MRF150

RF Power FET
150W, to 150MHz, 50V

Designed primarily for linear large-signal output stages u p
to 150 MHz

• Superior high order IMD

IMD(d3) (150W PEP): –32dB (Typ.)
IMD(d11) (150W PEP): –60dB (Typ.)

• Specified 50V, 30MHz characteristics

Output power = 150 Watts
Power gain = 17 dB (Typ.)
Efficiency = 45% (Typ.)

• 100% tested for load mismatch at all phase angles
