10/100 Mbps Ethernet Electrical To Optical Media Converter
CNFE100(X) Series
INCLUDED CONVERTERHARDENED POWERED
The ComNet™ Ethernet CNFE100X media converter series are one-channel
Ethernet electrical to optical media converters. These auto-negotiating devices
accept a 10/100 Mbps electrical input and convert this to a 100 Mbps optical
output. This series of media converters use multimode and single-mode optical
fiber and one and two fiber SC and ST optical connectors. LED indicators confirm
operational status. All models are environmentally hardened with no electrical or
optical adjustments (Plug and Play). Packaged in the exclusive ComNet ComFit
housing, the standard size units may be either wall or rack mounted. Models within
the series are also available in a small size. The units are powered by an included
DC power supply.
FEATURES
› 10/100 Mbps Ethernet
• 10/100 BASE-T/TX electrical port
• 100 BASE-FX optical port
› Electrical port supports Auto-Negotiation for 10 Mbps or
100 Mbps, full duplex or half duplex data.
› Optical port suppor ts 100 Mbps full duplex data
› Automatic MDI/MDI-X crossover
› Distances up to: 3 km (2 mi) Multimode
20 km (12 mi) Single Mode
› Transparent to data encoding/compatible with major data
protocols
› Tested and certified by an independent laboratory for full
compliance with the environmental requirements (ambient
operating temperature, mechanical shock, vibration, humidity
with condensation, high-line/low-line voltage conditions
and transient voltage protection) of NEMA TS-1/TS-2 and
CALTRANS Traffic Signal Control Equipment Specifications
› ST or SC optical connectors
› 1 or 2 fiber design
› AC/DC powered
› Voltage transient protection on all power and signal input/
output lines provides protection from power surges and
other voltage transient events.
› No in-field optical adjustments required
› LED Indicators
› Standard size is hot-swappable rack module
› Standard size is interchangeable between stand-alone or
rack mount use – ComFit
› IEEE 802.3 compliant
› Lifetime Warranty
APPLICATIONS
› 10/100 Mbps Ethernet Media Converter
› High Speed Computer Links
LIFETIME WARRANTY WWW.COMNET.NET TECH SUPPORT: 1.888.678.9427
CNFE100(X) Series
SPECIFICATIONS
10/100 Mbps Ethernet Electrical To Optical Media Converter
Ethernet
Data Rate 10/100 Mbps
IEEE 802.3 Compliant
Full Duplex or Half Duplex Electrical Port/Full Duplex Optical
Port
Connectors
Optical ST or SC, 1 or 2 Fibers
Power Terminal Block
Electrical RJ45
LED Indicators
- Optical Link/Data Activity
- Electrical Link/Data Activity
- Power
Power
Operating Voltage Range Mini AC: 22 to 27 VAC
Mini DC: 8 to 24 VDC
Standard: 8 to 24 VDC
Power Consumption Mini AC: 3W
Mini DC: 6W
Standard: 6W
Electrical & Mechanical
Current Protection Automatic Resettable Solid-State Current Limiters
Circuit Board Meets IPC Standard
Size (L×W×H) Standard: 6.1 × 5.3 × 1.1 in (15.5 × 13.5 × 2.8 cm)
Mini: 3.3 × 2.5 × 1.1 in (8.4 × 6.4 × 2.8 cm)
Shipping Weight: <2 lbs./0.9 kg
Environmental
MTBF >100,000 hours
Operating Temp -40˚ C to +75˚ C
Storage Temp -40˚ C to +85˚ C
Relative Humidity 0% to 95% (non-condensing)
[1] May be extended to humidity with condensation conditions by
adding suffix ‘/C’
1
TYPICAL APPLICATION
CNFE1002M1A
Optical Fiber
(Fiber count, mode, distance and connector
type are model dependent)
CNFE1002M1B
EE
CAT-5 CABLE
OPTICAL FIBER
LIFETIME WARRANTY WWW.COMNET.NET TECH SUPPORT: 1.888.678.9427
CNFE100(X) Series
10/100 Mbps Ethernet Electrical To Optical Media Converter
ORDERING INFORMATION – Standard Mount DC-Only Media Converter
Optical
Fibers
Part Number Description Connector
CNFE1002M1A 10/100 Mbps Ethernet 1310/1550nm ST 1 Multimode 10 dB 3 km (2 miles) 1
CNF E1002M1B 10/100 Mbp s Ethernet 1550/1310 nm ST 1 Multimode 10 dB 3 km (2 miles) 1
CNFE1002S1A 10/100 Mbps Eth ernet 1310/1550 nm ST 1 Singlemode 15 dB 20 km (12 miles) 1
CNFE1002S1B 10/100 Mbps Etherne t 1550/ 1310nm ST 1 Singlemode 15 dB 20 km (12 miles) 1
CNFE1003M2 10/100 Mbps Etherne t 1310nm SC 2 Multimode 10 dB 3 km (2 miles) 1
CNFE1003S2 10/100 Mbps Etherne t 1310nm SC 2 Singlemode 15 dB 20 km (12 miles) 1
CNFE1004M1A 10/100 Mbps Etherne t 1310/1550nm SC 1 Multimode 10 dB 3 km (2 miles) 1
CNF E1004M1B 10/100 Mbp s Ethernet 1550/ 1310nm SC 1 Multimode 10 dB 3 km (2 miles) 1
CNFE1004S1A 10/ 100 Mbps Ethern et 1310/1550 nm SC 1 Singlemode 15 dB 20 km (12 miles) 1
CNF E1004S1B 10/100 Mbps Ethern et 1550/1310 nm SC 1 Singlemode 15 dB 20 km (12 miles) 1
CNFE1005M2 10/100 Mbps Etherne t 1310nm ST 2 Multimode 10 dB 3 km (2 miles) 1
CNFE1005S2 10/100 Mbps Etherne t 1310nm ST 2 Singlemode 15 dB 20 km (12 miles) 1
Accessories
Options
DC Plug-in Power Supply, 90-264 VAC , 50/60 Hz (Included)
Add ‘/C’ for Conformally Coated Circuit Boards (Extra charge, consult f actory)
DIN-Rail Mounting Adaptor Plate Kit – With mounting hardware (Optional, order model DINBKT1 or DINBKT4)
Req’d Fiber
Pwr
Budget Max Distance
#
Rack
Slots
ORDERING INFORMATION – Mini AC/DC Power Media Converter
Optical
Fibers
Part Number Description Connector
CNFE1002MAC1A-M 10/100 Mbps Ethernet 1310/1550nm ST 1 Multimode 10 dB 3 km (2 miles) N/A
CNF E1002M AC1B-M 10/100 Mbps Ethernet 1550/1310nm ST 1 Multimode 10 dB 3 km (2 miles) N/A
CNFE1002SAC1A-M 10/100 Mbps Ethernet 1310/1550nm ST 1 Singlemode 15 dB 20 km (12 miles) N/A
CNFE1002SAC1B-M 10/100 Mbps Ethernet 1550/1310nm ST 1 Singlemode 15 dB 20 km (12 miles) N/A
CNFE10 03MAC2-M 10/100 Mbps Ethernet 1310nm SC 2 Multimode 10 dB 3 km (2 miles) N/A
CNFE10 03SAC2-M 10/100 Mbps Ethernet 1310nm SC 2 Singlemode 15 dB 20 km (12 miles) N/A
CNFE1004MAC1A-M 10/100 Mbps Ethernet 1310/1550nm SC 1 Multimode 10 dB 3 km (2 miles) N/A
CNF E1004MAC1B-M 10/100 Mbps Ethernet 1550/1310nm SC 1 Multimode 10 dB 3 km (2 miles) N/A
CNFE1004SAC1A-M 10/100 Mbps Ethernet 1310/1550nm SC 1 Singlemode 15 dB 20 km (12 miles) N/A
CNF E1004SAC 1B-M 10/100 Mbps Ethernet 1550/1310nm SC 1 Singlemode 15 dB 20 km (12 miles) N/A
CNFE10 05MAC2-M 10/100 Mbps Ethernet 1310nm ST 2 Multimode 10 dB 3 km (2 miles) N/A
CNFE10 05SAC2-M 10/100 Mbps Ethernet 1310nm ST 2 Singlemode 15 dB 20 km (12 miles) N/A
Accessories
Options
DC Plug-in Power Supply, 90-264 VAC , 50/60 Hz (Included)
Add ‘/C’ for Conformally Coated Circuit Boards (Extra charge, consult f actory)
DIN-Rail Mounting Adaptor Plate Kit – With mounting hardware (Optional, order model DINBKT1 or DINBKT4)
Req’d Fiber
Pwr
Budget Max Distance
#
Rack
Slots
