COMPAL LA-4821P Schematics

A

ZZZ2

ZZZ1

PCB

DAZ@

1 1

ZZZ5

MDC Cable

45@

ZZZ2

LA-4821P

MB

MB DA2@

DA2@

02/24 Change LA-4821P from mount to DA2@

ZZZ3

LS-4821P

FUNCTION_B

FUNCTION_B DA2@

DA2@

ZZZ4

LS-4822P

FP_B

FP_B DA2@

DA2@

B

C

D

E

Compal Confidential

2 2

KFT00 Schematics Document

Intel Penryn Processor with SiSM672FX + DDRII + SiS968 + SiS307ELV

2009-03-10

REV:1.0

3 3

4 4

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

A

B

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

C

2008/10/18 2009/10/18

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

D

Date: Sheet

Compal Electronics, Inc.

Cover Page

KFT00 M/B LA-4821P Schematic

147Tuesday, March 10, 2009

E

1.0

of

A

B

C

D

E

Compal Confidential

Model Name : KFT00

Fan Control

page 4

File Name : LA-4821P

1 1

CRT

page 17

Intel Penryn Processor

uPGA-478 Package

H_A#(3..35)

FSB

1066MHz

page 4,5,6

H_D#(0..63)

SiS M672FX

LCD Conn.

page 16

SiS 307ELV

page 18

PCI-Express

TEBGA-847

page 7,8,9,10,11

Thermal Sensor

page 4

Memory BUS(DDRII)

Single Channel

1.8V DDRII 533/667

Clock Generator

ICS9LPRS600C+ ICS9P935

page 14,15

200pin DDRII-SO-DIMM X2

BANK 0, 1, 2, 3

page 12,13

3 in 1 socket

page 27page 34

Finger Print Conn

page 37

Card Reader

RTS5158E

page 26

HDA Codec

ALC268

page 35

1GB/s MuTIOL IO Link

2 2

PCI-Express

SiS968

MII

TEBGA-570

page 19,20,21,22,23

New Card Socket

page 30 page 29

MINI Card x1

WLAN

LAN

RTL8201CL

page 28

PCI BUS

3.3V 33 MHz

IDSEL:AD22 (PIRQG#,PIRQH#, GNT#0, REQ#0)

USB Conn. x3

3.3V 48MHz

3.3V 24.576MHz/48Mhz

3.3V ATA-100 S-ATA

port 0

S-ATA HDD Conn.

USB

IDE

page 24

Bluetooth Conn

page 33 page 37

port 1

CDROM Conn.

page 24

Web Camera

HD Audio

MDC 1.5 Conn

Audio AMP

RJ45

3 3

page 28

LPC BUS

page 36

RTC CKT.

page 20

ENE KB926D2

page 31

Power On/Off CKT.

page 34

Touch Pad

page 33

Int.KBD

page 32

DC/DC Interface CKT.

page 39

Function /B.

page 34

BIOS

page 33

Power Circuit DC/DC

4 4

CHARGER

page 40, 41,43,44,45,46

page 42

A

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

B

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

C

2008/10/18 2009/10/18

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

D

Date: Sheet

Compal Electronics, Inc.

Block Diagrams

KFT00 M/B LA-4821P Schematic

247Tuesday, February 10, 2009

of

E

of

1.0

A

B

C

D

E

Voltage Rails

Power Plane

1 1

2 2

VIN B+ +CPU_CORE

+1.05VS +1.2VS +1.5VS +1.8V +1.8VS +2.5VS +3VALW +3VS +5VALW +5VS +VSB +RTCVCC

STATE

Full ON

S1(Power On Suspend)

S3 (Suspend to RAM)

S4 (Suspend to Disk)

S5 (Soft OFF)

Description

Adapter power supply (19V) AC or battery power rail for power circuit. Core voltage for CPU

0.9V switched power rail for DDR terminator+0.9VS ( Actual +0.9V )

1.05V switched power rail

1.2V switched power rail

1.5V switched power rail

1.8V power rail for DDR

1.8V switched power rail

2.5V switched power rail

3.3V always on power rail

3.3V switched power rail 5V always on power rail 5V switched power rail VSB always on power rail RTC power

SIGNAL

SLP_S3#SLP_S1#

LOW

HIGH HIGH HIGH

LOW

LOW LOW LOW

SLP_S4#

HIGH

LOWLOWLOW

SLP_S5#

HIGHHIGHHIGHHIGH

HIGH

LOW

S3S1

N/A N/A N/A

OFF

ON ON

ON

ON ON ON

ON

OFF

ON ON

OFF ON

OFF

ON ON

ON

OFF

ON

ONONON

+VALW

+V +VS Clock

ON

OFF

ON

OFF

S5

N/AN/AN/A

OFF OFF OFFOFF OFFOFF OFFOFF OFF OFF OFF ON*ON OFF ON* OFF ON*ON ON

ON

OFF

ONON

LOW

OFF

Note : ON* means that this power plane is ON only with AC power available, otherwise it is OFF.

External PCI Devices

DEVICE REQ/GNT #

EC SM Bus1 address

Device

Smart Battery EEPROM(24C16/02)

IDSEL #

Address

1010 000X b

PIRQ

EC SM Bus2 address

Device

ADI ADM1032 SMC EMC1402-1

Address

1001 100X b0001 011X b

M672 SM Bus address

Device

Clock Generator

DDR DIMM0 DDR DIMM1

Address

1101 001Xb

1010 000Xb 1010 001Xb

PROJECT ID Table

3 3

4 4

PROJECT_ID1

GPIO5 KFT00 0 KSW01 KSW91

A

PROJECT_ID0

GPIO0

0

1

0 11

SKU ID Table

R311

Vcc 3.3V +/- 5%

100K +/- 5%Ra

Ra~ R312

8.2K_0402_5%

12_C@

18K_0402_5%

12_MP@

Rb~ R311

Board ID

0 1 2

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

B

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

C

2008/10/18 2009/10/18

Rb

0

8.2K +/- 5% 18K +/- 5%

Compal Secret Data

V min

AD_BID

0 V

V typ

AD_BID

0 V 0 V

0.217 V 0.250 V 0.288 V

0.439 V 0.503 V 0.575 V

Deciphered Date

D

V

AD_BID

Title

Size Document Number Rev

B

KFT00 M/B LA-4821P Schematic

Date: Sheet

Rb BOM Structure

max

12_A@ 12_C@ 12_MP@

Compal Electronics, Inc.

Notes List

1.0

347Tuesday, March 10, 2009

E

1.0

of

5

4

3

2

1

5

H_A#[3..35] H_REQ#[0..4] H_RS#[0..2]

H_ADSTB#0<7>

H_ADSTB#1<7> H_A20M#<20>

H_FERR#<20> H_IGNNE#<20>

H_STPCLK#<20> H_INTR<20> H_NMI<20> H_SMI#<20>

H_STPCLK# H_INIT# H_IGNNE# H_SMI# H_A20M# H_NMI H_INTR H_THERMTRIP# H_FERR#

H_BR0# H_RESET# ITP_DBRESET#

JCPU1A

H_A#3 H_A#4 H_A#5 H_A#6 H_A#7 H_A#8 H_A#9 H_A#10 H_A#11 H_A#12 H_A#13 H_A#14 H_A#15 H_A#16

H_REQ#0 H_REQ#1 H_REQ#2 H_REQ#3 H_REQ#4

H_A#17 H_A#18 H_A#19 H_A#20 H_A#21 H_A#22 H_A#23 H_A#24 H_A#25 H_A#26 H_A#27 H_A#28 H_A#29 H_A#30 H_A#31 H_A#32 H_A#33 H_A#34 H_A#35

H_A20M# H_FERR# H_IGNNE#

H_STPCLK# H_INTR H_NMI H_SMI#

JCPU1A

J4

A[3]#

L5

A[4]#

L4

A[5]#

K5

A[6]#

M3

A[7]#

N2

A[8]#

J1

A[9]#

N3

A[10]#

P5

A[11]#

P2

A[12]#

L2

A[13]#

P4

A[14]#

P1

A[15]#

R1

A[16]#

M1

ADSTB[0]#

K3

REQ[0]#

H2

REQ[1]#

K2

REQ[2]#

J3

REQ[3]#

L1

REQ[4]#

Y2

A[17]#

U5

A[18]#

R3

A[19]#

W6

A[20]#

U4

A[21]#

Y5

A[22]#

U1

A[23]#

R4

A[24]#

T5

A[25]#

T3

A[26]#

W2

A[27]#

W5

A[28]#

Y4

A[29]#

U2

A[30]#

V4

A[31]#

W3

A[32]#

AA4

A[33]#

AB2

A[34]#

AA3

A[35]#

V1

ADSTB[1]#

A6

A20M#

A5

FERR#

C4

IGNNE#

D5

STPCLK#

C6

LINT0

B4

LINT1

A3

SMI#

M4

RSVD[01]

N5

RSVD[02]

T2

RSVD[03]

V3

RSVD[04]

B2

RSVD[05]

C3

RSVD[06]

D2

RSVD[07]

D22

RSVD[08]

D3

RSVD[09]

F6

RSVD[10]

Merom Ball-out Rev 1a

CONN@

ADDR GROUP 0 ADDR GROUP 1

XDP/ITP SIGNALS

THERMAL

PROCHOT#

THERMDA THERMDC

ICH

THERMTRIP#

H CLK

RESERVED

ADS# BNR#

BPRI#

DEFER#

DRDY# DBSY#

BR0#

IERR#

INIT#

LOCK#

CONTROL

RESET#

RS[0]# RS[1]# RS[2]#

TRDY#

HIT#

HITM#

BPM[0]# BPM[1]# BPM[2]# BPM[3]#

PRDY# PREQ#

TCK

TDO TMS

TRST#

DBR#

BCLK[0] BCLK[1]

H1 E2 G5

H5 F21 E1

F1

H_IERR#

D20

H_INIT#

B3 H4

H_RESET#

C1

H_RS#0

F3

H_RS#1

F4

H_RS#2

G3 G2

G6 E4

AD4 AD3 AD1 AC4 AC2

H_PREQ#

AC1

ITP_TCK

AC5

ITP_TDI

AA6

TDI

AB3

ITP_TMS

AB5

ITP_TRST#

AB6

ITP_DBRESET#

C20

H_PROCHOT#

D21

THERMDA_R

A24

THERMDC_R

B25

H_THERMTRIP#

C7

C114 0.1U_0402_16V4ZC114 0.1U_0402_16V4Z

1 2

A22 A21

H_THERMDA, H_THERMDC routing together, Trace width / Spacing = 10 / 10 mil

Intel :Don't Pull-up SiS : Pull-up 56ohm (Mount) Intel :Don't Pull-up SiS : Pull-up 56ohm (Mount) Intel :Don't Pull-up SiS : Pull-up 56ohm (Mount) Intel :Don't Pull-up SiS : Pull-up 56ohm (Mount) Intel :Don't Pull-up SiS : Pull-up 56ohm (Mount) Intel :Don't Pull-up SiS : Pull-up 56ohm (Mount) Intel :Don't Pull-up SiS : Pull-up 56ohm (Mount) Intel : Pull-up 56ohm (Mount) SiS : Pull-up 56ohm (Mount) Intel : Pull-up 56ohm (Mount) SiS : Pull-up 56ohm (Mount)

Intel :Don't Pull-up SiS : Pull-up 56ohm (Mount) Intel :Don't Pull-up SiS : Pull-up 56ohm (Un-Mount) Intel :Don't Pull-up SiS : Pull-up 150ohm (Mount)

4

Trace length must short

H_ADS# <7> H_BNR# <7> H_BPRI# <7>

H_DEFER# <7> H_DRDY# <7> H_DBSY# <7>

H_BR0# <7>

H_INIT# <20> H_LOCK# <7> H_RESET# <7>

H_TRDY# <7> H_HIT# <7>

H_HITM# <7>

Intel :Pull-up 56ohm (Un-Mount) SiS : Pull-up 56ohm (Mount)

Intel :Pull-up 56ohm (Mount) SiS : Pull-up 54.9ohm (Mount)

Intel :Pull-up 56ohm (Mount) SiS : Pull-up 75ohm (Mount)

Checklist recommend 39 Ohm

EMC1402

1/29 change to EMC1402 pn

Connect SB SYS_RESET# or just left NC

ITP_DBRESET# H_PROCHOT# <20>

1 2

R19 0_0402_5%R19 0_0402_5%

1 2

R20 0_0402_5%R20 0_0402_5%

THERMDA THERMDC

H_THERMTRIP# <20>

+3VS

1

C2

2

1 2

THERMDA THERMDC

2200P_0402_50V7K

R18 10K_0402_5%R18 10K_0402_5%

Address:100_1100

H_CLK_DP0 <14> H_CLK_DN0 <14>

FAN1 Conn

U1

EN_FAN1<31>

ADM1032ARMZ_MSOP8

MEROM@

Security Classification

2008/10/18 2009/10/18

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18 2009/10/18

3

Compal Secret Data

Deciphered Date

+VCC_FAN1

R815

1 2

330_0402_5%

2

+3VS

+5VS

EN_FAN1_R

12

C769

0.047U_0402_16V7K

FAN_SPEED1<31>

Place close to CPU within 500mil

+1.05VS

H_PREQ# H_IERR# ITP_TMS ITP_TDI H_PROCHOT# ITP_TCK ITP_TRST#

C1

0.1U_0402_16V4Z

1 2

1 2 3 4

C3 10U_0805_10V4ZC3 10U_0805_10V4Z

U2

1

VEN

2

VIN

3

VO

4

VSET

G990P11U_SOP8

R85 56_0402_5%@R85 56_0402_5%@

1 2

R115 56_0402_5%R115 56_0402_5%

1 2

R84 56_0402_5%R84 56_0402_5%

1 2

R83 150_0402_1%R83 150_0402_1%

1 2

R113 56_0402_5%R113 56_0402_5%

1 2

R69 27.4_0402_1%R69 27.4_0402_1%

1 2

R61 680_0402_5%R61 680_0402_5%

1 2

CRB pull 75 Ohm

Add Michael 2008/5/30 for second source

U1

LM95245CIMMX NOPB MSOP 8P

NS@

U1

VDD D+

ALERT/THERM2

DTHERM

EMC1402-1-ACZL-TR

SMSC@

1 2

GND GND GND GND

+3VS

12

R21

R21 10K_0402_5%

10K_0402_5%

1

C6

C6 1000P_0402_50V7K

1000P_0402_50V7K

2

Title

Size Document Number Rev

B

Date: Sheet

SCLK

SDATA

GND

8 7 6 5

R706 10K_0402_5%

EC_SMB_CK2 <31> EC_SMB_DA2 <31>

12

PENRYN@

+5VS

12

D1

D1 BAS16_SOT23-3

BAS16_SOT23-3

D2

1 2

BAS16_SOT23-3

C4 10U_0805_10V4ZC4 10U_0805_10V4Z

1 2

C5

1000P_0402_50V7K

1 2

40mil

+VCC_FAN1

ACES_85205-03001

Compal Electronics, Inc.

Merom (1/3)

KFT00 M/B LA-4821P Schematic

447Tuesday, March 10, 2009

1

1 2 3

4 5

+3VS

JFAN1

1 2 3

GND GND

CONN@

of

1.0

H_A#[3..35]<7> H_REQ#[0..4]<7> H_RS#[0..2]<7>

D D

C C

B B

+1.05VS

CPU to SB interface

R120 56_0402_5%R120 56_0402_5%

1 2

R141 56_0402_5%R141 56_0402_5%

1 2

R128 56_0402_5%R128 56_0402_5%

1 2

R144 56_0402_5%R144 56_0402_5%

1 2

R148 56_0402_5%R148 56_0402_5%

1 2

R137 56_0402_5%R137 56_0402_5%

1 2

R140 56_0402_5%R140 56_0402_5%

1 2

R127 56_0402_5%R127 56_0402_5%

A A

1 2

R208 56_0402_5%R208 56_0402_5%

1 2

+1.05VS

R114 51_0402_1%R114 51_0402_1%

1 2

R136 56_0402_5%@R136 56_0402_5%@

1 2

R112 150_0402_1%R112 150_0402_1%

1 2

5

4

3

2

1

GTL_REF

1

C368

C368 1U_0603_10V4Z

1U_0603_10V4Z

2

D D

SiS Recommend

Close to CPU pin AD26 within 500mils.

C C

Width=20 mil

B B

layout note: Route TEST3 & TEST5 traces on ground referenced layer to the TPs

1

C814

C814 220P_0402_50V7K

220P_0402_50V7K

2

H_DSTBN#0<7> H_DSTBP#0<7> H_DINV#0<7>

+1.05VS

R321

1K_0402_1%

R319

2K_0402_1%

1 2

H_DSTBN#1<7> H_DSTBP#1<7> H_DINV#1<7>

R111 1K_0402_5%@R111 1K_0402_5%@ R98 1K_0402_5%@R98 1K_0402_5%@

C364 0.1U_0402_16V4Z@C364 0.1U_0402_16V4Z@

1 2

12 12

T3

T3 T2

T2 T23

T23

CPU_BSEL0<14> CPU_BSEL1<14> CPU_BSEL2<14>

PAD

PAD PAD

PAD

CPU_BSEL CPU_BSEL2 CPU_BSEL1

@

@ @

@

H_D#0 H_D#1 H_D#2 H_D#3 H_D#4 H_D#5 H_D#6 H_D#7 H_D#8 H_D#9 H_D#10 H_D#11 H_D#12 H_D#13 H_D#14 H_D#15

H_D#16 H_D#17 H_D#18 H_D#19 H_D#20 H_D#21 H_D#22 H_D#23 H_D#24 H_D#25 H_D#26 H_D#27 H_D#28 H_D#29 H_D#30 H_D#31

GTL_REF

TEST1 TEST2 TEST3 TEST4 TEST5 TEST6

JCPU1B

E22

D[0]#

F24

D[1]#

E26

D[2]#

G22

D[3]#

F23

D[4]#

G25

D[5]#

E25

D[6]#

E23

D[7]#

K24

D[8]#

G24

D[9]#

J24

D[10]#

J23

D[11]#

H22

D[12]#

F26

D[13]#

K22

D[14]#

H23

D[15]#

J26

DSTBN[0]#

H26

DSTBP[0]#

H25

DINV[0]#

N22

D[16]#

K25

D[17]#

P26

D[18]#

R23

D[19]#

L23

D[20]#

M24

D[21]#

L22

D[22]#

M23

D[23]#

P25

D[24]#

P23

D[25]#

P22

D[26]#

T24

D[27]#

R24

D[28]#

L25

D[29]#

T25

D[30]#

N25

D[31]#

L26

DSTBN[1]#

M26

DSTBP[1]#

N24

DINV[1]#

AD26

GTLREF

C23

TEST1

D25

TEST2

C24

TEST3

AF26

TEST4

AF1

TEST5

A26

TEST6

B22

BSEL[0]

B23

BSEL[1]

C21

BSEL[2]

Merom Ball-out Rev 1a

CONN@

CPU_BSEL0

DATA GRP 0

DATA GRP 2DATA GRP 3

DSTBN[2]# DSTBP[2]#

DINV[2]#

DATA GRP 1

DSTBN[3]# DSTBP[3]#

DINV[3]# COMP[0]

MISC

COMP[1] COMP[2] COMP[3]

DPRSTP#

DPSLP#

PWRGOOD

D[32]# D[33]# D[34]# D[35]# D[36]# D[37]# D[38]# D[39]# D[40]# D[41]# D[42]# D[43]# D[44]# D[45]# D[46]# D[47]#

D[48]# D[49]# D[50]# D[51]# D[52]# D[53]# D[54]# D[55]# D[56]# D[57]# D[58]# D[59]# D[60]# D[61]# D[62]# D[63]#

DPWR#

SLP#

PSI#

Y22 AB24 V24 V26 V23 T22 U25 U23 Y25 W22 Y23 W24 W25 AA23 AA24 AB25 Y26 AA26 U22

AE24 AD24 AA21 AB22 AB21 AC26 AD20 AE22 AF23 AC25 AE21 AD21 AC22 AD23 AF22 AC23 AE25 AF24 AC20

R26 U26 AA1 Y1

E5 B5 D24 D6 D7 AE6

H_D#32 H_D#33 H_D#34 H_D#35 H_D#36 H_D#37 H_D#38 H_D#39 H_D#40 H_D#41 H_D#42 H_D#43 H_D#44 H_D#45 H_D#46 H_D#47

H_D#48 H_D#49 H_D#50 H_D#51 H_D#52 H_D#53 H_D#54 H_D#55 H_D#56 H_D#57 H_D#58 H_D#59 H_D#60 H_D#61 H_D#62 H_D#63

COMP0 COMP1 COMP2 COMP3

H_DPSLP# H_DPWR#_R H_PWRGOOD H_CPUSLP#

001133

166

200

01

0

1

0

H_D#[0..63]

H_DSTBN#2 <7> H_DSTBP#2 <7> H_DINV#2 <7>

H_DSTBN#3 <7> H_DSTBP#3 <7>

1 2 1 2 1 2 1 2

H_DINV#3 <7>

H_DPRSTP# <25,46> H_DPSLP# <25>

H_PWRGOOD <7> H_CPUSLP# <20> H_PSI# <46>

1 2

R126 0_0402_5%

R324 27.4_0402_1%R324 27.4_0402_1% R323 54.9_0402_1%R323 54.9_0402_1% R42 27.4_0402_1%R42 27.4_0402_1% R44 54.9_0402_1%R44 54.9_0402_1%

H_DPWR#_R H_DPWR#

R131

R131 10_0402_5%

10_0402_5%

H_D#[0..63] <7>

Resistor placed within

0.5" of CPU pin.Trace should be at least 25 mils away from any other toggling signal. COMP[0,2] trace width is 18 mils. COMP[1,3] trace width is 4 mils.

@

+CPU_CORE

H_DPWR# <7>

JCPU1C

A7

VCC[001]

A9

VCC[002]

A10

VCC[003]

A12

VCC[004]

A13

VCC[005]

A15

VCC[006]

A17

VCC[007]

A18

VCC[008]

A20

VCC[009]

B7

VCC[010]

B9

VCC[011]

B10

VCC[012]

B12

VCC[013]

B14

VCC[014]

B15

VCC[015]

B17

VCC[016]

B18

VCC[017]

B20

VCC[018]

C9

VCC[019]

C10

VCC[020]

C12

VCC[021]

C13

VCC[022]

C15

VCC[023]

C17

VCC[024]

C18

VCC[025]

D9

VCC[026]

D10

VCC[027]

D12

VCC[028]

D14

VCC[029]

D15

VCC[030]

D17

VCC[031]

D18

VCC[032]

E7

VCC[033]

E9

VCC[034]

E10

VCC[035]

E12

VCC[036]

E13

VCC[037]

E15

VCC[038]

E17

VCC[039]

E18

VCC[040]

E20

VCC[041]

F7

VCC[042]

F9

VCC[043]

F10

VCC[044]

F12

VCC[045]

F14

VCC[046]

F15

VCC[047]

F17

VCC[048]

F18

VCC[049]

F20

VCC[050]

AA7

VCC[051]

AA9

VCC[052]

AA10

VCC[053]

AA12

VCC[054]

AA13

VCC[055]

AA15

VCC[056]

AA17

VCC[057]

AA18

VCC[058]

AA20

VCC[059]

AB9

VCC[060]

AC10

VCC[061]

AB10

VCC[062]

AB12

VCC[063]

AB14

VCC[064]

AB15

VCC[065]

AB17

VCC[066]

AB18

VCC[067]

Merom Ball-out Rev 1a

CONN@

VCC[068] VCC[069] VCC[070] VCC[071] VCC[072] VCC[073] VCC[074] VCC[075] VCC[076] VCC[077] VCC[078] VCC[079] VCC[080] VCC[081] VCC[082] VCC[083] VCC[084] VCC[085] VCC[086] VCC[087] VCC[088] VCC[089] VCC[090] VCC[091] VCC[092] VCC[093] VCC[094] VCC[095] VCC[096] VCC[097] VCC[098] VCC[099] VCC[100]

VCCP[01] VCCP[02] VCCP[03] VCCP[04] VCCP[05] VCCP[06] VCCP[07] VCCP[08] VCCP[09] VCCP[10] VCCP[11] VCCP[12] VCCP[13] VCCP[14] VCCP[15] VCCP[16]

VCCA[01] VCCA[02]

VID[0] VID[1] VID[2] VID[3] VID[4] VID[5] VID[6]

VCCSENSE

VSSSENSE

AB20 AB7 AC7 AC9 AC12 AC13 AC15 AC17 AC18 AD7 AD9 AD10 AD12 AD14 AD15 AD17 AD18 AE9 AE10 AE12 AE13 AE15 AE17 AE18 AE20 AF9 AF10 AF12 AF14 AF15 AF17 AF18 AF20

G21 V6 J6 K6 M6 J21 K21 M21 N21 N6 R21 R6 T21 T6 V21 W21

B26 C26

AD6 AF5 AE5 AF4 AE3 AF3 AE2

AF7

AE7

.

+CPU_CORE

VCCSENSE

VSSSENSE

CPU_VID0 <46> CPU_VID1 <46> CPU_VID2 <46> CPU_VID3 <46> CPU_VID4 <46> CPU_VID5 <46> CPU_VID6 <46>

R27

R24 100_0402_1%R24 100_0402_1%

Length match within 25 mils.

Place this cap more close to B26/C26 rather than 10UF

1

+

C80

C80 330U_D2E_2.5VM_R9

330U_D2E_2.5VM_R9

2

20mils

1

C438

0.01U_0402_16V7K

2

100_0402_1%

1 2

100_0402_1%

VCCSENSE <46>

VSSSENSE <46>

+1.05VS

1

C432

C432 10U_0805_10V4Z

10U_0805_10V4Z

2

+CPU_CORE

+1.5VS

The trace width/space/other is

+1.05VS

R121 56_0402_5%R121 56_0402_5%

A A

1 2

R143 56_0402_5%R143 56_0402_5%

1 2

R133 56_0402_5%@R133 56_0402_5%@

1 2

R119 56_0402_5%@R119 56_0402_5%@

1 2

C650 0.1U_0402_16V4Z@C650 0.1U_0402_16V4Z@

1 2

5

H_CPUSLP# H_DPSLP# H_PWRGOOD H_DPWR#

H_PWRGOOD

Intel :Don't Pull-up SiS : Pull-up 56ohm (Mount)

SiS Recommend Intel :Pull-up 56ohm (Un-Mount) SiS : Pull-up 56ohm (Mount) Intel :Don't Pull-up (Connecte to ICH) SiS : Pull-up 56ohm (Un-Mount) Intel :Don't Pull-up SiS : Pull-up 56ohm (Un-Mount)

Intel :Don't Pull-down SiS :Pull-down Cap (Un-Mount)

4

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

H_DPRSTP#

2008/10/18 2009/10/18

3

C851 470P_0402_50V7K@C851 470P_0402_50V7K@

1 2

Compal Secret Data

Deciphered Date

2

20/7/25.

Close to CPU pin within 500mils.

Compal Electronics, Inc.

Title

Size Document Number Rev

B

KFT00 M/B LA-4821P Schematic

Date: Sheet

Compal Electronics, Inc.

Merom (2/3)

547Tuesday, March 10, 2009

1

1.0

of

5

4

3

2

1

+CPU_CORE

JCPU1D

A4

VSS[001]

A8

VSS[002]

A11

VSS[003]

A14

VSS[004]

A16

VSS[005]

A19

VSS[006]

D D

C C

B B

A23

VSS[007]

AF2

VSS[008]

B6

VSS[009]

B8

VSS[010]

B11

VSS[011]

B13

VSS[012]

B16

VSS[013]

B19

VSS[014]

B21

VSS[015]

B24

VSS[016]

C5

VSS[017]

C8

VSS[018]

C11

VSS[019]

C14

VSS[020]

C16

VSS[021]

C19

VSS[022]

C2

VSS[023]

C22

VSS[024]

C25

VSS[025]

D1

VSS[026]

D4

VSS[027]

D8

VSS[028]

D11

VSS[029]

D13

VSS[030]

D16

VSS[031]

D19

VSS[032]

D23

VSS[033]

D26

VSS[034]

E3

VSS[035]

E6

VSS[036]

E8

VSS[037]

E11

VSS[038]

E14

VSS[039]

E16

VSS[040]

E19

VSS[041]

E21

VSS[042]

E24

VSS[043]

F5

VSS[044]

F8

VSS[045]

F11

VSS[046]

F13

VSS[047]

F16

VSS[048]

F19

VSS[049]

F2

VSS[050]

F22

VSS[051]

F25

VSS[052]

G4

VSS[053]

G1

VSS[054]

G23

VSS[055]

G26

VSS[056]

H3

VSS[057]

H6

VSS[058]

H21

VSS[059]

H24

VSS[060]

J2

VSS[061]

J5

VSS[062]

J22

VSS[063]

J25

VSS[064]

K1

VSS[065]

K4

VSS[066]

K23

VSS[067]

K26

VSS[068]

L3

VSS[069]

L6

VSS[070]

L21

VSS[071]

L24

VSS[072]

M2

VSS[073]

M5

VSS[074]

M22

VSS[075]

M25

VSS[076]

N1

VSS[077]

N4

VSS[078]

N23

VSS[079]

N26

VSS[080] VSS[081]P3VSS[162]

Merom Ball-out Rev 1a

VSS[082] VSS[083] VSS[084] VSS[085] VSS[086] VSS[087] VSS[088] VSS[089] VSS[090] VSS[091] VSS[092] VSS[093] VSS[094] VSS[095] VSS[096] VSS[097] VSS[098] VSS[099] VSS[100] VSS[101] VSS[102] VSS[103] VSS[104] VSS[105] VSS[106] VSS[107] VSS[108] VSS[109] VSS[110] VSS[111] VSS[112] VSS[113] VSS[114] VSS[115] VSS[116] VSS[117] VSS[118] VSS[119] VSS[120] VSS[121] VSS[122] VSS[123] VSS[124] VSS[125] VSS[126] VSS[127] VSS[128] VSS[129] VSS[130] VSS[131] VSS[132] VSS[133] VSS[134] VSS[135] VSS[136] VSS[137] VSS[138] VSS[139] VSS[140] VSS[141] VSS[142] VSS[143] VSS[144] VSS[145] VSS[146] VSS[147] VSS[148] VSS[149] VSS[150] VSS[151] VSS[152] VSS[153] VSS[154] VSS[155] VSS[156] VSS[157] VSS[158] VSS[159] VSS[160] VSS[161]

VSS[163]

P6 P21 P24 R2 R5 R22 R25 T1 T4 T23 T26 U3 U6 U21 U24 V2 V5 V22 V25 W1 W4 W23 W26 Y3 Y6 Y21 Y24 AA2 AA5 AA8 AA11 AA14 AA16 AA19 AA22 AA25 AB1 AB4 AB8 AB11 AB13 AB16 AB19 AB23 AB26 AC3 AC6 AC8 AC11 AC14 AC16 AC19 AC21 AC24 AD2 AD5 AD8 AD11 AD13 AD16 AD19 AD22 AD25 AE1 AE4 AE8 AE11 AE14 AE16 AE19 AE23 AE26 A2 AF6 AF8 AF11 AF13 AF16 AF19 AF21 A25 AF25

.

C47

C47 330U_D2E_2.5VM_R9

330U_D2E_2.5VM_R9

10U_0805_6.3V6M

2 x 330uF(9mOhm/2) 2 x 330uF(9mOhm/2)

1

+

2

+CPU_CORE

1

C394

2

1

+

C350

@

2

330U_D2E_2.5VM_R9

South Side Secondary North Side Secondary

1

C383

10U_0805_6.3V6M

2

1

C408

2

10U_0805_6.3V6M

(Place these capacitors on South side,Secondary Layer)

+CPU_CORE

1

C379

2

1

C378

10U_0805_6.3V6M

2

1

C377

2

10U_0805_6.3V6M

(Place these capacitors on North side,Secondary Layer)

+CPU_CORE

1

C107

10U_0805_6.3V6M

2

1

C106

2

1

C105

2

10U_0805_6.3V6M

(Place these capacitors on South side,Primary Layer)

+CPU_CORE

1

C77

2

1

C76

10U_0805_6.3V6M

2

1

C75

2

10U_0805_6.3V6M

(Place these capacitors on North side,Primary Layer)

+CPU-CORE Decoupling SPCAP,Polymer

MLCC 0805 X5R

+1.05VS

1

2

0.1U_0402_16V4Z

C,uF ESR, mohm ESL,nH 6X330uF 9m ohm/6 1.8nH/6

32X22uF 3m ohm/32 0.6nH/32 32X10uF 3m ohm/32 0.6nH/32

1

C97

C87

0.1U_0402_16V4Z

2

0.1U_0402_16V4Z

1

C81

2

1

2

1

2

1

2

1

2

0.1U_0402_16V4Z

+CPU_CORE

1

+

C347

330U_D2E_2.5VM_R9

2

C409

C376

C104

C74

1

C410

2

10U_0805_6.3V6M

1

C375

2

10U_0805_6.3V6M

1

C103

2

10U_0805_6.3V6M

1

C84

2

10U_0805_6.3V6M

1

C96

2

0.1U_0402_16V4Z

1

+

C169

2

330U_D2E_2.5VM_R9

1

C411

10U_0805_6.3V6M

2

1

C385

10U_0805_6.3V6M

2

1

C89

10U_0805_6.3V6M

2

1

C78

10U_0805_6.3V6M

2

1

C83

2

C73

0.1U_0402_16V4Z

2

1

C412

2

10U_0805_6.3V6M

1

C393

2

10U_0805_6.3V6M

1

C46

2

10U_0805_6.3V6M

1

C88

2

10U_0805_6.3V6M

1

C392

10U_0805_6.3V6M

2

1

C384

10U_0805_6.3V6M

2

1

C90

10U_0805_6.3V6M

2

1

C85

10U_0805_6.3V6M

2

A A

Security Classification

2008/10/18 2009/10/18

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18 2009/10/18

3

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

2

Date: Sheet

Compal Electronics, Inc.

Merom (3/3)

KFT00 M/B LA-4821P Schematic

647Tuesday, February 10, 2009

1

1.0

of

5

+1.05VS

12

R210

75_0402_1%

D D

12

R202

150_0402_1%

C C

B B

+1.8VS +1.8VS

L40

A A

L40

1 2

MBK1608121YZF_0603

1

C454

C454 10U_0805_10V4Z

10U_0805_10V4Z

2

1 2

R399 0_0402_5%R399 0_0402_5%

1

C191

0.01U_0402_16V7K

2

1

C212

2

0.01U_0402_16V7K

1

C472

0.1U_0402_16V4Z

2

5

1

C200

0.1U_0402_16V4Z

2

H_CLK_DP1<14> H_CLK_DN1<14>

PAD

T30

PAD

T5

@

@ @

H_DPWR#<5>

H_DEFER#<4> H_TRDY#<4> H_RESET#<4> H_PWRGOOD<5> H_BPRI#<4> H_BR0#<4> H_RS#[0..2]<4>

H_REQ#[0..4]<4>

@

H_LOCK#<4>

H_ADS#<4> H_HITM#<4> H_HIT#<4> H_DRDY#<4> H_DBSY#<4> H_BNR#<4>

H_ADSTB#0<4> H_ADSTB#1<4> H_A#[3..35]<4>

C1XAVDD:10mA C4XAVDD:12mA

C1XAVDD

1

C481

0.01U_0402_16V7K

2

C1XAVSS

C1XAVDD C1XAVSS

C4XAVDD C4XAVSS

NB_GTLREF

PCREQ# EDRDY#

H_DPWR#

H_CLK_DP1 H_CLK_DN1

H_LOCK# H_DEFER# H_TRDY# H_RESET# H_PWRGOOD H_BPRI# H_BR0#

H_RS#0 H_RS#1 H_RS#2

H_ADS# H_HITM# H_HIT# H_DRDY# H_DBSY# H_BNR#

H_REQ#0 H_REQ#1 H_REQ#2 H_REQ#3 H_REQ#4

H_ADSTB#0 H_ADSTB#1

H_A#3 H_A#4 H_A#5 H_A#6 H_A#7 H_A#8 H_A#9 H_A#10 H_A#11 H_A#12 H_A#13 H_A#14 H_A#15 H_A#16 H_A#17 H_A#18 H_A#19 H_A#20 H_A#21 H_A#22 H_A#23 H_A#24 H_A#25 H_A#26 H_A#27 H_A#28 H_A#29 H_A#30 H_A#31 H_A#32 H_A#33 H_A#34 H_A#35

1 2

MBK1608121YZF_0603

1

C455

C455 10U_0805_10V4Z

10U_0805_10V4Z

2

1 2

R400 0_0402_5%R400 0_0402_5%

B16 C17

A17 B18

W24

U24 R24 N24 L21

R34 P32

E21

F18

G18

L32 P30 P31 F21 P28 N30 P33

K34

M31

K33

M34

N34 N32

M33

L34

M32

T34 R30 R29 R32 P34

U34

AA34

T32 T28 T31 T33 T30 U32 U30 V34 U29 V33 V32 V28 V31

W34

Y33

W32

V30

W30

Y34 Y28

W29

Y32 Y30

Y31 AA32 AA30 AA29 AB33 AB34 AB32 AC34 AB30 AB31

L31

4

U30C

C1XAVDD C1XAVSS

C4XAVDD C4XAVSS

HVREF HVREF HVREF HVREF HVREF

PCREQ# EDRDY#

DPWR#

CPUCLK CPUCLK#

HLOCK# DEFER# HTRDY# CPURST# CPUPWRGD BPRI# BREQ0#

RS0# RS1# RS2#

ADS# HITM# HIT# DRDY# DBSY# BNR#

HREQ0# HREQ1# HREQ2# HREQ3# HREQ4#

HASTB0# HASTB1#

HA3# HA4# HA5# HA6# HA7# HA8# HA9# HA10# HA11# HA12# HA13# HA14# HA15# HA16# HA17# HA18# HA19# HA20# HA21# HA22# HA23# HA24# HA25# HA26# HA27# HA28# HA29# HA30# HA31# HA32# HA33# HA34# HA35#

S IC SISM672FXA1 TEBGA 847P

1

C470

0.1U_0402_16V4Z

2

4

Host

1

C479

0.01U_0402_16V7K

2

HDSTBN0# HDSTBN1# HDSTBN2# HDSTBN3#

HDSTBP0# HDSTBP1# HDSTBP2# HDSTBP3#

HPCOMP HNCOMP

C4XAVDD

C4XAVSS

HD0# HD1# HD2# HD3# HD4# HD5# HD6# HD7# HD8#

HD9# HD10# HD11# HD12# HD13# HD14# HD15# HD16# HD17# HD18# HD19# HD20# HD21# HD22# HD23# HD24# HD25# HD26# HD27# HD28# HD29# HD30# HD31# HD32# HD33# HD34# HD35# HD36# HD37# HD38# HD39# HD40# HD41# HD42# HD43# HD44# HD45# HD46# HD47# HD48# HD49# HD50# HD51# HD52# HD53# HD54# HD55# HD56# HD57# HD58# HD59# HD60# HD61# HD62# HD63#

DBI0# DBI1# DBI2# DBI3#

3

H_D#0

N29

H_D#1

M30

H_D#2

M28

H_D#3

L30

H_D#4

L29

H_D#5

K28

H_D#6

K31

H_D#7

K30

H_D#8

H31

H_D#9

G34

H_D#10

H32

H_D#11

G32

H_D#12

K32

H_D#13

F34

H_D#14

F33

H_D#15

F32

H_D#16

H28

H_D#17

J30

H_D#18

H30

H_D#19

G29

H_D#20

J29

H_D#21

G30

H_D#22

F30

H_D#23

D33

H_D#24

D34

H_D#25

B32

H_D#26

B33

H_D#27

C34

H_D#28

D31

H_D#29

A32

H_D#30

A31

H_D#31

C31

H_D#32

B30

H_D#33

C30

H_D#34

A30

H_D#35

D28

H_D#36

G28

H_D#37

C29

H_D#38

C28

H_D#39

E28

H_D#40

E27

H_D#41

C27

H_D#42

G26

H_D#43

E26

H_D#44

D26

H_D#45

B26

H_D#46

A26

H_D#47

C26

H_D#48

G22

H_D#49

C24

H_D#50

A25

H_D#51

B24

H_D#52

C25

H_D#53

A24

H_D#54

E23

H_D#55

E25

H_D#56

G24

H_D#57

D22

H_D#58

C22

H_D#59

E22

H_D#60

C23

H_D#61

A23

H_D#62

A22

H_D#63

B22

H_DINV#0

J32

H_DINV#1

E32

H_DINV#2

F27

H_DINV#3

F23

H_DSTBN#0

H33

H_DSTBN#1

E31

H_DSTBN#2

B28

H_DSTBN#3

D24

H_DSTBP#0

H34

H_DSTBP#1

D32

H_DSTBP#2

A28

H_DSTBP#3

E24

H_PCOMP

A21 C21

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

R175 10_0402_5%R175 10_0402_5%

H_NCOMP

R188 110_0402_1%R188 110_0402_1%

H_D#[0..63] <5>

V_AVDD_PCIE_1.2V

SB_PCIE_WAKE#<21,29,30>

INT_N_A<9,19>

H_DINV#0 <5> H_DINV#1 <5> H_DINV#2 <5> H_DINV#3 <5>

H_DSTBN#0 <5> H_DSTBN#1 <5> H_DSTBN#2 <5> H_DSTBN#3 <5>

H_DSTBP#0 <5> H_DSTBP#1 <5> H_DSTBP#2 <5> H_DSTBP#3 <5>

+1.05VS

Compal Secret Data

2008/10/18 2009/10/18

3

Compal Secret Data

Deciphered Date

+1.2VS V_AVDD_PCIE_1.2V

SB_PCIE_WAKE# INT_N_A

G16

AA1 AB1 AB2 AC1 AD1 AE1 AE2 AF1 AG1

2

L22

1 2

MBK1608121YZF_0603

U30D

P7

PCIEAVDD

R7

PCIEAVDD

T7

PCIEAVDD

U7

PCIEAVDD

V7

PCIEAVDD

D7

PME# INTX#

E4

PERP0

E5

PERN0

F1

PERP1

G1

PERN1

H3

PERP2

H2

PERN2

H1

PERP3

J1

PERN3

K1

PERP4

PCIE

K2 L1

M1

N1 N2 P1 R1 T1 T2 U1

V1 W1 W2

Y1

2

PCIE

PERN4 PERP5 PERN5 PERP6 PERN6 PERP7 PERN7 PERP8 PERN8

PETP9(HDVBP2)

PERP9 PERN9

PETN9(HDVBN2)

PERP10

PETP10(HDVBP1)

PERN10

PETN10(HDVBN1)

PERP11

PETP11(HDVBP0)

PERN11

PETN11(HDVBN0) PERP12 PERN12

PETP13(HDVAP2)

PERP13 PERN13

PETN13(HDVAN2)

PETP14(HDVAP1)

PERP14 PERN14

PETN14(HDVAN1)

PETP15(HDVAP0)

PERP15 PERN15

PETN15(HDVAN0)

S IC SISM672FXA1 TEBGA 847P

HDVBP2

C653 0.1U_0402_10V7KC653 0.1U_0402_10V7K

HDVBN2

C660 0.1U_0402_10V7KC660 0.1U_0402_10V7K

HDVBP1

C662 0.1U_0402_10V7KC662 0.1U_0402_10V7K

HDVBN1

C654 0.1U_0402_10V7KC654 0.1U_0402_10V7K

HDVBP0

C655 0.1U_0402_10V7KC655 0.1U_0402_10V7K

HDVBN0

C656 0.1U_0402_10V7KC656 0.1U_0402_10V7K

HDVAP2

C658 0.1U_0402_10V7KC658 0.1U_0402_10V7K

HDVAN2

C657 0.1U_0402_10V7KC657 0.1U_0402_10V7K

HDVAP1

C652 0.1U_0402_10V7KC652 0.1U_0402_10V7K

HDVAN1

C651 0.1U_0402_10V7KC651 0.1U_0402_10V7K

HDVAP0

C659 0.1U_0402_10V7KC659 0.1U_0402_10V7K

HDVAN0

C661 0.1U_0402_10V7KC661 0.1U_0402_10V7K

1

PCIEAVDD:77mA

1

C201

0.1U_0402_16V4Z

2

REFCLK+ REFCLK-

PETP0 PETN0 PETP1 PETN1 PETP2 PETN2 PETP3 PETN3 PETP4 PETN4 PETP5 PETN5 PETP6 PETN6 PETP7 PETN7 PETP8 PETN8

PETP12 PETN12

12 12 12 12 12 12

Title

Size Document Number Rev

Custom

Date: Sheet

1

C218

0.01U_0402_16V7K

2

PCIE_CLK_NB

T5

PCIE_CLK_NB#

T4

G6 H6 G4 G5 J6 K6 J4 J5 L6 M6 M4 M5 P6 R6 P4 P5 V6 W6

HDVBP2

W4

HDVBN2

W5

HDVBP1

Y6

HDVBN1

AA6

HDVBP0

AA4

HDVBN0

AA5 AB6 AC6

HDVAP2

AC4

HDVAN2

AC5

HDVAP1

AD6

HDVAN1

AE6

HDVAP0

AE4

HDVAN0

AE5

HDVBP2_C HDVBN2_C HDVBP1_C HDVBN1_C HDVBP0_C HDVBN0_C

HDVAP2_C HDVAN2_C HDVAP1_C HDVAN1_C HDVAP0_C HDVAN0_C

Compal Electronics, Inc.

M672MX (1/5)-HOST/PCIE

KFT00 M/B LA-4821P Schematic

PCIE_CLK_NB <14> PCIE_CLK_NB# <14>

HDVBP2_C <18> HDVBN2_C <18> HDVBP1_C <18> HDVBN1_C <18> HDVBP0_C <18> HDVBN0_C <18>

HDVAP2_C <18> HDVAN2_C <18> HDVAP1_C <18> HDVAN1_C <18> HDVAP0_C <18> HDVAN0_C <18>

747Tuesday, March 10, 2009

1

of

1.0

5

DDRA_SDQ[0..63]<12,13> DDRA_SDM[0..7]<12,13> DDRA_SMA[0..14]<12,13>

D D

C C

B B

A A

DDRA_SDQ[0..63] DDRA_SDM[0..7] DDRA_SMA[0..14]

DDRA_SDQS0<12,13> DDRA_SDQS0#<12,13>

DDRA_SDQS1<12,13> DDRA_SDQS1#<12,13>

DDRA_SDQS2<12,13> DDRA_SDQS2#<12,13>

DDRA_SDQS3<12,13> DDRA_SDQS3#<12,13>

DDRA_SDQS4<12,13> DDRA_SDQS4#<12,13>

DDRA_SDQS5<12,13> DDRA_SDQS5#<12,13>

DDRA_SDQS6<12,13> DDRA_SDQS6#<12,13>

DDRA_SDQS7<12,13> DDRA_SDQS7#<12,13>

4

DDRA_SDQ0 DDRA_SDQ1 DDRA_SDQ2 DDRA_SDQ3 DDRA_SDQ4 DDRA_SDQ5 DDRA_SDQ6 DDRA_SDQ7 DDRA_SDM0 DDRA_SDQS0 DDRA_SDQS0#

DDRA_SDQ8 DDRA_SDQ9 DDRA_SDQ10 DDRA_SDQ11 DDRA_SDQ12 DDRA_SDQ13 DDRA_SDQ14 DDRA_SDQ15 DDRA_SDM1 DDRA_SDQS1 DDRA_SDQS1#

DDRA_SDQ16 DDRA_SDQ17 DDRA_SDQ18 DDRA_SDQ19 DDRA_SDQ20 DDRA_SDQ21 DDRA_SDQ22 DDRA_SDQ23 DDRA_SDM2 DDRA_SDQS2 DDRA_SDQS2#

DDRA_SDQ24 DDRA_SDQ25 DDRA_SDQ26 DDRA_SDQ27 DDRA_SDQ28 DDRA_SDQ29 DDRA_SDQ30 DDRA_SDQ31 DDRA_SDM3 DDRA_SDQS3 DDRA_SDQS3#

DDRA_SDQ32 DDRA_SDQ33 DDRA_SDQ34 DDRA_SDQ35 DDRA_SDQ36 DDRA_SDQ37 DDRA_SDQ38 DDRA_SDQ39 DDRA_SDM4 DDRA_SDQS4 DDRA_SDQS4#

DDRA_SDQ40 DDRA_SDQ41 DDRA_SDQ42 DDRA_SDQ43 DDRA_SDQ44 DDRA_SDQ45 DDRA_SDQ46 DDRA_SDQ47 DDRA_SDM5 DDRA_SDQS5 DDRA_SDQS5#

DDRA_SDQ48 DDRA_SDQ49 DDRA_SDQ50 DDRA_SDQ51 DDRA_SDQ52 DDRA_SDQ53 DDRA_SDQ54 DDRA_SDQ55 DDRA_SDM6 DDRA_SDQS6 DDRA_SDQS6#

DDRA_SDQ56 DDRA_SDQ57 DDRA_SDQ58 DDRA_SDQ59 DDRA_SDQ60 DDRA_SDQ61 DDRA_SDQ62 DDRA_SDQ63 DDRA_SDM7 DDRA_SDQS7 DDRA_SDQS7#

U30B

AD31

MD0A

AD30

MD1A

AG34

MD2A

AE29

MD3A

AE32

MD4A

AF34

MD5A

AF31

MD6A

AE30

MD7A

AD28

DQM0A

AF32

DQS0A

AF33

DQS0A#

AF28

MD8A

AJ34

MD9A

AH31

MD10A

AG30

MD11A

AF30

MD12A

AG32

MD13A

AJ32

MD14A

AJ31

MD15A

AH34

DQM1A

AH32

DQS1A

AH33

DQS1A#

AK34

MD16A

AH30

MD17A

AL32

MD18A

AM33

MD19A

AK32

MD20A

AG29

MD21A

AM34

MD22A

AL31

MD23A

AJ30

DQM2A

AK33

DQS2A

AL34

DQS2A#

AM32

MD24A

AP32

MD25A

AP31

MD26A

AM29

MD27A

AK30

MD28A

AK29

MD29A

AJ27

MD30A

AK28

MD31A

AN32

DQM3A

AM30

DQS3A

AM31

DQS3A#

AK20

MD32A

AM20

MD33A

AM19

MD34A

AJ19

MD35A

AN20

MD36A

AJ21

MD37A

AP19

MD38A

AH20

MD39A

AK21

DQM4A

AK19

DQS4A

AL19

DQS4A#

AK18

MD40A

AJ17

MD41A

AK17

MD42A

AP16

MD43A

AH18

MD44A

AP18

MD45A

AN18

MD46A

AP17

MD47A

AM18

DQM5A

AL17

DQS5A

AM17

DQS5A#

AN16

MD48A

AK16

MD49A

AN14

MD50A

AJ15

MD51A

AP15

MD52A

AM16

MD53A

AK15

MD54A

AP14

MD55A

AH16

DQM6A

AL15

DQS6A

AM15

DQS6A#

AL13

MD56A

AM13

MD57A

AM12

MD58A

AJ13

MD59A

AM14

MD60A

AK14

MD61A

AN12

MD62A

AH14

MD63A

AK13

DQM7A

AP12

DQS7A

AP13

DQS7A#

S IC SISM672FXA1 TEBGA 847P

DRAM

D1XAVDD

D1XAVSS

D4XAVDD D4XAVSS

MA0A MA1A MA2A MA3A MA4A MA5A MA6A MA7A MA8A

MA9A MA10A MA11A MA12A MA13A MA14A MA15A MA16A MA17A

RASA# CASA#

WEA#

FWDSDCLKOA

FWDSDCLKOA#

CS0A# CS1A# CS2A# CS3A#

ODT0A ODT1A ODT2A ODT3A

CKEA0 CKEA1 CKEA2 CKEA3

DDRVREF0 DDRVREF1

DDRCOMP

DDRCOMN

OCDVREFP OCDVREFN

S3AUXSW#

A15 B15

AP11 AP10

AH24 AP25 AM25 AL25 AP26 AM26 AN26 AK25 AP27 AP28 AK24 AN24 AP24 AM28 AM27 AN28 AP21 AP29

AM23 AP22 AJ23

AK12 AH12

AP23 AH22 AM22 AM21

AK22 AP20 AN22 AL21

AN30 AP30 AH26 AK27

AD18 AD23

AJ25 AK26

AH28 AJ29

B6

3

D1XAVDD D1XAVSS

D4XAVDD D4XAVSS

DDRA_SMA0 DDRA_SMA1 DDRA_SMA2 DDRA_SMA3 DDRA_SMA4 DDRA_SMA5 DDRA_SMA6 DDRA_SMA7 DDRA_SMA8 DDRA_SMA9 DDRA_SMA10 DDRA_SBS0 DDRA_SBS1 DDRA_SBS2 DDRA_SMA11 DDRA_SMA12 DDRA_SMA13

DDRA_SRAS# DDRA_SCAS# DDRA_SWE#

CLK_INT CLK_INC

DDRA_SCS0# DDRA_SCS1# DDRA_SCS2# DDRA_SCS3#

DDRA_ODT0 DDRA_ODT1 DDRA_ODT2 DDRA_ODT3

DDRA_CKE0 DDRA_CKE1 DDRA_CKE2 DDRA_CKE3

DDRVREF

DDRCOMP

R226 36_0402_1%R226 36_0402_1%

DDRCOMN

R227 36_0402_1%R227 36_0402_1%

OCDVREFP OCDVREFN

S3AUXSW#

DDRA_SBS0 <12,13> DDRA_SBS1 <12,13> DDRA_SBS2 <12,13>

DDRA_SRAS# <12,13> DDRA_SCAS# <12,13> DDRA_SWE# <12,13>

CLK_INT <15> CLK_INC <15>

DDRA_SCS0# <12> DDRA_SCS1# <12> DDRA_SCS2# <13> DDRA_SCS3# <13>

DDRA_ODT0 <12> DDRA_ODT1 <12> DDRA_ODT2 <13> DDRA_ODT3 <13>

DDRA_CKE0 <12> DDRA_CKE1 <12> DDRA_CKE2 <13> DDRA_CKE3 <13>

S3AUXSW# <31>

+1.8V

2

+1.8VS

L41

1 2

MBK1608121YZF_0603

1

C456

C456 10U_0805_10V4Z

10U_0805_10V4Z

2

R409 0_0402_5%R409 0_0402_5%

+1.8VS

1 2

MBK1608121YZF_0603

1

C583

C583 10U_0805_10V4Z

10U_0805_10V4Z

2

R473 0_0402_5%R473 0_0402_5%

+1.8V

12

R276

1K_0402_1%

12

R501

1K_0402_1%

+1.8V +1.8V

12

R277

40.2_0402_1%

12

R224

R224 36_0402_1%

36_0402_1%

1 2

OCDVREFP OCDVREFN

L52

1

2

1

2

0.1U_0402_16V4Z

1

C480

0.1U_0402_16V4Z

2

1

C579

0.1U_0402_16V4Z

2

C251

0.1U_0402_16V4Z

C238

12

R511

R511 36_0402_1%

36_0402_1%

12

R228

40.2_0402_1%

1

C233

C233 1U_0603_10V4Z

1U_0603_10V4Z

2

1

D1XAVDD:7mA

D1XAVDD

1

C471

0.01U_0402_16V7K

2

D1XAVSS

D4XAVDD:10mA

D4XAVDD

1

C578

0.01U_0402_16V7K

2

D4XAVSSDDRA_SMA14

DDRVREF

Place C233 under M672MX solder side.

Security Classification

2008/10/18 2009/10/18

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18 2009/10/18

3

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

2

Date: Sheet

Compal Electronics, Inc.

M672MX (2/5)-DDR

KFT00 M/B LA-4821P Schematic

1

of

847Tuesday, March 10, 2009

of

847Tuesday, March 10, 2009

of

847Tuesday, March 10, 2009

1.0

5

4

3

2

1

+1.8VS

L24

1 2

MBK1608121YZF_0603

1

C252

C252 10U_0805_10V4Z

10U_0805_10V4Z

2

D D

C C

B B

A A

1 2

R231 0_0402_5%R231 0_0402_5%

+1.8VS

12

R232

R232 150_0402_1%

150_0402_1%

12

R229

49.9_0402_1%

+1.8VS

1 2

MBK1608121YZF_0603

1

C467

C467 10U_0805_10V4Z

10U_0805_10V4Z

2

1 2

R396 0_0402_5%R396 0_0402_5%

+1.8VS

1 2

MBK1608121YZF_0603

1

C491

C491 10U_0805_10V4Z

10U_0805_10V4Z

2

1 2

R415 0_0402_5%R415 0_0402_5%

+1.8VS

1

C453

@

10U_0805_10V4Z

2

1 2

R383 0_0402_5%R383 0_0402_5%

L65

L45

R395

3.3_0402_5%

5

1

C250

0.1U_0402_16V4Z

2

1

C67

0.1U_0402_16V4Z

2

1

C249

0.1U_0402_16V4Z

2

1

2

1

2

1

2

Z4XAVDD:10mA

1

C248

0.01U_0402_16V7K

2

Z_VREF

VGA_CRT_HSYNC<17> VGA_CRT_VSYNC<17>

GMCH_CRT_CLK<17> GMCH_CRT_DATA<17>

DCLKAVDD:5mA

1

C469

C468

0.1U_0402_16V4Z

C469

0.01U_0402_16V7K

2

ECLKAVDD:5mA

C484

0.1U_0402_16V4Z

1 2

C178 0.1U_0402_16V4ZC178 0.1U_0402_16V4Z

1 2

C177 0.1U_0402_16V4ZC177 0.1U_0402_16V4Z

C461

@

1U_0603_10V4Z

1

C485

0.01U_0402_16V7K

2

1

C463

@

0.1U_0402_16V4Z

2

7/30 modified to @

Z4XAVDD

Z4XAVSS

DCLKAVDD

DCLKAVSS

ECLKAVDD

ECLKAVSS

VCOMP VVBWN

DACAVDD1

DACAVSS1

VGA_CRT_HSYNC VGA_CRT_VSYNC

GMCH_CRT_CLK GMCH_CRT_DATA

+1.8VS

1

2

DACAVDD1:73mA

DACAVDD1 Spec. Voltage : 1.5V +/- 5% Current : 100mA

ZAD[0..16]<19>

+3VS

12

R178

R178 390_0402_5%

390_0402_5%

INT_N_A<7,19>

REF_CLK0<14>

5/20 reserved by Ivan

R177

1 2

0_0402_5%

C174

C174 10U_0805_10V4Z

10U_0805_10V4Z

1 2

R406 0_0402_5%R406 0_0402_5%

4

1

2

ZAD[0..16]

R472 56_0402_5%R472 56_0402_5%

+1.8VS

12

R179

R179 390_0402_5%

390_0402_5%

@

1 2

C166 0.1U_0402_16V4Z

1 2

C167 0.1U_0402_16V4Z

@

R230 56_0402_5%R230 56_0402_5%

DACAVDD2:73mA

1

C483

C490

C490 1U_0603_10V4Z

1U_0603_10V4Z

1 2

R174 130_0402_5%R174 130_0402_5%

C483

0.1U_0402_16V4Z

2

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

Z_CLK0<14>

ZDREQ<19> ZUREQ<19>

ZSTB_DP0<19> ZSTB_DN0<19> ZSTB_DP1<19> ZSTB_DN1<19>

1 2 1 2

VGA_CRT_R<17> VGA_CRT_G<17> VGA_CRT_B<17>

R184 0_0402_5%R184 0_0402_5%

1 2

R185 0_0402_5%R185 0_0402_5%

1 2

R183 0_0402_5%R183 0_0402_5%

1 2

R182 0_0402_5%R182 0_0402_5%

1 2

R196 0_0402_5%R196 0_0402_5%

1 2

R195 0_0402_5%R195 0_0402_5%

1 2

VCOMP VVBWN

DACAVDD2

DACAVSS2

VRSET

3

U30A

Z_CLK0 ZDREQ

ZUREQ ZSTB_DP0

ZSTB_DN0 ZSTB_DP1 ZSTB_DN1

ZAD0 ZAD1 ZAD2 ZAD3 ZAD4 ZAD5 ZAD6 ZAD7 ZAD8 ZAD9 ZAD10 ZAD11 ZAD12 ZAD13 ZAD14 ZAD15 ZAD16

Z_VREF Z_COMP_P Z_COMP_N

Z4XAVDD Z4XAVSS

VGA_CRT_R VGA_CRT_G VGA_CRT_B

A_HSYNC A_VSYNC

A_DDC1CLK A_DDC1DAT

VCOMP VVBWN VRSET

INTA# VOSCI DACAVDD1

DACAVSS1 DACAVDD2

DACAVSS2 DCLKAVDD

DCLKAVSS

ECLKAVDD ECLKAVSS

Compal Secret Data

2008/10/18 2009/10/18

Compal Secret Data

U30A

AH10

ZCLK

AP8

ZDREQ

AN8

ZUREQ

AM7

ZSTB0

AL7

ZSTB0#

AP4

ZSTB1

AP5

ZSTB1#

AK10

ZAD0

AM6

ZAD1

AK11

ZAD2

AJ11

ZAD3

AP7

ZAD4

AJ9

ZAD5

AP6

ZAD6

AN6

ZAD7

AK9

ZAD8

AM4

ZAD9

AK6

ZAD10

AK8

ZAD11

AN4

ZAD12

AK7

ZAD13

AL5

ZAD14

AM5

ZAD15

AM8

ZAD16

AL9

ZVREF

AP9

ZCMP_P

AM9

ZCMP_N

AM10

Z4XAVDD

AN10

Z4XAVSS

D13

ROUT

C12

GOUT

C13

BOUT

F12

HSYNC

G12

VSYNC

D11

VGPIO0

E12

VGPIO1

D15

VCOMP

C15

VVBWN

C14

VRSET

F13

INTA#

F11

VOSCI

A12

DACAVDD1

B12

DACAVSS1

A13

DACAVDD2

B13

DACAVSS2

B10

DCLKAVDD

A11

DCLKAVSS

A9

ECLKAVDD

B8

ECLKAVSS

S IC SISM672FXA1 TEBGA 847P

Deciphered Date

ASL

ENTEST

TESTMODE0 TESTMODE1 TESTMODE2

TRAP0 TRAP1 TRAP2

TRAP3 TRAP4 TRAP5 TRAP6 TRAP7 TRAP8 TRAP9

TRAP10

AUXOK

PWROK

PCIRST#

AGPSTOP#

AGPBUSY#

VBVSYNC

VBHSYNC

VBHCLK

VBCLK

VBCAD

VACLK

NC0 NC1

2

F15 D16

E16 F16 D17 E17 F17

AC32 AD34 AB28 AD32 AD33 AE34 AC30 AC29

A5 C6 A7

G14 A6

D8 F7

E7 C8

E9 D9

NB_ENTEST

AUX_PWRGD SB_PWRGD NB_RST#

AGPSTOP# AGPBUSY#

VBVSYNC VBHSYNC

VBHCLK VBCLK

VBCAD

R193 4.7K_0402_5%R193 4.7K_0402_5%

1 2

AUX_PWRGD <20,31> SB_PWRGD <20,31> NB_RST# <18,19>

AGPSTOP# <20> AGPBUSY# <20>

VBVSYNC <18> VBHSYNC <18>

VBHCLK <18> VBCLK <18>

R559 33_0402_5%R559 33_0402_5%

VBCAD <18>

1 2

For SiS VB 307 use only

AH2 AG3

AGPBUSY# AUX_PWRGD SB_PWRGD

R258 4.7K_0402_5%R258 4.7K_0402_5%

C180 0.1U_0402_16V4ZC180 0.1U_0402_16V4Z C181 0.1U_0402_16V4ZC181 0.1U_0402_16V4Z

Title

Size Document Number Rev

Custom

KFT00 M/B LA-4821P Schematic

Date: Sheet

VACLKH_VACLK

1 2

1 2 1 2

Compal Electronics, Inc.

M672MX (3/5)-ASL

VACLK <18>

+3VS

1

1.0

of

947Tuesday, March 10, 2009

5

U30E

4

3

2

1

+1.8V

D D

+1.8VS

C C

+1.8VS

B B

A A

+1.8VS

+1.2VS

+1.2VALW

+1.8VALW

W23

VCCM

Y23

VCCM

AA23

VCCM

AB23

VCCM

AC23

VCCM

AC18

VCCM

AC20

VCCM

AC16

VCCM

AD16

VCCM

AD17

VCCM

AD19

VCCM

AD20

VCCM

AD21

VCCM

AD22

VCCM

AJ22

VCCM

AJ24

VCCM

AL23

VCCM

AL26

VCCM

AN21

VCCM

AN23

VCCM

AN25

VCCM

AN27

VCCM

AN29

VCCM

PWR

AP3 AB12 AB13

AC12 AC13 AC14 AC15

AH6

AH7

AN2

AK4

AK5

AM1

AM2

AM3

AN3

AN5

AN7

AN9

N19

N21

R21

U21

M11

N11

R11

U11

W11

AA11 AB11

AJ4 AJ5 AJ6 AJ7

AL1 AL2 AL3 AL4

E10 F10

P20 P22

T22 V22

P11 T11 V11 Y11

E8 F9 F8

B5 C5 D6

G8

PWR

VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8 VCC1.8

VDDVB1.8 VDDVB1.8 VDDVB1.8

VDD1.8 VDD1.8

PVDDH PVDDH PVDDH PVDDH PVDDH PVDDH PVDDH PVDDH

VDDPEX VDDPEX VDDPEX VDDPEX VDDPEX VDDPEX VDDPEX VDDPEX VDDPEX VDDPEX VDDPEX

AUX_IVDD AUX_IVDD AUX_IVDD

AUX1.8

S IC SISM672FXA1 TEBGA 847P

IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD

VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT

VTT VTTP VTTP VTTP VTTP VTTP VTTP VTTP VTTP VTTP VTTP

M13 M14 M15 M16 M17 M18 M19 N16 N17 N18 N20 R22 N22 N13 P13 Y13 Y22 T13 U13 U22 V13 W13 W22 AA13 AA22 AB14 AB15 AB16 AB18 AB20 AB22 AF6 AF7 AK3 AG4 AG5 AG6 AG7 R13 AH3 AH4 AH5 AJ1 AJ2 AJ3 AK1 AK2 AC22 AC21 AC19 AC17

A19 A20 B19 B20 C19 C20 D19 D20 E19 E20 F19 F20 G19 G20 L18 L19 L20 M20 M21 M22 M23 N23 P23 R23 T23 U23 V23 M12 N12 P12 R12 T12 U12 V12 W12 Y12 AA12

+1.2VS

+1.05VS

+1.8VS

+1.8V +1.2VS +1.8VALW +1.2VALW

C244 1U_0603_10V4ZC244 1U_0603_10V4Z

C245 1U_0603_10V4ZC245 1U_0603_10V4Z

C246 10U_0805_10V4ZC246 10U_0805_10V4Z

PVDDH/VCC1.8/VTTP/VDD1.8

+1.8VS +1.2VS

/VDDVB1.8:392mA

C232 0.1U_0402_16V4ZC232 0.1U_0402_16V4Z

C239 1U_0603_10V4ZC239 1U_0603_10V4Z

C247 10U_0805_10V4ZC247 10U_0805_10V4Z

1 2

VCCM:644mA

C225 1U_0603_10V4ZC225 1U_0603_10V4Z

C227 1U_0603_10V4ZC227 1U_0603_10V4Z

C243 10U_0805_10V4ZC243 10U_0805_10V4Z

C202 0.1U_0402_16V4ZC202 0.1U_0402_16V4Z

C195 1U_0603_10V4ZC195 1U_0603_10V4Z

C229 10U_0805_10V4ZC229 10U_0805_10V4Z

IVDD:2024mA

1 2

VDDPEX:876mA

1 2

AUX1.8:1mA AUX_IVDD:92mA

1

2

+1.05VS

Place these Cap under M672MX solder side.

+1.8V +1.2VS

C230 0.1U_0402_16V4ZC230 0.1U_0402_16V4Z

1 2

C231 0.1U_0402_16V4ZC231 0.1U_0402_16V4Z

1 2

C235 1U_0603_10V4ZC235 1U_0603_10V4Z

1 2

C223 1U_0603_10V4ZC223 1U_0603_10V4Z

1 2

C237 4.7U_0805_10V4ZC237 4.7U_0805_10V4Z

1 2

C236 4.7U_0805_10V4ZC236 4.7U_0805_10V4Z

1 2

+1.8VS +1.2VS +1.05VS

C198 0.1U_0402_16V4ZC198 0.1U_0402_16V4Z

1 2

C221 1U_0603_10V4ZC221 1U_0603_10V4Z

1 2

C193 1U_0603_10V4ZC193 1U_0603_10V4Z

1 2

C226 0.1U_0402_16V4ZC226 0.1U_0402_16V4Z

1 2

C209 0.1U_0402_16V4ZC209 0.1U_0402_16V4Z

1 2

C213 1U_0603_10V4ZC213 1U_0603_10V4Z

1 2

C220 1U_0603_10V4ZC220 1U_0603_10V4Z

1 2

C196 4.7U_0805_10V4ZC196 4.7U_0805_10V4Z

1 2

C242 4.7U_0805_10V4ZC242 4.7U_0805_10V4Z

1 2

C197 0.1U_0402_16V4ZC197 0.1U_0402_16V4Z

1 2

C240 1U_0603_10V4ZC240 1U_0603_10V4Z

1 2

C234 1U_0603_10V4ZC234 1U_0603_10V4Z

1 2

+1.8VALW +1.2VALW

1

2

C187

C187 1U_0603_10V4Z

1U_0603_10V4Z

1

C183

C183 1U_0603_10V4Z

1U_0603_10V4Z

2

VTT:80mA

C204 0.1U_0402_16V4ZC204 0.1U_0402_16V4Z

1 2

C192 1U_0603_10V4ZC192 1U_0603_10V4Z

1 2

C176 10U_0805_10V4ZC176 10U_0805_10V4Z

1 2

1

C182

C190

C190 1U_0603_10V4Z

1U_0603_10V4Z

C188 0.1U_0402_16V4ZC188 0.1U_0402_16V4Z

1 2

C179 1U_0603_10V4ZC179 1U_0603_10V4Z

1 2

C184 1U_0603_10V4ZC184 1U_0603_10V4Z

1 2

C182 1U_0603_10V4Z

1U_0603_10V4Z

2

Security Classification

2008/10/18 2009/10/18

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18 2009/10/18

3

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

2

Date: Sheet

Compal Electronics, Inc.

M672MX (4/5)-POWER

KFT00 M/B LA-4821P Schematic

10 47Tuesday, February 10, 2009

1

1.0

of

5

D D

B21 B23 B25 B27 B29 B31

C10 C11 C16 C18

G10

C32 C33

D10 D12 D21 D23 D25 D27 D29

E11 E13 E14 E18 E29 E30 E33

F14 F22 F24 F26 F28

P21 T21 V21

C C

B B

4

AA16

AA17

AA18

AA19

AA20

AA21

AA31

AA33

AB3

AB4

AB5

AB7

AB29

AC2

AC3

AC31

AC33

AD2

AD3

AD4

AD5

AD7

AD29

AE3

AE31

AE33

AF2

VSS

VSSM2VSSM3VSS

M29

AF3

VSS

GND

VSSN3VSSN4VSSN5VSSN6VSSN7VSS

U30F

A3

VSS

B2

VSS

B3

VSS

B4

VSS VSS

VSS VSS VSS VSS VSS

C1

VSS

C2

VSS

C3

VSS

C4

VSS

C9

VSS VSS VSS VSS VSS VSS VSS

D1

VSS

D2

VSS

D3

VSS

D4

VSS

D5

VSS VSS VSS VSS VSS VSS VSS VSS

E1

VSS

E2

VSS

E3

VSS

E6

VSS VSS VSS VSS VSS VSS VSS VSS

F2

VSS

F3

VSS

F4

VSS

F5

VSS

F6

VSS VSS VSS VSS VSS VSS

G2

VSS

G3

VSS

G7

VSS VSS VSS VSS VSS

VSSH5VSS

VSSJ2VSSJ3VSSJ7VSS

VSS

VSSK3VSSK4VSSK5VSS

VSSL2VSSL3VSSL4VSSL5VSSL7VSS

J33

K29

G31

VSS

G33

VSS

H4

H29

J31

VSS

L31

L33

VSS

AF4

VSS

AF5

N14

VSS

AF29

N15

VSS

AG2

N31

VSS

AG31

VSS

N33

3

AG33

AH1

VSS

VSSP2VSSP3VSS

2

AH29

AJ8

AJ10

AJ12

AJ14

AJ16

AJ18

AJ20

AJ26

AJ28

AJ33

AK31

AL6

AL8

AL10

AL12

AL14

AL16

AL18

AL20

AL28

AL30

AL33

AN11

AN13

AN15

AN17

VSS

T29

VSS

U2

VSS

U3

VSS

U4

VSS

U5

VSS

U6

VSS

U14

VSS

U15

VSS

U16

VSS

U17

VSS

U18

VSS

U19

VSS

U20

VSS

U31

VSS

U33

VSS

V2

VSS

V3

VSS

V4

VSS

V5

VSS

V14

VSS

V15

VSS

V16

VSS

V17

VSS

V18

VSS

V19

VSS

V20

VSS

V29

VSS

AN33

VSS

AN31

VSS

AN19

VSS

W3

VSS

W14

VSS

W15

VSS

W16

VSS

W17

VSS

W18

VSS

W19

VSS

W20

VSS

W21

VSS

W31

VSS

W33

VSS

Y2

VSS

Y3

VSS

Y4

VSS

Y5

VSS

Y7

VSS

Y14

VSS

Y15

VSS

Y16

VSS

Y17

VSS

Y18

VSS

Y19

VSS

Y20

VSS

Y21

VSS

Y29

VSS

AA2

VSS

AA3

VSS

AA14

VSS

AA15

VSS

AB17

VSS

AB19

VSS

AB21

VSS

P19

VSS

VSSR2VSSR3VSSR4VSSR5VSS

VSS

VSST3VSST6VSS

VSS

S IC SISM672FXA1 TEBGA 847P

T14

P14

P15

P16

P17

P18

P29

R14

R15

R16

R17

R18

R19

R20

R31

R33

T15

S IC SISM672FXA1 TEBGA 847P

T16

T17

T18

T19

T20

1

A A

Security Classification

2008/10/18 2009/10/18

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18 2009/10/18

3

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

2

Date: Sheet

Compal Electronics, Inc.

M672MX (5/5)-GND

KFT00 M/B LA-4821P Schematic

11 47Tuesday, February 10, 2009

1

1.0

of

5

+1.8V +1.8V

JDIMM1

+DIMM_VREF

DDRA_SDQ0 DDRA_SDQ1

DDRA_SDQS0#<8,13> DDRA_SDQS0<8,13>

D D

DDRA_SDQS1#<8,13> DDRA_SDQS1<8,13>

DDRA_SDQS2#<8,13> DDRA_SDQS2<8,13>

EC_TX_P80_DATA<13,29,31>

C C

EC_RX_P80_CLK<13,29,31>

B B

EC_RX_P80_CLK

A A

DDRA_CKE0<8>

DDRA_SBS2<8,13>

DDRA_SBS0<8,13> DDRA_SWE#<8,13>

DDRA_SCAS#<8,13> DDRA_SCS1#<8>

DDRA_ODT1<8>

DDRA_SDQS4#<8,13> DDRA_SDQS4<8,13>

R237 0_0402_5%R237 0_0402_5%

1 2

EC_RX_P80_CLK_R<13>

DDRA_SDQS6#<8,13> DDRA_SDQS6<8,13>

SDATA<13,14,15,20> SCLK<13,14,15,20>

+3VS

C786

2.2U_0603_6.3V6K

5

DDRA_SDQS0# DDRA_SDQS0

DDRA_SDQ2 DDRA_SDQ3

DDRA_SDQ8 DDRA_SDQ9

DDRA_SDQS1# DDRA_SDQS1

DDRA_SDQ10 DDRA_SDQ11

DDRA_SDQ16 DDRA_SDQ17

DDRA_SDQS2# DDRA_SDQS2

DDRA_SDQ18 DDRA_SDQ19

DDRA_SDQ24 DDRA_SDQ25

DDRA_SDM3 EC_TX_P80_DATA

DDRA_SDQ26 DDRA_SDQ27

DDRA_CKE0 EC_RX_P80_CLK

DDRA_SBS2 DDRA_SMA12

DDRA_SMA9 DDRA_SMA8

DDRA_SMA5 DDRA_SMA3 DDRA_SMA1

DDRA_SMA10 DDRA_SBS0 DDRA_SWE#

DDRA_SCAS# DDRA_SCS1#

DDRA_ODT1 DDRA_SDQ32

DDRA_SDQ33 DDRA_SDQS4#

DDRA_SDQS4 DDRA_SDQ34

DDRA_SDQ35 DDRA_SDQ40

DDRA_SDQ41 DDRA_SDM5 DDRA_SDQ42

DDRA_SDQ43 DDRA_SDQ48

DDRA_SDQ49

EC_RX_P80_CLK_R

DDRA_SDQS6# DDRA_SDQS6

DDRA_SDQ50 DDRA_SDQ51

DDRA_SDQ56 DDRA_SDQ57

DDRA_SDM7 DDRA_SDQ58

DDRA_SDQ59 SDATA

SCLK

+3VS

1

C787

0.1U_0402_16V4Z

2

Add GND Pin For EMI Recommend

DIMM0 STD H:5.2mm (BOT)

1

VREF

3

VSS

5

DQ0

7

DQ1

9

VSS

11

DQS0#

13

DQS0

15

VSS

17

DQ2

19

DQ3

21

VSS

23

DQ8

25

DQ9

27

VSS

29

DQS1#

31

DQS1

33

VSS

35

DQ10

37

DQ11

39

VSS

41

VSS

43

DQ16

45

DQ17

47

VSS

49

DQS2#

51

DQS2

53

VSS

55

DQ18

57

DQ19

59

VSS

61

DQ24

63

DQ25

65

VSS

67

DM3

69

NC

71

VSS

73

DQ26

75

DQ27

77

VSS

79

CKE0

81

VDD

83

NC

85

BA2

87

VDD

89

A12

91

A9

93

A8

95

VDD

97

A5

99

A3

101

A1

103

VDD

105

A10/AP

107

BA0

109

WE#

111

VDD

113

CAS#

115

NC/S1#

117

VDD

119

NC/ODT1

121

VSS

123

DQ32

125

DQ33

127

VSS

129

DQS4#

131

DQS4

133

VSS

135

DQ34

137

DQ35

139

VSS

141

DQ40

143

DQ41

145

VSS

147

DM5

149

VSS

151

DQ42

153

DQ43

155

VSS

157

DQ48

159

DQ49

161

VSS

163

NC,TEST

165

VSS

167

DQS6#

169

DQS6

171

VSS

173

DQ50

175

DQ51

177

VSS

179

DQ56

181

DQ57

183

VSS

185

DM7

187

VSS

189

DQ58

191

DQ59

193

VSS

195

SDA

197

SCL

199

VDDSPD

203

GND

FOX_ASOA426-M2RN-7F

CONN@

DQ12 DQ13

CK0# DQ14

DQ15

DQ20 DQ21

DQ22 DQ23

DQ28 DQ29

DQS3#

DQS3 DQ30

DQ31

NC/CKE1

NC/A15 NC/A14

RAS#

ODT0

NC/A13

DQ36 DQ37

DQ38 DQ39

DQ44 DQ45

DQS5#

DQS5 DQ46

DQ47 DQ52

DQ53

CK1#

DQ54 DQ55

DQ60 DQ61

DQS7#

DQS7 DQ62

DQ63

VSS DQ4 DQ5 VSS DM0 VSS DQ6 DQ7 VSS

VSS DM1 VSS CK0

VSS

VSS DM2

VSS

VSS VDD

VDD

VDD BA1

VDD

VDD VSS

VSS DM4 VSS

VSS

VSS CK1

VSS DM6 VSS

VSS

VSS SA0 SA1

4

2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40

42 44 46 48 50

NC

52 54 56 58 60 62 64 66 68 70 72 74 76 78 80 82 84 86 88 90

A11

92

A7

94

A6

96 98

A4

100

A2

102

A0

104 106 108 110

S0#

112 114 116 118 120

NC

122 124 126 128 130 132 134 136 138 140 142 144 146 148 150 152 154 156 158 160 162 164 166 168 170 172 174 176 178 180 182 184 186 188 190 192 194 196 198 200

4

DDRA_SDQ4 DDRA_SDQ5

DDRA_SDM0 DDRA_SDQ6

DDRA_SDQ7 DDRA_SDQ12

DDRA_SDQ13 DDRA_SDM1 DDR_CLK0

DDR_CLK0# DDRA_SDQ14

DDRA_SDQ15

DDRA_SDQ20 DDRA_SDQ21

DDRA_SDM2 DDRA_SDQ22

DDRA_SDQ23 DDRA_SDQ28

DDRA_SDQ29 DDRA_SDQS3#

DDRA_SDQS3 DDRA_SDQ30

DDRA_SDQ31 DDRA_CKE1

DDRA_SMA14 DDRA_SMA11

DDRA_SMA7 DDRA_SMA6

DDRA_SMA4 DDRA_SMA2 DDRA_SMA0

DDRA_SBS1 DDRA_SRAS# DDRA_SCS0#

DDRA_ODT0 DDRA_SMA13

DDRA_SDQ36 DDRA_SDQ37

DDRA_SDM4 DDRA_SDQ38

DDRA_SDQ39 DDRA_SDQ44

DDRA_SDQ45 DDRA_SDQS5#

DDRA_SDQS5 DDRA_SDQ46

DDRA_SDQ47 DDRA_SDQ52

DDRA_SDQ53 DDR_CLK1

DDR_CLK1# DDRA_SDM6 DDRA_SDQ54

DDRA_SDQ55 DDRA_SDQ60

DDRA_SDQ61 DDRA_SDQS7#

DDRA_SDQS7 DDRA_SDQ62

DDRA_SDQ63

R238 10K_0402_5%R238 10K_0402_5%

1 2

R239 10K_0402_5%R239 10K_0402_5%

1 2

DDR_CLK0 <15> DDR_CLK0# <15>

DDRA_SDQS3# <8,13> DDRA_SDQS3 <8,13>

DDRA_CKE1 <8>

Swap RP6 Pin2 & RP7 Pin 1

DDRA_SBS1 <8,13> DDRA_SRAS# <8,13> DDRA_SCS0# <8>

DDRA_ODT0 <8>

DDRA_SDQS5# <8,13> DDRA_SDQS5 <8,13>

DDR_CLK1 <15> DDR_CLK1# <15>

DDRA_SDQS7# <8,13> DDRA_SDQS7 <8,13>

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

3

+DIMM_VREF

20mils

1

C771

0.1U_0402_16V4Z

2

DDRA_SMA[0..14]<8,13>

DDRA_SDQ[0..63]<8,13>

DDRA_SDM[0..7]<8,13>

Swap RP11,RP12 Pin 1 & 2

DDRA_SBS2 DDRA_CKE0

DDRA_SMA9 DDRA_SMA12

DDRA_SMA8 DDRA_SMA5

DDRA_SMA3 DDRA_SMA1

DDRA_SMA10 DDRA_SBS0

DDRA_SWE# DDRA_SCAS#

DDRA_SCS1# DDRA_ODT1

DDRA_SMA11 DDRA_SMA14

DDRA_SMA6 DDRA_SMA7

DDRA_SMA2 DDRA_SMA4

DDRA_SBS1 DDRA_SMA0

DDRA_SCS0# DDRA_SRAS#

DDRA_SMA13 DDRA_ODT0

DDRA_CKE1

2008/10/18 2009/10/18

3

C277

2.2U_0603_6.3V6K

DDRA_SMA[0..14] DDRA_SDQ[0..63] DDRA_SDM[0..7]

1 4 2 3

RP11 56_0404_4P2R_5%RP11 56_0404_4P2R_5%

1 4 2 3

RP12 56_0404_4P2R_5%RP12 56_0404_4P2R_5%

1 4 2 3

RP6 56_0404_4P2R_5%RP6 56_0404_4P2R_5%

1 4 2 3

RP7 56_0404_4P2R_5%RP7 56_0404_4P2R_5%

1 4 2 3

RP8 56_0404_4P2R_5%RP8 56_0404_4P2R_5%

1 4 2 3

RP9 56_0404_4P2R_5%RP9 56_0404_4P2R_5%

1 4 2 3

RP10 56_0404_4P2R_5%RP10 56_0404_4P2R_5%

1 4 2 3

RP13 56_0404_4P2R_5%RP13 56_0404_4P2R_5%

1 4 2 3

RP14 56_0404_4P2R_5%RP14 56_0404_4P2R_5%

1 4 2 3

RP15 56_0404_4P2R_5%RP15 56_0404_4P2R_5%

1 4 2 3

RP16 56_0404_4P2R_5%RP16 56_0404_4P2R_5%

1 4 2 3

RP17 56_0404_4P2R_5%RP17 56_0404_4P2R_5%

1 4 2 3

RP18 56_0404_4P2R_5%RP18 56_0404_4P2R_5%

1 2

R241 56_0402_5%R241 56_0402_5%

Layout Note: Place these resistor closely JP35,all trace length Max=1.5"

Compal Secret Data

Deciphered Date

R236

1K_0402_1%

R235

1K_0402_1%

+0.9VS

2

+1.8V

12

0.1U_0402_16V4Z

12

0.1U_0402_16V4Z

2

1

New Add For SiS New Add For SiS

1

C770

2

1

C772

2

+1.8V

C296

2.2U_0603_6.3V6K

+1.8V

1

C778

0.1U_0402_16V4Z

2

+0.9VS

1

C780

0.1U_0402_16V4Z

2

+0.9VS

1

C784

0.1U_0402_16V4Z

2

+0.9VS

1

C306

0.1U_0402_16V4Z

2

Layout Note: Place one cap close to every 2 pullup resistors terminated to +0.9VS

+DIMM_VREF

1

C773

C773 220P_0402_50V7K

220P_0402_50V7K

2

@

C774

2.2U_0603_6.3V6K

1

C297

0.1U_0402_16V4Z

2

1

C781

0.1U_0402_16V4Z

2

1

C785

0.1U_0402_16V4Z

2

1

C305

0.1U_0402_16V4Z

2

Title

Size Document Number Rev

Date: Sheet

Date: Sheet of

+1.8V

1

+

C303

@

330U_D2E_2.5VM

2

Layout Note: Place near JP35

C776

C775

2.2U_0603_6.3V6K

B

KFT00 M/B LA-4821P Schematic

C776

2.2U_0603_6.3V6K

1

C779

0.1U_0402_16V4Z

2

1

C782

0.1U_0402_16V4Z

2

1

C299

0.1U_0402_16V4Z

2

1

C298

0.1U_0402_16V4Z

2

1

C295

0.1U_0402_16V4Z

2

1

C744

0.1U_0402_16V4Z

2

1

C308

0.1U_0402_16V4Z

2

Compal Electronics, Inc.

DDRII-SODIMM0

1

+

C304

@

330U_D2E_2.5VM

2

C777

2.2U_0603_6.3V6K

1

C783

0.1U_0402_16V4Z

2

1

C307

0.1U_0402_16V4Z

2

of

12 47Tuesday, March 10, 2009

1.0

A

+1.8V +1.8V

JDIMM2

+DIMM_VREF

DDRA_SDQ0 DDRA_SDQ1

DDRA_SDQS0#<8,12> DDRA_SDQS0<8,12>

1 1

DDRA_SDQS1#<8,12> DDRA_SDQS1<8,12>

DDRA_SDQS2#<8,12> DDRA_SDQS2<8,12>

EC_TX_P80_DATA<12,29,31>

2 2

3 3

4 4

EC_RX_P80_CLK<12,29,31>

DDRA_CKE2<8>

DDRA_SBS2<8,12>

DDRA_SBS0<8,12> DDRA_SWE#<8,12>

DDRA_SCAS#<8,12> DDRA_SCS3#<8>

DDRA_ODT3<8>

DDRA_SDQS4#<8,12> DDRA_SDQS4<8,12>

EC_RX_P80_CLK_R<12>

DDRA_SDQS6#<8,12> DDRA_SDQS6<8,12>

SDATA<12,14,15,20> SCLK<12,14,15,20>

C259

2.2U_0603_6.3V6K

A

+3VS

DDRA_SDQS0# DDRA_SDQS0

DDRA_SDQ2 DDRA_SDQ3

DDRA_SDQ8 DDRA_SDQ9

DDRA_SDQS1# DDRA_SDQS1

DDRA_SDQ10 DDRA_SDQ11

DDRA_SDQ16 DDRA_SDQ17

DDRA_SDQS2# DDRA_SDQS2

DDRA_SDQ18 DDRA_SDQ19

DDRA_SDQ24

DDRA_SDM3 EC_TX_P80_DATA

DDRA_SDQ26 DDRA_SDQ27

DDRA_CKE2 EC_RX_P80_CLK

DDRA_SBS2 DDRA_SMA12

DDRA_SMA9 DDRA_SMA8

DDRA_SMA5 DDRA_SMA3 DDRA_SMA1

DDRA_SMA10 DDRA_SBS0 DDRA_SWE#

DDRA_SCAS# DDRA_SCS3#

DDRA_ODT3 DDRA_SDQ32

DDRA_SDQ33 DDRA_SDQS4#

DDRA_SDQS4 DDRA_SDQ34

DDRA_SDQ35 DDRA_SDQ40

DDRA_SDQ41 DDRA_SDM5 DDRA_SDQ42

DDRA_SDQ43 DDRA_SDQ48

DDRA_SDQ49

EC_RX_P80_CLK_R

DDRA_SDQS6# DDRA_SDQS6

DDRA_SDQ50 DDRA_SDQ51

DDRA_SDQ56 DDRA_SDQ57

DDRA_SDM7 DDRA_SDQ58

DDRA_SDQ59 SDATA

SCLK

+3VS

1

C260

0.1U_0402_16V4Z

2

Add GND Pin For EMI Recommend

DIMM1 STD H:9.2mm (BOT)

1

VREF

3

VSS

5

DQ0

7

DQ1

9

VSS

11

DQS0#

13

DQS0

15

VSS

17

DQ2

19

DQ3

21

VSS

23

DQ8

25

DQ9

27

VSS

29

DQS1#

31

DQS1

33

VSS

35

DQ10

37

DQ11

39

VSS

41

VSS

43

DQ16

45

DQ17

47

VSS

49

DQS2#

51

DQS2

53

VSS

55

DQ18

57

DQ19

59

VSS

61

DQ24

63

DQ25

65

VSS

67

DM3

69

NC

71

VSS

73

DQ26

75

DQ27

77

VSS

79

CKE0

81

VDD

83

NC

85

BA2

87

VDD

89

A12

91

A9

93

A8

95

VDD

97

A5

99

A3

101

A1

103

VDD

105

A10/AP

107

BA0

109

WE#

111

VDD

113

CAS#

115

NC/S1#

117

VDD

119

NC/ODT1

121

VSS

123

DQ32

125

DQ33

127

VSS

129

DQS4#

131

DQS4

133

VSS

135

DQ34

137

DQ35

139

VSS

141

DQ40

143

DQ41

145

VSS

147

DM5

149

VSS

151

DQ42

153

DQ43

155

VSS

157

DQ48

159

DQ49

161

VSS

163

NC,TEST

165

VSS

167

DQS6#

169

DQS6

171

VSS

173

DQ50

175

DQ51

177

VSS

179

DQ56

181

DQ57

183

VSS

185

DM7

187

VSS

189

DQ58

191

DQ59

193

VSS

195

SDA

197

SCL

199

VDDSPD

201

GND

P-TWO_A5692B-A0G16-P

CONN@

VSS DQ4 DQ5 VSS DM0 VSS DQ6 DQ7

VSS DQ12 DQ13

VSS

DM1

VSS

CK0

CK0#

VSS DQ14 DQ15

VSS

VSS DQ20 DQ21

VSS

DM2

VSS DQ22 DQ23

VSS DQ28 DQ29

VSS

DQS3#

DQS3

VSS DQ30 DQ31

VSS

NC/CKE1

VDD

NC/A15 NC/A14

VDD

A11

VDD

BA1

RAS#

S0#

VDD ODT0

NC/A13

VDD

VSS DQ36 DQ37

VSS

DM4

VSS DQ38 DQ39

VSS DQ44 DQ45

VSS

DQS5#

DQS5

VSS DQ46 DQ47

VSS DQ52 DQ53

VSS

CK1

CK1#

VSS

DM6

VSS DQ54 DQ55

VSS DQ60 DQ61

VSS

DQS7#

DQS7

VSS DQ62 DQ63

VSS

SAO

SA1

GND

B

2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40

42 44 46 48 50

NC

52 54 56 58 60 62 64 66 68 70 72 74 76 78 80 82 84 86 88 90 92

A7

94

A6

96 98

A4

100

A2

102

A0

104 106 108 110 112 114 116 118 120

NC

122 124 126 128 130 132 134 136 138 140 142 144 146 148 150 152 154 156 158 160 162 164 166 168 170 172 174 176 178 180 182 184 186 188 190 192 194 196 198 200 202

B

DDRA_SDQ4 DDRA_SDQ5

DDRA_SDM0 DDRA_SDQ6

DDRA_SDQ7 DDRA_SDQ12

DDRA_SDQ13 DDRA_SDM1 DDR_CLK2

DDR_CLK2# DDRA_SDQ14

DDRA_SDQ15

DDRA_SDQ20 DDRA_SDQ21

DDRA_SDM2 DDRA_SDQ22

DDRA_SDQ23 DDRA_SDQ28

DDRA_SDQ29DDRA_SDQ25 DDRA_SDQS3#

DDRA_SDQS3 DDRA_SDQ30

DDRA_SDQ31 DDRA_CKE3

DDRA_SMA14 DDRA_SMA11

DDRA_SMA7 DDRA_SMA6

DDRA_SMA4 DDRA_SMA2 DDRA_SMA0

DDRA_SBS1 DDRA_SRAS# DDRA_SCS2#

DDRA_ODT2 DDRA_SMA13

DDRA_SDQ36 DDRA_SDQ37

DDRA_SDM4 DDRA_SDQ38

DDRA_SDQ39 DDRA_SDQ44

DDRA_SDQ45 DDRA_SDQS5#

DDRA_SDQS5 DDRA_SDQ46

DDRA_SDQ47 DDRA_SDQ52

DDRA_SDQ53 DDR_CLK3

DDR_CLK3# DDRA_SDM6 DDRA_SDQ54

DDRA_SDQ55 DDRA_SDQ60

DDRA_SDQ61 DDRA_SDQS7#

DDRA_SDQS7 DDRA_SDQ62

DDRA_SDQ63

R233 10K_0402_5%R233 10K_0402_5%

1 2

R234 10K_0402_5%R234 10K_0402_5%

1 2

DDR_CLK2 <15> DDR_CLK2# <15>

DDRA_SDQS3# <8,12> DDRA_SDQS3 <8,12>

DDRA_CKE3 <8>

DDRA_SBS1 <8,12> DDRA_SRAS# <8,12> DDRA_SCS2# <8>

DDRA_ODT2 <8>

DDRA_SDQS5# <8,12> DDRA_SDQS5 <8,12>

DDR_CLK3 <15> DDR_CLK3# <15>

DDRA_SDQS7# <8,12> DDRA_SDQS7 <8,12>

+3VS

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

C

+DIMM_VREF

20mils

1

C258

0.1U_0402_16V4Z

2

DDRA_SCS3# DDRA_ODT3

DDRA_CKE3 DDRA_CKE2

DDRA_SCS2# DDRA_ODT2

C255

2.2U_0603_6.3V6K

DDRA_SMA[0..14]<8,12> DDRA_SDQ[0..63]<8,12> DDRA_SDM[0..7]<8,12>

1 4 2 3

RP3 56_0404_4P2R_5%RP3 56_0404_4P2R_5%

1 4 2 3

RP5 56_0404_4P2R_5%RP5 56_0404_4P2R_5%

1 4 2 3

RP4 56_0404_4P2R_5%RP4 56_0404_4P2R_5%

DDRA_SMA[0..14] DDRA_SDQ[0..63] DDRA_SDM[0..7]

+0.9VS

D

4.7U_0805_10V4Z

+1.8V

C253

2.2U_0603_6.3V6K

+1.8V

1

C266

0.1U_0402_16V4Z

2

+0.9VS

1

C262

2

C256

2.2U_0603_6.3V6K

1

C267

0.1U_0402_16V4Z

2

1

C261

4.7U_0805_10V4Z

2

C254

2.2U_0603_6.3V6K

1

C265

0.1U_0402_16V4Z

2

E

Layout Note: Place near JP34

C264

2.2U_0603_6.3V6K

1

C257

0.1U_0402_16V4Z

2

C263

2.2U_0603_6.3V6K

EMI Recommend

+1.8V

1

C847

<EMI>

0.1U_0402_16V4Z

2

1

C848

<EMI>

0.1U_0402_16V4Z

2

1

C849

<EMI>

0.1U_0402_16V4Z

2

1

C850

<EMI>

0.1U_0402_16V4Z

2

01/06 Add C855,C856,C857,C858 (0.1uF) for EMI Recommend

+0.9VS

1

C856

<EMI>

0.1U_0402_16V4Z

2

Layout Note:

Layout Note: Place these resistor closely JP34,all trace length Max=1.5"

Compal Secret Data

2008/10/18 2009/10/18

C

Compal Secret Data

Deciphered Date

D

Place one cap close to every 2 pullup resistors terminated to +0.9VS

1

C855

<EMI>

0.1U_0402_16V4Z

2

Title

Size Document Number Rev

B

Date: Sheet

1

C857

<EMI>

0.1U_0402_16V4Z

2

Compal Electronics, Inc.

DDRII-SODIMM1

KFT00 M/B LA-4821P Schematic

1

C858

<EMI>

0.1U_0402_16V4Z

2

E

13 47Tuesday, March 10, 2009

of

1.0

5

+3VS

L3

1 2

KC FBM-L11-201209-221LMAT_0805

10U_0805_10V4Z

D D

+3VS

RP39

10K_1206_8P4R_5%

Remove R43 R66 R529 R527 and use PR39 Michael 2008/5/30

+3VS

R80 2.7K_0402_5%@R80 2.7K_0402_5%@ R55 2.7K_0402_5%@R55 2.7K_0402_5%@ R78 2.7K_0402_5%@R78 2.7K_0402_5%@

C C

R54 2.7K_0402_5%@R54 2.7K_0402_5%@ R76 2.7K_0402_5%@R76 2.7K_0402_5%@ R53 2.7K_0402_5%@R53 2.7K_0402_5%@ R52 2.7K_0402_5%R52 2.7K_0402_5% R74 2.7K_0402_5%@R74 2.7K_0402_5%@ R73 2.7K_0402_5%@R73 2.7K_0402_5%@ R56 2.7K_0402_5%R56 2.7K_0402_5%

45 36 27 18

C100

1

10U_0805_10V4Z

2

MODE

CLK_RESET#

STOP#

48M

C664

1

C69

0.1U_0402_16V4Z

2

1

2

SB

EC

C70

0.1U_0402_16V4Z

1

2

FSL0

FSL1

FSL2

FSL3

FSL4

1

C71

0.1U_0402_16V4Z

2

10U_0805_10V4Z

Reference schematic use 1206

REF_CLK0<9> REF_CLK1<20> VBRCLK<18>

CLK_PCI_SB<19>

CLK_PCI_EC<31>

DB

EXP_CLKREQ#<30>

R39 4.7K_0402_5%R39 4.7K_0402_5%

CPU_BSEL0<5> CPU_BSEL1<5> CPU_BSEL2<5>

B B

A A

C82 18P_0402_50V8JC82 18P_0402_50V8J

C86 18P_0402_50V8JC86 18P_0402_50V8J

DDATA<29,30>

DCLK<29,30>

1 2

R40 4.7K_0402_5%R40 4.7K_0402_5%

1 2

R38 4.7K_0402_5%R38 4.7K_0402_5%

1 2

XTAL_IN

12

Y1

14.31818MHZ_16PF_DSX840GA

XTAL_OUT

R352

2.2K_0402_5%

DDATA

+3VS

DCLK

5

FSL0 FSL1 FSL2

R355

2.2K_0402_5%

2N7002DW-T/R7_SOT363-6

WLAN_CLKREQ#<29>

CLK_PCI_DB<33> CLK_EN#<46>

VGATE<46> CPUSTP#<25>

SDATA<12,13,15,20>

SCLK<12,13,15,20>

R344

1K_0402_5%

Q3A

6 1

2 5

3

4

Q3B

Replace Package from SOT23 to SOT363-6 Michael 2008/5/30

1

C72

0.1U_0402_16V4Z

2

+3VS

C420

@

+3VS+3VALW

4

12

R32

@

10K_0402_5%

1

C98

0.1U_0402_16V4Z

2

1

C79

0.1U_0402_16V4Z

2

CLKGEN_VDD

1

C99

0.1U_0402_16V4Z

2

C405

0.1U_0402_16V4Z

Use SB03904008L & SB000006A00 FootPrint

L30

1 2

1

0.1U_0402_16V4Z

2

REF_CLK0 REF_CLK1 VBRCLK

CLK_PCI_SB

CLK_PCI_DB PCICLK7

CLK_EN#

VTTPWRGD

SDATA SCLK

R343

R343 1K_0402_5%

1K_0402_5%

SDATA

SCLK

4

KC FBM-L11-201209-221LMAT_0805

1

C403

1

C404

C404 10U_0805_10V4Z

2

R79 33_0402_5%R79 33_0402_5% R77 22_0402_5%R77 22_0402_5% R818 22_0402_5%R818 22_0402_5%

R75 33_0402_5%R75 33_0402_5%

R72 33_0402_5%R72 33_0402_5%

R50 33_0402_5%R50 33_0402_5% R71 33_0402_5%R71 33_0402_5% R51 33_0402_5%@R51 33_0402_5%@ R62 0_0402_5%@R62 0_0402_5%@

R81 0_0402_5%@R81 0_0402_5%@ R82 0_0402_5%R82 0_0402_5%

R67 0_0402_5%R67 0_0402_5%

R338 0_0402_5%R338 0_0402_5% R337 0_0402_5%R337 0_0402_5%

10U_0805_10V4Z

2

1 2 1 2 1 2

1 2

1 2 1 2 1 2 1 2

1 2 1 2

1 2

1 2 1 2

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

+3VS +3VS+CPU_CORE

2

B

E

VDDA

XTAL_IN XTAL_OUT

FSL0 FSL1

FSL2 FSL3 FSL4CLK_PCI_EC STOP# MODE CLKREQ0#EXP_CLKREQ# CLKREQ1#WLAN_CLKREQ#

CK_PWRGDVGATE CLK_RESET#CPUSTP#

SMDATA SMCLK

3

12

R58

@

10K_0402_5%

C

Q10

Q10 MMBT3904_SOT23

MMBT3904_SOT23

@

3 1

CLKGEN_VDD

U4

50

VDDA

47

GNDA

5

X1

6

X2

3

*FSL0/REF0_2x

4

**FSL1/REF1_2x

9

**FSL2/PCICLK0_2x

10

**FS3/PCICLK1_2x

11

**FS4/PCICLK2

12

*(PCI_STOP#)/PCICLK3

15

**MODE/PCICLK4

16

(PECLKREQ0#)/PCICLK5

17

(PECLKREQ1#)/PCICLK6

18

PCICLK7

1

VTTPWRGD/PD#/(CLK_STOP#)

28

*(CPU_STOP#)/RESET#

45

SDATA

46

SCLK

2008/10/18

3

12

R57

@

10K_0402_5%

C

Q9

2

B

MMBT3904_SOT23

E

@

3 1

2

14

19

23

VDDZ

VDDREF

VDDPCI_0

VDDPCI_1

ICS9LPR600

GNDREF7GNDPCI_0

GNDPCI_1

8

13

Compal Secret Data

VTTPWRGD

24

56

39

29

VDD48

VDDCPU

VDDPCIEX_0

VDDPCIEX_1

**SEL24_48#/24_48MHz

GNDZ

GND48

GNDCPU

GNDPCIEX_0

GNDPCIEX_1

ICS9LPR600BGLF-T_TSSOP56

20

27

53

42

32

Deciphered Date

CPUT_L0 CPUC_L0 CPUT_L1 CPUC_L1

PCIET_L0

PCIEC_L0 PCIET_L1

PCIEC_L1 PCIET_L2

PCIEC_L2 PCIET_L3

PCIEC_L3

PCIET_L4F PCIEC_L4F

PCIET_L5F PCIEC_L5F

SATACLKC_L SATACLKT_L

ZCLK0 ZCLK1

12MHz

2

FSL21FSL1FSL3FSL4 ZCLK

0

1

0

1

0

FSL0

1

0 1 0 200 100 33.30 1 133

CPUT_L0

55

CPUC_L0

54

CPUT_L1

52

CPUC_L1

51

PCIET_L0

44

PCIEC_L0

43 41

40

PCIET_L2

38

PCIEC_L2

37

PCIET_L3

36

PCIEC_L3

35

PCIET_L4F

34

PCIEC_L4F

33

PCIET_L5F

31

PCIEC_L5F

30

SATACLKC_L

48

SATACLKT_L

49

ZCLK0

21

ZCLK1

22

48M CLK_48M_CR

26

12M USB_CLK_12M

25

R95 33_0402_5%R95 33_0402_5%

1 2

R102 33_0402_5%R102 33_0402_5%

1 2

R94 33_0402_5%R94 33_0402_5%

1 2

R101 33_0402_5%R101 33_0402_5%

1 2

R91 33_0402_5%R91 33_0402_5%

1 2

R90 33_0402_5%R90 33_0402_5%

1 2

R89 33_0402_5%R89 33_0402_5%

1 2

R88 33_0402_5%R88 33_0402_5%

1 2

R106 33_0402_5%R106 33_0402_5%

1 2

R105 33_0402_5%R105 33_0402_5%

1 2

R87 33_0402_5%R87 33_0402_5%

1 2

R86 33_0402_5%R86 33_0402_5%

1 2

R104 33_0402_5%R104 33_0402_5%

1 2

R103 33_0402_5%R103 33_0402_5%

1 2

R92 33_0402_5%R92 33_0402_5%

1 2

R93 33_0402_5%R93 33_0402_5%

1 2

R49 22_0402_5%R49 22_0402_5%

1 2

R70 22_0402_5%R70 22_0402_5%

1 2

R65 33_0402_5%R65 33_0402_5%

1 2

R68 33_0402_5%R68 33_0402_5%

1 2

Pin 26 need BIOS to set disable,

for saving power & good EMI

Title

2009/10/18

2

Title

Clock Generator ICS9LPR600C

Size Document Number Rev

Custom

KFT00 M/B LA-4821P Schematic

Tuesday, March 10, 2009

Date: Sheet

1

H_CLK_DP0 H_CLK_DN0 H_CLK_DP1 H_CLK_DN1

PCIE_CLK_NB PCIE_CLK_NB#

PCIE_CLK_SB PCIE_CLK_SB#

PCIE_CLK_307 PCIE_CLK_307#

PCIE_CLK_EXP PCIE_CLK_EXP#

PCIE_CLK_WLAN PCIE_CLK_WLAN#

SATA_CLK_DN SATA_CLK_DP

Z_CLK0 Z_CLK1

Z_CLK0 Z_CLK1 CLK_PCI_SB

CLK_PCI_EC CLK_PCI_DB REF_CLK0 REF_CLK1

CPU MHz

133

166

1

PCI

PCIE

MHz

33.30

1000

100

33.3

H_CLK_DP0 <4> H_CLK_DN0 <4> H_CLK_DP1 <7> H_CLK_DN1 <7>

PCIE_CLK_NB <7> PCIE_CLK_NB# <7>

PCIE_CLK_SB <20> PCIE_CLK_SB# <20>

PCIE_CLK_307 <18> PCIE_CLK_307# <18>

PCIE_CLK_EXP <30> PCIE_CLK_EXP# <30>

PCIE_CLK_WLAN <29> PCIE_CLK_WLAN# <29>

SATA_CLK_DN <21> SATA_CLK_DP <21>

Z_CLK0 <9> Z_CLK1 <19>

CLK_48M_CR <26>

USB_CLK_12M <21>

C62 10P_0402_50V8J@C62 10P_0402_50V8J@

1 2

C61 10P_0402_50V8J@C61 10P_0402_50V8J@

1 2

C63 10P_0402_50V8J@C63 10P_0402_50V8J@

1 2

C66 10P_0402_50V8J@C66 10P_0402_50V8J@

1 2

C59 10P_0402_50V8J@C59 10P_0402_50V8J@

1 2

C65 10P_0402_50V8J@C65 10P_0402_50V8J@

1 2

C64 10P_0402_50V8J@C64 10P_0402_50V8J@

1 2

1

MHz

133

NB

SB

NewCard

of

14 47

of

14 47

of

14 47

307LV

WLAN

1.0

5

4

3

2

1

+1.8V

1

C852

D D

C852

<EMI>

0.1U_0402_16V4Z

2

L25

1 2

C853

<EMI>

0.1U_0402_16V4Z

KC FBM-L11-201209-221LMAT_0805

1

0.1U_0402_16V4Z

2

C854

<EMI>

1

2

10U_0805_10V4Z

C274

1

2

1

C665

C665 10U_0805_10V4Z

10U_0805_10V4Z

2

0.1U_0402_16V4Z

1

C273

C301

2

0.1U_0402_16V4Z

1

C302

2

0.1U_0402_16V4Z

1

C788

2

1

C275

2

0.1U_0402_16V4Z

CLKBUF_VDD

1

2

01/06 Add C852,C853,C854(0.1uF) for EMI Recommend

+1.8V

L26

1 2

1

C789

C789 10U_0805_10V4Z

10U_0805_10V4Z

2

C C

B B

Reference schematic use 1206

01/10 Change C789 from @ to mount for EMI Recommend

KC FBM-L11-201209-221LMAT_0805

1

C790

0.1U_0402_16V4Z

2

1

C276

C276 10U_0805_10V4Z

10U_0805_10V4Z

2

CLKBUF_AVDD

CLK_INC<8> CLK_INT<8>

SDATA<12,13,14,20> SCLK<12,13,14,20>

10P_0402_50V8J

C300 close to R242

CLKBUF_VDD

CLK_INC

CLK_INT

SDATA SCLK

R243 0_0402_5%R243 0_0402_5% R242 22_0402_5%R242 22_0402_5%

1

C300

2

R245 0_0402_5%R245 0_0402_5% R244 0_0402_5%R244 0_0402_5%

12 12

FB_INAFB_OUTA FB_OUTA_R

Horizontal rotate

U12

3

VDD1.8_0

11

VDD1.8_1

25

VDD1.8_2

21

VDD1.8_3

10

CLK_INC

9

CLK_INT

20

SDATA

19

SCLK

18

FB_IN

17

FB_OUT

8

GND_0

6

GND_1

28

GND_2

24

GND_3

14

GND_4

ICS9P935AFLF-T_SSOP28

VDDA1.8

DDRC0 DDRT0

DDRC1 DDRT1

DDRC2 DDRT2

DDRC3 DDRT3

DDRC4 DDRT4

DDRC5 DDRT5

CLKBUF_AVDD

7

DDRC0

R819 0_0402_5%R819 0_0402_5%

1

DDRT0

2

DDRC1

5

DDRT1

4

DDRC2

13

DDRT2

12

DDRC3

15

DDRT3 DDR_CLK3

16 23

22 27

26

1 2

R820 0_0402_5%R820 0_0402_5%

1 2

R821 0_0402_5%R821 0_0402_5%

1 2

R822 0_0402_5%R822 0_0402_5%

1 2

R823 0_0402_5%R823 0_0402_5%

1 2

R824 0_0402_5%R824 0_0402_5%

1 2

R825 0_0402_5%R825 0_0402_5%

1 2

R826 0_0402_5%R826 0_0402_5%

1 2

DDR_CLK0# DDR_CLK0

DDR_CLK2# DDR_CLK2

DDR_CLK1#

DDR_CLK1

DDR_CLK3#

DDR_CLK0# <12> DDR_CLK0 <12>

DDR_CLK2# <13> DDR_CLK2 <13>

DDR_CLK1# <12> DDR_CLK1 <12>

DDR_CLK3# <13> DDR_CLK3 <13>

A A

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18

3

Compal Secret Data

Deciphered Date

2009/10/18

2

Title

Size Document Number Rev

Custom

Date: Sheet

Clock Buffer ICS9P935

KFT00 M/B LA-4821P Schematic

Tuesday, March 10, 2009

1

15 47

of

1.0

5

LCD POWER CIRCUIT

4

3

2

1

G

2

C29

@

+LCDVDD_L

BKOFF#<31>

INVT_PWM<31>

+3VS

1 3

1

2

+3VS

S

D

W=60mils

Q5

Q5 SI2301BDS_SOT23

SI2301BDS_SOT23

+LCDVDD

DAC_BRIG INVT_PWM DISPOFF#

INVT_PWM

1

C36

@

4.7U_0805_10V4Z

2

W=60mils

1

C32

0.1U_0402_16V4Z

2

C44 680P_0402_50V7K<EMI>C44 680P_0402_50V7K<EMI>

1 2

C48 680P_0402_50V7K<EMI>C48 680P_0402_50V7K<EMI>

1 2

C45 680P_0402_50V7K<EMI>C45 680P_0402_50V7K<EMI>

1 2

C269 680P_0402_50V7K<EMI>C269 680P_0402_50V7K<EMI>

1 2

C268 0.1U_0402_16V4ZC268 0.1U_0402_16V4Z

1 2

C271 10U_0805_10V4ZC271 10U_0805_10V4Z

1 2

C272 0.1U_0402_16V4ZC272 0.1U_0402_16V4Z

1 2

D11 RB751V_SOD323D11 RB751V_SOD323

R25 0_0402_5%R25 0_0402_5%

21

1 2

+3VS

12

R28

4.7K_0402_5%

DISPOFF#BKOFF#

INV_PWN_R

+LCDVDD

D D

+3VALW +3VS

12

R827

R827 10K_0402_5%

2

B

E

10K_0402_5%

C

Q37

Q37 MMBT3904_SOT23

MMBT3904_SOT23

3 1

JLVDS1

3 5 7

13 15 17 19 21 23 25 27 29

31 32

ACES_88242-3001

ACES_88242-3001 CONN@

CONN@

Level Shift Circuit

R829

GMCH_ENVDD<18>

C C

+INVPWR_B+

L10

+LCDVDD

FBMA-L11-201209-221LMA30T_0805

+3VS

DAC_BRIG<31> LVDSAC- <18> I2CC_SCL<18> I2CC_SDA<18>

B B

12

INV_PWN_R DISPOFF# DAC_BRIG

I2CC_SCL I2CC_SDA

1 2

47K_0402_5%

R22

R22 100K_0402_5%

100K_0402_5%

12

(60 MIL)

+LCDVDD_L

SSM3K7002FU_SC70-3

2

B

112

4

3 5

6 8

7 9910 111112

14

13

16

15

18

17

20

19 21

22 24

23 25

26

27

28

29

30

GND1 GND2

12

R828

R828 15K_0402_5%

15K_0402_5%

C

Q38

Q38 MMBT3904_SOT23

MMBT3904_SOT23

E

3 1

2 4 6 8 10 12 14 16 18 20 22 24 26 28 30

12

13

D

Q8

S

GMCH_ENVDD_Q

Change Q7 Q8 package from SOT23 to SC70-3 Michael 2008/5/30

LVDSA2+ LVDSA2-

LVDSA1+ LVDSA1-

LVDSA0+ LVDSA0-

LVDSAC+ LVDSAC-

R16

R16 300_0603_5%

300_0603_5%

2

G

+3VALW

12

R17

R17 100K_0402_5%

100K_0402_5%

R15 10K_0402_5%R15 10K_0402_5%

13

D

Q7

2

G

SSM3K7002FU_SC70-3

G

SSM3K7002FU_SC70-3

S

LVDSA2+ <18> LVDSA2- <18>

LVDSA1+ <18> LVDSA1- <18>

LVDSA0+ <18> LVDSA0- <18>

LVDSAC+ <18>

12

2

C35

0.1U_0402_16V4Z

1

4.7U_0805_10V4Z

+INVPWR_B+

L12

KC FBM-L11-201209-221LMAT_0805

L11

KC FBM-L11-201209-221LMAT_0805

1

C43

C49

0.1U_0603_50V4Z

A A

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

3

2008/10/18 2009/10/18

Compal Secret Data

C43 68P_0402_50V8K

68P_0402_50V8K

2

@

Deciphered Date

12

2

B+

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

Compal Electronics, Inc.

LVDS & DVI Connector

KFT00 M/B LA-4821P Schematic

16 47Tuesday, March 10, 2009

of

1

of

1.0

A

B

C

D

E

D7

@

DAN217_SC59

1

2

3

CRT_R_2

CRT_G_2

CRT_B_2

1

C287

C287 10P_0402_50V8J

10P_0402_50V8J

2

CRT_HSYNC_2

CRT_VSYNC_2

1

C291

2

<EMI>

DAN217_SC59

+5VS

L13

KC FBM-L11-201209-221LMAT_0805

<EMI>

D9

@

1 2

+L_CRT_VCC

1

2

2 1

C292

C292 10P_0402_50V8J

10P_0402_50V8J

<EMI>

1

2

3

D8

RB491D_SC59-3

2

1

C288

2

<EMI>

100P_0402_50V8J

1

D10

<EMI>

DAN217_SC59

@

3

W=40mils

F1

21

1.1A_6VDC_FUSE

1

C278

0.1U_0402_16V4Z

2

1

C290

<EMI>

68P_0402_50V8K

2

1

C293

C293 68P_0402_50V8K

68P_0402_50V8K

2

<EMI>

12/22 Change to SE071680J80 (IFTXX)

+CRT_VCC+R_CRT_VCC

W=40mils

Follow JFT00 Smybol

JCRT1

6

11

1 7

12

2 8

13

3 9

14

4 10 15

5

SUYIN_070549FR015S208CR

CONN@

DSUB_12

DSUB_15

Add IFTXX Andy_1102

16 17

CRT Connector

D6

D5

@

DAN217_SC59

1 1

1 2

10P_0402_50V8J

12

CRT_HSYNC_1

+3VS

C284

CRT_VSYNC_1

1

2

Place closed to chipset

VGA_CRT_R<9>

VGA_CRT_G<9>

VGA_CRT_B<9>

2 2

VGA_CRT_R

VGA_CRT_G

VGA_CRT_B

75_0402_5%

R212

12

75_0402_5%

R213

12

R214

75_0402_5%

VGA_CRT_HSYNC<9>

12

Place closed to chipset

VGA_CRT_VSYNC<9>

1

C280

C279

2

10P_0402_50V8J

C289 0.1U_0402_16V4ZC289 0.1U_0402_16V4Z

1

C281

2

10P_0402_50V8J

1 2

VGA_CRT_HSYNC

C294 0.1U_0402_16V4ZC294 0.1U_0402_16V4Z

1

2

+CRT_VCC

1 2

VGA_CRT_VSYNC

1

5

U5

P

4

OE#

A2Y

G

TC7SET125FUF_SC70

3

+CRT_VCC

1

C283

C282

2

22P_0402_50V8J

CRT_HSYNC_0

1

5

U6

P

OE#

A2Y

G

TC7SET125FUF_SC70

3

1

2

CRT_VSYNC_0

4

L15

L15 FBMA-L10-160808-800LMT_0603

FBMA-L10-160808-800LMT_0603 L17

L17 FBMA-L10-160808-800LMT_0603

FBMA-L10-160808-800LMT_0603 L19

L19 FBMA-L10-160808-800LMT_0603

FBMA-L10-160808-800LMT_0603

1

C285

2

22P_0402_50V8J

R215 10K_0402_5%R215 10K_0402_5%

1 2

R216 39_0402_1%R216 39_0402_1%

1 2

R218 39_0402_1%R218 39_0402_1%

D6

@

DAN217_SC59

2

3

1

C286

C286 10P_0402_50V8J

10P_0402_50V8J

2

<EMI>

1

3

10P_0402_50V8J

1

2

1 2

L20 FCM1608C-121T_0603

1 2

L21 FCM1608C-121T_0603

+5VS

+CRT_VCC

3 3

12

R222

2.2K_0402_5%

2N7002DW-T/R7_SOT363-6

2.2K_0402_5%

DSUB_12

DSUB_15

R221

+3VS

6 1

Q44A

2N7002DW-T/R7_SOT363-6

10/5 Change to SB00000AR00

4 4

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

A

B

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

C

2008/10/18 2009/10/18

Compal Secret Data

Deciphered Date

D

+3VS

12

R220

2.2K_0402_5%

2

5

3

4

Q44B

12

R225

2.2K_0402_5%

+3VS

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

Compal Electronics, Inc.

CRT & TV-OUT Connector

KFT00 M/B LA-4821P Schematic

GMCH_CRT_DATA <9>

GMCH_CRT_CLK <9>

E

17 47Tuesday, March 10, 2009

1.0

of

5

+1.8VS +1.8VS

L2 MBK1608121YZF_0603L2 MBK1608121YZF_0603

1 2

1

C436

2

10U_0805_10V4Z

Modify 10U_1206 to

D D

10U_0805

1

0.1U_0402_16V4Z

2

For 307LV/ELV only

GMCH_ENVDD<16> ENBKL<31>

C C

VB_LAVDD

307LV/ELV: Stuff R107, R96, C110 Un-stuff R108 307DV/CP: Stuff R108 Un-stuff R107, R96, C110

B B

R108 1.65K_0402_1%@R108 1.65K_0402_1%@

1 2

R107 6.04K_0402_1%R107 6.04K_0402_1%

1 2

R96 24K_0402_1%R96 24K_0402_1%

1 2

C110

C110 1U_0603_10V4Z

1U_0603_10V4Z

VBRCLK<14>

1 2

+3VS

General I/O Power

1 2

R358 0_0402_5%R358 0_0402_5%

VBRCLK

1

C425

C444

C425

0.1U_0402_16V4Z

2

0.1U_0402_16V4Z

R130

100K_0402_5%

LVDSA2+<16> LVDSA2-<16> LVDSA1+<16> LVDSA1-<16> LVDSA0+<16> LVDSA0-<16> LVDSAC+<16> LVDSAC-<16>

I2CC_SDA<16> I2CC_SCL<16>

R830 0_0402_5%R830 0_0402_5%

1 2

NB_RST#<9,19>

VB_VDD3V

1

C434

0.1U_0402_16V4Z

2

1

C424

2

T17

T17 T20

T20 T21

T21 T18

T18 T7 T8

T10

12

T12

T12 T16

T16 T13

T13 T14

T14 T19

T19 T22

T22

T15

T15 T11

T11 T9

1

C423

2

0.1U_0402_16V4Z

PAD

PAD PAD

PAD PADT7PAD PADT8PAD

PAD

PAD PAD

PAD

EXTSWING

LVDSA2+ LVDSA2LVDSA1+ LVDSA1LVDSA0+ LVDSA0LVDSAC+ LVDSAC-

VBOSCO VBRCLK_R

PAD

PAD PAD

PAD PADT9PAD

VB_PCIEVDD VB_PCIEAVDD

254mA 35mA

1

C422

0.1U_0402_16V4Z

2

Modify 10U_1206 to 10U_0805

U7

G2

H2 H1

G1 E12 E11 G13 G12 F11

F3

G3

F2 F1 H3

J3

C13 A12 A13 C11 C12 A10 A11

C9

C10

A8 A9 C7 C8 A6 A7 C5 C6 A4 A5 C3 C4

E13 F12

J1

J2 G11 F10 E10 F13

NOTE: all stuffed(default)

+1.8VS

A A

1

C441

0.1U_0402_16V4Z

2

1

2

0.1U_0402_16V4Z

C437

0.1U_0402_16V4Z

1

C440

2

0.1U_0402_16V4Z

1

C433

2

Internal Core Power

5

Modify before using!

I2CC_SCL I2CC_SDA

4

L37 MBK1608121YZF_0603L37 MBK1608121YZF_0603

1

C439

C439 10U_0805_10V4Z

10U_0805_10V4Z

2

R365 0_0402_5%R365 0_0402_5%

VB_VDD3V VB_DACVDD

GPIOA GPIOB GPIOC GPIOD LCDSENSE/GPIOE INTN/GPIOF GPIOG GPIOH GPIOI GPIOJ GPIOK V2HSYNC/GPIOL V2VSYNC/GPIOM TSCLKI/GPION TVCLKO/GPIOO

EXTSWING LX3P LX3N LX2P LX2N LX1P LX1N LX0P LX0N LXC1P LXC1N LXC2P LXC2N LX4P LX4N LX5P LX5N LX6P LX6N LX7P LX7N

LDDCDATA LDDCCLK VBOSCO VBRCLK PFTEST2 PFTEST1 PFTESTO EXTRSTN

8/28 Change U6 from SIS307LV SA00000O920 to SIS307ELV SA00000O930

VSSF5VSSF6VSSF7VSSF8VSSF9VSSG5VSSG6VSSG7VSSG8VSSG9VSSH5VSSH6VSSH7VSSH8VSS

DDC pull-up

R124 2.2K_0402_5%R124 2.2K_0402_5%

1 2 1 2

R118 2.2K_0402_5%R118 2.2K_0402_5%

4

1 2

+1.8VS

392mA

G10

H13

IVDD

VDD3V

+5VS

3

H12

1

2

H10

H11

IVDD

VSS

H9

J10

C443

0.1U_0402_16V4Z

J4

G4

IVDDH4IVDD

IVDD

PCIEVSS

K10

K12

1

C442

0.01U_0402_16V7K

2

VB_PCIEAVSS

L2

L3

M1

PCIEVDD

PCIEVSS

PCIEVSSM5PCIEVSS

PCIEVSS

M4

M6

VB_PCIEAVDD

VB_LVDSPLLVDD

VB_PLL1VDD

L6

B3

C2

K2

DACVDD

PCIEVDD

PLL1VDD

PCIEAVDD

LVDSPLLVDD

PCIEVSS

PCIEVSSM7PCIEVSS

PCIEVSS

M8

M9

M11

M10

VB_PCIEVDD

K3

J7

J6

K4

J8

L1

PCIEVDDJ5PCIEVDD

PCIEVDD

PCIEVDDJ9PCIEVDD

SiS307ELV

PCIEVSS

PCIEVSSK5PCIEVSSK6PCIEVSSK7PCIEVSSK8PCIEVSSK9PCIEVSS

M2

M3

L11

L10

VB_LAVDD

E9

D10

D11

D12

D13

LAVDDE5LAVDDE6LAVDDE7LAVDDE8LAVDD

LAVDD

LAVSSA3LAVSSB4LAVSSB5LAVSSB6LAVSSB7LAVSSB8LAVSSB9LAVSS

PCIEVSS

N1

M12

M13

R334 0_0603_5%R334 0_0603_5%

B10

LAVSS

B11

B12

LAVSS

B13

PERN5/SVB_Bn PERP5/SVB_Bp PERN4/SVB_Gn PERP4/SVB_Gp PERN3/SVB_Rn PERP3/SVB_Rp

PERN2/SVA_Bn PERP2/SVA_Bp PERN1/SVA_Gn PERP1/SVA_Gp PERN0/SVA_Rn PERP0/SVA_Rp

LVDSPLLVSS

LAVSS

LAVSSD4LAVSSD5LAVSSD6LAVSSD7LAVSSD8LAVSS

REFCLKN

REFCLKP PCIERSET0 PCIERSET1

VACLK VBCLK

VBHSYNC

VBVSYNC

VBHCAD

VBHCLK

V2RSET V2COMP TVDACR TVDACG

TVDACB

TVCSYNC

PCIEAVSS

PLL1VSS DACVSS

DACVSS DACVSS DACVSS DACVSS

SIS307LV-B0_BGA_167P

D9

AGND

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18

3

Compal Secret Data

Deciphered Date

0.1U_0402_16V4Z

N12 N13 N10 N11 N8 N9

N6 N7 N4 N5 N2 N3

L7 L8

VB_PCIERSET0

L4

VB_PCIERSET1

L5 K13

VBCLK_R

J12 K11 J11 L13 L12

V2RSET

B2

V2COMP

B1 D2 D1 E2 E1

VB_PCIEAVSS

L9

VB_LVDSPLLVSS

A2

VB_PLL1VSS

K1 C1

D3 E3 E4 F4

AGND

2009/10/18

2

96mA

VB_LAVDD

1

C430

R132 33_0402_5%R132 33_0402_5%

R345 0_0402_5%R345 0_0402_5% R346 115_0402_1%

R346 115_0402_1%

PADT6PAD

0.1U_0402_16V4Z

2

1

C429

0.1U_0402_16V4Z

2

VB_LVDSPLLVDD

30mA

0.1U_0402_16V4Z

VB_LVDSPLLVSS

HDVBN2_C <7> HDVBP2_C <7> HDVBN1_C <7> HDVBP1_C <7> HDVBN0_C <7> HDVBP0_C <7>

HDVAN2_C <7> HDVAP2_C <7> HDVAN1_C <7> HDVAP1_C <7> HDVAN0_C <7> HDVAP0_C <7>

R370 499_0402_1%R370 499_0402_1%

1 2

R369 124_0402_1%R369 124_0402_1%

1 2

@

307ELV:NC these 4 pins!

T6

V2COMP

VB_DACVDD +3VS

99mA

1

C92

11mA

C93

2

0.01U_0402_16V7K

AGND

VBOSCO

2

1

VB_PLL1VDD

VB_PLL1VSS

Title

Size Document Number Rev

Custom

Date: Sheet

1

C431

0.1U_0402_16V4Z

2

Modify 10U_1206 to 10U_0805

1

C421

307ELV:stuff R345, un-stuff R346 307LV/DV/CP:stuff R346, un-stuff R345

1

C402

0.01U_0402_16V7K

2

0.01U_0402_16V7K

2

Modify 10U_1206 to 10U_0805

PCIE_CLK_307# <14> PCIE_CLK_307 <14>

VACLK <9> VBCLK <9> VBHSYNC <9> VBVSYNC <9> VBCAD <9> VBHCLK <9>

R336 0_0402_5%R336 0_0402_5%

VB_DACVDD

5/20 Change R345 from @ to stuff

C109 0.1U_0402_16V4ZC109 0.1U_0402_16V4Z

1 2

307ELV:change C94 to 0 ohm 307LV/DV/CP:C94=0.1uF

C94 0_0402_5%C94 0_0402_5%

1 2

8/28 Change C94 from 0.1U to 0 Ohm

1

C91

C91 10U_0805_10V4Z

10U_0805_10V4Z

2

4.7U_0805_10V4Z

Y2 14.31818MHZ_16PF_DSX840GA@Y2 14.31818MHZ_16PF_DSX840GA@

1 2

C116

@

27P_0402_50V8J

1

C118

0.1U_0402_16V4Z

2

Compal Electronics, Inc.

LVDS Encoder SiS307LV

KFT00 M/B LA-4821P Schematic

Tuesday, March 10, 2009

C669

R125 10_0402_5%@R125 10_0402_5%@

2

C113

@

27P_0402_50V8J

1

1 2

1

C119

0.01U_0402_16V7K

2

R139 0_0402_5%R139 0_0402_5%

1

MBK1608121YZF_0603

MBK1608121YZF_0603 L35

L35

1 2

1

C427

0.1U_0402_16V4Z

2

L32

1 2

MBK1608121YZF_0603

1 2

Side-Band Signals

AGND

1

C670

C670 10U_0805_10V4Z

10U_0805_10V4Z

2

7/30 change L14 to 1_0603 Add C669 and C670

1 2

L7

MBK1608121YZF_0603

1 2

1

+3VS

1

C428

10U_0805_10V4Z

2

+3VS

1

C399

10U_0805_10V4Z

2

L4

1_0603_5%

VBRCLK_R

+3VS

1

C154

C154 10U_0805_10V4Z

10U_0805_10V4Z

2

of

18 47

1.0

5

D D

C C

ZAD[0..16]<9>

+1.8VS

12

R198

R198 150_0402_1%

150_0402_1%

SZVREF

12

R200

B B

A A

10U_0805_10V4Z

R200

49.9_0402_1%

C541

+1.8VS

1

C194

0.1U_0402_16V4Z

2

1 2

R206 56_0402_5%R206 56_0402_5%

1 2

R204 56_0402_5%R204 56_0402_5%

L67

1 2

MBK1608121YZF_0603

1

0.1U_0402_16V4Z

2

1 2

R446 0_0402_5%R446 0_0402_5%

5

C549

1

2

SZCMP_N

SZCMP_P

AVDD_SZ4X

1

C550

0.01U_0402_16V7K

2

AVSS_SZ4X

16mA

ZAD[0..16]

ZSTB_DP0<9> ZSTB_DN0<9> ZSTB_DP1<9> ZSTB_DN1<9>

ZUREQ<9> ZDREQ<9>

Z_CLK1<14>

4

ZAD0 ZAD1 ZAD2 ZAD3 ZAD4 ZAD5 ZAD6 ZAD7 ZAD8 ZAD9 ZAD10 ZAD11 ZAD12 ZAD13 ZAD14 ZAD15 ZAD16

ZSTB_DP0 ZSTB_DN0 ZSTB_DP1 ZSTB_DN1

ZUREQ ZDREQ

SZCMP_N SZCMP_P

AVDD_SZ4X AVSS_SZ4X

SZVREF

3

U11A

H5

AD31

J4

AD30

J3

AD29

K1

AD28

K2

AD27

J5

AD26

K4

AD25

K3

AD24

L2

AD23

K5

AD22

L4

AD21

L3

AD20

M1

AD19

M2

AD18

L5

AD17

M4

AD16

P3

AD15

R1

AD14

R2

AD13

P5

AD12

R4

AD11

R3

AD10

T1

AD9

T2

AD8

T4

AD7

T3

AD6

U1

AD5

U2

AD4

T5

AD3

U4

AD2

U3

AD1

V1

AD0

Y22

ZAD0

Y25

ZAD1

Y23

ZAD2

W21

ZAD3

Y26

ZAD4

W22

ZAD5

W24

ZAD6

W25

ZAD7

U21

ZAD8

U24

ZAD9

U22

ZAD10

T22

ZAD11

U25

ZAD12

T23

ZAD13

T25

ZAD14

T26

ZAD15

AA26

ZAD16

V22

ZSTB0

V23

ZSTB0#

V25

ZSTB1

V26

ZSTB1#

AA23

ZUREQ

AA24

ZDREQ

AB24

ZCMP_N

AB25

ZCMP_P

AA22

AVDD_Z4X

AB23

AVSS_Z4X

AB26

ZVREF

AC26

ZCLK

AE22

SPI_DI

AD22

SPI_DO

AF21

SPI_CS1N

AE21

SPI_CS0N

SIS968-B0_TEBGA_570P

Security Classification

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

PCI

MuTIOL

SPI

Issued Date

SPI_HARDWARE_TRAP

PREQ4# PREQ3# PREQ2# PREQ1# PREQ0#

PGNT4# PGNT3# PGNT2# PGNT1# PGNT0#

C/BE3# C/BE2# C/BE1# C/BE0#

FRAME#

TRDY# STOP# SERR#

DEVSEL#

PLOCK#

PCICLK

PCIRST#

IDSAA2 IDSAA1 IDSAA0

IDE

IDECSA1# IDECSA0#

IIORA#

IIOWA#

IDACKA#

ICHRDYA

IDREQA

CBLIDA

AVDD_IDE AVSS_IDE

SPI_CLK

2008/10/18

3

INTA# INTB# INTC# INTD#

IRDY#

PAR

IDA0 IDA1 IDA2 IDA3 IDA4 IDA5 IDA6 IDA7 IDA8

IDA9 IDA10 IDA11 IDA12 IDA13 IDA14 IDA15

IIRQA

PCI_REQ#4

H2

PCI_REQ#3

H1

PCI_REQ#2

G3

PCI_REQ#1

G4

PCI_REQ#0

G2

PCI_GNT#4

J2

PCI_GNT#3

J1

PCI_GNT#2

H3

PCI_GNT#1

H4 G5

L1 M3 N5 R5

INT_N_A

F5

PCI_PIRQB#

F4

PCI_PIRQC#

F3

PCI_PIRQD#

G1

PCI_FRAME#

N1

PCI_IRDY#

N2

PCI_TRDY#

M5

PCI_STOP#

N3

PCI_SERR#

P2 P4

PCI_DEVSEL#

N4

PCI_PLOCK#

P1

CLK_PCI_SB

V2

PCI_RST#_R

D5

AE19 AD18 AC17 AF18 AB16 AE17 AD16

IDE_DD7

AF16 AE16 AF17 AC16 AD17 AE18 AB17 AF19 AC18

AD21 AD20 AB20

AC21 AB21

AF20 AD19 AC19

IDE_DIORDY

AE20

IDE_DDREQ

AB18

IDE_IRQ

AB19 AC20

V3

IDEAVSS

V4

AF22 AF23

1 2

R257 4.7K_0402_5%R257 4.7K_0402_5%

SPI_Hardware Trap

0:LPC (Default) 1:SPI

Compal Secret Data

Deciphered Date

PAD

PAD PAD

PAD

INT_N_A <7,9>

CLK_PCI_SB <14>

T28

T28 T29

T29 T27

T27 T26

T26

2

R384 33_0402_5%R384 33_0402_5%

1 2

R831 33_0402_5%R831 33_0402_5%

1 2

2009/10/18

2

1

+3VS

RP44

PCI_REQ#4 PCI_REQ#3 PCI_REQ#2 PCI_REQ#1

PCI_REQ#0 INT_N_A PCI_PIRQB# PCI_PIRQC#

PCI_PIRQD# PCI_FRAME# PCI_IRDY# PCI_TRDY#

PCI_STOP# PCI_SERR# PCI_DEVSEL# PCI_PLOCK#

PCI_RST# <28,29,30,31,33> NB_RST# <9,18>

IDE_DIORDY IDE_IRQ

IDE_DDREQ IDE_IRQ IDE_DD7

R450 4.7K_0402_5%@R450 4.7K_0402_5%@ R434 8.2K_0402_5%R434 8.2K_0402_5%

R441 4.7K_0402_5%@R441 4.7K_0402_5%@ R437 4.7K_0402_5%@R437 4.7K_0402_5%@ R259 5.6K_0402_5%R259 5.6K_0402_5%

1 8 2 7 3 6 4 5

1 2 1 2

1 2 1 2 1 2

RP44

8.2K_1206_8P4R_5%

RP45

8.2K_1206_8P4R_5%

RP46

8.2K_1206_8P4R_5%

RP47

8.2K_1206_8P4R_5%

+3VS

R450 => Intel :Pull-up 4.7K ohm (Mount) SiS : Pull-up ? ohm (Un-Mount) R434 => Intel :Pull-up 8.2K ohm (Mount) SiS :Not Pull-up R441 => Intel :Don't Pull-down SiS : Pull-down ? ohm (Un-Mount) R437 => Intel :Don't Pull-down SiS : Pull-down ? ohm (Un-Mount) R218 => Intel :Don't Pull-down SiS : Pull-down 5.6K ohm (Mount)

1

+1.8VS

1

C521

0.1U_0402_16V4Z

2

of

19 47

1.0

8mA

IDEAVDDIDEAVDD

1

C536

0.1U_0402_16V4Z

Title

Size Document Number Rev

Custom

Date: Sheet

2

IDEAVSS

Compal Electronics, Inc.

SIS968(1/5)-PCI_IDE_MuTIOL

SIS968(1/5)-PCI_IDE_MuTIOL KFT00 M/B LA-4821P Schematic

KFT00 M/B LA-4821P Schematic

Tuesday, March 10, 2009

L66

1 2

MBK1608121YZF_0603

1

C535

0.01U_0402_16V7K

2

1 2

R428 0_0402_5%R428 0_0402_5%

5

C175 15P_0402_50V8JC175 15P_0402_50V8J

X1

3

NC

2

32.768KHZ_12.5P_1TJS125BJ2A251

D D

NC

C172 15P_0402_50V8JC172 15P_0402_50V8J

OUT

4 1

IN

8/07 modified from 12P to 15P

+3VS

R430 4.7K_0402_5%R430 4.7K_0402_5%

1 2

R429 10K_0402_5%R429 10K_0402_5%

1 2

R430 => Intel :Not Pull-up SiS : Pull-up 4.7K ohm (Mount)

R173

LPC_DRQ0# SERIRQ

12

10M_0402_5%

SB_PWRGD<9,31>

LPC_FRAME#<31,33>

SERIRQ<31>

0.1U_0402_16V4Z

LPC_AD0<31,33> LPC_AD1<31,33> LPC_AD2<31,33> LPC_AD3<31,33>

R429 => Intel :Pull-up 10K ohm (Mount) SiS :Not Pull-up

R176

2

3

1

C326

C346

2

10U_0805_10V4Z

HDA_SDIN0<35> HDA_SDIN1<37>

H_INIT#<4> H_A20M#<4> H_SMI#<4> H_INTR<4>

H_NMI<4> H_IGNNE#<4> H_FERR#<4> H_STPCLK#<4> H_CPUSLP#<5>

H_PROCHOT#<4> H_THERMTRIP#<4> AGPBUSY#<9>

REF_CLK1<14>

SB_SPKR<35>

PBTN_OUT#<31>

PCI_PME#<31>

PSON#<31>

C168 0.1U_0402_16V4Z

PM_SLP_S5#<31> PM_SLP_S3#<31>

EC_SMI#<31>

EC_LID_OUT#<31>

EC_SCI#<31>

AGPSTOP#<9> CPUSTP_N_OLD<25> SB_DPRSLPVR<25>

GATEA20<31> KB_RST#<31>

+CHGRTC

1

C333

0.01U_0402_16V7K

2

0.1U_0402_16V4Z

EMI Recommend

HDA_BITCLK_SB

HDA_BITCLK_AUDIO<35> HDA_BITCLK_MDC<37> HDA_SDOUT_AUDIO<35>

C C

HDA_SDOUT_MDC<37> HDA_SYNC_AUDIO<35> HDA_SYNC_MDC<37> HDA_RST_AUDIO#<35> HDA_RST_MDC#<37>

8/29 change net from BAT_PWRGD to net +RTCVCC

SMT1-05_4P

SMT1-05_4P SW1

SW1

A@

1 2

6

+3VALW

B B

+3VS

A A

RP40

10K_1206_8P4R_5%

RP41

10K_1206_8P4R_5%

R381 10K_0402_5%R381 10K_0402_5%

1 2

R397 10K_0402_5%R397 10K_0402_5%

1 2

R393 10K_0402_5%R393 10K_0402_5%

1 2

R390 10K_0402_5%@R390 10K_0402_5%@

1 2

R403 10K_0402_5%@R403 10K_0402_5%@

1 2

R398 10K_0402_5%@R398 10K_0402_5%@

1 2

BATT1

-+

ML1220T13RE

@

1 2

R914 10_0402_5%

1 2

R192 33_0402_5%R192 33_0402_5%

1 2

R194 33_0402_5%R194 33_0402_5%

1 2

R201 33_0402_5%R201 33_0402_5%

1 2

R203 33_0402_5%R203 33_0402_5%

1 2

R197 33_0402_5%R197 33_0402_5%

1 2

R199 33_0402_5%R199 33_0402_5%

1 2

R166 33_0402_5%R166 33_0402_5%

1 2

R167 33_0402_5%R167 33_0402_5%

+RTCVCC

3 4

5

7/30 add for debug

EC_SMI#

45

EC_LID_OUT#

36

EC_SCI#

27

PM_SLP_S5#

18

AGPSTOP#

45

CPUSTP_N_OLD

36

GPIO14

27

PM_SLP_S3#

18

R291

+RTCBATT

12

1 2

511_0603_1%

5

@

1 2

C846 10P_0402_50V8J

HDA_SDOUT_SB

HDA_SYNC_SB

HDA_RST_SB#

CPU IU

1 2

0_0402_5%

AUX_PWRGD<9,31>

Remove R163 R162 R164 R388 R382 R425 R387 R381; Add RP40 RP41 Michael 2008/5/30

GPIO16 GATEA20 KB_RST# EC_THERM#

GATEA20 KB_RST#

D20

+RTC_BATT

D20

1

BAS40-04_SOT23

1U_0603_10V4Z

Decoupling Capacitor

Please close to SB

1

2

C473

12

@

+RTCVCC

C332

4

U11B

OSC32KHO OSC32KHI

BAT_PWRGD SB_PWRGD

1

+RTCVCC

2

LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3

LPC_FRAME# LPC_DRQ0# SERIRQ

HDA_SDIN0 HDA_SDIN1

HDA_SDOUT_SB HDA_SYNC_SB

HDA_RST_SB# HDA_BITCLK_SB

H_INIT# H_A20M# H_SMI# H_INTR H_NMI H_IGNNE# H_FERR# H_STPCLK# H_CPUSLP#

H_PROCHOT# H_THERMTRIP# AGPBUSY#

REF_CLK1 SB_SPKR PBTN_OUT#

PCI_PME# PSON#

PM_SLP_S5# PM_SLP_S3#

EC_SMI# EC_LID_OUT# EC_SCI#

AGPSTOP# CPUSTP_N_OLD SB_DPRSLPVR GPIO14

GPIO16 GATEA20 KB_RST#

Change D19 footprint from RLS4148_LL34-2 to LL34

D19 RLS4148_LL34-2D19 RLS4148_LL34-2

1 2

R279 10K_0402_5%R279 10K_0402_5%

1 2

12

J1

@

JOPEN

10U_0805_10V4Z

4

E2

OSC32KHO

E1

OSC32KHI

F1

BATOK

E4

PWROK

D1

RTCVDD

D2

RTCVSS

Y5

LAD0

AA4

LAD1

AB2

LAD2

AB3

LAD3

AB1

LFRAME#

AB4

LDRQ#

AA5

SIRQ

E5

HDA_SDIN0

C4

HDA_SDIN1

Y3

HDA_SDOUT

Y2

HDA_SYNC

B3

HDA_RESET#

Y1

HDA_BIT_CLK

AC23

INIT#

AE26

A20M#

AD23

SMI#

AC22

INTR

AE25

NMI

AE24

IGNNE#

AF24

FERR#

AF25

STPCLK#

AD24

CPUSLP#

AC24

PROCHOT#

AD25

THERMTRIP#

AE23

BMBUSY#

AA2

OSCI

F2

ENTEST

AA1

SPK

E6

PWRBTN#

A6

PME#

E7

PSON#

C3

AUXOK

A5

ACPILED

C2

GPIO10/SLP_S5#

C7

GPIO15/SLP_S3#

D6

GPIO7/GPWAK#

A4

GPIO8/RING

C6

GPIO9/HDA_SDIN2

F6

GPIO11/STP_PCI#/AGPSTOP#

D4

GPIO12/CPUSTP#/DPSLP#

D3

GPIO13/DPRSLPVR

B5

GPIO14/AGPSTOP#/S3AUXSW#

B7

GPIO16/DPRSTP#

D7

GPIO17/GA20#

B4

GPIO18/KBDRST#

SIS968-B0_TEBGA_570P

@

J2 JOPEN

1 2

BAT_PWRGD

LPCRTC HD Audio ACPI

CPU_S

APIC

GPIO

8/29 change J1,J4 from net BAT_PWRGD to net +RTCVCC

C328

1

2

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

3

AVSS_GMACCMP18

AVDD_GMACCMP18

OSC25MHO

OSC25MHI

GTXCLK EXTCLK

TXCLK

TXEN TXER

TXD0 TXD1 TXD2 TXD3

RGMCMP_N

GMACPCI Express

GPIO1/LDRQ1#/PCIE_HOTPLUG

GPIO14

2008/10/18

3

RGMCMP_P

RGMVREF

RXCLK

RXDV RXER

RXD0 RXD1 RXD2 RXD3

COL CRS MDC

MDIO

GPIO21 GPIO22 GPIO23 GPIO24

PRX0+

PRX0-

PTX0+

PTX0-

PRX1+

PRX1-

PTX1+

PTX1-

NC11 NC10

NC9

NC8

NC7

NC6

NC5

NC4

PCLK100P PCLK100N

AVDD_PEXTRX

AVSS_PEXTRX

RSET0 RSET1

PCIEPRSNT1 PCIEPRSNT0

GPIO0/STPCPU#

GPIO2/THERM# GPIO3/EXTSMI#

GPIO4/CLKRUN#

GPIO5/PREQ5# GPIO6/PGNT5#

GPIO19 GPIO20

R431 0_0402_5%R431 0_0402_5%

1 2

R394 0_0402_5%@R394 0_0402_5%@

1 2

Compal Secret Data

Deciphered Date

2

AVSS_GMACCMP

C8

AVDD_GMACCMP

D9

MOSC25MHO

B8

MOSC25MHI

A8

GTXCLK

A12 F14

B11 C12

C11 D12

A13 B13 C13

A14 B14 C14

A11 C10

E12 A10

C9 B9 A9

E10 E11 E14 E13

D8 F8 E8 A7

M26 M25 N24 N23 K26 K25 L24 L23

F26 F25 G24 G23 H26 H25 J24 J23

P26 P25 R25 R26 P22 P21

R21 R23

U5 AB5 V5 W4 W3 W2 W1

Y4 W5

PADT4PAD

EXTCLK TXCLK TX_EN

TXER TXD_0

TXD_1 TXD_2 TXD_3

RGMCMP_N RGMCMP_P RGMVREF

RXCLK RXDV

RXER RXD0

RXD1 RXD2 RXD3

COL CRS

MDIO GPIO21

GPIO22 GPIO23 GPIO24

PCIE_PTX_C_IRX_P0 PCIE_PTX_C_IRX_N0

PCIE_ITX_PRX_N0 PCIE_PTX_C_IRX_P1 PCIE_PTX_C_IRX_N1 PCIE_ITX_PRX_P1 PCIE_ITX_PRX_N1

PCIE_CLK_SB PCIE_CLK_SB# AVDD_PEXTRX AVSS_PEXTRX

R420 499_0402_1%R420 499_0402_1% R426 124_0402_1%R426 124_0402_1%

PCIEPRSNT1 PCI_PME# PCIEPRSNT0

PROJECT_ID0 GPIO1 GPIO2 CARD_RST#_R PM_CLKRUN# PROJECT_ID1 IDE_HRESET#

SCLK SDATA

T4

PAD

T25

R389 33_0402_5%R389 33_0402_5%

1 2

PAD

R146 33_0402_5%R146 33_0402_5%

1 2

R159 33_0402_5%R159 33_0402_5%

1 2

R158 33_0402_5%R158 33_0402_5%

1 2

R145 33_0402_5%R145 33_0402_5%

1 2

R260 33_0402_5%R260 33_0402_5%

1 2 1 2

TXCLK <28>

T24

R161 56_0402_5%R161 56_0402_5%

1 2

R160 56_0402_5%R160 56_0402_5%

1 2

R147 150_0402_1%R147 150_0402_1%

1 2

RXCLK <28> RXDV <28>

RXER <28> RXD0 <28>

RXD1 <28> RXD2 <28> RXD3 <28>

COL <28> CRS <28>

1 2

MDIO <28>

C515 0.1U_0402_10V7KC515 0.1U_0402_10V7K

1 2

C511 0.1U_0402_10V7KC511 0.1U_0402_10V7K

1 2

C512 0.1U_0402_10V7KC512 0.1U_0402_10V7K

1 2

C506 0.1U_0402_10V7KC506 0.1U_0402_10V7K

1 2

PCIE_CLK_SB <14> PCIE_CLK_SB# <14>

R427 0_0402_5%R427 0_0402_5%

1 2

7/20 modified

CARD_RST#_R <26>

PM_CLKRUN# <31>

SCLK <12,13,14,15> SDATA <12,13,14,15>

GPIO23 GPIO22 GPIO21 GPIO24

150_0402_1%

8mA

AVDD_GMACCMP

0.1U_0402_16V4Z

AVSS_GMACCMP

TXEN <28>

TXD0 <28> TXD1 <28> TXD2 <28> TXD3 <28>

12

R142

MDCH_MDC

U9

4

DO

3

DI

2

SK

1

CS

AT93C46-10SI-2.7_SO8

@

PCIE_ITX_C_PRX_P0PCIE_ITX_PRX_P0 PCIE_ITX_C_PRX_N0

PCIE_ITX_C_PRX_P1 PCIE_ITX_C_PRX_N1

10/26 modified

Remove R433 R435 R438 R439 Add RP42 Michael 2008/5/30

7/20 modified

R187 4.7K_0402_5%R187 4.7K_0402_5%

D14 RB751V_SOD323D14 RB751V_SOD323

2 1

EC_THERM#GPIO2

2009/10/18

12

CP_PE#PCIEPRSNT1

2

+1.8VS

CP_PE# <30>

EC_THERM# <31>

Title

Size Document Number Rev

Custom

KFT00 M/B LA-4821P Schematic

Tuesday, March 10, 2009

Date: Sheet

1

L38

1 2

MBK1608121YZF_0603

1

C457

0.01U_0402_16V7K

2

1 2

R832 0_0402_5%R832 0_0402_5%

Put closed to 968

MOSC25MHO

R151 0_0402_5%

MOSC25MHI

33P_0402_50V8J

the same with "180"

7/30 modified from 27P to 33P

1 2

Y4

25MHZ_20PF_6X25000017

25MHZ_20PF_6X25000017 C152

C152

33P_0402_50V8J

+3VALW

C459

+3VALW +3VALW

1

C120

0.01U_0402_16V7K

2

MDC <28>

5

GND

6

NC

7

NC

8

VCC

1

2

PCI-Express

PCIE_PTX_C_IRX_P0 <29> PCIE_PTX_C_IRX_N0 <29> PCIE_ITX_C_PRX_P0 <29> PCIE_ITX_C_PRX_N0 <29> PCIE_PTX_C_IRX_P1 <30> PCIE_PTX_C_IRX_N1 <30> PCIE_ITX_C_PRX_P1 <30>

30mA

AVDD_PEXTRX

0.1U_0402_16V4Z

AVSS_PEXTRX

GPIO23 PBTN_OUT#

PSON#

GPIO1 PM_CLKRUN#

CARD_RST#_R IDE_HRESET#

GPIO2

SB_DPRSLPVR

PROJECT_ID0

PROJECT_ID1

Compal Electronics, Inc.

SIS968(2/5)-PCIE_LAN_RTC

PCIE_ITX_C_PRX_N1 <30>

L9

L9 MBK1608121YZF_0603

MBK1608121YZF_0603

1

C186

C185

C186

0.01U_0402_16V7K

2

R404 4.7K_0402_5%R404 4.7K_0402_5%

R436 10K_0402_5%@R436 10K_0402_5%@

R915 10K_0402_5%@R915 10K_0402_5%@

1 2

R190 0_0402_5%R190 0_0402_5%

R386 4.7K_0402_5%R386 4.7K_0402_5%

1 2

R833 100K_0402_5%R833 100K_0402_5%

1 2

R385 4.7K_0402_5%R385 4.7K_0402_5%

1 2

R834 100K_0402_5%R834 100K_0402_5%

1 2

R611 1K_0402_5%R611 1K_0402_5% R443 10K_0402_5%@R443 10K_0402_5%@

1 2

R444 10K_0402_5%@R444 10K_0402_5%@

1 2

RP42

10K_1206_8P4R_5%

1 2

1 2 1 2

R424 1K_0402_5%R424 1K_0402_5%

1 2 1 2

R916 1K_0402_5%R916 1K_0402_5%

1

1 2

45 36 27 18

20 47

@

0_0402_5%

1 2

of

+1.8VALW

12

R150

C151

WLAN

NEW Card

+1.8VS

+3VALW

+3VS

1.0

5

4

3

2

1

+1.8VALW

L8

1 2

MBK1608121YZF_0603

0.1U_0402_16V4Z

D D

+3VALW

L43

1 2

MBK1608121YZF_0603

C C

0.1U_0402_16V4Z R168 0_0402_5%R168 0_0402_5%

R392 0_0402_5%R392 0_0402_5%

+1.8VALW

L46

1 2

MBK1608121YZF_0603

R407 0_0402_5%R407 0_0402_5%

+1.8VALW

L44

1 2

MBK1608121YZF_0603

C170

1 2

C489

0.1U_0402_16V4Z

C465

0.1U_0402_16V4Z

1 2

C476

0.1U_0402_16V4Z

1 2

C475

0.1U_0402_16V4Z

1

2

1

2

1

2

1

2

1

2

01/12 Add C865 (0.1uF) for ESD Recommend

B B

A A

+3VALW

R836 4.7K_0402_5%R836 4.7K_0402_5%

1 2

+1.8VS

L23

1 2

MBK1608121YZF_0603

0.1U_0402_16V4Z

1 2

R217 0_0402_5%R217 0_0402_5%

+3VS

L51

1 2

MBK1608121YZF_0603

0.1U_0402_16V4Z

1 2

R440 0_0402_5%R440 0_0402_5%

5

C222

C545

1

2

1

2

1

C215

0.01U_0402_16V7K

2

1

C548

0.01U_0402_16V7K

2

7mA

USBPVDD18

C171

0.01U_0402_16V7K

USBPVSS18

8mA

Place C478,C489 close to

C478

U11 Pin F17,F19,F22

0.01U_0402_16V7K

8mA

USBCMPAVDD33

Place C465,C466

C466

close to U11 Pin D21

0.01U_0402_16V7K

USBCMPAVSS33

9mA

USBCMPAVDD18

C477

0.01U_0402_16V7K

USBCMPAVSS18

284mA

UVDD18

C474

0.01U_0402_16V7K

UVDD18

C865

<EMI>

0.1U_0402_16V4Z

SB_PCIE_WAKE#

6mA

AVDD_SATARX

AVSS_SATARX

41mA

AVDD_SATAPLL33

AVSS_SATAPLL33

U11C

USB20_P0 USB20_N0 USB20_P1 USB20_N1 USB20_P2 USB20_N2 USB20_P3 USB20_N3 USB20_P4 USB20_N4 USB20_P5 USB20_N5 USB20_P6 USB20_N6 USB20_P7 USB20_N7

USB_OC#06 USB_OC#1 USB_OC#2 USB_OC#3 USB_OC#45

USB_OC#6 USB_OC#7

AVDD_SATARX AVSS_SATARX

AVDD_SATAPLL33

AVSS_SATAPLL33

SATA_REXT

SATA_CLK_DP SATA_CLK_DN

SB_PCIE_WAKE# ATRAP TRAP0

1 2

USB20_P0<30> USB20_N0<30> USB20_P1<33> USB20_N1<33> USB20_P2<30> USB20_N2<30> USB20_P3<37> USB20_N3<37> USB20_P4<30> USB20_N4<30> USB20_P5<30> USB20_N5<30> USB20_P6<26> USB20_N6<26> USB20_P7<37> USB20_N7<37>

USB_OC#06<30>

USB_OC#45<30>

SATA_CLK_DP<14> SATA_CLK_DN<14>

SB_PCIE_WAKE#<7,29,30>

USB BT

New Card

FP USB USB

Card Reader

CAMERA

R211 12K_0402_1%R211 12K_0402_1%

1 2

C216 22P_0402_50V8JC216 22P_0402_50V8J

1

+3VALW

2

1 2

R405 1K_0402_5%R405 1K_0402_5%

1 2

R155 1K_0402_5%@R155 1K_0402_5%@

133MHz:Internal pull-down 66MHz:External pull-up

Remove R838 R839 R840 R552 Add RP43 Michael 2008/5/30

+3VALW

4

RP43

45 36 27

1 2

18

Security Classification

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

10K_1206_8P4R_5%

R841 10K_0402_5%R841 10K_0402_5%

USB_OC#2 USB_OC#1 USB_OC#3 USB_OC#7

USB_OC#6

Issued Date

D26

UV0+

D25

UV0-

E24

UV1+

E23

UV1-

A20

UV2+

B20

UV2-

C19

UV3+

D19

UV3-

A18

UV4+

B18

UV4-

C17

UV5+

D17

UV5-

A16

UV6+

B16

UV6-

C15

UV7+

D15

UV7-

A23

OC0#

F21

OC1#

A24

OC2#

B24

OC3#

C23

OC4#

C24

OC5#

A25

OC6#

B23

OC7#

AF14

AVDD_SATARX

AF15

AVSS_SATARX

AC9

AVDD_SATAPLL33

AD9

AVDD_SATAPLL33

AC8

AVSS_SATAPLL33

AD8

AVSS_SATAPLL33

AF7

REXT

AE15

CLK100P

AD15

CLK100N

E9

PCIEWAKE

D10

ATRAP

E22

TRAP0

SIS968-B0_TEBGA_570P

2008/10/18

3

AVDD_USBCMP18 AVSS_USBCMP18

AVDD_USBCMP33 AVSS_USBCMP33

USB

SATA

Compal Secret Data

OSC12MHI

OSC12MHO

USBREF

AVDD_USBPLL18 AVSS_USBPLL18

UVDD33 UVDD33 UVDD33

UVDD18 UVDD18 UVDD18 UVDD18 UVDD18 UVDD18 UVDD18 UVDD18 UVDD18 UVDD18

STX0+

STX0-

SRX0+

SRX0STX1+

STX1-

SRX1+

SRX1-

XOUT

HDACT

ISWITCHOPEN1 ISWITCHOPEN0

IPB_OUT0 IPB_OUT1

Deciphered Date

XIN

USB_CLK_12M

A22 B22

USBREF

F20

USBPVDD18

B26

USBPVSS18

B25

USBCMPAVDD18

E21

USBCMPAVSS18

E20

USBCMPAVDD33

D21

USBCMPAVSS33

C21

USBCMPAVDD33

F17 F19 F22

UVDD18

J15 H15 H16 H17 H18 J19 F16 F15 E18 E16

SATA_ITX_DRX_P0

AC13

SATA_ITX_DRX_N0

AD13

SATA_DTX_C_IRX_P0

AF12

SATA_DTX_C_IRX_N0

AE12

SATA_ITX_DRX_P1

AC6

SATA_ITX_DRX_N1

AD6 AF5 AE5

SOSC25MHI

AE8 AF8

H_SATA_LED#

AA3

ISWITCHOPEN1

AC1

ISWITCHOPEN0

AD1

D22 C22

USB_CLK_12M <14>

R402 127_0402_1%R402 127_0402_1%

1 2

C560 0.01U_0402_16V7KC560 0.01U_0402_16V7K

1 2

C559 0.01U_0402_16V7KC559 0.01U_0402_16V7K

1 2

SATA_DTX_C_IRX_P0 <24> SATA_DTX_C_IRX_N0 <24>

C791 0.01U_0402_16V7KC791 0.01U_0402_16V7K

1 2

C792 0.01U_0402_16V7KC792 0.01U_0402_16V7K

SATA_DTX_C_IRX_P1 SATA_DTX_C_IRX_N1

2009/10/18

1 2

SATA_DTX_C_IRX_P1 <24> SATA_DTX_C_IRX_N1 <24>

1 2

R219 0_0402_5%R219 0_0402_5%

R207 1K_0402_5%R207 1K_0402_5%

1 2

R209 1K_0402_5%R209 1K_0402_5%

1 2

12

R205

@

10K_0402_5%

H_SATA_LED# SATA_LED#

R837 0_0402_5%R837 0_0402_5%

Title

Size Document Number Rev

Custom

Date: Sheet

2

Date: Sheet

SATA_ITX_C_DRX_P0 SATA_ITX_C_DRX_N0

SATA_ITX_C_DRX_P1 SATA_ITX_C_DRX_N1

+5VS+3VS

C663 0.1U_0402_16V4Z@C663 0.1U_0402_16V4Z@ R576 10K_0402_5%@R576 10K_0402_5%@

1

5

U39

P

4

OE#

A2Y

G

TC7SET125FUF_SC70@

3

1 2

Compal Electronics, Inc.

SIS968(3/5)-USB_SATA

KFT00 M/B LA-4821P Schematic

Tuesday, March 10, 2009

1 2 1 2

SATA_ITX_C_DRX_P0 <24> SATA_ITX_C_DRX_N0 <24>

SATA_ITX_C_DRX_P1 <24> SATA_ITX_C_DRX_N1 <24>

SATA_LED# <37>

of

21 47

1

1.0

5

D D

U11D

+1.05VS

22mA

+3VS

29mA

C C

+3VALW

4mA

+3VALW

8mA

+1.8VS

153mA

B B

U11D

AA21

VTT

AB22

VTT

V16

PVDD

V15

PVDD

V14

PVDD

T8

PVDD

N8

PVDD

L9

PVDD

W17

OVDD

W16

OVDD

W15

OVDD

W14

OVDD

W13

OVDD

W12

OVDD

K8

OVDD

L8

OVDD

M8

OVDD

P8

OVDD

R8

OVDD

U8

OVDD

V8

OVDD

H19

OVDD_AUX

H9

OVDD_AUX

H8

OVDD_AUX

F7

OVDD_AUX

J11

OVDD_AUX

J12

OVDD_AUX

H10

GMIIVDD_AUX

H11

GMIIVDD_AUX

H12

GMIIVDD_AUX

H13

GMIIVDD_AUX

J13

GMIIVDD_AUX

K18

AVDDPEX

L18

AVDDPEX

L19

AVDDPEX

M18

AVDDPEX

M19

AVDDPEX

N19

AVDDPEX

H21

AVDDPEX

J21

AVDDPEX

K21

AVDDPEX

L21

AVDDPEX

M21

AVDDPEX

N21

AVDDPEX

M22

AVDDPEX

H22

AVDDPEX

SIS968-B0_TEBGA_570P

Power

IVDD_AUX IVDD_AUX IVDD_AUX IVDD_AUX IVDD_AUX IVDD_AUX

AVDD_SATA AVDD_SATA AVDD_SATA AVDD_SATA AVDD_SATA AVDD_SATA AVDD_SATA AVDD_SATA AVDD_SATA AVDD_SATA AVDD_SATA AVDD_SATA AVDD_SATA AVDD_SATA AVDD_SATA

IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD IVDD

VDDZ VDDZ VDDZ VDDZ VDDZ VDDZ VDDZ VDDZ VDDZ VDDZ VDDZ VDDZ VDDZ VDDZ

4

T18 J14 U9 T9 R9 P9 N9 M9 K9 V10 V11 V12 V13 V17 R17 R18

N18 W19 V19 V18 U18 W18 P18 Y24 V24 T24 R24 AA25 W26 U26

J9 J8 J10 J16 J17 J18

W11 W10 W9 W8 V9 AF10 AE10 AD11 AD10 AC11 AC10 AB11 AB10 AB9 AB8

413mA

19mA

+1.8VS

190mA

+1.8VS

+1.8VALW

C537

0.1U_0402_16V4Z

3

+3VS

C502

0.1U_0402_16V4Z

C514

0.1U_0402_16V4Z

C533

0.01U_0402_16V7K

C504

0.01U_0402_16V7K

1

2

+1.8VS

1

2

+1.8VS

1

2

+1.8VS

1

2

1

C507

2

0.1U_0402_16V4Z

1

C525

2

0.1U_0402_16V4Z

C557,C555,C217,C228,C551,C554 close to U30 Pin AVDD_SATA

1

C555

2

0.1U_0402_16V4Z

C504,C509,C494,C495,C513,C503 close to U30 Pin AVDDPEX

1

C509

2

0.1U_0402_16V4Z

Put under 968 solder side

+1.8VS

0.1U_0402_16V4Z

1

2

0.1U_0402_16V4Z

1

C530

2

0.1U_0402_16V4Z

C520

1

2

0.1U_0402_16V4Z

C517

0.1U_0402_16V4Z

1

C522

2

0.1U_0402_16V4Z

1

C526

2

0.1U_0402_16V4Z

1U_0603_10V4Z

1

C217

2

1U_0603_10V4Z

1

C494

2

1

C794

2

0.1U_0402_16V4Z

1

C534

2

0.1U_0402_16V4Z

1

C527

2

1

C228

2

10U_0805_10V4Z

1

C495

2

10U_0805_10V4Z

1

0.1U_0402_16V4Z

2

1U_0603_10V4Z

1

C542

2

1U_0603_10V4Z

1

C539

2

0.1U_0402_16V4Z

+3VS

1

C531

2

1

C538

2

1U_0603_10V4Z

10U_0805_10V4Z

1

C540

2

1U_0603_10V4Z

+1.8VALW

1

C497

0.1U_0402_16V4Z

2

+3VALW

1

C501

2

1

C519

2

0.1U_0402_16V4Z

10U_0805_10V4Z

1

C543

2

1

C524

2

1

C500

2

0.1U_0402_16V4Z

1

C516

2

1

C556

2

10U_0805_10V4Z

1

C523

2

10U_0805_10V4Z

1

C488

C488 1U_0603_10V4Z

1U_0603_10V4Z

2

1U_0603_10V4Z

1

C148

2

1

C532

2

0.1U_0402_16V4Z

+1.05VS

1

C547

0.1U_0402_16V4Z

2

1

C510

2

1U_0603_10V4Z

+1.05VS

1

2

C546

0.1U_0402_16V4Z

1

C793

C793 1U_0603_10V4Z

1U_0603_10V4Z

2

+3VALW

1

C493

0.1U_0402_16V4Z

2

A A

5

4

1

C499

0.1U_0402_16V4Z

2

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

+3VALW

1

C482

0.1U_0402_16V4Z

2

2008/10/18

3

1

C486

0.1U_0402_16V4Z

2

+1.8VALW

1

C492

0.1U_0402_16V4Z

2

Compal Secret Data

Deciphered Date

1

C498

0.1U_0402_16V4Z

2

2009/10/18

+1.8VS +1.8VS

1

C513

0.1U_0402_16V4Z

2

1

C503

0.01U_0402_16V7K

2

Title

Size Document Number Rev

Custom

KFT00 M/B LA-4821P Schematic

Tuesday, February 10, 2009

Date: Sheet

1

C551

0.1U_0402_16V4Z

2

Compal Electronics, Inc.

SIS968(4/5)-POWER

1

C544

0.01U_0402_16V7K

2

1

22 47

1.0

of

5

D D

C C

B B

4

U11E

K10

VSS

K11

VSS

K12

VSS

L10

VSS

L11

VSS

L12

VSS

L14

VSS

L15

VSS

L16

VSS

M10

VSS

M11

VSS

M12

VSS

M13

VSS

Gound

M14 M15

N10 AD26 AC25

B10

B12

D11

D13

U15

U14

U13

U12

U11

U10

T14

T13

T12

T11

T10

R14

R13

R12

R11

R10

P14

P13

P12

P11

P10

N14

N13

N12

N11

P24

P23

N22

N26

N25

M24 M23

K22

G22

K24

K23

H24

H23

G26 G25

E26

E25

P16

M17

N17

P17

M16

N16

N15

L22 J22 L26

L25

J26 J25

F24 F23

Gound

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX AVSSPEX

3

VSSZ VSSZ VSSZ VSSZ VSSZ VSSZ VSSZ VSSZ VSSZ VSSZ VSSZ VSSZ VSSZ VSSZ

USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS USBVSS

AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA AVSS_SATA

U17 U16 T16 R16 R15 T17 P15 T15 Y21 V21 T21 R22 W23 U23

D14 E15 A15 B15 C16 D16 A17 B17 E17 C18 D18 A19 B19 E19 C20 D20 A21 B21 D23 D24 C25 C26 K13 K14 K15 K16 K17 L13 L17

AB6 AB7 AB12 AB13 AB14 AB15 AC2 AC3 AC4 AC5 AC7 AC12 AC14 AC15 AD2 AD3 AD4 AD5 AD7 AD12 AD14 AE1 AE2 AE3 AE4 AE6 AE7 AE9 AE11 AE13 AE14 AF2 AF3 AF4 AF6 AF9 AF11 AF13

2

1

SIS968-B0_TEBGA_570P

A A

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18

3

Compal Secret Data

Deciphered Date

2009/10/18

2

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

Compal Electronics, Inc.

SIS968(5/5)-GND

KFT00 M/B LA-4821P Schematic

Tuesday, March 10, 2009

1

23 47

of

1.0

A

B

C

D

E

F

G

H

SATA ODD Conn.

+5VS

0.1U_0402_16V4Z

C369

1

2

1000P_0402_50V7K

SATA_DTX_C_IRX_N1<21>

SATA_DTX_C_IRX_P1<21>

1

2

1 1

2 2

1

C370

SATA_DTX_C_IRX_N1

SATA_DTX_C_IRX_P1

C371

2

10U_0805_10V4Z

SATA_ITX_C_DRX_P1<21> SATA_ITX_C_DRX_N1<21>

1 2

C372 0.01U_0402_16V7KC372 0.01U_0402_16V7K

1 2

C373 0.01U_0402_16V7KC373 0.01U_0402_16V7K

SATA_DTX_IRX_N1

SATA_DTX_IRX_P1

SATA_ITX_C_DRX_P1 SATA_ITX_C_DRX_N1

SATA_DTX_IRX_N1 SATA_DTX_IRX_P1

R373 1K_0402_1%@R373 1K_0402_1%@

1 2

+5VS

Follow JAT10 Smybol

JSATA2

1

GND

2

A+

3

A-

4

GND

5

B-

6

B+

7

GND

8

DP

9

+5V

10

+5V

11

MD

12

GND GND13GND

OCTEK_SLS-13DC1G

CONN@

GND

15 14

SATA HDD Conn.

12/29 SATA trace routing for layout (Length)

SATA_ITX_C_DRX_P0<21>

SATA_ITX_C_DRX_N0<21>

SATA_DTX_C_IRX_N0<21>

SATA_DTX_C_IRX_P0<21>

+5VS

0.1U_0402_16V4Z

1

C366

2

1000P_0402_50V7K

1

C365

2

SATA_ITX_C_DRX_P0

R932 0_0402_5%R932 0_0402_5%

SATA_ITX_C_DRX_N0

R934 0_0402_5%R934 0_0402_5%

SATA_DTX_C_IRX_N0

R936 0_0402_5%R936 0_0402_5%

SATA_DTX_C_IRX_P0

R939 0_0402_5%R939 0_0402_5%

SATA_DTX_C_IRX_N0_R1 SATA_DTX_C_IRX_P0_R1

10U_0805_10V4Z

1

C367

2

1U_0603_10V4Z

1 2

C400 0.01U_0402_16V7KC400 0.01U_0402_16V7K C395 0.01U_0402_16V7KC395 0.01U_0402_16V7K

1

C353

2

10U_0805_10V4Z

1 2 1 2

1

2

C354

R941 0_0402_5%@R941 0_0402_5%@

1 2

SATA_ITX_C_DRX_P0_R2

R931 0_0402_5%@R931 0_0402_5%@

1 2

SATA_ITX_C_DRX_N0_R2

R930 0_0402_5%@R930 0_0402_5%@

1 2

SATA_DTX_C_IRX_N0_R2

R938 0_0402_5%@R938 0_0402_5%@

1 2

SATA_DTX_C_IRX_P0_R2

SATA_ITX_C_DRX_P0_R1 SATA_ITX_C_DRX_N0_R1

SATA_DTX_IRX_N0 SATA_DTX_IRX_P0

+3VS

1

C68

0.1U_0402_16V4Z

2

@

+5VS

+3VS

SATA_ITX_C_DRX_P0_R1

R933 0_0402_5%R933 0_0402_5%

1 2

SATA_ITX_C_DRX_N0_R1

R935 0_0402_5%R935 0_0402_5%

1 2

SATA_DTX_C_IRX_N0_R1

R937 0_0402_5%R937 0_0402_5%

1 2

SATA_DTX_C_IRX_P0_R1

R940 0_0402_5%R940 0_0402_5%

1 2

Follow JFT00 Smybol

JSATA1

1

GND

2

A+

3

A-

4

GND

5

B-

6

B+

7

GND

8

V33

9

V33

10

V33

11

GND

12

GND

13

GND

14

V5

15

V5

16

V5

17

GND

18

Reserved

19

GND

20

V12

21

V12

22

V12

SUYIN_127043FR022G204ZL_NR

CONN@

3 3

Re and Rf close to Rd

SATA_ITX_C_DRX_P0 SATA_ITX_C_DRX_P0_R1

Rd

Re Rf

4 4

SATA_ITX_C_DRX_P0_R2

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

A

B

C

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

D

2008/10/18 2009/10/18

E

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

F

Date: Sheet

Compal Electronics, Inc.

HDD & ODD Connector

KFT00 M/B LA-4821P Schematic

G

1.0

24 47Tuesday, March 10, 2009

H

1.0

of

5

+3VS

C496 0.1U_0402_16V4ZC496 0.1U_0402_16V4Z

5

U32

R401 33_0402_5%R401 33_0402_5%

D D

SB_DPRSLPVR<20>

1 2

0.01U_0402_16V7K

C464

1

@

2

4

Vcc

A2Y

1

NC

G

NL17SZ17DFT2G_SOT353-5

3

4

1 2

R414 33_0402_5%R414 33_0402_5%

1 2

Connecte to CPU

PM_DPRSLPVR_D <46> SB_DPRSLPVR<20>

3

R391 33_0402_5%R391 33_0402_5%

1 2

C460

@

0.01U_0402_16V7K

@

2

+3VS

C448 0.1U_0402_16V4ZC448 0.1U_0402_16V4Z

1 2

5NC1

U24

P

A2Y

G

NL17SZ14DFT2G_SOT353-5

1

2

NL17SZ14DFT2G_SOT353-5

3

R842 33_0402_5%R842 33_0402_5%

4

1 2

1

DPRSTP_N_INV

Use SA00001N400 FootPrint

R553 0_0402_5%@R553 0_0402_5%@

1 2

8/1 Rotate

R170

1.05K_0402_1%

+3VS

R171

R172

@

200K_0402_5%

8/1 Rotate

+1.05VS

12

R157

300_0402_5%

12

R165

300_0402_5%

7/20 Reserved

C C

DPRSTP_N_INV

H_DPSLP_N_LS

U40

1

A1

2

GND

3

A2

NC7WZ07P6X_NL_SC70-6

VCC

Y1

5

+3VALW

H_DPSLP#

4

Y2

DPRSTP_N_INV

H_DPSLP_N_LS

C173

0.01U_0402_16V7K

1

@

2

H_DPRSTP#

6

8

U10

EN

7

VREF2

6

SCL2

5

SDA2

2

VREF1

3

SCL1

4

SDA1

GND

PCA9306DCUR_VSSOP8

1

@

H_DPRSTP# <5,46> H_DPSLP# <5>

+3VS +3VS

C450 0.1U_0402_16V4ZC450 0.1U_0402_16V4Z

1 2

B B

CPUSTP_N_OLD<20>

A A

5

R372 499_0402_1%R372 499_0402_1%

1 2

R380 33_0402_5%R380 33_0402_5%

C447

100P_0402_50V8J

1

2

4

1

C451

@

0.01U_0402_16V7K

2

5

Vcc

A2Y

NC

G

U23

NL17SZ17DFT2G_SOT353-5

3

Security Classification

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

C458 0.1U_0402_16V4ZC458 0.1U_0402_16V4Z

1 2

Use SA00001N400 FootPrint

4 1

5

4

Vcc

A2Y

1

NC

G

U31

NL17SZ17DFT2G_SOT353-5

3

Use SA00001N400 FootPrint

Issued Date

1 2

R371 33_0402_5%R371 33_0402_5%

1 2

R379 33_0402_5%R379 33_0402_5%

2008/10/18

3

Compal Secret Data

Deciphered Date

+3VS

5

2

P

B

1

A

G

3

+3VS

5

U22

2

B

Vcc

1

A

G

NC7SZ32P5X_NL_SC70-5

3

1 2

C446 0.1U_0402_16V4ZC446 0.1U_0402_16V4Z

U33

H_DPSLP_N_LS

4

Y

NC7SZ08P5X_NL_SC70-5

1 2

C452 0.1U_0402_16V4ZC452 0.1U_0402_16V4Z

CPUSTP#

4

Y

2009/10/18

2

CPUSTP# <14>

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet of

Date: Sheet

Compal Electronics, Inc.

Other

KFT00 M/B LA-4821P Schematic

Tuesday, March 10, 2009

1

25 47

of

1.0

5

4

3

2

1

SD,MMC,MS muti-function pin define

MMC Card PIN Name

JREAD1

6

VDD_SD

9

DAT0_SD

10

DAT1_SD

2

DAT2_SD

3

CD/DAT3_SD

7

CLK_SD

11

WP_SD

4

CMD_SD

1

CD_SD

5

VSS_SD

8

VSS_SD

19

VCC_MS

13

VCC_MS

14

SCLK_MS

16

INS_MS

18

SDIO_MS

20

BS_MS

15

RESERVED_MS

17

RESERVED_MS

21

VSS_MS

12

VSS_MS

22

GND

23

GND

PROCO_MDR019-C0-1202

CONN@

1

MS Card PIN Name

MSWR MSBS MSCDAT1 MSCDAT0 MSCDAT2 MS_INS# MSCDAT3 MSCCLK MSCDAT6 MSCDAT7

26 47Tuesday, March 10, 2009

1.0

of

8 7 6 5

+VCC_3IN1

MDIO PIN Name

SP1 SP2 SP3 SP4 SP5 SP6 SP7 SP8 SP9 SP10

SP12 SP13 SP14 SP15 SP16 SP17 SP18 SP19

U42

VCC NC NC GND

AT93C46-10SI-2.7_SO8

@

SDDAT0_MSD0 XDD4_SDDAT1 SDDAT2_XDRE# SDDAT3_XDWE# SD_CLK SD_WP SD_CMD SD_CD#

SP6 MS_CLK

MS_INS# SDDAT0_MSD0 MS_BS SDDAT6_MSD3 SDDAT7_MSD2

Realtek Recommend

Change BOM control C796 R843 for 5158 and 5158E co-layout Michael 2008/6/18

D D

+3VS_CR_VCC

1

C799

C799 1U_0603_10V4Z

1U_0603_10V4Z

2

0.1U_0402_16V4Z

+3VS_CR_VCC

R846

C C

B B

R846

100K_0402_5%

1U_0603_10V4Z

CLK_48M_CR<14>

+3VALW

C804

0.1U_0402_16V4Z

1

C800

2

R844 0_0603_5%R844 0_0603_5%

1 2

@

1 2

R845 0_0603_5%

4.7U_0805_10V4Z

12

1 2

0_0603_5%

12

R850

@ R850

@

499K_0402_1%

R899

1 2

0_0402_5%

R849

C801

C802

CARD_RST#

C803

1

0.1U_0402_16V4Z

2

CARD_XTLI

12MHZ_16P_6X12000012

270K_0402_5%

1

C806

@

6P_0402_50V8J

2

CARD_RST#_R<20>

Y5

1 2

R854

@

+3VS

AV_PLL

@

CARD_XTLO

C807

@

6P_0402_50V8J

2

C797

C797 1U_0603_10V4Z

1U_0603_10V4Z

1

USB20_N6<21> USB20_P6<21>

6.19K_0402_1%

1

2

+VCC_OUT

1 2

R875

0_0402_5%@

R900

12

2

1

+3V3_IN CARD_RST# MODE_SEL CARD_XTLO CARD_XTLI

USB20_N6 USB20_P6

C798

0.1U_0402_16V4Z

11 33

44 45 47 48

14

12 32

46

12

R855

R855 0_0402_5%

0_0402_5%

1 3 7 9

8

4 5

2

6

C796

@

47P_0402_50V8J

U41

@

AV_PLL NC NC CARD_3V3 D3V3 D3V3

3V3_IN RST# MODE_SEL XTLO XTLI

DM DP GPIO0

RREF DGND

DGND AGND

AGND

RTS5158E-GR_LQFP48_7X7

5158E@

U41

S IC RTS5159-GR LQFP 48P CARD READER

5159@

+VCC_OUT

MODE_SEL

12

1

R843

5159@

0_0402_5%

2

XD_CLE_SP19 XD_CE#_SP18 XD_ALE_SP17

SD_DAT2/XD_RE#_SP16

SD_DAT3/XD_WE#_SP15

SD_DAT4/XD_WP#/MS_D7_SP13

SD_DAT5/XD_D0/MS_D6_SP12 SD_CLK/XD_D1/MS_CLK_SP11 SD_DAT6/XD_D7/MS_D3_SP10

SD_DAT7/XD_D2/MS_D2_SP8 SD_DAT0/XD_D6/MS_D0_SP7 SD_DAT1/XD_D3/MS_D1_SP6

XD_RDY_SP14

XD_D4/SD_DAT1_SP4

R856

1 2

0_0603_5%

4.7U_0805_10V4Z

MS_INS#_SP9

XD_D5_SP5

SD_CD#_SP3

SD_WP_SP2

XD_CD#_SP1

XTAL_CTR

C839

VREG

MS_D4

EEDI

MS_D5

EEDO EECS EESK

SD_CMD

NC

10 22 30

43 42 41 40 39 38 37 35 34 31 29 28 27 26 25 23 21 20 19 18

13 24

15 16 17 36

+VCC_3IN1

C808

10U_0805_10V4Z

MS_CLK SD_CLK

12

R857

@

C812

1 2

@

1

@

2

10_0402_5%

10P_0402_50V8J

AV_PLL

SDDAT2_XDRE# SDDAT3_XDWE#

SDCLK_MSCLK SDDAT6_MSD3 MS_INS# SDDAT7_MSD2 SDDAT0_MSD0 SP6 MS_BS XDD4_SDDAT1 SD_CD# SD_WP

CARD_EEDI

R851 0_0402_5%R851 0_0402_5%

CARD_EEDO CARD_EECS CARD_EESK SD_CMD

40mil

@

1

C809

2

0.1U_0402_16V4Z

1

2

10_0402_5%

10P_0402_50V8J

R847 0_0402_5%R847 0_0402_5%

1 2

R848 0_0402_5%R848 0_0402_5%

1 2

+3VS_CR_VCC

12

R858

@

1

C813

@

2

SD_CLK MS_CLK

0.1U_0402_16V4Z

+3VS_CR_VCC

1

C805

@

2

CS

SK

DI

DO

SD Card PIN Name

SDWP# SDCD# SDCDAT1

SDCDAT0 SDCDAT7

SDCDAT6 SDCCLKSP11 SDCDAT5 SDCDAT4

SDCDAT3 SDCDAT2

CARD_EECS

1

CARD_EESK

2

CARD_EEDO

3

CARD_EEDI

4

W=40mils

A A

CR_ON#<31>

R913 100K_0402_5%

5

C844

0.1U_0402_16V4Z

@

1 2

@

G

2

S

Q56

Q56 SI2301BDS_SOT23

SI2301BDS_SOT23

@

D

1 3

1

C845

@

1U_0603_10V4Z

2

W=40mils

12

R912

R912 0_0805_5%

0_0805_5%

+3VS_CR_VCC

4

Add C822 4.7u and reserve C808 10u for cost down Michael 2008/5/30

Security Classification

2008/10/18 2009/10/18

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18 2009/10/18

3

Compal Secret Data

Deciphered Date

2

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

Compal Electronics, Inc.

RTS5158E Cardreader

KFT00 M/B LA-4821P Schematic

5

D D

C C

4

3

2

1

B B

A A

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

3

2008/10/18 2009/10/18

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

2

Date: Sheet

Compal Electronics, Inc.

None

KFT00 M/B LA-4821P Schematic

27 47Tuesday, February 10, 2009

1

1.0

of

5

4

3

2

1

+3VALW

T1

TPRX+ TPRX-

PWFBOUT

R33 0_0603_5%R33 0_0603_5%

1

C56

0.1U_0402_16V4Z

R30 0_0603_5%R30 0_0603_5%

2

change T1 from SP050001310(Lankcom)

1

C50

to SP050004L00(TAIMAG)

0.1U_0402_16V4Z

2

Other CG use 1206

PWFBOUT

1

C95

10U_0805_10V4Z

2

Place C464, C465, L48 close to PWFBOUT and place C466 close to PWFBIN.

LED2

D3 RLS4148_LL34-2D3 RLS4148_LL34-2

LED3

D4 RLS4148_LL34-2D4 RLS4148_LL34-2

D34

1

PSOT24C_SOT23

@

12

C31 680P_0402_50V7KC31 680P_0402_50V7K

R12 150_0402_1%R12 150_0402_1%

1 2

R906 75_0402_5%R906 75_0402_5% R907 75_0402_5%R907 75_0402_5%

8/1 Change R12 from 300ohm to 150ohm

R908 75_0402_5%R908 75_0402_5% R575 75_0402_5%R575 75_0402_5%

For EMI => Change C31,C38 from SE071680J80 (68pF) to SE074681K80 (680pF)

L61

1 2 12

R34 75_0402_5%R34 75_0402_5%

1 2

R29 75_0402_5%R29 75_0402_5%

1 2

D33

1

PSOT24C_SOT23

@

12

+3V_LAN

1

2

RTSET ISOLATE

RPTR SPEED DUPLEX ANE LDPS RESETB

+3V_LAN

FBM-L11-160808-601LMT_0603

1

C147

C149

C147

0.1U_0402_16V4Z

2

+3V_LAN

1

C122

0.1U_0402_16V4Z

2

+3V_LAN_AVDD

PWFBOUT PWFBIN

TPRXTPRX+

TPTXTPTX+

R351 2K_0402_1%R351 2K_0402_1%

1 2

R361 4.7K_0402_5%R361 4.7K_0402_5%

1 2

R356 4.7K_0402_5%R356 4.7K_0402_5%

1 2

R353 4.7K_0402_5%R353 4.7K_0402_5%

1 2

R123 4.7K_0402_5%R123 4.7K_0402_5%

1 2

R116 4.7K_0402_5%R116 4.7K_0402_5%

1 2

R357 4.7K_0402_5%R357 4.7K_0402_5%

1 2

R363 0_0402_5%R363 0_0402_5%

1 2

R359 0_0402_5%@R359 0_0402_5%@

1 2

L6

1 2

LED0 LINKLED#

R149

Other CG use 1210

+3V_LAN

D D

R350 1.5K_0402_1%R350 1.5K_0402_1%

1 2

R366 4.7K_0402_5%@R366 4.7K_0402_5%@

1 2

R152 4.7K_0402_5%@R152 4.7K_0402_5%@

1 2

R368 4.7K_0402_5%R368 4.7K_0402_5%

1 2

R367 4.7K_0402_5%R367 4.7K_0402_5%

1 2

R153 4.7K_0402_5%R153 4.7K_0402_5%

1 2

R154 4.7K_0402_5%R154 4.7K_0402_5%

1 2

R364 4.7K_0402_5%R364 4.7K_0402_5%

1 2

R97 4.7K_0402_5%R97 4.7K_0402_5%

1 2

R354 4.7K_0402_5%R354 4.7K_0402_5%

1 2

C C

MDC<20> MDIO<20> TXD0<20> TXD1<20> TXD2<20> TXD3<20>

TXEN<20> TXCLK<20> RXDV<20> RXD0<20> RXD1<20> RXD2<20> RXD3<20> RXCLK<20> COL<20> CRS<20> RXER<20>

+3V_LAN

B B

1 2

25MHZ_20PF_6X25000017

C115

C115 33P_0402_50V8J

33P_0402_50V8J

MDC MDIO TXD0 TXD1 TXD2 TXD3 TXEN

R156 33_0402_5%R156 33_0402_5%

1 2

R109 33_0402_5%R109 33_0402_5%

1 2

R117 33_0402_5%R117 33_0402_5%

1 2

R122 33_0402_5%R122 33_0402_5%

1 2

R129 33_0402_5%R129 33_0402_5%

1 2

R135 33_0402_5%R135 33_0402_5%

1 2

R138 33_0402_5%R138 33_0402_5%

1 2

R903 33_0402_5%R903 33_0402_5%

1 2

R904 33_0402_5%R904 33_0402_5%

1 2

R905 33_0402_5%R905 33_0402_5%

1 2

R360 4.7K_0402_5%R360 4.7K_0402_5%

1 2

Y3

C117

C117 33P_0402_50V8J

33P_0402_50V8J

MDIO

ISOLATE

COL LED0 LED1 LED2 LED3 LED4 RXER CRS

LAN_XTAL_IN LAN_XTAL_OUT

LED0 LED1 LED2 LED3 LED4

TXC RXD_V RXD_0 RXD_1 RXD_2 RXD_3 RXC COL_R CRS_R RXER_R

MII_SNIB

R149 0_0603_5%

0_0603_5%

1

C150

C150 10U_0805_10V4Z

10U_0805_10V4Z

2

U8

25

MDC

26

MDIO

6

TXD0

5

TXD1

4

TXD2

3

TXD3

2

TXEN

7

TXC

22

RXDV

21

RXD0

20

RXD1

19

RXD2

18

RXD3

16

RXC

1

COL

23

CRS

24

RXER/FXEN

44

MII/SNIB

46

X1

47

X2

9

PHYAD0/LED0

10

PHYAD1/LED1

12

PHYAD2/LED2

13

PHYAD3/LED3

15

PHYAD4/LED4

RTL8201CL-VD-LF

+3V_LAN

MII I/F

CLK

PHY/LED

Other CG use

4.7U_0805_10V4Z

Place L47, C460, C462, C463 as close to each power pin as possible.

C121

0.1U_0402_16V4Z

C121

14

DVDD33

48

DVDD33

36

AVDD33

32

PWFBOUT

8

PWFBIN

PWRGND

30

TPRX-

31

TPRX+

33

TPTX-

34

TPTX+

28

RTSET

43

ISOLATE

40

RPTR

39

SPEED

38

DUPLEX

37

ANE

41

LDPS

42

RESETB

Network I/F

DGND DGND DGND

AGND AGND

27

NC

11 17 45 29 35

7/30 modified from 27P to 33P

TPRX-

R23 49.9_0402_1%R23 49.9_0402_1%

TPRX+

TPTX-

A A

TPTX+

1 2

R26 49.9_0402_1%R26 49.9_0402_1%

1 2

R36 49.9_0402_1%R36 49.9_0402_1%

1 2

R41 49.9_0402_1%R41 49.9_0402_1%

1 2

C41

1 2

C60

1 2

0.1U_0402_16V4Z

+3V_LAN_AVDD

1

C102

0.1U_0402_16V4Z

2

+3V_LAN

12

R362

4.7K_0402_5%

1

C435

0.1U_0402_16V4Z

2

+3V_LAN

PCI_RST# <19,29,30,31,33>

8/30 Add L61 FBMA-L10-160808-800LMT_0603 for EMI

R14 300_0402_5%R14 300_0402_5%

1 2

C38 680P_0402_50V7KC38 680P_0402_50V7K

FBMA-L10-160808-800LMT_0603

RXCT TXCT

RCT

TCT TPTX+ TPTX-

7/20 Swap pin 1,2 to 7,8 and 16,15 to 10,9

L5

FBM-L11-160808-601LMT_0603

1

C101

0.1U_0402_16V4Z

2

8/27 Change D7,D8 footprint from RLS4148_LL34-2 to LL34

8/1 Change D7,D8 from SC1B751V010 to SC11N414880

2 3

1 2 1 2

2

+3V_LAN

3

1

RD+

2

RD-

3

CT

4

NC

5

NC

6

CT

7

TD+ TD-8TX-

350uH_NS0013LF

12

PWFBIN

1

2

Lan Conn.

EMI Recommend

JLAN1

12 11

8

C42

1 2

C26

7 6 5 4 3 2 1

10

9

FOX_JM36113-L2R8-7F

CONN@

RX-

RX+ TXTX+

1000P_1206_2KV7K

0.1U_0402_16V4Z

RX+

RX-

CT NC NC

CT

TX+

C153

0.1U_0402_16V4Z

Follow JFT00 Smybol

Yellow LEDYellow LED+ PR4PR4+ PR2PR3PR3+ PR2+ PR1PR1+ Green LEDGreen LED+

1

2

16 15 14 13 12 11 10 9

GND GND

1

C27

4.7U_0805_10V4Z

2

RX+ RXRXCT

TXCT TX+ TX-

ACTIVITY LED

14 13

LINKLED

LANGND

LED0 LED1 LED2 LED3 LED4 Link Dupx 10Act 100Act COL

5

Security Classification

2008/10/18 2009/10/18

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18 2009/10/18

3

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

2

Date: Sheet

Compal Electronics, Inc.

LAN RTL8201CL

KFT00 M/B LA-4821P Schematic

28 47Tuesday, March 10, 2009

1

1.0

of

A

1 1

2 2

B

C

D

E

Mini-Express Card for WLAN

SB_PCIE_WAKE#<7,21,30>

C206

WLAN_ACTIVE BT_ACTIVE

WLAN_CLKREQ#<14>

PCIE_CLK_WLAN#<14> PCIE_CLK_WLAN<14>

EC_TX_P80_DATA<12,13,31>

PCIE_PTX_C_IRX_N0<20> PCIE_PTX_C_IRX_P0<20>

PCIE_ITX_C_PRX_N0<20> PCIE_ITX_C_PRX_P0<20>

EC_RX_P80_CLK<12,13,31>

1

0.1U_0402_16V4Z

2

A

WLAN_ACTIVE<33> BT_ACTIVE<33>

3 3

4 4

0.01U_0402_16V7K

R877 0_0402_5%R877 0_0402_5% R876 0_0402_5%R876 0_0402_5%

1

C205

4.7U_0805_10V4Z

2

1 2 1 2

WLAN_CLKREQ# PCIE_CLK_WLAN#

PCIE_CLK_WLAN EC_TX_P80_DATA

MINI_VCC

EC_RX_P80_CLK

+3VS +1.5VS

1

C199

2

Follow JFT00 Smybol

***

JMINW1

1

3

5

7

9

11

13

15

17

19

21

23

25

27

29

31

33

35

37

39

41

43

45

47

49

51

53

GND1

GND2

FOX_AS0B226-S40N-7F

CONN@

1

C241

0.01U_0402_16V7K

0.1U_0402_16V4Z

2

+1.5VS +3VS

2

4

6

8

10

12

14

16

18

20

22

24

26

28

30

32

34

36

38

40

42

44

46

48

50

52

54

For Arcadyan Broadcom 4312

MINI_RF_OFF# PCI_RST# MINI_VCC

DCLK DDATA

WLAN_LED#

1 2

R223

100K_0402_5%

@

MINI_VCCSB_PCIE_WAKE#

PCI_RST# <19,28,30,31,33>

DCLK <14,30> DDATA <14,30>

WLAN_LED# <37>

+3VS

PK292008Y10 and Arcadyan Ralink WN7612A PK29200BN00 WLAN pull +3VS

1

C207

4.7U_0805_10V4Z

2

B

C203

1

Security Classification

2

Security Classification

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

L68

1 2

KC FBM-L11-201209-221LMAT_0805

Issued Date

C

+3VS

12

R462

10K_0402_5%

13

D

S

RF_ON#

2

G

Deciphered Date

RF_ON# <31>

D

Q45

SSM3K7002FU_SC70-3

2008/10/18 2009/10/18

Q45

Compal Secret Data

Please place these caps between JMIN1 and JMIN2

DCLK

C757 100P_0402_50V8J@C757 100P_0402_50V8J@

DDATAMINI_RF_OFF#

Title

Size Document Number Rev

Date: Sheet

1 2

C758 100P_0402_50V8J@C758 100P_0402_50V8J@

1 2

Compal Electronics, Inc.

Mini-Card/Kill SW

KFT00 M/B LA-4821P Schematic

E

1.0

of

29 47Tuesday, March 10, 2009

of

29 47Tuesday, March 10, 2009

of

29 47Tuesday, March 10, 2009

A

B

C

D

E

New Card Socket (Left/TOP)

USB20_N2<21> USB20_P2<21>

DCLK<14,29>

DDATA<14,29>

+1.5VS_CARD1

+3VALW_CARD1 +3VS_CARD1

CP_PE#<20>

USB20_N2 USB20_P2

CP_USB#

DCLK DDATA

SB_PCIE_WAKE#

PERST1#

EXP_CLKREQ# CP_PE# PCIE_CLK_EXP# PCIE_CLK_EXP

PCIE_PTX_C_IRX_N1 PCIE_PTX_C_IRX_P1

PCIE_ITX_C_PRX_N1 PCIE_ITX_C_PRX_P1

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26

27 28

JAQ60

JEXP1

GND USB_DUSB_D+ CPUSB# RSV RSV SMB_CLK SMB_DATA +1.5V +1.5V WAKE# +3.3VAUX PERST# +3.3V +3.3V CLKREQ# CPPE# REFCLKREFCLK+ GND PERn0 PERp0 GND PETn0 PETp0 GND

GND1

GND3

GND2

GND4

SANTA_130810-1

CONN@

29 30

C695

0.1U_0402_16V4Z

C697

0.1U_0402_16V4Z

C699

0.1U_0402_16V4Z

+3VS_CARD1

1

2

+1.5VS_CARD1

1

2

+3VALW_CARD1

1

2

1

C696

@

4.7U_0805_10V4Z

2

1

C698

@

4.7U_0805_10V4Z

2

1

C700

@

4.7U_0805_10V4Z

2

SB_PCIE_WAKE#<7,21,29>

EXP_CLKREQ#<14> PCIE_CLK_EXP#<14>

PCIE_CLK_EXP<14>

PCIE_PTX_C_IRX_N1<20> PCIE_PTX_C_IRX_P1<20>

PCIE_ITX_C_PRX_N1<20> PCIE_ITX_C_PRX_P1<20>

New Card Power Switch

New Card

+3VS

0.1U_0402_16V4Z

PCI_RST# SYSON SUSP# CP_PE# CP_USB#

+1.5VS

C694

0.1U_0402_16V4Z

1 1

+3VALW

12

C689

0.1U_0402_16V4Z

12

C693

PCI_RST#<19,28,29,31,33> SYSON<31,39> SUSP#<31,39,42,44,45>

R635 100K_0402_5%R635 100K_0402_5% R636 100K_0402_5%R636 100K_0402_5%

12

12 12

internal pull high to 3.3Vaux-in EC need setting at Hi-Z & output Low

U18

12

1.5Vin

14

1.5Vin

2

3.3Vin

4

3.3Vin AUX_IN17AUX_OUT

6

SYSRST#

20

SHDN#

1

STBY#

10

CPPE#

9

CPUSB#

18

RCLKEN

R5538D001-TR-F_QFN20_4X4~D

1.5Vout

3.3Vout

PERST#

OC#

GND

+3VALW_CARD1

PERST1#

40 mils

+1.5VS_CARD1

+3VS_CARD1

60 mils

40 mils

11 13

3 5

15 19 8 16

NC

7

Change to GMT PartNumber

Update FootPrint from

2 2

SANTA_13181060-5_26P-T to SANTA_130810-1_26P

USB Connector

L69

@<EMI>L69

+USB_VCCA

1

+

2

C564

@

150U_D_6.3VM

W=80mils

1

C563

C563 470P_0402_50V7K

470P_0402_50V7K

2

1

C768

C768 10U_0805_10V4Z

10U_0805_10V4Z

2

+USB_VCCB

1

+

2

+USB_VCCB+USB_VCCA

C832

@

150U_D_6.3VM

W=80mils

1

C830

C830 470P_0402_50V7K

470P_0402_50V7K

2

1

C831

C831 10U_0805_10V4Z

10U_0805_10V4Z

2

1

4

USB20_N0<21> USB20_P0<21>

USB20_N0 USB20_P0

R878 0_0402_5%<EMI>R878 0_0402_5%<EMI> R879 0_0402_5%<EMI>R879 0_0402_5%<EMI>

Change SA005280110 SOP8

+5VALW +3VALW

3 3

U26

1

GND

2

IN

3

IN

1

C566

4.7U_0805_10V4Z

4 4

4.7U_0805_10V4Z

2

USB2_ON#<31>

+5VALW +3VALW

1

C833

2

USB2_ON#<31>

4

EN#

G528P1UF_SOP8

Close to JUSB1

copy LM75CIMMX-3_MSOP8 footprint

U44

1

GND

2

IN

3

IN

4

EN#

G545A2P8U MSOP 8P

Close to JUSB2

11/29 change this symbol's footprint as ADT7421ARMZ-REEL_MSOP8

A

OUT OUT OUT

OUT OUT

FLG

NC

OC

+USB_VCCA

8 7 6 5

+USB_VCCB

8 7 6 5

R468

R468 10K_0402_5%

10K_0402_5%

1 2

R691

0_0402_5%

1

C568

@

0.1U_0402_16V4Z

2

R884

R884 10K_0402_5%

10K_0402_5%

1 2

1

C834

@

0.1U_0402_16V4Z

2

4

1

USB20_N4<21>

+USB_VCCB

1

2

USB20_P4<21>

USB20_N5<21> USB20_P5<21>

C860

<EMI>

0.1U_0603_25V7K

12

USB_OC#06 <21>

USB_OC#45 <21>

B

USB20_N4 USB20_P4

USB20_N5

01/06 Add C860 for ESD Recommend

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

C

R880 0_0402_5%<EMI>R880 0_0402_5%<EMI> R881 0_0402_5%<EMI>R881 0_0402_5%<EMI>

R882 0_0402_5%<EMI>R882 0_0402_5%<EMI> R883 0_0402_5%<EMI>R883 0_0402_5%<EMI>

4

1

@<EMI>

1

4

WCM2012F2SF-121T04_0805

1 2 1 2

WCM2012F2SF-121T04_0805

4

1

L70

<EMI>

1 2 1 2

WCM2012F2SF-121T04_0805

4

1

L71

<EMI>

2008/10/18 2009/10/18

2

3

2

@

3

2

@

2

3

USB20_R_N0 USB20_R_P0

3

2

USB20_R_N4 USB20_R_P4

USB20_R_N5 USB20_R_P5USB20_P5

3

2

Compal Secret Data

Update New Symbol

+USB_VCCA

+USB_VCCB

Deciphered Date

JUSB1

1

VCC

2

D-

3

D+

4

GND

5

GND1

6

GND2

7

GND3

8

GND4

SUYIN_020173MR004S558ZL

CONN@

JUSB2

1 2 3 4 5 6 789

10

SUYIN_020122MR008S535ZA

CONN@

D

D74

@<EMI>D74

USB20_R_P0 USB20_R_N0

+USB_VCCA

+USB_VCCB

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

Compal Electronics, Inc.

NewCard & USB Connector

KFT00 M/B LA-4821P Schematic

@<EMI>

3

I/O

4

VCC

PJLCR05 SOT143

D75

@<EMI>D75

@<EMI>

3

I/O

4

VCC

PJLCR05 SOT143

D76

@<EMI>D76

@<EMI>

3

I/O

4

VCC

PJLCR05 SOT143

GND

2

I/O

1

USB20_R_P4USB20_R_N4

2

I/O

1

USB20_R_P5USB20_R_N5

2

I/O

1

30 47Tuesday, March 10, 2009

of

E

of

1.0

5

L29 FBM-11-160808-601-T_0603L29 FBM-11-160808-601-T_0603

+3VALW +EC_AVCC

1 2

0.1U_0402_16V4Z

1 2

L27 FBM-11-160808-601-T_0603L27 FBM-11-160808-601-T_0603

C355

2

1

ECAGND

1

C363

C363 1000P_0402_50V7K

1000P_0402_50V7K

2

+3VALW +EC_DVCC

C417

0.1U_0402_16V4Z

C417

0.1U_0402_16V4Z

C396

0.1U_0402_16V4Z

C396

0.1U_0402_16V4Z

1

2

20 mils

D D

+3VALW

22P_0402_50V8J@

R331

EC_SMB_CK1 EC_SMB_DA1

KB_RST#

C426

1 2

47K_0402_5%

0.1U_0402_16V4Z

R347 10K_0402_5%R347 10K_0402_5%

1 2

R349 0_0402_5%R349 0_0402_5%

KB_RST#<20>

CLK_PCI_EC<14>

+3VALW

PCI_PME#<20>

+5VALW

C C

1 2

R317 4.7K_0402_5%R317 4.7K_0402_5%

1 2

R310 4.7K_0402_5%R310 4.7K_0402_5%

1 2

R342 0_0402_5%R342 0_0402_5% D22

2 1

RB751V_SOD323

@

12

R340 10_0402_5%

C391

12

@D22

@

12

1

PM_CLKRUN#<20>

2

EC_PME#

GATEA20<20>

SERIRQ<20> LPC_FRAME#<20,33> LPC_AD3<20,33> LPC_AD2<20,33> LPC_AD1<20,33> LPC_AD0<20,33>

PCI_RST#<19,28,29,30,33> EC_SCI#<20>

ISP MODE SUPPORT

@

1 2 1 2

@

EC_TX_P80_DATA EC_RX_P80_CLK

12

EC_SMB_CK2 EC_SMB_DA2

100P_0402_50V8J

FRD#SPI_SO

FSEL#SPICS#

SUSP#

SPI_CLK_R SPI_SI

R327 4.7K_0402_5%

+3VS

1 2

R309 2.2K_0402_5%R309 2.2K_0402_5%

1 2

R308 2.2K_0402_5%R308 2.2K_0402_5%

EC Recommend

+3VALW

R887 4.7K_0402_5%R887 4.7K_0402_5%

B B

R888 4.7K_0402_5%R888 4.7K_0402_5%

+3VALW

1 2

R325 100K_0402_1%

1 2

R335 100K_0402_1%

1 2

C413 100P_0402_50V8J@C413 100P_0402_50V8J@

SPI_CS#<33> SPI_CLK_R<33> SPI_SI<33>

A A

EC DEBUG PORT

+3VALW

KSO3

1

@

2

ESB_CLK ESB_DAT

1 2 1 2 1 2

JDB3

1

2

3

4

ACES_85205-0400

DBCONN@

1

C358

@

100P_0402_50V8J

2

C357

ESB_CLK_R<34> ESB_DAT_R<34>

R341 0_0402_5%R341 0_0402_5% R332 0_0402_5%R332 0_0402_5% R326 0_0402_5%R326 0_0402_5%

5

KSO[0..15]<32> KSI[0..7]<32>

01/06 Change L55,L56 from 0ohm to 300ohm bead for EMI Recommend

ESB_CLK_R ESB_DAT_R

FSEL#SPICS#SPI_CS# SPI_CLK FWR#SPI_SI

12P_0402_50V8J

Modify X2 part number from SJ132P7KW10 to SJ132P7K220 for cost down; Michael 2008/5/30

KSO[0..15] KSI[0..7]

02/10 Change L55,L56 from 300ohm bead to 33ohm for LED random turn off issue

EC_SMB_CK1<41> EC_SMB_DA1<41> EC_SMB_CK2<4> EC_SMB_DA2<4>

PM_SLP_S3#<20> PM_SLP_S5#<20> EC_SMI#<20>

USB2_ON#<30> FAN_SPEED1<4>

EC_TX_P80_DATA<12,13,29> EC_RX_P80_CLK<12,13,29> ON/OFF#<34> SCROLL_LED#<34> NUM_LED#<34>

C820

33_0402_5%

L55

<EMI>L55

<EMI>

1 2

L56

<EMI>L56

<EMI>

1 2

33_0402_5%

XCLKI XCLKO

4

L28

1 2

FBM-11-160808-601-T_0603

C386

0.1U_0402_16V4Z

C386

0.1U_0402_16V4Z

C406

0.1U_0402_16V4Z

C406

0.1U_0402_16V4Z

GATEA20 SERIRQ

LPC_FRAME# LPC_AD3 LPC_AD2 LPC_AD1 LPC_AD0

CLK_PCI_EC PCI_RST# EC_RST# EC_SCI#

@

1 2

R329 0_0402_5%

EC_SMB_CK1 EC_SMB_DA1 EC_SMB_CK2 EC_SMB_DA2

PM_SLP_S5# EC_SMI#

USB2_ON# FAN_SPEED1

EC_TX_P80_DATA EC_RX_P80_CLK ON/OFF# SCROLL_LED# NUM_LED#

XCLKI XCLKO

4

1

IN

OUT

NC3NC

X2

2

32.768KHZ_12.5P_1TJS125BJ2A251

1

2

KSI0 KSI1 KSI2 KSI3 KSI4 KSI5 KSI6 KSI7 KSO0 KSO1 KSO2 KSO3 KSO4 KSO5 KSO6 KSO7 KSO8 KSO9 KSO10 KSO11 KSO12 KSO13 KSO14 KSO15

ESB_CLK ESB_DAT

4

1

2

C821

C821 12P_0402_50V8J

12P_0402_50V8J

20 mils

C815

1000P_0402_50V7K

C815

1000P_0402_50V7K

10 12

13 37 20 38

55 56 57 58 59 60 61 62 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 81 82

77 78 79 80

14 15 16 17 18 19 25 28 29 30 31 32 34 36

122 123

C359

1000P_0402_50V7K

C359

1000P_0402_50V7K

1

2

U21

1

GA20/GPIO00

2

KBRST#/GPIO01

3

SERIRQ#

4

LFRAME#

5

LAD3

7

LAD2

8

LAD1

LPC & MISC

LAD0 PCICLK

PCIRST#/GPIO05 ECRST# SCI#/GPIO0E CLKRUN#/GPIO1D

KSI0/GPIO30 KSI1/GPIO31 KSI2/GPIO32 KSI3/GPIO33 KSI4/GPIO34 KSI5/GPIO35 KSI6/GPIO36 KSI7/GPIO37 KSO0/GPIO20 KSO1/GPIO21 KSO2/GPIO22 KSO3/GPIO23 KSO4/GPIO24 KSO5/GPIO25 KSO6/GPIO26 KSO7/GPIO27 KSO8/GPIO28 KSO9/GPIO29 KSO10/GPIO2A KSO11/GPIO2B KSO12/GPIO2C KSO13/GPIO2D KSO14/GPIO2E KSO15/GPIO2F KSO16/GPIO48 KSO17/GPIO49

SCL1/GPIO44 SDA1/GPIO45 SCL2/GPIO46 SDA2/GPIO47

6

PM_SLP_S3#/GPIO04 PM_SLP_S5#/GPIO07 EC_SMI#/GPIO08 LID_SW#/GPIO0A SUSP#/GPIO0B PBTN_OUT#/GPIO0C EC_PME#/GPIO0D EC_THERM#/GPIO11 FAN_SPEED1/FANFB1/GPIO14 FANFB2/GPIO15 EC_TX/GPIO16 EC_RX/GPIO17 ON_OFF/GPIO18 PWR_LED#/GPIO19 NUMLED#/GPIO1A

XCLK1 XCLK0

KB926QFA1 LQFP 128P

KB926 D3

Int. K/B

Int. K/B Matrix

Matrix

SM Bus

+EC_AVCC

9

22

33

96

111

125

VCC

INVT_PWM/PWM1/GPIO0F

ACOFF/FANPWM2/GPIO13

PWM Output

AD Input

DA Output

PS2 Interface

TP_DATA/PSDAT3/GPIO4F

SPI Device Interface

SPI Flash ROM

BATT_CHGI_LED#/GPIO52

GPIO

BATT_LOW_LED#/GPIO54

GPO

GPIO

GPI

GND

11

24

35

94

113

3

20 mils

67

AVCC

BEEP#/PWM2/GPIO10

FANPWM1/GPIO12

BATT_TEMP/AD0/GPIO38

BATT_OVP/AD1/GPIO39

ADP_I/AD2/GPIO3A

AD3/GPIO3B

AD4/GPIO42

SELIO2#/AD5/GPIO43

DAC_BRIG/DA0/GPIO3C EN_DFAN1/DA1/GPIO3D

IREF/DA2/GPIO3E

DA3/GPIO3F

PSCLK1/GPIO4A PSDAT1/GPIO4B PSCLK2/GPIO4C PSDAT2/GPIO4D

TP_CLK/PSCLK3/GPIO4E

SDICS#/GPXOA00 SDICLK/GPXOA01

SDIDO/GPXOA02

SDIDI/GPXID0

SPIDI/RD#

SPIDO/WR#

SPICLK/GPIO58

SPICS#

CIR_RX/GPIO40

CIR_RLC_TX/GPIO41

FSTCHG/SELIO#/GPIO50

CAPS_LED#/GPIO53 SUSP_LED#/GPIO55

SYSON/GPIO56

VR_ON/XCLK32K/GPIO57

AC_IN/GPIO59

EC_RSMRST#/GPXO03 EC_LID_OUT#/GPXO04

EC_ON/GPXO05

EC_SWI#/GPXO06

ICH_PWROK/GPXO06

BKOFF#/GPXO08

WL_OFF#/GPXO09

GPXO10 GPXO11

PM_SLP_S4#/GPXID1

ENBKL/GPXID2

GPXID3 GPXID4 GPXID5 GPXID6 GPXID7

V18R

AGND

69

ECAGND

0.1U_0402_16V4Z

21 23 26 27

63 64 65 66 75 76

68 70 71 72

83 84 85 86 87 88

97 98 99 109

119 120 126 128

73 74 89 90 91 92 93 95 121 127

100 101 102 103 104 105 106 107 108

110 112 114 115 116 117 118

124

C356

INVT_PWM BEEP#

ACOFF

BATT_TEMP BATT_OVP ADP_I

MB_ID

DAC_BRIG EN_FAN1 IREF CHGVADJ

TP_CLK TP_DATA

FP_ON#

R320 10K_0402_5%@R320 10K_0402_5%@

1 2

MUTE_LED# CAM_ON# LID_SW#

FRD#SPI_SO FWR#SPI_SI SPI_CLK FSEL#SPICS#

S3AUXSW# PSON# FSTCHG CHARGE_LED0# CAPS_LED# CHARGE_LED1# PWR_LED# SYSON VR_ON ACIN

AUX_PWRGDPM_SLP_S3# EC_LID_OUT# EC_ON CR_ON# SB_PWRGD BKOFF# RF_ON# BT_ON#

ENBKL_Q EAPD EC_THERM# SUSP# PBTN_OUT# EC_PME#

2

C518

4.7U_0805_10V4Z

1

+3VALW

12

R312

RA@

Ra

100K_0402_5%

MB_ID PCI_RST#

1

2

12

R311

12_A@

Rb

0_0402_5%

INVT_PWM <16> BEEP# <35>

ACOFF <42>

1 2

C816 0.01U_0402_16V7KC816 0.01U_0402_16V7K

BATT_OVP <42> ADP_I <42>

DAC_BRIG <16> EN_FAN1 <4> IREF <42> CHGVADJ <42>

TP_CLK <33> TP_DATA <33>

FP_ON# <37> MUTE_LED# <35>

CAM_ON# <37> LID_SW# <34>

FRD#SPI_SO <33>

S3AUXSW# <8> PSON# <20> FSTCHG <42> CHARGE_LED0# <37>

T31

PAD

CHARGE_LED1# <37> PWR_LED# <37> SYSON <30,39> VR_ON <46> ACIN <40>

AUX_PWRGD <9,20> EC_LID_OUT# <20> EC_ON <34> CR_ON# <26> SB_PWRGD <9,20> BKOFF# <16> RF_ON# <29> BT_ON# <33>

EAPD <35,36> EC_THERM# <20> SUSP# <30,39,42,44,45> PBTN_OUT# <20>

1

C835

@

0.1U_0402_16V4Z

2

ENE Recommend

2

ECAGND

02/10 Change C720 from mount (33pF) to @ for LED random turn off issue

No stuff when use KB926C0 KB926 SPI STRAP PIN

@

Level Shift Circuit

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18

3

Compal Secret Data

Deciphered Date

2009/10/18

2

1

TP_CLK TP_DATA

KSO1 KSO2

R316 4.7K_0402_5%R316 4.7K_0402_5%

1 2

R315 4.7K_0402_5%R315 4.7K_0402_5%

1 2

R256 100K_0402_5%R256 100K_0402_5%

1 2

R885 47K_0402_5%R885 47K_0402_5%

1 2

R886 47K_0402_5%R886 47K_0402_5%

1 2

ENE Recommend

BATT_TEMP <41>

ESB_CLK_R ESB_DAT_R

AUX_PWRGD BEEP# SYSON EC_SCI# EC_THERM# SERIRQ

SB_PWRGD PBTN_OUT# EN_FAN1

C719

@

22P_0402_50V8J

<EMI>

01/06 Change C720 from @ to mount (33pF) for EMI Recommend

1

2

100P_0402_50V8J

C401

C419

C416

01/08 Add U46 (SC300001100) for ESD recommend

U46

ON/OFF# EC_ON

+3VALW

+3VS

+3VALW

ENBKL<18>

U46

6

D1-

5

VCC

4

D2+

IP4223CZ6_SO6

@<EMI>

R909 15K_0402_5%R909 15K_0402_5%

1 2

R869 10K_0402_5%R869 10K_0402_5%

1 2

R546

1 2

47K_0402_5%

Title

Size Document Number Rev

Custom

KFT00 M/B LA-4821P Schematic

Tuesday, March 10, 2009

Date: Sheet

3

D2-

2

GND

USB2_ON#

1

D1+

ACIN

C389 100P_0402_50V8JC389 100P_0402_50V8J

VR_ON ENBKL_Q

C

Q39

2

B

MMBT3904_SOT23

E

3 1

Compal Electronics, Inc.

EC_KB926

1 2

C819 100P_0402_50V8JC819 100P_0402_50V8J

1 2

C374 100P_0402_50V8JC374 100P_0402_50V8J

1 2

2

B

1

2

@

1

2

100P_0402_50V8J

C418

C360

1

2

100P_0402_50V8J

C415

C361

ENBKL_Q

C

Q40

Q40 MMBT3904_SOT23

MMBT3904_SOT23

E

3 1

31 47

+5VS

+3VALW

C720

C720 33P_0402_50V8J

33P_0402_50V8J

<EMI>

1

2

100P_0402_50V8J

C840

1

2

100P_0402_50V8J

C818

of

1.0

5

4

3

2

1

INT_KBD Conn.

JKB1

D D

KSI5 KSI4 KSO9 KSI6 KSI7 KSI1

C C

KSO15 KSO10 KSO11 KSO14 KSO13 KSO12 KSO3 KSO6 KSO8 KSO7 KSO4 KSO2 KSI0 KSO1 KSO5 KSI3 KSI2 KSO0

JKB1

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

GND1

26

GND2

ACES_85201-24051

CONN@

Follow JFT00 Smybol

KSI[0..7] KSO[0..15]

KSI[0..7] <31> KSO[0..15] <31>

Delete C525~C548 SE071101J80 (100pF) Add SI102101K80 (CP : 100pF) (EMI Recommend)

CP1

<EMI>CP1

KSI4 KSI5 KSO0 KSI2

KSI1 KSI7 KSI6 KSO9

KSO2 KSO4 KSO7 KSO8

<EMI>

81

2

7

3

6

4 5

100P_1206_8P4C_50V8

100P_1206_8P4C_50V8 CP2

<EMI>CP2

<EMI>

81

2

7

3

6

4 5

100P_1206_8P4C_50V8

100P_1206_8P4C_50V8 CP3

<EMI>CP3

<EMI>

81

2

7

3

6

4 5

100P_1206_8P4C_50V8

KSO6 KSO3 KSO12 KSO13

KSI3 KSO5 KSO1 KSI0

KSO14 KSO11 KSO10 KSO15

CP4

<EMI>CP4

<EMI>

2 3 4 5

81 7 6

100P_1206_8P4C_50V8

CP5

<EMI>CP5

<EMI>

2 3 4 5

100P_1206_8P4C_50V8

100P_1206_8P4C_50V8 CP6

<EMI>CP6

<EMI>

2 3 4 5

100P_1206_8P4C_50V8

81 7 6

B B

A A

Security Classification

2008/10/18 2009/10/18

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18 2009/10/18

3

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

2

Date: Sheet

Compal Electronics, Inc.

KB /SW Conn.

KFT00 M/B LA-4821P Schematic

32 47Tuesday, March 10, 2009

1

1.0

of

C836

0.1U_0402_16V4Z

SPI_CS#<31> SPI_CLK_R<31> SPI_SI<31>

Bluetooth Conn.

8M SPI ROM

For EC+BIOS

+3VALW

20mils

1

2

SPI_CS# SPI_CLK_R SPI_SI SPI_SO

U45

8

VCC

3

W

7

HOLD

1

S

6

C

5

D

SST25LF080A_SO8-200mil

SA000012E00

VSS

4

2

Q

R889 0_0402_5%R889 0_0402_5%

12

FRD#SPI_SO <31>

To TP/B Conn.

Follow JFT00 Smybol

JTP1

ACES_87151-06051

CONN@

1

C837

@

100P_0402_50V8J

2

8

G2

7

G1

6

5

4

3

2

1

TP_DATA TP_CLK

1

C838

@

100P_0402_50V8J

2

TP_DATA TP_CLK

+5VS

TP_DATA TP_CLK

+5VS

TP_DATA <31>

TP_CLK <31>

3

1

C552

0.1U_0402_16V4Z

2

D77

@

PSOT24C_SOT23-3

BT_LED#<37>

BT_ON#<31>

+5VS

12

R529

10K_0402_5%

BT_LED# USB20_P1

13

D

Q18

SSM3K7002FU_SC70-3

Q18

S

C553

0.1U_0402_16V4Z

1 2

R531 100K_0402_5%R531 100K_0402_5%

2

G

12

R530

R530 10K_0402_5%

10K_0402_5%

4.7U_0805_10V4Z

USB20_P1<21> USB20_N1<21> BT_ACTIVE<29>

WLAN_ACTIVE<29>

+3VALW

G

2

1 3

1

C557

@

2

S

Q19

Q19 SI2301BDS_SOT23

SI2301BDS_SOT23

D

W=40mils

USB20_N1 BT_ACTIVE WLAN_ACTIVE BTON_LED

1

C554

C554 1U_0603_10V4Z

1U_0603_10V4Z

2

C558

0.1U_0402_16V4Z

L39

1

4

WCM2012F2SF-121T04_0805

WCM2012F2SF-121T04_0805 R638 0_0402_5%<EMI>R638 0_0402_5%<EMI>

R639 0_0402_5%<EMI>R639 0_0402_5%<EMI>

+BT_VCC

@<EMI>L39

@<EMI>

1 2 1 2

2

3

USB20_R_P1 USB20_R_N1

Follow JFT00 Smybol Update Footprint

+BT_VCC

JBT1

8

10

8

GND

7

6

5

4

3

2

1

9

1

GND

CONN@

ACES_87213-0800G

FOR LPC DEBUG PORT

+3VS

JDB1

1

2

3

4

5

6

7

8

9

10

11

GND

12

GND

ACES_85201-1005N

DBCONN@

CLK_PCI_DB LPC_AD0

LPC_AD1 LPC_AD2 LPC_AD3 LPC_FRAME#

PCI_RST#

1

C576

@

2

0.1U_0402_16V7K

CLK_PCI_DB <14>

LPC_AD0 <20,31> LPC_AD1 <20,31> LPC_AD2 <20,31> LPC_AD3 <20,31>

LPC_FRAME# <20,31> PCI_RST# <19,28,29,30,31>

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18 2009/10/18

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

Compal Electronics, Inc.

BIOS, I/O Port & K/B Connector

KFT00 M/B LA-4821P Schematic

33 47Tuesday, March 10, 2009

of

1.0

ON/OFF switch

A

B

C

D

E

+3VALW

R533

1 1

2 2

SMT1-05_4P

SMT1-05_4P SW3

SW3

1 2

3 4

5

6

Power Button

ON/OFFBTN#

EC_ON<31>

DAN202UT106_SC70-3

EC_ON

R535

10K_0402_5%

1

1 2

D26

2

G

R533 100K_0402_5%

100K_0402_5%

1 2

ON/OFF#

2

51_ON#

3

C561

C561 1000P_0402_50V7K

1000P_0402_50V7K

13

D

S

Q21

Q21 SSM3K7002FU_SC70-3

SSM3K7002FU_SC70-3

ON/OFF# <31> 51_ON# <40>

2

1

12

D27

D27 RLZ20A_LL34

RLZ20A_LL34

Conductive Board Conn.

R890 0_0603_5%@R890 0_0603_5%@

+3VS

R891 0_0603_5%R891 0_0603_5%

+3VALW

R892 0_0603_5%@R892 0_0603_5%@

+5VS

R893 0_0603_5%@R893 0_0603_5%@

+5VALW

NUM_LED#<31> SCROLL_LED#<31>

NUM_LED# SCROLL_LED#

ESB_CLK_R<31> ESB_DAT_R<31>

02/18 Add L73,L74 and C866 for EMI recommend

+5VALW

+5VS

+3VALW

12/15 Add the pull-up resister of LID_SW# at M/B side. Solve system can't power on when unplug function board and w/ DC only.

LID_SW#<31>

R894 0_0402_5%R894 0_0402_5% R895 0_0402_5%R895 0_0402_5%

R896 0_0603_5%@R896 0_0603_5%@ R897 0_0603_5%R897 0_0603_5%

R917 100K_0402_1%R917 100K_0402_1%

1 2

12 12 12 12

1 2 1 2

FBMA-11-100505-301T_0402

L73

<EMI>L73

<EMI>

1 2

L74

<EMI>L74

<EMI>

1 2

FBMA-11-100505-301T_0402

12 12

+3V_5VSW

ESB_CLK_R_L ESB_DAT_R_L LID_SW# +5V_LED NUM_LED#_R SCROLL_LED#_R

ESB_CLK_R_L ESB_DAT_R_L

+5V_LED

LID_SW#

Update Symbol

JSW1

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

ACES_85203-08421-11

CONN@

C866

<EMI>

33P_0402_50V8J

2 4 6 8 10 12 14 16

SINGLE INT MIC/DUAL INT MIC

Internal MIC component close to U27

R582

+3VS

12

R723

R723 10K_0402_5%

10K_0402_5%

@

3 3

+MIC2_VREFO

1 2

R725 0_0402_5%R725 0_0402_5%

+MIC2_VREF_R+MIC2_VREFO

0.1U_0402_16V4Z

C723

@

1

2

12

R724

R724 27K_0402_5%

27K_0402_5%

@

Internal MIC component close to U27

@

R866 0_0603_5%

R865 0_0603_5%R865 0_0603_5%

4 4

GNDA

MIC_GND

+MIC2_VREF_R

JMICL1

G1 G2

ACES_85204-02001

CONN@

MIC2_L_OUT

1

2

3 4

Follow JFT00 Smybol

Internal MIC component close to U27

+MIC2_VREF_R

JMICR1

G1 G2

ACES_85204-02001

CONN@

Follow JFT00 Smybol

MIC2_R_OUT

1

2

3 4

12

0_0402_5%@

0_0402_5%@ D70

DUAL@D70

DUAL@

R583

1 2

12

2.2K_0402_5%

12

DUAL@<EMI>

2.2K_0402_5%

RLS4148_LL34-2

C623 220P_0402_50V7K

MIC_GND

R586

12

0_0402_5%SINGLE@

D71

DUAL@D71

DUAL@

R587

1 2

12

2.2K_0402_5%

RLS4148_LL34-2

C625 220P_0402_50V7K

<EMI>

2.2K_0402_5%

12

MIC_GND

DUAL@R583

DUAL@

12

R585

R585 0_0402_5%

0_0402_5%

SINGLE@

<EMI>

1 2

R707 0_0402_5%

D35

@

3

1

2

PSOT05C-LF-T7 SOT-23-3

<EMI>

1 2

R708 0_0402_5%

MIC2_L

MIC2_R

MIC2_L <35>

MIC2_R <35>

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

A

B

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

C

2008/10/18 2009/10/18

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

D

Date: Sheet

Compal Electronics, Inc.

PWROK/LID/Front/IO Board

KFT00 M/B LA-4821P Schematic

34 47Tuesday, March 10, 2009

E

1.0

of

5

HD Audio Codec

R852

D D

+VDDA

MIC2_L<34> MIC2_R<34>

C C

MIC1_L<36> MIC1_R<36>

EAPD<31,36>

B B

R852

0_0603_5%

10U_0805_10V4Z

1 2

R715 1K_0402_5%R715 1K_0402_5%

1 2

R716 1K_0402_5%R716 1K_0402_5%

1 2

R717 1K_0402_5%R717 1K_0402_5%

1 2

R718 1K_0402_5%R718 1K_0402_5%

R547

R547 10_0402_5%

10_0402_5%

@

1 2 1

C598

C598 15P_0402_50V8J

15P_0402_50V8J

2

@

SENSE FOR Ext. Mic.

MIC_SENSE<36>

1 2

R550 20K_0402_1%R550 20K_0402_1%

SENSE FOR Solo Int. Mic.

1 2

A A

R551 20K_0402_1%R551 20K_0402_1%

SENSE FOR HP

HP_SENSE<36>

R554 39.2K_0402_1%R554 39.2K_0402_1%

5

0.1U_0402_16V4Z

1

C573

MIC2_R_L MIC2_R_R

1

C574

2

0.1U_0402_16V4Z

C589 2.2U_0603_6.3V6KC589 2.2U_0603_6.3V6K C585 2.2U_0603_6.3V6KC585 2.2U_0603_6.3V6K

2/01 Let them floating

MIC1_R_L

C591 2.2U_0603_6.3V6KC591 2.2U_0603_6.3V6K

MIC1_R_R

C592 2.2U_0603_6.3V6KC592 2.2U_0603_6.3V6K

C594 100P_0402_50V8J

1 2

@

HDA_RST_AUDIO#<20> HDA_SYNC_AUDIO<20> HDA_SDOUT_AUDIO<20>

MUTE_LED#<31>

SENSE_A

SENSE_B

SENSE_A

12

1

C575

C577

@

100P_0402_50V8J

2

100P_0402_50V8J

2

MIC2_C_L MIC2_C_R

MIC1_C_L MIC1_C_R

MONO_IN

MUTE_LED# SENSE_A SENSE_B

Change U27 from SA00001GD00 to SA00001GD10

ESD

4.7K_0402_5%

0.01U_0402_16V7K

4

+AVDD_AC97

40mil

U27

AVDD125AVDD2

14

NC

15

NC

16

MIC2_L

17

MIC2_R

23

LINE1_L

24

LINE1_R

18

CD_L

20

CD_R

19

CD_GND

21

MIC1_L

22

MIC1_R

12

PCBEEP

11

RESET#

10

SYNC

5

SDATA_OUT

2

GPIO0

3

GPIO3

13

SENSE A

34

SENSE B

47

EAPD

48

SPDIFO

4

DVSS1

7

DVSS2

ALC268-GR_LQFP48

DGND

+3VS

12

R864

@

HDA_RST_AUDIO#

1

C817

2

@

Moat Bridge

1 2

R861 0_0805_5%R861 0_0805_5%

1 2

R862 0_0805_5%R862 0_0805_5%

1 2

R863 0_0805_5%R863 0_0805_5%

1 2

R555 0_0805_5%R555 0_0805_5%

1 2

R556 0_0805_5%R556 0_0805_5%

4

38

+3VS_DVDD

1

DVDD

LINE_OUT_L

LINE_OUT_R

HP_OUT_L HP_OUT_R

DMIC_CLK

BIT_CLK

SDATA_IN

MONO_OUT

LINE1_VREFO

GPIO1

MIC1_VREFO_L

MIC1_VREFO_R

MIC2_VREFO

VREF

JDREF

AVSS1 AVSS2

9

DVDD_IO

NC

NC NC

NC

10mil

AMP_LEFT

35

AMP_RIGHT

36

AMP_LEFT_HP

39

AMP_RIGHT_HP

41 45 46 43 44

HDA_BITCLK_AUDIO

6

SDIN0

8 37 29 31 28

10mil

32

10mil

30

10mil

ACZ_VREF

27

ACZ_JDREF

40 33 26

42

1

C570

2

0.1U_0402_16V4Z

1

C580

2

0.1U_0402_16V4Z

1 2

R545 33_0402_5%R545 33_0402_5%

+MIC1_VREFO_L +MIC1_VREFO_R +MIC2_VREFO

12

R548

20K_0402_1%

3

1

C571

@

4.7U_0805_10V4Z

2

1

C581

@

4.7U_0805_10V4Z

2

L33

1 2

FBMA-L11-160808-800LMT_0603

R898 0_0603_5%@R898 0_0603_5%@

AMP_LEFT <36> AMP_RIGHT <36> AMP_LEFT_HP <36> AMP_RIGHT_HP <36>

HDA_BITCLK_AUDIO <20>

HDA_SDIN0 <20>

10mil

1

C596

C596 10U_0805_10V4Z

10U_0805_10V4Z

2

+3VS

1

C597

C597 100P_0402_50V8J

100P_0402_50V8J

2

EC Beep

BEEP#<31>

SB_SPKR<20>

PCI Beep

Sense Pin Impedance Codec Signals

SENSE A / B

SENSE B

AGND

HDA_BITCLK_AUDIO

R549

R549 10_0402_5%

10_0402_5%

@

1 2 1

C599

C599 10P_0402_50V8J

10P_0402_50V8J

2

@

Regulator for CODEC

R853

+5VS

R853

0_0603_5%

60mil

10U_0805_10V4Z

C600

@

+5VS_VDDA

1

2

1

C601

2

0.1U_0402_16V4Z

10/2 change circuit

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/08/30

3

Compal Secret Data

Deciphered Date

2009/8/30

2

1

C572 0.1U_0402_16V4ZC572 0.1U_0402_16V4Z

1 2

R541 10K_0402_5%R541 10K_0402_5%

1 2

R543 10K_0402_5%R543 10K_0402_5%

1 2

MONO_IN_1 MONO_IN

1 2

C582 0.1U_0402_16V4ZC582 0.1U_0402_16V4Z

12

R544

R544 10K_0402_5%

10K_0402_5%

Funnction

39.2K 20K 10K

5.1K

39.2K 20K 10K

5.1K

U28

1

IN

2

GND

3

SHDN

G9191-475T1U_SOT23-5

PORT-A (PIN 39, 41) PORT-B (PIN 21, 22) PORT-C (PIN 23, 24) PORT-D (PIN 35, 36) PORT-E (PIN 14, 15) PORT-F (PIN 16, 17) PORT-G (PIN 43, 44) PORT-H (PIN 45, 46)

5

OUT

4

BYP

C603

0.01U_0402_16V7K

HP MIC LINE IN LINE OUT HP MIC LINE IN LINE OUT

40mil

(Max output = 300 mA)

1

C602

4.7U_0805_10V4Z

1

2

@

2

U8 change footprint

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

Compal Electronics, Inc.

<Title>

HD Audio Codec ALC268

KFT00 M/B LA-4821P Schematic

Tuesday, March 10, 2009

1

35 47

of

+VDDA

4.75V

1.0

A

APA2057 SPK/HP Amplifier

fo=1/(2*3.14*R*C)=106Hz R=1.5K / C= 1uF

R560 1.5K_0402_1%@R560 1.5K_0402_1%@

1 1

AMP_RIGHT<35> AMP_LEFT<35>

AMP_RIGHT_HP<35> AMP_LEFT_HP<35>

1 2

R569 0_0402_5%R569 0_0402_5%

9/5 If implement AMP BEEP, Swap C641 and R524.

2 2

R524 change from 0 Ohm to 47K

1 2

R562 1.5K_0402_1%@R562 1.5K_0402_1%@

1 2

C609 1U_0603_10V4ZC609 1U_0603_10V4Z

1 2

C608 1U_0603_10V4ZC608 1U_0603_10V4Z

1 2

C841 1U_0603_10V4ZC841 1U_0603_10V4Z

1 2

+5VS

1 2

C612 4.7U_0805_10V4ZC612 4.7U_0805_10V4Z

1 2

C613 4.7U_0805_10V4ZC613 4.7U_0805_10V4Z

1 2

C614 0.47U_0603_16V4ZC614 0.47U_0603_16V4Z

AMP_RHPIN AMP_LHPIN AMP_SD#

R563 100K_0402_5%R563 100K_0402_5%

1 2

R564 100K_0402_5%@R564 100K_0402_5%@

1 2

R565 39K_0402_5%R565 39K_0402_5%

1 2

R566 39K_0402_5%R566 39K_0402_5%

1 2

R567 0_0402_5%R567 0_0402_5%

1 2

C617 1U_0603_10V6KC617 1U_0603_10V6K C618 2.2U_0603_6.3V6KC618 2.2U_0603_6.3V6K C620 0.1U_0402_16V4ZC620 0.1U_0402_16V4Z

IN_A Gain = 10dB (Internal Speaker) IN_H Gain = 0dB (Headphone)

W=40mil

C604

12

B

C605

680P_0402_50V7K

AMPR AMPL

AMP_EN# HP_EN INR_H INL_H

AMP_BEEP AMP_CP+

AMP_CPAMP_BIAS

+5VALW

1

2

1

C606

0.1U_0402_16V4Z

0.1U_0402_16V4Z U29

U29

3

INR_A

5

INL_A

27

/AMP EN

24

HP EN

4

INR_H

6

INL_H

26

/SD

28

BEEP

12

CP+

14

CP-

25

BIAS

APA2057A_TSSOP28

+3VALW

2

10U_0805_10V4Z

19

11

HVDD

CVDD

11/28 Modified to X5R 11/28 Change to SE080105K80

20

10

PVDD

1

VDD

ROUT+

ROUT-

LOUT+

LOUT-

HP_R

HP_L

CVSS

VSS

GND PGND PGND CGND

GND

2

C607

C607 1U_0603_10V4Z

1U_0603_10V4Z

1

22 21

8 9

17 18

15 16 2

23 7 13 29

SPKR+ SPKR-

HP_R HP_L

CVSS

C

12

C619

C619 1U_0603_10V6K

1U_0603_10V6K

D

+MIC1_VREFO_R

+MIC1_VREFO_L

12

1

2

12

R558

2.2K_0402_5%

L47

KC FBM-L11-160808-121LMT 0603

L48

KC FBM-L11-160808-121LMT 0603

1

C611

<EMI>

220P_0402_50V7K

2

10mil 10mil

R557

2.2K_0402_5%

MIC_SENSE<35>

MIC1_R<35> MIC1_L<35>

MIC_SENSE

MIC1_R MIC1_L

220P_0402_50V7K

<EMI>

C610

Trace width/spacing/other=8/6/50

R570

@

12

HP_SENSE

HP_R HP_L

12

R568

@

0_0402_5%

10P_0402_50V8J

C615

<EMI>

KC FBM-L11-160808-121LMT 0603

KC FBM-L11-160808-121LMT 0603 KC FBM-L11-160808-121LMT 0603

KC FBM-L11-160808-121LMT 0603

1

C616

<EMI>

2

10P_0402_50V8J

L49 L50

HP_SENSE<35>

0_0402_5%

Trace width/spacing=15/9

1 2 1 2

10mil

1 2 1 2

<EMI>L47

<EMI> <EMI>L48

<EMI>

<EMI>L49

<EMI> <EMI>L50

<EMI>

MIC1_R_1 MIC1_L_1

HPR HPL

2

3

@

1

D29

D29 PSOT05C-LF-T7 SOT-23-3

PSOT05C-LF-T7 SOT-23-3

<EMI>

2

3

@

1

D30

D30 PSOT05C-LF-T7 SOT-23-3

PSOT05C-LF-T7 SOT-23-3

<EMI>

E

MICROPHONE IN JACK

JEMIC1

5 4 3

6 7 2 1

FOX_JA6333L-B3S0-7F~N

CONN@

RED

HEADPHONE OUT JACK

JEHP1

5 4 3

6 7 2 1

FOX_JA6333L-B3S0-7F~N

CONN@

GREEN

10 9 8

Add below circuit for APA2057 gain tunning use

+3VALW

3 3

EAPD<31,35>

EAPD

12

R577 0_0402_5%R577 0_0402_5%

SSM3K7002FU_SC70-3

R573

10K_0402_5%

2

G

Q24

C621

13

D

1 2

13

D

S

D

2

G

S

Q23

Q23 SSM3K7002FU_SC70-3

SSM3K7002FU_SC70-3

C621

0.01U_0402_16V7K

Gain= 10dB

Gain (dB) Low (V) High (V) Recommended (V) 10 11

4 4

12 13

3.45

3.56

3.68

3.80

3.51

3.62

3.73

3.85

A

3.48

3.59

3.70

3.82 +5VALW assume equal 5.1V

10 dB ---> 5.1 x 220 / 320 = 3.5

B

+5VALW

12

R571

R571 10K_0402_1%

10K_0402_1%

AMP_SD# HP_EN

R572 10K_0402_5%R572 10K_0402_5%

1 2

12

1

R574

R574 22K_0402_1%

22K_0402_1%

2

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

C

1

C622

0.1U_0402_16V4Z

2

Compal Secret Data

Deciphered Date

20mil

SPKR-

R581 0_0603_5%<EMI>R581 0_0603_5%<EMI>

SPKR+

R579 0_0603_5%<EMI>R579 0_0603_5%<EMI>

D

1 2 1 2

2009/8/302008/08/30

Speaker Conn.

JSPK1

SPK_R1SPK_R1+

2

3

D31

@

PSOT24C_SOT23

<EMI>

1

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

Compal Electronics, Inc.

AMP/VR/Audio Jack

KFT00 M/B LA-4821P Schematic

E

JSPK1

2 1

CONN@

ACES_85204-0200

36 47Tuesday, March 10, 2009

of

1.0

MDC Conn.

JMDC1

1

HDA_SDOUT_MDC<20> HDA_SYNC_MDC<20> HDA_RST_MDC#<20>

HDA_SDIN1<20>

Please add these caps close to JMDC1 as close as possible,

JMDC2

1

2

3

G1

4

G2

ACES_85204-02001

CONN@

HDA_SDOUT_MDC HDA_SYNC_MDC

SDIN1_MDC HDA_RST_MDC# HDA_BITCLK_MDC

R593

HDA_SDIN1 SDIN1_MDC

HDA_SDOUT_MDC HDA_SYNC_MDC HDA_RST_MDC# HDA_SDIN1

TIP RING

R593

1 2

33_0402_5%

C752 100P_0402_50V8J@C752 100P_0402_50V8J@ C753 100P_0402_50V8J@C753 100P_0402_50V8J@ C754 100P_0402_50V8J@C754 100P_0402_50V8J@ C756 100P_0402_50V8J@C756 100P_0402_50V8J@

C842

330P_1808_3KV7K

GND1

3

IAC_SDATA_OUT

5

GND2

7

IAC_SYNC

9

IAC_SDATA_IN

11

IAC_RESET#

Connector for MDC Rev1.5

ACES_88018-124G

CONN@

1 2 1 2 1 2 1 2

2

C843

C843 330P_1808_3KV7K

330P_1808_3KV7K

1

IAC_BITCLK

GND13GND14GND15GND16GND17GND

18

LED

R660

R660 820_0402_5%

+5VS

+5VALW

+5VS

820_0402_5%

1 2

R596

R596 820_0402_5%

820_0402_5%

1 2

R867

1 2

820_0402_5%

R597

R597 820_0402_5%

820_0402_5%

1 2

R598

1 2

820_0402_5%

R599

R599 820_0402_5%

820_0402_5%

1 2

R600

1 2

820_0402_5%

2 1

HT-191NB_BLUE_0603

2 1

HT-191NB_BLUE_0603

2 1

HT-191NB_BLUE_0603

2 1

LED4

LED1

LED8

HT-191UD_AMBER_0603

LED6

LED7

HT-191NB_BLUE_0603

HT-191NB_BLUE_0603 HT-191UD_AMBER_0603

HT-191UD_AMBER_0603

LED5

LED3

HT-191NB_BLUE_0603

20mil

+VCC_MDC

2

RES0

4

GND3 GND4

1 2

3 4

RES1

3.3V

6 8 10 12

JRJ11

Tip Ring

GND1 GND2

FOX_305-000-1176

CONN@

+3V_MDC

1

C629

C629 22P_0402_50V8J

22P_0402_50V8J

2

@

Amber Blue

03/02 Change LED5,LED6 from SC5191UD000 to SC500005T00

Amber Blue

R695 0_0402_5%R695 0_0402_5%

1 2

R697 0_0402_5%R697 0_0402_5%

1 2

+VCC_MDC +3V_MDC

C746

0.1U_0402_16V4Z

@

HDA_BITCLK_MDC

SATA_LED# <21>

PWR_LED# <31>

CHARGE_LED0# <31>

CHARGE_LED1# <31>

WLAN_LED# <29>

BT_LED# <33>

+3VS +3VS

HDA_BITCLK_MDC <20>

1

C745

0.1U_0402_16V4Z

2

@

R868

R868 10_0402_5%

10_0402_5%

@

1 2 1

C822

C822 10P_0402_50V8J

10P_0402_50V8J

2

@

Camera Conn

R910 0_0603_5%R910 0_0603_5%

+3VS

+5VS

R911 0_0603_5%@R911 0_0603_5%@ R590 0_0603_5%@R590 0_0603_5%@ R591 0_0603_5%@R591 0_0603_5%@

0.1U_0402_16V4Z

@

1 2

R874 100K_0402_5%

D73

@<EMI>D73

@<EMI>

3

I/O

4

VCC

PJLCR05 SOT143

+3VALW

+5VALW

CAM_ON#<31>

+3VS

Finger Print board

0.1U_0402_16V4Z

FP_ON#<31>

1 2

R871 100K_0402_5%

USB20_P3<21> USB20_N3<21>

+FP_VCC+3VS

C828

12 12 12 12

GND

@

I/O

@

USB20_N7<21> USB20_P7<21>

USB20_P3 USB20_N3

2

1

C826

W=20mils

+3V_5V_CAMERA

1

C829

@

1U_0603_10V4Z

W=20mils

S

Q54

Q54 SI2301BDS_SOT23

SI2301BDS_SOT23

@

D

1 3

1U_0603_10V4Z

2

W=20mils

S

G

2

Q55

Q55 SI2301BDS_SOT23

SI2301BDS_SOT23

@

D

1 3

USB20_N7 USB20_P7

USB20_R_N7USB20_R_P7

+3VS

@

G

2

12

R873

R873 0_0603_5%

0_0603_5%

+CAM_VCC

R594 0_0402_5%R594 0_0402_5%

1 2

R595 0_0402_5%R595 0_0402_5%

1 2

L42

@ <EMI>L42

@ <EMI>

4

1

WCM2012F2SF-121T04_0805

1

C827

@

1U_0603_10V4Z

2

12

R872

R872 0_0603_5%

0_0603_5%

W=20mils

4.7U_0805_10V4Z

3

2

+FP_VCC

+CAM_VCC

C627

1

2

1

C628

0.1U_0402_16V4Z

2

USB20_R_N7 USB20_R_P7

JCAM1

1

2

3

4

5

6

GND1

7

GND2

ACES_88266-05001

CAMCONN@

05/26 Change D36 from SC300000X00 to SC300000K00

D36

<EMI>D36

<EMI>

L72

@ <EMI>L72

@ <EMI>

C630

3

2

1

@

2

4

1

WCM2012F2SF-121T04_0805

R640 0_0402_5%R640 0_0402_5%

1 2

R641 0_0402_5%R641 0_0402_5%

1 2

4.7U_0805_10V4Z

USB20_R_P3 USB20_R_N3

C631

0.1U_0402_16V4Z

3

4

PJLCR05 SOT143

EMI Request

I/O

VCC

2

I/O

1

GND

JFP1

6 5 4 3 2 1

E&T_3802-E04N-01R

CONN@

Follow JFT00 Smybol

G1 G1 4 3 2 1

12/7 Modified LED footprint to LED_HT-297UD-CB_4P

12/15 Modified to correct LED symbol!

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/08/30 2009/8/30

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

Compal Electronics, Inc.

MDC/LED/Camera/FP

KFT00 M/B LA-4821P Schematic

of

37 47Tuesday, March 10, 2009

1.0

H7 HOLEAH7HOLEA

1

H15

H15 HOLEA

HOLEA

1

H23

H23 HOLEA

HOLEA

1

H32

H32 HOLEA

HOLEA

1

H8 HOLEAH8HOLEA

1

H16

H16 HOLEA

HOLEA

1

H33

H33 HOLEA

HOLEA

1

H9 HOLEAH9HOLEA

1

H17

H17 HOLEA

HOLEA

1

H25

H25 HOLEA

HOLEA

1

H34

H34 HOLEA

HOLEA

1

H10

H10 HOLEA

HOLEA

1

H18

H18 HOLEA

HOLEA

1

H26

H26 HOLEA

HOLEA

1

H35

H35 HOLEA

HOLEA

1

H11

H11 HOLEA

HOLEA

1

H19

H19 HOLEA

HOLEA

1

H27

H27 HOLEA

HOLEA

1

H36

H36 HOLEA

HOLEA

1

H12

H12 HOLEA

HOLEA

1

H20

H20 HOLEA

HOLEA

1

H28

H28 HOLEA

HOLEA

1

H13

H13 HOLEA

HOLEA

1

H21

H21 HOLEA

HOLEA

1

H29

H29 HOLEA

HOLEA

1

H14

H14 HOLEA

HOLEA

1

H22

H22 HOLEA

HOLEA

1

H31

H31 HOLEA

HOLEA

1

H39

H39 HOLEA

HOLEA

1

H40

H40 HOLEA

HOLEA

1

FM1FM1

1

FM3FM3

FM2FM2

1

FM4FM4

1

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/10/18 2009/10/18

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

Compal Electronics, Inc.

FAN & Screw Hole

KFT00 M/B LA-4821P Schematic

38 47Tuesday, February 10, 2009

of

1.0

A

B

C

D

E

1 1

+VSB

R288

R288 33K_0402_5%

33K_0402_5%

SSM3K7002FU_SC70-3

Change Q48 package from SOT23 to SC70-3; Michael 2008/5/30

2 2

+VSB

R287

R287 47K_0402_5%

47K_0402_5%

SSM3K7002FU_SC70-3

3 3

Change Q17 package from SOT23 to SC70-3; Michael 2008/5/30

+5VALW TO +5VS +1.8VALW to +1.8VS

01/09 Add C861 (0.1uF) for EMI Recommend

R296

R296 470_0603_5%

470_0603_5%

@

1 2

Q26

13

D

SSM3K7002FU_SC70-3

2

G

@

S

C861

<EMI>

0.1U_0402_16V4Z

1 2

+VSB

R286

R286 47K_0402_5%

47K_0402_5%

SYSON#

SSM3K7002FU_SC70-3

Change Q49 package from SOT23 to SC70-3; Michael 2008/5/30

1 2

+VSB

R283

R283 47K_0402_5%

47K_0402_5%

SUSP

SSM3K7002FU_SC70-3

Change Q16 package from SOT23 to SC70-3; Michael 2008/5/30

SUSP

1 2

SUSP

+5VALW

U13

8

S

D

7

S

D

6

S

D

5

G

D

AO4468_SO8

5VS_GATE

13

D

2

G

Q48

S

+3VALW TO +3VS

+3VALW

U16

8

S

D

7

S

D

6

S

D

5

G

D

AO4468_SO8

3VS_GATE

13

D

2

G

Q17

S

+1.5VS +1.05VS +0.9VS

R289

R289 470_0603_5%

470_0603_5%

@

1 2

Q20

13

D

SSM3K7002FU_SC70-3

SUSP SUSP SUSP

2

G

@

S

1 2 3 4

+5VS

1

C344

@

10U_0805_10V4Z

1

C323

0.1U_0603_25V7K

2

+3VS

C331

@

10U_0805_10V4Z

1

C320

0.1U_0603_25V7K

2

1

C334

2

1U_0603_10V4Z

Change Q25 Q50 package from SOT23 to Q52A Q52B SOT363-6; Michael 2008/5/30

1

C343

2

1U_0603_10V4Z

R280

R280 470_0603_5%

470_0603_5%

@

1 2

Q12

13

D

SSM3K7002FU_SC70-3

2

G

@

S

1 2 61

1

2

1 2 3

4

R295

@

470_0603_5%

Q52A

@

SUSP

2

2N7002DW-T/R7_SOT363-6

R292

@

470_0603_5%

Q52B

@

SUSP

5

2N7002DW-T/R7_SOT363-6

+1.8VALW TO +1.8V

+1.8VALW +1.8V

U17

D D D D

AO4468_SO8

1.8V_GATE

13

D

S

1

S

2

S

3

S

4

G

1

C340

@

10U_0805_10V4Z

2

1

C318

0.1U_0603_25V7K

2

1

C329

2

1U_0603_10V4Z

Change Q46 package from SOT23 to SC70-3; Michael 2008/5/30

R294

@

470_0603_5%

1 2 13

D

S

8 7 6

1

5

2

G

Q49

+1.2VALW TO +1.2VS

+1.2VALW +1.2VS

U14

D D D D

AO4468_SO8

1.2VS_GATE

13

D

S

1

S

2

S

3

S

4

G

1

C327

@

10U_0805_10V4Z

2

1

C317

0.1U_0603_25V7K

2

1

C338

2

1U_0603_10V4Z

R290

@

470_0603_5%

1 2 13

D

S

8 7 6 5

2

G

Q16

01/10 Add C862~C864 (0.1uF) for ESD Recommend

+1.8VS +3VALW B+

C862

<EMI>

0.1U_0402_16V4Z

1

0.1U_0402_16V4Z

2

<EMI>

C863

1

0.1U_0402_16V4Z

2

<EMI>

C864

1

2

01/06 Add C859 (0.1uF) for EMI Recommend

1

C859

<EMI>

0.1U_0402_16V4Z

2

SYSON#

2

G

Q46

SSM3K7002FU_SC70-3

Change Q47 Q51 package from SOT23 to Q53A Q53B SOT363-6; Michael 2008/5/30

SUSP

2

G

Q57

@

Q57

@

SSM3K7002FU_SC70-3

+VSB

R284

R284 47K_0402_5%

47K_0402_5%

SUSP

Q15

SSM3K7002FU_SC70-3

Change Q15 package from SOT23 to SC70-3; Michael 2008/5/30

Q15

7/24 Change R281 from 100K to 10K

+1.8VALW

12

2

G

SYSON<30,31>

SUSP#<30,31,42,44,45>

U15

8

D

7

D

6

D

5

D

AO4468_SO8

1.8VS_GATE

13

D

S

10K_0402_5%

S S S G

SYSON

R281

R282

+1.8VS

1 2

C330

3

@

4

10U_0805_10V4Z

1

C319

0.1U_0603_25V7K

2

+5VALW

SYSON#

2

G

12

Change Q13 Q14 package from SOT23 to SC70-3; Michael 2008/5/30

+5VALW

2

G

12

1

C342

2

1U_0603_10V4Z

R285

R285 100K_0402_5%

100K_0402_5%

1 2

13

D

SSM3K7002FU_SC70-3

Q14

S

R278

R278 100K_0402_5%

100K_0402_5%

1 2

SUSP

13

D

SSM3K7002FU_SC70-3

Q13

S

R293

@

470_0603_5%

1 2

13

D

S

1

C316

C316 100P_0402_50V8J

100P_0402_50V8J

2

SUSP

2

G

Q58

@

Q58

@

SSM3K7002FU_SC70-3

SUSP <45>

Change Q20 Q12 Q26 package from SOT23 to SC70-3; Michael 2008/5/30

4 4

3/14 Change R16 from 100K to 10K

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

A

B

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

C

2008/10/18 2009/10/18

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet

D

Date: Sheet

Compal Electronics, Inc.

DC Interface

KFT00 M/B LA-4821P Schematic

39 47Tuesday, March 10, 2009

E

1.0

of

A

B

C

D

PACIN

1 1

VIN

12

VINDE-1

VIN

12

PR19

84.5K_0402_1%

84.5K_0402_1% PR22

PR22 22K_0402_1%

22K_0402_1%

1 2

PR23

20K_0402_1%

VINDE-3

12

PC7

PL1

PJP1

1

2

G

G G

G

3

SINGA_2DC-S756B200

2 2

ADPIN

12

PC1

100P_0402_50V8J

PL1

SMB3025500YA_2P

1 2

12

PC2

PC2 1000P_0402_50V7K

1000P_0402_50V7K

12

PC3

100P_0402_50V8J

12

PC4

1000P_0402_50V7K

PC6

0.068U_0603_16V7K

VINDE-2

3 2

PR25

PR25 10K_0402_1%

10K_0402_1%

0.1U_0402_16V7K

PR18

PR18 1M_0402_1%

1M_0402_1%

1 2

VS

8

P

+

-

G

PU1A

PU1A LM393DG_SO8

LM393DG_SO8

4

12

O

12

PC5

1

RTCVREF

0.01U_0402_25V7K

3.3V

VIN

12

PR20

12

10K_0805_5%

PD1

RLZ4.3B_LL34

12

PR24

PR21

PR21 10K_0402_5%

10K_0402_5%

1 2

PACIN

10K_0402_1%

PC271 470P_0402_50V7K@PC271 470P_0402_50V7K@

1 2

ACIN <31>

PACIN <42>

Vin Detector

High 18.384 17.901 17.430

PJ1

+3VALWP +3VALW

+5VALWP +5VALW

+1.2VALWP +1.2VALW

3 3

+1.8VALWP +1.8VALW

2

112

JUMP_43X118@

PJ2

2

112

JUMP_43X118@

PJ3

2

112

JUMP_43X118@

PJ4

2

112

JUMP_43X118@

BATT+

SP093MX0000

PC87

@PC87

@

0.1U_0603_25V7K

CHGRTCP

PC91

@PC91

@

0.1U_0603_25V7K

51_ON#<34>

PJ5

2

112

JUMP_43X79@

PJ6

@PJ6

@

2

112

JUMP_43X118

PJ7

4 4

PJ7

2

JUMP_43X79

@

112

+0.9VS+0.9VSP

+CHGRTC

PR32

560_0603_5%

1 2

RTCVREF-1

+1.5VS+1.5VSP

+VSB+VSBP

Low 17.728 17.257 16.976

PD3

12

RLS4148_LL34-2

12

PR33

560_0603_5%

1 2

PR28

200_0603_5%

1 2

100K_0402_1%

PR30

22K_0402_1%

1 2

RTCVREF

3.3V

12

PC10

PC10 10U_0805_10V4Z

10U_0805_10V4Z

PR29

G920AT24U_SOT89-3

3

OUT

12

PU2

51ON-2

PC8

1 2

IN

GND

1

0.1U_0603_25V7K

PQ35

TP0610K-T1-E3_SOT23-3

0.22U_0603_25V7K

51ON-3

12

PR31

PR31 200_0603_5%

200_0603_5%

CHGRTCIN

2

12

PC11

PC11 1U_0805_25V4Z

1U_0805_25V4Z

PC92

@PC92

@

2

PD2

PR26

68_1206_5%

13

VIN

RLS4148_LL34-2

1 2

51ON-1

12

PC9

0.1U_0603_25V7K

PR27

PR27 68_1206_5%

68_1206_5%

VS

PJ16

2

JUMP_43X118

@PJ16

@

112

A

+1.05VS+1.05VSP

B

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/07/15

Compal Secret Data

Deciphered Date

C

2009/07/15

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

Compal Electronics, Inc.

DCIN & DETECTOR

DCIN & DETECTOR KFT00 MB Schematic

D

of

40 47Tuesday, March 10, 2009

of

40 47Tuesday, March 10, 2009

of

40 47Tuesday, March 10, 2009

0.2

A

B

C

D

12

PC14

0.01U_0402_50V7K

BATT+

PH1 under CPU botten side :

CPU thermal protection at 89 degree C Recovery at 70 degree C

12

PC16

1000P_0402_50V7K

VL

12

PR40

10K_0402_1%

PR43

78.7K_0603_1%

1 2

PH1

100K_0603_1%_TH11-4H104FT

12

TM_REF1

12

PC17

1U_0603_6.3V6M

PC15

12

0.1U_0603_25V7K

5

+

6

-

PR44

PR44 150K_0402_1%

150K_0402_1%

PR45

150K_0402_1%

VS

PR42

PR42 442K_0603_1%

442K_0603_1%

1 2

8

P

7

O

G

PU1B

PU1B LM393DG_SO8

LM393DG_SO8

4

12

VL

PR41

1 2

150K_0402_1%

MAINPWON <43>

PJP2

7

BATT+

SMD SMC

ID B/I

9

TS

G

8

1 1

SMART Battery:

7.BATT+

6.SMD

5.SMC

4.ID

3.B/I

2.TS

1.GND

2 2

GND1G

SUYIN_200275MR007G113ZL

6 5 4 3 2

EC_SMD EC_SMC

PR35

1K_0402_5%

100_0402_5%

PR37

BATT_DET <42>

PR34

12

1K_0402_5%@

12

PR39

PR39 100_0402_5%

100_0402_5%

1K_0402_5%@

PR36

6.49K_0402_1%

1 2

12

PR38

PR38 1K_0402_5%

1K_0402_5%

+3VALWP

EC_SMB_DA1 EC_SMB_CK1

12

BATT_DET

3S4SFloating

LOW

BATT++

12

BATT_TEMP <31>

PC12

PJ8

2

JUMP_43X118

12

PC13

1000P_0402_50V7K

@PJ8

@

112

EC_SMB_DA1 <31> EC_SMB_CK1 <31>

3 3

PQ36

TP0610K-T1-E3_SOT23-3

B+

PR47

PR47 22K_0402_1%

13

2

G

PC20

0.1U_0402_16V7K

22K_0402_1%

D

S

VL

PR48

PR49

10K_0402_1%

1 2

0_0402_5%

4 4

SPOK<43,44,45>

0_0402_5%

1 2

12

A

12

PR46

1 2

PQ37

PQ37 SSM3K7002F_SC59-3

SSM3K7002F_SC59-3

12

PC18

100K_0402_1%

0.22U_1206_25V7K

13

2

B

+VSBP

12

PC19

0.1U_0603_25V7K

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/07/15

Compal Secret Data

Deciphered Date

C

2009/07/15

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

Compal Electronics, Inc.

BATTERY CONN / OTP

BATTERY CONN / OTP KFT00 MB Schematic

D

of

41 47Tuesday, March 10, 2009

of

41 47Tuesday, March 10, 2009

of

41 47Tuesday, March 10, 2009

0.2

A

VIN P2

PQ38

8 7 6

PR51

1_1210_5%

PR52

1 2

340K_0402_1%

ACDET

1_1210_5%

PC292.2U_0805_25V6K

PR60

1 2

54.9K_0402_1%

PR59

PR59 47K_0402_1%

47K_0402_1%

1 2

PACIN<40>

PC25

47P_0402_50V8J

2

G

ACOFF#

12

1 1

12

PR58

1 2

2 2

3 3

4 4

47K_0402_5%

12

13

2

13

D

PQ45

PQ45 SSM3K7002FU_SC70-3

SSM3K7002FU_SC70-3

S

PR63

3K_0402_1%

1 2

PD5

1 2

1SS355_SOD323-2

PR54

1 2

2

PQ42

PQ42 DTC115EUA_SC70-3

DTC115EUA_SC70-3

5

PQ41

DTA144EUA_SC70-3

1 3

13

D

2

G

S

FSTCHG<31>

BATT_DET

3S4SFloating

1

S

D

2

S

D

3

S

D

4

G

D

FDS4435BZ_SO8

PQ46

PQ46 SSM3K7002FU_SC70-3

SSM3K7002FU_SC70-3

CHGVADJ<31>

12

PC27

0.1U_0603_25V7K

<BOM Structure>PR234

1 2

210K_0402_1%

1U_0603_10V6K

VREF

1 2

13

D

2

G

S

VREF

PR229

PR229 47K_0402_1%

47K_0402_1%

1 2

13

D

S

12

PR61

PR61 150K_0402_5%

150K_0402_5%

PR234

PR69

PR69 100K_0402_1%

100K_0402_1%

G

LOW

A

PQ39

1

S

2

S

3

S

4

G

FDS4435BZ_SO8

12

PR56

200K_0402_5%

PR64

@PR64

@

143K_0402_1%

12

PC38

CHGEN#

PQ48

PQ48 SSM3K7002F_SC59-3

SSM3K7002F_SC59-3

GND

CELLS

VREF

CELLS

2

PQ61

PQ61 SSM3K7002F_SC59-3

SSM3K7002F_SC59-3

Cells selector

REGN

12

VREF

1 2

8

D

7

D

6

D

5

D

SUSP#<30,31,39,44,45>

PR66

PR66 499K_0402_1%

499K_0402_1%

ADP_I<31>

3 Cell 4 Cell

PR231

PR231 100K_0402_1%

100K_0402_1%

B

VREF

0.01U_0402_16V7K

PC32

1 2

1U_0603_6.3V6M

BATT_DET <41>

B

PR53

PR53 113K_0402_1%

113K_0402_1%

1 2

PC26

PR62

PR62 0_0402_5%

0_0402_5%

1 2

PR67

15K_0402_5%

12

PC58

0.22U_0603_10V7K

C

PR5

1 2

PC21

ACP

ACN

3

2

ACP

ACN

SRP

CELLS

19

20

PR70

133K_0402_1%

PR71

PR71 200K_0402_1%

200K_0402_1%

4 3

CELLS

12

B+

PC34

0.1U_0603_25V7K

CHGEN#

1

CHGEN

PVCC

BTST

HIDRV

REGN

LODRV

PGND

DPMDET

21

12

2

TP

PH

PJ9

112

JUMP_43X118@

12

29

PC30

PC30 1U_0805_25V6K

1U_0805_25V6K

P2

1 2

28

BST_CHG

1 2

27

0_0603_5%

DH_CHG

26

25

24

23

22

IREF <31>

LX_CHG

REGN

DL_CHG

PD4

1SS355_SOD323-2

12

PC40

PC40 1U_0603_10V6K

1U_0603_10V6K

IREF Current

12

PC22

4.7U_1206_25V6K

PR232

12

PC23

4.7U_1206_25V6K

PC31

1 2

0.1U_0402_10V7K

AO4466_SO8

PC43

12

VREF

VADJ

12

PR68

10K_0402_5%

1 2

0.1U_0402_10V7K

ACSETACSET

12

PR57

PR57 100K_0402_5%

100K_0402_5%

8

IADSLP

9

AGND

10

VREF

11

VDAC

12

VADJ

13

EXTPWR

14

ISYNSET

PC42

100P_0402_50V8J

PC55

ACDET

5

6

7

LPREF

ACSET

PU3

PU3 BQ24740RHDR_QFN28_5X5

BQ24740RHDR_QFN28_5X5

IADAPT

SRSET

17

15

16

IADAPT

12

0.015_2512_1%

PC28

0.1U_0603_25V7K

4

LPMD

ACDET

BAT

SRN

18

1 2

1U_0603_6.3V6M

12

3.3V 3A

LI-3S :13.5V----BATT-OVP=1.5V BATT-OVP=0.1112*BATT+

8

5

P

+

7

0

6

-

G

PU4B

4

LM358DR_SO8

OVP-4

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/07/15

Compal Secret Data

Deciphered Date

C

BATT_OVP<31>

CHG_B+

PC24

4.7U_1206_25V6K

PQ47

12

PC116

0.1U_0603_25V7K

A/D

2009/07/15

PQ40

PQ40 FDS6675BZ_SO8

FDS6675BZ_SO8

1 2 3 6

4

ACOFF#

CHG_B+

578

PQ44

PQ44 AO4466_SO8

AO4466_SO8

3 6

241

12

578

PR75

PR75 10K_0402_1%

10K_0402_1%

3 6

241

12

0.1U_0603_25V7K

@

12

PR65

4.7_1206_5%

PC33

PC33 470P_0603_50V8J

470P_0603_50V8J

1 2

Custom

D

BATT+

8 7

5

PL3

PL3 10UH_MPL73-100_3A_20%

10UH_MPL73-100_3A_20%

1 2

12

PC35

10U_1206_25VAK

VS

12

8

3

P

+

1

0

2

-

G

PU4A

4

LM358DR_SO8

OVP-3

Compal Electronics, Inc.

Title

Size Document Number Rev

Date: Sheet

Compal Electronics, Inc.

KFT00 MB Schematic

47K_0402_5%

1 2

12

PR55

PR55 10K_0402_5%

10K_0402_5%

13

PQ43

PQ43 DTC115EUA_SC70-3

DTC115EUA_SC70-3

PR17

0.02_2512_1%

4 3

1 2

PC39

0.1U_0402_10V7K

BATT++

12

PR72

OVP-1

12

PC45

PR74

0.01U_0402_25V7K

OVP-2

12

PR76

CHARGER

D

PR50

2

1 2

340K_0402_1%

499K_0402_1%

105K_0402_1%

42 47Tuesday, March 10, 2009

VIN

ACOFF <31>

BATT+

12

PC36

10U_1206_25VAK

12

PC46

0.01U_0402_25V7K

of

12

PC37

0.2

10U_1206_25VAK

5

4

3

2

1

ISL6237_B+

12

PC50

PC49

10U_1206_25V6M

2200P_0402_50V7K

PL5

4.7U_LF919AS-4R7M-P3_5.2A_20%

12

PR79

4.7_1206_5%@

5V_SNB

12

PC60

680P_0603_50V8J@

12

+5VALWP

1

+

PC41

2

220U_6.3VM_R15

PR83

61.9K_0402_1%

@ PR83

@

1 2

PR85

1 2

0_0402_5%

12

0_0402_5%

100K_0402_1%

1 2

PR94

ISL6237_B+

578

3 6

241

578

3 6

241

PR88

PR89

12

PQ16

AO4466_SO8

PQ18

PQ18 AO4712_SO8

AO4712_SO8

1 2

200K_0402_5%

@

BST3A-1

PR80

PR80 0_0402_5%

0_0402_5%

PC56

0.1U_0603_25V7K

1 2

PC62

0.22U_0603_25V7K

VL

PR93

47K_0402_5%

1 2

806K_0603_1%

1 2

12

PC64

PR77

0_0402_5%

1 2

0.1U_0603_25V7K

BST3A

12

VL

2VREF_ISL6237

1 2

PC61

0.22U_0603_25V7K

PR95

@

PC65

0.047U_0402_16V7K

0.047U_0402_16V7K@

UG3

SW3

LG3

FB3

EN_LDO

3/5V_EN1

3/5V_EN2

12

PC51

PR92

PR92 0_0402_5%

0_0402_5%

1 2

2VREF_ISL6237

33 26 24

25

23

30

32

1

8

20

4

14

27

1 2

3/5V_VIN

6

PU6

TP DRVH2 VBST2

LL2

DRVL2

VOUT2

REFIN2

VREF2

LDOREFIN

NC

EN_LDO

EN1

EN2

5

3/5V_NC

12

PC63

1U_0603_10V6K

VIN

VREF3

1 2

PC52

3/5V_VCC

3

V5FILT

TONSE

2

3/5V_TON

12

PR96

PR96 0_0402_5%

0_0402_5%

2VREF_ISL6237

1U_0603_10V6K

7

LDO

V5DRV DRVH1

VBST1

DRVL1

VOUT1

SKIPSEL

PGOOD2

PGOOD1

GND

21

VL

12

PC53

4.7U_0805_6.3V6K

4.7U_0805_6.3V6K 1U_0603_10V6K

1U_0603_10V6K

1 2

19

HG5

15

BST5A

17

PR81

PR81 0_0402_5%

0_0402_5%

SW5

16

LL1

LG5

18

22

PGND

10

FB5

11

FB1

9

VSW

5V_SKIP

29

28

13

ILM1

12

TRIP1

ILIM2

31

TRIP2

SN0806081RHBR_QFN32_5X5

PC54

1 2

PR86

PR86 0_0402_5%@

0_0402_5%@ PR87

PR87 0_0402_5%

0_0402_5%

BST5A-1

12

1 2

PC57

0.1U_0603_25V7K

12

PR90

PR90 316K_0402_1%

316K_0402_1%

PR91

PR91 316K_0402_1%

316K_0402_1%

578

PQ15

PQ15 AO4466_SO8

AO4466_SO8

3 6

241

578

PQ17

AO4712_SO8

3 6

241

VL

SPOK <41,44,45>

12

+5VALWP Ipeak=8.11A ; Imax=5.677A Rds(on)=18m ohm(max) ; Rds(on)=15m ohm(typical) Vlimit=(5E-06 * 316K)/10=158mV Ilimit=158mV/(18m ~ 15m) =8.77A ~ 10.53A Iocp=Ilimit+Delta I/2 =9.75A ~11.51 A Delta I=1.956A (Freq=400KHz)

B+

PJ10

PJ10 JUMP_43X118@

JUMP_43X118@

2

112

D D

4.7U_LF919AS-4R7M-P3_5.2A_20%

1 2

+3VALWP

1

+

2

PC44

220U_D2_4VY_R15M

C C

B B

PR82

0_0402_5%

1 2

PR84

10K_0402_1%@

1 2

PD7

RLZ5.1B_LL34

VS

1 2

PL6

PC59

680P_0603_50V8J@

PC47

10U_1206_25V6M

4.7_1206_5%@

12

PC48

2200P_0402_50V7K

12

PR78

3V_SNB

12

PD6

RB751V-40TE17_SOD323-2

1 2

EN_LDO-1

PD8

RB751V-40TE17_SOD323-2@

1 2

MAINPWON<41>

+3VALWP Ipeak=4.85A ; Imax=3.395A Rds(on)=18m ohm(max) ; Rds(on)=15m ohm(typical) Vlimit=(5E-06 * 180K)/10=90mV Ilimit=90mV/(18m ~ 15m)

A A

=5A ~ 6A Iocp=Ilimit+Delta I/2 =5.967A ~ 6.967A Delta I=1.934A (Freq=300KHz)

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

3

2008/07/15

Compal Secret Data

Deciphered Date

2

2009/07/15

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

Compal Electronics, Inc.

3VALW/5VALW

KFT00 MB Schematic

Tuesday, March 10, 2009

1

43 47

of

0.2

5

D D

PR98

0_0402_5%

SPOK<41,43,45>

+5VALWP

C C

1 2

PR101

422_0603_1%

1 2

PC71

1U_0603_10V6K

12

PC68

0.1U_0402_16V7K

@

12

47P_0402_50V8J@

12

PR104

30.1K_0402_1%

20K_0402_1%

PC72

1 2

PR103

1 2

4

PR97

240K_0402_5%

1.2V_TON

1.2V_EN

1.2V_V5FILT

1.2V_FB

240K_0402_5%

1 2

BST_1.2V BST_1.2V-1

14TP15

1

2

TON

3

VOUT

4

V5FILT

5

VFB

6

PGOOD

VBST

EN_PSV

V5DRV

GND7PGND

8

PU7

PU7 TPS51117RGYR_QFN14_3.5x3.5

TPS51117RGYR_QFN14_3.5x3.5

DRVH

LL

TRIP

DRVL

PR99

0_0603_1%

1 2

UG_1.2V

13

SW_1.2V

12

1 2

11

16.5K_0402_1%

10

LG_1.2V

9

PR102

3

PC67

1 2

0.1U_0603_25V7K

+5VALWP

12

PC73

4.7U_0805_10V6K

578

3 6

578

3 6

1.2V_IN

PQ27

PQ27 AO4466_SO8

AO4466_SO8

241

2.2UH_PCMC063T-2R2MN_8A_20%

12

PR100

PQ28

12

AO4712_SO8

241

PC74

PL11

1 2

4.7_1206_5%@

680P_0603_50V7K@

2

12

PC66

10U_1206_25V6M

1

PJ11

2

JUMP_43X79@

1

+

2

112

PC69

220U_V_4VM_R15M

B+

+1.2VALWP

12

PC70

10U_0805_6.3V6M

VFB=0.75V

+1.2VS+5VS

PJ12

2

JUMP_43X118@

B B

PU12

7

POK

PR315

SUSP#<30,31,39,42,45>

A A

FB=0.8V Vout=0.8v*(1+R316/R319) Imax=3.22A Ipeak=4.6A

5

1 2

0_0402_5%

12

PC269

0.1U_0402_16V7K

@

8

EN

12

6

5

VIN

4

VOUT

VCNTL

3

VOUT

2

FB

9

VIN

GND

1

APL5913-KAC-TRL_SO8

4

PC263

1U_0603_6.3V6M

2

1

1 12

12

PR316

1.1K_0402_1%

12

PC264

4.7U_0805_6.3V6K

12

PC265

0.01U_0402_25V7K

PR319

3.4K_0402_1%

+1.05VSP

12

PC266

22U_0805_6.3V6M

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

12

PC268

PC267

@

22U_0805_6.3V6M

Compal Secret Data

2008/07/15

3

Compal Secret Data

Vo=VFB*(1+PR103/PR104)=1.203V Ton=187.68ns Freq=337KHz Cesr=15m ohm Ipeak=7.82A Imax=5.474A Delta I=((19-1.2)*(1.2/19))/(L*Freq)=1.516A Vtrip=Rtrip*10uA=165mV Iocp-min=Vtrip/(Rdsonmax*1.2)+0.758=8.4A Iocp-max=Vtrip/(Rdsontyp*1.2)+0.758=9.92A Iocp=8.4A~9.92A

Title

Deciphered Date

2

2009/07/15

Title

Size Document Number Rev

Custom

Date: Sheet

Compal Electronics, Inc.

1.2V//1.05V

KFT00 MB Schematic

1

of

44 47Tuesday, March 10, 2009

of

44 47Tuesday, March 10, 2009

of

44 47Tuesday, March 10, 2009

0.2

5

D D

PR106

0_0402_5%

SPOK<41,43,44>

+5VALWP

C C

VFB=0.75V Vo=VFB*(1+PR111/PR112)=1.829V

Freq=334KHz Cesr= ohm Ipeak=12.22 A Imax=8.554A Delta I=((19-1.8)*(1.8/19))/(L*Freq)=2.21A Vtrip=Rtrip*10uA=165mV Iocp-min=Vtrip/(Rdsonmax*1.2)+1.105=8.74A Iocp-max=Vtrip/(Rdsontyp*1.2)+1.105=10.27A Iocp=8.74A~10.27A

1 2

PR109

422_0603_1%

1 2

PC80

1U_0603_10V6K

12

PC77

0.1U_0402_16V7K@

12

PC81

47P_0402_50V8J@

1 2

PR111

17.8K_0402_1%

1 2

PR112

12.1K_0402_1%

4

PR105

240K_0402_5%

1.8V_TON

1.8V_EN

1.8V_V5FILT

1.8V_FB

240K_0402_5%

1 2

BST_1.8V BST_1.8V-1

1

14TP15

2

TON

3

VOUT

4

V5FILT

5

VFB

6

PGOOD

VBST

EN_PSV

V5DRV

GND7PGND

8

PU8

PU8 TPS51117RGYR_QFN14_3.5x3.5

TPS51117RGYR_QFN14_3.5x3.5

DRVH

LL

TRIP

DRVL

PR107

0_0603_1%

1 2

UG_1.8V

13

SW_1.8V

12 11 10

LG_1.8V

9

3

PC76

0.1U_0603_25V7K

1 2

PR110

16.5K_0402_1%

1 2

+5VALWP

12

PC82

4.7U_0805_10V6K

578

3 6

578

3 6

1.8V_IN

PQ23

PQ23 AO4466_SO8

AO4466_SO8

241

2.2UH_PCMC063T-2R2MN_8A_20%

12

PR108

4.7_1206_5%@

PQ25

12

AO4712_SO8

241

PC83

680P_0603_50V7K@

2

PL9

1 2

12

PC75

10U_1206_25V6M

PJ13

2

JUMP_43X79@

112

1

+

PC78

2

220U_D2_4VY_R15M

12

B+

+1.8VALWP

PC79

10U_0805_6.3V6M

1

+1.8V

1

PJ14

1

JUMP_43X79@

PC84

2

G

2

12

PR113

1K_0402_1%

13

D

PR116

PQ50

1K_0402_1%

SSM3K7002FU_SC70-3

S

12

PC88

0.1U_0402_16V7K

12

4

PU9

VIN1VCNTL

2

GND

3

VREF

4

VOUT

APL5331KAC-TRL_SO8

+0.9VSP

12

PC90

PC90 10U_0805_6.3V6M

10U_0805_6.3V6M

6 5

NC

7

NC

8

NC

9

TP

+3VALWP

12

PC85

PC85 1U_0603_6.3V6M

1U_0603_6.3V6M

SUSP#<30,31,39,42,44>

VFB=0.8V Imax=0.966A Ipeak=1.38A

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

3

B B

4.7U_0805_6.3V6K

PR115

SUSP<39>

Vout=Vin*R116/(R113+R116)=0.925

A A

Imax=1.4A Ipeak=2A

1 2

0_0402_5%

0.1U_0402_16V7K@

5

12

PC89

+1.8VS

0.1U_0402_16V7K@

2008/07/15

1

PJ15

1

JUMP_43X118

2

12

PC168

4.7U_0805_6.3V6K

PR268

0_0402_5%

1 2

PC171

Compal Secret Data

+5VS

12

Deciphered Date

12

PC167

1U_0603_6.3V6M

PU10

6

VCNTL

5

VIN

9

VIN

8

EN

7

POK

3

VOUT

4

VOUT

2

FB

GND

APL5913-KAC-TRL_SO8

1

2009/07/15

2

+1.5VSP

of

45 47Tuesday, March 10, 2009

of

45 47Tuesday, March 10, 2009

of

45 47Tuesday, March 10, 2009

PC170

12

PC169

1

22U_0805_6.3V6M

12

PR269

3K_0402_1%

Title

Size Document Number Rev

Custom

Date: Sheet

12

0.01U_0402_25V7K

PR270

3.4K_0402_1%

Compal Electronics, Inc.

1.8V/1.5V/0.9V

1.8V/1.5V/0.9V KFT00 MB Schematic

0.2

5

4

3

2

1

H_DPRSTP#

D D

C C

CPU_CSP1

PR132 470_0402_1%PR132 470_0402_1%

CPU_CSN1

PR136 470_0402_1%PR136 470_0402_1%

CPU_CSN2

PR137 470_0402_1%PR137 470_0402_1%

CPU_CSP2

PR138 470_0402_1%PR138 470_0402_1%

B B

PC270 470P_0402_50V7K

12

PC102

100P_0402_50V8J

12 12

PC111

100P_0402_50V8J

12

1 2

CLK_EN#<14>

1 2

PR146

100_0402_5%

@

VGATE<14>

CPU_VREF

1 2

PR130

5.11K_0402_1%

1 2

PC98 68P_0402_50V8JPC98 68P_0402_50V8J

1 2

PC99 0.22U_0603_10V7KPC99 0.22U_0603_10V7K

1 2

PC104 33P_0402_50V8JPC104 33P_0402_50V8J

1 2

PC106 33P_0402_50V8JPC106 33P_0402_50V8J

1 2

PC108 33P_0402_50V8JPC108 33P_0402_50V8J

1 2

PC112 33P_0402_50V8JPC112 33P_0402_50V8J

CPU_GNDSNS

CPU_VSNS

12

PR140

0_0402_5%

PR140

0_0402_5%

12

VSSSENSE

VCCSENSE

1 2

PR121

PR121 0_0402_5%@

0_0402_5%@

PC103

1U_0402_6.3V6K

CPU_DROOP CPU_VREF

CPU_CSP1-2

CPU_CSP1-2 CPU_CSN1-1

CPU_CSN1-1 CPU_CSN2-1

CPU_CSN2-1 CPU_CSP2-2

CPU_CSP2-2

CPU_THERM

12

PR141

0_0402_5%

PR141

0_0402_5%

PR143

PR143 20K_0402_5%

20K_0402_5%

12

PR147

PR147 100_0402_5%

100_0402_5%

<5>

+CPU_CORE

12

PR119

1

DROOP

2

VREF

3

GND

4

CSP1

5

CSN1

6

CSN2

7

CSP2

8

GNDSNS

9

VSNS

10

THERM

<5>

+3VS

12

PR120

10K_0402_5%@

1.91K_0402_1%

+3VS +5VS

12

PR235

PR124

0_0402_5%

@

12

PR123 124K_0402_1%PR123 124K_0402_1%

CPU_V5FILT

CPU_OSRSEL

CPU_ISLEW

38

39

41

40

GND

ISLEW

V5FILT

OSRSEL

PU11

TPS51620RHAR_QFN40_6X6

VR_TT#11DPRSTP#12PSI#13VID614VID515VID416VID317VID218VID119VID0

PSI#

CPU_DPRSTP#

12

PR149 0_0402_5%PR149 0_0402_5%

PR150 0_0402_5%PR150 0_0402_5%

CPU_VREF

12

PR126 0_0402_5%PR126 0_0402_5%

PR125 0_0402_5%PR125 0_0402_5%

CPU_TONSEL

CPU_TRIPSEL

36

37

TONSEL

TRIPSEL

VID5

VID6

VID4

1 2

PR152 0_0402_5%PR152 0_0402_5%

PR151 0_0402_5%PR151 0_0402_5%

VR_ON

PMON

12

@

PR127 0_0402_5%

CPU_VR_ON

34

35

PWRMON

VID3

1 2

PR153 0_0402_5%PR153 0_0402_5%

PR122 0_0402_5%PR122 0_0402_5%

VR_ON

PR154 0_0402_5%PR154 0_0402_5%

PM_DPRSLPVR_D

1 2

PR128 499_0402_1%

CPU_DPRSLPVR

CPU_CLK_EN#

31

33

32

CLK_EN#

DPRSLPVR

20

VID0

VID1

VID2

1 2

PR155 0_0402_5%PR155 0_0402_5%

PR156 0_0402_5%PR156 0_0402_5%

<31>

PGOOD DRVH1

VBST

LL1

DRVL1

V5IN

PGND

DRVL2

LL2

VBST2

DRVH2

PR157 0_0402_5%PR157 0_0402_5%

<25>

UGATE_CPU1

30

BOOT_CPU1

29

PHASE_CPU1

28

LGATE_CPU1

27

1 2

26

PC107 10U_0603_6.3V6M

25

LGATE_CPU2

24

PHASE_CPU2

23

BOOT_CPU2

22

UGATE_CPU2

21

PR133

1 2

0_0603_5%

PR139

1 2

0_0603_5%

+5VS

PD9

PD9 1SS355_SOD323-2

1SS355_SOD323-2

1 2

BOOT_CPU1-1

1 2

PC100

0.22U_0603_10V7K

+5VS

BOOT_CPU2-1

1 2

PC113

0.22U_0603_10V7K

1 2

PD10

PD10 1SS355_SOD323-2

1SS355_SOD323-2

3 5

241

PQ30

TPCA8028-H_SOP ADVANCE8

+5VS

786

5

4

PQ29

PQ29 TPCA8023-H_SO8

TPCA8023-H_SO8

3 5

241 786

5

4

PQ31

@

123

3 5

241

PQ33

SI4634DY-T1-E3_SO8

@

3 5

123

241

PQ34

TPCA8028-H_SOP ADVANCE8

PC94

10U_1206_25V6M

12

PR135

6.8_1206_5%@

CPU1_SNB

12

PC101

SI4634DY-T1-E3_SO8

680P_0603_50V7K@

12

PC109

10U_1206_25V6M

PQ32

TPCA8023-H_SO8

12

CPU2_SNB

12

PR142

6.8_1206_5%@

PC114

PC114 680P_0603_50V7K@

680P_0603_50V7K@

PC95

PC110

+CPU_B+

12

PC96

10U_1206_25V6M

2200P_0402_50V7K

12

0.36UH_PCMC104T-R36MN1R17_30A_20%

PR129

17.8K_0402_1%

1 2

PR134

28.7K_0402_1%

+CPU_B+

CPU_CSP1

10U_1206_25V6M

0.36UH_PCMC104T-R36MN1R17_30A_20%

12

PR144

17.8K_0402_1%

1 2

PR148

28.7K_0402_1%

CPU_CSP2

HCB4532KF-800T90_1812

1

+

PC97

2

100U_25V_M

1 2

PL13

PR131

69.8K_0402_1%

1 2

CPU_SN-1

1 2

PC105

0.033U_0402_16V7K

12

PL14

PR145

69.8K_0402_1%

1 2

CPU_SN-2

1 2

PC115

0.033U_0402_16V7K

PL12

1 2

PH2

100K_0603_1%_TH11-4H104FT

CPU_CSN1

PH3

100K_0603_1%_TH11-4H104FT

CPU_CSN2

B+

+CPU_CORE

<5>

<5,25>

CPU_VID6

CPU_VID5

4

<5>

CPU_VID3

CPU_VID4

CPU_VID2

CPU_VID1

H_PSI#

H_DPRSTP#

A A

5

<5>

CPU_VID0

<5>

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

3

2008/07/15

Compal Secret Data

Deciphered Date

2

2009/07/15

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

Compal Electronics, Inc.

+CPU_CORE

KFT00 MB Schematic

Tuesday, March 10, 2009

1

of

46 47

of

46 47

of

46 47

0.2

5

4

3

2

Version change list (P.I.R. List) Page 1 of 2

for PWR

Reason for change Rev. PG# Modify List Date PhaseFixed IssueItem

1

D D

1

2

3

4

5

6

7

8

C C

9

10

11

12

13

14

15

16

B B

17

Change charge current to 3.36A at Iref=3.3V change PR70 from 133K to 97.6K

change charger current sense size and value

Set charger voltage

change PQ38 ,PQ39 for EOL Change to FDS4435BZ

change PR90 ,PR91 for 3V,5V ocp set Change from 301K to 315K and 174K

change PR102 for 1.2V OCP set Change from 14.7K to 16.5K

change 1.2v from 1.225V to 1.2V follow KSWXX Change PR103 and PR104 to 18.2K and 30.1K

change PR110 for 1.8V OCP set Change from 14.7K to 16.5K

change 1.8v from 1.851V to 1.829V follow KSWXX Change PR111 and PR112 to 17.4K and 12.1K

change chgvadj risister match ec parameter Change PR66 100K to 499K

change PL13,PL14 for cost Change PL13 PL14 to Toho

modify CP point to 3.13A change PR53 from 0 to 113K ohm3

change charger current to 3A change PR70 from 97.6K to 133K ohm

change 3V OCP change PR91 from 180K to 316K ohm

adjust cpu load line change PR130 from 4.02K to 5.49 K ohm

change cpu choke footprint change choke footprint from toho to cyntec

change PR229 from 100k to 47k adjust cell pin voltage

18

19

20

21

22

A

3

A

change PR17 from 15m to 20m ohm

3

Delet PR64

3

4

5

6

3

7

A

C

change PC27 from 0.47U to 0.1Uadjust back to back mos turn off time

change PR103 from 18.2k to 20kAdjust 1.2v voltage from 1.2035V to 1.2483V for hw requet

change PR111 from 17.4k to 17.8kAdjust 1.8v voltage from 1.8285V to 1.8533V for hw request

change PR130 from 5.49k to 5.11kadjust cpu load line

change PC104 PC106 PC108 PC112 from K to J toleranceNPO must use J tolerance

23

A A

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

5

4

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

2008/07/15

3

Compal Secret Data

Deciphered Date

2

2009/07/15

Compal Electronics, Inc.

Title

Size Document Number Rev

Custom

Date: Sheet

Compal Electronics, Inc.

PIR (PWR)

KFT00 MB Schematic

1

of

47 47Tuesday, March 10, 2009

of

47 47Tuesday, March 10, 2009

of

47 47Tuesday, March 10, 2009

0.2

COMPAL LA-4821P Schematics

Specifications and Main Features

Frequently Asked Questions

User Manual
