INSTALLATION AND OPERATION MANUAL
FVT1031(M)(S)-P
10-BIT DIGITAL VIDEO WITH BI-DIRECTIONAL DATA
TRANSMITTER FOR PELCO DOME CAMERAS
The FVT1031(M)(S)-P series video transmitter along with the ComNet™
FVR1031 series receiver supports simultaneous broadcast-quality video
transmission of 10-bit digital video and bi-directional RS422 data over one
multimode or single mode optical fiber. The FVT1031(M)(S)-P is designed to
plug directly into the Pelco Spectra III/IV dome, and connects with power, video
input and two way data via the Pelco electrical connector.
See Figures 1 – 4 for complete installation details.
INS_FVT1301-P_REV–
02/05/10
PAGE 1

INSTALLATION AND OPERATION MANUAL FVT1031(M)(S)-P
FIGURE 1 – FVT1031-P TRANSMITTER
MULTIMODE OR SINGLE MODE
OPTICAL FIBER
FIGURE 2 – TOP VIEW FIGURE 3 – BOTTOM VIEW
TECH SUPPORT: 1.888.678.9427
INS_FVT1301-P_REV–
02/05/10
PAGE 2

INSTALLATION AND OPERATION MANUAL FVT1031(M)(S)-P
FIGURE 4 – MOUNTING INSTRUCTIONS
See your Pelco Spectra Dome III/IV installation manual for details of dome installation.
Remove lower dome and dome drive from Spectra III/IV
dome according to the dome’s instruction manual to reveal
the back box (A).
A
E
B
D
C
D
Open the hinged door of Spectra III/IV back box to reveal
the circuit board (B).
Carefully move the power wiring, if necessary, to allow room
for mounting the FVT1031-P transmitter to the circuit board.
Remove the plug from the 16-pin connector on the circuit
board (C).
Align the 16-pin connector on the dome circuit board with
its counterpart on the top of the FVT1031-P and plug the
header into the connector.
Using the supplied Phillips pan head screw with lock
washer, secure the transmitter into the mounting standoff
on the dome circuit board (D).
Connect the fi ber optic connector on the transmitter to the
dome’s fi ber optic adapter (E).
TECH SUPPORT: 1.888.678.9427
Close the back box and replace dome drive and lower
dome according to the dome’s instruction manual.
INS_FVT1301-P_REV–
02/05/10
PAGE 3

WARNING: Unit is to be used with a Listed Class 2 or LPS power supply rated 9-12 VDC @ 1A.
WARNING: This unit should be installed in a restricted access location; available through the use of a lock and key or other means of security. Access should
be limited to service personnel who have been instructed about the reasons for the restrictions to the location. Any and all precautions should be taken and
controlled by the authority responsible for the location.
IMPORTANT SAFEGUARDS:
A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be
greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient
temperature (Tma) specified by the manufacturer.
B) Reduced Air Flow - Installation of the equipment in a rack should be such that the amount of air flow required for safe operation of the equipment is not
compromised.
