INSTALLATION AND OPERATION MANUAL
FVT/FVR1001(M,S)1
10-BIT DIGITAL VIDEO
This manual serves the following
ComNet Model Numbers:
FVT1001M1
FVR1001M1
FVT1001S1
FVR1001S1
The FVT/FVR1001 series video transmitter/receiver supports the transmission of
short-haul quality 10-bit digital video over one multimode or single mode optical
fiber. This module is universally compatible with major CCTV camera manufacturers.
Plug-and-play design ensures ease of installation and no electrical or optical
adjustments are ever required.
Bi-color (Red/Green) LED indicators are provided for rapidly ascertaining equipment
operating status. Figure 4 on Page 3 describes the indicators for each light on the unit.
The FVT/FVR1001 is interchangeable between stand-alone or card mount configurations, or
may be DIN-rail mounted by the addition of ComNet model DINBKT1 adaptor plate.
See Figure A on Page 4 for mounting instructions.
INS_FVT/FVR1001_REV–
01/13/12
PAGE 1
INSTALLATION AND OPERATION MANUAL FVT/FVR1001(M,S)1
FIGURE 1 – FVT/FVR1001
MULTIMODE OR SINGLE MODE
OPTICAL FIBER
BLACK
BLACK WITH WHITE STRIPE
Power Supply:
Surface Mount: 8-15 VDC @ 2W
Rack Mount: From Rack
FIGURE 3 – FVT1001 TRANSMITTERFIGURE 2 – FVR1001 RECEIVER
REAR PANEL REAR PANELFRONT PANEL FRONT PANEL
NOTE: Remove Electrical Connector
for Rack Mount Units
Tech SupporT: 1.888.678.9427
INS_FVT/FVR1001_REV–
01/13/12
PAGE 2
