INSTALLATION AND OPERATION MANUAL

FVT/FVR240

24-CHANNEL DIGITALLY ENCODED VIDEO

The FVT/FVR240 is a twenty-four (24) channel ten (10) bit digitally encoded

video transmission system. It combines twenty-four individual video signals

into one high speed digital stream and transmits this over a one optical fiber.

The FVT/FVR240 consists of a twenty-four channel video transmitter (FVT240)

and a twenty-four channel video receiver (FVR240). Both the transmitter and

receiver are made up from four modules:

3 × 8 Channel Video Modules labeled “A” and “B”

1 × Passive Optical Wavelength Division Multiplexor (WDM)

1 × Chassis with integral power supply

The outputs of the 8 Channel Video Modules are combined at the transmitter

into a single optical signal by means of the WDM and separated out at the

receiver with an identical WDM. While the WDM has provision for five (5) different

wavelengths (colors), in this application only two wavelengths are used.

The video channels are referred to as A1, A2, etc. and B1, B2, etc. A video

input to the A3 transmitter BNC connector will be received out of the A3 BNC

on the corresponding video module.

The FVT240 and the FVR240 come completely assembled and tested from the

factory. There are no optical or electrical adjustments required or permitted.

See Figures 1 – 3 for complete installation instructions.

INS_FVT/FVR240_REVA

05/06/10

PAGE 1

INSTALLATION AND OPERATION MANUAL FVT/FVR240

FIGURE 1 – FVT240 TRANSMITTER FRONT AND REAR

Power Sources - The product should only be operated from

the ComNet C1-PS power supply.

TECH SUPPORT: 1.888.678.9427
