Compal LA-3241P, Nautilus V400WH Schematic

A

B

C

D

E

1 1

Compal confidential

2 2

HGL30/HGL31 Schematics Document

Mobile Yonah uFCPGA with Intel 945GM/PM+ICH7-M

3 3

LA-3241P

REV:1.0
2006/4/28
