Comnet FVT1021S1 User Manual

INSTALLATION AND OPERATION MANUAL

FVT/FVR1021(M)(S)1

10-BIT DIGITAL VIDEO WITH RETURN DATA

The FVT/FVR1021 series video transmitter/receiver and data transceiver

supports the simultaneous transmission of short-haul quality 10-bit digital

video and return data over one multimode or single mode optical fiber. This

module is universally compatible with major CCTV camera manufacturers and

supports RS232 and RS422 data interfaces as well as up-the-coax data.

Bi-color (Red/Green) LED indicators are provided for rapidly ascertaining

equipment operating status. These units are interchangeable between stand-

alone or card mount configurations. See Figure A on Page 5 for mounting

instructions.

Figures 4 through 6 on Page 3 illustrates the specific data connections for

RS232, RS422, Manchester and Bi-Phase data transmission.

Figure 7 on Page 4 describes the LED indicators for each light on the unit.

INS_FVT/FVR1021_REV–

02/05/10

PAGE 1

INSTALLATION AND OPERATION MANUAL FVT/FVR1021(M)(S)1

FIGURE 1 – FVT/FVR1021 TRANSMITTER AND RECEIVER

MULTIMODE OR SINGLE MODE
OPTICAL FIBER

BLACK

BLACK WITH WHITE STRIPES

FIGURE 2 – FVT1021 TRANSMITTER

REAR PANEL REAR PANELFRONT PANEL FRONT PANEL

Power Supply:

Surface Mount: 9-12VDC @ 1A

Rack Mount: From Rack

FIGURE 3 – FVR1021 RECEIVER

TECH SUPPORT: 1.888.678.9427

NOTE: Remove Electrical Connector for Rack Mount Units

INS_FVT/FVR1021_REV–

02/05/10

PAGE 2
