Comnet FVT10 User Manual

INSTALLATION AND OPERATION MANUAL

FVT10

VIDEO TRANSMITTER

The FVT10 single channel transmitter supports one independent AM video

signal on one independent multimode optical fiber. The FVT10 video transmitter

is compatible with the FVR10, FVR10M, FVR11, FVR11M, FVR21 and FVR22

receivers. Plug-and-play design ensures ease of installation requiring no

electrical or optical adjustments. The FVT10 is interchangeable between stand-

alone or card mount configurations.

See Figure A for mounting instructions.

INS_FVT10_REV–

12/03/10

PAGE 1

INSTALLATION AND OPERATION MANUAL FVT10

FIGURE 1 – FVT10 TRANSMITTER

OPTICAL FIBER

BLACK

BLACK WITH WHITE STRIPE

Power Supply:
Surface Mount: 8–15 VDC @ 80mA
Rack Mount: From Rack

FIGURE 2 – FVT10 TRANSMITTER

REAR PANELFRONT PANEL

FIGURE 3 – LED INDICATOR

VIDEO PRESENT

GREEN

RED

OFF

NOTE: Remove Electrical Connector for Rack Mount Units

A Video signal is
present.

No Video signal is
present.

Unit not powered up.

TECH SUPPORT: 1.888.678.9427

INS_FVT10_REV–

12/03/10

PAGE 2
