reserve1reserve UMA sku 15"

1 2

RC114 1K_0402_5%@

1 2

RC113 1K_0402_5%@

RC115 1K_0402_5%@

RC116 1K_0402_5%@

RC117 1K_0402_5%@

10K_0804_8P4R_5%

12

12

12

reservereserve

RPC17

BOARD_ID0
BOARD_ID1
BOARD_ID2

BOARD_ID3{4}

BOARD_ID3

BOARD_ID0

reserve 0

GPIO15, Internal PD

1: INTEL ME TLS W/ Confidentiality
*0: INTEL ME TLS W/O Confidentiality

GPIO66, Internal 20K PD

1: Enable Top Swap Mode
*0: Disable Top Swap Mode(default)

GPIO86, Internal PD

1: LPC
*0: SPI

GPIO81, No Reboot, Internal PD

1: Enabled No Reboot Mode
*0: Disable No Reboot Mode

1 2

RC181 10K_0402_5%UMA@

VGA_PWRGD

5

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

4

3

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

MCP (GPIO,USB,PCIE)

MCP (GPIO,USB,PCIE)

MCP (GPIO,USB,PCIE)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

Tuesday, February 11, 2014

Tuesday, February 11, 2014

Tuesday, February 11, 2014

1

of

of

of

9 59

9 59

9 59

1.0

1.0

1.0

5

4

3

2

1

VCC8

VCC9
VCC10
VCC11
VCC12
VCC13
VCC14
VCC15
VCC16
VCC17
VCC18
VCC19
VCC20
VCC21
VCC22
VCC23
VCC24
VCC25
VCC26
VCC27
VCC28
VCC29
VCC30
VCC31
VCC32
VCC33
VCC34
VCC35
VCC36
VCC37
VCC38
VCC39
VCC40
VCC41
VCC42
VCC43
VCC44
VCC45
VCC46
VCC47
VCC48
VCC49
VCC50
VCC51
VCC52
VCC53
VCC54
VCC55
VCC56
VCC57
VCC58
VCC59
VCC60
VCC61
VCC62
VCC63
VCC64
VCC65
VCC66
VCC67
VCC68

C36
C40
C44
C48
C52
C56
E23
E25
E27
E29
E31
E33
E35
E37
E39
E41
E43
E45
E47
E49
E51
E53
E55
E57
F24
F28
F32
F36
F40
F44
F48
F52
F56
G23
G25
G27
G29
G31
G33
G35
G37
G39
G41
G43
G45
G47
G49
G51
G53
G55
G57
H23
J23
K23
K57
L22
M23
M57
P57
U57
W57

CPU_CORE

+1.35V

Need short

JC1

112

JUMP_43X79

D D

VCC_SENSE

Length Match: <25Mil
Space: More Than 25Mil

+VCCIO_OUT

1

CC36

4.7U_0603_10V6-K

C C

SVID

1, Stripline Line, No More Than 6000Mil
2, Alert# Route Between CLK and Data
3, CLK Length<Data Length<CLK Length + 2000Mil
4, Space at least 18Mil

2

@

GND Reference

CPU_VCC_SENSE{59}

+1.05VS

+1.05VS

LC1

RC128 0_0402_5%

RC129 150_0402_1%@

1 2

UPB100505T-121Y-N

+1.05VS

1 2

@

CC39

22U_0805_6.3V6M

CPU_CORE

12

+1.05V_VCCST

@

RC127
100_0402_1%

1 2

CPU_VR_ON{59}

1

2

+1.35V_CPU

2

+VCCIOA_OUT

RC130

VCCST(0.1A)

1

CC40
1U_0402_10V6K

2

CPU_CORE

10K_0402_5%

CPU_SVID_ALERT#_R
CPU_SVID_CLK_R
CPU_SVID_DAT_R
VCCST_PWRGD
CPU_VR_ON
CPU_VR_READY

PWR_DEBUG

12

CPU_CORE

For RF

TC45@
TC46@

TC47@
TC48@

TC50@
TC51@
TC52@

TC53@
TC54@
TC55@

TC56@
TC57@
TC58@
TC59@
TC60@
TC61@
TC62@
TC63@
TC64@

CC2

1

2

@

33P_0402_50V8J

1

J58

1

AH26

AJ31
AJ33

AJ37
AN33
AP43
AR48
AY35
AY40
AY44
AY50

F59
N58

1

AC58

1

E63

AB23

A59
E20

AD23

1

AA23

1

AE59

1

L62
N63
L63
B59
F60
C59

D63
H59
P62
P60

1

P61

1

N59

1

N61
T59

1

AD60

1

AD59

1

AA59

1

AE60

1

AC59

1

AG58

1

U59

1

V59

1

AC22
AE22
AE23

AB57
AD57
AG57

C24
C28
C32

RSVD13
RSVD14

VDDQ1
VDDQ2
VDDQ3
VDDQ4
VDDQ5
VDDQ6
VDDQ7
VDDQ8
VDDQ9
VDDQ10
VDDQ11

VCC1
RSVD15
RSVD16

VCC_SENSE
RSVD17
VCCIO_OUT
VCCIOA_OUT
RSVD18
RSVD19
RSVD20

VIDALERT
VIDSCLK
VIDSOUT
VCCST_PWRGD
VR_EN
VR_READY

VSS344
PWR_DEBUG
VSS345
RSVD_TP1
RSVD_TP2
RSVD_TP3
RSVD_TP4
RSVD21
RSVD22
RSVD23
RSVD24
RSVD25
RSVD26
RSVD27
RSVD28
RSVD29

VCCST1
VCCST2
VCCST3

VCC2
VCC3
VCC4
VCC5
VCC6
VCC7

HASWELL-ULT-DDR3L_BGA1168

UC1L

L59

HSW_ULT_DDR3L

HSW ULT POWER

12 OF 19

+1.35V_CPU

2.2U_0603_10V6-K

CC26

1

2

CD@

For cost down, change to X5R.

10U_0603_6.3V6M

10U_0603_6.3V6M

CC34

1

2

1.35V_CPU(1.4A)

HW 4PCS 2.2UF CAP Mounted
HW 6PCS 10UF CAP Mounted
PWR 2PCS 470U Near VR Output

+1.35V_CPU

CC37

33P_0402_50V8J

1

2

@

CC30

1

2

CD@

CC38

33P_0402_50V8J

1

2
@

For RF

1

2

2.2U_0603_10V6-K

CC27

10U_0603_6.3V6M

1

2

2.2U_0603_10V6-K

2.2U_0603_10V6-K

CC28

10U_0603_6.3V6M

CC31

1

2

1

2

CC29

10U_0603_6.3V6M

CC32

1

2

10U_0603_6.3V6M

CC33

1

2

330U_2.5V_M

1

CC41

+

2

@

1

2

CC35

RC131
75_0402_1%

1 2

CPU_SVID_ALERT#{59}

CPU_SVID_CLK{59}

B B

CPU_SVID_DAT{59}

PCH_PWROK{8,44}

A A

RC133 43_0402_5%

1 2

RC138 0_0402_5%

5

RC134 0_0402_5%

RC135 0_0402_5%

@

1 2

@

1 2

@

12

1

CC46

0.01U_0402_16V7K

@

2

12

2

G

RC132
130_0402_1%

CPU_SVID_ALERT#_R

CPU_SVID_CLK_R

CPU_SVID_DAT_R

+3VALW

RC136
10K_0402_5%

1 2

61

D

QC6A

2N7002KDWH_SOT363-6

S

12

CC42
.1U_0402_10V6-K

@

4

5

G

+1.05V_VCCST

RC137
1K_0402_5%

1 2

VCCST_PWRGD

34

D

QC6B

2N7002KDWH_SOT363-6

S

2

CC140
1000P_0402_50V7K

1

@

VR_CPU_PWROK{44,59}

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

1 2

RC148 0_0402_5%

@

LC Future Center Secret Data

LC Future Center Secret Data

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

1

CC49

0.01U_0402_16V7K

@

2

Deciphered Date

Deciphered Date

Deciphered Date

2

G

+3VALW

RC144
10K_0402_5%

1 2

61

D

2N7002KDWH_SOT363-6
QC7A

S

2013/08/05

2013/08/05

2013/08/05

2

+1.05V_VCCST

RC145
10K_0402_5%

@

1 2

1 2

RC147 0_0402_5%

34

D

5

2N7002KDWH_SOT363-6

G

QC7B

S

Title

Title

Title

MCP (Power)

MCP (Power)

MCP (Power)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Wednesday, March 19, 2014

Wednesday, March 19, 2014

Wednesday, March 19, 2014

Date: Sheet

Date: Sheet

Date: Sheet

CPU_VR_ON

RC146
10K_0402_5%

1 2

UMA

UMA

UMA

CPU_VR_READY

1

1

CC141
100P_0402_50V8J

2

10 59

10 59

10 59

@

@

1.0

1.0

1.0

of

of

of

5

+1.05VS_VCCHSIO

1U_0402_10V6K

1U_0402_10V6K

CC51

CC53

1

1

D D

VCCHDA

C C

+3VL

RC149

+3VALW

RC150

1U_0402_10V6K

CC62

1

2

0_0402_5%

0_0402_5%

@

VCCHDA 11mA

+3VALW_PCH

22U_0805_6.3V6M

CC67

1

2

12

12

2

2

VCCSUS3_3[1:5] 65mA

VCCDSW3_3

VCCDSW3_3

1U_0402_10V6K

CC70

1

@

2

VCCDSW 114mA

+3VS

+1.05VS

1U_0402_10V6K

CC54

1

2

22U_0805_6.3V6M

CC71

1

2

VCCHSIO 1.838A

VCC1_05[1:9] 1.741A

VCC3_3[1:4] 41mA

+1.05VS

1

2

+1.05VS_PUSB3PLL

+1.05VS_PSATA3PLL

+1.05VS_POPIPLL

1 2

CC591U_0402_10V6K@

1 2

CC601U_0402_10V6K@

+1.05VS_PLPTCLKPLL

1U_0402_10V6K

1U_0402_10V6K

CC76

CC75

1

2

+3VALW_PCH

CD@

4

+1.05VS_DCPSUS3

+1.05VS_PLPTVCC1P05

TC66 @
TC67 @

1
1

UC1M

K9

VCCHSIO[1]

L10

VCCHSIO[2]

M9

VCCHSIO[3]

N8

VCC1_05[1]

P9

VCC1_05[2]

B18

VCCUSB3PLL

B11

VCCSATA3PLL

Y20

RSVD30

AA21

VCCAPLL[1]

W21

VCCAPLL[2]

J13

DCPSUS3

AH14

VCCHDA

AH13

DCPSUS2

AC9

VCCSUS3_3[1]

AA9

VCCSUS3_3[2]

AH10

VCCDSW3_3

V8

VCC3_3[1]

W9

VCC3_3[2]

J18

VCCCLK[1]

K19

VCCCLK[2]

A20

VCCACLKPLL

J17

VCCCLK[3]

R21

VCCCLK[4]

T21

VCCCLK[5]

K18

RSVD31

M20

RSVD32

V21

RSVD33

AE20

VCCSUS3_3[3]

AE21

VCCSUS3_3[4]

HASWELL-ULT-DDR3L_BGA1168

HSIO

USB3

HDA

VRM

GPIO/LPC

LPT LP POWER

HSW_ULT_DDR3L

OPI

13 OF 19

3

RTC

SPI

CORE

THERMAL SENSOR

SERIAL IO

SUS OSCILLATOR

USB2

VCCSUS3_3[5]

VCCRTC
DCPRTC

VCCSPI

VCCASW[1]
VCCASW[2]

VCC1_05[3]
VCC1_05[4]
VCC1_05[5]
VCC1_05[6]

VCC1_05[7]
DCPSUSBYP[1]
DCPSUSBYP[2]

VCCASW[3]

VCCASW[4]

VCCASW[5]

DCPSUS1[1]
DCPSUS1[2]

VCCTS1_5

VCC3_3[3]
VCC3_3[4]

VCCSDIO[1]

VCCSDIO[2]

DCPSUS4

RSVD34
VCC1_05[8]
VCC1_05[9]

+3VALW_PCH

2

CC50
1U_0402_10V6K

1

AH11
AG10
AE7

+DCPRTC

VCCSPI 18mA

Y8

+1.05VS
AG14
AG13

VCCASW[1:5] 658mA

J11
H11
H15
AE8
AF22
AG19

+PCH_DCPSUSBYP+1.05VS_DCPSUS2

AG20
AE9
AF9
AG8
AD10

+1.05VS_DCPSUS1

AD8

VCCTS1_5 3mA

J15
K14
K16

VCCSDIO 17mA

U8
T9

AB8

+1.05VS_DCPSUS4

AC20
AG16
AG17

+1.05VS

2

1

VCCSPI

+1.5VS

1U_0402_10V6K

CC77

CC52

0.1U_0402_10V7K

CC58

2

@

1

CC61

CC66

CC73

2

VCCRTC 1mA

12

0.1U_0402_10V7K

1U_0402_10V6K

12

12

1U_0402_10V6K

1U_0402_10V6K

12

1

VCCRTC

CC57

CC56

CC55

0.1U_0402_10V7K

0.1U_0402_10V7K
1U_0402_10V6K

2

2

2

1

1

1

+1.05VS

CC69

CC68

+3VS

2

1

2

1

0.1U_0402_10V7K

CC72

1U_0402_10V6K

1

2
@

@

+3VS

1U_0402_10V6K

CC74

2

@

1

CC63

1U_0402_10V6K

2

1

22U_0805_6.3V6M

CD@

+1.05VS

CC64

1U_0402_10V6K

2

2

1

1

CC65

10U_0603_6.3V6M

+3VALW_PCH +1.05VS_PLPTVCC1P05

12

RC151

@

+3VS

+3V_SPI

B B

VCCDSW3_3 +PCH_DCPSUSBYP

For Intel recommend, place one 0.47uF
capacitor to address temporary inrush
current.(DOC.489999)

0_0402_5%

1 2

RC152 0_0402_5%

@

+3VS

RC153

@

0_0402_5%

1 2

RC154 0_0402_5%

@

1 2

CC90 0.47U_0402_25V6K

VCCHDA

12

VCCSPI

+1.05VS

Needshort

JC2

@

112

JUMP_43X79

+1.05VS+1.05VS_VCCHSIO

1 2

LC3

2.2UH_CIG10W2R2MNC_20%

+1.05VS_PLPTCLKPLL 31mA

1 2

LC5

2.2UH_CIG10W2R2MNC_20%

LC6

1 2

1

CC91
33P_0402_50V8J

@

2

+1.05VS_PLPTVCC1P05 185mA

1

CC81
22U_0805_6.3V6M

2

1

CC88
22U_0805_6.3V6M

2

@

+1.05VS_POPIPLL 57mA

0_0603_5%

1

CC92
47U_0805_4V6-M

2

@

1

CC100
22U_0805_6.3V6M

2

1

CC95
22U_0805_6.3V6M

2

1

CC93
47U_0805_4V6-M

2

@

1

CC82
22U_0805_6.3V6M

2

1

CC98
22U_0805_6.3V6M

2

+1.05VS_POPIPLL

1

2

CC94
1U_0402_10V6K

1

CC83
22U_0805_6.3V6M

2

1

CC99
22U_0805_6.3V6M

2

1

CC84
1U_0402_10V6K

2

+1.05VS_PLPTCLKPLL

1

CC89
1U_0402_10V6K

2

1

CC79
22U_0805_6.3V6M

2

1

CC86
22U_0805_6.3V6M

2

+1.05VS_PUSB3PLL

1

CC80
1U_0402_10V6K

2

+1.05VS_PSATA3PLL

1

CC87
1U_0402_10V6K

2

2

1 2

LC2

2.2UH_CIG10W2R2MNC_20%

1 2

LC4

2.2UH_CIG10W2R2MNC_20%

+1.05VS_PUSB3PLL 41mA

1

CC78
22U_0805_6.3V6M

2

+1.05VS_PSATA3PLL 42mA

1

CC85
22U_0805_6.3V6M

2

For RF

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

MCP (Power2)

MCP (Power2)

MCP (Power2)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

11 59

11 59

11 59

of

of

1

of

1.0

1.0

1.0

5

4

3

2

1

A11

VSS1

A14

VSS2

D D

C C

B B

A18

VSS3

A24

VSS4

A28

VSS5

A32

VSS6

A36

VSS7

A40

VSS8

A44

VSS9

A48

VSS10

A52

VSS11

A56

VSS12

AA1

VSS13

AA58

VSS14

AB10

VSS15

AB20

VSS16

AB22

VSS17

AB7

VSS18

AC61

VSS19

AD21

VSS20

AD3

VSS21

AD63

VSS22

AE10

VSS23

AE5

VSS24

AE58

VSS25

AF11

VSS26

AF12

VSS27

AF14

VSS28

AF15

VSS29

AF17

VSS30

AF18

VSS31

AG1

VSS32

AG11

VSS33

AG21

VSS34

AG23

VSS35

AG60

VSS36

AG61

VSS37

AG62

VSS38

AG63

VSS39

AH17

VSS40

AH19

VSS41

AH20

VSS42

AH22

VSS43

AH24

VSS44

AH28

VSS45

AH30

VSS46

AH32

VSS47

AH34

VSS48

AH36

VSS49

AH38

VSS50

AH40

VSS51

AH42

VSS52

AH44

VSS53

AH49

VSS54

AH51

VSS55

AH53

VSS56

AH55

VSS57

AH57

VSS58

AJ13

VSS59

AJ14

VSS60

AJ23

VSS61

AJ25

VSS62

AJ27

VSS63

AJ29

VSS64

HASWELL-ULT-DDR3L_BGA1168

14 OF 19

VSS65
VSS66
VSS67
VSS68
VSS69
VSS70
VSS71
VSS72
VSS73
VSS74
VSS75
VSS76
VSS77
VSS78
VSS79
VSS80
VSS81
VSS82
VSS83
VSS84
VSS85
VSS86
VSS87
VSS88
VSS89
VSS90
VSS91
VSS92
VSS93
VSS94
VSS95
VSS96
VSS97
VSS98

VSS99
VSS100
VSS101
VSS102
VSS103
VSS104
VSS105
VSS106
VSS107
VSS108
VSS109
VSS110
VSS111
VSS112
VSS113
VSS114
VSS115
VSS116
VSS117
VSS118
VSS119
VSS120
VSS121
VSS122
VSS123
VSS124
VSS125
VSS126
VSS127
VSS128

AJ35
AJ39
AJ41
AJ43
AJ45
AJ47
AJ50
AJ52
AJ54
AJ56
AJ58
AJ60
AJ63
AK23
AK3
AK52
AL10
AL13
AL17
AL20
AL22
AL23
AL26
AL29
AL31
AL33
AL36
AL39
AL40
AL45
AL46
AL51
AL52
AL54
AL57
AL60
AL61
AM1
AM17
AM23
AM31
AM52
AN17
AN23
AN31
AN32
AN35
AN36
AN39
AN40
AN42
AN43
AN45
AN46
AN48
AN49
AN51
AN52
AN60
AN63
AN7
AP10
AP17
AP20

AP22
AP23
AP26
AP29

AP31
AP38
AP39
AP48
AP52
AP54
AP57
AR11
AR15
AR17
AR23
AR31
AR33
AR39
AR43
AR49

AR5
AR52
AT13
AT35
AT37
AT40
AT42
AT43
AT46
AT49
AT61
AT62
AT63

AU1
AU16
AU18
AU20
AU22
AU24
AU26
AU28
AU30
AU33
AU51
AU53
AU55
AU57
AU59
AV14
AV16
AV20
AV24
AV28
AV33
AV34
AV36
AV39
AV41
AV43
AV46
AV49
AV51
AV55

AP3

HSW_ULT_DDR3L

UC1N

HSW_ULT_DDR3L

UC1O

VSS129
VSS130
VSS131
VSS132
VSS133
VSS134
VSS135
VSS136
VSS137
VSS138
VSS139
VSS140
VSS141
VSS142
VSS143
VSS144
VSS145
VSS146
VSS147
VSS148
VSS149
VSS150
VSS151
VSS152
VSS153
VSS154
VSS155
VSS156
VSS157
VSS158
VSS159
VSS160
VSS161
VSS162
VSS163
VSS164
VSS165
VSS166
VSS167
VSS168
VSS169
VSS170
VSS171
VSS172
VSS173
VSS174
VSS175
VSS176
VSS177
VSS178
VSS179
VSS180
VSS181
VSS182
VSS183
VSS184
VSS185
VSS186
VSS187
VSS188
VSS189
VSS190
VSS191
VSS192

HASWELL-ULT-DDR3L_BGA1168

15 OF 19

VSS193
VSS194
VSS195
VSS196
VSS197
VSS198
VSS199
VSS200
VSS201
VSS202
VSS203
VSS204
VSS205
VSS206
VSS207
VSS208
VSS209
VSS210
VSS211
VSS212
VSS213
VSS214
VSS215
VSS216
VSS217
VSS218
VSS219
VSS220
VSS221
VSS222
VSS223
VSS224
VSS225
VSS226
VSS227
VSS228
VSS229
VSS230
VSS231
VSS232
VSS233
VSS234
VSS235
VSS236
VSS237
VSS238
VSS239
VSS240
VSS241
VSS242
VSS243
VSS244
VSS245
VSS246
VSS247
VSS248
VSS249
VSS250
VSS251
VSS252
VSS253
VSS254
VSS255
VSS256

AV59
AV8
AW16
AW24
AW33
AW35
AW37
AW4
AW40
AW42
AW44
AW47
AW50
AW51
AW59
AW60
AY11
AY16
AY18
AY22
AY24
AY26
AY30
AY33
AY4
AY51
AY53
AY57
AY59
AY6
B20
B24
B26
B28
B32
B36
B4
B40
B44
B48
B52
B56
B60
C11
C14
C18
C20
C25
C27
C38
C39
C57
D12
D14
D18
D2
D21
D23
D25
D26
D27
D29
D30
D31

UC1P

D33

VSS257

D34

VSS258

D35

VSS259

D37

VSS260

D38

VSS261

D39

VSS262

D41

VSS263

D42

VSS264

D43

VSS265

D45

VSS266

D46

VSS267

D47

VSS268

D49

VSS269

D5

VSS270

D50

VSS271

D51

VSS272

D53

VSS273

D54

VSS274

D55

VSS275

D57

VSS276

D59

VSS277

D62

VSS278

D8

VSS279

E11

VSS280

E17

VSS281

F20

VSS282

F26

VSS283

F30

VSS284

F34

VSS285

F38

VSS286

F42

VSS287

F46

VSS288

F50

VSS289

F54

VSS290

F58

VSS291

F61

VSS292

G18

VSS293

G22

VSS294

G3

VSS295

G5

VSS296

G6

VSS297

G8

VSS298

H13

VSS299

HASWELL-ULT-DDR3L_BGA1168

HSW_ULT_DDR3L

16 OF 19

VSS300
VSS301
VSS302
VSS303
VSS304
VSS305
VSS306
VSS307
VSS308
VSS309
VSS310
VSS311
VSS312
VSS313
VSS314
VSS315
VSS316
VSS317
VSS318
VSS319
VSS320
VSS321
VSS322
VSS323
VSS324
VSS325
VSS326
VSS327
VSS328
VSS329
VSS330
VSS331
VSS332
VSS333
VSS334
VSS335
VSS336
VSS337

VSS338
VSS339
VSS340

VSS_SENSE

VSS341

H17
H57
J10
J22
J59
J63
K1
K12
L13
L15
L17
L18
L20
L58
L61
L7
M22
N10
N3
P59
P63
R10
R22
R8
T1
T58
U20
U22
U61
U9
V10
V3
V7
W20
W22
Y10
Y59
Y63

V58
AH46
V23
E62
AH16

1 2

RC158 0_0402_5%

RC159
100_0402_1%

1 2

@

CPU_VSS_SENSE {59}

VSS_SENSE

Length Match: No More Than 25Mil
Space: More Than 25Mil
GND Reference

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

MCP (VSS)

MCP (VSS)

MCP (VSS)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

12 59

12 59

1

12 59

1.0

1.0

1.0

5

4

3

2

1

UC1Q

DC_TEST_AY2_AW2
DC_TEST_AY3_AW3

1

TC78 @
TC82 @
TC84 @

TC88 @

TC96 @
TC98 @
TC99 @
TC100 @
TC102 @
TC104 @
TC106 @
TC108 @
TC109 @
TC111 @
TC113 @
TC114 @
TC116 @
TC117 @
TC119 @
TC120 @

TC123 @
TC124 @
TC125 @
TC127 @

TC129 @

TC135 @

TP_DC_TEST_AY60
DC_TEST_AY61_AW61
DC_TEST_AY62_AW62

1

TP_DC_TEST_B2
DC_TEST_A3_B3
DC_TEST_A61_B61
DC_TEST_B62_B63

DC_TEST_C1_C2

1
1
1

1

1

CFG0

1

CFG1

1

CFG2

1

CFG3

1

CFG4

1

CFG5

1

CFG6

1

CFG7

1

CFG8

1

CFG9

1

CFG10

1

CFG11

1

CFG12

1

CFG13

1

CFG14

1

CFG15

1

CFG16

1

CFG18

1

CFG17

1

CFG19

CFG_RCOMP

1

1

TD_IREF

D D

C C

B B

RC163 49.9_0402_1%

TC70 @

TC73 @

12

CFG_RCOMP&TD_IREF

Width 20Mil
Space 15Mil
Length 500Mil

RC166 8.2K_0402_1%

12

AY2

DAISY_CHAIN_NCTF_AY2

AY3

DAISY_CHAIN_NCTF_AY3

AY60

DAISY_CHAIN_NCTF_AY60

AY61

DAISY_CHAIN_NCTF_AY61

AY62

DAISY_CHAIN_NCTF_AY62

B2

DAISY_CHAIN_NCTF_B2

B3

DAISY_CHAIN_NCTF_B3

B61

DAISY_CHAIN_NCTF_B61

B62

DAISY_CHAIN_NCTF_B62

B63

DAISY_CHAIN_NCTF_B63

C1

DAISY_CHAIN_NCTF_C1

C2

DAISY_CHAIN_NCTF_C2

HASWELL-ULT-DDR3L_BGA1168

UC1R

AT2

RSVD35

AU44

RSVD36

AV44

RSVD37

D15

RSVD38

F22

RSVD39

H22

RSVD40

J21

RSVD41

HASWELL-ULT-DDR3L_BGA1168

UC1S

AC60

CFG0

AC62

CFG1

AC63

CFG2

AA63

CFG3

AA60

CFG4

Y62

CFG5

Y61

CFG6

Y60

CFG7

V62

CFG8

V61

CFG9

V60

CFG10

U60

CFG11

T63

CFG12

T62

CFG13

T61

CFG14

T60

CFG15

AA62

CFG16

U63

CFG18

AA61

CFG17

U62

CFG19

V63

CFG_RCOMP

A5

RSVD53

E1

RSVD54

D1

RSVD55

J20

RSVD56

H18

RSVD57

B12

TD_IREF

HASWELL-ULT-DDR3L_BGA1168

HSW_ULT_DDR3L

17 OF 19

HSW_ULT_DDR3L

18 OF 19

HSW_ULT_DDR3L

RESERVED

19 OF 19

DAISY_CHAIN_NCTF_A3
DAISY_CHAIN_NCTF_A4

DAISY_CHAIN_NCTF_A60
DAISY_CHAIN_NCTF_A61
DAISY_CHAIN_NCTF_A62

DAISY_CHAIN_NCTF_AV1
DAISY_CHAIN_NCTF_AW1
DAISY_CHAIN_NCTF_AW2
DAISY_CHAIN_NCTF_AW3

DAISY_CHAIN_NCTF_AW61
DAISY_CHAIN_NCTF_AW62
DAISY_CHAIN_NCTF_AW63

RSVD42
RSVD43
RSVD44
RSVD45

RSVD46
RSVD47
RSVD48
RSVD49
RSVD50
RSVD51
RSVD52

RSVD_TP5
RSVD_TP6

RSVD_TP7
RSVD_TP8

RSVD58

RSVD_TP9

RSVD_TP10

RSVD_TP11

RSVD59

RSVD60
RSVD61

PROC_OPI_RCOMP

RSVD62
RSVD63

VSS342
VSS343

RSVD64
RSVD65

A3

DC_TEST_A3_B3

A4

TP_DC_TEST_A4

A60

TP_DC_TEST_A60

A61

DC_TEST_A61_B61

A62

TP_DC_TEST_A62

AV1

TP_DC_TEST_AV1

AW1

TP_DC_TEST_AW1

AW2

DC_TEST_AY2_AW2

AW3

DC_TEST_AY3_AW3

AW61

DC_TEST_AY61_AW61

AW62

DC_TEST_AY62_AW62

AW63

TP_DC_TEST_AW63

N23
R23
T23
U10

AL1
AM11
AP7
AU10
AU15
AW14
AY14

AV63
AU63

C63
C62
B43

A51
B51

L60

N60

W23
Y22
AY15

AV62
D58

P22
N21

P20
R20

PROC_OPI_COMP

1

TC71@

1

TC72@

1

TC74@

1

TC75@

1

TC76@

1

TC77@

1

TC83@

1

TC86@

1

TC93@

1

TC97@

1

TC101@

1

TC103@

1

TC105@

1

TC107@

1

TC110@

1

TC112@

1

TC115@

1

TC118@

49.9_0402_1%

12

PROC_OPI_RCOMP

Width 20Mil
Space 15Mil
Length 500Mil

1

RC162

TC126@

CFG3

CFG3

*1: Disable
0: Enable, Set DFX Enabled BIT
In Debug Interface MSR

CFG4

CFG4

*L: eDP enable
H: eDP disable

CFG0

CFG1

CFG8

CFG9

CFG10

RC160 1K_0402_1%@

RC161 1K_0402_1%

RC164 1K_0402_1%@

RC165 1K_0402_1%@

RC167 1K_0402_1%@

RC168 1K_0402_1%@

RC169 1K_0402_1%@

12

12

12

12

12

12

12

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

MCP (OTHER)

MCP (OTHER)

MCP (OTHER)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

13 59

13 59

1

13 59

1.0

1.0

1.0

5

4

3

2

1

DDR_SA_VREFDQ {6}

+1.35V

12

RD5

RD6

1 2

D D

C C

B B

A A

2_0402_5%

0.022U_0402_16V7-K

CD3

1

2

12

RD8

24.9_0402_1%

1.82K_0402_1%

+VREF_DQ_DIMMA

1.82K_0402_1%

12

RD7

CD4

CD@

DDRA_CKE0{6}

DDRA_BS2#{6}

DDRA_CLK0{6}
DDRA_CLK0#{6}

DDRA_BS0#{6}

DDRA_WE#{6}
DDRA_CAS#{6}

DDRA_CS1#{6}

+3VS

CD28

2.2U_0603_6.3V6K

.1U_0402_10V6-K

2.2U_0603_6.3V6K

1

CD2

2

1

1

CD29
.1U_0402_10V6-K

2

2

5

DDRA_DQ0
DDRA_DQ1

1

2

DDRA_DQ2
DDRA_DQ3

DDRA_DQ8
DDRA_DQ9

DDRA_DQS#1
DDRA_DQS1

DDRA_DQ10
DDRA_DQ11

DDRA_DQ16
DDRA_DQ17

DDRA_DQS#2
DDRA_DQS2

DDRA_DQ18
DDRA_DQ19

DDRA_DQ24
DDRA_DQ25

DDRA_DQ26
DDRA_DQ27

DDRA_CKE0

DDRA_BS2#

DDRA_MA12
DDRA_MA9

DDRA_MA8
DDRA_MA5

DDRA_MA3
DDRA_MA1

DDRA_CLK0
DDRA_CLK0#

DDRA_MA10
DDRA_BS0#

DDRA_WE#
DDRA_CAS#

DDRA_MA13
DDRA_CS1#

DDRA_DQ32
DDRA_DQ33

DDRA_DQS#4
DDRA_DQS4

DDRA_DQ34
DDRA_DQ35

DDRA_DQ40
DDRA_DQ41

DDRA_DQ42
DDRA_DQ43

DDRA_DQ48
DDRA_DQ49

DDRA_DQS#6
DDRA_DQS6

DDRA_DQ50
DDRA_DQ51

DDRA_DQ56
DDRA_DQ57

DDRA_DQ58
DDRA_DQ59

1 2

RD13 0_0402_5%

1 2

@

RD14
0_0402_5%

@

DDR3 SO-DIMM A

3A@1.5V

JDDR1

1

VREF_DQ

3

VSS_1

5

DQ0

7

DQ1

9

VSS_3

11

DM0

13

VSS_5

15

DQ2

17

DQ3

19

VSS_7

21

DQ8

23

DQ9

25

VSS_9

27

DQS1#

29

DQS1

31

VSS_11

33

DQ10

35

DQ11

37

VSS_13

39

DQ16

41

DQ17

43

VSS_15

45

DQS2#

47

DQS2

49

VSS_17

51

DQ18

53

DQ19

55

VSS_19

57

DQ24

59

DQ25

61

VSS_21

63

DM3

65

VSS_23

67

DQ26

69

DQ27

71

VSS_25

73

CKE0

75

VDD_1

77

NC_1

79

BA2

81

VDD_3

83

A12/BC#

85

A9

87

VDD_5

89

A8

91

A5

93

VDD_7

95

A3

97

A1

99

VDD_9

101

CK0

103

CK0#

105

VDD_11

107

A10/AP

109

BA0

111

VDD_13

113

WE#

115

CAS#

117

VDD_15

119

A13

121

S1#

123

VDD_17

125

TEST

127

VSS_27

129

DQ32

131

DQ33

133

VSS_29

135

DQS4#

137

DQS4

139

VSS_31

141

DQ34

143

DQ35

145

VSS_33

147

DQ40

149

DQ41

151

VSS_36

153

DM5

155

VSS_37

157

DQ42

159

DQ43

161

VSS_39

163

DQ48

165

DQ49

167

VSS_41

169

DQS6#

171

DQS6

173

VSS_43

175

DQ50

177

DQ51

179

VSS_45

181

DQ56

183

DQ57

185

VSS_47

187

DM7

189

VSS_49

191

DQ58

193

DQ59

195

VSS_51

197

SA0

199

VDDSPD

201

SA1

203

VTT_1

205

GND1

207

BOSS1

LCN_DAN06-K4406-0103

ME@

VSS_2

DQ4

DQ5
VSS_4
DQS0#

DQS0

VSS_6

DQ6

DQ7
VSS_8

DQ12
DQ13

VSS_10

DM1

RESET#

VSS_12

DQ14
DQ15

VSS_14

DQ20
DQ21

VSS_16

DM2

VSS_18

DQ22
DQ23

VSS_20

DQ28
DQ29

VSS_22

DQS3#

DQS3

VSS_24

DQ30
DQ31

VSS_26

CKE1

VDD_2

VDD_4

VDD_6

VDD_8

VDD_10

CK1

CK1#

VDD_12

BA1

RAS#

VDD_14

ODT0

VDD_16

ODT1

NC_2

VDD_18

VREF_CA

VSS_28

DQ36
DQ37

VSS_30

DM4

VSS_32

DQ38
DQ39

VSS_34

DQ44
DQ45

VSS_35

DQS5#

DQS5

VSS_38

DQ46
DQ47

VSS_40

DQ52
DQ53

VSS_42

DM6

VSS_44

DQ54
DQ55

VSS_46

DQ60
DQ61

VSS_48

DQS7#

DQS7

VSS_50

DQ62
DQ63

VSS_52

EVENT#

SDA

SCL

VTT_2

GND2

BOSS2

4

A15
A14

A11

A7

A6
A4

A2
A0

S0#

2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
68
70
72

74
76
78
80
82
84
86
88
90
92
94
96
98
100
102
104
106
108
110
112
114
116
118
120
122
124
126
128
130
132
134
136
138
140
142
144
146
148
150
152
154
156
158
160
162
164
166
168
170
172
174
176
178
180
182
184
186
188
190
192
194
196
198
200
202
204

206
208

+1.35V+1.35V

DDRA_DQ4
DDRA_DQ5

DDRA_DQS#0
DDRA_DQS0

DDRA_DQ6
DDRA_DQ7

DDRA_DQ12
DDRA_DQ13

CPU_DRAMRST#

DDRA_DQ14
DDRA_DQ15

DDRA_DQ20
DDRA_DQ21

DDRA_DQ22
DDRA_DQ23

DDRA_DQ28
DDRA_DQ29

DDRA_DQS#3
DDRA_DQS3

DDRA_DQ30
DDRA_DQ31

DDRA_CKE1

DDRA_MA15
DDRA_MA14

DDRA_MA11
DDRA_MA7

DDRA_MA6
DDRA_MA4

DDRA_MA2
DDRA_MA0

DDRA_CLK1
DDRA_CLK1#

DDRA_BS1#
DDRA_RAS#

DDRA_CS0#
DDRA_ODT0

DDRA_ODT1

DDRA_DQ36
DDRA_DQ37

DDRA_DQ38
DDRA_DQ39

DDRA_DQ44
DDRA_DQ45

DDRA_DQS#5
DDRA_DQS5

DDRA_DQ46
DDRA_DQ47

DDRA_DQ52
DDRA_DQ53

DDRA_DQ54
DDRA_DQ55

DDRA_DQ60
DDRA_DQ61

DDRA_DQS#7
DDRA_DQS7

DDRA_DQ62
DDRA_DQ63

SMB_DATA_S3
SMB_CLK_S3

1

CD68
33P_0402_50V8J

@

2

For RF

1

2

SMB_DATA_S3 {7,15,40}
SMB_CLK_S3 {7,15,40}

+0.675VS

0.65A@0.75V

For RF

DDRA_DQ[0..63] {6}

DDRA_DQS[0..7] {6}

DDRA_DQS#[0..7] {6}

DDRA_MA[0..15] {6}

33P_0402_50V8J

CD5

1

@

1

@

2

2

CPU_DRAMRST# {5,15}

33P_0402_50V8J

33P_0402_50V8J

CD7

CD6

1

@

2

Layout Note:
Place near DIMM

OSCON (220uF_6.3V_4.2L_ESR17m)*1=(SF000002Y0J)
(10uF_0603_6.3V)*8
(1U_0402_6.3V)*4
(.1U_0402_10V6-K)*4

+1.35V

CD8

10U_0603_6.3V6M

10U_0603_6.3V6M

1

DDRA_CKE1 {6}

DDRA_CLK1 {6}
DDRA_CLK1# {6}

DDRA_BS1# {6}
DDRA_RAS# {6}

DDRA_CS0# {6}
DDRA_ODT0 {5}

DDRA_ODT1 {5}

.1U_0402_10V6-K

CD22

1

2

2

CD@

+VREF_CA

CD23

2.2U_0603_6.3V6K

CD@

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

CD10

CD9

10U_0603_6.3V6M

1

1

2

2

CD@

+VREF_CA {15}

Layout Note:
Place near DIMM

+0.675VS

CD24

.1U_0402_10V6-K

.1U_0402_10V6-K

1

2

CD@

2013/08/08

2013/08/08

2013/08/08

10U_0603_6.3V6M

CD25

1

2

CD12

CD11

10U_0603_6.3V6M

1

2

10U_0603_6.3V6M

1

1

2

2

Tracewidth:20mils
Space:20mils

CD13

(10U_0603_6.3V)*2
(.1U_0402_10V)*4

CD26

.1U_0402_10V6-K

CD27

.1U_0402_10V6-K

1

1

2

2

CD@

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

CD14

10U_0603_6.3V6M

1

2

+VREF_CA

CD64

10U_0603_6.3V6M

10U_0603_6.3V6M

1

2

CD15

.1U_0402_10V6-K

10U_0603_6.3V6M

1

2

+1.35V

12

RD9

1.82K_0402_1%

1 2

RD10 0_0402_5%

12

RD11

1.82K_0402_1%

CD65

1

2

CD@

2013/08/05

2013/08/05

2013/08/05

2

CD16

1

2

CD18

CD17

.1U_0402_10V6-K

.1U_0402_10V6-K

1

2

@

.1U_0402_10V6-K

1

2

Note:
VREFtracewidth:20milsatleast
Spacing:20milstoothersignal/planes
PlacenearDIMMscoket

1

CD21

0.022U_0402_16V7-K

2

12

RD12

24.9_0402_1%

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

CD19

CD56

1U_0402_6.3V6K

1

2

DDRIII SO-DIMM A

DDRIII SO-DIMM A

DDRIII SO-DIMM A

CD57

1U_0402_6.3V6K

1

1

2

2

CD@

CD@

DDR_SM_VREFCA {6}

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

1U_0402_6.3V6K

CD@

UMA

UMA

UMA

1

2

1

CD58

1U_0402_6.3V6K

CD@

CD59

1

2

14 59

14 59

14 59

1

+

CD20
220U_6.3V_M

@

2

of

of

of

1.0

1.0

1.0

5

DDR_SB_VREFDQ {6}

+1.35V

12

RD15

RD16

1 2

2_0402_5%

D D

C C

B B

A A

0.022U_0402_16V7-K

CD32

1

2

12

RD18

24.9_0402_1%

1.82K_0402_1%

+VREF_DQ_DIMMB

1.82K_0402_1%

12

RD17

+3VS

CD54

2.2U_0603_6.3V6K

5

CD31

CD30

DDRB_CKE0{6}

DDRB_BS2#{6}

DDRB_CLK0{6}
DDRB_CLK0#{6}

DDRB_BS0#{6}

DDRB_WE#{6}
DDRB_CAS#{6}

DDRB_CS1#{6}

.1U_0402_10V6-K

2.2U_0603_6.3V6K

1

2

CD@

1

2

DDRB_DQ17
DDRB_DQ23

1

2

DDRB_DQ18

DDRB_DQ3 DDRB_DQ2
DDRB_DQ5

DDRB_DQS#0
DDRB_DQS0

DDRB_DQ6
DDRB_DQ1

DDRB_DQ8
DDRB_DQ10 DDRB_DQ12

DDRB_DQS#1
DDRB_DQS1

DDRB_DQ14
DDRB_DQ15

DDRB_DQ27
DDRB_DQ26

DDRB_DQ28 DDRB_DQ29
DDRB_DQ24

DDRB_CKE0

DDRB_BS2#

DDRB_MA12
DDRB_MA9

DDRB_MA8
DDRB_MA5

DDRB_MA3
DDRB_MA1

DDRB_CLK0
DDRB_CLK0#

DDRB_MA10
DDRB_BS0#

DDRB_WE#
DDRB_CAS#

DDRB_MA13
DDRB_CS1#

DDRB_DQ33

DDRB_DQS#4
DDRB_DQS4

DDRB_DQ38

DDRB_DQ40
DDRB_DQ43

DDRB_DQ42
DDRB_DQ44

DDRB_DQ52
DDRB_DQ51

DDRB_DQS#6
DDRB_DQS6

DDRB_DQ50
DDRB_DQ48

DDRB_DQ62
DDRB_DQ57

DDRB_DQ59 DDRB_DQ58
DDRB_DQ63

1 2

RD20 0_0402_5%

@

1 2

RD21 10K_0402_5%

1

CD55
.1U_0402_10V6-K

2

DDR3 SO-DIMM B

+1.35V +1.35V

3A@1.5V

3
5
7

9
11
13
15
17
19
21
23
25
27

31
33
35
37
39
41
43
45
47
49
51
53
55
57
59

63
65
67
69
71

73
75
77
79
81
83
85
87
89
91
93
95
97
99

101
103
105
107
109
111
113
115
117
119
121
123
125
127
129
131
133
135
137
139
141
143
145
147
149
151
153
155
157
159
161
163
165
167
169
171
173
175
177
179
181
183
185
187
189
191
193
195
197
199
201
203

205

4

JDDR2

VREF_DQ1VSS1
VSS2
DQ0
DQ1
VSS4
DM0
VSS5
DQ2
DQ3
VSS7
DQ8
DQ9
VSS9
DQS#1
DQS129RESET#
VSS11
DQ10
DQ11
VSS13
DQ16
DQ17
VSS15
DQS#2
DQS2
VSS18
DQ18
DQ19
VSS20
DQ24
DQ25
VSS2261DQS#3
DM3
VSS23
DQ26
DQ27
VSS25

CKE0
VDD1
NC1
BA2
VDD3
A12/BC#
A9
VDD5
A8
A5
VDD7
A3
A1
VDD9
CK0
CK0#
VDD11
A10/AP
BA0
VDD13
WE#
CAS#
VDD15
A13
S1#
VDD17
NCTEST
VSS27
DQ32
DQ33
VSS29
DQS#4
DQS4
VSS32
DQ34
DQ35
VSS34
DQ40
DQ41
VSS36
DM5
VSS37
DQ42
DQ43
VSS39
DQ48
DQ49
VSS41
DQS#6
DQS6
VSS44
DQ50
DQ51
VSS46
DQ56
DQ57
VSS48
DM7
VSS49
DQ58
DQ59
VSS51
SA0
VDDSPD
SA1
VTT1

G1

LCN_DAN06-K4406-0102
ME@

DQ4
DQ5

VSS3

DQS#0

DQS0

VSS6

DQ6

DQ7
VSS8
DQ12
DQ13

VSS10

DM1

VSS12

DQ14
DQ15

VSS14

DQ20
DQ21

VSS16

DM2

VSS17

DQ22
DQ23

VSS19

DQ28
DQ29

VSS21

DQS3

VSS24

DQ30
DQ31

VSS26

CKE1

VDD2

VDD4

VDD6

VDD8

VDD10

CK1#

VDD12

RAS#

VDD14

ODT0

VDD16

ODT1

VDD18

VREF_CA

VSS28

DQ36
DQ37

VSS30

DM4

VSS31

DQ38
DQ39

VSS33

DQ44
DQ45

VSS35

DQS#5

DQS5

VSS38

DQ46
DQ47

VSS40

DQ52
DQ53

VSS42

DM6

VSS43

DQ54
DQ55

VSS45

DQ60
DQ61

VSS47

DQS#7

DQS7

VSS50

DQ62
DQ63

VSS52

EVENT#

VTT2

4

A15
A14

A11

CK1

BA1

S0#

NC2

SDA
SCL

3

2
4

DDRB_DQ16

6

DDRB_DQ22

8
10

DDRB_DQS#2

12

DDRB_DQS2

14
16

DDRB_DQ19

18

DDRB_DQ20DDRB_DQ21

20
22
24

DDRB_DQ4

26
28
30

CPU_DRAMRST#

32
34

DDRB_DQ0

36

DDRB_DQ7

38
40

DDRB_DQ13

42
44
46
48
50

DDRB_DQ9

52

DDRB_DQ11

54
56

DDRB_DQ31

58

DDRB_DQ30

60
62

DDRB_DQS#3

64

DDRB_DQS3

66
68
70

DDRB_DQ25

72

74

DDRB_CKE1

76
78

DDRB_MA15

80

DDRB_MA14

82
84

DDRB_MA11

86

A7

A6
A4

A2
A0

G2

DDRB_MA7

88
90

DDRB_MA6

92

DDRB_MA4

94
96

DDRB_MA2

98

DDRB_MA0

100
102

DDRB_CLK1

104

DDRB_CLK1#

106
108

DDRB_BS1#

110

DDRB_RAS#

112
114

DDRB_CS0#

116

DDRB_ODT0

118
120

DDRB_ODT1

122
124
126
128
130

DDRB_DQ37

132

DDRB_DQ32DDRB_DQ36

134
136
138
140

DDRB_DQ35

142

DDRB_DQ34DDRB_DQ39

144
146

DDRB_DQ45

148

DDRB_DQ41

150
152

DDRB_DQS#5

154

DDRB_DQS5

156
158

DDRB_DQ46

160

DDRB_DQ47

162
164

DDRB_DQ49

166

DDRB_DQ53

168
170
172
174

DDRB_DQ54

176

DDRB_DQ55

178
180

DDRB_DQ56

182

DDRB_DQ61

184
186

DDRB_DQS#7

188

DDRB_DQS7

190
192
194

DDRB_DQ60

196
198
200

SMB_DATA_S3

202

SMB_CLK_S3

204

206

1

CD69
33P_0402_50V8J

@

2

For RF

For RF

@

DDRB_CKE1 {6}

DDRB_CLK1 {6}
DDRB_CLK1# {6}

DDRB_BS1# {6}
DDRB_RAS# {6}

DDRB_CS0# {6}
DDRB_ODT0 {5}

DDRB_ODT1 {5}

.1U_0402_10V6-K

1

CD48

2

SMB_DATA_S3 {7,14,40}
SMB_CLK_S3 {7,14,40}

+0.675VS

33P_0402_50V8J

CD33

1

1

@

2

2

CPU_DRAMRST# {5,14}

33P_0402_50V8J

33P_0402_50V8J

CD34

CD35

1

@

2

Layout Note:
Place near DIMM

(10uF_0603_6.3V)*8
(1U_0402_6.3V)*8
(.1U_0402_10V6-K)*4

+1.35V

CD37

CD36

10U_0603_6.3V6M

10U_0603_6.3V6M

1

2

CD@

CD44

.1U_0402_10V6-K

.1U_0402_10V6-K

1

2

+VREF_CB

1

CD49

2.2U_0603_6.3V6K

CD@

2

1 2

RD19 0_0402_5%

@

Layout Note:
Place near DIMM

+0.675VS

CD50

.1U_0402_10V6-K

.1U_0402_10V6-K

1

2

CD@

0.65A@0.75V

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

CD38

10U_0603_6.3V6M

1

2

CD@

CD45

1

2

10U_0603_6.3V6M

1

2

CD46

.1U_0402_10V6-K

.1U_0402_10V6-K

1

2

+VREF_CA {14}

(10U_0603_6.3V)*2
(.1U_0402_10V)*4

CD51

CD52

.1U_0402_10V6-K

1

2

.1U_0402_10V6-K

1

2

CD@

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

CD39

10U_0603_6.3V6M

1

2

CD47

1U_0402_6.3V6K

1

2

CD@

CD53

10U_0603_6.3V6M

1

2

Deciphered Date

Deciphered Date

Deciphered Date

CD66

1

2

CD40

1

2

CD60

1

2

2

Swap Table

Pin

Pin Name Net Name

DDRB_DQ[0..63] {6}

DDRB_DQS[0..7] {6}

DDRB_DQS#[0..7] {6}

DDRB_MA[0..15] {6}

CD43

CD42

CD41

10U_0603_6.3V6M

1

2

CD61

1U_0402_6.3V6K

1

2

CD@

CD67

10U_0603_6.3V6M

1

2

CD@

2

10U_0603_6.3V6M

1

2

CD62

1U_0402_6.3V6K

1

2

CD@

2013/08/05

2013/08/05

2013/08/05

10U_0603_6.3V6M

1

2

CD63

1U_0402_6.3V6K

1

2

CD@

Number

5

DQ0

7

DQ1

15

DQ2

17

DQ3

4

DQ4

6

DQ5

16

DQ6

18

DQ7

10

DQS#0

12

DQS0

21

DQ8

23

DQ9

33

DQ10

35

DQ11

22

DQ12

24

DQ13

34

DQ14

36

DQ15

27

DQS#1

29

DQS1

DQ16

39

DQ17

41

DQ18

51

DQ19

53

DQ20

40
42

DQ21

50

DQ22

52

DQ23

45

DQS#2

47

DQS2

DQ24

57

DQ25

59

DQ26

67

DQ27

69

DQ28

56

DQ29

58

DQ30

68

DQ31

70

DQS#3

62
64

DQS3

129

DQ32

131

DQ33

141

DQ34

143

DQ35

130

DQ36
DQ37

132

DQ38

140

DQ39

142

DQS#4

135

DQS4

137

DQ40

147

DQ41

149

DQ42

157

DQ43

159

DQ44

146
148

DQ45

158

DQ46

160

DQ47

152

DQS#5

154

DQS5

163

DQ48
DQ49

165

DQ50

175

DQ51

177

DQ52

164

DQ53

166

DQ54

174

DQ55

176

DQS#6

169

DQS6

171

181

DQ56

183

DQ57

191

DQ58

193

DQ59
DQ60

180

DQ61

182

DQ62

192

DQ63

194

DQS#7

186

DQS7

188

Title

Title

Title

DDRIII SO-DIMM B

DDRIII SO-DIMM B

DDRIII SO-DIMM B

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

1

DDRB_DQ17
DDRB_DQ23
DDRB_DQ18
DDRB_DQ21
DDRB_DQ16
DDRB_DQ22
DDRB_DQ19
DDRB_DQ20
DDRB_DQS#2
DDRB_DQS2

DDRB_DQ3
DDRB_DQ5
DDRB_DQ6
DDRB_DQ1
DDRB_DQ2
DDRB_DQ4
DDRB_DQ0
DDRB_DQ7
DDRB_DQS#0
DDRB_DQS0

DDRB_DQ8
DDRB_DQ10
DDRB_DQ14
DDRB_DQ15
DDRB_DQ13
DDRB_DQ12
DDRB_DQ9
DDRB_DQ11
DDRB_DQS#1
DDRB_DQS1

DDRB_DQ27
DDRB_DQ26
DDRB_DQ28
DDRB_DQ24
DDRB_DQ31
DDRB_DQ30
DDRB_DQ29
DDRB_DQ25
DDRB_DQS#3
DDRB_DQS3

DDRB_DQ33
DDRB_DQ36
DDRB_DQ39
DDRB_DQ38
DDRB_DQ37
DDRB_DQ32
DDRB_DQ35
DDRB_DQ34
DDRB_DQS#4
DDRB_DQS4

DDRB_DQ40
DDRB_DQ43
DDRB_DQ42
DDRB_DQ44
DDRB_DQ45
DDRB_DQ41
DDRB_DQ46
DDRB_DQ47
DDRB_DQS#5
DDRB_DQS5

DDRB_DQ52
DDRB_DQ51
DDRB_DQ50
DDRB_DQ48
DDRB_DQ49
DDRB_DQ53
DDRB_DQ54
DDRB_DQ55
DDRB_DQS#6
DDRB_DQS6

DDRB_DQ62
DDRB_DQ57
DDRB_DQ59
DDRB_DQ63
DDRB_DQ56
DDRB_DQ61
DDRB_DQ58
DDRB_DQ60
DDRB_DQS#7
DDRB_DQS7

UMA

UMA

UMA

1

of

of

of

15 59

15 59

15 59

1.0

1.0

1.0

5

D D

C C

B B

4

3

2

1

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

Blank

Blank

Blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

16 59

16 59

1

16 59

1.0

1.0

1.0

5

D D

C C

B B

4

3

2

1

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

Blank

Blank

Blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

17 59

17 59

1

17 59

1.0

1.0

1.0

5

D D

C C

4

3

2

1

B B

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

blank

blank

blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

1

of

of

of

18 59

18 59

18 59

1.0

1.0

1.0

5

D D

C C

4

3

2

1

B B

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2013/08/05

2013/08/05

2013/08/05

2

Title

blank

blank

blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

A3

A3

A3

Date: Sheet of

Date: Sheet of

Date: Sheet of

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

19 59

19 59

19 59

1

1.0

1.0

1.0

5

D D

C C

4

3

2

1

B B

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

blank

blank

blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

20 59

20 59

20 59

of

of

1

of

1.0

1.0

1.0

5

D D

C C

B B

4

3

2

1

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2013/08/05

2013/08/05

2013/08/05

2

Title

blank

blank

blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet of

Date: Sheet of

Date: Sheet of

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

21 59

21 59

21 59

1

1.0

1.0

1.0

5

D D

C C

4

3

2

1

B B

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2013/08/05

2013/08/05

2013/08/05

2

Title

blank

blank

blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

22 59

22 59

22 59

1

1.0

1.0

1.0

5

D D

C C

4

3

2

1

B B

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2013/08/05

2013/08/05

2013/08/05

2

Title

blank

blank

blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

of

of

of

23 59

23 59

23 59

1

1.0

1.0

1.0

5

D D

C C

4

3

2

1

B B

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

ATI_JET-LE_MEM IF

ATI_JET-LE_MEM IF

ATI_JET-LE_MEM IF

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

24 59

24 59

1

24 59

1.0

1.0

1.0

5

D D

C C

4

3

2

1

B B

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

ATI_JET-LE_VRAM_A

ATI_JET-LE_VRAM_A

ATI_JET-LE_VRAM_A

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

25 59

25 59

25 59

of

of

1

of

1.0

1.0

1.0

5

D D

C C

4

3

2

1

B B

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

ATI_JET-LE_VRAM_B

ATI_JET-LE_VRAM_B

ATI_JET-LE_VRAM_B

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

26 59

26 59

26 59

of

of

1

of

1.0

1.0

1.0

5

D D

C C

B B

4

3

2

1

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

Blank

Blank

Blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

27 59

27 59

1

27 59

1.0

1.0

1.0

5

D D

C C

B B

4

3

2

1

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

Blank

Blank

Blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

28 59

28 59

1

28 59

1.0

1.0

1.0

5

D D

C C

B B

4

3

2

1

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

Blank

Blank

Blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

29 59

29 59

1

29 59

1.0

1.0

1.0

5

D D

C C

B B

4

3

2

1

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

Blank

Blank

Blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

30 59

30 59

1

30 59

1.0

1.0

1.0

5

D D

C C

B B

4

3

2

1

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

Blank

Blank

Blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

31 59

31 59

1

31 59

1.0

1.0

1.0

5

D D

C C

B B

4

3

2

1

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

Blank

Blank

Blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

32 59

32 59

1

32 59

1.0

1.0

1.0

5

4

3

2

1

LCD POWER CIRCUIT

+LCDVDD

12

R1
130_0603_1%

34

Q8B

D D

PCH_ENVDD{4}

PCH_ENBKL

BKOFF#{44}

PCH_ENBKL{4}

C C

PCH_EDP_PWM{4}

2N7002KDWH_SOT363-6

1 2

R6 0_0402_5%

1 2

R11

@

0_0402_5%

1 2

R12 0_0402_5%

@

1 2

R14 0_0402_5%

@

1 2

R19 0_0402_5%

@

D

G

S

@

R7

100K_0402_5%

+3VS

R10

4.7K_0402_5%

@

1 2

DISPOFF#

ENBKL

12

R16
100K_0402_5%

+3VS

R18
1K_0402_5%

@

1 2

INVT_PWM

12

R20
100K_0402_5%

5

12

Q8A

2

G

ENBKL {44}

+5VALW

12

R2
100K_0402_5%

1 2

220K_0402_5%

.1U_0402_10V6-K

61

D

S

2N7002KDWH_SOT363-6

R4

C2

PCH_ENVDD

Reserve for power consumption test

B B

Touch Screen

1 2

R22

EC_TS_ON#{44}

+3VS +3VS_TS+3VS_TS_R

1 2

R25 0_0402_5%TS@

+3VALW

1 2

R27 0_0402_5%@

A A

TS@

100K_0402_5%

R26 0_0402_5%@

USB20_P4

USB20_N4

1

4

.1U_0402_10V6-K

C23

+3VS_TS_R

LP2301ALT1G_SOT23-3

Q11 TS@

1 2

L13

1

4

CMM21T-900M-N_4P

1 2

S

@

2

3

G

2

2

3

TS@

D

13

C25

.1U_0402_10V6-K

ForEMI

USB20_P4_CONN

USB20_N4_CONN

+3VS_TS

@

B+

1

2

+3VS

W=60mils

1

C1

4.7U_0603_6.3V6K

CD@

Q9

2

1

2

2

S

G

LP2301ALT1G_SOT23-3

D

+LCDVDD

1 3

B+ +LEDVDD

2A80mil

AO3401A_SOT23-3

Q33

1 2

@

@

C132

@

USB20_N4{9}

USB20_P4{9}

+3VS_TS

1

2

AZ5215-01F_DFN1006P2E2

LEDVDD_EN#

2

G

1

2

@

D2

1

2

Q34

@

R28 10K_0402_5%@

R23 0_0402_5%TS@
R24 0_0402_5%TS@

R179

100K_0402_5%

1 2

R181

0_0402_5%

.1U_0402_10V6-K

L1

1 2

FCM2012CF-800T06_2P

R17

12

@

0_0805_5%

D

S

13

@

G

2

12

R180
100K_0402_5%

@

13

D

S

2N7002KW_SOT323-3

12

1 2
1 2

USB20_P4_CONN

USB20_N4_CONN

ForEMI

+LCDVDD_CON

C7

1

2

4.7U_0603_6.3V6K

TS_RS

USB20_N4_CONN
USB20_P4_CONN

3

1

W=60mils

C8

1

2

.1U_0402_10V6-K

CD@

2A80mil

4.7U_0805_25V6-K

470P_0402_50V7K

C14

1

2

CD@

2

D1
AZC199-02S.R7G_SOT23-3

@

For RF

C15

1

2

EMIRequest

C43

1

2

@

33P_0402_50V8J

680P_0402_50V7K

JTS1

1
2
3
4
5
6

ACES_87213-00601-P01

ME@

+3VS

C22

@

1
2
3
4
5

GND1

6

GND2

Touch Screen

CMOS_ON#{9}

EDP_AUX
EDP_AUX#

CPU_EDP_AUX{4}
CPU_EDP_AUX#{4}

R21

1

2

7
8

0.01U_0402_25V7K

+3VS

R8
100K_0402_1%

@

1 2

R13
100K_0402_1%

@

1 2

CPU_EDP_TX0+{4}
CPU_EDP_TX0-{4}

CPU_EDP_TX1+{4}
CPU_EDP_TX1-{4}

1 2

@

0_0402_5%

+3VS

1 2

R5

1

C9

@

2

R9
100K_0402_1%

@

1 2

R15
100K_0402_1%

@

1 2

CPU_EDP_TX1+ EDP_TX1+

CPU_EDP_AUX EDP_AUX
CPU_EDP_AUX# EDP_AUX#

CPU_EDP_HPD{4}

W=60mils

DMIC_DATA{43}

DMIC_CLK{43}

USB20_P5{9}
USB20_N5{9}

Needshort

JUMP_43X39

LP2301ALT1G_SOT23-3

W=40 mils W=40mils

C5

.1U_0402_10V6-K

@

@

100K_0402_5%

For EMI
Close to R5

+LEDVDD

1 2

C19 .1U_0402_10V6-K

1 2

C16 .1U_0402_10V6-K

1 2

C17 .1U_0402_10V6-K

1 2

C18 .1U_0402_10V6-K

1 2

C20 .1U_0402_10V6-K

1 2

C21 .1U_0402_10V6-K

+LCDVDD_CON

+3VS

R182 0_0402_5%
R183 0_0402_5%

+3VS_CMOS

0.047U_0402_16V7K

USB20_P5

USB20_N5

J1

@

2

112

S

Q7

@

G

1

2

1

C10
.1U_0402_10V6-K

@

2

DMIC_CLK

INVT_PWM{4}

@

1 2

@

1 2

C24

EMI request

CMOS Camera

+3VS_CMOS_R

D

13

.01U_0402_16V7-K

C6

1

2

2

@

EMI request

DISPOFF# INVT_PWM

C11

1

2

100P_0402_50V8J

EDP_TX0+CPU_EDP_TX0+
EDP_TX0-CPU_EDP_TX0-

EDP_TX1-CPU_EDP_TX1-

DISPOFF#

INVT_PWM

USB20_P5_R
USB20_N5_R

2

W=40mils

1

CD@

L12

1

4

CMM21T-900M-N_4P

@

2

3

2

USB20_P5_R

3

USB20_N5_R

1

4

1 2

R3

1

C3
.1U_0402_10V6-K

CD@

2

C12

@

ForEMI

+3VS_CMOS

@

0_0603_5%

1

C4
10U_0603_6.3V6M

@

2

1

2

470P_0402_50V7K

JEDP1

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

13

13

14

14

15

15

16

16

17

17

18

18

19

19

20

20

21

21

22

22

23

23

24

24

25

25

26

26

G1

27

27

G2

28

28

G3

29

29

G4

30

30

G5

ACES_50406-03071-001

ME@

C13

1

2

470P_0402_50V7K

@

31
32
33
34
35

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

eDP/ CMOS/Touch screen

eDP/ CMOS/Touch screen

eDP/ CMOS/Touch screen

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

of

of

of

33 59

33 59

1

33 59

1.0

1.0

1.0

5

4

3

2

1

L2

HDMI_CLK-_C

HDMI_CLK+_C HDMI_CLK+_CON

D D

HDMI_TX0-_C

HDMI_TX0+_C

HDMI_TX1-_C HDMI_TX1-_CON

HDMI_TX1+_C

HDMI_TX2-_C

HDMI_TX2+_C

1

1

4

4

HDMI2012F2SF-900T04_4P

L3

1

1

4

4

HDMI2012F2SF-900T04_4P

L4

1

1

4

4

HDMI2012F2SF-900T04_4P

L5

1

1

4

4

HDMI2012F2SF-900T04_4P

2

2

3

3

2

2

3

3

2

2

3

3

2

2

3

3

HDMI_CLK-_CON

HDMI_TX0-_CON

HDMI_TX0+_CON

HDMI_TX1+_CON

HDMI_TX2-_CON

HDMI_TX2+_CON

@

1 2

C26 3.3P_0402_50V8-C

@

1 2

C27 3.3P_0402_50V8-C

@

1 2

C28 3.3P_0402_50V8-C

@

1 2

C29 3.3P_0402_50V8-C

@

1 2

C30 3.3P_0402_50V8-C

@

1 2

C31 3.3P_0402_50V8-C

@

1 2

C32 3.3P_0402_50V8-C

@

1 2

C33 3.3P_0402_50V8-C

+3VS

G

5

Q1B

S

34

HDMICLK_R

DDPB_CLK{4}

DDPB_DATA{4}

G

2

Q1A

S

61

2N7002KDWH_SOT363-6

D

D

2N7002KDWH_SOT363-6

HDMIDAT_R

HDMI_DET HDMI_DET

HDMIDAT_R

HDMICLK_R HDMICLK_R

+5VS_HDMI

D3

1

1

2

2

4

4

5

3

3

8

AZ1045-04F_DFN2510P10E-10-9

@

9

10

8

9

7

7

6

65

HDMIDAT_R

+5VS_HDMI

For EMC

For EMC

C C

B B

HDMI_CLK-_C

HDMI_CLK+_C

HDMI_TX0-_C

HDMI_TX0+_C

HDMI_TX1-_C

HDMI_TX1+_C

HDMI_TX2-_C

HDMI_TX2+_C

1 2

R29 470_0402_5%

1 2

R30 470_0402_5%

1 2

R31 470_0402_5%

1 2

R32 470_0402_5%

1 2

R33 470_0402_5%

1 2

R34 470_0402_5%

1 2

R37 470_0402_5%

1 2

R38 470_0402_5%

+3VS

1 2

R42

100K_0402_5%

+3VS

R35

1M_0402_5%

13

D

2

G

@

Q13

2N7002KW_SOT323-3

S

HDMI_HPD{4}

HDMI_CLK-{4}

HDMI_CLK+{4}

HDMI_TX0-{4}

HDMI_TX0+{4}

HDMI_TX1-{4}

HDMI_TX1+{4}

HDMI_TX2-{4}

HDMI_TX2+{4}

G

2

1 2

S

2N7002KW_SOT323-3

Q12

13

D

HDMI_CLK-

HDMI_CLK+
HDMI_TX0-

HDMI_TX0+
HDMI_TX1-

HDMI_TX1+
HDMI_TX2-

HDMI_TX2+

+5VS

3

D4

BAT54S-7-F_SOT23-3

1

D4

R41
20K_0402_5%

1 2

12

C35 .1U_0402_10V6-K

12

C36 .1U_0402_10V6-K

12

C37 .1U_0402_10V6-K

12

C38 .1U_0402_10V6-K

12

C39 .1U_0402_10V6-K

12

C40 .1U_0402_10V6-K

12

C41 .1U_0402_10V6-K

12

C42 .1U_0402_10V6-K

2

@

HDMI_DET

SUSP{46}

+5VS

HDMI_CLK-_C

HDMI_CLK+_C
HDMI_TX0-_C

HDMI_TX0+_C
HDMI_TX1-_C

HDMI_TX1+_C
HDMI_TX2-_C

HDMI_TX2+_C

D5

2

3

RB491D_SOT23-3

@

Q22

1 3

D

2

R43 0_0402_5%@

R44 0_0402_5%@
R45 0_0402_5%@

R46 0_0402_5%@
R47 0_0402_5%@

R48 0_0402_5%@
R49 0_0402_5%@

R50 0_0402_5%@

1

S

LP2301ALT1G_SOT23-3

G

HDMIDAT_R
HDMICLK_R

12

12
12

12
12

12
12

12

F1

0.5A_8V_KMC3S050RY

R39

2.2K_0402_5%

1 2

HDMI_CLK-_CON

HDMI_CLK+_CON
HDMI_TX0-_CON

HDMI_TX0+_CON
HDMI_TX1-_CON

HDMI_TX1+_CON
HDMI_TX2-_CON

HDMI_TX2+_CON

21

+5VS_HDMI+5VS_HDMI_F

R40

2.2K_0402_5%

1 2

1

C34
.1U_0402_10V6-K

2

JHDMI1

19

HP_DET

18

+5V

17

DDC/CEC_GND

16

SDA

15

SCL

14

Reserved

13

CEC

12

CK-

11

CK_shield

10

CK+

9

D0-

8

D0_shield

7

D0+

6

D1-

5

D1_shield

4

D1+

3

D2-

2

D2_shield

1

D2+

FOX_QJ111A1-RC0AH1-8H

ME@

GND1
GND2

GND3
GND4

20
21

22
23

Close to JHDMI1

D6

1

1

HDMI_CLK-_CON HDMI_CLK-_CON

A A

2

2

4

4

5

3

3

8

AZ1045-04F_DFN2510P10E-10-9

@

5

9

HDMI_CLK+_CONHDMI_CLK+_CON

10

8

9

7

HDMI_TX0+_CONHDMI_TX0+_CON

7

6

65

HDMI_TX1-_CON

HDMI_TX1+_CON

HDMI_TX2-_CON

HDMI_TX2+_CONHDMI_TX0-_CON HDMI_TX0-_CON

For EMC

D7

1

1

2

2

4

4

5

3

3

8

AZ1045-04F_DFN2510P10E-10-9

@

4

9

10

8

9

7

7

6

65

HDMI_TX1-_CON

HDMI_TX1+_CON

HDMI_TX2-_CON

HDMI_TX2+_CON

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

Title

Title

HDMI_CONN

HDMI_CONN

HDMI_CONN

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

34 59

34 59

1

34 59

1.0

1.0

1.0

5

4

3

2

1

+3VS_DVGA+3VS +3VS_DVGA +3VS_DVGA

RVG1

@

1 2

0_0603_5%

CVG1

.47U_0402_6.3V6K

D D

+1.5VS

RVG2

@

1 2

0_0603_5%

1

CVG9

4.7U_0603_6.3V6K

C C

B B

VFB=0.8V
Vo=VFB*(1+RVG3/RVG5)
OCP:Min 4A

VGA_TX0-{4}
VGA_TX0+{4}
VGA_TX1-{4}
VGA_TX1+{4}

VGA_AUX#{4}
VGA_AUX{4}

VGA_HPD{4}

CVG30

.1U_0402_10V6-K

2

SUSP#{44,46,55,56,57}

1 2

CVG15 .1U_0402_10V6-K

1 2

CVG16 .1U_0402_10V6-K

1 2

CVG17 .1U_0402_10V6-K

1 2

CVG18 .1U_0402_10V6-K

1 2

CVG19 .1U_0402_10V6-K

1 2

CVG20 .1U_0402_10V6-K

1 2

RVG11 1K_0402_5%

1

2

LVG1

1

2

1U_0402_10V6K

+1.5VS_VIN

+3VS_DVGA

1 2

PBY160808T-331Y-N

CVG7

RVG4

1 2

10K_0402_5%

CVG14

.1U_0402_10V6-K

12

RVG13
10K_0402_5%

1

CVG31
1U_0402_6.3V6K

2

1

2

DRX0N
DRX0P
DRX1N
DRX1P
AUXN
AUXP

DP_HPD

1

2

CVG26

1

2

1 2

LVG2

PBY160808T-331Y-N

12

RVG3
10K_0402_1%

12

RVG5
20K_0402_1%

VGA_SDA
RVGA

RVG126.65K_0402_1%

REXT

RVG104.99K_0402_1%

VDDA33
VDD33

VDD12
XTLO
XTLI
AUXN
AUXP
DP_HPD
VDDRX
DRX0P
DRX0N

DRX1P

CVG27

1

DRX1N
RST#
PD#RST# PD# CFG

2

.01U_0402_16V7-K

1

CVG4
1U_0402_6.3V6K

2

+1.2VS

1

CVG8
10U_0603_6.3V6M

2

UVG2

1

VGA_SDA

2

RVGA

3

REXT

4

VDDA33

5

VDD33

6

GND1

7

VDD12_1

8

XTLO

9

XTLI

10

AUXN

11

AUXP

12

DP_HPD

13

VDDRX

14

DRX0p

15

DRX0n

16

GND2

17

DRX1p

18

DRX1n

19

RST#

20

PD#

41

EPAD

PS8613TQFN40GTR2-A1_TQFN40_5X5

.47U_0402_6.3V6K

+1.2VS

+1.35VS

VGA_SCL

GNDVGA3

GNDVGA2

VDD33VGA

GNDVGA1

VGA_HS

VGA_VS

TESTMODE

GPIO3/TSCK_O

VDD12_2

GPIO2/INTRQ

CVG5

1 2

RVG34 0_0603_5%

1 2

RVG35 0_0603_5%@

40
39

RED

38
37

GREEN

36
35
34

BLUE

33
32
31
30

GPIO1

29
28

CSDA

27

CSCL

26
25
24

GPIO0

23

GND3

22
21

CFG

VDD33 VDDA33 VDD33VGA

1

CVG2
1U_0402_6.3V6K

2

+5VALW

6
5
9

8

EN

7

POK FB

12

RVG6
100K_0402_5%

1

@

2

+3VS

CVG22

1

2

.1U_0402_10V6-K

UVG1

.1U_0402_10V6-K

VCNTL
VIN1
VIN2

EN
POK

CVG23

1

2

CVG3

.47U_0402_6.3V6K

3

VOUT1

4

VOUT2

2

FB

GND

APL5930KAI-TRG_SO8

1

CVG24

CVG25

1

1

2

2

.1U_0402_10V6-K

.01U_0402_16V7-K

CD@

1 2
1 2

.1U_0402_10V6-K

1 2

LVG3

PBY160808T-331Y-N

1

2

+1.35VS_DVGA

CVG10

.47U_0402_6.3V6K

CSDA

CSCL

1 2

RVG7 4.7K_0402_5%

1 2

RVG8 4.7K_0402_5%

VGA_SCL
RED

GREEN

VDD33VGA
BLUE

VGA_HS
VGA_VS
GPIO1

CSDA
CSCL
GPIO3/TSCK_O
VDD12
GPIO0

GPIO2/INTRQ

1

CVG6

4.7U_0603_6.3V6K

2

1 2

LVG4

PBY160808T-331Y-N

1

2

+3VS_DVGA

1 2

CVG21 .1U_0402_10V6-K

VGA_HS {36}
VGA_VS {36}
GPIO1 {36}

1

TVG1 PAD @

1

TVG2 PAD @

.01U_0402_16V7-K

5VS_GATE{46}

CVG28

1

2

1

2

4.7U_0603_6.3V6K

1

CVG51

2

@

RVG36

VDD12 VDDRX

CVG11
1U_0402_6.3V6K

Initial code loading selection, internal pull down ~80kΩ:
L: Loading initial code from internal MTP ROM
H: No initial code loading, external I2C control is expected

CVG29

1

2

.1U_0402_10V6-K

CD@

Needopen

QVG1

8
7
6
5

1 2

@

10K_0402_5%

.47U_0402_6.3V6K

CFG

JVG1

112

JUMP_43X39

RVG9 4.7K_0402_5%@

+1.35VS+1.35V

@

2

1

CVG46

4.7U_0603_6.3V6K

@
1
2
3

AP4800BGM-HF_SO-8@

4

1

CVG48

.1U_0402_10V6-K

@

2

+1.35VS_DVGA

CVG12

1 2

1

2

2

1 2

LVG5

PBY160808T-331Y-N

+3VS_DVGA

+3VS_DVGA

GPIO3/TSCK_O

I2C address, 3-state inputs:
L: 0x50h ~ 0x6Fh
M: 0x90h ~ 0xAFh
H: 0x30h ~ 0x4Fh

RVG14

4.7K_0402_5%

@

1 2

RVG15

4.7K_0402_5%

@

1 2

1

CVG47

.1U_0402_10V6-K

@

2

1

CVG13
1U_0402_6.3V6K

2

RED

1 2

RVG16 1M_0402_5%

YVG1

XTLI

A A

15P_0402_50V8J

CVG32

1

2

1

27MHZ_10PF_7V27000050

5

OSC1

GND12OSC2

GND2

4

3

XTLO

1

CVG33
12P_0402_50V8-J

2

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

GREEN

BLUE

VGA_SCL

VGA_SDA

3

1 2

RVG17 10_0402_5%

1 2

RVG18 10_0402_5%

1 2

RVG20 10_0402_5%

1 2

RVG23 0_0402_5%

@

1 2

RVG24 0_0402_5%

@

LC Future Center Secret Data

LC Future Center Secret Data

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

CRT_R {36}

CRT_G {36}

CRT_B {36}

CRT_DDC_CLK {36}

CRT_DDC_DAT {36}

2013/08/05

2013/08/05

2013/08/05

2

Title

Title

Title

DP to CRT Converter(PS8613)

DP to CRT Converter(PS8613)

DP to CRT Converter(PS8613)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

35 59

35 59

1

35 59

1.0

1.0

1.0

5

4

3

2

1

CRT Connector

FVG1

21

1

2

12

RVG42
0_0402_5%

@

HSYNC_CONCRT_HSYNC_R

CVG42
15P_0402_50V8J

VSYNC_CON

CVG45
15P_0402_50V8J

+CRT_VCC_CON

+CRT_VCC_CON

@

1

CVG34
.1U_0402_10V6-K

2

CD@

JCRT1

6

11

1
7

12

2
8

13

3
9

14

4
10
15

5

SUYIN_070546HR015M25KZR

ME@

1 2

16

G

17

G

RVG39

+5VS

2

@

D D

3

PMEG2010ET_SOT23-3

DVG1

+CRT_VCC

1

0.5A_8V_KMC3S050RY

W=40mils

1

CRT_DET#

+3VS_DVGA

RVG28

LVG9

LVG10

TVG3PAD@

12

RVG29

1 2

BLM18BA100SN1D

1 2

BLM18BA100SN1D

CRT_R_CON

CRT_DDC_DAT
CRT_G_CON

HSYNC_CON
CRT_B_CON

VSYNC_CON

CRT_DDC_CLK

100P_0402_50V8J

1 2

@

0_0402_5%

CVG41

@

1

2

1

2

1 2

5P_0402_50V8-C

CVG36

1

2

5P_0402_50V8-C

CVG37

LVG6

BLM18BA100SN1D

LVG7

BLM18BA100SN1D

LVG8

BLM18BA100SN1D

1 2

1 2

CRT_DDC_DAT{35}

3.3P_0402_50V8-C

3.3P_0402_50V8-C

3.3P_0402_50V8-C

CVG38

1

1

2

2

CVG39

CVG40

1

2

CRT_DDC_CLK{35}

CRT_R{35}

CRT_G{35}

CRT_B{35}

12

RVG25
75_0402_1%

12

RVG26
75_0402_1%

12

RVG27
75_0402_1%

5P_0402_50V8-C

CVG35

1

1

2

2

CLOSE TO UVG1

C C

+5VS

CVG49

1 2

RVG40
0_0402_5%

@

1 2

1 2

VGA_HS{35}

B B

VGA_VS{35}

RVG43 0_0402_5%

@

RVG47
0_0402_5%

@

1 2

1 2

RVG45 0_0402_5%

@

.1U_0402_10V6-K

CVG50

1 2

.1U_0402_10V6-K

@

@

RVG37

1 2

1K_0402_5%

1

5

P

4

OE#

A2Y

G

UVG3
74AHCT1G125GW_SOT353-5

3

@

+5VS

RVG38

1 2

1K_0402_5%

1

5

P

4

OE#

A2Y

G

UVG4
74AHCT1G125GW_SOT353-5

3

@

@

CRT_HSYNCVGA_HS

@

CRT_VSYNCVGA_VS

1 2

RVG44 0_0402_5%

@

1 2

RVG48 0_0402_5%

@

RVG41
0_0402_5%

@

1 2

1 2

1 2

RVG32 33_0402_5%

RVG46
0_0402_5%

@

1 2

RVG33 33_0402_5%

4.7K_0402_5%

GPIO1{35}

CRT_VSYNC_R

@

0_0603_5%

For EMC

RVG30

2.2K_0402_5%

CVG43

100P_0402_50V8J

+5VS_HDMI

1

DVG2

1

AZ5425-01F_DFN1006P2E2

@

2

2

+5VS

1 2

1

2

@

RVG31

2.2K_0402_5%

1 2

1

CVG44
68P_0402_50V8J

2

@

CRT_DDC_CLK

CRT_DDC_DAT

DVG3

1

CRT_B_CON

CRT_G_CON CRT_G_CON

CRT_R_CON

CRT_DET# CRT_DET#

A A

1

2

2

4

4

5

3

3

8

AZ1045-04F_DFN2510P10E-10-9

@

5

10

9

7

65

9

CRT_B_CON

8

7

CRT_R_CON

6

VSYNC_CON

HSYNC_CON

CRT_DDC_CLK

CRT_DDC_DAT

For EMC

DVG4

1

1

2

2

4

4

5

3

3

8

AZ1045-04F_DFN2510P10E-10-9

@

4

9

10

8

9

7

7

6

65

VSYNC_CON

HSYNC_CON

CRT_DDC_CLK

CRT_DDC_DAT

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

Title

Title

CRT

CRT

CRT

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

36 59

36 59

1

36 59

1.0

1.0

1.0

5

4

3

2

1

+3VALWTO+3VALW_LAN

+3VALW_LANrisingtime(10%~90%):

+3VALW +3VALW_LAN

D D

LAN_PWR_ON#{44}

PCIE_WAKE#{8,9,40,44}

+3VS

12

12

LAN_WAKE#{40,44}

RL9
1K_0402_1%

RL11
15K_0402_5%

@

C C

RL2

100K_0402_5%

RL10

+3VALW

12

@

1 2

0_0402_5%

@

1 2

RL3

@

47K_0402_5%

1 2

RL7 0_0402_5%@

1 2

RL6 0_0402_5%

LAN_PWR_ON#ISOLATE#

.1U_0402_10V6-K

+3VALW_LAN

1

CL8

2
@

RL5
10K_0402_5%

@

1 2

Needshort

JL1

112

JUMP_43X79

LP2301ALT1G_SOT23-3

S

Q14

G

2

PCIE_WAKE#_R

PCIE_PRX_DTX_N3{9}
PCIE_PRX_DTX_P3{9}

2

@

D

13

@

CL9

@

PLT_RST#{8,40,44}

0.5ms＜spec＜100ms

width:40mils

1

CL4

1

2

.01U_0402_16V7-K

ClosetoPin11 ClosetoPin32

CL10closetoPin18
CL11closetoPin17

CL5

2

4.7U_0603_6.3V6K

RL8

1 2

@

0_0402_5%

1 2
1 2

@

1 2

2.49K_0402_1%

@

RL12

CL10 .1U_0402_10V6-K
CL11 .1U_0402_10V6-K

1

2

TL3 @

TL4 @

1

CL6

2

4.7U_0603_6.3V6K

.1U_0402_10V6-K

ClosetoPin11 ClosetoPin32

+3VALW_LAN
RSET
+LAN_VDD10
LAN_XTALO
LAN_XTALI

1

LAN_DISABLE#LAN_PWR_ON#

1

+LAN_REGOUT
+LAN_VDDREG
+LAN_VDD10
PCIE_WAKE#_R
ISOLATE#
PLT_RST#
PCIE_PRX_C_DTX_N3
PCIE_PRX_C_DTX_P3

1

CL7

2

.1U_0402_10V6-K

UL1

33

GND

32

AVDD33_2

31

RSET

30

AVDD10

29

CKXTAL2

28

CKXTAL1

27

LED0

26

LED1/GPIO

25

LED2

24

REGOUT

23

VDDREG

22

DVDD10

21

LANWAKEB

20

ISOLATEB

19

PERSTB

18

HSON

17

HSOP

RTL8111GUL-CG_QFN32_4X4

GIGA@

+3VALW_LAN +LAN_VDDREG

RL1

@

1 2

0_0603_5%

16

REFCLK_N

REFCLK_P

HSIN
HSIP

CLKREQB

AVDD33_1

MDIN3

MDIP3

AVDD10_2

MDIN2

MDIP2

MDIN1

MDIP1

AVDD10_1

MDIN0

MDIP0

CLK_PCIE_LAN#

15

CLK_PCIE_LAN

14

PCIE_PTX_C_DRX_N3

13

PCIE_PTX_C_DRX_P3

12

LAN_CLKREQ#_R

11

+3VALW_LAN

10

LAN_MDI3-

9

LAN_MDI3+

8

+LAN_VDD10

7

LAN_MDI2-

6

LAN_MDI2+

5

LAN_MDI1-

4

LAN_MDI1+

3

+LAN_VDD10

2

LAN_MDI0-

1

LAN_MDI0+

1

CL1

4.7U_0603_6.3V6K

2

LAN_CLKREQ#_R

CLK_PCIE_LAN# {8}
CLK_PCIE_LAN {8}
PCIE_PTX_C_DRX_N3 {9}
PCIE_PTX_C_DRX_P3 {9}

LAN_MDI3- {38}
LAN_MDI3+ {38}

LAN_MDI2- {38}
LAN_MDI2+ {38}
LAN_MDI1- {38}
LAN_MDI1+ {38}

LAN_MDI0- {38}
LAN_MDI0+ {38}

1

CL2
.1U_0402_10V6-K

2

CD@

+3VALW_LAN +3VS

RL4

10K_0402_5%

@

1 2

2

G

QL1

1 3

2N7002KW_SOT323-3

1 2

RL18 0_0402_5%

@

D

S

@

LAN_CLKREQ# {8}

B B

YL1

1

OSC1

GND12OSC2

1

CL12

10P_0402_50V8J

A A

5

25MHZ_10PF_7V25000014

2

GND2

4

3

LAN_XTALI

LAN_XTALO

1

CL13
10P_0402_50V8J

2

+LAN_REGOUT

4

ForRTL8111GUL/RTL8106EUL(SWRmode)

1 2

LL1

2.2UH_NLC252018T-2R2J-N_5%

4.7U_0603_6.3V6K

CL15

1

1

CL16
.1U_0402_10V6-K

2

2

CD@

+LAN_VDD10

1

2

CL17
.1U_0402_10V6-K

1

2

ClosetoPin3,8,22,30

LayoutNote:LL1mustbe
within200miltoPin36,
CL15,CL16mustbewithin
200miltoLL1
+LAN_REGOUT:Width=60mil

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

CL18
.1U_0402_10V6-K

2013/08/05

2013/08/05

2013/08/05

2

1

CL19
.1U_0402_10V6-K

2

1

CL20
.1U_0402_10V6-K

2

1

CL21
1U_0402_6.3V6K

2

@

1

CL22
.1U_0402_10V6-K

2

@

ClosetoPin22(Reserved)

Title

Title

Title

LAN_RTL8111GUL/RTL8106EUL

LAN_RTL8111GUL/RTL8106EUL

LAN_RTL8111GUL/RTL8106EUL

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

37 59

37 59

1

37 59

1.0

1.0

1.0

5

DL1/DL2
1'S PN:SC300003M00

4

3

2

1

TL1

24

D D

DL1

9
2

4

+3VALW_LAN

LAN_MDI2- LAN_MDI3-

C C

+3VALW_LAN

5

6

7

AZ3033-04F_DFN2525P10E10

DL2

9
2

4
5

6

7

AZ3033-04F_DFN2525P10E10

@

I/O4
NC1

NC2
VDD

NC3

I/O3

I/O4
NC1

NC2
VDD

NC3

I/O3

@

I/O2

NC5

GND

NC4

I/O1

I/O2

NC5

GND

NC4

I/O1

3

LAN_MDI3+LAN_MDI2+

10

11

8

1

3

10

11

8

1

LAN_MDI0+LAN_MDI1+

LAN_MDI0-LAN_MDI1-

1

CL24

2

68P_0402_50V8J

LAN_MDI0-{37}

LAN_MDI0+{37}

LAN_MDI1-{37}

LAN_MDI1+{37}

LAN_MDI2+{37}

LAN_MDI2-{37}

LAN_MDI3+{37}

LAN_MDI3-{37}

LAN_MDI0- LAN_MDO0-

LAN_MDI0+

LAN_MDI1- LAN_MDO1-

LAN_MDI1+

LAN_MDI2+

LAN_MDI2-

LAN_MDI3+

LAN_MDI3-

23

22

21

20

19

18

17

16

15

14

13

GST5009 LF

MCT1

MX1+

MX1-

MCT2

MX2+

MX2-

MCT3

MX3+

MX3-

MCT4

MX4+

MX4-

GIGA@

TCT1

TD1+

TD1-

TCT2

TD2+

TD2-

TCT3

TD3+

TD3-

TCT4

TD4+

TD4-

1

2

3

4

5

6

7

8

9

10

11

12

MCT

LAN_MDO0+

MCT

LAN_MDO1+

MCT

LAN_MDO2+

LAN_MDO2-

MCT

LAN_MDO3+

LAN_MDO3-

0.022U_0603_50V7K

CL32

12

1

2

CHASSIS1_GND

RL17
20_0603_5%

1

CL25
1000P_1206_2KV7-K

2

@

1

DL3

1

BS4200N-C-LV_SMB-F2

2

2

Place Close to TL1

JRJ1

B B

RL14

RL15

RL16

@

@

0_0603_5%

@

0_0603_5%

0_0603_5%

CHASSIS1_GND

1 2

1 2

1 2

Reserve for EMI go rural solution

LAN_MDO0+

LAN_MDO0-

LAN_MDO1+

LAN_MDO2+

LAN_MDO2-

LAN_MDO1-

LAN_MDO3+

LAN_MDO3-

1

PR1+

2

PR1-

3

PR2+

4

PR3+

5

PR3-

6

PR2-

7

PR4+

8

PR4-

SANTA_130460-3

ME@

GND_4

GND_3

GND_2

GND_1

12

11

10

9

CHASSIS1_GND

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

2013/08/08

2013/08/08

2013/08/08

3

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2013/08/05

2013/08/05

2013/08/05

2

Title

LAN_Transformer

LAN_Transformer

LAN_Transformer

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

B

B

B

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

1

of

of

of

38 59

38 59

38 59

1.0

1.0

1.0

5

D D

4

3

2

1

Close to U1

SMSC thermal sensor
placed near DIMM

U1

1

VDD

2

D+

3

D-

12

@

4

T_CRIT#

NCT7718W_MSOP8

Address 1001_100xb

SCL

SDA

ALERT#

GND

8

EC_SMB_CK2

7

EC_SMB_DA2

6

5

EC_SMB_CK2 {7,44}

EC_SMB_DA2 {7,44}

REMOTE2+

100P_0402_50V8J

REMOTE2-

C46

1

Near CPU core

C

2

Q16

B

@

2

MMBT3904WH_SOT323-3

E

3 1

2200P_0402_50V7K

C44

1

2

REMOTE+_R

REMOTE-_R

.1U_0402_10V6-K

CD@

C47

+3VS

R51

REMOTE+_R

REMOTE-_R

10K_0402_5%

1

2

+3VS

C C

REMOTE2+

REMOTE2-

1 2

R176 0_0402_5%@

1 2

R177 0_0402_5%@

REMOTE+_R

REMOTE-_R

REMOTE+/-_R, REMOTE1+/-, REMOTE2+/-:
Trace width/space:10/10 mil
Trace length:<8"

FAN Conn

B B

C49

10U_0805_10V6K

+5VS

R52

1 2

1

2

@

0_0603_5%

.1U_0402_10V6-K

C50

+5VS_FAN

1

@

2

EC_FAN_SPEED{44}
EC_FAN_PWM{44}

JFAN1

1

1

2

2

3

3

4

4

5

GND1

6

GND2

ACES_85205-04001

ME@

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

2013/08/08

2013/08/08

2013/08/08

3

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2013/08/05

2013/08/05

2013/08/05

2

Title

Thermal sensor/FAN CONN

Thermal sensor/FAN CONN

Thermal sensor/FAN CONN

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet of

Date: Sheet of

Date: Sheet of

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

1

39 59

39 59

39 59

1.0

1.0

1.0

A

B

Mini-Express Card(WLAN/WiMAX)

C

+3VS_WLAN

D

E

Needshort

+3VS

+3VALW

1 1

.1U_0402_10V6-K

1 2

R54

AOAC_ON#{44}

2 2

WLAN_CLKREQ#{8}

AOAC@

100K_0402_5%

If support AOAC, NC R61;
if not support AOAC, stuff R61.

1

C51

@

2

1

2

+3VS

G

2

AOAC@

S

2N7002KW_SOT323-3

1 2

R61 0_0402_5%

@

J2

112

JUMP_43X79

LP2301ALT1G_SOT23-3

D

S

13

Q17

G

2

C54
.1U_0402_10V6-K

AOAC@

+3VS_WLAN

R60

Q18

10K_0402_5%

1 2

13

D

AOAC@

AOAC@

@

2

.01U_0402_16V7-K

1

C52

@

2

WLAN_CLKREQ_Q#

+3VS_WLAN

1

2

PCIE_WAKE#{8,9,37,44}

LAN_WAKE#{37,44}

C53
.1U_0402_10V6-K

AOAC@

PCIE_PTX_C_DRX_P4{9}
PCIE_PTX_C_DRX_N4{9}

PCIE_PRX_DTX_P4{9}
PCIE_PRX_DTX_N4{9}

CLK_PCIE_WLAN{8}
CLK_PCIE_WLAN#{8}

R57 0_0402_5%@

USB20_P6{9}
USB20_N6{9}

WLAN_CLKREQ_Q#

1 2

JWLAN1

1

GND1

3

USB_D+

5

USB_D-

7

GND2

9

NC

11

NC

13

NC

15

NC

17

MLDIR_SENSE

19

DP_ML3N

21

DP_ML3P

23

GND3

25

DP_ML2N

27

DP_ML2P

29

GND4

31

DP_HPD

33

GND5

35

PETP0

37

PETN0

39

GND6

41

PERP0

43

PERN0

45

GND7

47

REFCLKP0

49

REFCLKN0

51

GND8

53

CLKREQ0#

55

PEWAKE0#

57

GND9

59

PETP1

61

PETN1

63

GND10

65

PERP1

67

PERN1

69

GND11

71

REFCLKP1

73

REFCLKN1

75

GND12

76

PEG1

JAE_SM3ZS067U410BAR1000

ME@

3.3VAUX1

3.3VAUX2

DP_AUXN
DP_AUXP

RESERVED1
RESERVED2
RESERVED3

RESERVED/W_DISABLE#2

W_DISABLE#1

I2C_DATA

I2C_ALERT#

RESERVED4

CLKREQ1#

PEWAKE1#

3.3VAUX4

3.3VAUX5

LED#1

NC
NC
NC
NC

LED#2

GND16

GND13
DP_ML1N
DP_ML1P

GND14
DP_ML0N
DP_ML0P

GND15

COEX3

COEX2

COEX1

SUSCLK

PERST0#

I2C_CLK

PERST1#

PEG2

2
4
6

1

8
10
12
14

16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
68
70
72
74

77

T2@

1

T3@

EC_TX_RSVD EC_TX_R
EC_RX_RSVD BT_OFF#

SUSCLK_R
PLT_RST#
BT_OFF#
WLAN_OFF#
SMB_DATA_S3_R
SMB_CLK_S3_R

1

EC_TX_R

1 2

R62 0_0402_5%@

1 2

R63 0_0402_5%@

1 2

R55 0_0402_5%

1 2

R53 1K_0402_5%

1 2

R56 0_0402_5%

1 2

R58 0_0402_5%@

1 2

R59 0_0402_5%@

T4@

+3VS_WLAN

@

@

SUSCLK {8}
PLT_RST# {8,37,44}
PCH_BT_OFF# {9}
PCH_WLAN_OFF# {9}
SMB_DATA_S3 {7,14,15}
SMB_CLK_S3 {7,14,15}

EC_TX_R

R184 100_0402_1%

BT_OFF#

R185 100_0402_1%

12

R186
100K_0402_5%

1 2

1 2

EC_TX {44}

EC_RX {44}

3 3

4 4

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

A

B

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

C

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

D

2013/08/05

2013/08/05

2013/08/05

Title

NGFF WLAN

NGFF WLAN

NGFF WLAN

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

40 59

40 59

40 59

of

of

E

of

1.0

1.0

1.0

A

LEFT SIDE USB3.0 PORT X2

+5VALW

1 1

2.2U_0603_10V6-K

1 2

C58

USB_ON#{44,45}

USB_ON# USB_OC1#

U2

1

GND

2

VIN1

3

VIN2

4

EN/EN

AP2820CMMTR-G1_MSOP8

VOUT3

VOUT2

VOUT1

FLAG

Low Active 2A

8

7

6

5

+USB_VCCA

1

C61
1000P_0402_50V7K

@

2

B

USB_OC1# {9}

C

USB20_N2{9}
USB20_P2{9}

D

1 2

R65 0_0402_5%@

1 2

R64 0_0402_5%@

E

+USB_VCCA

+

1 2

C55

220U_6.3V_M

1 2

C56

1U_0603_25V6M@

1 2

C57

470P_0402_50V7K@

JUSB1

1

USB20_N2_RUSB20_N2
USB20_P2_RUSB20_P2

2

3

4

ME@

VBUS
D­D+
GND

GND1
GND2
GND3
GND4

C-K_20267-5K11-02

5
6
7
8

USB20_P2_R

USB20_N2_R

1

D9

1

2 2

2

@

2

AZ5425-01F_DFN1006P2E2

L8

USB20_P2

USB20_N2 USB20_N2_R

3 3

4 4

USB30_RX_N1

USB30_TX_C_N1

USB30_TX_C_P1

USB20_N1

USB20_P1

For EMC

1

1

4

4

CMM21T-900M-N_4P

L9

3

3

2

2

DLW21SN900HQ2L_4P

L10

3

3

2

2

DLW21SN900HQ2L_4P

L11

1

1

4

4

CMM21T-900M-N_4P

A

2

2

3

3

4

USB30_RX_R_N1

4

1

USB30_RX_R_P1USB30_RX_P1

1

4

USB30_TX_R_N1

4

1

USB30_TX_R_P1

1

2

2

3

3

USB20_P2_R

USB20_N1_R

USB20_P1_R

USB30_RX_R_N1

USB30_RX_R_P1

USB30_TX_R_P1

For EMC

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

B

D12

9

10

8

9

7

7

6

6 5

AZ1045-04F_DFN2510P10E-10-9

USB30_TX_P1{9}

USB30_TX_N1{9}

USB20_P1{9}

USB20_N1{9}

USB30_RX_P1{9}

USB30_RX_N1{9}

@

1

USB30_RX_R_N1

1

2

USB30_RX_R_P1

2

4

USB30_TX_R_N1USB30_TX_R_N1

4

5

USB30_TX_R_P1

3

3

8

1 2

C64 .1U_0402_10V6-K

1 2

C65 .1U_0402_10V6-K

USB20_N1 USB20_N1_R

USB30_RX_N1 USB30_RX_R_N1

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

2013/08/08

2013/08/08

2013/08/08

C

USB20_P1_R

USB20_N1_R

Deciphered Date

Deciphered Date

Deciphered Date

1

D13

1

2

@

2

AZ5425-01F_DFN1006P2E2

USB30_TX_C_P1USB30_TX_P1 USB30_TX_R_P1

1

D10

1

2

@

2

AZ5425-01F_DFN1006P2E2

1

D14

1

2

@

2

AZ5425-01F_DFN1006P2E2

R68 0_0402_5%@

R69 0_0402_5%@
R70 0_0402_5%@

R71 0_0402_5%@
R72 0_0402_5%@

R73 0_0402_5%@

2013/08/05

2013/08/05

2013/08/05

1 2

1 2
1 2

1 2
1 2

1 2

D

+USB_VCCA

1

D11

1

2

@

2

AZ5425-01F_DFN1006P2E2

+USB_VCCA

1 2

C62

1U_0603_25V6M@

1 2

C63

470P_0402_50V7K@

JUSB2

9

StdA_SSTX+

1

VBUS

USB30_TX_R_N1USB30_TX_C_N1USB30_TX_N1
USB20_P1_RUSB20_P1

USB30_RX_R_P1USB30_RX_P1

Title

Title

Title

USB2.0/USB3.0 PORT (LEFT)

USB2.0/USB3.0 PORT (LEFT)

USB2.0/USB3.0 PORT (LEFT)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

8

StdA_SSTX-

3

D+

7

GND_DRAIN

2

D-

6

StdA_SSRX+

4

GND_5

5

StdA_SSRX-

SUYIN_020053GR009M2736L

UMA

UMA

UMA

E

ME@

GND_1
GND_2
GND_3
GND_4

41 59

41 59

41 59

10
11
12
13

of

of

of

1.0

1.0

1.0

A

B

C

D

E

F

G

H

SATA HDD Conn.

JHDD1

1

SATA_PTX_DRX_P0{7}

1 1

2 2

SATA_PTX_DRX_N0{7}

SATA_PRX_DTX_N0{7}

SATA_PRX_DTX_P0{7}

+5VS_HDD

1

C74
1000P_0402_50V7K

CD@

2

SATA_PTX_DRX_P0
SATA_PTX_DRX_N0

SATA_PRX_DTX_P0

1

C75
.1U_0402_10V6-K

2

1 2

C66 .01U_0402_16V7-K

1 2

C67 .01U_0402_16V7-K

1 2

C68 .01U_0402_16V7-K

1 2

C69 .01U_0402_16V7-K

+5VS +5VS_HDD

1

C76
1U_0402_10V6K

CD@

2

Needshort

1

C77
10U_0805_10V6K

2

J3

@

112

JUMP_43X79

SATA_PTX_C_DRX_P0
SATA_PTX_C_DRX_N0

SATA_PRX_C_DTX_N0SATA_PRX_DTX_N0
SATA_PRX_C_DTX_P0

2

1

C78
10U_0805_10V6K

@

2

2
3
4
5
6
7

8

9
10
11
12
13
14
15
16
17
18
19
20
21
22

SUYIN_127043HR022M32QZR

GND_1
A+
A­GND_2
B­B+
GND_3

V33_1
V33_2
V33_3
GND_4
GND_5
GND_6
V5_1
V5_2
V5_3
GND_7
DAS/DSS
GND_8
V12_1
V12_2
V12_3

ME@

SATA_PTX_DRX_P1{7}
SATA_PTX_DRX_N1{7}

SATA_PRX_DTX_N1{7}

SATA_PRX_DTX_P1{7}

SATA_PTX_DRX_P1
SATA_PTX_DRX_N1

SATA_PRX_DTX_N1 SATA_PRX_C_DTX_N1_14
SATA_PRX_DTX_P1

1 2

C70 .01U_0402_16V7-K14@

1 2

C71 .01U_0402_16V7-K14@

1 2

C72 .01U_0402_16V7-K14@

1 2

C73 .01U_0402_16V7-K14@

SATA_PTX_C_DRX_P1_14
SATA_PTX_C_DRX_N1_14

SATA_PRX_C_DTX_P1_14

ODD_DETECT#_R

+5V_ODD
ODD_DA#_R

For EMC

SATA_PTX_DRX_P1
SATA_PTX_DRX_N1

SATA_PRX_DTX_N1
SATA_PRX_DTX_P1

ODD_DETECT#{7}

NeedShort

J4

2

112

3 3

R75

10K_0402_5%

@

ODD_EN{9}

R81

100K_0402_5%

@

+5VS +5V_ODD+5VALW

12

1 2

12

R76
10K_0402_5%

@

1 2

ODD_EN#

100K_0402_5%

13

D

Q20

2

G

S

2N7002KW_SOT323-3

@

@

C83

@

R78

LP2301ALT1G_SOT23-3

1

2

.1U_0402_10V6-K

JUMP_43X79

D

S

13

G

2

@

1

2

Q19

1

C84

2

@

C87
.01U_0402_16V7-K

@

1

2

.01U_0402_16V7-K

C85

ODD_EN#

1

2

C86

10U_0805_10V6K

CD@

.1U_0402_10V6-K

Q21

2

G

12

13

D

S

2N7002KW_SOT323-3@

R79
470_0603_5%

@

ODD_DA#{9}

ODD_DA_EC#{44}

1 2

C79 .01U_0402_16V7-K15@

1 2

C80 .01U_0402_16V7-K15@

1 2

C81 .01U_0402_16V7-K15@

1 2

C82 .01U_0402_16V7-K15@

1 2

R74 0_0402_5%@

0_0402_5%

1 2

R80 0_0402_5%@

1 2

R86 0_0402_5%@

R92

@

1 2

SATA_PTX_C_DRX_P1_15
SATA_PTX_C_DRX_N1_15

SATA_PRX_C_DTX_N1_15
SATA_PRX_C_DTX_P1_15

ODD_DETECT#_R

+5V_ODD
ODD_DA#_R

1

C135

2

@

100P_0402_50V8J

+3VS

12

R77
10K_0402_5%

@

ODD_DA#_R

FOR14"

SATAODDConn.

JODD1

1

GND_1

2

RX+

3

RX-

4

GND_2

5

TX-

6

TX+

7

GND_3

8

DP

9

+5V_1

10

+5V_2

11

MD

12

GND_4

13

GND_5

SUYIN_127382FB013S255ZL

ME@

GND1
GND2

14
15

FOR15"

SATAODDFFCConn

JODD2

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

GND_1

12

GND_2

ACES_51524-01001-003

ME@

4 4

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

A

B

C

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

D

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

E

F

2013/08/05

2013/08/05

2013/08/05

Title

HDD/ODD CONN

HDD/ODD CONN

HDD/ODD CONN

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

G

UMA

UMA

UMA

of

of

of

42 59

42 59

42 59

H

1.0

1.0

1.0

5

4

3

2

1

+3VS +1.5VS

+5VS

D D

DA1

1

2

CA16

4.7U_0603_10V6-K

2

3

BAT54CW_SOT323-3

5.11K_0402_1%

1 2

RA17

39.2K_0402_1%

1 2

RA36

20K_0402_1%

+5VD

CD@

2

2

CA19

CA18

1

1

.1U_0402_10V6-K

.1U_0402_10V6-K

1

RA15

BEEP#{44}

PCH_BEEP{9}

C C

PLUG_IN{45}

CD@

1

CA15

2

4.7U_0603_10V6-K

B B

Close to Pin11,13,16

RA24

HDA_RST_AUDIO#

EC_MUTE#{44}

A A

EC_MUTE#

5

RB751V-40_SOD323-2
DA3

RB751V-40_SOD323-2
DA4

RA35

1

CA37

2

@

100P_0402_50V8J

12

+3.3VD

1 2

JSENSE

1 2

@

0_0402_5%

1 2

1 2

1 2

0_0402_5%

1

CA38

2

@

RA2

1 2

RA7

1 2

RA10

1 2

.1U_0402_10V6-K

CA2

RA14
10K_0402_5%

@

@

100P_0402_50V8J

@

0_0603_5%

@

0_0603_5%

@

0_0603_5%

1 2

DMIC_CLK{33}
DMIC_DATA{33}

PC_BEEPPC_BEEP1

HDA_RST_AUDIO#{7}

HDA_BITCLK_AUDIO{7}

HDA_SYNC_AUDIO{7}

HDA_SDOUT_AUDIO{7}

+3.3VD

12

RA28
47K_0402_5%

@

SPKR_MUTE#

DMIC_CLK

DMIC_DATA

For EMI

HDA_SDIN0{7}

+3.3VD

+5VA

+5VD

+3VS

HDA_RST_AUDIO#

HDA_BITCLK_AUDIO

HDA_SYNC_AUDIO

33_0402_5%

HDA_SDOUT_AUDIO

1 2

RA1833_0402_5%

@

RA16

1 2

12

RA190_0402_5%

+5VD

1 2

CA14 1U_0402_6.3V6K

1 2

CA17 2.2U_0603_6.3V6K

GND GNDA

CA23

1

1

CA22

2

2

@

68P_0402_50V8J

4

22P_0402_50V8-J

22P_0402_50V8-J

1 2

RA8 0_0402_5%@

1 2

RA11 0_0402_5%

@

UA1

9

RESET#

5

BIT_CLK

8

SYNC

RA27

1

2

6

SDATA_IN

4

SDATA_OUT

10

PC_BEEP

39

SPKR_MUTE#

38

JSENSE

37

GPIO1/PORTC_R_MIC

MUSIC_REQ/GPIO0/PORTC_L_MIC36MICBIASC

40

DMIC_CLK/MUSIC_REQ/GPIO0

1

DMIC_DAT/GPIO1

11

CLASS-D_REF

13

LPWR_5.0

16

RPWR_5.0

19

FLY_P

20

FLY_N

21

AVEE

41

GND

CX20752-21Z_QFN40_5X5

1 2

1 2

1 2

1 2

1 2

1 2

1 2

@

27_0402_5%

CA25

CA26

1

2

@

@

33P_0402_50V8J

CX20751-11Z

HDA_RST_AUDIO#

HDA_SYNC_AUDIO

HDA_SDOUT_AUDIO

HDA_BITCLK_AUDIO

HDA_SDIN0

SDATA_IN

PC_BEEP
SPKR_MUTE#

JSENSE

DMIC_CLK_R
DMIC_DATA_R

.1U_0402_10V6-K

1 2

CA13

RA1 0_0402_5%@

RA4 0_0402_5%@

RA6 0_0402_5%@

RA9 0_0402_5%@

RA12 0_0402_5%@

RA13 0_0402_5%@

Use 250mils wide trace bridging
AGND and DGND at codec

CA24

1

2

@

33P_0402_50V8J

For EMI

DVDD_IO

CA1

2

1

.1U_0402_10V6-K

+3VL

Close to Pin7

3

FILT_1.8V

7

VDD_IO

2

VDDO_3.3

18

DVDD_3.3

27

AVDD_3.3

29

VREF_1.65V

28

AVDD_5V

12

LEFT+

14

LEFT-

17

RIGHT+

15

RIGHT-

35
34

MICBIASB

HGNDA
HGNDB

AVDD_HP

PORTA_R

PORTA_L

2

CA27

1

220P_0402_50V7K

CD@

220P_0402_50V7K

CD@

2

CA28

1

33
32

30
31

25
26

24

23
22

2

CA29

1

220P_0402_50V7K

CD@

2013/08/08

2013/08/08

2013/08/08

PORTB_R_LINE

PORTB_L_LINE

PORTD_A_MIC
PORTD_B_MIC

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

+3VS

+3VALW

1 2

RA3 0_0603_5%@

1 2

RA5 0_0603_5%@

1 2

RA43 0_0603_5%

Close to Pin3

2

1

1

2

CA3

.1U_0402_10V6-K

CA4

FILT_1.8V
DVDD_IO

AVDD_3.3
VREF_1.65V
+5VA

SPK_L+
SPK_L-

SPK_R+
SPK_R-

MICBIASB

LINE_B_R
LINE_B_L

PORTD_A_MIC
PORTD_B_MIC

RING2_CONN
RING3_CONN

AVDD_HP

HPOUT_R
HPOUT_L

Stuff DA2 to prevent
cross-talk between
HPOUT_R/L,if NC
DA2,RA37/RA38 need change
to 2.2K.

2

CA30

1

220P_0402_50V7K

CD@

4.7U_0603_10V6-K

+3.3VD

MICBIASB

RA42

0_0402_5%

1 2
1 2
1 2
1 2

CD@
CD@
CD@

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

AVDD_HP

CA16 close to Pin18
CA17 close to Pin2

2

1

CA7

1

CD@

DA2
BAT54AWT1G_SOT323-3

12

@

RA37

RA2515_0402_5% CD@
RA2915_0402_5%
RA3215_0402_5%
RA3315_0402_5%

2

.1U_0402_10V6-K

1

12

3

2

3K_0402_1%

3K_0402_1%

12

12

RA38

PORTD_A_MIC
PORTD_B_MIC

SPK_R+

RA26 BLM18PG221SN1D_2P

SPK_R-

RA31 BLM18PG221SN1D_2P

SPK_L+

RA30 BLM18PG221SN1D_2P

SPK_L-

RA34 BLM18PG221SN1D_2P

2

CA8

1U_0402_6.3V6K

RA41
0_0402_5%

@

4.7U_0603_10V6-K

RA22

1 2
1 2

RA23

1 2
1 2
1 2
1 2

2013/08/05

2013/08/05

2013/08/05

RA39

100_0402_5%

CA35

100_0402_5%
100_0402_5%

+5VA

AVDD_HP

2

CA11

1

.1U_0402_10V6-K

Close to Pin28 Close to Pin24

Close to Pin27

1

2

1

2

1

CA32

CA6

2

2.2U_0603_6.3V6K

1

CA10

2

1U_0402_6.3V6K

HP_OUTR {45}
HP_OUTL {45}

RING3_CONN {45}
RING2_CONN {45}

JSPK1

1

1

2

2

3

3

4

4

5

GND1

6

GND2

470P_0402_50V7K

ACES_88231-04001

ME@

43 59

43 59

43 59

1

1

1

CA33

CA34

2

2

2

470P_0402_50V7K

470P_0402_50V7K

UMA

UMA

UMA

1

CA5

.1U_0402_10V6-K

CA9

.1U_0402_10V6-K

LINE_B_L

LINE_B_R

12

1

2

Close to Pin29

12

RA40
100_0402_5%

1

CA36

4.7U_0603_10V6-K

2

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

1 2

RA20 82.5_0402_1%

1 2

RA21 82.5_0402_1%

1 2

CA20 2.2U_0603_6.3V6K

1 2

CA21 2.2U_0603_6.3V6K

SPK_R+_CONN
SPK_R-_CONN
SPK_L+_CONN
SPK_L-_CONN

1

CA31

2

470P_0402_50V7K

Codec_CX20752

Codec_CX20752

Codec_CX20752

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

2

CA12

1

.1U_0402_10V6-K

1.0

1.0

1.0

of

of

of

5

ForESD

PLT_RST#

1

CE1
220P_0402_50V7K

2

D D

For EMI

CLK_PCI_EC

1 2

RE2 10_0402_5%@

10P_0402_50V8J

1

CE2

2

@

VCCRTC

Change RE6 to 0ohm jump

UMA: delete WRST# PORT

+3VALW_R

1 2

DE1

RE8 100K_0402_5%

C C

+3VALW_R

1 2

RE16 2.2K_0402_5%

1 2

RE17 2.2K_0402_5%

+3VS

1 2

RE20 2.2K_0402_5%

1 2

RE22 2.2K_0402_5%

B B

+3VL

RB751V-40_SOD323-2

1 2

H_PECI{5}

@

1

CE12
1U_0402_6.3V6K

2

KSI[0..7]{45}

KSO[0..17]{45}

EC_SMB_CK1

EC_SMB_DA1

EC_SMB_CK2

EC_SMB_DA2

1 2

RE24 43_0402_5%

+3VL

KBRST#{9}
SERIRQ{9}

LPC_FRAME#{7}

LPC_AD3{7}
LPC_AD2{7}
LPC_AD1{7}
LPC_AD0{7}

CLK_PCI_EC{8}

EC_SMI#{9}
EC_RX{40}
EC_TX{40}

PLT_RST#{8,37,40}

EC_SCI#{9}

IT9

KSI[0..7]

KSO[0..17]

EC_SMB_CK1
EC_SMB_DA1

KSI7
KSI6
WRST#

PAD @
PAD @
PAD @
PAD @
PAD @

PAD @
PAD @
PAD @

For factory EC flash

ON/OFF{45}

EC_ON{54}
EC_SMB_CK1{52,53}
EC_SMB_DA1{52,53}

LAN_PWR_ON#{37}

EC_SMB_CK2{7,39}
EC_SMB_DA2{7,39}

1 2

RE27 0_0402_5%

EC_VR_ON{59}

USB_ON#{41,45}

DPWROK_EC{8}

EC_RSMRST#{8}

EC_LID_OUT#{9}

AC_PRESENT{8}

LPC_FRAME#

CLK_PCI_EC
WRST#

EC_RX
EC_TX
PLT_RST#

1

PAD@

1
1
1
1
1

1
1
1

ON/OFF

EC_SMB_CK1
EC_SMB_DA1
PECI_EC

EC_SMB_CK2
EC_SMB_DA2

@

USB_ON#

IT1
IT2
IT3
IT4
IT5

IT6
IT7
IT8

ACLU2: delete RE33 and VGA_AC_DET

1 2

RE35 10K_0402_5%@

1 2

RE36 10K_0402_5%@

1 2

RE38 10K_0402_5%

1 2

RE40 10K_0402_5%

ON/OFF

BKOFF#

LID_SW#

BKOFF#

forECversionupdatetoEX,manualmodifyPNtoFX

+3VL

GPG2

A A

RE43 10K_0402_5%@

GPG2

RE44 10K_0402_5%

GPG2

RE46 10K_0402_5%@

whenmirror,GPG2pullhigh
whennomirror,GPG2pulllow

12

12

12

+3VALW_R

EC_SPI_CS0#

EC_SPI_SI

EC_SPI_SO

EC_SPI_CLK

5

1 2

RE45 0_0402_5%

@

1 2

RE47 0_0402_5%

@

1 2

RE48 0_0402_5%

@

1 2

RE49 0_0402_5%

@

4

CloseEC

CE3

1 2

.1U_0402_10V6-K

1 2

RE4 0_0402_5%@

1 2

RE6 0_0402_5%

126

KSI0
KSI1
KSI2
KSI3
KSI4
KSI5
KSI6
KSI7
KSO0
KSO1
KSO2
KSO3
KSO4
KSO5
KSO6
KSO7
KSO8
KSO9
KSO10
KSO11
KSO12
KSO13
KSO14
KSO15
KSO16
KSO17

110
111
115
116
117
118

112
125

128

SPI_CS0#

SPI_SI

SPI_SO

SPI_CLK

4

VCOREVCC

@

UE1

4
5
6
7
8

9
10
13
14
15
16
17
22
23

58
59
60
61
62
63
64
65
36
37
38
39
40
41
42
43
44
45
46
51
52
53
54
55
56
57

94
95

33
35
93

2

IT8586E-AX_LQFP128_14X14

3

VBAT

KBRST#/GPB6
SERIRQ/GPM6
LFRAME#/GPM5
LAD3/GPM3
LAD2/GPM2
LAD1/GPM1
LAD0/GPM0
LPCCLK/GPM4
WRST#
ECSMI#/GPD4
PWUREQ#/BBO/SMCLK2ALT/GPC7
LPCPD#/GPE6
LPCRST#/GPD2
ECSCI#/GPD3
GA20/GPB5

KSI0/STB#
KSI1/AFD#
KSI2/INIT#
KSI3/SLIN#
KSI4
KSI5
KSI6
KSI7
KSO0/PD0

Int. K/B

KSO1/PD1

Matrix

KSO2/PD2
KSO3/PD3
KSO4/PD4
KSO5/PD5
KSO6/PD6
KSO7/PD7
KSO8/ACK#
KSO9/BUSY
KSO10/PE
KSO11/ERR#
KSO12/SLCT
KSO13
KSO14
KSO15
KSO16/SMOSI/GPC3
KSO17/SMISO/GPC5

PWRSW#
XLP_OUT
SMCLK1/GPC1
SMDAT1/GPC2
SMCLK2/PECI/GPF6
SMDAT2/PECIRQT#/GPF7
CRX1/SIN1/SMCLK3/GPH1/ID1
CTX1/SOUT1/GPH2/SMDAT3/ID2

VSTBY0
GPE4

GINT/CTS0#/GPD5
RTS1#/GPE5
CLKRUN#/GPH0/ID0

CK32KE/GPJ7
CK32K/GPJ6

SPI_CS0# {7}

SPI_SI {7}

SPI_SO {7}

SPI_CLK {7}

RE1 0_0603_5%@

50

92

114

VSTBY2

VSTBY3

VSTBY4

VSTBY126VSTBY5

+3VALW_EC

127

121

VSTBY(PLL)

+3VS

11

12

VCC

VCORE

LPC

IT8586E/AX
LQFP-128L

EXTERNAL SERIAL FLASH

SPI Flash ROM

SM Bus

WAKE UP

GPIO

Clock

VSS1

VSS2

VSS4

VSS349VSS6

1

27

91

NOVO#

For EMI

1 2

RE3

@

1 2

0_0603_5%

AllcapacitorsclosetoEC

+3VALW_R

1

CE6

2

.1U_0402_10V6-K

CD@

minimumtracewidth12mil

74

AVCC

PWM0/GPA0
PWM1/GPA1
PWM2/GPA2

PWM

PWM3/GPA3
PWM4/GPA4

PWM5/GPA5
PWM6/SSCK/GPA6
PWM7/RIG1#/GPA7

TMRI0/GPC4
TMRI1/GPC6

ADC0/GPI0
ADC1/GPI1
ADC2/GPI2

ADC

ADC3/GPI3
ADC4/GPI4

ADC5/DCD1#/GPI5

ADC6/DSR1#/GPI6
ADC7/CTS1#/GPI7

DAC2/TACH0B/GPJ2
DAC3/TACH1B/GPJ3

DAC

DAC4/DCD0#/GPJ4

DAC5/RIG0#/GPJ5

PS2CLK0/TMB0/CEC/GPF0

PS2DAT0/TMB1/GPF1

PS2

PS2CLK2/GPF4

PS2DAT2/GPF5

UART

EGAD/GPE1
EGCS#/GPE2
EGCLK/GPE3

GPIO

SSCE0#/GPG2
SSCE1#/GPG0

DSR0#/GPG6

DTR1#/SBUSY/GPG1/ID7

CRX0/GPC0

CTX0/TMA0/GPB2

RI1#/GPD0
RI2#/GPD1

TACH2/GPJ0

TACH1A/TMA1/GPD7

TACH0A/GPD6

L80HLAT/BAO/GPE0

L80LLAT/GPE7

AVSS

VSS5

75

113

122

EC_AGND

.01U_0402_16V7-K

1

CE20

2

@

+3VL

+3VALW

.1U_0402_10V6-K

GPF2
GPF3

GPH3/ID3
GPH4/ID4
GPH5/ID5
GPH6/ID6

NC1
NC2
NC3
NC4

AC_IN#

LID_SW#

GPJ1

PECI_EC

BATT_TEMP

ACIN#

ON/OFF

3

1

1

CE7

CE8

2

2

.1U_0402_10V6-K

24
25
28
29
30
31

EC_FAN_PWM

32
34

SUS_VCCP

120

LAN_WAKE#

124

SUSP#

66
67
68

BATT_TEMP

69
70
71
72
73

78
79
80

H_PROCHOT#_EC

81

85
86
87
88
89

TP_CLK

90

TP_DATA

96
97
98
99

101

EC_SPI_CS0#

102

EC_SPI_SI

103

EC_SPI_SO

105

EC_SPI_CLK

108

ACIN#

109

LID_SW#

82

VGA_GATE#

83
84

77
100

GPG2

106

EC_ADAPTER_R

104
107

SYSON

119

BKOFF#

123
18
21
76
48
47

EC_FAN_SPEED

19
20

Change RE30 to 0ohm jump

VR_HOT#{59}

1 2

CE15 47P_0402_50V8J@

1 2

CE16 100P_0402_50V8J@

1 2

CE17 100P_0402_50V8J@

1 2

CE18 1U_0402_6.3V6K@

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

1

1

CE9

2

2

.1U_0402_10V6-K

.1U_0402_10V6-K

1

PAD @

1

PAD @

1

PAD @

1 2

RE34 0_0402_5%

H_PROCHOT#_EC

2N7002KW_SOT323-3

1

CE10

CE11

@

2

.1U_0402_10V6-K

PWR_LED# {45}
BATT_CHG_LED# {45}
BATT_LOW_LED# {45}

BATT_LEN# {52}

SYS_PWROK {8}

EC_FAN_PWM {39}

BEEP# {43}

SUS_VCCP {57}

SUSP# {35,46,55,56,57}

NTC_V {52}

TURBO_V {52}
BATT_TEMP {52,53}
VR_IMVP_IMON {59}
VR_CPU_PWROK {10,59}

ADP_I {52,53}
ADAPTER_ID {51,53}

IT11

UMA: pin 73 delete VGA_IMON port and add TP

SUSWARN# {8}
MAINPWON {52}

ENBKL {33}

IT12

PBTN_OUT# {8}

PM_SLP_SUS# {8}

SUSACK# {8}
TP_CLK {45}
TP_DATA {45}

CAPS_LED# {45}

PCH_PWR_EN {46,52}

ACOFF {53}

PCH_PWROK {8,10}

LID_SW# {45}

IT10

VDDQ_PGOOD {55}

ADAPTER_ID_ON# {53}

EC_MUTE# {43}

SYSON {55}
BKOFF# {33}

PM_SLP_S3# {8}
PM_SLP_S4# {8}
NOVO# {45}

EC_TS_ON# {33}

EC_FAN_SPEED {39}

NUM_LED# {45}

@

2013/08/08

2013/08/08

2013/08/08

RE14 0_0402_5%

Change RE14 to 0ohm jump

UMA: pin 85 delete VGA_PWRGD port and add TP

UMA: pin 82 delete VGA_GATE# port and add a TP

13

D

QE1

2

G

S

+3VS

1

CE19
.1U_0402_10V6-K

2

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

2

+3VALW_R+3VALW_R

1 2

LE1 HCB1608KF-181T20

1 2

LE2 HCB1608KF-181T20

1 2

@

12

RE260_0402_5%

@

12

RE25 0_0402_5%@

1 2

RE29 0_0402_5%

UMA: pin 19 delete RE30 and VGA_AC_DET

H_PROCHOT# {5,51,52}

1

CE14
47P_0402_50V8J

@

2

ACIN#

ACIN#{8,53}

2N7002KW_SOT323-3

Deciphered Date

Deciphered Date

Deciphered Date

2

PROCHOT# {52}

+3VL

12

RE42
10K_0402_5%

13

D

QE2

2

G

S

2013/08/05

2013/08/05

2013/08/05

1

CE4
.1U_0402_10V6-K

2

EC_AGND

EC_AGND

EC_ADAPTER {51}

PM_SLP_S5# {8}
ME_FLASH {7}

AOAC_ON# {40}

PCIE_WAKE# {8,9,37,40}

ODD_DA_EC# {42}

ACIN {53}

1

+3VALW_EC

1

CE5
1000P_0402_50V7K

2

EC_FAN_SPEED

EC_FAN_PWM

LPC_FRAME#

ENBKL

TP_CLK

TP_DATA

USB_ON#

SUSP#

SUSP#

SYSON

SUS_VCCP

EC_ADAPTER_R

C

C

C

RE10 10K_0402_5%

RE12 4.7K_0402_5%

RE13 4.7K_0402_5%

RE15 100K_0402_5%

+3VS+5VS

RE37 0_0402_5%@

RE39 0_0402_5%@

RE41

100K_0402_5%

Title

Title

Title

EC ITE8586LQFP

EC ITE8586LQFP

EC ITE8586LQFP

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

+3VALW_R

12

RE5
10K_0402_5%

LAN_WAKE#

1 2

1 2

RE11 10K_0402_5%@

1 2

RE7 10K_0402_5%

1 2

RE9 100K_0402_5%@

RE52

0_0402_5%

@

12

12

1 2

1 2

RE18 100K_0402_5%@

1 2

RE19 100K_0402_5%

1 2

RE21 100K_0402_5%

1 2

RE23 100K_0402_5%

1 2

RE28 100K_0402_5%@

SYSON

EMCRequest

@

1 2

1 2

EC_TX
EC_RX

12

@

UMA

UMA

UMA

1

LAN_WAKE# {37,40}

+3VS

+3VS+5VS

RE51
0_0402_5%

1 2

1 2

+5VALW

+3VALW_R

1

CE13
.1U_0402_10V6-K

2

J80P1

1

1

2

2

3

3

4

4

5

GND1

6

GND2

ACES_85205-04001

ME@

44 59

44 59

44 59

of

of

of

1.0

1.0

1.0

5

ON/OFF switch

NOVO#{44}

D D

ON/OFFBTN#

1 2

J5

SHORT PADS

1 2

J6

SHORT PADS

NOVO#

ON/OFF

+3VL +3VALW

R82
100K_0402_5%@

1 2

1 2

@

1 2

R85 0_0402_5%

@

1 2

R119 0_0402_5%

R83
100K_0402_5%

+3VALW

D15

2

3

BAT54CW_SOT323-3

R111
100K_0402_5%

@

1 2

ON/OFF

1

+3VL

R114
100K_0402_5%

1 2

NOVO_BTN#

ON/OFF {44}

TP/B Connector

+5VS

C C

+3VS

For 14" For 15"

VDD

1

CLK

2

DAT

3

B B

GND

4

TP-L

5

TP-R

6

TP_PWR

1 2

R160

@

0_0402_5%

1 2

R141

0_0402_5%

TP_CLK{44}
TP_DATA{44}

1

2

C114

.1U_0402_10V6-K

@

C115

TP_CLK
TP_DATA

TP_P5

@

1

1

TP_P6

2

2

C116

100P_0402_50V8J

100P_0402_50V8J

TP_LEFT Button

2

5

1

SW1

A

A1

VDD

1

CLK

2

DAT

3

GND

4

TP-L

5

TP-R

6

14@

1

SW3

14@

GND1

B3B1

GND2

EVQPLHA15_4P

4

6

TP_RIGHT Button

2

5

A

A1

GND1

B3B1

GND2

EVQPLHA15_4P

4

6

JTP1

1
2
3
4
5
6

ACES_50503-0060N-001

ME@

AZ5215-01F_DFN1006P2E2

1

DT2

1

2

@
2

AZ5215-01F_DFN1006P2E2

1

DT4

1

2

@
2

1
2
3
4
5

7

GND1

6

8

GND2

For EMC

TP_P5

TP_P6

4

K/B Connector

KSI[0..7]

KSO[0..17]

CAPS_LED#

C117 100P_0402_50V8J@

NUM_LED#

C118 100P_0402_50V8J@

KSO2 KSO1

C89 100P_0402_50V8J@

KSO15

C92 100P_0402_50V8J@

KSO6

C94 100P_0402_50V8J@

KSO8

C96 100P_0402_50V8J@

KSO13

C98 100P_0402_50V8J@

KSO12

C100 100P_0402_50V8J@

KSO11

C102 100P_0402_50V8J@

KSO10

C104 100P_0402_50V8J@

KSO3

C106 100P_0402_50V8J@

KSO4

C108 100P_0402_50V8J@

KSI0

C110 100P_0402_50V8J@

KSO0

C112 100P_0402_50V8J@

For EMC

TP_CLK
TP_DATA

TP_LEFT Button

2

5

1

SW2

A

A1

GND1

B3B1

GND2

15@

EVQPLHA15_4P

4

6

TP_RIGHT Button

2

5

1

SW4

A

A1

GND1

B3B1

GND2

15@

EVQPLHA15_4P

4

6

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

312

AZC199-02S.R7G_SOT23-3@

AZ5215-01F_DFN1006P2E2

AZ5215-01F_DFN1006P2E2

KSI[0..7] {44}

KSO[0..17] {44}

DT1

TP_P5

1

DT3

1

2

@

2

TP_P6

1

DT5

1

2

@

2

PWR_CAPS_LED

C133 100P_0402_50V8J@

PWR_NUM_LED

C134 100P_0402_50V8J@

KSO16

C91 100P_0402_50V8J@

KSO17

C88 100P_0402_50V8J@

C90 100P_0402_50V8J@

KSO7

C93 100P_0402_50V8J@

KSI2

C95 100P_0402_50V8J@

KSO5

C97 100P_0402_50V8J@

KSI3

C99 100P_0402_50V8J@

KSO14

C101 100P_0402_50V8J@

KSI7

C103 100P_0402_50V8J@

KSI6

C105 100P_0402_50V8J@

KSI5

C107 100P_0402_50V8J@

KSI4

C109 100P_0402_50V8J@

KSO9

C111 100P_0402_50V8J@

KSI1

C113 100P_0402_50V8J@

PWR/B Connector

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

1 2

D17

For EMC

3

14"

JKB2

27

GND1

28

GND2

26

CAPS_LED#{44}

CAPS_LED#
PWR_CAPS_LED
KSO15
KSO10
KSO11
KSO14
KSO13
KSO12
KSO3
KSO6
KSO8
KSO7
KSO4
KSO2
KSI0
KSO1
KSO5
KSI3
KSI2
KSO0
KSI5
KSI4
KSO9
KSI6
KSI7
KSI1

26

25

25

24

24

23

23

22

22

21

21

20

20

19

19

18

18

17

17

16

16

15

15

14

14

13

13

12

12

11

11

10

10

9

9

8

8

7

7

6

6

5

5

4

4

3

3

2

2

1

1

ACES_88514-02601-071

ME@

2

300_0402_5%

1

+3VS

12

12

R90

R84

300_0402_5%

NUM_LED#

NUM_LED#{44}

PWR_NUM_LED
CAPS_LED#
PWR_CAPS_LED
KSO17
KSO16
KSO15
KSO10
KSO11
KSO14
KSO13
KSO12
KSO3
KSO6
KSO8
KSO7
KSO4
KSO2
KSI0
KSO1
KSO5
KSI3
KSI2
KSO0
KSI5
KSI4
KSO9
KSI6
KSI7
KSI1

15"

JKB1

30

30

GND1

29

29

GND2

28

28

27

27

26

26

25

25

24

24

23

23

22

22

21

21

20

20

19

19

18

18

17

17

16

16

15

15

14

14

13

13

12

12

11

11

10

10

9

9

8

8

7

7

6

6

5

5

4

4

3

3

2

2

1

1

ACES_50504-3041-001

ME@

31
32

KB_1

KB_2

KB_3

KB_4

KB_5

KB_6

KB_7

KB_8

KB_9

KB_10

KB_11

KB_12

KB_13

KB_14

KB_15

KB_16

KB_17

KB_18

KB_19

KB_20

KB_21

KB_22

KB_23

KB_24

15"

14"

KSI1_14 KSO0_15

KSI2_15KSI7_14

KSI6_14 KSI3_15

KSO5_15KSO9_14

KSO1_15KSI4_14

KSI5_14 KSI0_15

KSO2_15KSO0_14

KSO4_15KSI2_14

KSO7_15KSI3_14

KSO8_15KSO5_14

KSO6_15KSO1_14

KSO3_15KSI0_14

KSO2_14

KSO12_15

KSO13_15KSO4_14

KSO7_14 KSO14_15

KSO11_14KSO8_14

KSO10_15KSO6_14

KSO3_14 KSO15_15

KSO16_15KSO12_14

KSO17_15KSO13_14

KB_LED_PWR_15

KSO14_14

CAPS_LED#_15KSO11_14

VDD_15KSO10_14

NUM_LED#_15KSO15_14

USB I/O Connector

Right Side USB2.0 Port X 1 (USB/B)

+3VL

JPWRB1

1

1

LID_SW# {44}

2

2

3

3

4

4

5

5

6

GND1

6

GND2

ACES_50503-0060N-001

ME@

7
8

NOVO_BTN#
ON/OFFBTN#
LID_SW#

1

1

2

@

2

AZ5215-01F_DFN1006P2E2

2.2U_0603_10V6-K

C119

1 2

USB_ON#{41,44}

USB20_P0

USB20_N0

U3

1

GND

2

VIN1

3

VIN2

EN/EN4FLAG

AP2820CMMTR-G1_MSOP8

Low Active 2A

L14

112

4

4

CMM21T-900M-N_4P@

VOUT3

VOUT2

VOUT1

+USB_VCCB+5VALW

8

7

6

5

2

3

3

USB20_P0_CONN

USB20_N0_CONN

USB_OC2#USB_ON#

1

C120
1000P_0402_50V7K

@

2

USB_OC2# {9}

USB20_P0{9}
USB20_N0{9}

USB20_P3{9}
USB20_N3{9}

HP_OUTR{43}
HP_OUTL{43}

RING2_CONN{43}

RING3_CONN{43}

PLUG_IN{43}

1 2

R67 0_0402_5%

1 2

R66 0_0402_5%

+USB_VCCB

+3VS

@

USB20_P0_CONN

@

USB20_N0_CONN

USB20_P3
USB20_N3

HP_OUTR
HP_OUTL

RING2_CONN

RING3_CONN
PLUG_IN

JUSB3

18

18

G2

17

17

G1

16

16

15

15

14

14

13

13

12

12

11

11

10

10

9

9

8

8

7

7

6

6

5

5

4

4

3

3

2

2

1

1

ACES_50505-0184N-P01

20
19

For 14" For 15"

LED

PWR_LED#

PWR_LED#{44}

1

1

2

2

LED1

D16

AZ5425-01F_DFN1006P2E2

LED4

@

1 2

LTW-C193TS5

1 2

LTW-C193TS5

1 2

R142 560_0402_5%

14@

15@

+5VALW

1

D18

AZ5425-01F_DFN1006P2E2

1

2

@

2

1

D19

AZ5425-01F_DFN1006P2E2

1

2

@

2

LED2

LED5

LED3

LED6

1 2

LTST-C193KFKT-LC

1 2

LTST-C193KFKT-LC

1 2

LTW-C193TS5

1 2

LTW-C193TS5

BATT_LOW_LED#{44}

A A

BATT_CHG_LED#{44}

BATT_LOW_LED#

BATT_CHG_LED#

5

1 2

14@

R143 470_0402_5%

15@

14@

R144 300_0402_5%

15@

1 2

+3VALW

+5VALW

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

4

3

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

2

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2013/08/05

2013/08/05

2013/08/05

Title

KBD/PWR/IO/LED/TP Conn.

KBD/PWR/IO/LED/TP Conn.

KBD/PWR/IO/LED/TP Conn.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

1

UMA

UMA

UMA

45 59

45 59

45 59

of

of

of

1.0

1.0

1.0

+5VALW to +5VS

A

B

C

D

E

+3VALW to +3VS

AP4800BGM
VGS=10V, ID=9A, Rds=18m ohm
VGS=+-25V

+5VALW

1 1

10U_0805_25V6K

2 2

C124

1

@

2

Q23

8
7
6
5

C127

0.01U_0402_25V7K

PCH_PWR_EN#_R PCH_PWR_EN#

PCH_PWR_EN{44,52}

+5VS

1
2
3

AP4800BGM-HF_SO-8

4

1

2

1 2

R158 100K_0402_5%@

1

2

R148

1 2

82K_0402_1%

R153

820K_0402_5%

PCH_PWR_EN

100K_0402_5%

C121
10U_0805_10V6K

CD@

5VS_GATE5VS_GATE_R

12

@

12

R162

13

D

S

Q30

2

G

1

C122
1U_0603_25V6M

2

CD@

R149

150K_0402_5%

Q25

2

G

2N7002KW_SOT323-3

+5VALW

12

R155
100K_0402_5%

@

13

D

S

2N7002KW_SOT323-3@

12

SUSP

+20VSB

2

12

R145
470_0603_5%@

13

D

Q26

G

S

2N7002KW_SOT323-3@

.1U_0402_10V6-K

PCH_PWR_EN#_R

C125

10U_0805_25V6K

+3VALW +3VALW_PCH +5VALWVCCRTC

1

C129

@

2

Needshort

J7

@

112

JUMP_43X79

LP2301ALT1G_SOT23-3

D

S

Q29

13

G

2

1

2

C131
.1U_0402_10V6-K

@

2

@

1

@

2

Id=3.2A

1

C130

0.01U_0402_25V7K

@

2

+3VALW

AP4800BGM
VGS=10V, ID=9A, Rds=18m ohm
VGS=+-25V

Q24

8
7
6
5

C128

0.01U_0402_25V7K

+3VS

1
2
3

AP4800BGM-HF_SO-8

4

3VS_GATE_R

1

2

1 2

R150

0_0402_5%

820K_0402_5%

SUSP{34}

1

C123
10U_0603_6.3V6M

2

CD@

12

R154

@

100K_0402_5%

SUSP

SUSP#{35,44,55,56,57}

2N7002KDWH_SOT363-6

0_0402_5%

0_0402_5%

R156

@

R147

R151

@

12

1

C126
1U_0603_25V6M

2

CD@

12

5VS_GATE

12

3VS_GATE

Q6A

2

G

R152

470K_0402_5%@

13

D

Q27

2

G

S

2N7002KW_SOT323-3

@

12

R157
100K_0402_5%

61

D

S

5VS_GATE {35}

12

+20VSB

SUSP

+0.675VS

12

@

13

D

Q28

2

G

S

12

R159
47_0603_5%

34

Q6B

D

5

G

S

2N7002KDWH_SOT363-6

R146
470_0603_5%

2N7002KW_SOT323-3@

SUSP

3 3

4 4

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

A

B

C

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

D

2013/08/05

2013/08/05

2013/08/05

Title

DC V TO VS INTERFACE

DC V TO VS INTERFACE

DC V TO VS INTERFACE

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

46 59

46 59

46 59

of

of

E

of

1.0

1.0

1.0

5

D D

AC
MODE

A1

VIN

V

PU301

V

BATT
MODE

C C

BATT

B1

4

B2

A2

+3VLP

V

A3

B5

A4

+3VALW

B4

B3

V

EC

V

V

A2

PU904

V

B+

V

EC_ON

ON/OFF

NOVO

3

PCH_PWR_EN#

1

DPWROK_EC

4

PCH_RSMRST#

5

PBTN_OUT#

PM_SLP_S3#
PM_SLP_S4#
PM_SLP_S5#

V

PM_SLP_SUS#

12

PCH_PWROK

13

SYS_PWROK

2

2

Q25,+3V_PCH

V

3

+3V_PCH

1

V

V

PM_DRAM_PWRGD

VV

6

PCH

H_CPUPWRGD

CPU_PLTRST#

14

V

15

16

CPU

V

V

V

V

11 VR_REDY

PU901
+CPU_CORE

B B

V

10

VR_ON

SUSP#,SUSP

SYSON

7

9

+1.35V
PU501

V

Q31

V

+5VS

Q32

V

+3VS

PU602

V

+1.5VS

PU502

V

+0.675V

SUS_VCCP

A A

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

8

3

PU701

V

+1.05VS

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

Title

Title

Power sequence Block

Power sequence Block

Power sequence Block

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

47 59

47 59

1

47 59

1.0

1.0

1.0

5

D D

4

3

2

1

Board ID

BOARD_ID0

C C

BOARD_ID1

00

BOARD_ID3BOARD_ID2

00

01

*

0011

111

00

B B

011

0

0

10

Description

BDW + Jet-LE sku

BDW + Topaz-XT sku00

BDW + N15V-GM sku1000

BDW + N15S-GT sku1001

HSW + Jet-LE sku0010

HSW + Topaz-XT sku0101

HSW + N15V-GM sku

HSW + N15S-GT sku

BDW + UMA sku

HSW + UMA sku

Stuff Resistor

RC107,RC108,RC109,RC123

RC107,RC108,RC102,RC123

RC107,RC101,RC109,RC123

RC107,RC101,RC102,RC123

RC100,RC108,RC109,RC123

RC100,RC108,RC102,RC123

RC100,RC101,RC109,RC123

RC100,RC101,RC102,RC123

RC107,RC108,RC109,RC121

RC100,RC108,RC109,RC121

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

2013/08/08

2013/08/08

2013/08/08

3

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2013/08/05

2013/08/05

2013/08/05

2

Title

Virtual symbol

Virtual symbol

Virtual symbol

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

B

B

B

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

UMA

UMA

UMA

1

of

of

of

48 59

48 59

48 59

1.0

1.0

1.0

5

4

3

2

1

NH1
HOLEA

1

D D

C C

pad_c2p3d2p3n

H1
HOLEA

1

pad_SHT7P0X7P05BR10P65X10P3D2P8

pad_ct6p0shapeb8p0x6p75d2p3

@

GP2
PAD_RT2P65X2P2

GP1
PAD_RT2P65X2P2

1

1

PAD_SHAPET5P0X6P0B7P0D2P3

H14
HOLEA

1

1

1

NH3
HOLEA

1

pad_o2p3x2p8d2p3x2p8n

H2
HOLEA

1

PAD_CT6P0shapeb10p04x10p0d2p8

GP3

@

PAD_RT2P65X2P2

1

1

pad_o2p3x2p8d2p3x2p8n

Pad_ct8p0b9p0d2p8

H15
HOLEA

1

@

NH4
HOLEA

1

H3
HOLEA

1

GP4
PAD_RT2P65X2P2

@

1

1

pad_ct6p0b7p0d2p3

NH5
HOLEA

1

pad_c2p3d2p3n

H4
HOLEA

1

Pad_ct8p0b9p0d2p8

H16
HOLEA

1

GP5
PAD_RT2P65X2P2

@

1

1

H5
HOLEA

pad_shapet8p8x8p0cb9p0d2p8

H17
HOLEA

1

pad_shapet6p8x8p0cb8p0d2p5

GP6
PAD_RT2P65X2P2

@

1

1

1

PAD_ShapeT5P0X6P0-D

GP7
PAD_RT2P65X2P2

1

1

H6
HOLEA

1

pad_shapet8p8x8p0cb9p0d2p8

H18
HOLEA

1

GP8

@

PAD_RT2P65X2P2

1

pad_ct6p5b5p0d4p0

H19
HOLEA

1

PAD_shapeT5P0X6P0-U

@

1

H7
HOLEA

1

H8
HOLEA

1

pad_ct6p5b5p0d4p0

H20
HOLEA

1

pad_ct5p5b6p0d3p3

H9
HOLEA

1

pad_ct6p5b5p0d4p0

H10
HOLEA

1

pad_ct6p5b5p0d4p0

H21
HOLEA

1

CHASSIS1_GND

pad_ct5p5b8p0d2p5

B B

GP9
PAD_RT2P21X2P99

@

1

1

GP10
PAD_RT2P21X2P99

@

1

1

GP11
PAD_RT2P45X2P5

@

1

1

GP12
PAD_RT2P45X2P5

@

1

1

FFC CONN GROUND PAD

PCB Fedical Mark PAD

A A

FD1

1

FD2

FD3

1

1

5

FD4

FD5

FD6

1

1

1

4

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

2013/08/08

2013/08/08

2013/08/08

3

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2013/08/05

2013/08/05

2013/08/05

2

+3VS

1

C136
.1U_0402_10V6-K

@

2

For EMC

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

B

B

B

Date: Sheet

Date: Sheet

Date: Sheet

+5VALW +3VALW

1 2

C137 .1U_0402_10V6-K

@

1 2

C138 .1U_0402_10V6-K

@

Hole

Hole

Hole

UMA

UMA

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

1

of

of

of

49 59

49 59

49 59

1.0

1.0

1.0

5

4

3

2

1

PGOOD

PGOODEN

PGOOD

+5VLP/ 100mA

+5VALW/6A

ALW_PWRGD

+3VLP/ 100mA

+3VALW/ 5A

ALW_PWRGD

+1.35V/12A

+0.675VS/2A

CPU Core/14A/32A

VGATE

+VGA_CORE/31A

VGA_PWRGD

SY8036LDBC
DFN10_3X3

Switch Mode

SUSP#

FOR VDDR

EN PGOOD

ANPEC

APL5932AQBI-TRG
TDFN10_3X3

Switch Mode

FOR VDDR

EN PGOOD

SUSP#

Silergy

SY8032ABC
SOT23-6

Switch Mode

FOR VDDR

EN PGOOD

Silergy

SY8032ABC
SOT23-6

Switch Mode

FOR VDDR

EN PGOOD

Silergy

+1.05VS/5A

+1.5VSP/1A

+1.05VSP_VGA/2A

+1.8VSP_VGA/1A

D D

B+

Adaptor

EC_ON

Silergy

SY8208CQNC

Converter

FOR SYSTEM

EN PGOOD

PAGE 39

Silergy

SY8206BQNC

Converter

FOR SYSTEM

EC_ON

EN PGOOD

PAGE 39

Richtek

RT8231AGQW

SYSON

C C

TI

SUSP#

BQ24737RGRR

S5

WQFN20_3X3

S3

Switch Mode

FOR DDR

Battery Charger

Switch Mode

PAGE 46

SMBus

VR_ON

Battery

Li-ion

B B

4S1P/41WH

NVDD_PWR_EN

Onsemi

NCP81101MNTXG
QFN28_4X4

Switch Mode

FOR CPU Core

Interisl

ISL62771HRTZ
TQFN40_5X5

VIDs

Switch Mode

EN

FOR GPU VDDC

PGOOD_NB

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

3

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

Power Diagram

Power Diagram

Power Diagram

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

UMA

UMA

UMA

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

1

50 59

50 59

50 59

of

of

of

1.0

1.0

1.0

5

4

3

2

1

+3VL

VIN

PR9406

@

@

set OVP

RTC_VCC

12

PR368

12

0_0402_5% @

+3VALW

PR9400

1 2

1K_0603_5%

change to 1K SD01310018J

H_PROCHOT#

1 2

BAT_D

JDCIN1

1

1

2

2

3

3

4

4

5

D D

C C

B B

5

ACES_50299-00501-003

ME@

PF101

21

APDIN1APDINAPDIN

7A_24VDC_429007.WRML

ADAPTER_ID {44,53}

12

12

PC102

PC101

1000P_0402_50V7K

470P_0402_50V7K

0.1U_0402_25V6

@

EC_ADAPTER{44}

PL706

HCB2012KF-121T50_0805

1 2

PL708

HCB2012KF-121T50_0805

1 2

For EMI request

+5VALW

PR367

0_0402_5%

1 2

PC1259

@

1 2

@

PR9417

30K_0402_1%

PQ204

2

G

2N7002KW_SOT323-3

@

@

+3VALW

12

13

D

S

12

12

470P_0402_50V7K

12

@

@

0.1U_0402_25V6

PC104

1000P_0402_50V7K

737_ACP{53} 737_ACN {53}

PC1258

0.1U_0402_25V6

PC103

PR9403

1 2

35.7K_0402_1%

@

PR9404

10K_0402_1%

45W current limit 2.8A
65W current limit 3.6A

PC1257

12

0.1U_0402_25V6

@

12

@

PC1260

12

PR9412

@

10K_0402_5%

+3VALW

@

PC1256

0.1U_0402_25V6

1 2

PU1208

10

@

CSN

PROCHOT#

1

CSP

2

VCC

3

ILIM

EN4TMER

GND

11

RT9553AGQW_WDFN10_3X3

1 2

@

375K for 15uS
124K for 5uS

RESET

OVSET

UVSET

+1.05VS

PR9405

10K_0402_5%

@

9

8

7

6

5

PR9407

124K_0402_1%

12

12

@

0_0402_5%

1 2

12

PR9411

10K_0402_1%

@

PR369

12

@

PR9410

24K_0402_1%

@

+3VALW

H_PROCHOT#{5,44,52}

12

JRTC1

FDK_ML1220-TT28

@

+1.05VS

12

10K_0402_5%

PR9409

1 2

2.94K_0402_1%

PR9413

10K_0402_1%

@

VCCRTC

PD703
RB751V-40_SOD323-2

PD704

12

RB751V-40_SOD323-2

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

DCIN / RTC

DCIN / RTC

DCIN / RTC

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

of

of

of

51 59

51 59

1

51 59

1.0

1.0

1.0

5

JBATT1

1
2
3
4
5
6

7
GND1
GND2

SUYIN_200082GR007G232ZR

ME@

D D

VMB2

1
2
3

EC_SMCA

4

EC_SMDA

5
6
7
8
9

12

PR201

100_0402_1%

BATT_TEMP_IN

12

PR202

8A_24V_F1206HI8000V024T

1 2

100_0402_1%

PR203

1 2

100K_0402_1%

PR204

1 2

10K_0402_5%

PF201

3

2

VMB

C8BBPH403025-1TAPING_2P

12

PC201

1000P_0402_50V7K

EC_SMB_CK1 {44,53}

EC_SMB_DA1 {44,53}

+3VALW

BATT_TEMP {44,53}

VMB2

JBATT2

1

1

2

2

3

GND1

GND2

ME@

VMB2

3

4

4

5

5

6

6

7

7

8
9

12

PR226
280K_0402_1%

12

PR224

49.9K_0402_1%

EC_SMCA
EC_SMDA
BATT_TEMP_IN

0.01U_0402_25V7K

PR222

10K_0402_1%

1 2

1

@

PD306

1

2

2

AZ5215-01F_DFN1006P2E2

+5VALW

12

PC207

3

+_1

2

-_1

PR225

100K_0402_1%

1 2

PR230
100K_0402_1%

1 2

10M_0402_5%

8

PU202A

P

1

O1

G

AS393MTR-G1_SO8

4

+3VL

C C

SUYIN_200082GR007G232ZR

B B

12

PC108

0.1U_0402_25V6

@

A A

PD305
AZC199-02S.R7G_SOT23-3

@

1

Reverse PD305 For EMI request

PR228

1 2

@

BATT_LEN#{44}

+3VALW +3VALW

PR221

1 2

100K_0402_1%

PR229

10K_0402_1%

1 2

PL201

1 2

5

G

+3VALW

PR227

1 2

100K_0402_1%

2

4

A/D

PR223

1 2

100K_0402_1%

34

D

PQ996B
2N7002KDWH_SOT363-6

S

PQ996A

61

D

G

S

BATT+

12

PC202

0.01U_0402_25V7K

2N7002KDWH_SOT363-6

BATT_OUT {53}

3

PH201 under CPU botten side :
CPU thermal protection at 92+-3 degree C
Recovery at 56 +-3 degree C

+5VLP

PC203

0.1U_0603_25V7-M

@

1 2

H_PROCHOT#{5,44,51}

2N7002KW_SOT323-3

PROCHOT#{44}

12.5V

PC107

0.1U_0402_25V6

PQ201

12

@

@

13

D

S

VMB2

12

PR103

499K_0402_1%

@

12

PR114

180K_0402_1%

@

+3VS

1 2

2

ADP_OCP_1

G

PR215

1 2

0_0402_5% @

1 2

PR9416

20K_0402_1%

ALW_PWRGD{54}

PCH_PWR_EN{44,46}

PR208
100K_0402_1%

@

10K_0402_1%

PC1268

OTP_N_003

@

1 2

0_0402_5%

+3VALW

PR105

1 2

@

12

12

PR116

@

430K_0402_1%

220P_0402_50V7K

@

1

2

3

4

PR214

1 2

1.78M_0402_1%

@

PU201

VCC

TMSNS1

GND

RHYST1

OT1

TMSNS2

RHYST2

OT2

G718TM1U_SOT23-8

+5VALW

PR106

@

8

PU202B

5

P

+_2

O2

6

-_2

G

AS393MTR-G1_SO8

4

@

1 2

1 2

1K_0402_1%

8

7

OTP_N_002

6

5

ADP_OCP_2

MAINPWON {44}

7

PR219

0_0402_5%

PR220

2

For KB930 --> Keep PU1 circuit
(Vth = 0.825V)

For KB9012 (Red square) --> Remove PU201 circuit, but keep PR206
PH201, PR205,PR211,PQ201,PR208,PR212

ADP_I{44,53}

4.42K_0402_1%

+3VALW

1 2

@

PR205

@

Turbo_V_1

1 2

PR210

57.6K_0402_1%

@

PR108
221K_0402_1%

VIN

VSBP_1

1 2

PQ101A

2

G

@

PR211

0_0402_5%

1 2

@

Turbo_V

61

D

S

12

PC206
1U_0402_6.3V6K

@

1 2

@

1 2

1M_0402_5%

PQ203

2

G

+3VL

12

NTC_V_1

12

PR209

10K_0402_1%

@

PR213

PR212

10K_0402_1%

{44}

2N7002KDWH_SOT363-6

PR353

@

13

0_0402_5%

1 2

NTC_V

1 2

B+

PR216

PR217

1 2

VSBP_2 VSBP_3

22K_0402_1%

D

S

2N7002KW_SOT323-3

PR206

13.7K_0402_1%

{44}

430K_0402_1%

PR352
1M_0402_5%

@

12

PC204

100K_0402_1%

12

PR207

21.5K_0402_1%

@

12

PH201

100K_0402_1%_NCP15WF104F03RC

+5VALW

PR110

@

1 2

@

13

D

2

PQ205

G

2N7002KW_SOT323-3

S

PR366

1 2

0_0603_5%

@

PQ202

TP0610K-T1-E3_SOT23-3

12

0.22U_0603_25V7K

5

G

@

2

PR109

0_0402_5%

UVP_1

@

34

D

PQ101B
2N7002KDWH_SOT363-6

S

+VSBP

13

1 2

12

H_PROCHOT#

PJ201
JUMP_43X39

112

@

PC205

0.1U_0603_25V7-M

1

2

+20VSB

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

BATTERY CONN/OTP

BATTERY CONN/OTP

BATTERY CONN/OTP

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

C

C

C

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

1

52 59

52 59

52 59

of

of

of

1.0

1.0

1.0

5

4

B+

3

Charge Option() bit[8]=1

2

1

P2 P3

12

PR303
200K_0402_1%

0.1U_0603_25V7-M

P2-1

12

P2-2

34

D

PQ307B
2N7002KDWH_SOT363-6

S

EC_SMB_CK1{44,52}

EC_SMB_DA1{44,52}

VIN

@

@

PQ302

SI4483ADY-T1-GE3_SO8

1
2
3 6

4

12

PR356

20K_0402_1%

61

D

PQ990A

2

G

S

2N7002KDWH_SOT363-6

59K_0402_1%

0.1U_0402_25V6

12

PR323

1M_0402_5%

34

12

D

S

2N7002KDWH_SOT363-6

@

8
7

5

PC301

1 2

100P_0402_50V8J

BATT_OUT {52}

PR311

1 2

PC316

1 2

PR313 0_0402_5%

1 2

PR315 0_0402_5%

1 2

ADP_I{44,52}

100P_0402_50V8J

5

G

PQ995B

P2

10_1206_5%

PC314

1U_0603_25V6M

VIN

PR310
390K_0402_1%

1 2

737_ACDET

ACPRN

737_SDA

ADP_I

PC318

+3VS

ADAPTER_ID_ON# {44}

PR308

12

737_SCL

1 2

10K_0402_5%

1 2

4

PR318

PR321

100K_0402_1%

PR301

0.01_1206_1%

1

2

737_ACP{51} 737_ACN{51}

PC310

12

0.1U_0603_25V7-M

12

6

5

9

8

7

PC312

0.1U_0603_25V7-M

2

20

VCC

ACDET

ACOK

SCL

BQ24737RGRR_VQFN20_3P5X3P5

SDA

IOUT

11

@

BM#

12

737_ILIM

PR324

316K_0402_1%

1 2

+3VALW

4

3

PC311

0.1U_0603_25V7-M

12

1

ACP

ACN

PU301

CMPIN

ILIM10BM#

4

PR319

6.8_0603_5%

0.1U_0603_25V7-M

12

14

3

CMPOUT

REGN

HIDRV

PHASE

LODRV

SRN12SRP

13

SRN_1

SRP_1

12

12

PC322

1 2

PC323

0.1U_0603_25V7-M

1 2

@

GND

BTST

PAD

PR320

10_0603_5%

PC109

0.1U_0603_25V7-M

17

16

18

19

15

21

1 2

12

PC324

0.1U_0603_25V7-M

PL707

1 2

C8BBPH403025-1TAPING_2P

PC302

10U_0805_25V6K

1 2

@

For EMI request

BQ24737_VDD

PC315
1U_0603_25V6M

1 2

PD303

RB751V-40_SOD323-2

12

BST_CHG

DH_CHG

@

10U_0805_25V6K

1 2

PR312

1 2

2.2_0603_5%

3

PC303

@

PQ301

AO4407AL_SO8

8

VIN

D D

C C

B B

200K_0402_5%

2

G

ACOFF{44}

BATT_OUT

PR345

0_0402_5%

@

BATT_TEMP{44,52}

12

PR302

P2_G1

61

PQ307A

S

2N7002KDWH_SOT363-6

1 2

7

5

PQ304

LTA044EUBFS8TL_UMT3F-3

2

P2_G2

13

2

D

2N7002KDWH_SOT363-6

1 2

PACIN

47K_0402_1%

PR314

1 2

ACOFF-1

0_0402_5%

12

PR349

1M_0402_5%

PQ990B

5

G

34

S

1
2
36

4

1 2

1 3

PQ305
LTC015EUBFS8TL_UMT3F-3

PR307
68K_0402_1%

PR309

5

G

PACIN_G

61

D

PQ998A

2

G

S

2N7002KDWH_SOT363-6

D

PC308

+3VALW

12

PR322
750_0603_1%

61

D

PQ995A

2

PR336

0_0402_5%

A A

12

PC1267

680P_0402_50V7K

PC1266

@

0.1U_0402_25V6

S

1 2

@

1

12

1

2

2

ADAPTER_ID_ON#_G

G

2N7002KDWH_SOT363-6

ADAPTER_ID {44,51}

PD304
AZ5425-01F_DFN1006P2E2

5

PR328
1M_0402_5%

12

12

PC105

1000P_0402_50V7K

1 2

PC317

12

0.047U_0603_16V7K

LX_CHG

DL_CHG

ACPRN

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

12

12

PC110

1000P_0402_50V7K

1000P_0402_50V7K

PC306

PC305

1 2

1 2

4.7U_0805_25V6-K

AO4466L_SO8

PQ309

AO4466L_SO8

12

PR325
47K_0402_1%

PQ998B

5

G

PR334

0_0402_5%

1 2

@

PC111

1000P_0402_50V7K

1 2

@

4.7U_0805_25V6-K

4

PQ311

BQ24737_VDD

2013/08/08

2013/08/08

2013/08/08

PC106

PC304

4.7U_0805_25V6-K

2N7002KDWH_SOT363-6

ACPRN ACIN#

For EMI request

DISCHG_G

PC307

2200P_0402_50V7K

1 2

DISCHG_G-1

PQ308B
2N7002KDWH_SOT363-6

34

D

S

6

578

123

6

578

4

123

12

PR326
10K_0402_1%

34

D

S

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

PQ303

AO4407AL_SO8

1
2
3 6

PR304

1 2

47K_0402_1%

PR305
10K_0402_1%

5

G

4.7UH_PCMB063T-4R7MS_5.5A_20%

12

6251_SN

12

PR327

1 2

10K_0402_1%

12

PR333
12K_0402_1%

ACIN# {8,44}

PACIN_N

12

0.1U_0603_25V7-M

PR347

1M_0402_5%

PL302

1 2

PR317

4.7_1206_5%

@

PC321
680P_0402_50V7K

@

737_SRP

737_SRN

PACIN

Deciphered Date

Deciphered Date

Deciphered Date

2

ACOFF-1

1 2

4

PD301

1SS355_SOD323-2

PD302

1 2

1SS355_SOD323-2

PC313

CHG

ACIN {44}

8
7

5

PR306
200K_0402_1%

1 2

PACIN_P

61

D

12

S

2N7002KDWH_SOT363-6

PR316

0.01_1206_1%

1

2

2013/08/05

2013/08/05

2013/08/05

BATT+

VIN

2

PACIN737_VCC

G

PQ308A

4

3

BATT+

12

12

PC320

PC319

10U_0805_25V6K

10U_0805_25V6K

Title

Title

Title

CHARGER

CHARGER

CHARGER

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

C

C

C

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

1

53 59

53 59

53 59

of

of

of

1.0

1.0

1.0

5

D D

B+

PJ302

2

112

JUMP_43X79

@

PR337

EC_ON{44}

C C

1 2

0_0402_5%

PC1054

@

0.1U_0402_25V6

B+

B B

EC_ON

1.5A

12

PC1046

0.1U_0402_25V6

12

3V_GND 3V_GND

PJ1

1 2

JUMPER

PJ305

2

JUMP_43X79

@

PR346

@

0.1U_0402_25V6

@

112

PC1069

5V_GND

3V_GND

1 2

0_0402_5%

12

12

12

12

PR335

PC1047

1M_0402_5%

10U_0805_25V6K

3V_GND

PR339
1M_0402_5%

@

2.5A

12

PC1060

PC1058

0.1U_0402_25V6
10U_0805_25V6K

12

PR348

1M_0402_5%

5V_GND 5V_GND

PJ2

1 2

JUMPER

@

12

12

PC1059

10U_0805_25V6K

4

1U_0603_25V6M

5V_GND

+3V_VIN

+3VALW_FB

+3VLP

PC1062

1 2

+5VALW_EN

+5VFB

+5V_VIN

+5VVCC

7

8

9

1

3

PU904

EN2

PG

IN

BS

LX

GND

EN1

OUT

SY8206BQNC_QFN10_3X3

FB

LDO

PJ304

2

112

JUMP_43X39

@

PU905

8

IN

9

GND

5

VCC

1

EN

SY8208CQNC_QFN10_3X3

3

FB

6800pf soft start 2ms
47nf soft start 7ms

OUT

LDO

2

6

10

4

5

PG

BS

LX

100mA

+3VL

2

6

10

4

7

3

+3V_PWRGD

PC1048

1 2

+3VBS

+3VLX

+3VALW_P+3VALW_EN

3V_GND

0.1U_0603_25V7-M

+3VLP

12

PC1055

4.7U_0603_6.3V6K

1

@

PTP1
PAD

PC1057

1 2

0.01U_0402_25V7K

PL303

1 2

2.2UH_PCMB063T-2R2MS_8A_20%

12

PR338

4.7_1206_5%

@

12

PC1106
1000P_0402_50V9-J

@

PR341

1 2

1K_0402_1%

change 470P to 10nf for soft start time 2ms

+3V_PWRGD

+5V_PWRGD

PC1061

1 2

+5VBS

0.1U_0603_25V7-M

+5VLX

PR351

0_0402_5%

100mA

12

PC1070

5V_GND

PC1072

1 2

6800P_0402_25V7-K

12

+5VALW_P

+5VLP

4.7U_0603_6.3V6K

1 2

PR350

1K_0402_1%

PL304

1 2

3.3UH_PCMB063T-3R3MS_6.5A_20%

12

PR340

4.7_1206_5%

@

12

PC1107
1000P_0402_50V9-J

@

12

PC1049

PR343

1 2

0_0402_5% @

PR344

1 2

0_0402_5% @

12

12

PC1050

22U_0805_6.3V6M

+3VALW

12

PC1063

22U_0805_6.3V6M

12

PC1051

22U_0805_6.3V6M

PR342
100K_0402_5%

@

1 2

12

PC1080

22U_0805_6.3V6M

12

PC1052

22U_0805_6.3V6M

12

PC1090

22U_0805_6.3V6M

+3VALW_P

22U_0805_6.3V6M

ALW_PWRGD {52}

+5VALW_P

PC1091

22U_0805_6.3V6M

2

PJ303

2

JUMP_43X79

@

2

4A

112

PJ306

JUMP_43X79

@

1

+3VALW

+5VALW

5A

112

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

PWR_3VALW/5VALW

PWR_3VALW/5VALW

PWR_3VALW/5VALW

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

C

C

C

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

54 59

54 59

54 59

of

of

1

of

1.0

1.0

1.0

A

1 1

+3VALW

1k for 500K
12k for 670K

PR375

PR9414

1K_0402_1%

1 2

2A

PC1265

21

PC1263

10K_0402_1%

20

PU1207

PAD

1

PGOOD

VTTSNS

2

VLDOIN

3

VTT

TPS51716RUKR_WQFN20_3X3

4

VTTGND

5

VTTREF

VREF6REFIN8PGND

VREF

1 2

1 2

12

VDDQ_PGOOD{44}

2 2

+0.675VSP

2A

@

+VTT_REFP

PJ315

2

112

JUMP_43X79

@

3 3

PC1099

22U_0805_6.3V6M

12

PC1100

+0.675VS+0.675VSP

+1.35V

12

22U_0805_6.3V6M

PC1264

1U_0402_6.3V6K

12

0.1U_0402_25V6

0.01U_0402_25V7K

12

12

PR9415

18

19

TRIP

MODE

GND7VDDQSNS

PR374

REFIN

10K_0402_1%

12

B

12

PC1102

0.1U_0402_10V7K

S3_1.35V

100K_0402_1%

S5_1.35V

16

17

S3

9

10

PR379

31.6K_0402_1%

@

PR9350 0_0402_5%

1 2

@

PR377 0_0402_5%

12

PR376 0_0402_5%

12

12

PC1101 0.1U_0402_10V7K

@

S5

15

VBST

14

DRVH

13

SW

12

V5IN

11

DRVL

SUSP# {35,44,46,56,57}

CPU_DRAMPG_CNTL {5}

SYSON {44}

PR380

0.1U_0603_25V7-M

1 2

PR381 0_0402_5%

12

UG_1.35V

LX_1.35V

12

PC1104
1U_0603_25V6M

LG_1.35V

PC1081

12

AON7408L_DFN

+5VALW

AON7506_DFN

0_0603_5%

BST_1.35V

PQ997

PQ43

C

2A

1.35V_B+

12

12

PC1064

PC857

@

5

4

321

5

4

321

0.1U_0402_25V6

12

1.35V_SN

12

PJ309

2

112

12

JUMP_43X79

PC856

@

10U_0805_25V6K

10U_0805_25V6K

PL307

1 2

0.68UH_PCMC063T-R68MN_15.5A_20%

PR378

4.7_1206_5%

@

PC1103
1000P_0402_50V9-J

@

B+

1

+

PC1105

330U_2.5V_M

2

PJ317

2

112

JUMP_43X118@

PJ316

2

112

JUMP_43X118@

14A

D

+1.35V

+1.35VP
Vout=1.367V
Iocp min=13A

4 4

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

A

B

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

C

2013/08/05

2013/08/05

2013/08/05

Title

1.35VS/+0.675VS

1.35VS/+0.675VS

1.35VS/+0.675VS

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

D

of

of

of

55 59

55 59

55 59

1.0

1.0

1.0

A

1 1

+3VALW

2 2

500mA

PJ604

2

JUMP_43X39

@

112

12

PC616

4.7U_0603_6.3V6K

PR614

1 2

SUSP#{35,44,46,55,57}

EN_1_5VSP

0_0402_5%

VFB=0.8V

B

PC615

1U_0603_25V6M

12

PC618

.1U_0402_10V6-K

@

12

+5VALW

+3VS

12

PR616
100K_0402_5%

@

C

+1.5VSP +1.5VS

PU602

6

VCNTL

5

VIN1

9

VIN2

8

EN

7

POK

3

VOUT1

4

VOUT2

2

FB

GND

APL5930KAI-TRG_SO8

1

12

PR613

21.5K_0402_1%

12

PR615

24K_0402_1%

12

PC728
220P_0402_50V7K

@

12

PC617
10U_0603_6.3V6M

500mA

PJ603

2

JUMP_43X39

@

112

D

3 3

4 4

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

A

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

B

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

C

2013/08/05

2013/08/05

2013/08/05

Title

+1.35VS_VGA/+1.5VS

+1.35VS_VGA/+1.5VS

+1.35VS_VGA/+1.5VS

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet of

Date: Sheet of

Date: Sheet of

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

UMA

UMA

UMA

D

56 59

56 59

56 59

1.0

1.0

1.0

5

4

+3VS

PR701
10K_0402_5%

@

1 2

3

2

1

1_05VS_PG

PJ704

2

D D

35,44,46,55,56}

+5VALW

SUSP#

SUS_VCCP{44}

JUMP_43X79

@

PR704

@

1 2

0_0402_5%

PR994

1 2

0_0402_5%

112

@

@

PC1066

PR705

12

1 2

12

0.1U_0402_25V6

12

.1U_0402_10V6-K

47K_0402_5%

PC702

22U_0805_6.3V6M

PC709

@

1_05VS_EN

12

PC701

22U_0805_6.3V6M

1_05VS_PVIN

12

PC711

0.01U_0402_25V7K

VFB=0.6V

C C

9

PU701

1

VIN

4

EN

8

SS

2

LX1

PG

5

LX2

6

LX3

10

OUT

7

FB

GND

3

SY8868QMC_QFN10_2X2

1_05VS_LX

12

PR707
100K_0402_1%

1_05VS_FB

12

SNB_1_05VS

12

PL701

1 2

0.68UH_PCMC063T-R68MN_15.5A_20%

PR703

4.7_1206_5%

@

PC710
680P_0402_50V7K

@

PR706

12

75K_0402_1%

12

PC712
220P_0402_50V7K

12

PC703

22U_0805_6.3V6M

12

PC704

22U_0805_6.3V6M

12

PC705

22U_0805_6.3V6M

12

PC706

22U_0805_6.3V6M

5A

1

+

PC707
330U_D2_2V_Y

2

@

PJ702

2

JUMP_43X79

@

+1.05VS

112

B B

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

+1.05VS/+1.05VS_VGA

+1.05VS/+1.05VS_VGA

+1.05VS/+1.05VS_VGA

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

C

C

C

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

1

57 59

57 59

57 59

of

of

of

1.0

1.0

1.0

5

D D

C C

4

3

2

1

B B

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

3

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

blank

blank

blank

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

1

58 59

58 59

58 59

of

of

of

1.0

1.0

1.0

5

VR_IMVP_IMON{44}

+5VALW

D D

PR9345

12

@

PC1181

10P_0402_50V8J

1 2

PC1152

@

2200P_0402_50V7K

1 2

PR362

0_0402_5%

1 2

PC1154

1000P_0402_50V7K

PR9343

0_0402_5%

PR9146

0_0402_5%

499_0402_1%

12

12

@

CORE_GND

4.02K_0402_1%

1 2

PR9145

1 2

2.2_0603_5%

12

@

12

+1.05VSR

PR9265

PR9098

75_0402_1%

@

PR2

1 2

1 2

12

PC242
1U_0603_25V6M

CORE_GND

12

130_0402_1%

CORE_GND

PR31

0_0402_5%

PC1153

PR3

330P_0402_50V7K

49.9_0402_1%

1 2

CPU_VSS_SENSE{12}

C C

CPU_VCC_SENSE{10}

B B

+1.05VS +1.05VSR

PR9330

1K_0402_1%

1 2

0_0402_5%

560P_0402_50V7-K

CPU_VR_ON{10}

PR9148

0_0402_5%

PR9344

0_0402_5%

@

1 2

PR9402

PC1254

1 2

EC_VR_ON{44}

CPU_SVID_ALERT#{10}

12

12

12

@

+5VALW

VR_HOT#{44}

CPU_SVID_DAT{10}

CPU_SVID_CLK{10}

PR9149

0_0402_5%

PR9347

0_0402_5%

4

CORE_GND CORE_GND

12

12

PR9334

27.4K_0402_1%

PR9346

0_0402_5%

12

16.2K_0402_1%

CORE_GND CORE_GND

12

12

@

PR9333

16.5K_0402_1%

PR1

22

ROSC

23

COMP

24

FB

25

DIFFOUT

26

VSN

27

VSP

28

VCC

29

GND

CORE_GND

12

PC620

.1U_0402_10V6-K

@

12

PR60

PC1157

CSCOMP

12

21

20

ILIM

IOUT

ENABLE1VR_HOT#2SDIO3ALERT#4VRMP7SCLK

CORE_GND

54.9_0402_1%

470P_0402_50V7K

12

PH901

PR9338

75K_0402_1%

CORE_GND

CPU_CORECPU_CSREF

12

12

PR9340

PR9401

CSCOMP

102K_0402_1%
10_0402_1%

CSSUM

12

17

16

19

18

15

IMAX

PVCC

CSREF

CSSUM

VBOOT

CSCOMP

TSENSE

PGND

VR_RDY

5

6

12

12

12

PC622

.1U_0402_10V6-K

CORE_GND

220K_0402_5%_TSM0B224J4702RE

PC1172

2.2U_0603_6.3V6K

LG

SW

HG

BST

PU908
NCP81101MNTXG_QFN28_4X4

PC1155

0.01U_0402_25V7K

12

1 2

PR9341

0_0402_5%

14
13
12
11
10
9
8

+3VS

@

PC626

10U_0603_6.3V6M

1 2

165K_0402_1%

TSENSE
CPU_LG

CPU_HG_R

PR9331

1 2

1K_0402_1%

12

PR47

10K_0402_5%

PJ3

1 2

JUMPER

@

PR9337

CORE_GND

+5VALW

PR9332

69.8K_0402_1%

1 2

PC1156

0.01U_0402_25V7K

1 2

CPU_PH

1 2

PR80

2_0603_5%

VR_CPU_PWROK {10,44}

TSENSE

PR9147

0_0402_5%

1 2

PC1158

PC1159

68P_0402_50V8J

330P_0402_50V7K

CPU_CSREF

PC1171
1000P_0402_50V7K

1 2

CPU_HG_R

CORE_GND

CORE_GND

PC97

1 2

0.22U_0603_25V7K

CPU_B+

12

PR9339

59K_0402_1%

3

1 2

PR9335

1 2

140K_0603_1%

PR365

1 2

0_0603_5%

12

CPU_LG

12

CPU_HG

PH902

100K_0402_1%_TSM0B104F4251RZ

4

4

CPU_PH

5

321

CPU_B+

12

12

PC1065

PQ40

@

AON6414AL_DFN8-5

CPU_PH

AON6554_DFN

12

4.7_1206_5%

12

PC621
680P_0402_50V7K

For EMI request

PQ39

123 5

12

PC100

PC99

10U_0805_25V6K

0.1U_0402_25V6

PL9

1 2

0.22UH_SPS-06CZ-R22M-V1_23A_20%

PR617

12

PC98

10U_0805_25V6K

2

B+

1

PJ708

1

JUMP_43X79

2

2

@

12

PC113

10U_0805_25V6K

10U_0805_25V6K

PC989

12

12

1

+

68U_25V_M

2

PC1164

22U_0805_6.3V6M

PC1167

22U_0805_6.3V6M

@

12

12

12

PC1073

@

12

PC1162

PC1176

3A

12

PC1088

22U_0805_6.3V6M

@

12

PC1149

22U_0805_6.3V6M

22U_0805_6.3V6M

22U_0805_6.3V6M

12

PC1089

22U_0805_6.3V6M

22U_0805_6.3V6M

@

12

PC1177

22U_0805_6.3V6M

@

12

PC1165

22U_0805_6.3V6M

12

PC1178

22U_0805_6.3V6M

@

32A

12

PC1139

@

PC1170

22U_0805_6.3V6M

@

@

22U_0805_6.3V6M

12

PC1163

12

12

PC1148

22U_0805_6.3V6M

12

12

PC1160

22U_0805_6.3V6M

12

22U_0805_6.3V6M

PC1180

22U_0805_6.3V6M

CPU_CORE

PC1116

22U_0805_6.3V6M

12

PC1173

PC1174

22U_0805_6.3V6M

1

+

PC708
220U_D2_2.5VY_R6M

2 3

1

22U_0805_6.3V6M

A A

Title

Title

Security Classification

Security Classification

Security Classification

Issued Date

Issued Date

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF LC FUTURE CENTER. AND CONTAINS CONFIDENTIAL
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY LC FUTURE CENTER NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF LC FUTURE CENTER.

3

2013/08/08

2013/08/08

2013/08/08

LC Future Center Secret Data

LC Future Center Secret Data

LC Future Center Secret Data

Deciphered Date

Deciphered Date

Deciphered Date

2

2013/08/05

2013/08/05

2013/08/05

Title

PWR_CPU Core

PWR_CPU Core

PWR_CPU Core

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

C

C

C

Date: Sheet

Date: Sheet

Date: Sheet

UMA

UMA

UMA

Monday, December 09, 2013

Monday, December 09, 2013

Monday, December 09, 2013

59 59

59 59

59 59

of

of

1

of

1.0

1.0

1.0
