Comnet FVR81S1 User Manual

INSTALLATION AND OPERATION MANUAL

Value Line
FVT/FVR81

8-CHANNEL DIGITAL VIDEO MULTIPLEXER

The FVT/FVR81 is an eight (8) channel video transmission system. It combines

eight individual video signals into one high speed digital stream and transmits

this over one optical fiber.

These units may be directly plugged into the ComNet Rack (Part C1) or they

can operate as standalone modules. See Figure A on Page 4 for mounting

instructions.

See Figures 1 – 4 for complete installation details.

INS_FVT/FVR81_REV–

04/12/10

PAGE 1

INSTALLATION AND OPERATION MANUAL FVT/FVR81

FIGURE 1 – FVT/FVR81 TRANSMITTER AND RECEIVER

MULTIMODE OR SINGLE MODE
OPTICAL FIBER

BLACK

BLACK WITH WHITE STRIPE

FIGURE 2 – FVT81 TRANSMITTER

REAR PANEL REAR PANELFRONT PANEL FRONT PANEL

FIGURE 3 – FVR81 RECEIVER

NOTE: Remove Electrical Connector for Rack Mount Units

TECH SUPPORT: 1.888.678.9427

INS_FVT/FVR81_REV–

04/12/10

PAGE 2
