Comnet FVTDR101B User Manual

INSTALLATION AND OPERATION MANUAL

FVTDR101B Transmitter
FVRDT10M1 Receiver

VIDEO WITH RETURN DATA

The ComNet™ FVTDR101B for the Bosch dome camera system supports the

simultaneous transmission of video in one direction and pan tilt and zoom

control signals in the reverse direction.

The FVTDR101B supports RS-232 and RS-422 data signals from the receiver to

the transmitter and outputs RS-422 data into the Bosch dome. See Figure 4 on

Page 3 for Data Connection Settings.

Bi-color (Red/Green) LED indicators on the receiver are provided for rapidly

ascertaining equipment operating status. See Figure 5 on Page 3 for an

explanation of each LED indicator.

The FVTDR101B is camera mounted and powered by the camera’s internal

power supply. The module is compatible with the ComNet FVRDT10M1

receiver, which is interchangeable between stand-alone or card mount

configurations. See Figure A on Page 4 for mounting instructions.

See Figures 1 – 5 for complete installation details.

INS_FVTDR101B_FVRDT10M1_REV–

07/13/11

PAGE 1

INSTALLATION AND OPERATION MANUAL FVTDR101B/FVRDT10M1

FIGURE 1 – FVRDT10M1 RECEIVER

MULTIMODE OPTICAL FIBER

BLACK

BLACK WITH WHITE STRIPE

Power Supply:
Surface Mount: 8–15 VDC @ 350mA
Rack Mount: From Rack

FIGURE 2 – FVRDT10M1 RECEIVER

REAR PANELFRONT PANEL

NOTE: Remove Electrical

Connector for Rack Mount Units

FIGURE 3 –
FVTDR101B IN DOME TRANSMITTER

MULTIMODE
OPTICAL FIBER

TECH SUPPORT: 1.888.678.9427

INS_FVTDR101B_FVRDT10M1_REV–

07/13/11

PAGE 2
