ceiling, pendant and surface mount loudspeakers
commercial design series
commercial design series
CEILING MOUNT SYSTEMS
PENDANT MOUNT SYSTEMS
cost-effective solutions
Ceiling, Pendant and Surface Mount
Loudspeaker Series
One Family. Uniform Sound.
Extraordinary value.
Commercial Design ceiling loudspeakers include a standard prole
4.5-inch, 6.5-inch and 8-inch two-way model, as well as a low prole
4.5-inch loudspeaker in a shallow back can. The 6.5-inch model is
also available in a standard black nish version for nightclubs, bars,
restaurants or any application requiring a black ceiling system.
These are true coaxial loudspeakers, which means a real compression
driver is concentrically arranged so that the upper frequencies emerge
through the center of the low-frequency driver’s magnetic structure
and cone via a precisely tapered Tru-Phase™ high-frequency waveguide.
This special construction provides consistent, wide dispersion up to
16 kHz, all but eliminating high-frequency narrowing. Reection and
diffraction problems at multiple frequencies, often found in ceiling
loudspeakers at this price point attempting to emulate a true coaxial
design, are altogether eliminated. CDS ceiling systems feature a genuine
coaxial design using separate magnets for the LF and HF drivers for
reduced distortion and high sensitivity, thereby permitting up to 3 dB
greater output level while requiring up to half the amplication power
of competing products. If deeper low frequency response is required, a
D10SUB or DS8SUB subwoofer from Community’s Distributed Design
Series family may be added.
Commercial Design ceiling loudspeaker systems are designed with
place-through-the-cutout Tile Support Bridge Rails and their snap-on
spacers, as well as Drop-Stop™ installation assistant tabs to facilitate
quick installation. Since the loudspeaker is pre-assembled in the back
can with its crossover network, and pre-wired to an external Euro
connector, the installer can simply insert a unit into the ceiling to snap it
in place. This leaves both hands free to tighten the two clamp actuator
screws, adjust the front-face power setting dial, and snap on the grille.
In addition, the Commercial Design family includes a 6.5-inch full-range
pendant mount loudspeaker utilizing the same components as the
6.5-inch C6 ceiling model and CS6 surface mount model. Featuring the
same high sensitivity and realistic sound reproduction, the CP6 pendant
loudspeaker is also equipped with a built-in autoformer, allowing the
full loudspeaker output to be realized with 70V or 100V distribution
lines. An easy-access selector switch is conveniently located on the face
of the loudspeaker for selectable 8 ohm or 70V/100V operation, while
an integrated rear cover hides all wiring and hanging hardware for an
aesthetically pleasing installation.
Two 15-foot (4.5m) long 2mm (0.77”) high tensile galvanized steel
wire rope suspension cables with integrated spring clips for attaching
the cable to the enclosure are included, along with Gripple
adjustable height cable fasteners. Optional accessories include 30ft
(9.1m) and 50ft (15.2m) hang kits, replacement Gripple speed clamps
and trimmable 14ft (4.3m) decorative split loom tubing.
The CP6 is designed for open architecture spaces or any location
where a stylish pendant form factor is desired, providing high quality
paging and musical performance suitable for retail environments,
restaurants, resorts, and numerous other applications.
®
brand
The Commercial Design Series (CDS) is a comprehensive family of cost-effective ceiling, pendant and
surface mount loudspeakers that deliver exceptionally high quality sound, with predictable and uniform
coverage. Comprised of 4.5-inch, 6.5-inch and 8-inch form factors, all members of the Commercial
Design Series share similar high performance components for uniform voicing throughout the series.
This means that various members of the CDS family can be combined in a single installation without
compromising consistency from zone to zone. CDS loudspeakers further benet from similar voicing
and acoustic performance to Community’s premium Distributed Design Series, allowing consistency
in applications where members of both loudspeaker families are used. CDS loudspeakers are easy
to install with labor-saving features and are very competitively priced for loudspeaker systems in its
performance class.
All ceiling models in the Commercial Design Series are ETL listed to
comply with UL1480, UL2043 and CSA60065, with quality assured
by Community’s long history of building high performance, durable
loudspeakers for sound reinforcement and contracting applications.
Each model accommodates 8-ohm as well as 70V/100V applications.
All Commercial Design models feature Community’s
Tru-Phase™ high frequency waveguide for greater
coverage consistency. Upper frequencies emerge
through the center of the LF driver’s magnetic structure
and cone through this proprietary phase plug to deliver
consistent, wide dispersion up to 16 kHz.
SURFACE MOUNT SYSTEMS
Surface mount loudspeakers in the Commercial Design Series include
two-way 4.5-inch, 6.5-inch and 8-inch full-range loudspeakers in
standard black and white nishes. Easily outperforming loudspeakers of
a larger size format, the CS4, CS6 and CS8 provide high power handling,
high sensitivity and realistic sound reproduction.
These loudspeakers feature a modern, streamlined design and are
equipped with a built-in autoformer, allowing large numbers of
distributed loudspeakers to be powered from a 70V or 100V amplier
output. The black or white cabinets are furthermore easy to customize
since they accept a wide variety of paints. For durability and improved
sonic quality, these longitudinally cross-braced cabinets have thick-walls
and internally reinforced ABS plastic construction. This high-impact
strength construction and internal ribbing reduces resonances. A
convenient front-accessible power tap switch is hidden behind a
rotatable logo. Installation is simple and exible using the included
multi-angle pan-tilt bracket which allows low prole mounting and
precise positioning of the enclosure in either horizontal or vertical
orientation.
TIME-SAVING INSTALLATION FEATURES
APPLICATIONS
• Convention centers, exhibit halls
• Corporate training rooms
• Hotels, ballrooms
• Athletic venues, sports facilities, health clubs
• Houses of worship
• Airports, transportation facilities
• Retail environments, shopping malls
• Nightclubs, bars, restaurants
FEATURES
• Comprehensive family of ceiling, pendant and surface mount
loudspeakers with similar components and uniform voicing
• True coaxial loudspeakers with HF compression drivers
• High intelligibility with exceptional uniform coverage
• High efciency, high output, low distortion
• Tru-Phase™ high frequency waveguide
• Selectable 8 ohm or 70V/100V operation
• Same components and similar voicing as the premium
Distributed Design Series from Community
Commercial Design Series
specifications
Model C4LP C4 CS4
Loudspeaker Type Ceiling mount (low prole), full-range Ceiling mount, full-range Surface mount, full-range
Drivers LF 1 x 4.5", HF 1 x ¾" LF 1 x 4.5", HF 1 x ¾" LF 1 x 4.5", HF 1 x ¾"
Operating Range (±10 dB) 90 Hz - 13.5 kHz 75 Hz - 13.5 kHz 70 Hz - 13.5 kHz
Max Input Power Rating 60W continuous, 150W program 60W continuous, 150W program 60W continuous, 150W program
Sensitivity (1W/1m) 91 dB SPL 91 dB SPL 90 dB SPL
Nominal -6 dB Beamwidth 140° conical 140° conical 140° conical
Available 70V Taps 8W, 4W, 2W, 1W 8W, 4W, 2W, 1W 30W, 15W, 7.5W, 3.75W
Available 100V Taps 16W, 8W, 4W, 2W 16W, 8W, 4W, 2W 30W, 15W, 7.5W
Nominal Impedance 8 ohms 8 ohms 8 ohms
Enclosure Corrosion-resistant zinc plated steel Corrosion-resistant zinc plated steel ABS plastic, matte nish, paintable
Finish White White Black or white
Included Accessories Tile support bridge rails, grille, paint mask,
Optional Accessories Can Adapter/Trim Ring (white),
Input Connections 4-pole Euroblock connector with two-pair
4.5-INCH FORMAT6.5-INCH FORMAT8-INCH FORMAT
Safety ETL listed to comply with UL1480, UL2043
Dimensions (H x W x D) 8.3" x 8.3" x 3.6" (211 x 211 x 92 mm) 8.3" x 8.3" x 5.5" (211 x 211 x 140 mm) 6.4" x 9.6" x 6.5" (162 x 243 x 164 mm)
cut-out template, screwdriver
New Construction Bracket
of non-interrupt parallel connections
and CSA60065. Suitable for air handling
spaces per NFPA 70 & NFPA 90.
Model C6 CS6 CP6
Loudspeaker Type Ceiling mount, full-range Surface mount, full-range Pendant mount, full-range
Drivers LF 1 x 6.5", HF 1 x ¾" LF 1 x 6.5", HF 1 x ¾" LF 1 x 6.5", HF 1 x ¾"
Operating Range (±10 dB) 70 Hz - 13.5 kHz 65 Hz - 13.5 kHz 70 Hz - 13.5 kHz
Max Input Power Rating 60W continuous, 150W program 60W continuous, 150W program 60W continuous, 150W program
Sensitivity (1W/1m) 91 dB SPL 90 dB SPL 91 dB SPL
Nominal -6 dB Beamwidth 120° conical 120° conical 120° conical
Available 70V Taps 30W, 15W, 7.5W, 3.75W 30W, 15W, 7.5W, 3.75W 30W, 15W, 7.5W, 3.75W
Available 100V Taps 30W, 15W, 7.5W 30W, 15W, 7.5W 30W, 15W, 7.5W
Nominal Impedance 8 ohms 8 ohms 8 ohms
Enclosure Corrosion-resistant zinc plated steel ABS plastic, matte nish, paintable ABS plastic, matte nish, paintable
Finish Black or white Black or white Black or white
Included Accessories Tile support bridge rails, grille, paint mask,
Optional Accessories Can Adapter/Trim Ring (white or black),
Input Connections 4-pole Euroblock connector with two-pair
Safety ETL listed to comply with UL1480, UL2043
Dimensions (H x W x D) 9.8" x 9.8" x 6.5" (249 x 249 x 165 mm) 7" x 11.8" x 10.7" (177 x 300 x 272 mm) 13.6" x 10" x 10" (346 x 254 x 254 mm)
cut-out template, screwdriver
New Construction Bracket
of non-interrupt parallel connections
and CSA60065. Suitable for air handling
spaces per NFPA 70 & NFPA 90.
Tile support bridge rails, grille, paint mask,
cut-out template, screwdriver
Can Adapter/Trim Ring (white),
New Construction Bracket
4-pole Euroblock connector with two-pair
of non-interrupt parallel connections
ETL listed to comply with UL1480, UL2043
and CSA60065. Suitable for air handling
spaces per NFPA 70 & NFPA 90.
Low prole multi-angle pan-tilt bracket,
IP56 rated connector cover
None 30ft (9.1m) and 50ft (15.2m) pendant hang
4-pole Euroblock connector with two-pair
of non-interrupt parallel connections
Built-in safety cable attachment eyebolt ETL listed to comply with UL1480 &
Low prole multi-angle pan-tilt bracket,
IP56 rated connector cover
None
4-pole Euroblock connector with two-pair
of non-interrupt parallel connections
Built-in safety cable attachment eyebolt
Two pendant hang kits, ABS plastic rear
cover, rear cover ingress weather plug
kits, replacement Gripple
trimmable 14ft (4.3m) decorative split loom
tubing
Two 2-pole Euroblock connectors
CSA60065. Gripple
& cable fastener listed per UL1598 and
UL2239, TUV and CSA Class 3426-01 &
Class 3426-81. Included safety cable with
SWL of 99 lbs (45 kg).
®
speed clamp,
®
suspension system
Model C8 CS8
Loudspeaker Type Ceiling mount, full-range Surface mount, full-range
Drivers LF 1 x 8", HF 1 x ¾" LF 1 x 8", HF 1 x ¾"
Operating Range (±10 dB) 65 Hz - 13.5 kHz 45 Hz - 13.5 kHz
Max Input Power Rating 60W continuous, 150W program 60W continuous, 150W program
Sensitivity (1W/1m) 91 dB SPL 89 dB SPL
Nominal -6 dB Beamwidth 120° conical 110° conical
Available 70V Taps 30W, 15W, 7.5W, 3.75W 30W, 15W, 7.5W, 3.75W
Available 100V Taps 30W, 15W, 7.5W 30W, 15W, 7.5W
Nominal Impedance 8 ohms 8 ohms
Enclosure Corrosion-resistant zinc plated steel ABS plastic, matte nish, paintable
Finish White Black or white
Included Accessories Tile support bridge rails, grille, paint mask,
Optional Accessories Can Adapter/Trim Ring (white),
Input Connections 4-pole Euroblock connector with two-pair
Safety ETL listed to comply with UL1480, UL2043
Dimensions (H x W x D) 11.3" x 11.3" x 7.6" (287 x 287 x 192 mm) 9.7" x 13.8" x 12.4" (247 x 350 x 315 mm)
cut-out template, screwdriver
New Construction Bracket
of non-interrupt parallel connections
and CSA60065. Suitable for air handling
spaces per NFPA 70 & NFPA 90.
Low prole multi-angle pan-tilt bracket,
IP56 rated connector cover
None
4-pole Euroblock connector with two-pair
of non-interrupt parallel connections
Built-in safety cable attachment eyebolt
Community Professional Loudspeakers
333 East Fifth Street
Chester, PA 19013-4511 USA
Phone (610) 876-3400
Fax (610) 874-0190
info@communitypro.com
communitypro.com
9APR2013
Loading...
