Page 1
USER GUIDE 1-8
COMPACT ROLLING WALKER
model number: COM 940
Page 2
About your COMODITÀ Tipo All Terrain Rolling Walker
COMODITÀ is a company concerned with your comfort, safety
and mobility. Our products will simplify your movements, offering
support and safety for your daily activities, helping you do what
you want, when you want it.
The modern patented design and sturdy construction of the
COMODITÀ Tipo All Terrain Rolling Walker (ref. COM 940) make it
one of the safest and most stylish walkers in the market.
Built to support weights of up to 300 lb, it is tested and approved
under international testing standards for walkers and rollators.
The COMODITÀ Tipo All Terrain Rolling Walker is built with the best
materials available to ensure the highest safety you can find.
In addition, the COMODITÀ Tipo All Terrain Rolling Walker comes
with the exclusive COMODITÀ Pisa removable cup holder, cane
holder and washable nylon shopping bag, as well as a convenient
travel bag.
The COMODITÀ Tipo All Terrain Rolling Walker has two 12”
aluminum front wheels, with pneumatic tires, making it very easy to
indoors and just about any terrain outdoors. It can also be easily
double folded for storage or transportation.
1
Page 3
Main Features:
Extra-large 12” aluminum front wheels and 10” rear wheels
with pneumatic tires, for safer indoor and outdoor use
Wide, comfortable nylon seat
Adjustable handle height
Padded ergonomic backrest
Removable cup holder and cane holder included
Convenient transport nylon bag
Hand brake locks for safety while sitting
Double fold construction makes it very compact and easy
to transport
Four light reflectors at the front and two at the back for
additional safety
Nylon shopping bag with light reflecting strap for added
security
Product Dimensions and Specifications
Unit weight: 22 lb (9.9 kg)
Weight capacity: 300 lb (136 kg)
Recommended user height: 5'4" to 6'4" (1,62 m to 1,90 m)
Overall height: 34” / 39” (85.5 cm / 99.5 cm)
Overall length: 29.5” (75 cm)
Overall width: 25” (63.5 cm)
Folded measurements: 36” x 13” x 19”
Front wheel diameter: 12” (30 cm)
Back wheel diameter:” (20 cm)
Seat height from floor: 22½” (57.5 cm)
Seat depth: 11” (28.5 cm)
Seat width: 17½” (44 cm)
Size of nylon bag: 17” W, 8” D, 10” H (43 cm W, 20 cm D, 25
cm H)
2
Page 4
Assembly Instructions
Assembling your COMODITÀ Tipo All Terrain Rolling
Walker is extremely simple!
1. Carefully remove the walker from the shipping carton.
2. Place the rollator on a flat surface.
3. Raise the handles to the upright position.
4. Lock the frame on both sides by bringing the folding lock
lever (pic 1) up 180 degrees, so it points up (pic 2). Turn
the folding lever 90 degrees towards the back wheel, so
it slides into the folding lock lever plastic support (pic 3).
Note: You can only slide the folding lock lever into the
plastic support if it is in the correct position, with most of
the extension of the lever very close to the plastic frame.
PIC 1 PIC 2 PIC 3
3
Page 5
5. Release the plastic locking device that holds the walker
folded.
6. Open the walker and lock it in the opened position by
pushing down the sides of the seat onto the main frame
until you hear a click.
7. Insert both sides of the nylon bag into the nylon bag
metal support.
4
Page 6
8. Insert the cup holder into its plastic support on the side of
the walker.
9. Adjust the height of the handles by standing upright
behind the walker with the shoulders relaxed and arms
hanging at your side. The handgrips should be at a
height even with your wrists.
IT IS THAT SIMPLE! NO TOOLS, NO LOOSE PARTS!
5
Page 7
Operating Instructions
TO WALK:
Position yourself behind the walker and hold both handles
firmly.
Roll your walker slowly forward so that the rear wheels are a
few inches ahead of your body.
While maintaining a steady and safe roll forward, place your
foot in line with the rear wheels.
Repeat the movement with your other foot.
To slow down, slowly squeeze the brake handles up.
To lock the brakes, push down on the brake handles until the
brakes “click” into locked position. Do not push it any further
than this point.
To unlock the brakes and resume walking, pull up the brake
handles until you hear a “click.”
TO USE THE SEAT OF YOUR WALKER:
Make sure your walker is in a flat surface, not on an incline.
LOCK the brakes before sitting.
Make sure your feet rest flat on the ground.
6
Page 8
Care and Maintenance
PERIODIC BRAKE ADJUSTMENT
To adjust the sensitivity of the brake:
To tighten the brake (reduce the gap between the brake
pad and wheel) rotate the adjusting nut clockwise.
To loosen the brake (increase the gap between the brake
and the wheel) rotate the adjusting nut counterclockwise.
WARNING!
Over adjustment of the brake might prevent the wheels from
moving freely.
Under adjustment of the brake may cause the brake pad not
to engage at all.
DO NOT USE WALKER IF BRAKES ARE NOT WORKING PROPERLY.
7
Page 9
Safety Instructions
WARNING!!! Failure to follow safety
instructions may result in serious injuries.
DO NOT use this product as a wheelchair.
DO NOT transport someone while sitting on this walker.
DO NOT exceed maximum weight capacity.
Brakes MUST be on LOCKED position before sitting on the
seat.
DO NOT self-propel the walker while seated.
DO NOT sit on the walker on an incline.
INSPECT BRAKES before each use.
DO NOT use the walker if the brakes are not working
properly.
ALL WHEELS MUST be in contact with the floor or ground
at all times.
BACKREST IS NOT intended to support your full weight. It is
intended to provide back support while you are seated.
DO NOT use in escalators, stairs, moving sidewalks or
uneven surfaces.
BOTH FEET should rest flat on the ground when sitting.
ALWAYS check if the seat is locked down and well
connected to the frame when the rollator is open.
Warranty
Your Comodità Rolling Walker is warranted to be free of defects in material and
workmanship for a period of one year from the date of purchase for the original
owner. This warranty does not cover product failure due to user negligence, misuse
of the product, failure to adhere to instructions, or normal wear and tear. In the
event of a defect covered by this warranty, we will, at our discretion, repair or
replace the product. This warranty does not include any labor or shipping charges.
